FUNAI Philco DP100HH8A User manual

PRECAUTIONSSETUP
DVD FUNCTIONS
INFORMATIONEspañol
DVD/CD Player
DP100HH8 A
Owner’s Manual
Please read before using this unit.
If you need additional operating assistance
after reading this owner’s manual, please call
TOLL FREE : 1-800-317-6062
or visit our web site at
http://www.funai-corp.com
INSTRUCCIONES EN ESPAÑOL INCLUIDAS.
Supplied Accessories
remote control
(NB094UD)
batteries (AA x2)
RCA audio/video
cables
(WPZ0102TM018/
WPZ0102LTE01)
owner’s manual
(1VMN24994)
STANDBY-ON
AUDIO
SUBTITLE
ANGLE
REPEAT CLEAR
A-B
PAUSE
SETUP TOPMENU MENU
ENTER MODE
ZOOM RETURN
SKIP
OPEN/CLOSE
DISPLAY SEARCH
MODE
12
3
45
6
78
9
0+10
PLAY
REV FWD
STOP
Owner's Manual
Contents
If your TV has antenna in jack only, it is still possible
to connect this unit to your TV by using an RF
modulator. In this case, follow the instructions below.
1) Disconnect the power cords of the devices from
the AC outlet.
2) Make the connection as illustrated below.
3) Set your RF modulator’s channel 3/4 switch to
either 3 or 4, whichever the TV channel is least
used in your area. If your RF modulator has a
modulator/antenna switch, set it according to the
manual supplied with the RF modulator.
4) Plug in the power cords of the devices to the AC outlet.
5) Turn on your TV and choose the same channel
as you set the RF modulator’s channel 3/4
switch to. For more details, follow the manual
supplied with the RF modulator.
rear of TV
rear of your RF
modulator
AUDIO IN TO TVANT. IN
LR
CHANNEL
43
VIDEO IN
ANT. IN
Set channel 3 or 4
rear of this unit
RF coaxial cable
RF coaxial
cable
VHF / UHF
antenna
cable TV
company
or
RCA video cable
RCA audio cable
L
R
VIDEO
OUT
AUDIO
OUT
S-VIDEO
OUT
C
R
/P
R
C
B
/P
B
VIDEO
OUT
Y
L
R
AUDIO
OUT
DIGITAL
AUDIOOUT
COMPONENT
VIDEOOUT
COAXIAL
Connecting to RF Modulator (Not Supplied)
Note:
• RF modulator is not supplied with this unit. You need to
purchase it at your local store.
• The quality of picture may become poor if this unit is
connected to an RF modulator.
© 2008 Funai Electric Co., Ltd.
PRECAUTIONS
■ Important Safeguards .................................................. .2
■ About the Discs ............................................................ .5
Playable Discs................................................................ .5
Unplayable Discs............................................................ .5
SETUP
■ Connections.................................................................. .6
Connection to a TV......................................................... .6
Connection to an Audio System..................................... .7
Rear Terminals............................................................... .7
■
About the Remote Control........................................... .8
Remote Control .............................................................. .8
Installing the Batteries for the Remote Control .............. .8
DVD FUNCTIONS
■ Playback ........................................................................ .9
■ MP3 Playback............................................................... .10
■ Search Functions ........................................................ .10
Using Track Search....................................................... .10
Using Title / Chapter Search ......................................... .10
Using Time Search........................................................ .10
■
On-Screen Display....................................................... .11
■ Repeat / Random / Programmed Playback ............... .12
Repeat Playback ........................................................... .12
Repeat A-B Playback .................................................... .12
Random Playback ......................................................... .12
Programmed Playback .................................................. .12
■
Special Settings........................................................... .13
Subtitle Language.......................................................... .13
Audio Language ............................................................ .13
Camera Angles.............................................................. .13
Black Level Setting........................................................ .13
Stereo Sound Mode....................................................... .13
Virtual Surround............................................................. .13
■
DVD Setting.................................................................. .14
LANGUAGE Setting ...................................................... .14
DISPLAY Setting ........................................................... .15
AUDIO Setting............................................................... .15
PARENTAL Setting ....................................................... .16
OTHERS Setting ........................................................... .16
Reset to the Default Setting
(Except for PARENTAL Setting).................................... .17
INFORMATION
■ Troubleshooting Guide ............................................... .17
■ Specifications .............................................................. .18
■ LIMITED WARRANTY .................................................. .18
■ Español......................................................................... .19
■ Quick Use Guide............................................ Back Cover
E6KPTUD_DP100HH8 A.indd 1E6KPTUD_DP100HH8 A.indd 1 2008/01/08 14:13:022008/01/08 14:13:02

–2 –EN
PRECAUTIONS
PRECAUTIONS
1. READ INSTRUCTIONS - All the safety and operating instructions should be
read before the apparatus is operated.
2. RETAIN INSTRUCTIONS - The safety and operating instructions should be
retained for future reference.
3. HEED WARNINGS - All warnings on the apparatus and in the operating
instructions should be adhered to.
4. FOLLOW INSTRUCTIONS - All operating and use instructions should be
followed.
5. CLEANING - Unplug this apparatus from the wall outlet before cleaning. Do
not use liquid cleaners or aerosol cleaners. Use a damp cloth for cleaning.
EXCEPTION: An apparatus that is meant for uninterrupted service and, that
for some specific reason, such as the possibility of the loss of an authorization
code for a CATV converter, is not intended to be unplugged by the user for
cleaning or any other purpose, may exclude the reference to unplugging the
apparatus in the cleaning description otherwise required in item 5.
6. ATTACHMENTS - Do not use attachments not recommended by the
apparatus manufacturer as they may cause hazards.
7. WATER AND MOISTURE - Do not use this apparatus near water, for
example, near a bath tub, wash bowl, kitchen sink, or laundry tub, in a wet
basement, or near a swimming pool, and the like.
8. ACCESSORIES - Do not place this apparatus on an
unstable cart, stand, tripod, bracket, or table.The apparatus
may fall, causing serious injury to someone, and serious
damage to the apparatus. Use only with a cart, stand,
tripod, bracket, or table recommended by the manufacturer,
or sold with the apparatus. Any mounting of the apparatus
should follow the manufacturer’s instructions and should
use a mounting accessory recommended by the manufacturer. An apparatus
and cart combination should be moved with care. Quick stops, excessive
force, and uneven surfaces may cause the apparatus and cart combination to
overturn.
AMEUBLES - Cet appareil ne doit être placé que sur un meuble (avec ou
sans roulettes) recommandé par le fabricant. Si vous l’installez sur un meuble
à roulettes, déplacez les deux ensembles avec précaution. Un arrêt brusque,
l’utilisation d’une force excessive et des surfaces irrégulières risquent de
déstabiliser l’ensemble et de le renverser.
9. VENTILATION - Slots and openings in the cabinet and the back or bottom
are provided for ventilation and to ensure reliable operation of the apparatus
and to protect it from overheating, these openings must not be blocked or
covered. The openings should never be blocked by placing the apparatus on
a bed, sofa, carpet, rug, or other similar surface.This apparatus should never
be placed near or over a radiator or heat register. This apparatus should not
be placed in a built-in installation such as a bookcase or rack unless proper
ventilation is provided or the manufacturer’s instructions have been adhered to.
10. POWER SOURCES - This apparatus should be operated only from the type
of power source indicated on the marking label. If you are not sure of the type
of power supply to your home, consult your apparatus dealer or local power
company. For the apparatus’s intended to operate from battery power, or other
sources, refer to the operating instructions.
11. GROUNDING OR POLARIZATION - This apparatus is equipped with a
polarized alternating-current line plug (a plug having one blade wider than
the other).This plug will fit into the power outlet only one way.This is a safety
feature. If you are unable to insert the plug fully into the outlet, try reversing
the plug. If the plug should still fail to fit, contact your electrician to replace
your obsolete outlet. Do not defeat the safety purpose of the polarized plug.
12. POWER-CORD PROTECTION - Power-supply cords should be routed so
that they are not likely to be walked on or pinched by items placed upon
or against them, paying particular attention to cords at plugs, convenience
receptacles, and the point where they exit from the apparatus.
13. OUTDOOR ANTENNA GROUNDING - If an outside antenna or cable
system is connected to the apparatus, be sure the antenna or cable system
is grounded so as to provide some protection against voltage surges and
built-up static charges. Article 810 of the National Electrical Code, ANSI/
NFPA No. 70, provides information with respect to proper grounding of the
mast and supporting structure, grounding of the lead-in wire to an antenna
discharge unit, size of grounding conductors, location of antenna-discharge
unit, connection to grounding electrodes, and requirements for the grounding
electrode. (Fig. A)
FIGURE A
EXAMPLE OF ANTENNA GROUNDING
AS PER NATIONAL ELECTRICAL CODE
ANTENNA
LEAD
WIRE
ANTENNA
DISCHARGE UNIT
(NEC SECTION 810-20)
GROUNDING CONDUCTORS
(NEC SECTION 810-21)
GROUND
CLAMP
GROUND CLAMP
ELECTRIC
SERVICE
EQUIPMENT
POWER SERVICE GROUNDING
ELECTRODE SYSTEM
(NEC ART 250, PART H)
NEC – NATIONAL ELECTRICAL CODE
14. LIGHTNING - For added protection for this apparatus receiver during a
lightning storm, or when it is left unattended and unused for long periods
of time, unplug it from the wall outlet and disconnect the antenna or cable
system.This will prevent damage to the apparatus due to lightning and
power-line surges.
15. POWER LINES - An outside antenna system should not be located in the
vicinity of overhead power lines or other electric light of power circuits, or
where it can fall into such power lines or circuits.When installing an outside
antenna system, extreme care should be taken to keep from touching such
power lines or circuits as contact with them might be fatal.
16. OVERLOADING - Do not overload wall outlets and extension cords as this
can result in a risk of fire or electric shock.
17. OBJECT AND LIQUID ENTRY - Never push objects of any kind into this
apparatus through openings as they may touch dangerous voltage points or
short out parts that could result in a fire or electric shock. Never spill liquid of
any kind on the apparatus.
18. SERVICING - Do not attempt to service this apparatus yourself as opening
or removing covers may expose you to dangerous voltage or other hazards.
Refer all servicing to qualified service personnel.
19. DAMAGE REQUIRING SERVICE - Unplug this apparatus from the wall
outlet and refer servicing to qualified service personnel under the following
conditions:
a. When the power supply cord or plug is damaged or frayed.
b. If liquid has been spilled, or objects have fallen into the apparatus.
c. If the apparatus has been exposed to rain or water.
d. If the apparatus does not operate normally by following the operating
instructions. Adjust only those controls that are covered by the operating
instructions, as improper adjustment of other controls may result in
damage and will often require extensive work by a qualified technician to
restore the apparatus to its normal operation.
e. If the apparatus has been dropped or damaged in any way.
f. When the apparatus exhibits a distinct change in performance, this
indicates a need for service.
20. REPLACEMENT PARTS - When replacement parts are required, be sure the
service technician uses replacement parts specified by the manufacturer that
have the same characteristics as the original part. Unauthorized substitutions
may result in fire, electric shock, injury to persons or other hazards.
21. SAFETY CHECK - Upon completion of any service or repairs to this
apparatus, ask the service technician to perform routine safety checks to
determine that the apparatus is in proper operating condition.
22. HEAT - This apparatus should be situated away from heat sources such as
radiators, heat registers, stoves, or other products (including amplifiers) that
produce heat.
The model and serial numbers of this unit may be found on the cabinet.
You should record and retain those numbers for future reference.
Serial No.:
Model No.:
WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE
THIS APPARATUS TO RAIN OR MOISTURE.
CAUTION: TO REDUCE THE RISK OF ELECTRIC
SHOCK, DO NOT REMOVE COVER (OR BACK).
NO USER SERVICEABLE PARTS INSIDE. REFER
SERVICING TO QUALIFIED SERVICE PERSONNEL.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
The exclamation point within an equilateral triangle is
intended to alert the user to the presence of important
operating and maintenance (servicing) instructions in
the literature accompanying the apparatus.
The lightning flash with arrowhead symbol, within an
equilateral triangle, is intended to alert the user to the
presence of uninsulated “dangerous voltage” within the
apparatus’s enclosure that may be of sufficient magnitude
to constitute a risk of electric shock to persons.
The caution marking is located on the rear or bottom of the cabinet.
Important Safeguards
E6KPTUD_DP100HH8 A.indd 2E6KPTUD_DP100HH8 A.indd 2 2008/01/08 14:13:032008/01/08 14:13:03

