Profile
Microwave/Convection Oven
Owner’s Manual
Model:
825 Watts
JVM1090
2
41
Helpful Information
Care and Cleaning 42
47
If Something Goes Wrong
Before You Call For Service 47
GE Service Numbers 50
Warranty Back Cover
GE Answer Center®
800.626.2000
GE Appliances
11
Important Safety Information
Precautions to Avoid Possible Exposure
to Excessive Microwave Energy 2
Special Notes About Microwaving 6
Operating Instructions
Features of Your Microwave 11
The Controls on Your Microwave 12
Time Cooking 17
Temperature Cooking 27
Automatic Cooking 32
Other Features 36
49-40002
164D3370P003

2
Important Safety Information
Read All Safety Information
Before Using
Precautions
to Avoid
Possible
Exposure to
Excessive
Microwave
Energy
Do Not Attempt to operate
this oven with the door
open since open-door
operation can result in
harmful exposure to
microwave energy. It is
important not to defeat
or tamper with the safety
interlocks.
Do Not Place any object
between the oven front
face and the door or
allow soil or cleaner
residue to accumulate on
sealing surfaces.
Do Not Operate the oven
if it is damaged. It is
particularly important
that the oven door close
properly and that there is
no damage to the:
1 door (bent)
2 hinges and latches
(broken or loosened)
3 door seals and sealing
surfaces.
The Oven Should Not be
adjusted or repaired by
anyone except properly
qualified service
personnel.
For Your
Safety
For your safety the information in this manual must be
followed to minimize the risk of fire or explosion or to
prevent property damage, personal injury or loss of life.

3
Welcome to the GE family.
We’re proud of our quality
products and we believe
in dependable service.
You’ll see it in this easy-to-
use manual and you’ll hear
it in the friendly voices of
our consumer service
department.
Best of all, you’ll
experience these values
each time you use your
microwave. That’s
important, because your
new microwave will be part
of your family for a long
time.
Welcome
Write down the model and
serial numbers here.
They
are on a label inside the
oven.
Model number
Serial number
Date of purchase
Staple your receipt to the
inside back cover of this
manual. You will need it to
obtain service under
warranty.
Help us
help you
800.626.2000
Before you call for service,
there are a few things you
can do to help us serve you
better.
Read this manual.
It contains instructions to
help you use and maintain
your microwave properly.
If you received a damaged
oven...
immediately contact
the dealer (or builder) that
sold you the oven.
Save time and money.
Check the section titled
“If Something Goes
Wrong” before calling.
This section helps you
solve common problems
that might occur.
If you do need service,
you can relax knowing help
is only a phone call away.
A list of toll-free customer
service numbers is
included in the back of
this book. Or call the
GE Answer Center® at
800.626.2000, 24 hours
a day, 7 days a week.
Need Help?
Start Here!…Before using your Microwave

Important Safety Information
Read All Safety Information
Before Using
To reduce the risk of fire, burns, electric shock, injury to persons, or exposure to excessive
microwave energy when using your appliance, follow basic precautions, including the
following sections.
WARNING
•Read and follow the
specific “Precautions to
Avoid Possible Exposure
to Excessive Microwave
Energy” on page 2.
•This appliance must be
grounded. Connect only
to properly grounded
outlet. See Grounding
Instructions section on
page 10.
•Do not mount this
appliance over a sink.
•Install or locate this
appliance only in
accordance with the
provided Installation
Instructions.
•This over-the-range oven
was designed for use over
ranges no wider than 42
inches. It may be installed
over both gas and electric
cooking equipment.
•Do not operate this
appliance if it has a
damaged power cord or
plug, if it is not working
properly, or if it has been
damaged or dropped.
•Do not cover or block
any openings on the
appliance.
•Use this appliance only
for its intended use as
described in this guide.
Do not use corrosive
chemicals or vapors in
this appliance. This
microwave oven is
specifically designed to
heat, dry or cook food,
and is not intended
for laboratory or
industrial use.
This microwave oven is
UL listed for installation
over electric and gas
ranges.
This microwave oven is
not approved or tested
for marine use.
Safety
Precautions
4

•Do not store this
appliance outdoors. Do
not use this product near
water—for example, in a
wet basement, near a
swimming pool or near
a sink.
•Keep power cord away
from heated surfaces.
•Do not immerse power
cord or plug in water.
•When using the
convection or
combination cooking
functions, both the
outside and inside of the
oven will become hot.
Always use hot pads to
remove containers of
food and accessories such
as broiler pan, oven shelf
and temperature probe.
•To reduce the risk of fire
in the oven cavity:
— Do not cover the shelf
or any other part of the
oven with metal foil.
This will cause
overheating of the
microwave/convection
oven.
— Do not overcook food.
Carefully attend
appliance if paper,
plastic or other com-
bustible materials are
placed inside the oven
while cooking.
— Remove wire twist-ties
and metal handles from
paper or plastic con-
tainers before placing
them in the oven.
— Do not use the oven
for storage purposes.
Do not leave paper
products, cooking
utensils or food in the
oven when not in use.
— If materials inside oven
should ignite, keep the
oven door closed, turn
the oven off and
disconnect the power
cord, or shut off power
at the fuse or circuit
breaker panel. If the
door is opened, the fire
may spread.
•See door surface cleaning
instructions in the Care
and Cleaning section(s)
of this guide.
•This appliance should
be serviced only by
qualified service
personnel. Contact
nearest authorized
service facility for
examination, repair
or adjustment.
•As with any appliance,
close supervision is
necessary when used by
children.
SAVE THESE INSTRUCTIONS
5

