GEN6 PREMIUM CLASS NAVIGATION | SIMPLE MANUAL
GENESIS GV80
ENGLISH
FRANÇAIS
ESPAÑOL
한국어
1 JX1_AVNT_USA_QRG_ENG_MFL71279723.indd 1 2020-10-27  11:33:24

2
ENG
ThANk yOU fOR PURChASING ThIS
GEN6 PREMIUM CLASS NAVIGATION.
Please scan this QR code to open the Gen6 premium class navigation web manual.
Before using the product, read the contents of this user’s manual
carefully and use this product safely.
1 JX1_AVNT_USA_QRG_ENG_MFL71279723.indd 2 2020-10-27  11:33:24

3
ENG
hOw TO SCAN QR COdE
hOw TO SCAN QR COdE
a Open the camera on your iPhone and
point it at the code.
b Scanning QR code :
Press [Manual] > [Web Manual (Navigation)].
Scan the QR code, then tap the noti󳝌cation to go to the web page.
c Access the content.
a Open the Play Store. After searching
QR code reader, install it. Open the QR
code reader on your android and point
it at the code.
b Scanning QR code :
Press [Manual] > [Web Manual (Navigation)].
Scan the QR code, then tap URL in the code to go to the web page.
c Access the content.
You can access directly following URL
address. ( http://webmanual.genesis.com/
PREM_GEN6/AVNT/JX1/USA/English/index.
html)
You can access directly following URL
address. ( http://webmanual.genesis.com/
PREM_GEN6/AVNT/JX1/USA/English/index.
html)
KiOS (iPhone)
KAndroid (Galaxy etc.)
1 JX1_AVNT_USA_QRG_ENG_MFL71279723.indd 3 2020-10-27  11:33:25

4
ENG
PRECAUTIONS fOR SAfETy / TAbLE Of CONTENTS
SAfETy NOTES
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC
SHOCK, DO NOT REMOVE THE COVER (OR
BACK). NO USER SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE
PERSONNEL.
The lightning 󳝍ash with the arrowhead
symbol within an equilateral triangle is
intended to alert the user about the presence of
uninsulated dangerous voltage within the
product’s enclosure that may be of suf󳝌cient
magnitude to constitute a risk of electric shock.
The exclamation point within an equilateral
triangle is intended to alert the user to the
presence of important operating and
maintenance (servicing) instructions in the
literature accompanying the appliance.
Always operate the vehicle in a safe
manner. Do not become distracted by
the vehicle while driving and always be fully
aware of all driving conditions. Do not change
settings or any functions. Pull over in a safe and
legal manner before attempting such operations.
To promote safety, certain functions are disabled
unless the parking brake is on.
To reduce the risk of electric shock, do
not remove the cover or back of this
product. There are no user-serviceable parts
inside. Refer servicing to quali󳝌ed service
personnel.
To reduce the risk of 󳝌re or electric
shock, do not expose this product to
dripping or splashing water, rain, or moisture.
When driving your vehicle, be sure to
keep the volume of the unit low enough
to allow you to hear sounds coming from the
outside.
Do not drop it and avoid heavy impacts
at anytime.
The driver should not watch the monitor
while driving. If the driver watches the
monitor while driving, it may lead to
carelessness and cause an accident.
fCC NOTICE (fOR USA)
This equipment has been tested and found
to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable
protection against harmful interference in
a residential installation. This equipment
generates, uses, and can radiate radio frequency
energy and, if not installed and used in
accordance with the instructions, may cause
harmful interference to radio communications.
However, there is no guarantee that interference
will not occur in a particular installation. If this
equipment does cause harmful interference
to radio or television reception, which can be
determined by turning the equipment off and
on, the user is encouraged to try to correct the
interference by one or more of the following
measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the
equipment and the receiver.
- Connect the equipment to an outlet on a
circuit different from that to which the receiver
is connected.
- Consult the dealer or an experienced radio/TV
technician for help.
This device complies with part 15 of the FCC
Rules. Operation is subject to the following two
conditions: (1) this device may not cause harmful
interference and (2) this device must accept any
interference received, including interference that
may cause undesired operation. Any changes
PRECAUTIONS fOR SAfETy / TAbLE Of CONTENTS
1 JX1_AVNT_USA_QRG_ENG_MFL71279723.indd 4 2020-10-27  11:33:26