–3 –EN
PRECAUTIONS
CAUTION: To prevent electric shock, match wide blade of plug to wide slot, fully insert.
ATTENTION: Pour éviter les chocs électriques, introduire la lame la plus large de la fiche dans la borne
correspondante de la prise et pousser jusqu’au fond.
FCC WARNING
This apparatus may generate or use radio frequency energy. Changes or modifications to this apparatus may
cause harmful interference unless the modifications are expressly approved in the manual. The user could lose
the authority to operate this apparatus if an unauthorized change or modification is made.
RADIO-TV INTERFERENCE
This apparatus has been tested and found to comply with the limits for a Class B digital device, pursuant to Part
15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference
in a residential installation. This apparatus generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this apparatus does
cause harmful interference to radio or television reception, which can be determined by turning the apparatus off
and on, the user is encouraged to try to correct the interference by one or more of the following measures:
1) Reorient or relocate the receiving antenna.
2) Increase the separation between the apparatus and receiver.
3) Connect the apparatus into an outlet on a circuit different from that to which the receiver is connected.
4) Consult the dealer or an experienced radio/TV technician for help.
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.
NOTE TO CATV SYSTEM INSTALLER
This reminder is provided to call the CATV system installer's attention to Article 820-40 of the NEC that provides
guidelines for proper grounding and, in particular, specifies that the cable ground should be connected to the
grounding system of the building as close to the point of cable entry as practical.
LASER SAFETY
This apparatus employs a laser. Only a qualified service person should remove the cover or attempt to service
this apparatus, due to possible eye injury.
CAUTION: Use of controls or adjustments or performance of procedures other than those specified herein may
result in hazardous radiation exposure.
CAUTION: Visible and invisible laser radiation when open and interlock defeated. Do not stare into beam.
LOCATION: Inside, near the deck mechanism.
IMPORTANT COPYRIGHT INFORMATION
Unauthorized copying, broadcasting, public performance and lending of discs are prohibited. This product
incorporates copyright protection technology that is protected by U.S. patents and other intellectual property
rights. Use of this copyright protection technology must be authorized by Macrovision, and is intended for home
and other limited viewing uses only unless otherwise authorized by Macrovision. Reverse engineering or
disassembly is prohibited.
E6KPTUD_DP100HH8 A.indd 3E6KPTUD_DP100HH8 A.indd 3 2008/01/08 14:13:042008/01/08 14:13:04

–4 –EN
PRECAUTIONS
TO AVOID THE HAZARDS OF ELECTRICAL
SHOCK AND FIRE
Do not handle the power cord with wet hands.
Do not pull on the power cord when disconnecting it
from an AC outlet. Grasp it by the plug.
Do not put your fingers or objects into the unit.
LOCATION AND HANDLING
Do not install the unit in direct sunlight, near strong
magnetic fields, or in a place subject to dust or
strong vibration.
Avoid a place with drastic temperature changes.
Install the unit in a horizontal and stable position.
Do not place anything directly on top or bottom of
the unit. Depending on your external devices, noise
or disturbance of the picture and/or sound may be
generated if the unit is placed too close to them. In
this case, please ensure enough space between the
external devices and the unit.
Depending on the environment, the temperature
of this unit may increase slightly. This is not a
malfunction.
TRADEMARK INFORMATION
Manufactured under license from
Dolby Laboratories. Dolby and the
double-D symbol are trademarks of
Dolby Laboratories.
Product that have earned ENERGY STAR®
are designed to protect the environment
through superior energy efficiency.
is a trademark of DVD Format/Logo
Licensing Corporation.
DEW CONDENSATION WARNING
Dew condensation may form inside the unit in the
following conditions. If so, do not use this unit at
least for a few hours until its inside gets dry.
- The unit is moved from a cold place to a warm
place.
- Under conditions of high humidity.
- After heating a cold room.
NOTE ABOUT RECYCLING
This unit’s packaging materials are
recyclable and can be reused. Please
dispose of any materials in accordance
with your local recycling regulations.
Batteries should never be thrown away or
incinerated but disposed of in accordance with your
local regulations concerning chemical wastes.
SYMBOLS USED IN THIS MANUAL
The following symbols appear in some headings in this
manual.
: Description refers to DVD-video.
: Description refers to audio CD.
: Description refers to CD-RW/-R with MP3 files.
•
•
•
•
•
•
•
•
•
•
MAINTENANCE
Servicing
• Please refer to relevant topics on the “Troubleshooting
Guide” on page 17 before returning the unit.
• If this unit becomes inoperative, do not try to correct the
problem by yourself. There are no user-serviceable parts
inside. Turn off, unplug the power plug, and please call
our help line mentioned on the front page to locate an
authorized service center.
Cleaning the Cabinet
• Use a soft cloth slightly moistened with a mild detergent
solution. Do not use a solution containing alcohol, spirits,
ammonia or abrasive.
Cleaning Discs
• When a disc becomes dirty, clean it with a cleaning cloth.
Wipe the disc from the center to out. Do not wipe in a
circular motion.
• Do not use solvents such as benzine, thinner,
commercially available cleaners, detergent, abrasive
cleaning agents or antistatic spray intended for analog
records.
Cleaning the Disc Lens
• If this unit still does not perform properly although you refer
to the relevant sections and to “Troubleshooting Guide” in
this owner’s manual, the laser optical pickup unit may be
dirty. Consult your dealer or an authorized service center
for inspection and cleaning of the laser optical pickup unit.
Disc Handling
• When you handle a disc, hold it by its edge and try not to
touch the surface of the disc.
• Always store the disc in its protective case when not in
use.
© 2008 Funai Electric Co., Ltd.
All rights reserved. No part of this manual may be
reproduced, copied, transmitted, disseminated, transcribed,
downloaded or stored in any storage medium, in any form
or for any purpose without the express prior written consent
of Funai. Furthermore, any unauthorized commercial
distribution of this manual or any revision hereto is strictly
prohibited.
Information in this document is subject to change without
notice. Funai reserves the right to change the content
herein without the obligation to notify any person or
organization of such changes.
with the design is a registered trademark of
Funai Electric Co., Ltd and may not be used in any way
without the express written consent of Funai. All other
trademarks used herein remain the exclusive property
of their respective owners. Nothing contained in this
manual should be construed as granting, by implication or
otherwise, any license or right to use any of the trademarks
displayed herein. Misuse of any trademarks or any other
content in this manual is strictly prohibited. Funai shall
aggressively enforce its intellectual property rights to the
fullest extent of the law.
E6KPTUD_DP100HH8 A.indd 4E6KPTUD_DP100HH8 A.indd 4 2008/01/08 14:13:042008/01/08 14:13:04

