Gigabyte GA-8IGML-T User manual

Whenyou installing AGPcard,please make surethefollowing
notice isfullyunderstood and practiced.IfyourAGPcardhas
"AGP4Xnotch"(showbelow),please make sureyourAGPcardis
AGP4X(1.5V).
Donotuse AGP2Xcard(3.3V)inthismotherboard.Itwill
burnand damagethemotherboardduetoIntel®845(E/G)/850(E)
chipsetcan'tsupportAGP2X(3.3V).
Example1:Diamond VipperV770 golden fingeriscompatiblewith2X/
4Xmode AGPslot. It can be switched between AGP2X(3.3V)or
4X(1.5V)mode byadjusting the jumper.The factorydefaultforthiscard
is2X(3.3V).If you install thiscardinGA-8IGML-Tseries(oranyAGP
4Xonly)motherboardswithoutswitching the jumperto4Xmode (1.5V),
itwill burnthe motherboard.
Example2:SomeATiRage 128 Prographics cardsmade by“Power
Color”,the graphics cardmanufacturer&someSiS305 cards,their
golden fingeriscompatiblewith2X/4Xmode AGPslot, buttheysupport
2X(3.3V)only.If you install thiscardinGA-8IGML-Tseries(oranyAGP
4Xonly)motherboards,itwill burnthe motherboard.
Note:AlthoughGigabyte'sAG32S(G)graphicscardisbasedonATiRage
128 Prochip,the design ofAG32S(G)iscompliancewithAGP4X(1.5V)
specification.Therefore,AG32S(G)will workfine withIntel®845(E/G)/
850(E)based motherboards.

MTheauthorassumes no responsibilityforanyerrors
oromissionsthatmay appearinthisdocumentnor
does theauthormake acommitmenttoupdatethe
information containedherein.
MThird-partybrandsand names arethepropertyof
theirrespective owners.
MPlease do notremove anylabelson motherboard,this
may voidthewarrantyofthismotherboard.
MDuetorapidchangeintechnology,someofthe
specificationsmightbeoutofdatebeforepublication
ofthisbooklet.

DeclarationofConformity
We,Manufacturer/Importer
(full address)
G.B.T.TechnologyTräding GMbH
AusschlagerWeg41,1F,20537 Hamburg,Germany
declarethattheproduct
(descriptionofthe apparatus,system,installation towhichitrefers)
MotherBoard
GA-8IGML-T
isinconformitywith
(referencetothespecification underwhichconformityisdeclared)
inaccordancewith89/336EEC-EMCDirective
oEN55011 Limitsand methodsofmeasurement
ofradiodisturbancecharacteristics of
industrial,scientificand medical(ISM
high frequency equipment
oEN61000-3-2*
TEN60555-2Disturbancesinsupplysystemscause byhouseholdappliancesand similar
electricalequipment“Harmonics”
oEN55013 Limitsand methodsofmeasurement
ofradiodisturbancecharacteristics of
broadcastreceiversand associated
equipment
oEN61000-3-3*Disturbancesinsupplysystemscause
byhouseholdappliancesand similar
electricalequipment“Voltage fluctuations”
oEN55014 Limitsand methodsofmeasurement
ofradiodisturbancecharacteristics of
householdelectricalappliances,
portabletoolsand similarelectrical
apparatus
TEN50081-1Genericemission standardPart1:
Residualcommercialand lightindustry
TEN50082-1GenericimmunitystandardPart1:
Residualcommercialand lightindustry
oEN55015 Limitsand methodsofmeasurement
ofradiodisturbancecharacteristics of
fluorescentlampsand luminaries
Genericemission standardPart2:
Industrialenvironment
oEN55081-2
Immunityfromradiointerferenceof
broadcastreceiversand associated
equipment
Genericemission standardPart2:
Industrialenvironment
oEN55082-2
TEN55022 Limitsand methodsofmeasurement
ofradiodisturbancecharacteristics of
information technologyequipment
lmmunityrequirementsforhousehold
appliancestoolsand similarapparatus
oENV55104
Cabled distribution systems;Equipment
forreceiving and/ordistribution from
sound and television signals
EMCrequirementsforuninterruptible
powersystems(UPS)
oEN50091-2
oEN55020
oDINVDE0855
opart10
opart12
(ECconformitymarking)
TCEmarking
Themanufactureralsodeclares theconformityofabove mentionedproduct
withtheactualrequiredsafetystandardsinaccordance withLVD73/23 EEC
Safetyrequirementsformainsoperated
electronicand related apparatusfor
householdand similargeneraluse
oEN60950
oEN60065
Safetyofhouseholdand similar
electricalappliances
oEN60335
Manufacturer/Importer
Signature:
Name:
(Stamp)Date:May.17,2002
TEN60555-3
TimmyHuang
TimmyHuang
oEN50091-1

