Gigabyte 8S651MP-RZ User manual

User'sManual
IntelPentium®4ProcessorMotherboard
Rev.1001
12ME-8S651MPRZ-1001
Copyright
©2003GIGABYTETECHNOLOGYCO., LTD
CopyrightbyGIGA-BYTETECHNOLOGYCO.,LTD.("GBT").Nopartofthismanualmaybereproduced ortransmitted inanyfrom
withoutthe expressed,written permission ofGBT.
Trademarks
Third-partybrandsand namesarethe propertyoftheirrespectiveowners.
Notice
Pleasedo notremoveanylabelson motherboard,thismayvoidthe warrantyofthismotherboard.
Due torapidchange intechnology,someofthe specificationsmightbe outofdatebeforepublication ofthisbooklet.
The authorassumesnoresponsibilityforanyerrorsoromissionsthatmayappearinthisdocumentnordoesthe authormakea
commitmenttoupdatetheinformationcontained herein.
8S651MP-RZ/
8S651MP-RZ-C

Mother Board
8S651MP-RZ
Jun. 25, 2004
Motherboard 8S651MP-RZ
Jun. 25 ,2004

Preparing YourComputer
Computermotherboardsand expansion cardscontainverydelicateIntegrated Circuit(IC)chips.To
protectthemagainstdamagefromstaticelectricity,youshouldfollowsomeprecautionswheneveryou
workon yourcomputer.
1.Unplug yourcomputerwhen working onthe inside.
2.Useagroundedwriststrap beforehandlingcomputercomponents.Ifyou do nothaveone,
touchbothofyourhandstoasafelygrounded objectortoametalobject, suchasthe power
supplycase.
3.Holdcomponentsbythe edgesand trynottouchthe ICchips,leadsorconnectors,orother
components.
4.Placecomponentson agrounded antistaticpad oron thebag thatcamewiththe components
wheneverthe componentsareseparated fromthe system.
5.EnsurethattheATXpowersupplyisswitched off beforeyou plug inorremovethe ATXpower
connectoronthemotherboard.
Installing themotherboardtothechassis
Ifthe motherboardhasmounting holes,buttheydon'tline upwiththe holeson the baseand there
areno slotstoattachthe spacers,do notbecomealarmed you can still attachthe spacerstothe
mounting holes.Justcutthe bottomportion ofthe spacers(the spacermaybe alittlehardtocutoff, so
be carefulofyourhands).Inthiswayyoucan stillattachthe motherboardtothe basewithoutworrying
aboutshortcircuits.Sometimesyoumayneed tousethe plasticspringstoisolatethe screwfromthe
motherboardPCBsurface,becausethe circuitwiremaybe nearbythe hole.Becareful,don'tletthe
screwcontactanyprinted circuitwriteorpartson the PCBthatarenearthe fixing hole,otherwiseit
maydamagethe boardorcauseboardmalfunctioning.

-4-
8S651MP-RZSeriesMotherboard
English
TableofContent
Chapter1Introduction ................................................................................................5
FeaturesSummary..............................................................................................................................5
8S651MP-RZSeriesMotherboardLayout .........................................................................................7
BlockDiagram.....................................................................................................................................8
HardwareInstallation Process ............................................................................................................9
Step 1:Install the CentralProcessing Unit(CPU).............................................................................9
Step 1-1:CPUInstallation .........................................................................................................10
Step 1-2:CPUCooling Fan Installation ....................................................................................10
Step2:Install memorymodules....................................................................................................... 11
Step 3:Install expansion cards.........................................................................................................12
Step 4:Install I/OPeripheralsCables..............................................................................................12
Step 4-1:I/OBack PanelIntroduction .......................................................................................12
Step 4-2:ConnectorsIntroduction ..............................................................................................13
Chapter2BIOSSetup .............................................................................................. 21
The MainMenu (Forexample:BIOSVer.:E4).............................................................................21
StandardCMOSFeatures................................................................................................................23
Advanced BIOSFeatures................................................................................................................25
Integrated Peripherals.......................................................................................................................26
PowerManagementSetup ................................................................................................................28
PnP/PCIConfigurations....................................................................................................................30
PCIHealthStatus.............................................................................................................................31
Frequency/VoltageControl................................................................................................................32
TopPerformance................................................................................................................................33
LoadFail-SafeDefaults......................................................................................................................33
LoadOptimizedDefaults....................................................................................................................34
SetSupervisor/UserPassword.......................................................................................................34
Save&ExitSetup ............................................................................................................................35
ExitWithoutSaving ...........................................................................................................................35
Chapter3DriverInstallation ...................................................................................... 36