–5 –EN
PRECAUTIONS
If you cannot play back a disc which bears one of the marks above, check the following notes.
*1: This unit conforms to the NTSC color system. Discs recorded in other color systems such as PAL cannot be played
back.
*2: Certain DVD-video do not operate as described in this manual due to the intentions of the disc’s producers.
*3: Discs recorded in the VR (Video Recording) format cannot be played back.
*4: Scratched or stained discs may not be played back.
*5: Some discs cannot be played back because of incompatible recording conditions, characteristics of the recorder or
special properties of discs.
*6: You can play back discs which bear the marks above. If you use non-standardized discs, this unit may not play them
back. Even if they are played back, the sound or video quality will be compromised.
*7: Only the discs recorded in the video format and finalized can be played back. Unfinalized discs cannot be played back.
Depending on the recording status of a disc, the disc may not be played back at all. The picture or sound may not be
smooth, etc.
*8: If the recorded portion of the disc is too small (smaller than 2-3/16 inches (55mm) across), it may not be played back.
*9: Do not glue
paper or put stickers on to the disc. These may damage the disc, and the unit may not read it correctly.
About the Discs
Playable Discs
Unplayable Discs
NEVER play back the following discs as malfunction may result!
DVD-RAM / DVD-audio / CD-i / photo CD / video CD / DVD with region codes other than 1 or ALL / DTS-CD / DVD-ROM
for personal computers / CD-ROM for personal computers / HD DVD / Blu-ray Disc
On the following disc, the sound MAY NOT be heard.
super audio CD
Any other discs without compatibility indications
is a trademark of DVD Format/Logo Licensing Corporation.
Type of
media Mark (logo) Region code Recorded
signals
Disc
size Disc types
DVD-video
*1, 2, 4, 6, 9 or
digital video
(MPEG2)
5 inches
(12 cm)
or
3 inches
(8 cm)
e.g.) title 1 title 2
chapter 1 chapter 2 chapter 1 chapter 2 chapter 3 chapter 4
DVD-RW
DVD-R
*1, 3, 4, 5, 6,
7, 8, 9
DVD+RW
DVD+R
*1, 4, 5, 6,
8, 9
audio CD
*4, 6, 9 digital audio
5 inches
(12 cm)
or
3 inches
(8 cm)
e.g.)
track 1 track 2 track 5 track 6
track 3 track 4
audio CD
CD-RW
CD-R
*4, 5, 6, 8, 9,
digital audio
or
MP3
e.g.) folder 1 folder 2
le 1 le 2 le 1 le 2 le 3 le 4
MP3
Note:
• Only the sound recorded on the normal CD layer can be delivered. The sound recorded on the high density super audio
CD layer cannot be delivered.
E6KPTUD_DP100HH8 A.indd 5E6KPTUD_DP100HH8 A.indd 5 2008/01/08 14:13:052008/01/08 14:13:05

–6 –EN
SETUP
Connection to a TV
Connections
SETUP
AUDIO
OUT
R
L
LR
AUDIO IN
S-VIDEO
OUT
C
R
/P
R
C
B
/P
B
VIDEO
OUT
Y
L
R
AUDIO
OUT
DIGITAL
AUDIO OUT
COMPONENT
VIDEO OUT
COAXIAL
VIDEO IN
VIDEO
OUT
S-VIDEO IN
S-VIDEO
OUT
AUDIO OUT VIDEO OUT
Method 1
standard pictureanalog audio
Method 2
good picture
S-VIDEO OUT
RCA video
cable
RCA audio
cable S-video cable
Note:
• Connect this unit directly to the TV. If RCA audio/video cables are connected to a VCR, pictures may be distorted
due to the copy protection system.
Admiral: AUX
Curtis Mathis: LINE1, LINE2, 00, 90, 91, 92, 93
GE: INPUT, TV/VCR, 00, 90, 91, 92, 93
Hitachi: INPUT, AUX
JVC: VIDEO, VIDEO1, VIDEO2, VIDEO3
Kenwood: AUX
LXI-Series: 00
Magnavox: AUX CHANNEL
Panasonic: TV/VIDEO
RCA: INPUT, TV/VCR, 00, 90, 91, 92, 93
Samsung: TV/VIDEO
Sanyo: VIDEO
Sharp: 00
Sony: VIDEO1, VIDEO2, VIDEO3
Toshiba: TV/GAME
Zenith: 00
TV
This unit
After connecting to your TV:
You will need to switch to video input on your TV. This is usually marked TV/VIDEO, INPUT or AUX.
Please refer to your TV’s manual for details.
INPUT MODES FOR COMMON TV BRANDS
Listed below are inputs for common brand name TV’s.
If your TV is compatible with 525 progressive scanning and you want to enjoy that high quality picture;
You must select the connection Method 3 above and progressive scanning mode. To set the mode, set “PROGRESSIVE”
to “ON” in “DISPLAY” menu, so that the P-SCAN indicator on the front panel lights up. Refer to pages 14-15 for more
details.
• When “PROGRESSIVE” is “ON”, video signals from the unit’s VIDEO OUT and S-VIDEO OUT jacks will be distorted or
not be output at all.
If your TV is not compatible with progressive scanning;
Use this unit in interlace mode and set “PROGRESSIVE” to “OFF” either in “DISPLAY” menu or by pressing and holding
[PLAY B]on the front of the unit for more than 5 seconds, so that the P-SCAN indicator on the front panel turns off.
COAXIAL
DIGITAL
AUDIO OUT
AUDIO
OUT
VIDEO
OUT
R
L
Y
COMPONENT
VIDEO OUT
C
R /P R
C B /P B
COMPONENT
VIDEO IN COMPONENT VIDEO IN
or
P R
Y
P B
C R
Y
C B
better picture
Method 3
COMPONENT VIDEO OUT
component
video cable
and or or
Supplied cables used in this connection are as follows:
• RCA audio cable (L/R) x 1
• RCA video cable x 1
Please purchase the rest of the necessary cables at your local store.
E6KPTUD_DP100HH8 A.indd 6E6KPTUD_DP100HH8 A.indd 6 2008/01/08 14:13:082008/01/08 14:13:08

–7 –EN
SETUP
COAXIAL
COAXIAL
DIGITAL
AUDIO OUT
LR
AUDIO
OUT
R
L
Note:
• The audio source on a disc in a Dolby Digital
multi-channel surround format cannot be recorded as
digital sound by an MD or DAT deck.
• By hooking this unit up to a Dolby Digital decoder, you
can enjoy high-quality Dolby Digital multi-channel
surround sound as heard in the movie theaters.
• Playing back a DVD using incorrect settings may
generate noise distortion and may also damage the
speakers.
stereo system
Audio
This unit
Analog Audio Connection
analog audio
input jacks
AUDIO OUT
DIGITAL
AUDIO OUT
Digital Audio Connection
RCA audio cable
digital audio
coaxial cable
Dolby Digital decoder,
MD deck or DAT deck
Connection to an Audio System
* To complete these settings, refer to pages 14-15.
SETUP > AUDIO>
DOLBY DIGITAL
Connecting to a Dolby Digital decoder
for Dolby Digital audio output.
BITSTREAM
Connecting to the other device
(an MD deck or DAT deck etc.)
without Dolby Digital decoder. PCM
Connection
Setting
digital audio
input jack
Rear Terminals
4 521
3
1
S-VIDEO OUT jack
Connect an optional S-video cable here through the S-video in jack of a television.
2
COMPONENT VIDEO OUT jacks
Connect optional component video cable here through the component video in jacks of a television.
3
VIDEO OUT jack
Connect a yellow video cable here through the video in jack of a television.
4
AUDIO OUT jacks
Connect an audio cable here through the audio in jacks of a television or other audio device.
5
DIGITAL AUDIO OUT COAXIAL jack
Connect a digital audio coaxial cable here through the digital audio coaxial in jack of a decoder or audio receiver.
S-VIDEO
OUT
C
R
/P
R
C
B
/P
B
VIDEO
OUT
Y
L
R
AUDIO
OUT
DIGITAL
AUDIO OUT
COMPONENT
VIDEO OUT
COAXIAL
Note:
• Please purchase the necessary cables at your local store. (Refer to pages 6-7.)
Supplied cables used in this connection are as
follows:
• RCA audio cable (L/R) x 1
Please purchase the rest of the necessary cables
at your local store.
E6KPTUD_DP100HH8 A.indd 7E6KPTUD_DP100HH8 A.indd 7 2008/01/08 14:13:092008/01/08 14:13:09

–8 –EN
SETUP
Installing the Batteries for the
Remote Control
Install batteries (AA x2) matching the
polarity indicated inside battery com-
partment of the remote control.
23
1
Keep in mind the following when using
the remote control:
• Make sure that there are no obstacles
between the remote control and the
remote sensor on the unit.
• The maximum operable ranges from
the unit are as follows.
-Line of sight:
approx. 23 feet (7m)
-Either side of the center:
approx. 16 feet (5m) within 30°
-Above: approx. 16 feet (5m) within 15°
-Below: approx. 10 feet (3m) within 30°
OPEN/CLOSE
PLAY STOP POWER
P-SCAN
Remote Control
Note:
• Do not mix alkaline and manganese
batteries.
• Do not mix old and new batteries.
• Always remove batteries from
remote control if they are dead or if
the remote control is not to be used
for an extended period of time. This
will prevent battery acid from leaking
into the battery compartment.
About the Remote Control
Button
(Alphabetical order)
123
456
789
0
+10
• To select chapter or title
directly.
• To select track directly. (CD)
• To select folder/file directly.
(MP3)
ENTER
• To move the cursor and deter-
mine its position. • To move the cursor and deter- mine its position.
A-B
• To repeat between your cho-
sen point of A and B. • To repeat between your cho- sen point of A and B.
ANGLE
• To select camera angles on
a disc. ------
AUDIO
• To select audio language on
a disc. • To select “STEREO”, “L-ch” or “R-ch”. (CD)
CLEAR
• To remove status number in
program input.
• To clear the numbers entered
incorrectly.
• To cancel the point for A-B
repeat.
• To remove status number in
program input.
• To clear the numbers entered
incorrectly.
• To cancel the point for A-B
repeat.
DISPLAY
• To display the current disc
mode. • To display the current disc mode.
REV FWD
• To search forward/backward
through a disc.
• To begin slow forward play-
back in the pause mode.
• To search forward/backward
through a disc.
MENU
• To call up the menu on a disc. ------
MODE
• To arrange the playing order
or play randomly.
• To set black level on/off.
• To set virtual surround on/off.
• To arrange the playing order
or play randomly.
• To set virtual surround on/off.
OPEN/CLOSE
• To open or close the disc tray.
• To turn on the unit. • To open or close the disc tray. • To turn on the unit.
PAUSE
• To pause disc playback.
• To advance playback one
frame at a time. • To pause disc playback.
PLAY
• To begin disc playback.
• To turn on the unit. • To begin disc playback. • To turn on the unit.
REPEAT
• To play back a chapter or title
repeatedly.
• To play back a track or disc
repeatedly. (CD)
• To play back a file, folder or
disc repeatedly. (MP3)
RETURN
• To return to the previous
operation in menu. • To return to the previous operation in menu.
SEARCH
MODE • To search chapter, title or
time.
• To search tracks.
• To search time. (CD)
• To search folders. (MP3)
SETUP
• To call up the setup menu. • To call up the setup menu.
SKIP
• To skip chapters or titles. • To skip tracks. (CD)
• To skip folders or files. (MP3)
STANDBY-ON
• To turn the unit on/off. • To turn the unit on/off.
STOP
• To stop playback. • To stop playback.
SUBTITLE
• To select subtitles on a disc. ------
TOP MENU
• To call up the top menu on
a disc. ------
ZOOM
• To magnify part of a picture.
(2x / 3x / 4x / 1/2x) ------
Media
STANDBY-ON
AUDIO
SUBTITLE
ANGLE
REPEAT CLEAR
A-B
PAUS E
SETUP TOP MENU MENU
ENTER MODE
ZOOM RETURN
SKIP
OPEN/CLOSE
DISPLAY SEARCH
MODE
12
3
45
6
78
9
0+10
PLAY
REV FWD
STOP
E6KPTUD_DP100HH8 A.indd 8E6KPTUD_DP100HH8 A.indd 8 2008/01/08 14:13:102008/01/08 14:13:10

