USER’S MANUAL
(482mm)
19"

1
Contents
Contents
Introduction.........................................................................................1
Safety Instructions...............................................................................2
1. Overview...........................................................................................3
2. Using the CD/USB/Reader...........................................................4 - 6
2.1 Main Controls and Operations......................................................4 - 5
2.2 Radio Operation...............................................................................6
2.3 RDS Function...................................................................................6
3. Using the Remote Control...........................................................7 - 9
3.1 Main Controls and Operations......................................................7 - 8
3.2 Radio Operation...............................................................................9
3.3 RDS Function...................................................................................9
4. Specifications.................................................................................10
Introduction
Introduction
Thank you for choosing the Galaxy Audio CD Player/Recorder. You have joined
hundreds of thousands of other satisfied Galaxy customers. Since 1977 Galaxy Audio’s
professional experience in design and manufacturing ensure our products’ quality,
performance and reliability.
For the most up to date manual and information
visit www.galaxyaudio.com.

2
Safety Instructions
Safety Instructions
!
IMPORTANT SAFETY INSTRUCTIONS !
READ these instructions.
KEEP these instructions.
HEED all warnings.
FOLLOW all instructions.
DO NOT use this apparatus near water.
CLEAN ONLY with dry cloth.
DO NOT block any ventilation openings. Install in accordance with the manu-
facturer's instructions.
DO NOT install near any heat sources such as radiators, heat registers, stoves,
or other apparatus (including amplifiers) that produce heat.
DO NOT defeat the safety purpose of the polarized or grounding-type plug. A
polarized plug has two blades with one wider than the other. A grounding type
plug has two blades and a third grounding prong. The wider blade or the third
prong are provided for your safety. If the provided plug does not fit into your
outlet, consult an electrician for replacement of the obsolete outlet.
PROTECT the power cord from being walked on or pinched, particularly at plugs,
convenience receptacles, and the point where they exit from the apparatus.
ONLY USE attachments/accessories specified by the manufacturer.
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
This symbol indicates that dangerous voltage
Constituting a risk of electric shock is present
within this unit.
This symbol indicates that there are important
Operating and maintenance instructions in the
Literature Accompanying This Unit
UNPLUG this apparatus during lightning storms or when unused for long periods of
time.
REFER all servicing to qualified service personnel. Servicing is required when the
apparatus has been damaged in any way, such as power-supply cord or plug is dam-
Aged, liquid has been spilled or objects have fallen into the apparatus, the apparatus
has been exposed to rain or moisture, does not operate normally, or has been
dropped.
DO NOT expose the apparatus to dripping and splashing. DO NOT put objects filled
with liquids, such as vases, on the apparatus.
USE only with a cart, stand, tripod, bracket, or table
Specified by the manufacturer, or sold with the
Apparatus. When a cart is used, use caution when
moving the cart/apparatus combination to avoid
injury from tip-over.
Remove the batteries from the receiver if the system will not be used for a long
period of time. This will avoid any damage resulting from a defective, leaking
battery.
DO NOT throw used batteries into a fire. Be sure to dispose of or recycle used
batteries in accordance with local waste disposal laws.
12.
13.
14.
15.
16.
17.

1. Overview
Accessories:
lAM Antenna Set x 1
lFM Antenna Wire x 1
lAV Cable x 1
lAC Power Cord x 1
lRemote Controller x 1
Installation:
lOffers USB, SD Card, CD and Tuner playing function.
lCompatible up to 16G USB, SD card / SDHC
lAccept 12 cm disc, such as CD, CD-R, CD-RW, MP3 disk
lPlaying format: MP3, WMA
Features
3
1. Connect AV Cable to OUTPUT Terminal.
2. Connect AC Power Cable in between Socket and AC power resource in AC 110V.
3. Terminal for External Power Supply DC 24V.
4. Connect ANT wire to rear terminal for receiving TUNER function.