Introduction-5-
English
Chapter1Introduction
Features Summary
Motherboard—8S651MP-RZSeries:
8S651MP-RZ/8S651MP-RZ-C
CPU—Socket478 forIntel®MicroFC-PGA2Pentium®4processor
—SupportIntel®Pentium®4(Northwood,0.13 m)processor
—IntelPentium®4400/533 MHzFSB
—2nd cache dependson CPU
Chipset—NorthBridge:SiS651
—SouthBridge:SiS962L
Memory—2184-pinDDR sockets
—SupportsDDR200/DDR266/DDR333
—Supportsup to2un-bufferDouble-sided DIMM DDR200/266/333
—Supportsup to2GB(Max)
—Supportsonly2.5VDDR DIMM
Slots—1UniversalAGPslot(4X)devicesupport
—3PCIslot
On-BoardIDE—2IDEbusmaster(UDMA33/ATA66/ATA100/ATA133)IDE
portsforup to4ATAPIdevices
—SupportsPIOmode3,4(UDMA33/ATA66/ATA100/ATA133)
IDE&ATAPICD-ROM
On-BoardFloppy—Floppyportsupports2FDD with360K,720K,1.2M,1.44Mand 2.88Mbytes
On-BoardPeripherals—1Parallelport
—1Serialport(COMA),1VGAport,COMBon board
—6xUSB 2.0/1.1(2xRear,4xFrontbycable)
—1FrontAudioConnector
—1IrDAconnectorforIR
—PS/2Keyboardinterfaceand PS/2Mouseinterface
On-BoardVGA—BuildinSiS651 Chipset
On-BoardLAN*—BuildinRTL8201 Chipset
On-BoardSound — RealtekALC655 CODEC
—Line Out/2frontspeaker
—Line In/2rearspeaker(bys/wswitch)
—MicIn/center&subwoofer(bys/wswitch)
—SPDIFOut/SPDIFIn
—CD_In/GamePort
BIOS—Licensed AwardBIOS
—SupportsQ-Flash
I/OControl—W83697HF
tobe continued......
“*”For8S651MP-RZonly.

-6-
8S651MP-RZSeriesMotherboard
English
Pleasesetthe CPUhostfrequency inaccordancewithyourprocessor'sspecifications.
Wedon'trecommend you tosetthe systembusfrequency overthe CPU'sspecification
becausethesespecificbusfrequenciesarenotthe standardspecificationsforCPU,
chipsetand mostofthe peripherals.Whetheryoursystemcan run underthesespecific
busfrequenciesproperlywill depend on yourhardwareconfigurations,including CPU,
Chipsets,Memory,Cards….etc.
HardwareMonitor—CPU/SystemFan Revolution detect
—CPU/SystemFan Control
—CPUOverheatWarning
—SystemVoltage Detect
AdditionalFeatures—SupportsEasyTune 4
—Supports@BIOS
FormFactor—24.4cmx21.5cmMicroATXsizeformfactor,4layersPCB.

Introduction-7-
English
8S651MP-RZSeries MotherboardLayout
“*”For8S651MP-RZonly.
“#”For8S651MP-RZ-C.
DIMM _LED
KB_MS
USB_LAN*
ATX_12V
CPU_FAN
PWR_LED
COMA
LPT
SOCKET478
ATX
VGA
8S651MP-RZ
FDD
CI
COMB
F_PANEL
BATSYS_FAN
PCI2
PCI3
F_USB1
W83697HF
BIOS
SiS962L
IR
CODEC
F_USB2
CLR_CMOS
F_AU DIO
CD_IN
GAME
LINE_IN
LINE_OUTMIC_IN
SiS651
IDE1
IDE2
AGP
PCI1
DDR2 DDR1
RTL8201*
SUR_CEN
SPDIF_IO
-C#
21.5cm
24.4 cm

