Congratulations on your purchase of the Signal Generator. Your complete
satisfaction is very important to us.
Gefen TV
Gefen TV is a unique product line catering to the growing needs for innovative
home theater solutions. We specialize in total integration for your home theater,
while also focusing on going above and beyond customer expectations to ensure
you get the most from your hardware. We invite you to explore our distinct
product line and hope you find your solutions. Don’t see what you are looking for
here? Please call us so we can better assist you with your particular needs.
The Gefen TV Signal Generator
The Gefen TV Signal Generator is a hand-portable, cost-effective testing tool
that allows installers to locate and eliminate problems with HDTV Equipment and
Displays, as well as calibrate equipment on-the-spot.
How It Works
Simply connect the HDMI output port of the Gefen TV Signal Generator to your
HDTV display. Power-cycle all equipment. Activate the On-Screen Display (OSD)
Menu via the remote control and select the tests that you would like to perform.
The easy-to-use on-screen menu system will guide you through the options and
features. You can feed digital or analog audio into the Signal Generator rear
panel in order to hear music while testing displays rather than hearing the default
high-pitched audio test tone.
1
INTRODUCTION

2
READ THESE NOTES BEFORE INSTALLING OR
OPERATING THE SIGNAL GENERATOR
• The Gefen TV Signal Generator can be customized using it’s programming
application. Please download this application from Gefen’s website at:
http://www.gefen.com/kvm/support/download.jsp
• HDMI 1.2 / HDCP 1.0 / DVI 1.0 compliant.
OPERATION NOTES

3
Features
• Multi-format video output for SD and HD video
• LCD display of function being performed
• Test patterns include: color purity, gradual, B&W, grid, circle, etc.
• Provides total 35 patterns and 39 timings
• PAL and NTSC frame rates are fully supported
• Overscan function to zoom in on undersized video input
• RGB & YUV color spaces / PC & HDTV timings supported
• Optical and analog audio inputs
• HDMI 1.2, HDCP 1.1 and DVI 1.0 compliant
• Small form factor, easy to transport, audio tone output
• Supports HDCP signal verification pattern (Pattern 39)
Package Includes
(1) Gefen TV Signal Generator
(1) 6 foot HDMI cable (M-M)
(1) 5V DC Power Supply
(1) User’s Manual
FEATURES

4
Front Panel
Back Panel
NOTE:
1. OVERSCAN Button
By default, the Gefen TV Signal Generator is set to underscan mode. If your
video signal does not fill the entire display, press this button once to switch
to overscan mode. You can press the button a second time to revert to
underscan mode.
2. HDMI OUT
The HDMI output can be connected to an HDMI display using HDMI cable or
to a DVI display using HDMI to DVI cable or Gefen adapter from HDMI to DVI.
3. RS232 Communication Port
Connect to the RS-232 serial port of your PC to customize the unit using the
appropriate application.
RS-232
Port HDMI Output Optical Audio Input Analog
Audio Input
Overscan
Main Power
Switch
5V DC
Input
PANEL DESCRIPTIONS

5
External Audio Analog Indicator
External Audio Optical Indicator YUV 4:2:2 Color Space Indicator
YUV 4:4:4 Color Space Indicator
RGB 4:4:4 Color Space Indicator
Auto Mode Indicator
External Audio HDMI Indicator
HDMI Signal Output
DVI Signal Output
Audio
Selector Timing
Selector UPTiming
Selector DOWN
Output
Signal
Selector LCD Display Auto
Mode
Selector
Pattern
Selector UP
Pattern
Selector DOWN
Color Space
Selector
TOP PANEL DESCRIPTIONS

6
How to connect the Gefen TV Signal Generator
1. Connect the HDMI OUT of the Gefen Signal Generator to the HDMI of your
HDMI display or device.
2. Plug the 5V power supply into the Gefen TV Signal Generator.
3. Turn on the display first.
4. Turn on the Gefen TV Signal Generator second.
You may need to press the OVERSCAN button if the signal from the Gefen TV
Signal Generator does not fill the entire screen.
If you are not receiving a picture, check your power supply. Make sure the Gefen
TV Signal Generator is plugged in and that the unit is turned on. If your display
has more than one HDMI port, make sure that your display is set up to receive
signals from that input. If you’re testing HDMI, make sure that the Output Signal
Selector is set to HDMI.
If you are still unable to receive a picture, it is possible that the current output
timing is not supported by your monitor. The current timing (resolution and
refresh rate) are displayed in the LCD window on the unit. Use the Timing
Selector UP or DOWN buttons to select a different timing. See chart on page 8.
Once you have established a timing that is accepted by your display, you can
select from a wide array of video test patterns by using the Pattern Selector UP
or DOWN buttons (see table beginning on page 9).
Checking stereo or multi-channel audio capability
1. Connect the HDMI OUT to the HDMI IN of your A/V receiver (if applicable).
2. Connect the HDMI OUT of the Gefen TV Signal Generator to the HDMI IN of
your A/V receiver.
3. Connect the HDMI OUT from theA/V receiver to the HDMI IN of your display.
4. Set the Audio Output Selector to INT SINEWAVE. (If you are using the
optional digital optical or analog stereo audio inputs, please select those
instead.)
5. Use the Pattern Selector buttons to select P38 AUDIO and follow the
onscreen directions.
The audio test is capable of verifying 2, 4, 6 and 8 discrete channel audio.
CONNECTING AND OPERATING THE SIGNAL GENERATOR

