GE JVM1530DM Manual

For answers to your Monogram,® GE Profile™or
GE®appliance questions, visit our website at
ge.com or call GE Answer Center®service,
800.626.2000.
340198
Specification Created 7/07
Listed by
Underwriters
Laboratories
JVM1530DM
GE® 1.5 Cu. Ft. Capacity Over-the-Range Microwave Oven
Note: When replacing a 36" range hood, this kit fills in the
additional width to provide a custom, built-in appearance.
For installation between cabinets only; not for end-of-cabinet
installation. Each kit contains two, 3"-wide filler panels.
Important Information: When installing the Spacemaker
microwave oven over a range, allow minimum of 2" from bottom
of Spacemaker microwave oven to top of range backguard to
allow for removal of light covers.
Ventilation Options: The Spacemaker microwave oven
is designed for adaptation to the following three types of
ventilation:
• Outside exhaust (vertical)
• Outside exhaust (horizontal)
• Recirculating (non-vented ductless – see Filter Kit drawing)
Installation Information: This information is not intended to
be used for installing unit described. Before installing, consult
installation instructions packed with product/kit for current
dimensional data.
Dimensions (in inches)
Over-the-Range Microwave Oven
66" MIN.
Mounting
height
from floor
30" MIN.
width required Exhaust outlet
connects to
3-1/4" X 10" duct
16-1/2
21-3/4
Door open
15-1/16
15-3/4
29-7/8
Minimum distance from
door hinge side to adjacent
wall should equal 1/2-inch.
13"
MAX.
12"
MIN.
Dimensions and Installation Information (in inches) Optional Accessories (Available at additional cost)
12" Filler Panel Kits
JX41–Black
JX40WH–White
15" Filler Panel Kits
JX48BL–Black
JX48WH–White
Filter KitsJX81–Recirculating
Charcoal Filter Kit
To be used when the
Spacemaker microwave oven
cannot be vented to the outside.

For answers to your Monogram,® GE Profile™or
GE®appliance questions, visit our website at
ge.com or call GE Answer Center®service,
800.626.2000.
340198
Specification Created 7/07
Listed by
Underwriters
Laboratories
JVM1530DM
GE® 1.5 Cu. Ft. Capacity Over-the-Range Microwave Oven
JVM1530DMWW/BB
c
onvenience
c
ooking
AM/PM
Power
Level
Surface
Light
Vent
Fan
Add
30 Sec.
Express Cook
Clock
1
4
2
5
3
6
7 8
0
9
Popcorn Beverage Reheat
D ISPLAY
S CROLL S PEED
T imer
on/off
Reminder
Defrost
Auto/Time
Time
Cook
Clear
Off
Delay
Start
Start
Pause
Spacemaker
Features and Benefits
• 1.5 cu. ft. capacity - 950 watts (IEC-705 test procedure)
• Convenience cooking controls - Allows cooking and reheating
at the touch of a button
• Auto and Time Defrost - Automatically defrosts for a specified
amount of time
• Turntable - Continually rotates food to ensure even cooking
• Two-Speed, 200-CFM Venting System - Quickly removes smoke
and steam from cooktop
• Full-View Cooktop Lighting - Illuminates the cooking surface below
• 10 Power Levels - Offer maximum cooking flexibility, from warming
and reheating, to the full speed of microwave cooking at high power
• Model JVM1530DMBB – Black
• Model JVM1530DMWW - White