-8-
8S651MP-RZSeriesMotherboard
English
Block Diagram
Pentium4
Socket478
CPU
SiS651
AC97
CODEC
SiS962L
CPUCLK+/-(100/133 MHz)
SystemBus
400/533 MHz
DDR
200/266/333MHz
ZCLK(66MHz)
HCLK+/-(100/133 MHz)
66 MHz
33 MHz
14.318 MHz
48 MHz
24 MHz
33 MHz
LPCBUS
AGP4X
AGPCLK
(66MHz)
3PCI
PCICLK
(33MHz)
AC97 Link
MIC
LINE-IN
LINE-OUT
6USB
Ports
ATA33/66/100/133
IDEChannels
Floppy
LPTPort
PS/2
KB/Mouse
COM
Ports
BIOS
W83697HF
GamePort
RTL8201 *
RJ45 *
VGAPort
CLKGEN
ZCLK(66MHz)
CPUCLK+/-(100/133 MHz)
AGPCLK(66MHz)
HCLK+/-(100/133 MHz)
PCICLK(33MHz)
USBCLK(48MHz)
14.318 MHz
33 MHz
“*”For8S651MP-RZonly.

-9-HardwareInstallation Process
English
Tosetup yourcomputer,you mustcompletethe following steps:
Step 1-Install the CentralProcessing Unit(CPU)
Step 2-Install memorymodules
Step 3-Install expansion cards
Step 4-Install I/OPeripheralscables
HardwareInstallation Process
Step2
Step4
Step4
Step1
Step4
Step3
Step1:Install theCentralProcessing Unit(CPU)
Beforeinstalling the processor,adheretothe following warning:
1.Pleasemakesurethe CPUtype issupported bythe motherboard.
2.The processorwill overheatwithoutthe heatsinkand/orfan,resulting inpermanent
irreparabledamage.
3. If you do notmatchthe CPUsocketPin1and CPUcutedge well,itwill causeimproper
installation.Pleasechange the insertorientation.
4.Applythermalgreasebetween the processorand cooling fan.
5.Neverrun the processorwithoutthe heatsinkproperlyand firmlyattached.Permanent
damage will result.
6.Pleasesetthe CPUhostfrequency inaccordancewithyourprocessor'sspecifications.
Wedon'trecomm end you tosetthe systembusfrequency overthe CPU'sspecification
becausethesespecificbusfrequenciesarenotthe standardspecificationsforCPU,
chipsetand mostofthe peripherals.Whetheryoursystemcan run underthesespecific
busfrequenciesproperlywill depend on yourhardwareconfigurations,including CPU,
Memory,Cards…etc.
HTfunctionalityrequirementcontent:
Enabling the functionalityofHyper-Threading Technologyforyourcomputersystem
requiresall ofthe following platformcomponents:
-CPU:AnIntel®Pentium4ProcessorwithHTTechnology
-Chipset: AnIntel®ChipsetthatsupportsHTTechnology
-BIOS:ABIOSthatsupportsHTTechnologyand hasitenabled
-OS:Anoperation systemthathasoptimizationsforHTTechnology

-10 -
8S651MP-RZSeriesMotherboard
English
Step1-1:CPUInstallation
Figure1.
Pull the rod tothe 90-degree directly.
Figure2.
LocatePin1inthe socketand lookfora(golden)cutedge on the
CPUuppercorner.Insertthe CPUintothe socket. (Donotforcethe
CPUintothe socket.)Then movethe socketlevertothe locked
position whileholding pressureon the centerofthe CPU.
Step1-2:CPUCooling FanInstallation
Figure1.
Applythe thermaltape(orgrease)toprovide betterheatconduction
between yourCPUand cooling fan.
Figure2.
Fasten the cooling fan supporting-baseontothe CPUsocketon the
motherboard.
Socket
Actuation
Lever
Figure3.
Makesurethe CPUfan isplugged tothe CPUfan connector,than
install complete.