5
ENG
PRECAUTIONS fOR SAfETy / TAbLE Of CONTENTS
or modi󳝌cations in construction of this device
which are not expressly approved by the party
responsible for compliance could void the user’s
authority to operate the equipment.
FCC Radio Frequency Interference
Requirements (for UNII devices)
High power radars are allocated as primary
users of the 5.25 to 5.35 GHz and 5.65 to 5.85
GHz bands. These radar stations can cause
interference with and/or damage this device.
This device cannot be co-located with any other
transmitter.
FCC RF Radiation Exposure Statement
[For having wireless function (WLAN,
Bluetooth,...)]
This equipment complies with FCC radiation
exposure limits set forth for an uncontrolled
environment. This transmitter must not be co-
located or operating in conjunction with any
other antenna or transmitter.
This equipment should be installed and operated
with minimum distance 20 cm (7.8 inches)
between the antenna and your body. Users must
follow the speci󳝌c operating instructions for
satisfying RF exposure compliance.
TAbLE Of CONTENTS
3 How to scan QR code
4 PRecautions foR safety / table
of contents
4 safety notes
4 fcc notice (foR usa)
6 name and function of eacH
comPonent
6 Head unit
7 fRont seat contRol keyes
8 steeRing wHeel Remote contRol
9 basic contRols
9 tuRning tHe system on
9 tuRning tHe system off
9 system Reset
10 using contRolleR and
toucHPad
10 uPdate
11 tRoublesHooting
12 Speci󳛴cation
1 JX1_AVNT_USA_QRG_ENG_MFL71279723.indd 5 2020-10-27  11:33:26

6
ENG
NAME ANd fUNCTION Of EACh COMPONENT
hEAd UNIT
The image of this product may be different from the actual product.
NAME ANd fUNCTION Of EACh COMPONENT
aMAP button
↟Moves to the map screen showing
the current position of vehicle.
↟When the destination is set, the voice
navigation starts on the map screen.
bNAV button
↟Moves to navigation menu.
↟Press and hold to move to the
destination search screen.
cK(Custom) button
↟User may select and use a desired
feature with this button.
↟Press and hold to move to the
custom button settings screen.
dRADIO button
↟Activates radio mode.
↟Each button press changes the mode
in sequence of FM > AM > SXM > FM.
eMEDIA button
↟Press this button to switch between
the media menu screen and media
play screen.
↟Press and hold to move to the media
menu screen.
f SETUP button
↟Moves to settings screen.
↟Press and hold to move to the version
info screen.
1 JX1_AVNT_USA_QRG_ENG_MFL71279723.indd 6 2020-10-27  11:33:26

7
ENG
NAME ANd fUNCTION Of EACh COMPONENT
fRONT SEAT CONTROL kEyES
The image of this product may be different
from the actual product.
a :/VOL wheel button
↟ Press brie󳝍y to turn AV on/off.
↟Press and hold to turn on or off the
display.
↟Turn the wheel up/down to adjust the
volume.
bBACK button
↟Press brie󳝍y to move to the previous
screen.
↟Press and hold to go to the home
screen.
cHOME button
↟Press brie󳝍y to go to the home
screen.
↟Press and hold to go to the map
screen.
d TUNE button
↟Radio: Turn the wheel up/down to
increase/decrease the frequency by
one step. (FM: 0.2MHz, AM: 10 KHz)
↟SiriusXM: Turn to change the channel.
↟USB/Sounds of nature: Search for a
󳝌le by turning the wheel up/down.
And, when the name of desired 󳝌le
is displayed, press the button to play
the 󳝌le.
eMENU button
↟Displays a pop-up menu for each
mode when pressed brie󳝍y.
↟Turns on and off the split screen on
the map when pressed and held.
fController
Use controller to move and select the
menu.
1 JX1_AVNT_USA_QRG_ENG_MFL71279723.indd 7 2020-10-27  11:33:26

