Fujitsu WSYA050ML3 Service manual

AIR TO WATER
Comfort series
DESIGN & TECHNICAL MANUAL
Split type
HYDRAULIC
INDOOR
WSYA050ML3
WSYA080ML3
WSYA100ML3
OUTDOOR
WOYA060KLT WOYA080KLT WOYA100KLT
DA_CF002EF_07
2021.01.25

Notices:
• Product specifications and design are subject to change without notice for future improvement.
• For further details, please check with our authorized dealer.
Copyright © 2020, 2021 Fujitsu General Limited. All rights reserved.

CONTENTS
1. OUTDOOR UNIT
2. HYDRAULIC INDOOR UNITS
3. CONTROL SYSTEM

1. OUTDOOR UNIT
2021.01.25
DA_CH01_CF001EF_06

CONTENTS
1. OUTDOOR UNIT
1. Combination ................................................................................................01-1
2. Specifications..............................................................................................01-2
2-1. Nominal capacity and nominal input ...............................................................................01-2
2-2. Technical specifications..................................................................................................01-3
2-3. Product fiche...................................................................................................................01-4
2-4. Product information ........................................................................................................01-5
2-5. Electrical specifications...................................................................................................01-6
3. Dimensions..................................................................................................01-7
3-1. Model: WOYA060KLT ....................................................................................................01-7
3-2. Model: WOYA080KLT ....................................................................................................01-8
3-3. Model: WOYA100KLT ....................................................................................................01-9
4. Installation space ......................................................................................01-10
4-1. Models: WOYA060KLT and WOYA080KLT .................................................................01-10
4-2. Model: WOYA100KLT ..................................................................................................01-13
5. Piping diagrams ........................................................................................01-16
5-1. Models: WOYA060KLT and WOYA080KLT .................................................................01-16
5-2. Model: WOYA100KLT ..................................................................................................01-17
6. Wiring diagrams ........................................................................................01-18
6-1. Models: WOYA060KLT and WOYA080KLT .................................................................01-18
6-2. Model: WOYA100KLT ..................................................................................................01-18
7. External input and output (For WOYA100KLT).......................................01-19
7-1. External input................................................................................................................01-19
7-2. External output .............................................................................................................01-21
8. Function settings (For WOYA100KLT) ....................................................01-23
8-1. Control PCB and switch buttons location......................................................................01-23
8-2. Local setting procedure ................................................................................................01-25
9. Heating capacity table ..............................................................................01-27
9-1. Model: WOYA060KLT (5 kW).......................................................................................01-27
9-2. Model: WOYA060KLT (6 kW).......................................................................................01-27
9-3. Model: WOYA080KLT ..................................................................................................01-28
9-4. Model: WOYA100KLT ..................................................................................................01-28
10. Cooling capacity table ..............................................................................01-29
10-1.Model: WOYA060KLT (5 kW)......................................................................................01-29
10-2.Model: WOYA060KLT (6 kW)......................................................................................01-29
10-3.Model: WOYA080KLT .................................................................................................01-29
10-4.Model: WOYA100KLT .................................................................................................01-29
11. Operation noise (sound pressure)...........................................................01-30
11-1.Noise level curve .........................................................................................................01-30
11-2.Sound level check point...............................................................................................01-32

12. Operation range ........................................................................................01-33
12-1.Models: WOYA060KLT, WOYA080KLT, and WOYA100KLT......................................01-33
13. Safety devices ...........................................................................................01-34
14. Accessories ...............................................................................................01-35
CONTENTS (continued)

1. Combination
Class Outdoor unit Hydraulic indoor unit
5.0 kW WOYA060KLT WSYA050ML3
6.0 kW WOYA060KLT WSYA080ML3
8.0 kW WOYA080KLT WSYA080ML3
10.0 kW WOYA100KLT WSYA100ML3
- (01-1) - 1. Combination
OUTDOOR UNIT OUTDOOR UNIT