-11 -HardwareInstallation Process
English
Step2:Install memorymodules
DDR
SupportUnbuffered DDR DIMM Sizestype:
64 Mbit(2Mx8x4banks)64 Mbit(1Mx16x4banks)128Mbit(4Mx8x4banks)
128Mbit(2Mx16x4banks)256Mbit(8Mx8x4banks)256Mbit(4Mx16x4banks)
512Mbit(16Mx8x4banks)512Mbit(8Mx16x4banks)
Notch
Beforeinstalling the memorymodules,adheretothe following warning:
1.When DIMM LEDisON,do notinstall /removeDIMM fromsocket.
2.Pleasenotethatthe DIMM modulecan onlyfitinone direction due tothe one notch.
Wrong orientation will causeimproperinstallation.Pleasechange the insertorientation.
The motherboardhas2dualinline memorymodule(DIM M)sockets.The BIOSwill automatically
detectsmemorytype and size.Toinstall the memorymodule,justpushitverticallyintothe DIMM
socket. The DIM M modulecan onlyfitinone direction due tothe notch.Memorysizecan varybetween
sockets.
1.The DIM M sockethasanotch,sothe DIM M
memorymodulecan onlyfitinone direction.
2. Insertthe DIMM memorymoduleverticallyinto
the DIM M socket. Then pushitdown.
3.Closethe plasticclipatbothedgesofthe DIMM
socketstolock the DIM M module.
Reversethe installation stepswhen you wishto
removethe DIM M module.

-12 -
8S651MP-RZSeriesMotherboard
English
Step3:Install expansion cards
1.Read the related expansion card'sinstruction documentbeforeinstall the expansion cardinto
the computer.
2.PleasemakesureyourAGPcardisAGP4X(1.5V).
3.Pleasecarefullypull outthe small white-drawablebaratthe end ofthe AGPslotwhen you tryto
install/Uninstall the AGPcard.Pleasealign the AGPcardtothe onboardAGPslotand press firmly
downon the slot.MakesureyourAGPcardislocked bythe small white-drawablebar.
AGPCard
Step4:Install I/OPeripheralsCables
Step4-1:I/OBack PanelIntroduction
u
v*
w
x
y z
{
|}~
uPS/2Keyboardand PS/2Mouse connector
ThisconnectorsupportsstandardPS/2keyboardand PS/2mouse.
vLAN port*
LANisfastEthernetwith10/100Mbpsspeed.
wUSBport
Beforeyou connectyourdevice(s)intoUSB connector(s),pleasemakesureyourdevice(s)such
asUSB keyboard,mouse,scanner,zip,speaker...etc.HaveastandardUSB interface.Alsomake
sureyourOSsupportsUSB controller.If yourOSdoesnotsupportUSB controller,pleasecontact
OSvendorforpossiblepatchordriverupgrade.Formoreinformation pleasecontactyourOSor
device(s)vendors.
xParallelport(LPT)
Devicelikeprintercan be connected toParallelport.
ySerialport(COMA)
Mouseand modemetc.can be connected toSerialport.
"*"For8S651MP-RZonly.

-13 -HardwareInstallation Process
English
zVGAport
Monitorcan be connected toVGAport.
{Game/MIDIport
Thisconnectorsupportsjoystick,MIDIkeyboardand otherrelateaudiodevices.
|LineOutjack
Connectthe stereo speakersorearphone tothisconnector.
}LineInjack
DeviceslikeCD-ROM,walkman etc.can be connecttoLine Injack.
~MICInjack
Microphone can be connecttoMICInjack.
Afterinstallation ofthe audiodriver,you areabletouse2/4/6-channelaudiofeaturebysoftware
selection.You can connect"Frontspeaker"to"Line Out"jack,Connect"Rearspeaker"to"Line In"
jack and connect"Center/Subwoofer"to"MICIn"jack.
Step4-2:ConnectorsIntroduction
1)ATX_12V11)F_AUDIO
2)ATX12)SUR_CEN
3)CPU_FAN 13)CD_IN
4)SYS_FAN 14)SPDIF_IO
5)IDE1/IDE2 15)IR
6)FDD 16)F_USB1/F_USB2
7)DIMM_LED17)COMB
8)F_PANEL18)CI
9)PWR_LED19)CLR_CMOS
10)BAT
31 7
15
9
10 817
16
14
4
6
5
18
13
11
19
12
2

