Solar LED Parasol Instruction Manual
For correct usage, please read these instructions carefully before first use and
store in a safe place for future reference.
After Sales Support
Call 0871 911 7031
Email
customerservice@gardengearonline.
co.uk
Product Code: G3974 G3976 G3978
G3980 G3982
Thank you for purchasing this product,
which has been made to demanding
high quality standards and is
guaranteed for domestic use against
manufacturing faults for a period of 12
months from date of purchase

2
INTRODUCTION
Congratulations
You have made an excellent choice with the purchase of this quality Garden
Gear product.
By doing so you now have the assurance and peace of mind which comes
from purchasing a product that has been manufactured to the highest
standards, performance and safety.
We want you to be completely satisfied with your purchase, so this Garden
Gear product is backed by our full 12 month manufacturers guarantee
and an outstanding after sales service through our dedicated Helpline.
Register your product for an extended 2-year warranty by visiting our website
www.gardengearonline.co.uk. The product must be registered, along with
your contact information, within 30 days of purchase. For full terms and
conditions please visit our website.
We hope you enjoy using your purchase for many years to come.

3
Safety Information
•Read this manual carefully before using the Solar LED Parasol.
•Please keep out of the reach of children.
•Remove the batteries if left for long periods of time and store in a cool
and dry place.
•When disposing of batteries please ensure they are correctly recycled.
•Do not mix old and new batteries as it could cause the leakage of
caustic acid that could cause skin burns and damage any materials it
meets.
•When installing batteries make sure they are the correct polarity.
•Always wear gloves and proceed cautiously when removing leaking
batteries.
•Make sure you dispose of batteries at your local recycling centre.
•Use the Solar LED Parasol and batteries for their intended purpose only.
•Please retain instructions for further reference.
•Not suitable for commercial purposes.
How the solar panel works
During the day, the solar panel on the Solar LED Parasol converts solar power
into energy and stores it in the rechargeable batteries. At night the Solar LED
Parasol’s lights can be turned on by using the switch illustrated in “Step 7” on
the assembly diagram.
The duration of illumination will depend on the geographical location,
weather conditions and seasonal light availability where the Solar LED Parasol
is situated.
Choosing an ideal location
Choose an outdoor location where the solar panel on the parasol can
receive at least 6 hours full and direct sunshine each day. Shady locations will
reduce the battery charge and shorten the working time of the Solar LED
Parasol lights during the evening. Position the Solar LED Parasol’s solar panel
at least 2 metres away from other light sources. The closer the panel is to a
light source, the less effectively they will work.
Before first use
If the Solar LED Parasol’s solar panel is covered by a protective film, remove
the film before using it. Place the Solar LED Parasol in a location where it can
receive a full 8 hours of sunlight to allow the batteries to reach maximum
capacity.

4
Parts List
Part
Description
Qty
Part
Description
Qty
A
Base 1
1
F
Securing
Bolt
1
B
Base 2
1
G
Parasol
1
C
Support
1
H
Spanner
1
D
M8x20 Bolt
4
J
Solar Panel
1
E
8mm
Washer
4
Assembly
1. Join the base by placing
B perpendicular on top of
A.
2. Place the support (C) on to
the top of the base (A&B) and
secure with 4x bolts (D) and
washers (E).

5
3. Loosely attach the securing
bolt (F) as shown.
At this stage, weight the base
down with a suitable parasol
base. We recommend the
Garden Gear parasol base
(item code G2307).
4. Attach the solar panel (J) by
connecting the wire at the top
of the parasol and twisting into
the holder.
Place the parasol (G) into the
support (C) and tighten the
securing bolt (F) to secure.
5. ①Ensure the parasol
canopy is free from any
obstructions.
②Undo the clamp.
③Slide upwards to position
shown.
6. ①Secure the clamp again.
②Lift the rear of the canopy
arm.
③Slide the collar down to lock
the arm into place.

6
7. ①Wind the crank handle to
open the canopy.
②To switch on the lights, press
the switch located on one of the
ribs to the on position.
8. To close the parasol:
①Open the clamp.
②Slide down.
③Secure the clamp.
9. Then wind the crank in the
opposite direction to close the
canopy.
10. ①Slide the collar up to
release the arm.
②Slide the arm down to retract
the canopy.

7
Troubleshooting
If the Solar LED Parasol’s lights do not turn on at night, it may be caused by
one of the following conditions:
1. Batteries are not fully charged or need replacing:
Make sure the Solar LED Parasol’s solar panel is in an area where it can get
the maximum amount of full, direct sunlight every day. Allow sunlight to
recharge the batteries for a full sunny day. If the weather has been cloudy
or overcast during the day, the batteries will not be recharged for
operation at night. The Solar LED Parasol’s solar panel must have direct
sunlight every day to fully charge the batteries. If the Solar LED Parasol’s
solar panel does not receive enough sunlight one day, they will recharge
the next sunny day and resume normal operation. Check and replace the
batteries periodically throughout the year, especially after winter.
Replacement batteries can be purchased locally at a retailer near you.
See ‘Specifications’ for the battery type.
2. If the Solar LED Parasol’s solar panel is dirty, the dirt may not allow the
batteries to fully charge. This will shorten the life of the batteries. Clean
regularly with a damp cloth or paper towel.
3. If the Solar LED Parasol’s solar panel is located too close to a street light,
porch light or another solar light, the lights may not turn on automatically
at night. Eliminate the other light source or relocate the Solar LED Parasol.
11. ①Release the clamp.
②Slide up slightly so the arms
are in the position shown above.
③Secure the clamp back into
place.
12. When closed, ensure that the
arms are in the position shown
above.
If using a cover, it can be placed
over the fabric from the bottom
and secured with the toggle at the
top.

8
4. After correcting the problem, check the light operation immediately after
dark. If the light will only operate for a short time, the batteries need
recharging.
Specifications
•Battery: 1 x 3.7V 18650 Lithium Ion 2000mAH rechargeable
•LED Lights: 24 (3 per rib)
•Open Diameter: 2.7m
•Ribs: x8
•Fabric: 160g Polyester
GUARANTEE
IMPORTANT
Please do not return this product without first calling the Customer Service
number below:
0871 911 7031*
Thank you for purchasing this product, which has been made to
demanding high quality standards and is guaranteed for domestic use
against manufacturing faults for a period of 12 months from the date of
purchase.
Register your product for an extended 2-year warranty by visiting our website
www.gardengearonline.co.uk. The product must be registered, along with
your contact information, within 30 days of purchase. For full terms and
conditions please visit our website.
This guarantee does not affect your statutory rights. If your product fails due to
a defect in material or workmanship during this period, please return it to the
place of purchase. Normal wear and tear is not covered under the
guarantee.
Any guarantee is invalid if the product has been misused or subject to
neglect or an attempted repair other than by our own service centre.
Due to continuous product improvement, we reserve the right to change the
product specification without prior notice.
After Sales Customer Service:
Customer Service Department, Branded Garden Products Ltd, Premier House,
Hortonwood 7, Telford, TF1 7GP, UK
Telephone: [phone]*
E-mail [e-mail]
Please retain for future reference.
Colours and contents may vary.
Waste electrical products should not be disposed of with household waste.
Please recycle where facilities exist. Check with your Local Authority or retailer
for recycling advice.
Please note that all products with the symbol below must be recycled.
*Calls cost 13p per minute plus your phone company’s access charge