7
CONNECTING AND OPERATING THE SIGNAL GENERATOR
External Audio Inputs
In addition to using the internal sinewave for checking audio, the Gefen TV
Signal Generator allows you to use your own audio source and accepts both
analog and digital audio signals. For digital audio connections, connect an optical
cable from your audio source to the OPTICAL input on the back of the unit and
select EXT OPT by pressing the Audio Selector button. For analog connections,
connect a stereo RCA cable to your audio source and plug the other end into the
Analog Input jacks and select EXT L/R by pressing theAudio Selector button. To
prevent a reversed stereo image, make sure that the left and right channels are
connected properly.
Testing DVI
You can test DVI devices by setting the Output Signal Selector to DVI. This
button will toggle between HDMI and DVI color space. Simply connect the HDMI
OUT from the Gefen TV Signal Generator to the DVI IN of the device you wish to
test.
Color Space
You can switch color spaces by pressing the Color Space Selector button.
Pressing this button will cycle through RGB, YUV2 and YUV4 color spaces.
HDMI supports all color spaces but DVI only supports YUV2.
HDCP compliance
To check HDCP compliance, select a timing that is accepted by your display and
use the Pattern Selector buttons to select P39 HDCP-Produce from the list of
patterns.
You can also check audio in this mode by setting the Audio Output Selector to
INT SINEWAVE.
HDCP testing can only be verified through HDMI or DVI connections.
Automatic Testing
The Gefen TV Signal Generator has the capability to auto select specific timings
from the table provided on page 8.
Press the AUTO button to start auto mode. To stop the auto mode, press the
AUTO button again.

8
LCD LAYOUT
TIMING TABLE
No. Resolution Hz No. Resolution Hz
T01 640x480 60 T19 1600x1200 60
T02 640x480 72 T20 1920x1200 60
T03 640x480 75 T21 720x480i 59
T04 640x480 85 T22 720x480i 60
T05 800x600 56 T23 720x480p 59
T06 800x600 60 T24 720x480p 60
T07 800x600 72 T25 1280x720p 59
T08 800x600 75 T26 1280x720p 60
T09 800x600 85 T27 1920x1080i 59
T10 1024x768 60 T28 1920x1080i 60
T11 1024x768 70 T29 1920x1080p 59
T12 1024x768 75 T30 1920x1080p 60
T13 1024x768 85 T31 720x576i 50
T14 1280x960 60 T32 720x576p 50
T15 1280x960 85 T33 1280x720p 50
T16 1280x1024 60 T34 1920x1080i 50
T17 1280x1024 75 T35 1920x1080p 50
T18 1280x1024 85
Timing Number
Pattern Number
Pattern Name
Timing Resolution Timing Frequency (Hz)

9
PATTERN TABLE
No. Name Description Application
P01 White
Purity Pattern
White (100% Y)
3 primary colors:
Red, Green, Blue
4 Additional colors:
Magenta, Yellow,
Cyan and Black
- Brightness control
- Purity checks and adjustment
- Interference between sound
and chroma carrier
- Color A.G.C.
- Chroma writing current of
video recorders
- White setting
- Synchronization
- FM demodulator (white level)
- Beam current of picture tube
- Luminance writing current
P02 Blue
P03 Red
P04 Magenta
P05 Green
P06 Cyan
P07 Yellow
P08 Black
P09 RED Setting
Gradient Pattern
Press the AUTO
button to enter
the user menu for
the percentage
adjustment of each
color.
- Brightness control
- Luminance writing current
- Linearity of video amplifier
- Overall color performance
- Amplitude response
resolution
- Linearity of chroma amplitude
P10 Green Setting
P11 Blue Setting
P12 Gray Setting
P13 Color Bar
Color Bar
8 vertical bars:
White, Yellow, Cyan,
Green, Magenta,
Red, Blue and Black
- Overall color performance
- Burst keying
- Subcarrier regeneration
- Matrix circuit check
- RGB amplifiers
- Color delay versus B/W
signal saturation
P14 Gray -8 Grayscale
Full screen linear
staircase signal to
white
Steps:
8/16/32/64/256
- Brightness + contrast
circuitry
- Grayscale tracking
- Linearity of video amplifier
P15 Gray-16
P16 Gray-32
P17 Gray-64
P18 Gray-256
P19 V-Line On/ Off
Black White
Vertical
Full screen linear
vertical bar signal
with black/white
intervals of 1 and 12
pixels
- Check bandwidth and phase
behavior of a video
transmission
- Verify video amplifier
- Verify color temperature
P20
BW-12