-14 -
8S651MP-RZSeriesMotherboard
English
1)ATX_12V(+12VPowerConnector)
Thisconnector(ATX_12V)suppliesthe CPUoperation voltage (Vcore).
If this"ATX_12Vconnector"isnotconnected,systemcannotboot.
PinNo.Definition
1GND
2GND
3+12V
4+12V
2)ATX(ATXPower)
ACpowercordshouldonlybe connected toyourpowersupplyunitafterATXpowercableand other
related devicesarefirmlyconnected tothe mainboard.
1
1 0
2 0
1 1
PinNo.Definition
1 3.3V
2 3.3V
3GND
4VCC
5GND
6VCC
7GND
8PowerGood
95VSB (stand by+5V)
10 +12V
PinNo.Definition
11 3.3V
12 -12V
13 GND
14 PS_ON(soft on/off)
15 GND
16 GND
17 GND
18 -5V
19 VCC
20 VCC
3
1
4
2
3)CPU_FAN (CPUFAN Connector)
Pleasenote,aproperinstallation ofthe CPUcoolerisessentialtopreventthe CPUfromrunning
underabnormalcondition ordamaged byoverheating.The CPUfan connectorsupportsMax.
currentup to600 mA.
PinNo.Definition
1GND
2+12V
3Sense
1

-15 -HardwareInstallation Process
English
4)SYS_FAN (SystemFAN Connector)
Thisconnectorallowsyou tolinkwiththe cooling fan on the systemcasetolowerthe system
temperature.
PinNo.Definition
1GND
2+12V
3Sense
1
5)IDE1/IDE2(IDE1/IDE2Connector)
Pleaseconnectfirstharddisk toIDE1and connectCDROMtoIDE2.
The red stripe ofthe ribbon cablemustbe the sameside withthe Pin1.
IDE1IDE2
1
3 9
2
4 0
6)FDD (FloppyConnector)
Pleaseconnectthe floppydriveribbon cablestoFDD.It supports360K,720K,1.2M,1.44Mand
2.88Mbytesfloppydisk types.
The red stripe ofthe ribbon cablemustbe the sameside withthe Pin1.
1
3 4
2
3 3

-16 -
8S651MP-RZSeriesMotherboard
English
7)DIMM_LED
DonotremovememorymoduleswhileDIMM LEDison.It mightcauseshortorotherunexpected
damagesdue tothe 2.5Vstand byvoltage.Removememorymodulesonlywhen ACPowercord
isdisconnected.
+-
8)F_PANEL(2x10pinsconnector)
Pleaseconnectthe powerLED,PCpeaker,resetswitchand powerswitchetcofyourchassisfront
paneltothe F_PANELconnectoraccording tothe pinassignmentabove.
HD(IDEHardDisk ActiveLED)Pin1:LEDanode(+)
Pin2:LEDcathode(-)
SPK(SpeakerConnector) Pin1:VCC(+)
Pin2-Pin3:NC
Pin4:Data(-)
RST(ResetSwitch)Open:NormalOperation
Close:ResetHardwareSystem
PW(SoftPowerConnector) Open:NormalOperation
Close:PowerOn/Off
MPD(MessageLED/Power/Pin1:LEDanode(+)
SleepLED)Pin2:LEDcathode(-)
NC NC
SPK-
SPK+
20
Speaker
Connector
1
19
IDEHardDisk
ActiveLED
ResetSwitch
21
Soft Power
Connector
1
MPD+
MPD-
Message LED/Power/
Sleep LED
PW-
PW+
1
HD+
HD-
1
RST+
RST-
NC
1

-17 -HardwareInstallation Process
English
+
9)PWR_LED
PWR_LEDisconnectwiththe systempowerindicatortoindicatewhetherthe systemison/off. It will
blinkwhen the systementerssuspend mode.If you usedualcolorLED,powerLEDwill turnto
anothercolor.
1
PinNo.Definition
1MPD+
2MPD-
3MPD-
10)BAT(Battery)
CAUTION
Dangerofexplosion ifbatteryisincorrectly
replaced.
Replaceonlywiththe sameorequivalenttype
recommended bythe manufacturer.
Disposeofused batteriesaccording tothe
manufacturer'sinstructions.
If you wanttoeraseCMOS...
1.TurnOFF the computerand unplug the powercord.
2.Removethe battery,waitfor30 second.
3.Re-install the battery.
4.Plug the powercordand turnONthe computer.

