Galaxy Equipment 177MW900GUA User manual

User Manual User Manual
1
900W Microwave
Model: 177MW900GUA
Please read and keep these instructions. Indoor use only.
05/2023

User Manual User Manual
2
Table of Contents
Specifications
Safety Instructions .....................................................................................................................3
Grounding Instructions ..............................................................................................................4
Microwave Assembly .................................................................................................................5
Installation ..................................................................................................................................6
Operation ...................................................................................................................................7
Care and Cleaning ...................................................................................................................13
Troubleshooting .......................................................................................................................13
Model 177MW900GUA
Rated Voltage 120V~60Hz
Rated Input Power (Microwave): 1350W
Rated Output Power (Microwave): 900W
Oven Capacity: 25L
Turntable Diameter: ø10.63"
External Dimensions: 19.10" x 14.76" x 11.53"
Net Weight: 27.88 lbs.
E171666

User Manual User Manual
3
When using electrical equipment, basic safety precautions should be followed to
reduce the risk of burns, electrical shock, fire, or injury to persons.
READ ALL OF THE INSTRUCTIONS BEFORE USING THIS EQUIPMENT.
1. This equipment MUST BE GROUNDED.
Connect only to properly GROUNDED
outlet. See “GROUNDING
INSTRUCTIONS” on page 4 for further
details.
2. Use this equipment ONLY for its intended
use as described in this manual. This type
of microwave is specifically designed to
heat, cook or dry food. It is not designed
for industrial, laboratory or commercial
food service use.
3. DO NOT heat items able to explode in
this microwave, such as eggs, sealed
containers, glass jars, etc.
4. DO NOT operate this equipment if the
cord, plug and/or door is damaged, if it
is not working properly or if it has been
damaged or dropped.
5. This equipment, including power cord,
must be serviced ONLY by qualified
service personnel. Contact the nearest
authorized service facility for examination,
repair, or adjustment.
6. DO NOT cover or block filter or other
openings on equipment.
7. DO NOT store this equipment outdoors.
8. DO NOT use this product near water or
immerse the cord and/or plug in water.
9. Keep cord AWAY from HEATED surfaces.
10. DO NOT let cord hang over edge of table
or counter.
11. DO NOT overcook food as to avoid fire in
microwave cavity.
12. If materials inside the microwave ignite,
keep microwave door CLOSED, turn
microwave off and disconnect the power
cord, or shut off power at the fuse or
circuit breaker panel.
13. DO NOT use the cavity for storage.
14. DO NOT overheat liquids.
15. After heating, allow the container to stand
in the microwave oven for a short time
before removing the container.
16. DO NOT operate equipment without load
or food in microwave cavity.
17. DO NOT use metal utensils in microwave.
18. NEVER use paper, plastic, or combustible
materials that are not intended for cooking.
19. Clean microwave regularly and remove
any food deposits.
20. Not certified for commercial food service
use.
21. This product is intended for office/light
duty non-commercial food service use.
Excessive use can shorten the lifespan of
electrical parts.
SAVE THESE INSTRUCTIONS
Important Safety Instructions

User Manual User Manual
4
Opening Your New Microwave
• Inspect microwave for any damage such as cracks or dents in door or inside microwave cavity.
• Remove all materials from microwave interior.
• Remove all plastic wrap and packaging material before use.
• Do not install microwave next to or above source of heat, such as an oven or radiator. This could
cause the microwave oven to operate improperly and could shorten life of electrical parts.
• Install microwave on a level countertop surface.
• Outlet should be located so that the plug is accessible when microwave is in place.
Grounding Instructions
Microwave MUST be grounded. Grounding reduces risk of electric shock by providing an escape
wire for the electric current, if an electrical short occurs. This microwave is equipped with a cord
having a ground wire with a grounding plug. The plug must be plugged into an outlet that is properly
installed and grounded. Do not use an extension cord.
This device complies with part 18 of the FCC Rules
TO AVOID RISK OF ELECTRICAL SHOCK OR DEATH, THIS
MICROWAVE MUST BE EARTHED. TO AVOID RISK OF ELECTRICAL
SHOCK OR DEATH, DO NOT ALTER THE PLUG.

User Manual User Manual
5
Microwave Assembly
Remove the microwave and accompanying materials from the carton and oven cavity.
Your microwave comes with the following accessories:
(1) Glass Tray
(1) Turntable Ring
User Manual
F
G
A
CB
ED
A) Control panel
B) Turntable shaft
C) Turntable ring assembly
D) Glass tray
E) Observation window
F) Door assembly
G) Safety interlock system
Turntable Installation
Hub (underside)
Glass tray
Turntable shaft
Turntable ring assembly
8
Glass tray 1
Turntable ring assembly 1
Microwave Assembly
Oven Parts and Accessories
Remove the microwave and acompanying materials from the carton and
oven cavity.Your microwave comes with the following accessories:
b. Both the glass tray and turntable ring assembly
must always be used during operation.
c. All food and containers of food must be placed on
the glass tray during operation.
a. DO NOT place the glass tray upside down. The
glass tray should never be restricted in motion.
d. If the glass tray or turntable ring assembly
becomes damaged, contact the
manufacturer for replacement.
A. Control Panel
B. Turntable Shaft
C. Turntable Ring Assembly
D. Glass Tray
E. Observation Window
F. Door Assembly
G. Safety Interlock System
Turntable Installation
a. DO NOT place the glass tray upside down.
The glass tray should never be restricted in motion.
b. Both the glass tray and turntable ring assembly
must always be used during operation.
c. All food and containers of food must be placed on
the glass tray during operation.
d. If the glass tray or turntable ring assembly
becomes damaged, contact the manufacturer for
replacement.
User Manual
F
G
A
CB
ED
A) Control panel
B) Turntable shaft
C) Turntable ring assembly
D) Glass tray
E) Observation window
F) Door assembly
G) Safety interlock system
Turntable Installation
Hub (underside)
Glass tray
Turntable shaft
Turntable ring assembly
8
Glass tray 1
Turntable ring assembly 1
Microwave Assembly
Oven Parts and Accessories
Remove the microwave and acompanying materials from the carton and
oven cavity.Your microwave comes with the following accessories:
b. Both the glass tray and turntable ring assembly
must always be used during operation.
c. All food and containers of food must be placed on
the glass tray during operation.
a. DO NOT place the glass tray upside down. The
glass tray should never be restricted in motion.
d. If the glass tray or turntable ring assembly
becomes damaged, contact the
manufacturer for replacement.
Turntable Ring Assembly
Turntable Shaft
Glass Tray
Hub (underside)
