Genesis G80 User manual

Looking For more detailed information? This Quick Reference Guide does not replace your vehicle’s
Owner’s Manual. If you require additional information or are unsure of a specific issue, we
recommend that you always refer to the vehicle’s Owner’s Manual or contact your authorized
retailer of Genesis Branded Products. The information contained in this Quick Reference Guide is
correct at the time of printing; however, specifications and equipment can change without notice.
No warranty or guarantee is being extended in this Quick Reference Guide, and Genesis Brand
reserves the right to change product specifications and equipment at any time without incurring
obligations. Some vehicles are shown with optional equipment.
MAINTENANCE
Low tire pressure indicator /
TPMS malfunction indicator
Scheduled Maintenance Normal Usage Severe Usage*
Engine Oil And Filter* Replace 7,500 or 12 mos. Replace 3,750 or 6 mos.
Fuel Additives Add Every 7,500 or 12 mos.
Tire Rotation Perform 7,500 Perform 7,500
Air Cleaner Filter Inspect
Replace
7,500
30,000
Inspect
Replace
More Frequently
Same As Normal
Fuel Tank Air Filter Inspect 30,000 Inspect
Replace
Same As Normal
More Frequently
Vacuum Hose Inspect 7,500 Inspect Same As Normal
Fuel Lines, Fuel Hoses And Connections Inspect 30,000 Inspect Same As Normal
Vapor Hose & Fuel Filler Cap, Fuel tank Inspect 30,000 Inspect Same As Normal
Climate Control Air Filter
(For Evaporator And Blower Unit) Replace 15,000 Replace More Frequently
Air Conditioning Refrigerant Inspect 15,000 Inspect Same As Normal
Brake Hoses & Lines Inspect 15,000 Inspect Same As Normal
Drive Shafts & Boots Inspect 15,000 Inspect 7,500 or 6 mos.
Exhaust Pipe & Mufer Inspect 15,000 Inspect Same As Normal
Front Brake Disc/Pads, Calipers Inspect 15,000 Inspect More Frequently
Rear Brake Disc/Pads Inspect 15,000 Inspect More Frequently
Steering Gear Box, Linkage & Boots/
Lower Arm Ball Joint, Upper Arm Ball Joint Inspect 15,000 Inspect More Frequently
Suspension Mounting Bolts Inspect 15,000 Inspect Same As Normal
Propeller Shaft Inspect 15,000 Inspect 7,500 or 6 mos.
Brake Fluid Inspect 30,000 Inspect Same As Normal
Parking Brake Inspect 30,000 Inspect More Frequently
Front(AWD)/Rear Differential Oil Inspect 37,500 Replace 75,000
Fuel Filter Inspect 30,000 Inspect Same As Normal
Valve Clearance (3.8L) Inspect 60,000 Inspect Same As Normal
Drive Belt 1st Inspect 60,000 or 72 mos.
Add. Inspect 15,000 or 24 mos. Inspect Same As Normal
Spark Plugs (Iridium Coated) Replace 105,000 Replace More Frequently
Coolant 1st Replace 120,000 or 120 mos.
Add. Replace 30,000 or 24 mos. Replace Same As Normal
Automatic Transmission Fluid No, Check, No service required Replace 60,000
*Check the engine oil regularly between recommended oil change. We recommend Quaker State oil.
*See Owner’s Manual for details.
☐TIRE PRESSURE MONITORING SYSTEM (TPMS)- page 35
☐PARKING ASSIST SYSTEM (PAS) - page 33
• To activate wipers move the switch down
to one of the three positions
(AUTO, LO, HI)
• To adjust "AUTO" speed move switch
• To spray washer fluid pull lever toward you
• Push lever up for a single wiper pass
☐WINDSHIELD WIPER / WASHER - page 09
AUTO
LO
HI
MIST
OFF
NOTE: Tire pressure may vary in colder temperatures causing the
low tire pressure indicator to illuminate. Inflate tires according to
the Tire Pressure Label located on the driver’s side door pillar.
If the PAS is OFF, it will automatically turn ON when in Reverse.
PAS will automatically turn OFF when driving forward and
speed is over 6 mph.
☐HOW TO DEFROST
1
Press the front defrost button.
2
Set to warmest temperature setting.
3
Set to highest fan speed.
WALK THE CUSTOMER THROUGH EACH OF
THE FOLLOWING KEY DELIVERY FEATURES
☐
DEMONSTRATE AUTOMATIC CLIMATE CONTROL - page 18 – 19
☐DEMONSTRATE HOW TO SET THE CLOCK - page 29
NP150-G2017
(Rev 11/09/16)
Printing 12/29/16
☐GENESIS CONNECTED SERVICES – page 21-23
- Assist with creating a Genesis Owners account
- Show Genesis Connected Services Users Manual
- Encourage customers to press the Genesis Connected
Services button
Roadside Assistance: 1-844-340-9742
SiriusXM®Radio: 1-800-967-2346
Genesis Customer Care &
Connected Services:
GENESIS G80
Quick Reference Guide
1-844-340-9741
www.GenesisMotorsUSA.com