-18 -
8S651MP-RZSeriesMotherboard
English
11)F_AUDIO(F_AUDIOConnector)
If you wanttouseFrontAudioconnector,you mustremove5-6,9-10 Jumper.Inordertoutilizethe
frontaudioheader,yourchassismusthavefrontaudioconnector.Alsopleasemakesurethe pin
assigmenton the cableisthe sameasthe pinassigmenton the MBheader.Tofind outifthe chassis
you arebuying supportfrontaudioconnector,pleasecontactyourdealer.Pleasenote,you can
havethe alternativeofusing frontaudioconnectororofusing rearaudioconnectortoplaysound.
PinNo.Definition
1MIC
2GND
3REF
4POWER
5FrontAudio(R)
6RearAudio(R)
7Reserved
8NoPin
9FrontAudio(L)
10 RearAudio(L)
1 09
1 2
12)SUR_CEN
PleasecontactyournearestdealerforoptionalSUR_CENcable.
PinNo.Definition
1SUROUTL
2SUROUTR
3GND
4NoPin
5CENTER_OUT
6BASS_OUT
1
5 6
2
13)CD_IN
ConnectCD-ROMorDVD-ROMaudioouttothe connector.
PinNo.Definition
1CD-L
2GND
3GND
4CD_R
1

-19 -HardwareInstallation Process
English
15)IR
Makesurethe pin1on the IRdeviceisaling withpinone the connector.Toenablethe IRfunction
on the board,you arerequired topurchasean option IRmodule.Becarefulwiththe polarityofthe
IRconnector.ForoptionalIRcable,pleasecontactyourlocaldealer.
PinNo.Definition
1VCC
2NoPin
3IRDataInput
4GND
5IRDataOutput
1
14)SPDIF_IO(SPDIFIn/Out)
The SPDIFoutputiscapableofproviding digitalaudiotoexternalspeakersorcompressed AC3
datatoan externalDolbyDigitalDecoder.Usethisfeatureonlywhen yourstereo systemhas
digitalinputfunction.UseSPDIFINfeatureonlywhen yourdevicehasdigitaloutputfunction.
Becarefulwiththe polarityofthe SPDIF_IOconnector.Check the pinassignmentcarefullywhile
you connectthe SPDIF_IOcable,incorrectconnection between the cableand connectorwill
makethe deviceunabletoworkoreven damage it. ForoptionalSPDIF_IOcable,pleasecontact
yourlocaldealer.
PinNo.Definition
1VCC
2NoPin
3SPDIF
4SPDIFI
5GND
6GND
1
6 2
5
16)F_USB1/F_USB2(FrontUSBConnector)
Becarefulwiththe polarityofthe F_USB connector.Check the pinassignmentcarefullywhileyou
connectthe F_USB cable,incorrectconnection between the cableand connectorwill makethe
deviceunabletoworkoreven damage it. ForoptionalF_USB cable,pleasecontactyourlocal
dealer.PinNo.Definition
1Power
2Power
3USBDX-
4USBDy-
5USBDX+
6USBDy+
7GND
8GND
9NoPin
10 NC
2 10
19

-20 -
8S651MP-RZSeriesMotherboard
English
17)COMB(COMBConnector)
Becarefulwiththe polarityofthe COMBconnector.Check the pinassignmentwhileyou connect
the COMBcable.PleasecontactyournearestdealerforoptionalCOMBcable.
PinNo.Definition
1NDCDB-
2NSINB
3NSOUTB
4NDTRB-
5GND
6NDSRB-
7NRTSB-
8NCTSB-
9NRIB-
10 NoPin
1 9
1 02
18)CI(CASE OPEN)
This2pinconnectorallowsyoursystemtoenableordisablethe "caseopen"iteminBIOSifthe
systemcasebeginremove.
PinNo.Definition
1Signal
2GND
1
19)CLR_CMOS(ClearCMOS)
You mayclearthe CMOSdatatoitsdefaultvaluesbythisjumper.ToclearCMOS,temporarily
shor1-2pin.Defaultdoesn'tinclude the "Shunter"topreventfromimproperusethisjumper.
1
1
Open:Normal
Close:ClearCMOS