–9 –EN
DVD FUNCTIONS
STANDBY-ON
AUDIO
SUBTITLE
ANGLE
REPEAT CLEAR
A-B
PAU SE SKIP
OPEN/CLOSE
DISPLAY SEARCH
MODE
12
3
45
6
78
9
0+10
PLAY
REV FWD
STOP
DVD FUNCTIONS
Please note : most instructions in this manual refer to remote control use.
Playback
Before:
Turn on the TV, amplifier and any other
devices which are connected to this unit.
Make sure the TV and audio receiver are
set to the correct channel.
( ⇒on page 10 )
Note:
• When you play back a CD-RW/-R with MP3
files, details on page 10.
• A “ ” may appear at the top-right on the TV
screen when the operation is prohibited by the
disc or this unit.
• Some DVD may start playback from title 2 or 3 due to
specific programs.
• During the playback of a 2-layered disc, pictures may
stop for a moment. This happens while the 1st layer is
being switched to the 2nd layer. This is not a malfunction.
• You can change the on-screen language in “PLAYER
MENU” setting. (Refer to page 14.)
4
3
1
OPEN/CLOSE
PLAY STOP POWER
P-SCAN
1
Press [STANDBY-ON] to turn on
this unit.
2
Press [OPEN / CLOSE A]and
insert a disc with label facing up.
3
Press [PLAY B]to start playback.
4
Press [STOP C]to stop playback.
222 1
Lights up when power is on.
Resume Playback
Press [STOP C] during playback. Resume icon
will appear at the top-left on the TV screen.
Press [PLAY B], playback will resume from
the point at which playback was stopped.
Slow Forward Search
Press [FWD g]repeatedly in the pause
mode to select the required forward speed.
To continue playback, press [PLAY B].
Paused and Step-by-Step Playback
Press [PAUSE F] during playback.
To continue playback, press [PLAY B].
The disc goes forward by one frame each time [PAUSE F]
is pressed in the pause mode.
To continue playback, press [PLAY B].
Note:
• Slow forward speed is different depending on the disc.
Approximate speed is 1(1/32), 2(1/16), 3(1/8), 4(1/4) and
5(1/2).
• Set “STILL MODE” to “FIELD” in “DISPLAY” menu if
pictures in the slow playback mode are blurred. (Refer to
pages 14-15.)
• The reverse of slow playback is not available.
Fast Forward / Reverse Search
Use [FWD g]or [REV h]repeatedly
during playback to select the required
forward or reverse speed.
To continue playback, press [PLAY B].
1
E1
Note:
• Set “STILL MODE” to “FIELD” in “DISPLAY” menu if
pictures in the pause mode are blurred. (Refer to pages
14-15.)
PAUSE
Note:
• Menu operations may vary depending on the disc. Refer
to the manual accompanying the disc for more details.
R.STOP
Note:
• To cancel resume, press [STOP C]one more time in the
stop mode.
• For MP3, playback will resume from where you stopped (if
the power has been turned off, the playback will start from
the beginning of the track).
• The resume playback information stays on even when the
power is turned off, as long as the disc stays in the unit.
Note:
• Fast forward or reverse search speed is different
depending on the disc. Approximate speed is 1(2x), 2(4x),
3(8x), 4(16x) and 5(32x).
Note:
• Zooming function does not work while the disc menu is
displayed.
• Some part of the picture may not be zoomed depending
on the disc or playback status.
Zoom
1) Press [ZOOM] repeatedly during playback to select the
required zoom factor: 2x, 3x, 4x, 1/2x or off.
x2 x3 x4 x1/2
2) Use [K/ L/ s/ B]to slide the zoomed picture across
the screen.
3) To exit zoom function, press [ZOOM] repeatedly to select
OFF.
Disc Menu
Some discs contain menus which allow you to customize
DVD playback. Use [K/ L/ s/ B]to select an item, then
press [ENTER] (or [PLAY B]).
Calling Up a Menu Screen during Playback
• Press [MENU] to call up the disc menu.
• Press [TOP MENU] to call up the title menu.
2
34
E6KPTUD_DP100HH8 A.indd 9E6KPTUD_DP100HH8 A.indd 9 2008/01/08 14:13:142008/01/08 14:13:14

–10 –EN
DVD FUNCTIONS
1
1
2
Enter the desired track number
within 5 seconds.
1
Search Functions
Using Time Search
2 Enter the desired time within 5
seconds.
03/24 001/002 -- : -- : --
OFF
SEARCH
MODE
PLAY
Press cursor [B]
to highlight .
CD: once
DVD: twice
Using Track Search
Using [SEARCH MODE]
-- /26 00:00:19 OFF
Using Title / Chapter Search
Using [SEARCH MODE]
1
2
Enter the desired title or chapter
number within 5 seconds.
-- /24 001/002 00:00:30 OFF
Press [SEARCH MODE] once for
the title search.
For the chapter search, press
cursor [B] to highlight .
-- /26 00:00:19 OFF
123
456
789
0
+10
SEARCH
MODE SEARCH MODE
1
PLAY
TR 1 TR 2 TR 3 TR 4
Current Track
SKIP SKIP
Using [SKIP H , G ]
Using [SKIP
H , G ]
SKIP
SKIP
Note:
• To play time 0:15:00, press [1], [5],
[0], [0] of [the Number buttons].
• Press [CLEAR] to erase the
incorrect input at step 2.
• For DVD and audio CD, time search
is not available for programmed or
random playback.
Note:
• Depending on the disc being played
back, this function can also be performed
by directly entering the desired chapter
number with [the Number buttons].
Refer to the manual accompanying the
disc.
• For DVD, title/chapter search is not avail-
able for programmed or random playback.
PLAY
03/24 --- /002 00:00:32 OFF
123
456
789
0
+10
2 Select the desired file from the list on
the right side in the file list.
MP3 Playback
1 Select the desired folder from the list
on the left side in the file list.
004/027 001/013 00:00:36 OFF
file name1
1. folder1
2. folder2
3. folder3
4. folder4
5. folder5
6. folder6
7. folder7
8. folder8
1. file name1
2. file name2
3. file name3
4. file name4
5. file name5
6. file name6
7. file name7
8. file name8
3
3
3
3
3
3
3
3
MP3 is a method of compressing files. You can copy MP3 files on CD-RW/-R from the
computer and play back the files on this unit.
Insert a CD-RW/-R with MP3 files, then the file list will automatically appear on the TV
screen.
Note:
• Some selections may take a while to
be recognized.
• Folders are known as groups; files are
known as tracks.
• MP3 files are accompanied by 3icon.
• Folders are accompanied by icon.
• Refer to “On-Screen Display” on
page 11 for more details.
• If you record data over 20 times, it may
not be played back correctly.
This unit recommends the files recorded
under the following circumstances:
• Sampling frequency: 44.1kHz or 48kHz.
• Constant bit rate: 32kbps ~ 320kbps.
• To play back a double-digit track, press
the track number directly (e.g. for track
14, press [1], [4] and [ENTER]).
• To play back a triple-digit track, press
the track number directly for MP3.
(e.g. for track 114, press [1], [1], [4]
and [ENTER]).
CH 1 CH 2 CH 3 CH 4
Current Chapter
SKIP SKIP
Note:
• For audio CD, track search is not
available for programmed or random
playback.
3 Press [ENTER].
ENTER
ENTER
ENTER
or
ENTER
3 Press [ENTER].
ENTER
ENTER
ENTER
3 Press [ENTER].
ENTER
ENTER
ENTER
ENTER
ENTER
ENTER
ENTER
PLAY
or
ENTER
3 Refer to “Resume Playback” on
page 9.
STOP
001/027 001/007 00:00:12 OFF
file name11
1. folder1
2. folder2
3. folder3
4. folder4
5. folder5
6. folder6
7. folder7
8. folder8
1. file name11
2. file name12
3. file name13
4. file name14
5. file name15
6. file name16
7. file name17
3
3
3
3
3
3
3
ENTER
ENTER
ENTER
PLAY
or
ENTER
Press [ENTER]
or [PLAY B] .
e.g.) CD e.g.) DVD
123
456
789
0
03/24 001/002 -- : -- : --
OFF
e.g.) DVD
E6KPTUD_DP100HH8 A.indd 10E6KPTUD_DP100HH8 A.indd 10 2008/01/19 14:26:182008/01/19 14:26:18