Important Safety Information
Special Notes About Microwaving
Arcing is the microwave
term for sparks in the oven.
Arcing is caused by:
•The temperature probe
in the microwave but not
inserted in the food.
•The metal shelf not
installed correctly so it
touches the microwave
wall.
•Metal or foil touching the
side of the oven.
•Foil not molded to food
(upturned edges act like
antennas).
•Metal, such as twist-ties,
poultry pins, or gold-
rimmed dishes, in the
microwave.
•Recycled paper towels
containing small metal
pieces being used in the
microwave.
If you see arcing, press
the CLEAR/OFF pad and
correct the problem.
Arcing
•Do not pop popcorn in
your microwave oven
unless in a special
microwave popcorn
accessory or unless you
use popcorn labeled for
use in microwave ovens.
•Some products such as
whole eggs and sealed
containers—for example,
closed jars—will explode
and should not be heated
in this microwave oven.
Such use of the
microwave oven could
result in injury.
•Do not boil eggs in a
microwave oven. Pressure
will build up inside egg
yolk and will cause it to
burst, possibly resulting
in injury.
•Operating the microwave
with no food inside for
more than a minute or
two may cause damage to
the oven and could start a
fire. It increases the heat
around the magnetron
and can shorten the life
of the oven.
•Foods with unbroken
outer “skin” such as
potatoes, hot dogs,
sausages, tomatoes,
apples, chicken livers and
other giblets, and egg
yolks should be pierced
to allow steam to escape
during cooking.
Foods
6

7
•Avoid heating baby food
in glass jars, even with the
lid off. Make sure all
infant food is thoroughly
cooked. Stir food to
distribute the heat
evenly. Be careful to
prevent scalding when
warming formula or
breast milk. The container
may feel cooler than the
milk really is. Always test
the milk before feeding
the baby.
•Spontaneous boiling—
Under certain special
circumstances, liquids
may start to boil during
or shortly after removal
from the microwave oven.
To prevent burns from
splashing liquid, we
recommend the following:
before removing the
container from the oven,
allow the container to
stand in the oven for 30
to 40 seconds after the
oven has shut off. Do not
boil liquids in narrow-
necked containers such
as soft drink bottles, wine
flasks and especially
narrow-necked coffee
cups. Even if the
container is opened,
excessive steam can build
up and cause it to burst
or overflow.
•Don’t defrost frozen
beverages in narrow-
necked bottles (especially
carbonated beverages).
Even if the container is
opened, pressure can
build up. This can cause
the container to burst,
possibly resulting in
injury.
•Hot foods and steam
can cause burns. Be
careful when opening
any containers of hot
food, including popcorn
bags, cooking pouches
and boxes. To prevent
possible injury, direct
steam away from hands
and face.
•Do not overcook
potatoes. They could
dehydrate and catch
fire, causing damage to
your oven.
•When cooking pork,
follow the directions
exactly and always cook
the meat to an internal
temperature of at least
170°F. This assures that,
in the remote possibility
that trichina may be
present in the meat, it
will be killed and meat
will be safe to eat.
SAFETY
FACT
SUPERHEATED WATER
Microwaved water and
other liquids do not
always bubble when
they reach the boiling
point. They can actually
get superheated and not
bubble at all.
Superheated liquid will
bubble up out of the cup
when it is moved or
when something like a
spoon or tea bag is put
into it.
To prevent this from
happening and causing
injury, do not heat any
liquid for more than 2
minutes per cup. After
heating, let the cup
stand in the microwave
for 30 seconds before
moving it or putting
anything into it.

