GE TRIVECTION ZET3038 Manual

ZET3038SH/WH/BH – GE Monogram 30" Built-In Single Oven
with Trivection™ Technology
Specification Revised 6/04
130311
Dimensions (in inches)
30" Built-In Single Oven Dimensions (in inches)
Note: These ovens are not approved for stackable or
side-by-side installations.
Note: Cabinets installed adjacent to wall ovens must have an
adhesion spec of at least a 194°F temperature rating.
Installation Information: Before installing, consult installation
instructions packed with product for current dimensional data.
R
Listed by
Underwriters
Laboratories
For answers to your Monogram,
® GE Profile™ or
GE® appliance questions, visit our website at
GEAppliances.com or call
GE Answer Center® service, 800.626.2000.
Electric wall ovens are not approved for installation
with a plug and receptacle. They must be hard wired in
accordance with installation instructions.
jt930_install_ii.eps
SWO
Bottom of
Cutout
Acceptable
junction box
location area
SWO
18"
12"
3-1/2"
10-3/4 "
(Must support 225 lbs.)
KW Rating
240V 5.9
208V 4.4
Breaker Size
240V 30 Amps
208V 30 Amps
C
L
(Must Support 275 LBS.)
2 x 4 or
equivalent
runners
Suitable
bracing
to support
runners
21-5/8"
over centerline
of cabinet
29-3/4''
28-1/4''
30''
Recommended
Cutout Location
32-1/2" from
the floor
21''
Allow min. of 21'' for
clearance to adjacent corners,
drawers, walls, or etc.
Cutout Height
27-1/4'' min.
27-5/16'' max.
B
A
Cutout Depth
23-1/2'' min.
Cutout Width
28-1/2'' min.
28-5/8'' max.
A = Allow 11/16" - 3/4" for overlap of oven over side edges of cutout.
B = Allow 1" overlap of oven over top and 1-1/4" overlap at the bottom
edges of cutout.

ZET3038SH/WH/BH – GE Monogram 30" Built-In Single Oven
with Trivection™ Technology
Specification Revised 6/04
130311
ZET3038SHSS
12 3
45 6
78
0
UPPER OVEN
CLEAR
OFF
CLEAR
OFF
OVEN
LIGHT
OVEN
LIGHT
TIMER
ON / OFF
LOCK
LOWER OVEN
9
Features and Benefits
• Trivection technology – Combines thermal,
convection and microwave energies to produce
quality food remarkably fast
• Sophisticated styling
• Cooking versatility
• Full-size oven capacity
• Glass touch electronic controls
• Halogen interior light
• Model ZET3038SHSS – Stainless steel
• Model ZET3038WHWW – White
• Model ZET3038BHBB – Black
