Gardenpro Tidymaster Series Installation guide

CONCRETE SLAB
2360mm
2360mm
FRONT: 2.26m
SIDE: 2.26m
HEIGHT: 2.05m
OPTIONAL
We thank you for choosing an Australian Made Shed.
At GARDENPRO we want to here what you think about our products
and instructions. We love feedback!. Please contact us at
[email protected].
TOOLS REQUIRED
OPTIONAL
Gardenpro Tidymaster Series
Shed Model: J23231TK
GARDENPRO ASSEMBLY INSTRUCTION MANUAL SHED MODEL: J23231TK 05-10-2017 PAGE 01

10mm
50mm
50mm
IMPORTANT:
WHEN LAYING YOUR CONCRETE
SLAB, CHAMFER THE 50mm EDGES
DOWNWARDS BY 10mm.
THIS WILL ENSURE THAT
WATER RUN OFF IS KEPT
CLEAR FROM YOUR SHED
GENERAL INSTRUCTIONS
A NOTE ON SAFETY
·The site for the shed must be level.
·It is recommended that the shed be set on a 100mm concrete slab and anchored
down appropriately (refer FINAL CONSTRUCTION page for details).
·Anchor sets are supplied as standard items with this product.
·Before commencing any assembly, read through these instructions in detail to gain
a thorough understanding of assembly methods and associated details.
·Unpack the carton and carefully identify and check off all the parts against the parts
described and illustrated on pages three and four.
·Some parts may have sharp edges. It is
advisable to wear gloves when handling
these items and safety glasses if drilling
holes. Sensible shoes are highly
recommended.
·Do not erect your shed in windy conditions,
ensure that the shed is securely anchored to
a solid foundation immediately after
construction is completed.
·It is highly recommended to erect the shed
with two or more people.
SITE PREPARATION
GARDENPRO ASSEMBLY INSTRUCTION MANUAL SHED MODEL: J23231TK 05-10-2017
Gardenpro Tidymaster Series
Shed Model: J23231TK
PAGE 02

COMPONENTS PACKING LIST - CHECK OFF ALL COMPONENTS
COMPONENT
DESCRIPTION
PART
No. CHECK COMPONENT DESCRIPTION
PART
No. CHECK
QTY QTY
2
1
2
2
2
6
2
1
STEEL SHEET
1785mm X 773mm 31A
1785mm X 773mm 30A
STEEL SHEET STEEL SHEET
1915mm X 773mm 36L
STEEL SHEET
1915mm X 773mm 36R
STEEL SHEET
1785mm X 731mm 32A
STEEL SHEET
1725mm X 773mm B
15A
PEAK BRACE
2
STEEL SHEET
1980mm X 773mm 42D
STEEL SHEET
1170mm X 773mm 49A
ZARSP
1RIDGE BEAM JOINER
L: 450mm
97BL
1RIDGE
BEAM
L = 1126.5mm
97BR
1RIDGE
BEAM
L = 1126.5mm
1
J23231GCP
CHANNEL SET
(SEE PAGE 4 & 5) 1
INSTRUCTIONS & FITTINGS
PACKET
(SEE PAGE 5)
GARDENPRO ASSEMBLY INSTRUCTION MANUAL SHED MODEL: J23231TK 05-10-2017
Gardenpro Tidymaster Series
Shed Model: J23231TK
PAGE 03

2 2
11
79B
CHANNEL
L = 788mm
58B
CHANNEL
L = 1725mm
58A
CHANNEL WITH HINGES
L = 1725mm
58C
CHANNEL
L = 773mm
1
CHANNEL
L = 1143mm
83L
CHANNEL
L = 1143mm
83R
2
COMPONENTS PACKING LIST - (CONT.) CHECK OFF ALL COMPONENTS
54AL
54CL
54BL
81DL
81CL
60BL
54CR
1
1
1
1
4
2
1
1
1
1
4
2
CHANNEL
L = 1126.5mm
CHANNEL
L = 1126.5mm
CHANNEL
L = 1126.5mm
CHANNEL
L = 1126.5mm
CHANNEL
L = 1126.5mm
CHANNEL
L = 1126.5mm
54BR
81DR
81CR
60BR
54AR
CHANNEL
L = 1126.5mm
CHANNEL
L = 1126.5mm
CHANNEL
L = 1126.5mm
CHANNEL
L = 1126.5mm
CHANNEL
L = 1126.5mm
CHANNEL
L = 1126.5mm
COMPONENT
DESCRIPTION
PART
No. CHECK COMPONENT
DESCRIPTION
PART
No. CHECK
QTY QTY
GARDENPRO ASSEMBLY INSTRUCTION MANUAL SHED MODEL: J23231TK 05-10-2017
Gardenpro Tidymaster Series
Shed Model: J23231TK
PAGE 04

