G4M HDP-1 User manual

HDP-1
HIGH TOP UPRIGHT DIGITAL PIANO
User Manual

3
WARNING! EN
Do not open cover. No user-serviceable parts inside. Refer servicing to qualified service personnel
Do not place the product in a location near a heat source such as a radiator, or in an area subject to direct
sunlight, excessive dust, mechanical vibration or shock
The product must not be exposed to dripping or splashing and no objects filled with liquids, such as vases, shall
be placed on the product
No naked flame sources, such as lighted candles, should be placed on the product
Allow adequate air circulation and avoid obstructing vents (if present) to prevent internal heat build-up. The
ventillation must not be impeded by covering the appliance with items such as newspapers, table-cloths,
curtains etc.
The mains plug is used to disconnect the appliance from the mains supply. Ensure that the mains outlet is easily-
accessible and remove the plug from the mains outlet if you notice any abnormality with the appliance.
VAROVÁNÍ! CZ
Nezakrývejte. Uvnitř nejsou žádné součásti opravitelné uživatelem. S požadavkem na servis se odkažte na
kvalifikované servisní oddělení.
Neumisťujte produkt v blízkosti zdroje tepla, jako je radiátor, nebo na místo s přímým slunečním světlem,
nadměrným prášení, mechanickými vibracemi nebo šokem.
Produkt nesmí přijít do kontaktu s vodou a žádné objekty naplněné tekutinami, jako například vázy, by neměly být
umístěny na produkt.
Žádné zdroje otervřeného ohně, jako například svíčky, by neměly být umístěny na produkt.
Umožněte dostatečnou cirkulaci vzduchu a vyhněte se obstrukci ventilátorů (pokud jsou přítomné) pro předejití
interního přehřívání. Ventilace nesmí být narušena překrytím zařízení výrobky jako např. noviny, kuchyňské
utěrky, záclony apod.
Hlavní kabel umožňuje odpojit zařízení od elektřiny. Ujistěte se, že hlavní napájecí výstup je snadno dostupný a
odpojte kabel pokud zaznamenáte jakoukoliv abnormalitu na zařízení.
DVARSEL! DK
Dækslet må ikke åbnes. Ingen bruger-udskiftelige dele indeni. Overlad service til kvalificeret service personale
Placer ikke produktet i nærheden af varmekilder såsom en radiator eller i direkte sollys, meget støv, mekaniske
vibrationer eller stød
Produktet må ikke udsættes for vand eller stænk, og ingen genstande fyldt med væsker, f.eks. vaser, må
anbringes på produktet
Må ikke placeres nær åben ild, tændte stearinlys må ikke placeres på produktet
Vær sikker på at der er tilstrækkelig luftcirkulation og undgår at dække ventiler (hvis der er nogen) for at undgå
at produktet bliver varmt. Ventillationen må ikke blokeres med overdækning af apparatet med genstande som
aviser, dug, gardiner osv.
Stikket bruges til at afbryde apparatet fra strømmen. Sikre at stikkontakten er let tilgængelige, og fjern stikket
fra stikkontakten, hvis du bemærker noget unormalt med apparatet.
WAARSCHUWING! NL
Maak de behuizing niet open. Dit toestel bevat geen onderdelen die door de gebruiker kunnen worden
vervangen.Laat onderhoud over aan bevoegd onderhoudspersoneel.
Plaats het produkt niet in de buurt van een hittebron zoals een radiator of in direkt zonlicht of in een stofrijke
omgeving, mechanische vibratie of schok.
Plaats het produkt niet in de buurt vanspattende of lekkende voorwerpen gevuld met een vloeistof zoals
bijvoorbeeld een vaas.
Er mogen geen open vlammen zoals aangestoken kaarsen op de apparatuur worden geplaatst.
Zorg om overhitting te voorkomen voor voldoende ventilatie enbellemmer ventilatieroosters niet. Bedek het
produkt niet met dingen zoals kranten, tafellakens, gordijnen etc.
De stekker van dit apparaat wordt gebruikt om het apparaat aan en uit te zetten. Zorg ervoor dat het stopcontact
gemakkelijk bereikbaar is en haal de stekker uit het stopcontact als u enige onregelmatigheid ondervindt.
VAROITUS! FI
Älä avaa kantta. Ei sisällä käyttäjä-huollettavia osia. Huollot saa suorittaa vain pätevä huoltomies.
Älä säilytä tuotetta minkään kuuman lähellä kuten patteri tai suorassa auringonpaisteessa, pölyisessä,
mekaanisessa värinässä tai iskussa
Tuotetta ei saa altistaa tippuvalle tai loiskeelle tai nesteitä sisältäviä tuotteita kuten maljakko eivät saa olla
tuotteen lähettyvillä
Avotulia kuten sytytetty kynttilä ei saa olla tuotteen päällä.
Salli riittävä ilmankierto ja vältä tuuletusaukkojen tukkiminen (jos sellaisia on olemassa) estämään sisäisen
lämmön muodostuminen. Tuuletusta ei saa estää peittämällä laite esineillä, kuten sanomalehdillä, pöytäliinoilla,
verhoilla jne.
ATTENTION! FR
Ne pas ouvrir le couvercle. Aucune pièce interne réparable par l’utilisateur. Confier la réparation a du personnel
de réparation qualifié
Ne pas laisser l’appareil à proximité d’une source de chaleur telle qu’un radiateur, dans un endroit directement
exposé aux rayons du soleil, trop poussiéreux, ou pouvant subir des chocs mécaniques
L’appareil ne doit pas être exposé aux gouttes d’eau et aux éclaboussures, et aucun objet rempli de liquide, tel
qu’un vase, ne doit être posé dessus
Ne placer aucune source de flamme nue, telle qu’une bougie allumée, sur l’appareil
Assurer une circulation d’air susante et éviter d’obstruer les fentes (le cas échéant) afin d’éviter une surchaue
interne. La ventilation ne doit pas être bloquée en couvrant l’appareil avec des objets tels que des journaux, des
nappes, des rideaux, etc.
La prise secteur est utilisée comme dispositif de débranchement. La prise murale doit être facile d’accès,et en
cas d’anomalie de l’appareil, débrancher la prise de courant au niveau de la prise murale.
WARNUNG! DE
Önen Sie nicht das Gehäuse. Im Inneren befinden sich keine vom Benutzer zu wartenden Teile. Überlassen Sie
Wartungsarbeiten qualifiziertem Fachpersonal.
Stellen Sie das Produkt nicht an einen Ort in der Nähe einer Wärmequelle wie etwa eines Heizkörpers oder in
einem Bereich mit direktem Sonnenlicht, übermäßigem Staub, mechanischen Vibrationen oder Stößen.
Schützen Sie das Produkt vor tropfenden oder spritzenden Flüssigkeiten, und stellen Sie keine mit Flüssigkeiten
gefüllten Gegenstände wie Vasen auf das Produkt.
Oene Feuerquellen wie Kerzen dürfen nicht auf dem Gerät abgestellt werden.
Sorgen Sie für eine ausreichende Luftzirkulation und vermeiden Sie, dass die Lüftungsschlitze (falls vorhanden)
abgedeckt werden, um einen internen Wärmestau zu verhindern. Die Belüftung darf nicht durch Abdecken des
Gerätes mit Gegenständen wie Zeitungen, Tischdecken, Vorhängen usw. blockiert werden.
Der Netzstecker dient zum Trennen des Gerätes vom Netz. Vergewissern Sie sich, dass die Steckdose leicht
zugänglich ist, und ziehen Sie den Stecker aus der Steckdose, wenn Sie eine Anomalie mit dem Gerät bemerken.
AVVERTIMENTO! IT
Non aprire il coperchio. Se fosse necessario, riferirsi ad un esperto.
Non esporre il prodotto a fonti di calore, luce del sole diretta, polvere, vibrazioni meccaniche o altri possibili
shock.