2. Using the CD/USB/Reader
2.1 Main Controls and Operations
BUTTON FUNCTIONS
POWER For switching the system On and Off.
VOLUME For adjusting the volume.
AUX IN Connect iPod or other audio source.
LED ON/OFF To switch the LED On or Off.
Press to Start and Pause playing.
PLAY/PAUSE
/
4
To Stop playing and Eject disk.
BAND: To switch FM 1/ FM2 / AM.
- Press to stop; LCD display shows all the number of tracks.
- Press again to eject the disk; LCD display shows “EJECT”
- Press again, the disk will be automatically inserted.
STOP/EJECT
and BAND
Press the button to select the function of CD, USB, SD Card,
or RADIO mode.
MODE
M
Play in a Random order and conrmation button.
- Press to play all songs in a random order. The LCD display
shows “RAN”
- [ENTER] for “PROG” function. (Please see “PROG” section for
operating program function.)
RAN/ENTER
Repeat Play:
- To play the standard format CD:
1. Press once to repeat current track. The LCD display will
show “REP 1”.
2. Press again to repeat whole CD. The LCD display shows “ALL”.
3. Then press again to cancel the repeat function.
- To play MP3 format of CD, USB, or SD Card:
1. Press once to repeat current track. The LCD display will
show “REP1”.
2. Press again to repeat current folder. LCD display
shows “REP1 F”.
3. Press again to repeat all songs in the le. The LCD display will
show “ALL”.
4. Press again to cancel repeating function.
REPEAT

5
BUTTON FUNCTIONS
Backward to last Folder.
FOLDER
PREV - Press to go Backwards to the previous track.
- Press for 2 seconds for a faster rewind.
Forward to next Folder.
FOLDER
NEXT - Press to Fast Forward to the next track.
- Press for 2 seconds for a faster forwarding.
For temporarily Muting the sound.
MUTE
PROG
[PROG]: To memorize the songs that are selected.
Up to 10 songs can be stored.
- Select desired song. Press [PROG] button, LCD shows “PROG”.
Then press [ENTER] button store 1st song. LCD display shows
“00 01” for the 1st song. Start over the above process for storing
up to 10 songs.
- Press to start playing programmed songs. The LCD
will show “MEMO”. Press or button to select
programmed songs.
- Press [PROG] again to cancel program function.

6
2.3 RDS Function
AF (Alternative Frequency): Assuming an alternative frequency is available for the station, if the current
signal is weak, press AF. The RDS will search a different frequency with a stronger signal with the
same station.
DISP (Display): The name of the station that is currently tuned in (known as the Program Service or PS).
For example, if Classic FM were tuned in, then when pressing DISP, the display will switch from the
frequency to “Classic”. Otherwise, it will show “NO PS”.
PTY (Program Type): Radio stations can assign different program types to their shows. These can be
picked up by an RDS radio. Press PTY and the LCD will show the radio program type such as news,
sports or drama. If the radio station does not assign the program type for the program, the LCD will
show “NO PTY”.
TA (Trafc Announcement): Press TA and the RDS will automatically search for the trafc or travel
stations and will stop at the travel or trafc station.
Note: Please do not insert an 8 cm disc or computer CD.
When inserting the disk into the CD player or taking out the disk, it is required to let the CD automatically
operate. Do not push, or take out the disk by hand before the disk is completely in/out from device,
otherwise it will damage the unit.
2.2 Radio Operation
Press [MODE] button to select Radio mode.
BAND: For switching between FM1, FM2, and AM. Stations in FM1 and FM2 are exactly the same.
Provisions are made for storing up to 10 memory presets.
TUN ▲ / TUN ▼: Press ▲ or ▼ to search stations. Press for over 3 seconds to enter into automatic
scan searching. Scanning stops when unit begins receiving the station.
[MEM. / M ▲] Buttons: Memorizing radio stations: Up to 10 stations can be stored.
lPress [TUN ▲ / TUN ▼] buttons to search the stations. Press [MEM] button then press [M ▲] to
choose store CH. The LCD will show “CH1”. Start over the above process to store 2~10 CH.
lTo play the stored station, directly press [M ▲] button under RADIO mode.

7
123PROG
7 8 9
0
6
45
STOP
RAN
REPEAT
F.WDF.FF.B
M1 M2 M3
M9M8
M7
M6
M4 M5
M10
REV.
FOLDER
ENTER
EJECT
MODE
BAND
TA AF PTY DISP
TUNING
A B
PLAY/
MEMORY
AUTO SCAN
3. Using the Remote Control
3.1 Main Controls and Operations
BUTTON FUNCTIONS
MODE Press to select CD, USB, SD Card, or RADIO Mode.
PLAY / PAUSE. Press to Play or Pause.
Press to Eject or Insert the disk.
Stop to play
Press once to activate Fast Backward. Press again to cancel fast
backward. Then Press , back to normal play.
Move Backward to the previous track.
Press to Fast Forward. Press again to cancel. Then Press ,
back to normal play.
Move Forward to next track.