FCC Part15,SubpartB,Section 15.107(a)and Section 15.109
(a),Class BDigitalDevice
DECLARATIONOFCONFORMITY
PerFCC Part2Section 2.1077(a)
ResponsiblePartyName:
Address:
Phone/Fax No:
hereby declaresthattheproduct
ProductName:
Conformstothefollowing specifications:
Thisdevice complieswithpart15 oftheFCC Rules.Operation is
subjecttothefollowing twoconditions:(1)Thisdevice maynot
causeharmfuland(2)thisdevice mustacceptanyinference received,
including thatmaycauseundesiredoperation.
RepresentativePerson’sName:
Signature:EricLu
SupplementaryInformation:
ModelNumber:
17358 RailroadStreet
CityofIndustry,CA 91748
G.B.T.INC.(U.S.A.)
[phone]/[phone]
Motherboard
GA-8IGML-T
Date:
ERICLU
May17,2002

USER’SMANUAL
GA-8IGML-TSeries
P4Titan DDR Motherboard
Pentium®4ProcessorMotherboard
Rev.2001
12ME-8IGMLT-2001

-2-GA-8IGML-TseriesMotherboard
English
TableofContent
ItemChecklist......................................................................................... 4
WARNING!.............................................................................................. 4
Chapter1Introduction ............................................................................ 5
FeaturesSummary..................................................................................... 5
GA-8IGML-TSeriesMotherboardLayout .................................................. 7
Chapter2HardwareInstallation Process............................................... 8
Step 1:Install the CentralProcessing Unit(CPU)...................................... 9
CPUInstallation ................................................................................................................. 9
CPUHeatSinkInstallation.............................................................................................. 10
Step 2:Install memorymodules............................................................... 11
Step 3:Install expansion cards.................................................................13
Step 4:Connectribbon cables,cabinetwires,and powersupply...........14
Step4-1:I/OBack PanelIntroduction............................................................................. 14
Step4-2:ConnectorsIntroduction ................................................................................... 16
Chapter3BIOSSetup.......................................................................... 22
The MainMenu (Forexample:BIOSVer.:F1)........................................23
StandardCMOSFeatures........................................................................25
Advanced BIOSFeatures.........................................................................28
Integrated Peripherals..............................................................................30
PowerManagementSetup.......................................................................35
PnP/PCIConfigurations............................................................................37
PCHealthStatus.......................................................................................38
Frequency/Voltage Control.......................................................................39

Introduction
English
-3-
Top Performance......................................................................................41
Load Fail-SafeDefaults............................................................................42
Load Optimized Defaults..........................................................................43
SetSupervisor/UserPassword.................................................................44
Save&ExitSetup......................................................................................45
ExitWithoutSaving....................................................................................46
Block Diagram..........................................................................................47
Chapter4TechnicalReference............................................................ 47
Q-FlashIntroduction.................................................................................48
@BIOSIntroduction .................................................................................50
Easy TuneTM4Introduction ......................................................................51
Chapter5Appendix............................................................................. 52

-4-GA-8IGML-TseriesMotherboard
English
Computermotherboardsandexpansion cardscontainverydelicateIntegratedCircuit(IC)chips.To
protectthemagainstdamagefromstaticelectricity,youshouldfollowsomeprecautionswheneveryou
workon yourcomputer.
1.Unplugyourcomputerwhenworking ontheinside.
2.Useagroundedwriststrapbeforehandlingcomputercomponents.If youdonothave
one,touchbothofyourhandstoasafelygroundedobjectortoametalobject,suchas
thepowersupplycase.
3.HoldcomponentsbytheedgesandtrynottouchtheICchips,leadsorconnectors,or
othercomponents.
4.Placecomponentsonagroundedantistaticpadoronthebagthatcamewiththe
componentswheneverthecomponentsareseparatedfromthesystem.
5.EnsurethattheATXpowersupplyisswitchedoffbeforeyoupluginorremovetheATX
powerconnectoronthemotherboard.
Ifthemotherboardhasmountingholes,buttheydon’tlineupwiththeholesonthebaseandthereare
noslotstoattachthespacers,donotbecomealarmedyoucanstillattachthespacerstothemounting
holes.Justcutthebottomportionofthespacers(thespacermaybealittlehardtocutoff,sobecareful
ofyourhands).Inthiswayyoucanstillattachthemotherboardtothebasewithoutworryingaboutshort
circuits.Sometimesyoumayneedtousetheplasticspringstoisolatethescrewfromthemotherboard
PCBsurface,becausethecircuitwiremaybenearbythehole.Becareful,don’tletthescrewcontact
anyprintedcircuitwriteorpartsonthePCBthatarenearthefixinghole,otherwiseitmaydamagethe
boardorcauseboardmalfunctioning.
Installing themotherboardtothechassis…
WARNING!
þTheGA-8IGML-TorGA-8IGML-T-CmotherboardþGA-8IGML-Tseriesuser’smanual
þIDEcablex1/Floppycablex1þQuickPCInstallationGuide
þCDformotherboarddriver&utility
ItemChecklist