Non esporre il prodotto a perdite di liquido o a spruzzi. Non appoggiare nessun oggetto contenente acqua sul
prodotto.
Non esporre il prodotto a fuoco, candele o oggetti simili.
Assicurarsi la circolazione dell’aria e non ostruire le ventole, se presenti, per evitare il surriscaldamento. La
ventilazione non deve subire impedimenti dovuti a giornali, tovaglie, tende, ecc.
La spina principale viene utilizzata per disconnettere il prodotto dalla principale fonte di energia. Assicurarsi che
la spina sia facilmente accessibile e disconnettere l’unità nel caso si notassero dei difetti di funzionamento.
ADVARSEL! NO
Ikke åpne dekselet. Inneholder ingen deler som kan brukes. Overlat reperasjon til kvalifisert servicepersonell.
Ikke plasser produktet i nærheten av varmekilder som f.eks. en radiator, eller i områder som er utsatt for direkte
sollys, mye støv, mekanisk vibrasjon eller støt.
Produktet må ikke utsettes for drypping eller spruting, og gjenstander som er fylt med væsker, som f.eks. vaser,
skal ikke plasseres på produktet.
Åpne flammer, som f.eks. tente lys, bør ikke plasseres på produktet.
Tillat tilstrekkelig luftsirkulasjon og unngå å blokkere ventiler (hvis tilstede) for å forhindre intern
varmeoppsamling. Pass på at ventilasjon ikke hindres ved å unngå å dekke apparatet med ting som aviser,
bordduker, gardiner osv.
Stikkontakten brukes til å koble apparatet fra strømforsyningen. Forsikre deg om at stikkontakten er lett
tilgjengelig og ta støpselet ut av stikkontakten hvis du oppdager uregelmessigheter under bruk av apparatet.
OSTRZEŻENIE! PL
Nie otwierać pokrywy. W środku nie ma części nadających się do naprawy przez użytkownika. Prosimy
pozostawić serwis dla wyszkolonego personelu.
Nie umieszczać produktu w pobliżu źródła ciepła, np. grzejnika, lub w bezpośrednim świetle słonecznym, kurzu,
czy mechanicznym wibracjom.
Produkt ten nie może być eksponowanyna kapanie lub chlapanie, aprzedmioty wypełnione płynami, takie jak
wazy, nie powinny być na nim umieszczane.
Źródła otwartego ognia, takie jak np. świece, nie powinny być umiejscowiane na produkcie.
Należy zapewnić odpowiednią wentylację i unikaćblokowania otworów wentylacyjnych, aby uniknąć
wewnętrznegowzrostu temperatury.Wentylacja nie powinna być utrudniana poprzez nakrywanie urządzenia
gazetami, obrusami czy zasłonami.
Wtyczka sieciowa służy do odłączenia urządzeniaod zasilania sieciowego. Należy upewnić się, że gniazdo
sieciowe jest łatwo dostępne, a w razie wystąpienianieprawidłości w funkcjonowaniu urządzenia odłączyć je
od zasialania sieciowego.
ATENÇÃO! PT
Não abra a tampa. Não tente a reparação do instrumento por si. Dirija-se a pessoal qualificado
Não aproxime a uma fonte de calor excessivo ou exponha o produto à luz solar, poeira, vibração ou choque
Não mantenha o produto num local húmido ou perto líquidos como vasos, etc.
Não aproxime o produto a fontes de fogo vivo, como velas
Mantenha o produto num espaço suficientemente arejado de forma a evitar sobre-aquecimento. Não bloqueie a
ventilação do instrumento, cobrindo-o com artigos como cortinas, toalhas de mesa ou jornais
O transformador é utilizado para conectar e desconectar o artigo da principal fonte de energia. Certifique-se que
a ficha é facilmente acessível e que o artigo está devidamente ligado à corrente se detectar alguma anomalia
com o funcionamento
VÝSTRAHA! SK
Neotvárajte kryt. Vo vnútri nie sú žiadne súčasti, ktoré sú opraviteľné užívateľom. S požiadavkou na servis sa
obráťte na kvalifikované servisné stredisko.
Nevystavujte produkt do blízkosti akéhokoľvek tepelného zdroja ako napr. radiátora, alebo do kontaktu so
slnečným žiarením, nadmerným prašným prostredím, mechanickým vibráciám alebo šokom.
Produkt nesmie prísť do kontaktu s vodou a žiadny objekt naplnený vodou, ako napr. váza, nesmie byť umiestnený
na produkt.
Žiadne výrobky s otvoreným ohňom, ako napr. sviečky, by nemali byť umiestnené na produkt.
Umožnite dostatočnú cirkuláciu vzduchu a zabráňte obštrukcii ventilačných otvorov (ak sú prítomné) kvôli
prevencii vnútorného prehrievania. Ventilácia nesmie byť narušená prekrytím zariadenia výrobkami ako napr.
noviny, kuchynské utierky, záclony a pod.
Hlavný kábel umožňuje odpojiť zariadenie od elektriny. Uistite sa, že hlavný napájací výstup je ľahko dostupný a
odpojte kábel ak zaznamenáte akúkoľvek abnormalitu na zariadení.
OPOZORILO! SI
Ne odpirajte pokrova. V notranjosti ni nobenih delov, ki jih uporabnik lahko sam popravlja. Popravilo prepustite
usposobljenemu osobju
Ne postavljajte izdelka na lokacijo v bližini vira toplote, kot je radiator, ali na območje, ki je izpostavljeno
neposredni sončni svetlobi, pretiranem prahu, mehanskim tresljajem ali udarcem
Izdelek ne sme biti izpostavljen kapljanju ali brizganju in nobeni predmeti, napolnjeni z vodo, kot so vaze, se ne
smejo postaviti na izdelek
Nobenega od virov odprtega ognja, kot so vžgane sveče, se ne sme postavljati na izdelek
Zagotovite zadostno kroženje zraka in umaknite ovire na odprtinah (če obstajajo), zaradi preprečevanja kopičenja
notranje toplote. Ventilacijo se ne sme ovirati s prekrivanjem naprave s predmeti, kot so časopisi, prti, zavese itn.
Omrežni vtič se uporablja za izklop naprave iz električnega omrežja. Poskrbite, da je omrežna vtičnica zlahka
dostopna in izvlecite vtikač iz vtičnice, če opazite kakršno koli nepravilnost pri napravi.
¡ADVERTENCIA! ES
No abra la tapa. No intente reparar el aparato usted mismo.  Llévelo a reparar por personal calificado.
No coloque el aparato cerca de fuentes de calor excesivo o donde esté expuesto a luz solar directa, golpes,
vibraciones o polvo.
Evite lugares expuestos a humedad. No ponga objetos llenos de líquidos en la superficie de este aparato.
No se deben colocar fuentes de llama desnuda, como velas encendidas, en la superficie de este aparato.
Mantenga suficiente espacio alrededor del aparato para permitir una ventilación adecuada. No obstruya o tape
las aberturas con objetos como periódicos, manteles, cortinas, etc.
El enchufe se utiliza para desconectar el producto de la corriente. Si nota algún defecto, desconéctelo de la toma
de corriente.
VARNING! SE
Öppna ej locket. Inga användarvänliga delar inuti. För reparationer vänd er till kvalificerad servicepersonal
Ställ ej produkten vid en värmekälla t.ex element, i direkt solljus, damm, elektronisk vibration eller shock.
Produkten bör ej bli utsatt för droppande eller stänk och inga objekt fyllda med vätskor som t.ex vaser skall
ställas på produkten.
Ingen källa till öppna flammor som t.ex tända ljus bör placeras på produkten.
Tillåt tillräcklig luftcirkulation och blockera ej eventuella ventiler för att undvika intern överhettning. Ventilen bör
ej täckas av föremål såsom tidningar, dukar, gardiner etc.
Nätkontakten används för att koppla bort apparaten från eluttaget. Se till att eluttaget är lättåtkomligt och
avlägsna kontakten från eluttaget om du upptäcker något abnormalt med produkten.
Warnings