8
BUTTON FUNCTIONS
FOLDER Press to forward to next Folder; LCD display shows folder number.
- Press to play all songs in a Random order. The LCD display
will show “RAN”.
RAN
Repeat Play:
- To play the standard format CD:
1. Press once to repeat current track. The LCD display will
show “REP 1”.
2. Press again to repeat whole CD. The LCD display shows “ALL”.
3. Then press again to cancel the repeat function.
- To play MP3 format of CD, USB, or SD Card:
1. Press once to repeat current track. The LCD display will
show “REP1”.
2. Press again to repeat current folder. LCD display
shows “REP1 F”.
3. Press again to repeat all songs in the le. The LCD display will
show “ALL”.
4. Press again to cancel repeating function.
REPEAT
ON / OFF Mute. For temporarily muting the sound.
ENTER : Press to conrm the execution of [PROG] function.
PROG
[PROG]: To memorize the songs that are selected.
Up to 10 songs can be stored.
- Select desired song. Press [PROG] button, LCD shows “PROG”.
Then press [ENTER] button store 1st song. LCD display shows
“00 01” for the 1st song. Start over the above process for storing
up to 10 songs.
- Press to start playing programmed songs. The LCD
will show “MEMO”. Press or button to select
programmed songs.
- Press [PROG] again to cancel program function.

3.2 Radio Operation
9
Press the [MODE] button to select Radio mode.
BAND: Switching between FM1, FM2, and AM.
TUN ▲ / TUN ▼: Press ▲ or ▼ for searching stations.
AUTO SCAN - +: Automatic Scan Searching. Scanning stops when unit receives the station.
MEMORY: Memorizing radio stations: Up to 10 stations can be stored.
lPress [TUN ▲ / TUN ▼] button to search the stations. Press M1 ~ M10 buttons to store up to10
stations.
M1 ~ M10: Press to play memorized channels directly.
3.3 RDS Function
AF (Alternative Frequency): Assuming an alternative frequency is available for the station, if the current
signal is weak, press AF. The RDS will search a different frequency with a stronger signal with the
same station.
DISP (Display): The name of the station that is currently tuned in (known as the Program Service or PS).
For example, if Classic FM were tuned in, then when pressing DISP, the display will switch from the
frequency to “Classic”. Otherwise, it will show “NO PS”.
PTY (Program Type): Radio stations can assign different program types to their shows. These can be
picked up by an RDS radio. Press PTY and the LCD will show the radio program type such as news,
sports or drama. If the radio station does not assign the program type for the program, the LCD will
show “NO PTY”.
TA (Trafc Announcement): Press TA and the RDS will automatically search for the trafc or travel
stations and will stop at the travel or trafc station.
Note:
- Remote controller should be aimed at the IR window on the faceplate. The optimal receiving distance is
3 meters. The usable distance is 5 meters.
- Battery installation of the remote controller:
1. To open up the battery cover (on the back side of the remote controller), Press down on the cap and
slide it from the left to the right, then to pull it out.
2. Place in a new battery (battery type: CR2025 3V, with its positive upward).
3. Reverse the actions stated in the statement 1 to close it.

10
Connections:
FM Ant: 75 Ohm
AM Ant: Push Terminals
Outputs:
Unbalanced: 2 x RCA
Inputs:
Line In: 1/8" Stereo
13.2VDC Input: Screw Terminal
110-120 VAC Input: IEC C14
USB Type: A
Accessories: AM and FM Antenna
Power Cord
Remote Control
Dimensions: 19" x 1.75" x 9.5" (483 x 44.5 x 241 mm)
Weight: 7.54lbs (3.42 kg)
4. Specications

1-800-369-7768 www.galaxyaudio.com
V20140605
Printed in China
© Copyright Galaxy Audio 2014
WARRANTY Information can be viewed online at
http://www.galaxyaudio.com/warranty.php
THREE YEAR LIMITED WARRANTY
Specifications in this manual are subject to change without notice.
For the most up to date manual and information
visit www.galaxyaudio.com.