2. Specifications
2-1. Nominal capacity and nominal input
Model name
Hydraulic indoor unit WSYA050ML3 WSYA080ML3 WSYA100ML3
Outdoor unit WOYA060KLT WOYA060KLT WOYA080KLT WOYA100KLT
Power supply 1 Ø 230 V ~ 50 Hz
-15°C/+45°C
Heating capacity Nominal kW 3.50 4.00 5.00 7.50
Input power Nominal kW 1.81 2.05 2.62 3.75
COP Nominal 1.93 1.95 1.91 2.00
-10°C/+55°C
Heating capacity Nominal kW 3.75 4.00 5.00 7.10
Input power Nominal kW 2.19 2.31 2.96 4.06
COP Nominal 1.71 1.73 1.69 1.75
-10°C/+35°C
Heating capacity Nominal kW 4.00 4.50 5.60 8.20
Input power Nominal kW 1.49 1.69 2.38 3.35
COP Nominal 2.68 2.67 2.35 2.45
-7°C/+35°C
Heating capacity Nominal kW 4.40 5.00 5.70 8.90
Input power Nominal kW 1.59 1.90 2.13 3.36
COP Nominal 2.76 2.63 2.68 2.65
-7°C/+55°C
Heating capacity Nominal kW 3.90 4.25 5.30 8.00
Input power Nominal kW 2.11 2.25 2.79 4.10
COP Nominal 1.85 1.89 1.90 1.95
+2°C/+35°C
COP priority
Heating capacity Nominal kW 2.50 3.40 4.50
Input power Nominal kW 0.651 0.863 1.14
COP Nominal 3.84 3.94 3.95
Capacity priority
Heating capacity Nominal kW 4.50 5.30 6.30 9.30
Input power Nominal kW 1.33 1.65 1.96 3.08
COP Nominal 3.39 3.22 3.21 3.02
+7°C/+35°C
Heating capacity
Minimum
kW
1.93 1.97 3.56
Nominal 4.50 5.50 7.50 9.50
Maximum 7.75 9.37 9.85 15.29
Input power Nominal kW 0.949 1.18 1.69 2.11
COP Nominal 4.74 4.65 4.43 4.50
+7°C/+45°C
Heating capacity Nominal kW 4.50 5.50 7.50 9.00
Input power Nominal kW 1.26 1.54 2.20 2.475
COP Nominal 3.57 3.56 3.41 3.45
+7°C/+55°C
Heating capacity Nominal kW 4.50 5.50 7.00 9.00
Input power Nominal kW 1.70 2.06 2.63 3.33
COP Nominal 2.64 2.67 2.66 2.70
NOTE: Test conditions are complied with EN14511-2
2-1. Nominal capacity and nominal input - (01-2) - 2. Specifications
OUTDOOR UNIT OUTDOOR UNIT

2-2. Technical specifications
Outdoor unit model name WOYA060KLT WOYA080KLT WOYA100KLT
Enclosure
Material Steel sheet
Color Beige
Approximate color of Munsell 10YR 7.5/1.0NN
Dimensions
(H × W × D)
Net mm 632 × 799 × 290 716 × 820 × 315 998 × 940 × 320
Gross 692 × 940 × 375 776 × 961 × 450 1,176 × 1,027 × 445
Weight Net kg 39 42 65
Gross 43 46 71
Heat exchanger
Dimensions
(H × W × D) mm 588 × 881 × 36.38 672 × 881 × 36.38 966 × 905 × 36.38
Fin pitch 1.3 1.45
Rows × Stages 2 × 28 2 × 32 2 × 46
Pipe type Copper
Fin type Type (Material) Corrugate (Aluminum)
Surface treatment Corrosion resistance
Fan
Airflow rate Heating m3/h 2,100 3,120 4,130
Type × Q'ty Propeller fan × 1
Discharge direction Horizontal
Motor quantity 1
Motor output W 49 120
Compressor Type DC 2 rotary × 1
Motor output W 1,200 2,180
Operation range
Heating Minimum °CDB -20
Maximum °CWB 35
Sanitary water Minimum °CDB -20
Maximum °CWB 35
Refrigerant
Type (Global Warming Potential) R32 (675)
Charge g 970 1,020 1,630
Control Expansion valve (electric type)
Number of circuits 1
Refrigerant oil Type RmM68AF
Charged volume l 0.55 0.80
Connection pipe
Connection method Liquid mm Flare connection
Gas Flare connection
Size (standard) Liquid mm Ø6.35 Ø9.52
Gas Ø12.70 Ø15.88
Pre-charge length
m
15 20
Max. length 30
Min. length 3.0
Additional refrigerant charge g/m 25 20
Max. height difference m 20
Defrost method Reverse cycle
Defrost control Outdoor unit heat exchanger temperature sensor
Capacity control method Inverter control
2-2. Technical specifications - (01-3) - 2. Specifications
OUTDOOR UNIT OUTDOOR UNIT