4
Thank you for purchasing the HDP-1 High Top Upright Digital Piano.
To get the most out of your product, please read this manual carefully.
BOXCONTENTS
• 1 x 88 Key High Top Digital Piano
• 1 x PSU
• 1 x User Manual
FEATURES
• 88 Hammer Action Keys
• 127 Sounds
• Bluetooth Connectivity
• DSP Eects
• Aux Input, Aux Output, USB Input and USB to Host Connections
• 2 Track Recording
High Top Upright Digital Piano

PEDAL
USB AUX OUT AU X IN DC IN
FRONT
PEDAL
USB AUX OUT AU X IN DC IN
REAR
5
5
12 3 4
6 7 8
Connections
FRONT CONNECTION PANEL
1. MASTER VOLUME
Use this control to adjust the global volume of the piano. It is advised
to set the MASTER VOLUME to “MINIMUM” when powering on the
piano, and then adjust the volume to your desired level when playing.
When using headphones, this dial is used to control the level of the
headphones also.
2. POWER
Use this switch to power on the device when it is connected to the
mains.
3. USB DRIVE
Insert a compatible USB flash drive (not included) to play MP3 files
through the piano’s internal speakers.
4. HEADPHONES OUTPUTS
Two sets of standard headphones can be connected via the
headphones outputs for private practice. The internal speakers are
automatically muted when headphones are connected to headphones
1 jack.
REAR CONNECTION PANEL
5. USB TO HOST
The HDP-1 allows the transfer of MIDI via USB from the piano to an
audio interface or “host.” Use the audio interface to control the MIDI
signal.
6. AUX OUTPUT
The 3.5mm can be used to connect the piano to a compatible external
sound system, such as a keyboard amplifier, interface, or mixer.
7. AUX INPUT
The 3.5mm AUX IN stereo inputs allow you to mix an external
sound source (such as a smartphone or MP3 player) with the piano’s
internal sounds, for playback through the piano’s in-built speakers or
headphone output.
8. DC POWER INPUT
Safely connect the included power supply, firstly to the piano and
then to the mains, before turning on the piano.