8
ENG
NAME ANd fUNCTION Of EACh COMPONENT
STEERING whEEL REMOTE
CONTROL
The image of this product may be different from
the actual product.
ai(Voice Recognition) button
↟When it is pressed shortly
-Activates voice recognition mode.
-Press and hold the button to cancel
voice recognition.
↟When it is pressed and held
- Activates voice recognition mode
of the connected phone projection
device.
bW(Bluetooth Call) button
When it is pressed shortly
↟Searches new Bluetooth phone or
connects the registered phone if
Bluetooth is not connected.
↟If Bluetooth is connected,
-If selected in the call waiting screen,
displays call history screen.
-If selected in call history screen, makes
a call to last called number.
-If selected in phone entrance screen,
enters the last call number.
-If selected in phone reception alert
screen, answers the phone call.
-If selected in calling, ends the call.
When it is pressed and held
↟When Bluetooth is connected, if selected
in Bluetooth hand free waiting mode,
redials.
↟If selected in pop-up of calling, rejects
the call.
cJ/Ibutton
Turn the wheel up/down to adjust the
volume.
f(MUTE) button
Press the wheel to turn mute on/off.
d MODE button
↟When it is pressed shortly
- Selects a mode from Bluetooth audio,
FM, AM, SXM, USB music, USB video,
phone projection or sounds of nature.
↟When it is pressed and held
- Moves to the mode button (steering
wheel) settings screen.
eL(Custom) button
↟User may select and use a desired feature
with this button.
↟Press and hold to move to the custom
button settings screen.
fS/Wbutton
↟When it is pressed shortly
- In FM/AM mode, selects a preset radio
station .
- In SiriusXM mode, plays broadcast
channel saved in the preset.
- In media mode, searches track, 󳝌le or
chapter.
↟When it is pressed and held
- In FM/AM mode, broadcasting are
automatically searched.
- In SiriusXM mode, changes the
broadcast channels saved in presets
until the button is released .
- While USB mode activated, rewinds or
fast forwards the 󳝌le.
1 JX1_AVNT_USA_QRG_ENG_MFL71279723.indd 8 2020-10-27  11:33:26

9
ENG
bASIC CONTROLS
TURNING ThE SySTEM ON
The image of this product may be different from the actual product.
1. Press the engine start button. Once the system is turned on,
the booting process will start and the safety warning page is
displayed.
↟Press [Language] to change the language of system display.
↟ Press [Driver 1], [Driver 2] or [Guest] to change the pro󳝌le of
system.
2. Press [Con󳝌rm].
,NOTE
↟You cannot operate the system while it is booting up. It may
take some time for all of features of the system boot up.
↟The safety warning page is displayed every time the ACC
is turned on. The displayed warnings are related to safety,
please read thoroughly and comply with the safety warnings.
TURNING ThE SySTEM Off
Press and hold [:/VOL] the wheel on the front seat control key.
To turn the system on again, press [:/VOL] the wheel on the front
seat control key.
,NOTE
Check the volume when turning on the system. Before turning
on the system, adjust the volume to a reasonable level.
SySTEM RESET
This feature is used to reset the system in the occurrence of an
unforeseen error or problem. Press [MAP] button and [SETUP]
button for 5 seconds.
bASIC CONTROLS
1 JX1_AVNT_USA_QRG_ENG_MFL71279723.indd 9 2020-10-27  11:33:28

10
ENG
bASIC CONTROLS
USING CONTROLLER ANd TOUChPAd
Rotate controller to left/right or use touchpad to switch or select
the menu.
Controller Description
Rotate controller to left/right to switch
the menu.
Swipe up/down/left/right on touchpad
to switch the menu.
Press touchpad to select the menu.
Write the desired words or gesture on
the touchpad.
Press controller to up/down/left/right
to focus menu or move map position.
UPdATE
For supplementation of system software, addition of new functions,
and renewal of map, update is needed.
1. Press [Setup] > [General] > [Software Information] on the home
screen.
2. After inserting the USB with the update 󳝌le, press [Update].
3. Update is carried out automatically, and after completion,
system automatically reboots.
,NOTE
↟This product requires regular updates for software
corrections, new functions and map updates. Updating may
require up to 1 hour depending on the data size.
↟Turning off the power or ejecting the USB during the update process
may result in update failure.
1 JX1_AVNT_USA_QRG_ENG_MFL71279723.indd 10 2020-10-27  11:33:28