COMPONENT
DESCRIPTION
PART
No. CHECK COMPONENT DESCRIPTION
PART
No. CHECK
QTY QTY
INSTRUCTIONS & FITTINGS PACKET
COMPONENT
DESCRIPTION
PART
No. CHECK COMPONENT
DESCRIPTION
PART
No. CHECK
QTY QTY
COMPONENTS PACKING LIST - (CONT.) CHECK OFF ALL COMPONENTS
1
1 2
1
4
89A
JAMB L= 1785mm
89B
JAMB L= 1785mm
90B
JAMB L= 788mm
91A
JAMB L= 1120mm
86A
LIP TRIM L= 1170mm
1 2
1
12A
DOOR
STRAP
L: 165mm 14A
CAP GABLE
L: 170mm
ASSEMBLY
INSTRUCTIONS
CSJ
10 CHANNEL JOINER
L= 200mm
DOOR
PADBOLT
HASP
1
1
SELF TAPPING SCREWS
PACKET CONTAINING 220
1
DOOR
PADBOLT
FAST006
3/16 COUNTERSUNK
SCREWS & NUTS
63.2 x 8mm
BLIND POP RIVETS
6
PSTKSGL - SINGLE DOOR FITTINGS PACK
PACK 6P - SCREW PACK 6
PACK 6P
SCREW PACK 6
1
PHILLIPS DRIVER BIT
3mm DRILL BIT
1 1
DRILL
FAST007
FAST038
10 16mm TEK
SCREWS FAST014
1SINGLE DOOR
FITTINGS PACK PSTKSGL
GARDENPRO ASSEMBLY INSTRUCTION MANUAL SHED MODEL: J23231TK 05-10-2017
Gardenpro Tidymaster Series
Shed Model: J23231TK
PAGE 05

GARDENPRO ASSEMBLY INSTRUCTION MANUAL SHED MODEL: J23231TK 05-10-2017
Gardenpro Tidymaster Series
Shed Model: J23231TK
PAGE 06
20mm
15mm
QTY = 10pcs.
CHANNEL
PUSH PUSH
CHANNEL
CSJ
INSTRUCTIONS FOR JOINING SPLICED CHANNELS
CSJ
CSJ
HIGH-SIDE
CHANNEL
LOW-SIDE
CHANNEL
CSJ
CSJ
CSJ
= =
= =
==
==
STEP 1.
Position the channels and the CSJ
joiner channel so the center of the
CSJ is in line with the end of each
channel to be joined together.
STEP 2.
Join the first channel to the CSJ by inserting the center
of the CSJ (on an angle) to the end of the channel
where the JOIN>> text is marked. Push down one side
of the CSJ until you hear a 'click'.
STEP 3.
Join the second channel to the CSJ
by positioning the <<JOIN end of the
channel at the center of the CSJ
(on an angle). Push the CSJ into
the channel until you here a 'click'.
=
The joined channels should now
look like the picture above with the
CSJ positioned equally inside of the
joined channels.
FINISHED CHANNEL
=
NOTE: THE TEXT MARKED ON ALL PARTS MUST BE SHOWN ON THE SAME SIDE AS EACH OTHER.
JOIN>> <<JOIN JOIN>>
JOIN>> SJ
JOIN>>
<<JOIN
JOIN>> <<JOIN
J
CSJ
DRILL 4mm x 3mm (2 PER A SIDE)
HOLES TO SECURE SECTIONS
TOGETHER. (THESE SCREWS
MAY HAVE TO BE TEMPORARILY
REMOVED AND REPLACED
DURING LATER ASSEMBLY)

GARDENPRO ASSEMBLY INSTRUCTION MANUAL SHED MODEL: J23231TK 05-10-2017
Gardenpro Tidymaster Series
Shed Model: J23231TK
PAGE 07
=
=
=
=
=
4 X 81CR
2253mm
2 x 60B
4 x 81C
1 x 54A
1 x 54C
1 x 54B
NOTE: JOIN TOGETHER 20 X CHANNEL SECTIONS USING 10 X CHANNEL JOINERS (PART CSJ)
81CL
81CR
60BR
60BL
2 X 60BR
2 X 60BL
4 X 81CL
1 X 54AR
1 X 54AL
1 X 54CR
1 X 54CL
1 X 54BR
1 X 54BL
NOTE: SOME CHANNELS HAVE
HOLES IN THEM - YOU WILL NEED
TO RE-DRILL HOLES ON ANY
CHANNEL WHERE THE CSJ
JOINING CHANNEL COVERS
HOLES ON THE CHANNELS
YOU ARE CONNECTING
STEP 1. PRE-ASSEMBLY OF SPLICED CHANNELS
=
1 X 81DR
2 x 81D
81DL
81DR
1 X 81DL
54BR
54CR
54AR
54BL
54CL
54AL