6
3
2
1
Foot Pedals
After following the included assembly guide, and before powering on
the piano, please ensure that the foot pedals cable is connected to the
pedal input jack on the rear connection panel.
The HDP-1 features a three-pedal unit, providing the same pedal
configuration as a grand piano.
SOFT PEDAL (LEFT)
Pressing the soft pedal will change the character of the notes played,
making them softer and quieter.
SOSTENUTO PEDAL(CENTRE)
The sostenuto pedal is similar to the damper pedal, however pressing
this pedal will only sustain the noted being played when the pedal is
pressed. Any notes played after the pedal is pressed/held down will
not sustain.
DAMPER/SUSTAIN PEDAL (RIGHT)
When the sustain pedal is pressed down, the sound of all notes played
will sustain, even after releasing the keys.
“Half pedalling” is possible, meaning the sustain duration will depend
how far the pedal is pressed down, a response similar to the delicate
controls found on acoustic pianos.
ROTARYEFFECTS
When the FX option is set to ROTARY, the soft pedal (left) and
sostenuto pedal (middle) will control the rotary eect. In this mode, the
left pedal controls the rotary eect speed and the middle pedal stops
the rotary eect. Please note, the rotary eect is only applied to the
main selected voice.

TEMPO
G.PIANO
STRINGS
MUSIC ASSIST
GUITAR
DUAL
ACCOMP START/STOP RHYTHM
OTHERS
E.PIANO ORGAN
FUNCTION
HDP-1
/SAVE
M1 M2 M3
M4 M5 M6
/
/LOAD
Control Panel
1
2
7
3
5
8 9 10
11 12 13
6
4
1. LCD SCREEN
Displays the current parameters, values and selected functions.
2. ARROW KEYS / ENTER
Use the up, down, left and right arrow keys to move the cursor on
the screen. Use the middle ENTER button to enter a specific menu or
select an item.
3. BACK / SAVE
Use the BACK button to go back one step. Or press and hold to SAVE
performacre settings
4. HOME / LOAD
Use the HOME button to return to the main screen. Or press and
hold to LOAD saved performances.
5. TEMPO
Use the TEMPO button to quickly access the metronome tempo and
adjust it using the left and right arrow buttons.
6. FUNCTION
Press this to access the functions menu.
7. SOUNDS / REGISTRATION
Use the six SOUNDS buttons to select the desired instrument bank.
8. MUSIC ASSIST
Use this to enter MUSIC ASSIST mode and access the Metronome,
Record, Lesson Music and USB Flash Drive functions.
9. PLAY / STOP
Use these buttons to play / stop the Metronome, Record and Lesson
Music functions.
10. DUAL
Use this to enter DUAL mode and access the Layer, Split and Twin
piano functions.
11. ACCOMP
Use this button to access the accompaniment menu.
12. START / STOP
Use this button to start and stop playback of the rhythm
accompaniments.
13. RHYTHM / FX
Press the RHYTHM button to display the list of accompaniment
rhythms. Press and hold this button to display the list of in-built
special FX.
7

8
Sound Select
The HDP-1 allows you to choose from 127 main voices,
a percussion kit and 2 x sound eect sets.
The piano’s default sound is the German Grand Piano. To select a
dierent sound, press the desired sound group button, then press
the middle enter button to display that group’s sounds list. Select the
desired sound using the up or down arrow buttons.
Sounds can also be selected using the left and right arrow buttons on
the main screen. Also, pressing a sound group button twice will display
the sound list for that group.
To return to the main screen, press either the BACK or HOME buttons.
G.Piano
German G.Piano
Concert G.Piano
Warm G.Piano
Stage G.Piano
Mellow G.Piano
Light Pop G.Piano
Honkytonk Piano
E.Piano
Vintage E.Piano
Modern E.Piano
Bright E.Piano
Clavinet
Harpsichord
Vibraphone
Synthesizer 1
Synthesizer 2
Celesta
Glockenspiel
Music Box
Marimba
Xylophone
Tubular bells
Santur
Organ
Pipe Organ
E.Organ Gospel
E.Organ Jazz
E.Organ Rock
Reed Organ
Harmonica
Concertina
Accordion
Strings
Symphony Strings
Bright Strings
Brass Strings
Pizzicato Strings
Synth Strings
Slow Strings
Tremolo Strings
Violin Soloist
Viola Soloist
Cello Soloist
Contrabass 1
Contrabass 2
Choir Aha
Vocal Ooh
Chorale
Voice Doo
Voice Ooh
Vocal Doo
Girls Ooh
Orchestral Harp
Orchestral Timpani
Guitar
Acoustic Guitar
Steel Guitar
Clean Guitar
Jazz Guitar
Driven Guitar
Distortion Guitar
Muted Guitar
Guitar Harmonics
Acoustic Bass
Fingered Bass
Picked Bass
Fretless Bass
Slap Bass 1
Slap Bass 2
Synth Bass 1
Synth Bass 2
Others
Gayageum
Daegeum
Brass Section
Big Band Brass
Synth Brass 1
Synth Brass 2
French Horn
Trumpet Soloist
Trombone
Tuba
Muted Trumpet
Alto Saxophone
Tenor Saxophone
Soprano Saxophone
Baritone Saxophone
Flute Soloist
Orchestral Flute
English Horn
Clarinet
Bassoon
Piccolo
Orchestral Oboe
Recorder
Pan Flute
Bottle Blow
Whistle
Ocarina
Synth Lead 1
Synth Lead 2
Synth Lead 3
Synth Lead 4
Synth Lead 5
Synth Lead 6
Synth Pad 1
Synth Pad 2
Synth Pad 3
Synth Pad 4
Synth Pad 5
Synth Pad 6
Synth Pad 7
Synth Pad 8
Synth Eect 1
Synth Eect 2
Synth Eect 3
Synth Eect 4
Synth Eect 5
Synth Eect 6
Synth Eect 7
Sitar
Banjo
Kalimba
Bagpipes
Fiddle
Shehnai
Tinkle Bell
Agogo
Steel Drums
Wood Block
Taiko
Melodic Tom
Drum Set
SFX 1 Set
SFX 2 Set