10
PATTERN TABLE
No. Name Description Application
P21
H-Line On/
Off
Black-White
Horizontal
Full screen linear
Horizontal bar
signal black/white
intervals of 1/3/6
pixels
- Check bandwidth and phase
behavior of a video transmission
- Verify video amplifier
- Verify color temperature
P22
Hor-3
P23 Hor-6
P24 Multi-burst
Multi-burst
Full screen
definition pattern
of frequencies
0.5, 1.0, 2.0,
4.0, 4.8, and 5.8
MHz for 625 line
systems
- Video bandwidth
- Check luminance amplifier in B/W
- Amplitude response resolution
- Check resolution of monitors
and video recorders
P25
Pluge
Pluge Pattern
Three vertical bar
pluge pulses and
3 horizontal pluge
pulse boxes
- Calibrate black level
- Calibrate black levels: super-
black, normal-black and near-black
P26 Grid-1
Grid
Full screen grid
with black/white
intervals of 1 and
6 pixels
- Static convergence
- Dynamic convergence
- Pin-cushion correction
- E/W-N/S corrections
- Amplitude response
P27
Grid-36
P28 Gra-256-R Gradient
Full screen linear
256 step staircase
signal from black
to red, green, or
blue
- Brightness + contrast circuitry
- Linearity of video amplifier
P29
Gra-256-G
P30 Gra-256-B
P31 Circles
Circles
Black circle on
white background,
640x480 has 4 by
3 total 12 circles,
800x600 has 5 by
3 total 15 circles,
and 1024x768
has 6 by 4 total
24 circles
- Overall linearity
- Overall geometry
- Framing
- Reflections

11
PATTERN TABLE
No. Name Description Application
P32 EDID
EDID Reader
Press the AUTO
button to initiate an
EDID read of the
currently connected
display.
-Extremely useful for examining
a display’s EDID for errors and
capabilitites
-Detailed descriptions of
various aspects of the EDID
are listed on multiple pages
P33 Gefen-1 Gefen Patterns
Gefen specifically
designed patterns
- Multiple purpose
P34 Gefen-2
P35 Gefen-3
P36 Gefen-4
P37 Crosshatch
Crosshatch
Vertical and
horizontal hatch
pattern. White lines
on a black
- Multiple point color
convergence
- Overall geometry, rotation,
and overscan
P38
Audio
Audio
PCM sine wave
tone sent to either
the analog, optical,
or internal HDMI
output. 2, 4, 6, or 8
channel
- Multi-channel audio
compatibility
P39
HDCP
HDCP-Produce
Green/Blue
horizontal bars
with HDCP
verification and data
comparison on the
upper first third area
of black background
- HDCP verification
- HDCP data comparison
- HDCP authentication check
- HDCP transmitting encrypted
data check

12
SIGNAL GENERATOR PROGRAMMING APPLICATION
1. Main Window
Double-click the executable file to launch the remote control application. The
main window will show up. Click the Connect button to link to the unit.
2. Select COM Port to Control
The application will prompt you to select which COM port connected to the unit
you want to control. Select from COM1 or COM2 and click OK.
Pin Definition Pin Definition
1NC 1NC
2 TxD 2 RxD
3 RxD 3 TxD
4NC 4NC
5 GND 5 GND
6NC 6NC
7NC 7NC
8NC 8NC
9NC 9NC
The RS-232 program can be downloaded from the download section of
Gefen’s website at: http://www.gefen.com/kvm/support/download.jsp

13
SIGNAL GENERATOR PROGRAMMING - TIMING
Click on the TIMING button to launch the TIMING selection window. Click
“Show List” button to select from TIMING list and adjust the Horizontal/Vertical/
Pixel Clock settings, when complete, click “Run Timing” button to start the
output of selected timing (resolution/frequency.)
List of Timings

14
SIGNAL GENERATOR PROGRAMMING - PATTERN
Click the PATTERN button to launch the PATTERN selection window. Click
“Show List” button to select from TIMING list and adjust the Horizontal/Vertical/
Pixel Clock settings, when complete, click “Run Timing” button to start the
output of selected timing (resolution/frequency.)
List of Patterns

15
SIGNAL GENERATOR PROGRAMMING - UPLOADING
Click and select the “Program” from “Edit” option of the tool bar to launch the
Program window.
Program the desired sequence of timing/pattern/unit/show time, then click
“Upload” to send the program to the unit.
Click and select the “Save as” from “File” option of the tool bar to save your
program. You click the “Open” from “File” option of the tool bar later on to load
your saved program.

16
Single Link Video Bandwidth ............................................................... 165 MHz
Audio Input ........................................... Digital Optical, Left / Right Analog RCA
Video Output ............................................................. HDMI (Type A Connector)
Power Supply .................................... 5V DC 3.2A Power Supply (AC 90-240V)
Dimensions …………………………………………….......... 11” W x 5” D x 1¾” H
RS-232 …...……………………………………………………............. DB-9 type C
Weight ...................................................................................................... 1.5 lbs
SPECIFICATIONS

17