–11 –EN
DVD FUNCTIONS
On-Screen Display
You can check the information about the current disc by pressing [DISPLAY] on the remote control.
current repeat setting
T(Title):
current title number / total
titles
03/24 001/002 00:00:40 OFF
001/002 00:00:19 - 00:01:11 NORMAL
03/24 00:00:20 - 00:01:09 NORMAL
elapsed time of the
current chapter
C(Chapter):
current chapter number /
total chapters
elapsed time of the
current title
remaining time of the
current chapter
1
2
4
3
Note:
• Some DVD will not allow you to set chapter playback
correctly.
current play mode setting
DISPLAY
CH(Chapter):
current chapter number /
total chapters
TT(Title):
current title number / total
titles
remaining time of the
current title
current play mode setting
elapsed time of the
current title
TR(Track):
current track number /
total tracks
01/26 00:00:11 OFF
01/26 00:00:12 - 00:03:20 NORMAL
01/26 00:00:14 - 01:11:28 NORMAL
elapsed time of the cur-
rent track
elapsed time of the cur-
rent track
current repeat setting
remaining time of the
current track
1
2
4
3
current play mode setting
DISPLAY
DISPLAY
DISPLAY
TR(Track):
current track number /
total tracks
ALL:
current track number / total
tracks
remaining time of the
entire disc
current play mode setting
elapsed time of entire disc
current folder number /
total folders
004/027 001/013 00:00:36 OFF
file name1
1. folder1
2. folder2
3. folder3
1. file name1
2. file name2
3. file name3
3
3
3
001/013 00:00:43 - 00:03:36 NORMAL
file name1
1. folder1
2. folder2
3
. f
o
l
de
r
3
1. file name1
2. file name2
3
. fil
e
n
a
m
e3
3
3
3
elapsed time of the
current file
elapsed time of the
current file
current repeat setting
remaining time of the
current file
file name1
1. folder1
2. folder2
3. folder3
4 f ld 4
1. file name1
2. file name2
3. file name3
4 fil 4
3
3
3
3
1
2
3
current play mode setting
DISPLAY
DISPLAY
TR(Track):
current file number / total
files in the current folder
current file number / total
files in the current folder
DISPLAY
DISPLAY
E6KPTUD_DP100HH8 A.indd 11E6KPTUD_DP100HH8 A.indd 11 2008/01/08 14:13:232008/01/08 14:13:23

–12 –EN
DVD FUNCTIONS
2 Select “RANDOM”.
Then press [ENTER].
Random playback will start.
1
at your desired starting point (A)
2
at your desired ending point (B)
• Point B should be in the same title
or track as point A.
1 Press [MODE] once during stop
mode.
1 Press [MODE] once during stop
mode.
Repeat / Random / Programmed Playback
OFF
CHAPTER
TITLE
(repeat off)
(current chapter repeat)
(current title repeat)
Each time you press [REPEAT], repeat
function changes as example below.
Repeat Playback
Repeat function is available only during
playback.
Repeat A-B Playback
Programmed Playback
You may determine the order in which
chapters or tracks will play back.
1
REPEAT
OFF
TRACK
ALL
(repeat off)
(current track repeat)
(entire disc repeat)
A-B
A-B
CHAPTER
A-
A-B
2 Select “PROGRAM”.
Then press [ENTER].
3 Select “PLAY”,
then press [ENTER].
NORMAL RANDOM PROGRAM
Random Playback
This function shuffles the playing
order of chapters or tracks instead
of playback in the sequence.
MODE
NORMAL RANDOM PROGRAM
Note:
• Repeat setting (except “ALL”) will
be cleared when moving to another
title, chapter, track/file or folder.
• This function is not available with
some discs or during repeat A-B
playback.
Note:
• During random playback, you cannot
go back to the previous track, using
[SKIP G] allows you to search
chapters or tracks randomly.
• During DVD random playback, you
can play back chapters in the cur-
rent title randomly.
• Some DVD will not allow you to set
random playback.
Note:
•To erase all program at once, select
“ALL CLEAR’’ and press [ENTER] or
press [CLEAR] at step 2.
•If the title, chapter, track number is
incorrect, the programmed number
you entered will be skipped during
programmed playback.
•While a program is being played back,
[STOP C]works as follows;
Press [STOP C]and [PLAY B]next,
so that the programmed playback
restarts.
Press [STOP C]twice and [PLAY B]
next, so that playback restarts from
the first track in the original order.
However, your programmed playback
can be restarted when you follow the
above steps. (Your programs are still
stored until either the disc is removed
or power is turned off.)
•Some DVD will not allow you to set
programmed playback.
•During programmed playback, you
cannot setup “ TITLE’’ (DVD), “
GROUP’’ (MP3).
Note:
• To exit the sequence, press [A-B]
so that “OFF” appears.
•
To cancel point A, press [CLEAR] at
step 1.
• This function does not work in the
other repeat modes.
PLAY
PLAY
MODE
• Up to 20 chapters or tracks can
be ordered.
• Enter the desired number with
[the Number buttons].
DVD: title and chapter number
CD: track number
MP3: folder and file number
MAX: 2DVD-PROGRAM
Total: 3 TITLE CHAPTER PLAY ALL CLEAR
02
05
01
--
--
007
005
002
---
---
--
--
--
--
--
---
---
---
---
---
--
--
--
--
--
---
---
---
---
---
--
--
--
--
--
---
---
---
---
---
OFF
TRACK
GROUP
ALL
(repeat off)
(current file repeat)
(current folder repeat)
(entire disc repeat)
e.g.) DVD
e.g.) DVD
• During playback, press [MODE].
CD/MP3: twice
DVD: three times
ENTER
ENTER
ENTER
ENTER
ENTER
ENTER
ENTER
ENTER
• During playback, press [MODE].
CD/MP3: twice
DVD: three times
123
456
789
0
+10
ENTER
ENTER
ENTER
E6KPTUD_DP100HH8 A.indd 12E6KPTUD_DP100HH8 A.indd 12 2008/01/08 14:13:252008/01/08 14:13:25

–13 –EN
DVD FUNCTIONS
1
1
1
1
Special Settings
Audio Language
This unit allows you to select an audio
language (if multiple languages are
available on disc) during DVD playback.
1
1. ENG Dolby D 5.1ch 48k/3
AUDIO
Each time you press [AUDIO], audio
language changes as example below. Stereo Sound Mode
This unit allows you to select a sound
mode during CD playback.
1
STEREO
Each time you press [AUDIO], sound
mode changes as example below.
Subtitle Language
This unit allows you to select a subtitle
language (if available) during DVD
playback.
1. ENG/6
OFF (no subtitles)
ENG (English subtitles)
FRE (French subtitles)
...
Each time you press [SUBTITLE],
subtitle language changes as example
below.
Camera Angles
Some DVD may contain
scenes which have been
shot simultaneously from
various angles. You can
change the camera angle if
appears on the screen. If the “ANGLE
ICON” setting is “OFF” in “OTHERS”
menu, will not appear. (Refer to
pages 14-16.)
1
1/8
ANGLE
ON
OFF
Black Level Setting
Adjust the black level to make the dark
areas of the TV picture brighter.
Virtual Surround
You can enjoy stereophonic virtual world
on your existing 2 channel stereo system.
2
OFF
ON: makes the dark areas brighter.
OFF: shows the original picture as recorded.
3
RETURN
2 Using [s/ B], you can select the
desired sound mode.
ROCK
3D: sound mode suitable for setting
stereophonic audio.
JAZZ: sound mode suitable for jazz
music
ROCK: sound mode suitable for rock music
POP: sound mode suitable for pop music
CLASSIC: sound mode suitable for
classic music
OFF: no effects (original sound)
3
MODE
SUBTITLE
To set subtitle ON/OFF
2
OFF
ENTER
Note:
• If your language is not shown after
pressing [SUBTITLE] several times,
the disc may not have that language.
However, some discs allow subtitle
language setting on the disc menu.
(Operation varies depending on the
disc, so refer to the manual along with
the disc.)
•
When “ ” appears on the TV screen,
it means no subtitle is recorded on the
scene.
• Some discs will only allow you to change
the subtitle from the disc menu. Refer to
the manual accompanying the discs for
details.
Press twice.
(once for CD and MP3)
Note:
• Virtual surround is available only
when the DVD player is connected
to a TV or stereo using the red and
white AUDIO OUT jacks on the DVD
player. Also, select the “SETUP”
menu to use Dolby Digital
connection (COAXIAL), and setting in
PCM mode.
PLAY
SUBTITLE
PLAY
PLAY
PLAY
MODE
PLAY
RETURN
PLAY
AUDIO
Note:
• Some discs will only allow you to change the
audio setting from the disc menu. Refer to the
manual accompanying the discs for details.
• If your language is not shown after pressing
[AUDIO] several times, the disc may not have
that language. However, some discs allow
audio language setting on the disc menu.
(Operation varies depending on the disc, so
refer to the manual along with the disc.)
ENG (English audio)
SPA
(Spanish audio)
FRE
(French audio)
...
STEREO (right and left channels
are active)
L-ch (left channel is active)
R-ch (right channel is active)
ENTER
1. ENG/6
ENTER
Each time you press [ANGLE], camera
angle changes.
PLAY
E6KPTUD_DP100HH8 A.indd 13E6KPTUD_DP100HH8 A.indd 13 2008/01/19 14:26:222008/01/19 14:26:22