The DUAL mode consists of Layer, Split and Twin Piano functions and
allows a wider variety of sounds and playing options.
LAYER
This function allows two sounds to be played simultaneously.
Firstly, select the main sound, as described in the Sound Select
section. Then, press the DUAL button once to access the layer mode.
The default layer sound is Symphony Strings. When the screen cursor
is next to “LY” a dierent layer sound can be chosen by pressing the
desired sound group button, then using the left and right arrow buttons
as required.
The cursor can be moved using the up or down arrow buttons, to select
either the main sound or layered sound.
The balance between the volumes of the two layered sounds can be
adjusted in the function menu.
To turn o the layer sound, press the DUAL button three times
(Layer -> Layer+Split -> Split -> O)
SPLIT
The piano keys can be “split” into two sections, allowing dierent
sounds to be played in the left and right hands.
Firstly, select the main sound, as described in the Sound Select section.
This sound will be assigned to the right-hand section of the piano. Then,
press the DUAL button twice to access the split mode. The default layer
sound is Symphony Strings. When the screen cursor is next to “SP” a
dierent left-hand sound can be chosen by pressing the desired sound
group button, then using the left and right arrow buttons as required.
The cursor can be moved using the up or down arrow buttons, to select
either the main sound or split sound.
The balance between the volumes of the two sounds can be adjusted in
the function menu.
The default point at which the piano sounds are “split” is piano key F#3.
This can be adjusted using the function menu and selecting Voice, then
Split Point, followed by the desired piano key to divide the two selected
sounds.
To turn o the split sound, press the DUAL button once
(Layer -> Layer+Split -> Split -> O)
TWIN PIANO
Twin Piano divides the piano notes into two equal “twin” keyboards
with nearly identical registers, allowing two people to play the same
notes simultaneously. This is ideal for tuition settings.
To set the piano to Twin mode, press the FUNCTION button and use the
or buttons to move the cursor to CONTROLLER. Press the button
to enter CONTROLLER settings. Now use the or buttons to move
the cursor to DUAL BUTTON and select the TWIN mode using
the and buttons.
Once the desired voice is selected, press the DUAL button. The piano
keyboard will now be divided into two sections, with Eb4 as the split
point. In this mode, the left and right pedals both function as sustain
pedals.
Press the DUAL button again to exit the Twin mode.
9
Dual Mode

Display Range Default
TIME SIG. 2/2, 1/4, 2/4, 3/4, 4/4, 5/4, 6/4, 7/4, 6/8, 9/8, 12/8, 3/8, 7/8 4/4
TEMPO ♩= 40 ~ 250 (Quarter note basis) 120
VOLUME 50 ~ 100 80
Display Range Default
TIME SIG. 2/2, 1/4, 2/4, 3/4, 4/4, 5/4, 6/4, 7/4, 6/8, 9/8, 12/8, 3/8, 7/8 4/4
TEMPO ♩= 40 ~ 250 (Quarter note basis) 120
VOLUME 50 ~ 100 80
10
To select the METRONOME mode, press the MUSIC ASSIST button to
bring up the mode selection screen. Navigate to METRONOME using
the up and down buttons ( , ), and press the button to enter it.
Press the / button to start the metronome and press it again to
stop it.
METRONOME SETTINGS
To adjust the time signature, tempo or volume of the metronome, use
the or buttons to move the cursor and select the item you want to
set. Then, use the left to decrease or right button to increase the
setting value. If you want to make changes quickly, press and hold the
left or right button. To reset the setting to its default value, press the
left and right buttons simultaneously.
TEMPO
The TEMPO button makes adjusting the metronome tempo simple. If the
TEMPO button is pressed when the metronome screen is not displayed,
the tempo adjustment window will appear on the screen. You can then
adjust the tempo using the or buttons. Please note, when playing
the built in music, not all songs will have an adjustable tempo.
Metronome
DISPLAY RANGE DEFAULT
TIME SIG. 2/2, 1/4, 2/4, 3/4, 4/4, 5/4, 6/4, 7/4, 6/8, 9/8, 12/8, 3/8, 7/8 4/4
TEMPO = 40 ~ 250 (Quarter note basis) 120
VOLUME 50 ~ 100 80