2-3. Product fiche
Model name
Hydraulic indoor unit WSYA050ML3 WSYA080ML3 WSYA100ML3
Outdoor unit WOYA060KLT WOYA060KLT WOYA080KLT WOYA100KLT
Temperature application °C 55 35 55 35 55 35 55 35
Declared load profile — — — — — — — —
Seasonal space heating energy efficiency class A++ A+++ A++ A+++ A++ A+++ A++ A+++
Water heating energy efficiency class — — — — — — — —
Rated heat output kW 5 5 5 6 6 7 8 9
Supplementary heater kW 3 3 3 3 3 3 3 3
Annual energy consumption kWh 3,035 2,322 3,411 2,594 3,903 2,982 5,083 3,875
Annual electricity consumption kWh — — — — — — — —
Annual fuel consumption GJ Not applicable
Seasonal space heating energy efficiency % 125 175 125 175 128 177 130 178
Water heating energy efficiency % — — — — — — — —
Sound power level Hydraulic unit dB 40 — 40 — 40 — 40 —
Work only during off-peak hours Not applicable
Specific precautions in assembled, installed, or maintained Refer to the installation and operating manuals.
Rated heat output Colder climate kW — — — — — — — —
Warmer climate kW 5 6 5 6 6 6 8 8
Annual energy consumption Colder climate kWh — — — — — — — —
Warmer climate kWh 1,772 1,253 1,809 1,351 1,911 1,294 2,632 1,795
Annual electricity consumption Colder climate kWh — — — — — — — —
Warmer climate kWh — — — — — — — —
Seasonal space heating energy efficiency Colder climate % — — — — — — — —
Warmer climate % 157 236 156 230 159 228 162 235
Water heating energy efficiency Colder climate % — — — — — — — —
Warmer climate % — — — — — — — —
Sound power level Outdoor unit dB 57 — 57 — 60 — 62 —
NOTES:
• Product fiche according to Commission Delegated Regulation (EU) 811/2013
• Acoustic noise information:
– The maximum sound pressure level is less than 70 dB (A) for both hydraulic unit and outdoor unit.
– According to IEC 704-1 and ISO 3744.
• If the air to water heat pump is operated under higher temperature conditions than those listed, the built-in protection circuit may operate to prevent internal circuit damage. Also, during
cooling modes, if the unit is used under conditions of lower temperatures than those listed above, the heat exchanger may freeze, leading to water leakage and other damage.
• Do not use this unit for any purposes other than the Heating and Cooling.
2-3. Product fiche - (01-4) - 2. Specifications
OUTDOOR UNIT OUTDOOR UNIT