–14 –EN
DVD FUNCTIONS
2 Select the desired item.
LANGUAGE
AUDIO
SUBTITLE
DISC MENU
PLAYER MENU
1 Press [SETUP].
SETUP
Note:
∗1
• Language options are not
available with some discs.
• If “OTHERS” is selected in the
“AUDIO”, “SUBTITLE” or “DISC
MENU” screen, select the de-
sired language using
[K/ L/ s/ B]. Press [ENTER].
LANGUAGE_AUDIO
DUTCH
JAPANESE
FINNISH
ROMANIAN
IRISH
CZECH
RUSSIAN
KOREAN
NORWEGIAN
TURKISH
PORTUGUESE
HUNGARIAN
CHINESE
DANISH
ICELANDIC
GREEK
POLISH
• Only the languages supported
by the disc can be selected.
∗2
• “LANGUAGE” setting for
“AUDIO” and “SUBTITLE” are
not available with some discs.
Then press [AUDIO] and
[SUBTITLE]. Details are on
page 13.
LANGUAGE Setting
Follow steps 1 to 2 above.
3 Select the desired item. 5 To exit the menu 4 Select the desired language.
AUDIO: ∗1 ∗2
(Default: ORIGINAL)
Sets the audio
language.
SUBTITLE: ∗1 ∗2
(Default: OFF)
Sets the subtitle
language.
DISC MENU: ∗1
(Default: ENGLISH)
Sets the language in
DVD menu.
PLAYER MENU
(Default: ENGLISH)
Sets the language for
the on-screen display.
OTHERS_ANGLE ICON
ANGLE ICON
AUTO POWER OFF
ON
OFF
AUDIO_DRC
DRC
DOWN SAMPLING
DOLBY DIGITAL
ON
OFF
DISPLAY_TV ASPECT
TV ASPECT
STILL MODE
PROGRESSIVE
4:3 LETTER BOX
4:3 PAN & SCAN
16:9 WIDE
LANGUAGE_AUDIO
AUDIO
SUBTITLE
DISC MENU
PLAYER MENU
ORIGINAL
ENGLISH
FRENCH
SPANISH
GERMAN
ITALIAN
SWEDISH
OTHERS
You can change the settings of the unit.
LANGUAGE menu AUDIO menuDISPLAY menu OTHERS menu
LANGUAGE_AUDIO
AUDIO
SUBTITLE
DISC MENU
PLAYER MENU
ORIGINAL
ENGLISH
FRENCH
SPANISH
GERMAN
ITALIAN
SWEDISH
OTHERS
LANGUAGE_SUBTITLE
AUDIO
SUBTITLE
DISC MENU
PLAYER MENU
OFF
ENGLISH
FRENCH
SPANISH
GERMAN
ITALIAN
SWEDISH
OTHERS
LANGUAGE_PLAYER MENU
AUDIO
SUBTITLE
DISC MENU
PLAYER MENU
ENGLISH
FRANÇAIS
ESPAÑOL
LANGUAGE_DISC MENU
AUDIO
SUBTITLE
DISC MENU
PLAYER MENU
ENGLISH
FRENCH
SPANISH
GERMAN
ITALIAN
SWEDISH
DUTCH
OTHERS
A
LANGUAGE menu
DVD Setting
page 14
A
page 15
B
page 15
C
page 16
E
PARENTAL_PASSWORD
PASSWORD NO
YES
PARENTAL menu
page 16
D
LANGUAGE_AUDIO
AUDIO
SUBTITLE
DISC MENU
PLAYER MENU
ORIGINAL
ENGLISH
FRENCH
SPANISH
GERMAN
ITALIAN
SWEDISH
OTHERS
ENTER
ENTER
ENTER
<SETUP MENU>
INITIALIZE_INITIALIZE
INITIALIZE YES
INITIALIZE menu
page 17
F
LANGUAGE
AUDIO
SUBTITLE
DISC MENU
PLAYER MENU
ENTER
ENTER
ENTER
ENTER
ENTER
ENTER
ENTER
ENTER
ENTER
SETUP
E6KPTUD_DP100HH8 A.indd 14E6KPTUD_DP100HH8 A.indd 14 2008/01/08 14:13:382008/01/08 14:13:38

–15 –EN
DVD FUNCTIONS
ENTER
ENTER
ENTER
TV ASPECT: (Default: 4:3 LETTER BOX)
See note on the left.
TV ASPECT
STILL MODE
PROGRESSIVE
4:3 LETTER BOX
4:3 PAN & SCAN
16:9 WIDE
DISPLAY_TV ASPECT
4:3 LETTER BOX
4:3 PAN & SCAN
16:9 WIDE
ENTER
ENTER
ENTER
ENTER
ENTER
ENTER
STILL MODE: (Default: AUTO)
See note on the left.
TV ASPECT
STILL MODE
PROGRESSIVE
AUTO
FIELD
FRAME
DISPLAY_STILL MODE
AUTO
FIELD
FRAME
ENTER
ENTER
ENTER
Select the
desired
setting.
ENTER
ENTER
ENTER
ENTER
DRC (Dynamic Range Control): (Default: ON)
Set to “ON” to compress the range between soft and loud sounds.
DOLBY DIGITAL: (Default: BITSTREAM)
Set to “BITSTREAM” when the unit is connected to a Dolby Digital decoder.
• BITSTREAM: outputs a Dolby Digital signals.
• PCM: convert the Dolby Digital into PCM (2 channel).
DRC
DOWN SAMPLING
DOLBY DIGITAL
ON
OFF
AUDIO_DRC
ON
OFF
DOWN SAMPLING: (Default: ON)
Set to “ON” when outputting in 48kHz.
Set to “OFF” when outputting the original sound.
DRC
DOWN SAMPLING
DOLBY DIGITAL
BITSTREAM
PCM
AUDIO_DOLBY DIGITAL
BITSTREAM
PCM
DRC
DOWN SAMPLING
DOLBY DIGITAL
ON
OFF
AUDIO_DOWN SAMPLING
ON
OFF
ENTER
ENTER
ENTER
ENTER
ENTER
ENTER
ENTER
ENTER
ENTER
Select the
desired
setting.
ENTER
Select the
desired
setting.
ENTER
Select the
desired
setting.
ENTER
Select the
desired
setting.
ENTER
ENTER
ENTER
ENTER
ENTER
ENTER
ENTER
ENTER
ENTER
ENTER
ENTER
ENTER
ENTER
TV ASPECT
STILL MODE
PROGRESSIVE
OFF
ON
DISPLAY_PROGRESSIVE
OFF
ON
4
4
5 To exit
“TV ASPECT”
or “STILL
MODE” menu
To complete
“PROGRESSIVE”
setting
3 Select the desired item.
DISPLAY_TV ASPECT
TV ASPECT
STILL MODE
PROGRESSIVE
4:3 LETTER BOX
4:3 PAN & SCAN
16:9 WIDE
3 Select the desired item.
AUDIO_DRC
DRC
DOWN SAMPLING
DOLBY DIGITAL
ON
OFF
You can change the display functions. Follow steps 1 to 2 on page 14.
DISPLAY menu
Choose the appropriate audio settings for your device. It only affects during the playback of DVD. Follow steps 1 to 2 on
page 14.
AUDIO menu
SETUP
Note:
DRC:
• This function is
available only on the
discs which are re-
corded in the Dolby
Digital format.
DOWN SAMPLING:
• When playing back
disc with copyright
protection, the sound
will be down sampled
at 48kHz, even if you
set to “OFF”.
DISPLAY Setting
B
AUDIO Setting
C
5 To exit the menu
SETUP
ENTER
ENTER
Note:
TV ASPECT:
• Select “4:3 LETTER BOX”, so that
black bars may appear on the top and
bottom of the screen.
• Select “4:3 PAN & SCAN” for a full
height picture with both sides adjusted.
• Select “16:9 WIDE” if a wide-screen TV
is connected to this unit.
STILL MODE:
• Select “AUTO” usually.
• If you select “AUTO”, it automatically
selects the best resolution setting
(“FRAME” or “FIELD”) based on the
data characteristics of the pictures.
(default)
• If you select “FIELD”, the picture in the
still mode will be stabilized.
• If you select “FRAME”, the picture in
the still mode will be highly defined.
• An individual picture on TV screen is
called a “frame”, which consists of two
separate images called as “field”.
• Some pictures may be blurred if you
select “AUTO” in the still mode due to
their date characteristics.
PROGRESSIVE: (Default: OFF)
See note on the right.
Before proceeding…
1. Make sure yourTV has progressive scan.
2. Connect with component video cable
NOTE: If there is no picture or picture is
distorted after selecting ‘YES’,
wait about 15 seconds for auto recovery.
Activate Progressive?
SELECT: K/ LSET:ENTER
NO
YES
NO
YES
NO
YES
Confirm again to use progressive scan.
If Picture is good, select ‘YES’.
SELECT: K/ LSET:ENTER
If there is no
picture or you
do not press
any buttons for
15 seconds,
“PROGRESSIVE”
will switch to
“OFF” and it will
exit the “SETUP”
menu.
Note:
PROGRESSIVE:
• You can set
“PROGRESSIVE” to
“OFF” in “DISPLAY”
menu or press and
hold [PLAY B]on the
front of the unit for
more than 5 seconds
during playback, so
that the P- SCAN
indicator on the front
panel turns off.
•
When “PROGRESSIVE”
is “ON”, video signals
from the unit’s VIDEO
OUT and S-VIDEO OUT
jacks will be distorted or
not be output at all.
Select
“Yes”.
ENTER
Select
“Yes”.
ENTER
SETUP
Select
“ON”.
ENTER
ENTER
ENTER
ENTER
E6KPTUD_DP100HH8 A.indd 15E6KPTUD_DP100HH8 A.indd 15 2008/01/08 14:13:402008/01/08 14:13:40

–16 –EN
DVD FUNCTIONS
8 Enter your new 4-
digit password again.
3 Press [ENTER],
and then select “YES”.
6 Select “CHANGE” at step
5 above.
Note:
• Record the password in
case you forget it.
•
If you forget the password,
press [4], [7], [3], [7] at step
3 above, then enter your new
password. Password will be
cleared and parental levels
will be set to “8 [ADULT]”.
PARENTAL_CHANGE
PASSWORD
LEVEL
CHANGE
PARENTAL_PASSWORD
PASSWORD NO
YES
Parental control limits the disc viewing that exceed your settings. (An incorrect password will not be acceptable.)
This feature prevents your children from viewing inappropriate materials.
Parental Levels
Parental level allows you to set the rating levels of your DVD. Playback will stop if the ratings exceed the levels you set.
Follow steps 1 to 2 on page 14.
To Change the Password for Parental Controls
You can change your password for parental controls. Follow steps 1 to 2 on page 14.
PARENTAL menu
5 Select “LEVEL”.
PASSWORD
LEVEL
CHANGE
7 Enter your desired
4-digit password.
Enter new password ----
PASSWORD
LEVEL
CHANGE
9 To exit the menu
PARENTAL menu
4
You can change the other functions. Follow steps 1 to 2 on page 14.
3 Select the desired item.
OTHERS menu
5 To exit the menu
ANGLE ICON: (Default: ON)
Set to “ON” to display when
multiple camera angles are available
during DVD playback.
AUTO POWER OFF: (Default: ON)
Set to “ON” to turn this unit off
automatically after 30 minutes of no
use.
ANGLE ICON
AUTO POWER OFF
ON
OFF
ON
OFF
ANGLE ICON
AUTO POWER OFF
ON
OFF
ON
OFF
OTHERS_ANGLE ICON
ANGLE ICON
AUTO POWER OFF
ON
OFF
ENTER
ENTER
ENTER
TIPS FOR LEVELS
• 8 [ADULT]: DVD software of any grades (adult/
general/children) can be played back.
• 7 [NC-17]: no one under 17 admitted
• 6 [R]: restricted; under 17 requires
accompanying parent or adult guardian
• 5 [PGR]: parental guidance recommended
• 4 [PG13]: unsuitable for children under 13
• 3 [PG]: parental guidance suggested
• 2 [G]: general audience
• 1 [KID SAFE]: suitable for children
PARENTAL Setting
D
OTHERS Setting
E
ENTER
4 Enter your desired
4-digit password.
Enter password ----
PASSWORD NO
YES
6 Select the desired
level, and press
[ENTER].
PAS SWO RD
LEVEL
CHANGE
8 [ADULT]
Re-enter password ----
PASSWORD NO
YES
If you do not need
parental lock, choose
“NO”. Press [ENTER].
123
456
789
0
Enter a new
password again.
ENTER
ENTER
7 To exit the menu
SETUP
123
456
789
0
Select the
desired
setting.
ENTER
Select the
desired
setting.
ENTER
If the password has not been
set yet.
PARENTAL_CHANGE
PASSWORD
LEVEL
CHANGE
Enter password ----
If the password has been
set already, enter the current
4-digit password.
ENTER
ENTER
ENTER
ENTER
ENTER
ENTER
ENTER ENTER
ENTER
ENTER ENTER
ENTER
ENTER
SETUP
SETUP
ENTER
ENTER
ENTER ENTER
ENTER
ENTER
ENTER
ENTER
ENTER
ENTER
ENTER
ENTER
ENTER
ENTER
ENTER
Re-enter password ----
PASSWORD
LEVEL
CHANGE
123
456
789
0
Note:
• For DVD, the resume information will be cleared if you change the
parental level when the resume information is on.
PARENTAL menu
E6KPTUD_DP100HH8 A.indd 16E6KPTUD_DP100HH8 A.indd 16 2008/01/08 14:13:442008/01/08 14:13:44