GARDENPRO ASSEMBLY INSTRUCTION MANUAL SHED MODEL: J23231TK 05-10-2017
Gardenpro Tidymaster Series
Shed Model: J23231TK
PAGE 08
STAGE 1: PUSH RIDGE BEAMS TOGETHER, MAKE SURE THERE IS A 50mm OVERLAP
OF THE RIDGE CAP
STAGE 2: INSERT RIDGE CAP JOINER INTO CONNECTED RIDGE CAPS.
MAKE SURE JOINER HAS 225mm IN EACH RIDGE CAP.
STAGE 3: TURN RIDGE CAP OVER AND MEASURE 250mm FROM THE END OF EACH RIDGE
CAP.
PLACE TEK SCREWS IN 50mm INCREMENTS FROM SAID END.
REPEAT THIS PROCESS FOR THE OPPOSING HALF OF RIDGE BEAM
INSTRUCTIONS FOR JOINING SPLICED RIDGE BEAM

GARDENPRO ASSEMBLY INSTRUCTION MANUAL SHED MODEL: J23231TK 05-10-2017
Gardenpro Tidymaster Series
Shed Model: J23231TK
PAGE 09
PHILLIPS DRIVER BIT
QTY. = 1
QTY. = 8
QTY. = 2
QTY. = 1
SELF DRILLING TEK SCREW
PART ZARSP - 450mm LONG
ZARSP
RIDGE BEAM 1126.5mm
PARTS 97BL & 97BR
STEP 2. PRE-ASSEMBLY OF SPLICED RIDGE BEAM
PUSH PUSH
97BL
97BR
16mm
200mm
250mm
2253mm OVERALL LENGTH
(PART 97B)
16mm
THE TOP SECTIONS OF
CAPPING WILL OVERLAP
EACH OTHER AT THE
JOIN BY 50mm.

VIEW OF ROOF COMPONENTS
NO.
86A
60B
14A
86A
81C
86A
86A
14A
81C
97B
49A
49A
49A
49A
49A
49A
GARDENPRO ASSEMBLY INSTRUCTION MANUAL SHED MODEL: J23231TK 05-10-2017
Gardenpro Tidymaster Series
Shed Model: J23231TK
PAGE 10

VIEW OF WALL COMPONENTS
79B
54C
91A
89B
89A
32A
32A
36R
42D
36L
30A
31A
30A 36R
42D
36L
B
22A
81D
81C
83L
54A
83L
15A
83R
54B
81C
83R
90B
GARDENPRO ASSEMBLY INSTRUCTION MANUAL SHED MODEL: J23231TK 05-10-2017
Gardenpro Tidymaster Series
Shed Model: J23231TK
PAGE 11

ASSEMBLY INTRODUCTION
FASTENING SYMBOLS
The snap-tite assembly system locks most perimeter channels to all roof and wall
sheets without the need for tools and fasteners.
To pre-assemble the four wall panels
and two roof panels, the perimeter
channels are secured to the top and
bottom of each panel using the
snaptite system, as detailed on the
following pages wherever you see
the symbol.
Position sheets on timbers,
trestles or partly over edge of
concrete slab.
Each perimeter channel must finish flush
with the edges of the sheets. the snap-tite
system allows adjustment for this
process by simply tapping the channel
along the sheets until each end is neatly
flush.
Join components together with one screw at this
location only, as some channel sections have extra
holes that are not required for this model of garden
shed
Do not join components together at this location yet,
as the screw may obstruct further assembly of other
components
4mm NUT & BOLT SET
3mm POP RIVETS
PUSH
PUSH
HIGH SIDE
HIGH SIDE
PUSH
HIGH SIDE
HIGH SIDE
After joining sheets together,
position channel over one end of the
sheets, gently tapping it over the
snaptite lugs, working along the
sheets to the other end.
HIGH SIDE
SNAP
T TE
i
SNAP
T TE
i
SNAP
T TE
i
NOTE: The 'high side' is always on
the inside of the shed.
GARDENPRO ASSEMBLY INSTRUCTION MANUAL SHED MODEL: J23231TK 05-10-2017
Gardenpro Tidymaster Series
Shed Model: J23231TK
PAGE 12

GARDENPRO ASSEMBLY INSTRUCTION MANUAL SHED MODEL: J23231TK 05-10-2017
Gardenpro Tidymaster Series
Shed Model: J23231TK
PAGE 13
DOOR PANEL ASSEMBLY
20mm FLANGE
58C
58C
58A
15mm FLANGE
B
B
SNAP
T TE
i
SNAP
T TE
i
58B
12A

