JVM1650BH/CH/SH/WH – GE Spacemaker®Over-the-Range Microwave Oven
Dimensions (in inches)
For answers to your Monogram,®GE Profile™or
GE®appliance questions, visit our website at
GEAppliances.com or call
GE Answer Center®service, 800.626.2000.
R
Listed by
Underwriters
Laboratories
Note: Requires 120V grounded outlet. Electrical receptacle must be located in
cabinet above Spacemaker microwave oven. No additional wiring, venting or
cabinet rebuilding necessary in many cases. Complete detailed, easy-to-follow
installation instructions and convenient full-size templates are packed with
the Spacemaker microwave oven.
Important Information: When installing the Spacemaker microwave oven
over a range, allow minimum of 2" from bottom of Spacemaker microwave
oven to top of range backguard to allow for removal of light covers.
Ventilation Options: The Spacemaker microwave ovens are designed for
adaptation to the following three types of ventilation:
•Outside exhaust (vertical –as shown)
•Outside exhaust (horizontal)
•Recirculating (non-vented ductless –see Filter Kit drawing)
Installation Information: This information is not intended to be used for
installing unit described. Before installing, consult installation instructions
packed with product/kit for current dimensional data.
21-3/4"
Door open
16-13/32
66" MIN.
Mounting
height
from
floor
30"
MIN.
width
required
12"
MIN.
Exhaust outlet
connects to
3-1/4" X 10" duct
15-1/4
16
29-7/8
Specification Created 10/03
340101

GE Appliances
JVM1650BH/CH/SH/WH –GE Spacemaker®Over-the-Range Microwave Oven
Specification Created 10/03
340101
R
Listed by
Underwriters
Laboratories
For answers to your Monogram,®GE Profile™or
GE®appliance questions, visit our website at
GEAppliances.com or call
GE Answer Center®service, 800.626.2000.
Optional Accessories (Available at additional cost)
HOOD EXHAUST DUCT: Outside ventilation requires a HOOD EXHAUST DUCT. Read the following carefully.
EXHAUST CONNECTION: The hood exhaust has been designed to mate with a standard 3-1/4" x 10"
rectangular duct. If a round duct is required, a rectangular-to-round transition adaptor must be used.
Do not use less than a 6”diameter duct
REAR EXHAUST: If a rear or horizontal exhaust is to be used, care should be taken to align exhaust with space
between studs, or wall should be prepared at the time it is constructed by leaving enough space between the
wall studs to accommodate exhaust.
MAXIMUM DUCT LENGTH: For satisfactory air movement, the total duct length of 3-1/4" x 10" rectangular or
6" diameter round duct should not exceed 140 equivalent feet.
ELBOWS, TRANSITIONS,WALL AND ROOF CAPS, etc., present additional resistance to airflow and are
equivalent to a section of straight duct which is longer than their actual physical size. When calculating the total
duct length, add the equivalent length of all transitions and adaptors plus the lengths of all straight duct sections.
The chart below shows the approximate feet of equivalent length of some typical ducts.
Duct Equivalent Feet
A. Rectangular-To-round 5 ft.
Transition Adaptor
B. Wall Cap 40 ft.
C. 90°Elbow 10 ft.
D. 45°Elbow 5 ft.
E. 90°Elbow 25 ft.
F. 45°Elbow 5 ft.
G. Roof Cap 24 ft.
Filter Kits
JX81A–Recirculating
Charcoal Filter Kit
To be used when the
Spacemaker microwave
oven cannot be vented
to the outside.
Filler Panel Kits
JX48BL–Black
JX48WH–White
When replacing a 36" or 42"
range hood, this kit fills in the
additional width to provide a
custom built-in appearance.
For installation between
cabinets only; not for
end-of-cabinet installation.
Each kit contains two 3"-wide
filler panels.

GE Appliances
JVM1650BH/CH/SH/WH –GE Spacemaker®Over-the-Range Microwave Oven
Spacemaker
123
789
CLOCK AM/FM AUTO
NITELIGHT REMINDER
COOK
SNACKS
BEVERAGE
VEGETABLES
POPCORN REHEAT
POTATO
TIMECOOK
DEFROST
AUTO/TIME
HELP
DELAY
START START
CLEAR
OFF
ADD
30SEC.
TURNTABLE VENTFAN
BEEPER
VOLUME
SURFACE
LIGHT
POWER
LEVEL
DISPLAYON/OFF
GUIDEBEHIND DOOR
456
0
EXPRESSCOOK EXPRESSCOOK EXPRESSCOOK
EXPRESSCOOK EXPRESSCOOK EXPRESSCOOK
ON/OFF HI-LO-OFF
BRIGHT-LIGHT-OFF
SCHOOLSPEED
SENSOR
COOKING CONVENIENCE
COOKING
TIMER
ON-OFF
PAUSE
SELECTIONS
Features and Benefits
•1.6 cu. ft. capacity –1000 Watts (IEC-705 test procedure)
•Sensor cooking controls –Automatically adjust the time and power for perfect cooking results.
•Convenience cooking controls –Allows cooking and reheating at the touch of a button.
•Auto/Time Defrost –Automatically defrosts for a specified amount of time.
•Oven rack with two positions –Increases cooking flexibility and space.
•Turntable On/Off –Ideal for oversized, oblong-shaped dishes.
•Three-speed, 300-CFM vortex venting system –Quickly removes smoke and steam from
the cooktop.
•Model JVM1650BH –Black on black
•Model JVM1650CH –Bisque on bisque
•Model JVM1650SH –Stainless steel
•Model JVM1650WH –White on white