–17 –EN
INFORMATION
3 Select the desired
PLAYER MENU
Language, using [the
Number buttons].
Troubleshooting Guide
If the unit does not perform properly when operated as instructed in this owner’s manual, refer to the following.
• Some functions are not available in specific modes, but this is not a malfunction. Read the description in this owner’s
manual for more details on correct operations.
• Playback from a desired track and random playback are not available during programmed playback.
• Some functions are prohibited on some discs.
INFORMATION
Note:
• When you do not
wish to initialize,
press [SETUP] to
exit the menu at
step 2.
<SETUP MENU>
Press
twice.
SETUP
STOP
ENTER
ENTER
ENTER
Problem Corrective action
No power –Check if the AC power cord is properly connected.
–Unplug the outlet once, and wait for 5-10 seconds and then plug it in again.
No sound or picture
–Check if the TV is switched on.
–Check the video connection.
–Check the audio/video cable connections to the TV.
(Refer to page 6.)
Distorted picture
–Sometimes a small amount of picture distortion may appear.
This is not a malfunction.
–Connect the unit directly to the TV.
–Set “PROGRESSIVE” correctly in “DISPLAY” menu. Turn it on only if your TV has progressive
scan and you are using the component video connections between the unit and the TV. Disable
progressive scan for all other connections. (Refer to page 6.)
Completely distorted picture or
black/white picture with DVD
–Connect this unit directly to the TV.
–Make sure the disc is compatible with the unit.
No sound or distorted sound –Adjust the volume.
–Check that the speakers are connected correctly.
No audio at digital output –Check the digital connections.
–Check if the audio format of the selected audio language matches your receiver capabilities.
No DTS audio is output. –This unit does not support DTS audio.
This is not a malfunction.
Picture freezes momentarily during
playback. –Check the disc for fingerprints/dirty and clean with a soft cloth wiping from center to edge.
Disc cannot be played back.
–Clean the disc.
–Ensure the disc is inserted in correct direction.
–Check if the disc is defective by trying another disc.
–Cancel the parental lock or change the control level.
–Insert a correct disc that plays back on this unit.
–
Handle a disc with special care so that it does not have fingerprints, scratches, or dusts on its surface.
No return to start-up screen when
disc is removed. –Reset the unit by switching off the unit, then on again.
The unit does not respond to
the remote control.
–Aim the remote control directly at the sensor on the front panel.
–Reduce the distance to the unit.
–Replace the batteries in the remote control.
–Re-insert the batteries with their polarities (+/– signs) as indicated.
–Tune your radio to an empty AM station so that you hear a lot of noises. Then, turn up the
volume. If you hear some signal sound from the radio by pressing buttons on the remote control,
the remote control is working.
–Press and hold any button on remote control toward a digital camera. The remote control is
working if you confirm infrared light through the digital camera.
Buttons do not work or the unit stops
responding. –To completely reset the unit, unplug the AC cord from the AC outlet for 5-10 seconds.
The unit does not respond to some
operating commands during playback. –Operations may not be permitted by the disc. Refer to the instructions of the disc.
The unit cannot read CD / DVD. –Use a commonly available cleaning CD / DVD to clean the lens before sending the unit for
repair.
Angle does not switch. –The angle cannot be switched for DVD which do not contain multiple angles. In some cases
multiple angles are only recorded for specific scenes.
Playback does not start
when the title is selected. –Check the “PARENTAL” setting.
The password for rating level
has been forgotten. –Enter the default password “4737”, then your forgotten password will be cleared.
ENTER
INITIALIZE_INITIALIZE
INITIALIZE YES
LANGUAGE
AUDIO
SUBTITLE
DISC MENU
PLAYER MENU
ENGLISH
FRENCH
SPANISH
SELECT MENU LANGUAGE
1
2
3
1 Press [SETUP].
Reset to the Default Setting (Except for PARENTAL Setting)
F
2 Select “INITIALIZE”.
E6KPTUD_DP100HH8 A.indd 17E6KPTUD_DP100HH8 A.indd 17 2008/01/08 14:13:482008/01/08 14:13:48

–18 –EN
INFORMATION
Specifications
LIMITED WARRANTY
FUNAI CORP. will repair this product, free of charge in the USA in
the event of defect in materials or workmanship as follows:
DURATION:
PARTS: FUNAI CORP. will provide parts to replace defective
parts without charge for one (1) year from the date of
original retail purchase. Certain parts are excluded from
this warranty.
LABOR: FUNAI CORP. will provide the labor without charge for a
period of ninety (90) days from the date of original retail
purchase.
LIMITS AND EXCLUSIONS:
This warranty is extended only to the original retail purchaser. A
purchase receipt or other proof of original retail purchase will be
required together with the product to obtain service under this war-
ranty.
This warranty shall not be extended to any other person or trans-
feree.
This warranty is void and of no effect if any serial numbers on
the product are altered, replaced, defaced, missing or if service
was attempted by an unauthorized service center. This limited war-
ranty does not apply to any product not purchased and used in the
United States.
This product is produced for home use and this warranty only covers
failures due to defects in material or workmanship which occurs dur-
ing normal use. It does not cover damage which occurs in shipment,
or failures which are caused by repairs, alterations or product not
supplied by FUNAI CORP., or damage which results from accident,
misuse, abuse, mishandling, misapplication, alteration, faulty instal-
lation, improper maintenance, commercial use such as hotel, rental
or office use of this product or damage which results from fire, flood,
lightning or other acts of God.
THIS WARRANTY DOES NOT COVER PACKING MATERIALS,
ANY ACCESSORIES (EXCEPT REMOTE CONTROL), ANY
COSMETIC PARTS, COMPLETE ASSEMBLY PARTS, DEMO
OR FLOOR MODELS.FUNAI CORP. AND ITS REPRESENTA-
TIVES OR AGENTS SHALL IN NO EVENT BE LIABLE FOR ANY
GENERAL, INDIRECT OR CONSEQUENTIAL DAMAGES ARIS-
ING OUT OF OR OCCASIONED BY THE USE OF OR THE IN-
ABILITY TO USE THIS PRODUCT. THIS WARRANTY IS MADE
IN LIEU OF ALL OTHER WARRANTIES, EXPRESS OR IMPLIED,
AND OF ALL OTHER LIABILITIES ON THE PART OF FUNAI,
ALL OTHER WARRANTIES INCLUDING THE WARRANTY OF
MERCHANTABILITY, AND FITNESS FOR A PARTICULAR PUR-
POSE, ARE HEREBY DISCLAIMED BY FUNAI AND ITS REP-
RESENTATIVES IN THE UNITED STATES. ALL WARRANTY
INSPECTIONS AND REPAIRS MUST BE PERFORMED BY AN
AUTHORIZED SERVICE CENTER. THIS WARRANTY IS VALID
WHEN THE UNIT IS CARRIED-IN TO AN AUTHORIZED SERV-
ICE CENTER.
IMPORTANT:
THIS LIMITED WARRANTY GIVES YOU SPECIFIC LEGAL
RIGHTS. YOU MAY HAVE OTHER RIGHTS THAT VARY FROM
STATE TO STATE. IF, AT ANY TIME DURING THE WARRANTY
PERIOD, YOU ARE UNABLE TO OBTAIN SATISFACTION WITH
THE REPAIR OF THIS PRODUCT, PLEASE CONTACT FUNAI
CORP.
ATTENTION:
FUNAI CORP. RESERVES THE RIGHT TO MODIFY ANY
DESIGN OF THIS PRODUCT WITHOUT PRIOR NOTICE.
WARRANTY STATEMENT REGARDING NON AUTHORIZED
REPAIRS:
To obtain warranty service, you must take the product, or
deliver the product freight prepaid, in either its original packag-
ing or packaging affording an equal degree of protection, to any
AUTHORIZED SERVICE CENTER. FUNAI CORP. will not reim-
burse you for any service done by unauthorized service providers
without prior written approval.
To locate your nearest AUTHORIZED SERVICE CENTER or for
general service inquiries, please contact us at:
FUNAI CORPORATION
Customer Service
Tel :[phone]
http://www.funai-corp.com
19900 Van Ness Avenue, Torrance, CA 90501
Output signal format :
NTSC color
Power source :
120V AC +/- 10%, 60Hz +/- 0.5%
Power consumption :
10W (standby : 0.9W)
Operating temperature :
41°F (5°C) to 104°F (40°C)
Dimensions :
W : 8.3” (210mm)
H : 2.0” (50mm)
D : 9.7” (245mm)
Weight :
Approx 1.8lbs. (0.8kg)
• Designs and specifications are subject
to change without notice.
• If there is a discrepancy between
languages, the default language will be
English.
E6KPTUD_DP100HH8 A.indd 18E6KPTUD_DP100HH8 A.indd 18 2008/01/08 14:13:492008/01/08 14:13:49