REAR PANEL ASSEMBLY
30A
31A
30A
54B
81D
SNAP
T TE
i
SNAP
T TE
i
SIDE PANEL ASSEMBLY
(2 Required)
INSIDE
OF
SHED
36L
42D
36R
83R
81C
83L
15A
GARDENPRO ASSEMBLY INSTRUCTION MANUAL SHED MODEL: J23231TK 05-10-2017
Gardenpro Tidymaster Series
Shed Model: J23231TK
PAGE 14

2 x PRE-PUNCHED
HOLES TO THIS
END OF EACH
SHEET WITH PART
NO. 81C FITTED
ROOF PANEL ASSEMBLY
(2 Required)
SNAP
T TE
i
SNAP
T TE
i
49A
49A
49A
86A
81C
86A
60B
GARDENPRO ASSEMBLY INSTRUCTION MANUAL SHED MODEL: J23231TK 05-10-2017
Gardenpro Tidymaster Series
Shed Model: J23231TK
PAGE 15

FRONT PANEL ASSEMBLY
89B
89A
32A
32A
54A
79B
54C
90B
SNAP
T TE
i
SNAP
T TE
i
SNAP
T TE
i
SNAP
T TE
i
GARDENPRO ASSEMBLY INSTRUCTION MANUAL SHED MODEL: J23231TK 05-10-2017
Gardenpro Tidymaster Series
Shed Model: J23231TK
PAGE 16

DOOR PANEL ASSEMBLY
NOTE: The two holes required to connect the padbolt hasp for each door have not been pre-punched, to
allow for proper alignment. position each hasp centrally over the padbolt shaft, and drill 3mm holes and
secure with screws
NOTE: NUTS AND BOLTS (SUPPLIED) MAY BE USED
INSTEAD OF POP RIVETS (SUPPLIED) BY SIMPLY
ENLARGING THE HINGE HOLE SETS IN THE JAMB
USING A 4MM DRILL BIT
91A
91A
B
B
GARDENPRO ASSEMBLY INSTRUCTION MANUAL SHED MODEL: J23231TK 05-10-2017
Gardenpro Tidymaster Series
Shed Model: J23231TK
PAGE 17

PANEL CONSTRUCTION
NOTE: Take care to ensure that both front
and rear wall panels are not positioned
upside down. The top channel of each
panel is pre-punched for attaching roof
sheets, the bottom channels
are not.
SIDE WALL PANEL
CHANNELS FIT INTO THE
NOTCHED FRONT AND
REAR WALL PANEL
CHANNELS
CHANNEL TYPE 60B
THIS END
CHANNEL TYPE
81C THIS END
97B
GARDENPRO ASSEMBLY INSTRUCTION MANUAL SHED MODEL: J23231TK 05-10-2017
Gardenpro Tidymaster Series
Shed Model: J23231TK
PAGE 18

SLIDE THE ROOF PANEL INTO
POSITION, AND SECURE WITH
ONE SCREW AT EACH CORNER
ONLY AT THIS STAGE
SECURE PEAK
BRACE TO RIDGE
BEAM AND ROOF
PANEL WITH ONE
SCREW AT EACH
END
MOVE THE OTHER
ROOF PANEL INTO
POSITION AND SECURE
PEAK BRACE TO RIDGE
BEAM AND ROOF
PANEL WITH ONE
SCREW AT EACH END
ROOF CONSTRUCTION
INSIDE VIEW OF FIXING
GARDENPRO ASSEMBLY INSTRUCTION MANUAL SHED MODEL: J23231TK 05-10-2017
Gardenpro Tidymaster Series
Shed Model: J23231TK
PAGE 19

DYNABOLT
BOLT & NUT
STEEL
ANGLE
SLAB
WALL
SHEET
FINAL CONSTRUCTION
BEND THE TOP AND
BOTTOM FLANGES AS
SHOWN, THEN HOOK THE
BOTTOM FLANGES UNDER
THE TOP CHANNEL AND
SCREW THE TOP FLANGES
FOR BOTH AS SHOWN
GABLE CAPS
14A
- EACH ANCHOR CONSISTS OF ONE NUT, BOLT,
DYNABOLT AND STEEL ANGLE
- DRILL A 10mm HOLE INTO
THE WALL SHEET
- DRILL A 10mm HOLE INTO THE
CONCRETE
ANCHORING OF SHED
LOCATION OF 12
CONCRETE ANCHORS
GARDENPRO ASSEMBLY INSTRUCTION MANUAL SHED MODEL: J23231TK 05-10-2017
Gardenpro Tidymaster Series
Shed Model: J23231TK
PAGE 20