2-4. Product information
Model name
Hydraulic indoor unit WSYA050ML3 WSYA080ML3 WSYA100ML3
Outdoor unit WOYA060KLT WOYA060KLT WOYA080KLT WOYA100KLT
Air-to-water heat pump Yes
Water-to-water heat pump No
Brine-to-water heat pump No
Low-temperature heat pump No
Equipped with a supplementary heater Yes
Heat pump combination heater No*1
Temperature application °C 55 35 55 35 55 35 55 35
Rated heat output*2Prated kW 5 5 5 6 6 7 8 9
Seasonal space heating energy efficiency ƞs % 125 175 125 175 128 177 130 178
Declared capacity for heating for part load at indoor temperature 20 °C and outdoor temperature Tj
Tj = –7°C Pdh kW 4.2 4.4 4.7 5.0 5.5 5.8 7.3 7.5
Tj = +2°C Pdh kW 2.5 2.7 2.9 3.0 3.3 3.5 4.4 4.6
Tj = +7°C Pdh kW 1.9 2.1 1.8 2.1 2.1 2.3 3.6 3.9
Tj = +12°C Pdh kW 2.3 2.4 2.3 2.4 2.4 2.5 7.3 7.5
Tj = bivalent temperature Pdh kW 4.2 4.4 4.7 5.0 5.5 5.8 7.1 7.3
Tj = operation limit temperature Pdh kW 3.8 4.0 4.0 4.5 5.0 5.6 55 35
Tj = –15°C (if TOL < –20°C) Pdh kW — — — — — — — —
Bivalent temperature Tbiv °C -7 -7 -7 -7 -7 -7 -7 -7
Cycling interval capacity for heating Pcych kW Not applicable
Degradation co-efficient*3Cdh 0.9 0.9 0.9 0.9 0.9 0.9 0.9 0.9
Declared coefficient of performance or primary energy ratio for part load at indoor temperature 20 °C and outdoor temperature Tj
Tj = –7°C COPd1.99 2.84 1.97 2.74 1.91 2.70 2.05 2.98
Tj = +2°C COPd3.11 4.40 3.11 4.38 3.18 4.35 3.24 4.46
Tj = +7°C COPd4.25 5.85 4.29 6.04 4.52 6.32 4.47 5.89
Tj = +12°C COPd5.91 7.39 6.06 7.43 6.37 8.07 5.97 7.14
Tj = bivalent temperature COPd1.99 2.84 1.97 2.74 1.91 2.70 2.05 2.98
Tj = operation limit temperature COPd1.71 2.68 1.73 2.67 1.69 2.35 1.72 2.71
Tj = –15°C (if TOL < –20°C) COPd————————
Operation limit temperature TOL °C -10 -10 -10 -10 -10 -10 -10 -10
Cycling interval efficiency COPcyc Not applicable
Heating water operating limit temperature WTOL °C 55 55 55 55 55 55 55 55
Power consumption in modes other than active mode
Off mode POFF kW 0.004 0.004 0.004 0.004 0.004 0.004 0.004 0.004
Thermostat-off mode PTO kW 0.013 0.012 0.013 0.012 0.014 0.014 0.021 0.020
Standby mode PSB kW 0.010 0.010 0.010 0.010 0.010 0.010 0.008 0.008
Crankcase heater mode PCK kW 0.000 0.000 0.000 0.000 0.000 0.000 0.000 0.000
Supplementary heater
Rated heat output*2PSUP kW 0.9 1.0 1.3 1.1 1.2 0.9 1.1 1.2
Type of energy input Electric
Other items
Capacity control Variable
Sound power level Indoor unit LWA dB 40 — 40 — 40 — 40 —
Outdoor unit LWA dB 57 — 57 — 60 — 62 —
Annual energy consumption QHE kWh 3,035 2,322 3,411 2,594 3,903 2,982 5,083 3,875
Emissions of nitrogen oxides NOxmg/kWh Not applicable
Rated airflow rate Outdoor unit m3/h 2,100 1,640 2,100 2,100 3,120 3,120 4,130 4,130
Declared load profile — — — — — — — —
Daily electricity consumption Qelec kWh — — — — — — — —
Annual energy consumption AEC kWh — — — — — — — —
Water heating energy efficiency ηwh % ————————
Daily fuel consumption Qfuel kWh Not applicable
Contact details FUJITSU GENERAL (EURO) GmbH
Fritz-Vomfelde-Straße 26-32, 40547 Düsseldorf, Germany
NOTES:
• Product information according to Commission Delegated Regulation (EU) 811/2013
• Product information is based on the average climate condition.
• *1: When using an optional component, this function is available.
• *2: For heat pump space heaters and heat pump combination heaters, the rated heat output Prated is equal to the design load for heating Pdesignh, and the rated heat output of a supple-
mentary heater Psup is equal to the supplementary capacity for heating sup (Tj).
• *3: If Cdh is not determined by measurement then the default degradation coefficient is Cdh = 0.9.
2-4. Product information - (01-5) - 2. Specifications
OUTDOOR UNIT OUTDOOR UNIT

