GE Profile SpacemakerXL JVM1350SY User guide

JVM1350SY—GE Profile™SpacemakerXL Microwave Oven
Dimensions (in inches)
Created 7/97
TM
For answers to your Monogram,®GE Profile
Performance Series,™GE Profile,™GE,
Hotpoint and RCA appliance questions, call
GE Answer Center®service, 800.626.2000.
R
Listed by
Underwriters
Laboratories
Note: Requires 120V grounded outlet. Electrical receptacle must be
located in cabinet above SpacemakerXL microwave oven. No additional
wiring, venting or cabinet rebuilding necessary in many cases. Complete
detailed, easy-to-follow installation instructions and convenient full-size
templates are packed with the SpacemakerXL microwave oven.
Important Information: When installing the SpacemakerXL
microwave oven over a range, allow minimum of 2" from bottom of
SpacemakerXL microwave oven to top of range backguard to allow
for removal of light covers.
Ventilation Options: The SpacemakerXL microwave ovens are designed
for adaptation to the following three types of ventilation:
• Outside exhaust (vertical—as shown)
• Outside exhaust (horizontal)
• Recirculating (non-vented ductless—see Filter Kit drawing)
Installation Information: This information is not intended to be used for
installing unit described. Before installing, consult installation instructions
packed with product/kit for current dimensional data.
21-3/4"
Door open
16-1/2
66" MIN.
Mounting
height
from
floor
30"
MIN.
width 
required
MAX.
Exhaust outlet
connects to
3-1/4" X 10" duct
14
12"

16-1/4

JVM1350SY—GE Profile™SpacemakerXL Microwave Oven
Optional Accessories (Available at additional cost)
Created 7/97
TM
For answers to your Monogram,®GE Profile
Performance Series,™GE Profile,™GE,
Hotpoint and RCA appliance questions, call
GE Answer Center®service, 800.626.2000.
R
Listed by
Underwriters
Laboratories
Filler Panel Kits
JX41—Black
When replacing a
36" or 42" range
hood, this kit fills in
the additional width to
provide a custom,
built-in appearance. For
installation between cabinets
only; not for end-of-cabinet
installation. Each kit contains
two, 3"-wide filler panels.
Two kits are needed
for a 42" opening.
Filter Kits
JX81A—Recirculating Charcoal Filter Kit
To be used when the SpacemakerXL
microwave oven cannot be vented to
the outside.
JX22SS—Stainless Steel Decorative
Panel Kit
When replacing a Hi/Low range with a
SpacemakerXL microwave oven over a
range model, this panel kit fills in the
area between the microwave and
range left by the Hi/Low model.
Optional Accessories
Recirculating Charcoal Filter Kit JX81A
Filler Panel Kit JX41
Decorative Panel Kit JX22SS

Created 7/97
TM
JVM1350SY—GE Profile™SpacemakerXL Microwave Oven
REMINDER
AUTO
NITELIGHT TIMER
ON/OFF
CLOCK AM/ PM
SEEGUIDESCROLLSPEED
SENSORCOOK ING
POPCORN REHEAT
GROUND
MEATS
CANNED
VEG POTATOES
BEVERAGE FISH
FILLETS CHICKEN PIECES
FROZEN
VEG FRESH VEG
SEEGUIDEBEHINDDOOR
DEFROST
AUTO/ TIME
MICRO
COOKI & II TEMPCOOK / ROAST
PROBESEEGUIDE
1
EXPRESSCOOK
4
EXPRESSCOOK
7
5
EXPRESSCOOK
6
EXPRESSCOOK
89
ADD
30SEC
POWER
LEVEL
3
EXPRESSCOOK
2
EXPRESSCOOK
0
DISPLAYON/ OFF1-10
START
DELAY
START
CLEAR
OFF
HELP
SELECTIONS
SOUND
LEVEL VENT
FAN
TURNTABLE
SURFACE
LIGHT
0-1-2-3 HI-LO-OFF ON-OFF
BRIGHT-NIGHT-OFF
Features and Benefits
•1.3 cu. ft. Oven Cavity
• 900 Watts*
• CircuWave™Plus Cooking System
• SmartControl System With Interactive Display
• Sensor Cooking Controls For Popcorn, Beverage, Reheat, Ground Meats,
Fish Fillets, Chicken Pieces, Potatoes and Three Vegetable Pads
• Add 30 Seconds
• Turntable On/Off
• Help Pad
• Instant On Controls
• Auto Defrost/Time Defrost
• Micro Cook I & II
• Temp Cook/Roast (Probe)
• Dual Rack
• Timer On/Off
• Programmable Nite Light
• Full-View Cooktop Lighting
• Model JVM1350WW–White on White
• Model JVM1350BW–Black on Black
• Model JVM1350AW–Almond onAlmond
• Model JVM1350SY–Stainless Steel
*IEC-705 Test Procedure