Steering
wheel
adjustment
Page06
Instrument
cluster
Page14-15
Navigation
Page26
Head lights
and fog
lights
Page08
Climate
control
Page18-19
Driver's
main
controls
Page07
Wiper and
washer
Page09
Transmission
Page36
Table of contents
Automatic Emergency Braking (AEB) 35
Auto Hold 34
AUX, USB and iPod port 27
Blind Spot Detection system (BSD) 38
Bluetooth operational tips 24
Bluetooth phone pairing 20
Child - protector rear door lock 12
Climate control 18-19
Climate control system seat & seat warmer 31
Clock adjustment 29
Cruise control/Advance smart cruise control 40
Driver Information System (DIS) 28
Drive mode integrated control system 39
Driver position memory system 05
Driver's main controls 07
Electronic Stability Control (ESC) 37
Electronic Parking Brake (EPB) 34
Engine start/stop button 05
Front seat adjustment 03
Fuel filler door 07
Genesis Connected Services 21-23
Headlights and fog lights 08
Headrest adjustment 04
Head up display 17
Heated steering wheel 32
HomeLink wireless garage control system 13
Instrument cluster 14-15
Interior lights 10
Lane Keeping Assist System (LKAS) 37
LCD display control/modes 16
Navigation 26
Panoramic Sunroof 10
Parking assist system (PAS) 33
Parking Guide system 33
Rearview camera 32
Rear window curtain 30
Seat belt adjustment 04
Smart key 02
Steering wheel adjustment 06
Steering wheel audio control 24
Tire Pressure Monitoring System (TPMS) 35
Transmission/paddle shifter 36
Trunk 11
Voice recognition tips 25
Wipers and washer 09
Engine start/
stop button
Page05
Cruise control/
Advanced smart
cruise control
Page40
AUX,USB
and iPod
Page27
Driver position
memory system
Page05
*Some vehicles may not be equipped
with all the listed features.
Use this Quick Reference Guide to learn
about the features that will enhance your
enjoyment of your Genesis Branded vehicle.
More detailed information about these
features are available in your Owner’s Manual.
FREQUENTLY ASKED QUESTIONS
•Pair phone to your vehicle. Refer to page 20.
WARNING!
To reduce the risk of serious injury to yourself and others,
read and understand the important SAFETY INFORMATION
in your Owner’s Manual.

GETTING STARTED
Quick Reference Guide I 03
02 I Quick Reference Guide
Driver’s door Lock / Unlock
Smart key must be within 28~40 in.
from the outside door handle.
Press: Once – Unlock driver door
Twice – Unlock all doors
Third – Lock all doors
Lock
Unlock
Trunk unlock
Panic
NOTE: The key hole is located under
the key hole cover
B
.
SMART KEY
A
B
Remove mechanical key.
Press and hold the release button
A
to remove the mechanical key.
GENESIS
FRONT SEAT ADJUSTMENT
2
Forward and backward
1
Seat cushion length (for driver’s seat)
2
Seatback angle
3
Seat cushion height
1
Lumbar support
4
Seat bolster adjustment (for driver’s seat)
5
1
34
5
A

GETTING STARTED
Quick Reference Guide I 05
04 I Quick Reference Guide
HEADREST ADJUSTMENT
To Raise Headrest:
Pull headrest up.
To Lower Headrest:
Press lock button while pressing
down on headrest.
To adjust headrest forward:
Pull forward to 1 of 3 positions.
To adjust backward:
Pull it fully forward to the farthest
position and release it.
To Raise Center Headrest:
Rotate headrest forward.
Lift headrest up.
To Lower Center Headrest:
Press lock button while pressing
down on headrest.
Press button to rotate headrest
down.
GENESIS
With the ignition OFF and foot
OFF of brake pedal, press the
engine start / stop button.
• Once for ACC(Accessory) mode.
• Twice for ON mode.
• Three times for OFF.
ENGINE START/STOP BUTTON
To start the engine in any mode(including OFF), press
the engine start/stop button while pressing the brake pedal.
To shut the engine OFF, place shift lever in P(Park) and press
the engine start/stop button again.
Emergency situations
Shut off engine while drving
Press and hold engine start/stop button for more than 2 seconds or press
3 times consecutively within 3 seconds.
Restart engine while driving
Press engine start/stop button with shift lever in N(Neutral).
Storing
1. Adjust the driver’s seat, outside
rearview mirrors, steering wheel,
instrument panel illumination and
head up display.
2. Press the SET button. The
system will beep once.
3. Press one of the memory buttons
(1 or 2) within 5 seconds.
The system will beep twice.
Recalling
Press the desired memory button
(1 or 2). The system will beep once.
DRIVER POSITION MEMORY SYSTEM
NOTE: Transmission must be in P(Park).
SEAT BELT ADJUSTMENT (Front seat)
Pull up to raise.
Press button and
push down to lower.
A
A
Rear center headrest
NOTE: For resetting, please see
Owner’s Manual for procedure.