¢Energy efficiency value
Application: 35°C
Model name
Hydraulic indoor unit WSYA050ML3 WSYA080ML3 WSYA100ML3
Outdoor unit WOYA060KLT WOYA060KLT WOYA080KLT WOYA100KLT
Seasonal energy efficiency of heat pump for space heating % 175 175 177 178
Type of temperature control
Outdoor sensor (included in the package) II — II — II — II —
Modulating room thermostat (outdoor sensor included in the package) — IV — IV — IV — IV
Bonus % 2 4 2 4 2 4 2 4
Seasonal space heating energy efficiency of package in average climate conditions % 177 179 177 179 179 181 180 182
Energy class of the packages A+++ A+++ A+++ A+++ A+++ A+++ A+++ A+++
Seasonal space heating energy efficiency of package in warmer climate conditions % 238 240 232 234 230 232 237 239
Seasonal space heating energy efficiency of package in colder climate conditions % — — — — — — — —
Application: 55°C
Model name
Hydraulic indoor unit WSYA050ML3 WSYA080ML3 WSYA100ML3
Outdoor unit WOYA060KLT WOYA060KLT WOYA080KLT WOYA100KLT
Seasonal energy efficiency of heat pump for space heating % 125 125 128 130
Type of temperature control
Outdoor sensor (included in the package) II — II — II — II —
Modulating room thermostat (outdoor sensor included in the package) — IV — IV — IV — IV
Bonus % 2 4 2 4 2 4 2 4
Seasonal space heating energy efficiency of package in average climate conditions % 127 129 127 129 130 132 132 134
Energy class of the packages A++ A++ A++ A++ A++ A++ A++ A++
Seasonal space heating energy efficiency of package in warmer climate conditions % 159 161 158 160 161 163 164 166
Seasonal space heating energy efficiency of package in colder climate conditions % — — — — — — — —
¢Class of temperature controller
Controller class II VI
Contribution to energy efficiency % 2 4
NOTE: Controller class VI: UTW-C55XA, UTW-C58XD, UTW-C74TXF, UTW-C74HXF, UTW-C78XD
2-5. Electrical specifications
Outdoor unit model name WOYA060KLT WOYA080KLT WOYA100KLT
Available voltage range 198—264 V
Power supply Voltage V 1 Ø 230
Frequency Hz 50
Maximum operating current*1Heating A 13.0 18.0 19.0
Wiring spec.*2
Main fuse (circuit breaker) current A 16 30
Power cable mm22.5 or more 4.0 or more
Transmission cable Size mm21.5 or more
Max. length m 31
Wiring connections quantity*3For power supply 3
For connection with indoor 4
NOTES:
• *1: Maximum operating current is the total current of the indoor unit and the outdoor unit.
• *2: Selected based on Japan Electrotechnical Standard and Codes Committee E0005.
• *3: Included earth wiring.
2-4. Product information - (01-6) - 2. Specifications
OUTDOOR UNIT OUTDOOR UNIT

3. Dimensions
3-1. Model: WOYA060KLT
Unit: mm
Side view
Side view Front view
Bottom view Side view (Valve part)
Top view
580
79919 68 16 290
33 30
109
353
632
20
330
Pitch of bolts for installation
Pitch of bolts for installation
4-
M1 0 hole
120
184
180
Airflow
Drain hole
3-1. Model: WOYA060KLT - (01-7) - 3. Dimensions
OUTDOOR UNIT OUTDOOR UNIT

3-2. Model: WOYA080KLT
Unit: mm
Side viewSide view Front view
Top view
16 315
20 18
600 109
353 330
Pitch of bolts for installation
Pitch of bolts for installation
4-
M1 0 hole
82019 68
716
20
Bottom view Side view (Valve part)
119
184
194
Airflow
Drain hole
3-2. Model: WOYA080KLT - (01-8) - 3. Dimensions
OUTDOOR UNIT OUTDOOR UNIT