Status Track Setting Details Remarks
Before
recording
READY REC The track is waiting for recording. If both tracks are empty, one
track must be selected.
OFF The track is not selected.
Recording REC The track is recording. REC letters blink.
After
recording
PLAY Play the recording of that track. One track must be selected if
both tracks are recorded.
MUTE Do not play the recording for that track.
Mode Selection Record Screen
11
The piano has a recording feature that enables you to capture
your performances.
1. Press the MUSIC ASSIST button and use the and buttons to
move the cursor to select RECORD and enter this mode with the
button.
2. Select a track before recording. Select TRACK1 or TRACK2 with
the or buttons. At this time, use the or buttons to set the
track to READY REC state. When you start playing or press the /
button, recording of the selected track starts. All tracks can be
recorded using the dual function.
If you continuously record for an extended period without playing,
the recording will automatically stop when the recording capacity is
reached. In the event of a temporary malfunction when the recording
capacity is exceeded, turn o and then turn on the power to the piano.
Note that the piano’s settings are recorded, however the eects such
as FX, tune, stretch tune, hammer sound and string/damper/cabinet
resonance sound are not recorded. Please note, the metronome is not
available during recording mode.
3. To finish recording, press the / button to stop recording. The
track number is highlighted and the display will show PLAY. Repeat
steps 2 and 3 to record on the remaining track.
To record without hearing the previously recorded track, change the
setting of this track to MUTE. If a track has already been recorded
and you wish to record over it, you need to delete the existing
recording first.
4. Select the track to play back using the or buttons to change the
track’s setting to PLAY
5. Press the / button to stop playback. Please note, track selection
cannot be changed during playback. The / button will flash
during playback.
6. Press the MUSIC ASSIST button to quit recording and return to
performance mode.
Recording
STATUS TRACK SETTING DETAILS REMARKS
Before Recording READY REC The track is waiting for recording. If both tracks are empty, one
OFF The track is not selected. track must be selected.
Recording REC The track is recording. REC letters blink.
After Recording PLAY Play the recording of that track. One track must be selected if
MUTE Do not play the recording for that track. both tracks are recorded.

12
RECORDING WITH AUTO ACCOMPANIMENT
To start recording with Auto Accompaniment, set Track 1 to ‘READY
REC’. You can refer to page 11 of the manual for instructions on how to
do this.
Please note that Auto Accompaniment is not available to be recorded
on Track 2. If you change the recording track to Track 2, the auto
accompaniment mode will close.
Make sure that Track 1 is in READY REC status, as the ACCOMP and
START/STOP buttons will not work otherwise.
Press the RHYTHM button to choose the desired rhythm for the
accompaniment. Refer to page 16 of the manual for instructions on how
to do this.
If you want to use Chordal Accompaniment, press the ACCOMP button
and select the desired mode. Refer to page 17 of the manual for
instructions on how to do this.
Use the TEMPO button and or buttons to adjust the tempo of the
accompaniment to your liking.
Press the / button or play a note on the keyboard to start recording
with the auto accompaniment. There are 2 ways to start the auto
accompaniment, as described on page 17 of the manual.
Note that recording to Track 1 will automatically start with the
accompaniment playing.
Use the START/STOP button to start or stop the auto accompaniment
as needed during the recording.
Press the / button again to finish the recording once you are done.
Recording
DELETE A RECORDING
1. Move the cursor to DELETE with the or buttons, then select the
track(s) to erase using the or buttons:
TR1 = delete the recording currently on Track 1
TR2 = delete the recording currently on Track 2
TR1+TR2 = delete the recordings currently on both Track 1 and Track 2
2. Press the button. The “PRESS ENTER” window will appear.
Press the button again to confirm. A beep tone will sound.
MEMORY BANK
The HDP-1 has five recording memory banks that can be used to store
up to five, 2-track recordings.
1. To select a memory bank, move the cursor to “SONG No” using
the or buttons and select the desired memory bank (1 to 5) using
the or buttons.
2. To clear a memory bank, select the desired bank and follow the
“Delete a Recording” information as described above.

PLAYING MUSIC VIA USB
To play music through the HDP-1 speakers via the USB port, insert a
compatible USB flash drive (sold separately).
Please note, when inserting a USB flash drive, or powering on the piano
with a USB flash drive already inserted, allow a few seconds of loading
time for data to be read, without playing the piano keys. The HDP-1
supports the widely used FAT32 format for USB drives.
Press the MUSIC ASSIST button. Then move the cursor to USB FLASH
DRIVE using the or buttons and press the button to enter this
mode.
Move the cursor using the or buttons to select the desired file
type, either SMF (Standard MIDI File) or MP3 and press the button to
enter/select the desired file.
Press the / button to control playback.
Press the button to return to the previous screen.
The HDP-1 features in-built classical music for you to play along to.
MP3 files can also be played through the HDP-1 via a USB flash drive
(not included).
PLAYING THE IN-BUILT SONGS
Press the MUSIC ASSIST button. Then move the cursor to LESSON
MUSIC using the or buttons and press the button to enter this
mode.
When the cursor is on the music title, songs can be selected using the
or buttons. Or, press the “ “ button to display the music list and
select the desired songs using the or buttons. Press the “ “
button again to enter the playback screen. Press the / button to
play/stop the song.
For more information, please refer to the Piano Music and Composer
music lists on pages 14/15.
To return to the previous step, press the button.
stsiLcisuM
neercSgniyalP
Mode Selection
Mode Selection
PLAYBACK SETTINGS
There are various playback settings when playing songs in Lesson
Music mode. Move the cursor using the or buttons to select the
desired setting and then change the setting value using the button
to decrease or the button to increase the setting. To return to the
previous step, press the button.
The following parameters can be changed:
Tempo – adjust the tempo of the music from 40-250 beats per minute.
Part – separate the parts by left- or right-hand accompaniment/melody.
Select from Left + Right-hand (L+R), Right-hand only (R), or Left-hand
only (L) parts.
Volume – adjust the volume of the music playback from a range of
0-100.
Play – choose if playback is either a single song (ONCE), a single
song on repeat (REPEAT), or all songs in the selected folder played
continuously (ALL).
Transpose – adjust the pitch of the music over a range of +/- 12
semitones.
13
Music Player