–19 –ES
Español
✄
5
123
456
789
0
+10
• Para seleccionar directamente el capítulo
o título.
•Para seleccionar directamente la canción.
(CD)
•Para seleccionar directamente el grupo/
canción. (MP3)
ENTER
•Para mover el cursor y determinar la
posición. •Para mover el cursor y determinar la posición.
A-B
•Para repetir entre su punto A y B
seleccionado. •Para repetir entre su punto A y B seleccionado.
ANGLE
•Para seleccionar los ángulos de la
cámara en un disco. ------
AUDIO
•Para seleccionar idiomas de audio en un
disco. •Para seleccionar “ESTÉREO”, “L-ch” o “R-ch”. (CD)
CLEAR
•Para eliminar el Nº de estado en la
entrada de programa.
•Para borrar los números mal entrados.
•Para borrar el punto para la repetición
A-B.
•Para eliminar el Nº de estado en la
entrada de programa.
•Para borrar los números mal entrados.
•Para borrar el punto para la repetición
A-B.
DISPLAY
•Para mostrar el modo de disco actual. • Para mostrar el modo de disco actual.
REV FWD
• Para buscar en avance/retroceso por un disco.
•Para empezar la reproducción en avance
lento durante el modo de pausa.
•Para buscar en avance/retroceso por un
disco.
MENU
•Para llamar el menú en un disco. ------
MODE
•Para disponer el orden de reproducción o
la reproducción aleatoria.
•Para activar/desactivar el nivel del negro.
•
Para activar/desactivar el ambiental virtual.
•Para disponer el orden de reproducción o
la reproducción aleatoria.
•Para activar/desactivar el ambiental
virtual.
OPEN/CLOSE
•Para abrir o cerrar la bandeja del disco.
•Para encender la unidad. •Para abrir o cerrar la bandeja del disco. •Para encender la unidad.
PAUSE
•Para hacer una pausa en la reproducción.
•
Para avanzar la reproducción un cuadro cada vez.
•Para hacer una pausa en la reproducción
del disco.
PLAY
• Para empezar la reproducción del disco.
•Para encender la unidad. •Para empezar la reproducción del disco. •Para encender la unidad.
REPEAT
•Para reproducir repetidamente un
capítulo o título.
•Para reproducir repetidamente una
canción o disco. (CD)
•Para reproducir repetidamente una
cansión, grupo o disco. (MP3)
RETURN
•Para volver a la operación anterior en el
menú. •Para volver a la operación anterior en el menú.
SEARCH
MODE •Para buscar un capítulo, título o tiempo. •Para buscar una canción.
•Para buscar el tiempo. (CD)
•Para buscar los grupos. (MP3)
SETUP
• Para llamar el menú de ajustes de DVD. •Para llamar el menú de ajustes de DVD.
SKIP
• Para saltar capítulos o titulo. •Para saltar canciones. (CD)
•Para saltar los grupos o canciones. (MP3)
STANDBY-ON
•Para encender o apagar la unidad. •Para encender o apagar la unidad.
STOP
• Para parar la reproducción. •Para parar la reproducción.
SUBTITLE
•Para seleccionar subtítulos en un disco. ------
TOP MENU
•Para llamar el menú inicial en un disco. ------
ZOOM
•Para ampliar la imagen de vídeo en DVD.
(2x / 3x / 4x / 1/2x) ------
2 Seleccione “PLAYER MENU”.
1 Confirme que ha seleccionado
“LANGUAGE”.
Si su televisor tiene entradas de
AUDIO/VIDEO vea la sección
“Connection to a TV” en la página 6 en
el manual de manejo. En caso
contrario, vea la sección “Connecting
to RF Modulator (Not Supplied)” en
la página del frente en el manual de
manejo.
STANDBY-ON
AUDI O
SUBTITLE
ANGLE
REPEAT CLEAR
A-B
PAUSE SKIP
OPEN/CLOSE
DISPLAY SEARCH MODE
12
3
45
6
78
9
0+10
PLAY
REV FWD
STOP
Español
Conexiones
4 Para salir del menú
3 Seleccione el idioma deseado para
las indicaciones en la pantalla.
LANGUAGE_PLAYER MENU
AUDIO
SUBTITLE
DISC MENU
PLAYER MENU
ENGLISH
FRANÇAIS
ESPAÑOL
1
Para cambiar el idioma en
la pantalla
3
Reproducción
4
4
3
Antes.
¡Encienda el televisor,
amplificador y otros equipos
conectados a esta unidad.
Asegúrese
que el
televisor y el
sintonizador
de audio
están en el
canal
correcto.
Control remoto
Instalación de las pilas en
el control remoto
1
2
13
SETUP
ENTER
ENTER
ENTER
ENTER
ENTER
ENTER
ENTER
ENTER
ENTER
1 Para abrir o
cerrar la bandeja
del disco
2 Ponga un disco
con la etiqueta
hacia arriba.
3 Para empezar la
reproducción
4 Para parar la
reproducción
STOP
STANDBY-ON
OPEN/CLOSE
PLAY
STOP
SETUP
STANDBY-ON
1
ENTER
Disco
Botón
(Orden alfabético)
LANGUAGE_PLAYER MENU
AUDIO
SUBTITLE
DISC MENU
PLAYER MENU
ENGLISH
FRANÇAIS
ESPAÑOL
LANGUAGE
AUDIO
SUBTITLE
DISC MENU
PLAYER MENU
2
ENTER
E6KPTUD_DP100HH8 A.indd 19E6KPTUD_DP100HH8 A.indd 19 2008/01/11 17:45:162008/01/11 17:45:16

✄
Before:
Turn on the TV, amplifier
and any other devices which
are connected to this unit.
Make sure the
TV and audio
receiver are set
to the correct
channel.
2 Select “PLAYER MENU”.
1 Confirm that “LANGUAGE” is selected.
If your TV has AUDIO/VIDEO input
jacks, see the section “Connection to a
TV” on page 6 of the owner’s manual.
If not, see the section “Connecting to
RF Modulator (Not Supplied)” on the
front page of the owner’s manual.
Printed in China E6KPTUD
1VMN24994 ★★★★★
STANDBY-ON
AUDI O
SUBTITLE
ANGLE
REPEAT CLEAR
A-B
PAUSE SKIP
OPEN/CLOSE
DISPLAY SEARCH MODE
12
3
45
6
78
9
0+10
PLAY
REV FWD
STOP
Quick Use Guide
Connections
4 To exit the menu
3 Select the desired language for the
on-screen language.
1
To Change the
On-Screen Language
3
Playback
4
4
3
Remote Control
5
Installing the Batteries for
the Remote Control
2
1
2
13
SETUP
ENTER
ENTER
ENTER
ENTER
ENTER
ENTER
ENTER
ENTER
ENTER
1 To open the disc
tray
2 Insert a disc with
label facing up.
3 To start playback 4 To stop playback
STOP
STANDBY-ON
OPEN/CLOSE
PLAY
STOP
SETUP
STANDBY-ON
1
ENTER
123
456
789
0
+10
• To select chapter or title directly. • To select track directly. (CD)
• To select folder/file directly. (MP3)
ENTER
• To move the cursor and determine its
position. • To move the cursor and determine its position.
A-B
• To repeat between your chosen point of
A and B. • To repeat between your chosen point of A and B.
ANGLE
• To select camera angles on a disc. ------
AUDIO
• To select audio language on a disc. • To select “STEREO”, “L-ch” or “R-ch”.
(CD)
CLEAR
• To remove status number in program
input.
• To clear the numbers entered incorrectly.
• To cancel the point for A-B repeat.
• To remove status number in program
input.
• To clear the numbers entered incorrectly.
•
To cancel the point for A-B repeat.
DISPLAY
• To display the current disc mode. • To display the current disc mode.
REV FWD
• To search forward/backward through
a disc.
• To begin slow forward playback in the
pause mode.
• To search forward/backward through
a disc.
MENU
• To call up the menu on a disc. ------
MODE
• To arrange the playing order or play
randomly.
• To set black level on/off.
• To set virtual surround on/off.
•
To arrange the playing order or play
randomly.
• To set virtual surround on/off.
OPEN/CLOSE
• To open or close the disc tray.
• To turn on the unit. • To open or close the disc tray. • To turn on the unit.
PAUSE
• To pause disc playback.
•
To advance playback one frame at a time.
• To pause disc playback.
PLAY
• To begin disc playback.
• To turn on the unit. • To begin disc playback. • To turn on the unit.
REPEAT
• To play back a chapter or title repeatedly.
• To play back a track or disc repeatedly.
(CD)
• To play back a file, folder or disc
repeatedly. (MP3)
RETURN
• To return to the previous operation in
menu. • To return to the previous operation in menu.
SEARCH
MODE • To search chapter, title or time. • To search tracks.
• To search time. (CD)
• To search folders. (MP3)
SETUP
• To call up the setup menu. • To call up the setup menu.
SKIP
• To skip chapters or titles. • To skip tracks. (CD)
• To skip folders or files. (MP3)
STANDBY-ON
• To turn the unit on/off. • To turn the unit on/off.
STOP
• To stop playback. • To stop playback.
SUBTITLE
• To select subtitles on a disc. ------
TOP MENU
• To call up the top menu on a disc. ------
ZOOM
• To magnify part of a picture.
(2x / 3x / 4x / 1/2x) ------
Media
Button
(Alphabetical order)
LANGUAGE_PLAYER MENU
AUDIO
SUBTITLE
DISC MENU
PLAYER MENU
ENGLISH
FRANÇAIS
ESPAÑOL
LANGUAGE_PLAYER MENU
AUDIO
SUBTITLE
DISC MENU
PLAYER MENU
ENGLISH
FRANÇAIS
ESPAÑOL
LANGUAGE
AUDIO
SUBTITLE
DISC MENU
PLAYER MENU
ENTER
E6KPTUD_DP100HH8 A.indd 20E6KPTUD_DP100HH8 A.indd 20 2008/01/11 17:45:212008/01/11 17:45:21