Important Safety Information
Special Notes About Microwaving
Make sure all cookware
used in your microwave
oven is suitable for
microwaving. Most glass
casseroles, cooking dishes,
measuring cups, custard
cups, pottery or china
dinnerware which does not
have metallic trim or glaze
with a metallic sheen can
be used. Some cookware is
labeled “suitable for
microwaving.”
•If you are not sure if a
dish is microwave-safe,
use this test: Place in the
oven both the dish you
are testing and a glass
measuring cup filled with
1 cup of water—set the
measuring cup either in
or next to the dish.
Microwave 1 minute at
high. If the dish heats, it
should not be used for
microwaving. If the dish
remains cool and only the
water in the cup heats,
then the dish is
microwave-safe.
•If you use a meat ther-
mometer while cooking,
make sure it is safe for
use in microwave ovens.
•Do not use recycled
paper products. Recycled
paper towels, napkins
and waxed paper can
contain metal flecks
which may cause arcing
or ignite. Paper products
containing nylon or
nylon filaments should
be avoided, as they may
also ignite.
•Some styrofoam trays
(like those that meat is
packaged on) have a thin
strip of metal embedded
in the bottom. When
microwaved, the metal
can burn the floor of the
oven or ignite a paper
towel.
•Do not use paper
products when the
microwave/convection
oven is operated in the
convection or
combination mode.
•Do not use the microwave
to dry newspapers.
•Not all plastic wrap is
suitable for use in micro-
wave ovens. Check the
package for proper use.
•Paper towels, waxed
paper and plastic wrap
can be used to cover
dishes in order to retain
moisture and prevent
spattering. Be sure to
vent plastic wrap so steam
can escape.
•Cookware may become
hot because of heat
transferred from the
heated food. Pot holders
may be needed to handle
the cookware.
•“Boilable” cooking
pouches and tightly
closed plastic bags should
be slit, pierced or vented
as directed by package. If
they are not, plastic could
burst during or immed-
iately after cooking,
possibly resulting in injury.
Also, plastic storage
containers should be at
least partially uncovered
because they form a tight
seal. When cooking with
containers tightly covered
with plastic wrap, remove
covering carefully and
direct steam away from
hands and face.
Microwave-Safe
Cookware
8
How to test for a microwave-
safe dish.

9
•Use foil only as directed
in this guide. TV dinners
may be microwaved in
foil trays less than 3/4″
high; remove the top foil
cover and return the tray
to the box. When using
foil in the microwave
oven, keep the foil at
least 1 inch away from the
sides of the oven.
•Plastic cookware—Plastic
cookware designed for
microwave cooking is very
useful, but should be used
carefully. Even microwave-
safe plastic may not be as
tolerant of overcooking
conditions as are glass or
ceramic materials and
may soften or char if
subjected to short periods
of overcooking. In longer
exposures to over-
cooking, the food and
cookware could ignite.
Follow these guidelines:
1 Use microwave-safe
plastics only and use
them in strict compliance
with the cookware
manufacturer’s
recommendations.
2 Do not microwave empty
containers.
3 Do not permit children to
use plastic cookware
without complete
supervision.
The fan will operate
automatically under
certain conditions (see
Automatic Fan feature).
Take care to prevent the
starting and spreading of
accidental cooking fires
while the vent fan is in use.
•Clean the underside of
the microwave often. Do
not allow grease to build
up on the microwave or
the fan filters.
•In the event of a grease
fire on the surface units
below the microwave
oven, smother a flaming
pan on the surface unit
by covering the pan
completely with a lid, a
cookie sheet or a flat tray.
•Use care when cleaning
the vent fan filters.
Corrosive cleaning
agents, such as lye-based
oven cleaners, may
damage the filters.
•When flaming foods
under the microwave,
turn the vent fan off. The
fan, if operating, may
spread the flame.
•Never leave surface units
beneath your microwave
oven unattended at high
heat settings. Boilovers
cause smoking and greasy
spillovers that may ignite
and spread if the
microwave vent fan is
operating. To minimize
automatic fan operation,
use adequate sized
cookware and use high
heat on surface units only
when necessary.
The Vent Fan

Important Safety Information
Grounding Instructions/Optional Kits
WARNING
Improper use of the
grounding plug can result in
a risk of electric shock.
This appliance must be
grounded. In the event of
an electrical short circuit,
grounding reduces the risk
of electric shock by
providing an escape wire
for the electric current.
This appliance is equipped
with a power cord having a
grounding wire with a
grounding plug. The plug
must be plugged into an
outlet that is properly
installed and grounded.
Consult a qualified electri-
cian or service technician if
the grounding instructions
are not completely under-
stood, or if doubt exists as
to whether the appliance is
properly grounded.
If the outlet is a standard
2-prong wall outlet, it is
your personal responsibility
and obligation to have it
replaced with a properly
grounded 3-prong wall
outlet.
Do not under any circum-
stances cut or remove the
third (ground) prong from
the power cord.
Do not use an adapter plug
with this appliance.
Do not use an extension
cord with this appliance. If
the power cord is too short,
have a qualified electrician
or service technician install
an outlet near the
appliance.
For best operation, plug
this appliance into its own
electrical outlet to prevent
flickering of lights, blowing
of fuse or tripping of
circuit breaker.
Grounding
Instructions
Filler Panel Kits
JX40WH—White
JX41—Black
JX40AL—Almond
When replacing a 36″or
42″range hood, filler panel
kits fill in the additional
width to provide a custom
built-in appearance.
For installation between
cabinets only; not for end-
of-cabinet installation. Each
kit contains two 3″-wide
filler panels. Two kits are
needed for a 42″opening.
Filter Kits
JX81A—Recirculating
Charcoal Filter Kit
Filler kits are used when
the microwave oven cannot
be vented to the outside.
Decorative Panel Kit
JX22SS—Stainless Steel
When replacing a Hi/Low
range, the decorative panel
kit fills in the area between
the microwave and the
range left by the Hi/Low
model.
Available at extra cost from
your GE supplier.
Optional Kits
Ensure proper ground
exists before use.
10