14
NO. TITLE COMPOSER DISPLAY
1 Etude Op.10 No.4 in C-sharp minor ‘Torrent’ F. Chopin CHOPN
2Liebesträume S.541 No.3 F. Liszt LISZT
3 Sonate No.8 in C minor 'Pathetique' Op.13 - 3. Rondo Allegro L. V. Beethoven BETVN
4 Prelude Op.3 No.2 in C-sharp minor S. Rachmanino RACHM
5 Moments Musicaux Op.94 No.3 F. Schubert SCHBT
6Gymnopedie 1ere E. Satie SATIE
7Jeux d'eau M. Ravel RAVEL
8 Piano Sonata no.11 in A Major KV331 - 3. Rondo Alla turca W. A. Mozart MOZRT
9Maiden’s Prayer T. Badarzewska BADAR
10 Das wohltemperierte Klavier I-Praeludium und Fuge 1 in C Major BWV 846 J. S. Bach BACH
11 The Seasons Op.37 b - VI. June 'Barcaroll' P. Tchaikovsky TCHSK
12 Traumerei from Kinderszenen R. Schumann SCHMN
13 The Flight Of The Bumble Bee N. Rimsky-Korsakov RACHM
14 Arabesque No.1 in E Major C. Debussy DBSSY
15 Hungarian Dance No.5 in F-sharp minor J. Brahms BRHMS
16 36 Fantasie per clavicembalo TWV33 - 1. Allegro G. P. Telemann TELMN
17 Impromptu Op.66 No. 4 C-sharp minor (Fantasie-Impromptu)
F. Chopin CHOPN
18 Etude Op.10 No.5 in G-flat Major 'Black Keys'
19 Etude Op.10 No.12 in C minor 'Revolutionary'
20 Nocturne Op.9 No.2 in E-flat Major-Andante
21 Nocturne Op.9 No.1 in B-flat minor-Larghetto
22 Nocturne Op.27 No.2
23 Ballade Op.23 No.1 in G minor
24 Polonaise in A-flat Major Op.53 Eroic
25 Waltz Op.18 Grand Waltz
26 Waltz Op.34 No.1
27 Waltz Op.64 No.1
28 Waltz Op.64 No.2
29 Scherzo No.2
30 Prelude Op.28 No.24 in D minor - Allegro appassionato
31 Sonate No.8 in C minor 'Pathetique' Op.13 - 1. Grave Allegro molto e con brio
L. V. Beethoven BETVN
32 Sonate No.8 in C minor 'Pathetique' Op.13 - 2. Adagio cantabile
33 Sonate No.14 in C-sharp minor 'Moonlight' Op.27 No.2 - 1. Adagio sostenuto
34 Sonate No.14 in C-sharp minor 'Moonlight' Op.27 No.2 - 2. Allegretto
35 Sonate No.14 in C-sharp minor 'Moonlight' Op.27 No.2 - 3. Presto con fuoco
36 Fur Elese Wo059
37 Rondo A Capriccio Op.129
38 Variations (Ah! Vous dirai-je, Maman)
W. A. Mozart MOZRT39 Piano Sonata No.9 in A minor KV310 - 1. Allegro maestoso
40 Piano Sonata No.10 in C Major KV330-1. Allegro moderato
41 Suite bergamasque 3. Clair de lune C. Debussy DBSSY
42 Pour le piano 3. Toccata
43 The Seasons Op.37b - IV. April 'Snowdrop' P. Tchaikovsky TCHSK
44 The Seasons Op.37b - X. October 'Autumn song'
45 Impromptus Op.90 No.2 in E-flat Major R. Schubert SCHBT
46 12 Transcendental Etudes S.139-4 Mazeppa in D minor F. Liszt LISZT
47 Spring song-Frulingslied Op.62 No.6 F. Mendelssohn MENDL
48 Waltz Op.39 No.15 in A-flat Major J. Brahms BRHMS
49 Prelude in C-Major BWV933 (Harpsichord) J. S. Bach BACH
50 Preludium und Fuge in B-flat major BWV560 (Pipe Organ)
Piano Music List

15
GROUP COMPOSER TITLES DISPLAY
BEYER BEYER BEYER No.01-106 BEYER
BURGMULLER BURGMULLER BURG No.01-25 BURG
CZERNY CZERNY CZERNY100 No.01-106 CZN100
CZERNY30 No.01-30 CZN30
CZERNY40 No.01-40 CZN40
SONATINES F. KUHLAU Sonatine01_1-06_2
M. CLEMENTI Sonatine07_1-12_2
J. HAYDN Sonatine13_1-13_3
W.A. MOZART Sonatine14_1-14_3
L.V BEETHOVEN Sonatine15_1-16_2
J.L. DUSSEK Sonatine17_1-17_2
Etudes & Sonatines List

To select a rhythm, press the RHYTHM button. The rhythm list will be
displayed on the screen.
Use the or buttons to highlight the desired rhythm from the list
and press the button to enter the playback screen.
Press the START/STOP button to control playback.
Press the button to return to the previous screen.
The rhythm volume and tempo can be adjusted to suit your
performance. Move the cursor using the or buttons to select the
desired setting and then change the setting value using the button to
decrease or the button to increase the settings.
Rhythm List Rhythm Play
16
Choosing a Rhythm
NO. RHYTHM NO. RHYTHM NO. RHYTHM
01 POP 1 30 MOTOWN 2 59 BOSSANOVA 2
02 POP 2 31 SLOWROCK 1 60 BOSSANOVA 3
03 DANCE 1 32 SLOWROCK 2 61 WALTZ 1
04 DANCE 2 33 SLOWROCK 3 62 WALTZ 2
05 DANCE 3 34 GOSPEL 63 WALTZ 3
06 DANCE 4 35 FUNK 1 64 WALTZ 4
07 DANCE 5 36 FUNK 2 65 MARCH 1
08 DANCE 6 37 FUNK 3 66 MARCH 2
09 HIPHOP 38 BOOGIE 67 POLKA
10 HOUSE 39 SOUL 1 68 BLUEGRASS
11 BALLAD 1 40 SOUL 2 69 DOLCE
12 BALLAD 2 41 LATIN 1 70 CLASSIC
13 BALLAD 3 42 LATIN 2 71 COUNTRY 1
14 BALLAD 4 43 LATIN 3 72 COUNTRY 2
15 BALLAD 5 44 LATIN 4 73 FOLKROCK 1
16 BALLAD 6 45 SAMBA 74 FOLKROCK 2
17 BEGUINE 1 46 RHUMBA 75 COUNTRYROCK
18 BEGUINE 2 47 SALSA 1 76 FOLK
19 R&B 48 SALSA 2 77 REGGAE
20 NEWAGE 49 TANGO 1 78 CHACHA
21 ROCK 1 50 TANGO 2 79 MAKARENA 1
22 ROCK 2 51 BLUES 1 80 MAKARENA 2
23 ROCK 3 52 BLUES 2
24 ROCK 4 53 SWING 1
25 ROCK 5 54 SWING 2
26 SHUFFLE 1 55 JAZZ 1
27 SHUFFLE 2 56 JAZZ 2
28 SHUFFLE 3 57 JAZZ 3
29 MOTOWN 1 58 BOSSANOVA 1
There are 80 in-built rhythms on the HDP-1 to play along to.