11
ENG
TROUbLEShOOTING
Problem: The power does not turn on.
↟Possible Cause: The fuse is disconnected.
↟Countermeasure:
- Replace with a suitable fuse.
- If the fuse is disconnected again, please contact your dealer.
↟Possible Cause: Device is not properly connected.
↟Countermeasure: Check to see that the device has been properly connected.
Problem: The system does not play.
↟Possible Cause: The vehicle battery is low.
↟Countermeasure: Charge the battery if the problem persists, contact your point
of purchase or service center.
Problem: The image colour/tone quality is low.
↟Possible Cause: The brightness, saturation, and contrast levels are not set
properly.
↟Countermeasure: Properly adjust the brightness, saturation, and contrast levels
through Display Setup.
Problem: Sound does not work.
↟Possible Cause: The volume level is set to the lowest level.
↟Countermeasure: Adjust the volume level.
↟Possible Cause: The connection is not proper.
↟Countermeasure: Check to see that the device has been properly connected.
↟Possible Cause: The device is currently fast-forwarding, rewinding, scanning, or
playing in slow mode.
↟Countermeasure: The sound will not work when the device is fast-forwarding,
rewinding, scanning, or playing in slow mode.
Problem: The sound or image quality is low.
↟Possible Cause: Vibration is occurring from where the conversion switch has
been installed.
↟Countermeasure: The sound may be short circuited and the image distorted if
the device vibrates.
Problem: The USB does not work
↟Possible Cause: USB memory is damaged.
↟Countermeasure: Please use after formatting the USB into FAT 16/32, exFAT,
NTFS format.
↟Possible Cause: USB memory has been contaminated.
↟Countermeasure: Remove any foreign substances on the contact surface of the
USB memory and infotainment system.
↟Possible Cause: A separately purchased USB HUB is being used.
↟Countermeasure: Directly connect the USB memory with the infotainment
system on the vehicle.
↟Possible Cause: A USB extension cable is being used.
↟Countermeasure: Directly connect the USB memory with the infotainment
system on the vehicle.
↟Possible Cause: A USB which is not a Metal Cover Type USB Memory is being
used.
↟Countermeasure: Use standard USB Memory.
↟Possible Cause: An HDD type, CF, SD Memory is being used.
↟Countermeasure: Use standard USB Memory.
↟ Possible Cause: There are no music 󳝌les which can be played.
↟ Countermeasure: Only MP3, WMA 󳝌le formats are supported. Please use only
the supported music 󳝌le formats.
TROUbLEShOOTING
1 JX1_AVNT_USA_QRG_ENG_MFL71279723.indd 11 2020-10-27  11:33:28

12
ENG
Specication
Specication
Common
Power Supply DC 14.4 V
Operation Power DC 9 ~ 16V
Current Consumption Max. 6A
Dark Current
(average) Max. 1mA
Operating
Temperature -20 ~ 70 °C
Storage Temperature -40 ~ 85 °C
Dimensions
(Headunit)
232 (W) X 85.2 (H) X 164.5 (D)
mm
Weight (Head unit) 1.4kg
Front
Monitor
Screen Size
(Outline Dimension)
361.82 (H) X 112.4 (V) X 12.8
(D) mm (Typ.), (W/PemNut,
W/Cover Glass 1.1T)
Resolution 2560 X 720 (14.5”)
Operating Method TFT, In Plane Switching (IPS),
Active Matrix
Viewing Angle 80/80/80/80 (L/R/U/D)
Internal Lighting LED
Radio
AM
Tuning Range 530 ~ 1710 Khz
Usable Sensitivity 35 dBuV
SNR Ratio 45 dB
FM
Tuning Range 87.5 ~ 107.9 Mhz
Usable Sensitivity 10 dBuV
SNR Ratio 50 dB
SiriusXM™
Tuning Range 2333.465 ~ 2344.045 Mhz
Min. Sensitivity -80dBm
T.H.D Max. 0.2 %
Bluetooth
Supported pro󳝌le
HFP 1.7/ A2DP 1.3/ AVRCP
1.6 / PBAP 1.2 / MAP 1.2/ SPP
1.2 / BIP 1.2
Supported Bluetooth
Speci󳝌cation 4.2
Frequency Range
/Output Power
2402 ~ 2480 Mhz
Max. 4.0 dBm
Number of Channels 79
1 JX1_AVNT_USA_QRG_ENG_MFL71279723.indd 12 2020-10-27  11:33:29

13
ENG
Specication
CDMA
RX
Frequency
Range
869MHz~894MHz(BC0),
1930MHz~1990MHz(BC1)
Min. Sensitivity -104dBm (FER =0.5% under)
TX
Frequency
Range
824MHz~849MHz(BC0),
1850MHz~1910MHz(BC1)
Max. Power Power Class3(BC0),Power
Class2(BC1), 23dBm~30dBm
LTE
RX
Frequency
Range
1930MHz~1990MHz(B2),
2110MHz~2155MHz(B4),
869MHz~894MHz(B5),
746MHz~756MHz(B13)
Min. Sensitivity
-95dBm @10M(B2),
-94dBm @20M(B4),
-95dBm @10M(B5),
-94dBm @10M(B13)
(Throughput ≥95%)
TX
Frequency
Range
1850MHz~1910MHz(B2),
1710MHz~1755MHz(B4),
824MHz~849MHz(B5),
777MHz~787MHz(B13)
Max. Power Power Class3 (B2,B4,B5,B13)
20.3~25.7dBm
1 JX1_AVNT_USA_QRG_ENG_MFL71279723.indd 13 2020-10-27  11:33:29

*MFL71279723*
1 JX1_AVNT_USA_QRG_ENG_MFL71279723.indd 14 2020-10-27  11:33:29