3-3. Model: WOYA100KLT
Unit: mm
Top view
Bottom view
Side viewFront view
940
998
266.7
Pipe & Cable port
Rear view
Ф28: Cable port
Pipe port
650
35.748
143147
39.8
53.9 Liquid
40 320
355
62.9 Gas
12.9
297.2
(Gas valve)
(Liquid valve)
Ф28
Cable port
1-1/8
(29)
Pipe port
23.4
129.1
85.3
50
29
Pipe port
A
95
89
A
3 Way valve
(Liquid)
3 Way valve
(Gas)
320
139.8
96
40 5
Ф28
Cable port
120
Pipe port
55
25
50
B
B
50
25
141.9 70
67 Pipe port
264.6
351.9
47.6
15.262.6
15.6
3-3. Model: WOYA100KLT - (01-9) - 3. Dimensions
OUTDOOR UNIT OUTDOOR UNIT

4. Installation space
4-1. Models: WOYA060KLT and WOYA080KLT
¢Space requirement
Provide sufficient installation space for product safety.
CAUTION
Keep the space shown in the installation examples.
If the installation is not performed accordingly, it could cause a short circuit and result in a lack of
operating performance.
Single outdoor unit installation
•When the upper space is open:
Unit: mm
Obstacles at rear only Obstacles at rear and sides
100 or more
250 or more
100 or more
100 or more
Obstacles at front Obstacles at front and rear
600 or more
600 or more
100 or more
•When an obstruction in the upper space:
Unit: mm
Obstacles at rear and above Obstacles at rear, sides, and above
100 or more
Max. 200
600 or more
250 or more
100 or more
Max. 200
100 or more
600 or more
4-1. Models: WOYA060KLT and WOYA080KLT - (01-10) - 4. Installation space
OUTDOOR UNIT OUTDOOR UNIT

Multiple outdoor unit installation
• Provide at least 250 mm of space between the outdoor units if multiple units are installed.
• When routing the piping from the side of an outdoor unit, provide space for piping.
• No more than 3 units must be installed side by side.
When 4 units or more are arranged in a line, provide the space as shown in the following ex-
ample “When an obstruction in the upper space:”.
•When the upper space is open:
Unit: mm
Obstacles at rear only Obstacles at front only
200 or more
250 or more
1,000 or more
250 or more
Obstacles at front and rear
200 or more
1,000 or more
250 or more
•When an obstruction in the upper space:
Unit: mm
Obstacles at rear and above.
1,500 or more
200 or more
250 or more
250 or more
Max. 300
1,500 or more
4-1. Models: WOYA060KLT and WOYA080KLT - (01-11) - 4. Installation space
OUTDOOR UNIT OUTDOOR UNIT

Outdoor units installation in multi-row
Unit: mm
Single parallel unit arrangement Multiple parallel unit arrangement
100 or more
200 or more
500 or more
1,000 or more
200 or more
400 or more
1,000 or more
250 or more
2,000 or more
250 or more
1,000 or more 200 or more
250 or more
200 or more
NOTES:
• If the space is larger than stated above, the condition will be the same as when there is no ob-
stacle.
• Height above the floor level should be 50 mm or more.
• When installing the outdoor unit, be sure to open the front and left side to obtain better operation
efficiency.
CAUTION
• Do not install the outdoor unit in two-stage where the drain water could freeze. Otherwise the
drainage from the upper unit may form ice and cause a malfunction of the lower unit.
• If the unit is installed in a region that is exposed to high winds, freezing conditions, freezing rain,
snow fall or heavy snow accumulation, take appropriate measures to protect it from those ele-
ments.To ensure stable operation, the outdoor unit must be installed on a raised stand or rack,
at or above the anticipated snow depth for the region. The installation of snow hoods and drift
prevention fencing is recommended when blowing and drifting snow is common to the region.
4-1. Models: WOYA060KLT and WOYA080KLT - (01-12) - 4. Installation space
OUTDOOR UNIT OUTDOOR UNIT