The HDP-1 features a versatile auto accompaniment system that can
provide rhythmic accompaniment to a diverse range of musical genres.
Either drum beats only or chordal accompaniment (drums and chord
parts together) can be selected, both providing a great way to add
depth to your piano performances.
Starting Auto Accompaniment
1. Drum Beat only – after selecting a rhythm, press the START/
STOP button on the playback screen to start and stop the drum
accompaniment.
2. Chordal Accompaniment – after selecting a rhythm, turn on the
ACCOMP button and play a chord in the low range
(piano keys A0 to F#3).
There are four types of chord input methods:
1. Single Finger – enter chords of up to three keys.
2. Fingered – the full chord is only detected when it is correctly played
in the low range (piano keys A0 to F#3).
3. Multi-Finger (Default) – both Single Fingered and Fingered methods
can be used in this mode.
4. Full Keyboard – this mode recognises chords played on all
piano keys.
Single Finger example:
CHORD EXAMPLE
Major
Play a note to generate a major triad with that note as its bass. C
Minor
Play a note and its left side black key to generate a minor triad with the
first note as its bass.
Cm
Seventh
Play a note and its left side white key to generate a dominant 7th chord
with the first note as its bass.
C7
Minor Seventh
Play a note and its left side white and black keys to generate a minor
7th chord with the first note as its bass.
Cm7
17
Auto Accompaniment

18
Major: C Minor: Cm 7th: C7 Minor 7th: Cm7
Major 7th: CM 7 Augmented: Caug Diminished: Cdim Suspended 4th: Csus4
Minor 7th flat 5th: Cm7 5 7th Suspended 4th: C7sus4 Diminished 7th: Cdim7 Augmented 7th: Caug7
Minor-major 7th: CmM7 7th flat 5th: C7 5 Suspended 2nd: Csus2 Augmented major 7th: CM7#5
Major flat 5th: CM 5 6th: C6 Minor 6th: Cm6 Major Add 9th: Cadd9
Minor Add 9th: Cmadd9 Minor major: CmM7 5
Fingered example:
Auto Accompaniment

19
INTRO / OUTRO
To add an intro or outro to the chordal accompaniment, press the
FUNCTION button, use the button to select ACCOMP and press the
button to enter this menu. Then use the or buttons to select
either the INTRO START or OUTRO STOP options and use the or
buttons to turn the feature on or o.
FILL PATTERNS
To add variation to your performance, when using auto accompaniment
playback drum fill patterns can be added by pressing the left pedal (soft)
or middle pedal (sostenuto).
To turn o this pedal feature, press the FUNCTION button, use the
button to select CONTROLLER and press the button to enter this
menu. Then use the or buttons to select PEDAL FILL-IN option and
use the or buttons to turn the feature on or o.
ENDINGAUTO ACCOMPANIMENT
Ending the auto accompaniment can be controlled using the START/
STOP button. Press the START/STOP button once to end with a 4-bar
outro with a variation pattern. Alternatively, press the START/STOP
button twice to stop the accompaniment immediately.
To turn o the outro feature press the FUNCTION button, use the
button to select ACCOMP and press the button to enter this menu.
Then use the or buttons to select OUTRO STOP options and use
the or buttons to turn the feature o.
AUTO ACCOMPANIMENT SETTINGS
When in the rhythm playback screen, the volume, tempo and
accompaniment type settings can be adjusted as required. Move the
cursor using the or buttons to select the desired setting and use
the or buttons to adjust the volume (0-100) or tempo (40-250bpm)
of the accompaniment. Press the ACCOMP button to select the type
of accompaniment mode (Single Finger, Fingered, Multi Finger, Full
Keyboard) using the and buttons.
MEMORY SETTINGS
The HDP-1 allows you to save all settings made to sounds via its in-built
memory.
To save performance settings, press and hold down the /SAVE button
and then press the desired memory button M1-M6. When saving is
complete, the “REGIST MEMORY” message will be shown on the
screen.
To load saved performance settings, press and hold the /LOAD button
and then press the desired memory button M1-M6.
Settings can be stored in five memory banks, each with M1-M6 options,
meaning a total of 30 performance settings can be saved.
To select dierent memory banks, press the FUNCTION button and
then press the button to enter SYSTEM settings. Now use the or
buttons to move the cursor to REGIST BANK and select the desired
memory bank (A-E) using the or buttons.
Press the FUNCTION button again to exit the function menu and return
to the home screen.
Auto Accompaniment

20
The HDP-1 includes a wide range of features that allow you to adjust
the instrument exactly to your liking and performance preferences.
These features can be accessed via the functions menu.
Press the FUNCTION button and use the or buttons to move the
cursor to the desired setting and press the button to enter its menu.
A symbol on the screen indicates that the setting has a sub-menu,
which again can be accessed by pressing either the or buttons.
Use the or buttons to decrease or increase parameter values or
turn features on or o.
Press the FUNCTION button again to exit the function menu and return
to the home screen.
Functions