Introduction
English
-5-
FormFactor—24.4cmx21cmMicroATXsizeformfactor,4layersPCB.
Motherboard—GA-8IGML-TSeriesMotherboard:
—GA-8IGML-T/GA-8IGML-T-C
CPU—Socket478 forIntel®MicroFC-PGA2Pentium®4processor
—SupportIntel®Pentium®4(Northwood,0.13 m)processor
—IntelPentium®4533/400MHzFSB
—2ndcachedependsonCPU
Chipset—ChipsetIntel845GHOST/AGP/Controller
—ICH4I/OControllerHub
Memory—2184-pinDDR DIMM sockets
—SupportsPC2100 DDR orPC1600 DDR DIMM
—Supportsup to2GBDRAM(Max)
—Supportsonly2.5VDDR DIMM
I/OControl—ITE8702
Slots—1AGPslot4X(1.5V)devicesupportonly
—3PCIslotsupports33MHz&PCI2.2compliant
On-BoardIDE—2IDEbusmaster(DMA33/ATA66/ATA100)IDEportsforupto4
ATAPIdevices
—SupportsPIOmode3,4(UDMA33/ATA66/ATA100)IDE&ATAPI
CD-ROM
On-BoardPeripherals—1Floppyportsupports2FDDwith360K,720K,1.2M,1.44M
and 2.88Mbytes.
—1ParallelportsupportsNormal/EPP/ECPmode
—2Serialports(COMA&COMB),1VGAport
—6xUSB 2.0/1.1(2xRear,4xFrontbycable)
—1FrontAudioconnector
On-BoardVGA—BuildinIntel845GChipset
On-BoardUSB 2.0—BuildinICH4Chipset
Chapter1Introduction
tobecontinued......
Features Summary

-6-GA-8IGML-TseriesMotherboard
English
On-BoardLAN—BuilitinRTL8100BLChipset*
—1RJ45port*
On-BoardSound —RealtekALC650 CODEC
—1Buzzer
—LineOut/2frontspeaker
—Line In/2rearspeaker(bys/wswitch)
—MicIn/center&woofer(bys/wswitch)
—SPDIFout:bys/wswitch
—CD In/AUXIn/SPDIF/Gameport
PS/2Connector—PS/2KeyboardinterfaceandPS/2Mouseinterface
BIOS—LicensedAWARD BIOS,2MbitFWH
—SupportsQ-Flash
AdditionalFeatures—PS/2Keyboardpasswordpoweron
—PS/2Mousepoweron
—STR(Suspend-To-RAM)
—ACRecovery
—USB KB/Mousewakeup fromS3
—Polyfuseforkeyboard,USB,gameportover-currentprotection
—Supports@BIOS
—SupportsEasyTune4
Jumperless —OverClock (CPU/DDR/AGP)byBIOS
Overclocking
PleasesettheCPUhostfrequencyinaccordancewithyourprocessor’sspecifications.
Wedon’trecommendyoutosetthesystembusfrequency overtheCPU’sspecification
becausethesespecificbusfrequenciesarenotthestandardspecificationsforCPU,
chipsetandmostoftheperipherals.Whetheryoursystemcanrununderthesespecific
busfrequenciesproperlywilldepend on yourhardwareconfigurations,includingCPU,
Chipsets,SDRAM,Cards….etc.
“*”NotsupportforGA-8IGML-T-C

Introduction
English
-7-
GA-8IGML-TSeries MotherboardLayout
“*”NotsupportforGA-8IGML-T-C
GA-8IGML-T
KB_MS
COMA
IR
LPT
GAME
LINE_IN
LINE_OUT
MIC_IN
ATX_12V
CD_IN
F_AUDIO
F_PANEL
BATTERY
SYS_FAN
ICH4
SOCKET478
CPU_FAN
ATX
FDD
IDE1
IDE2
ITE8702
PCI1
PCI2
PCI3
DDR2
DDR1
CODEC
F_USB1
CLR_CMOS
VGA
BIOS
SPDIFCOMB
AUX_IN
RTL
8100BL*
CI
AGP
PWR_LED
845G
USB /LAN*
SUR_CEN
F_USB2
BIOS_WP
BZ
(-C)

-8-GA-8IGML-TseriesMotherboard
English
Tosetupyourcomputer,youmustcompletethefollowingsteps:
Step1-InstalltheCentralProcessingUnit(CPU)
Step2-Installmemorymodules
Step3-Installexpansioncards
Step4-Connectribboncables,cabinetwires,andpowersupply
Step5-SetupBIOSsoftware
Step6-Installsupportingsoftwaretools
Chapter2HardwareInstallation Process
Step2
Step4
Step3
Step4
Step4
Step1
Step4

-9-HardwareInstallation Process
English
Step1:Install theCentralProcessing Unit(CPU)
CPUInstallation
Pin1indicatorPin1indicator
CPUTop View CPUBottomView
SocketActuation Lever
1.Pullup the CPUsocketlever
andupto90-degreeangle.
Pin1indicator
2.LocatePin1inthesocketandlook
fora(golden)cutedge ontheCPU
uppercorner.TheninserttheCPU
intothesocket.
3.Press downthe CPUsocket
leverandfinishCPUinstallation.
MPlease make suretheCPUtypeissupportedbythemotherboard.
MIfyou do notmatchtheCPUsocketPin1and CPUcutedgewell, itwill cause
improperinstallation.Please changetheinsertorientation.

-10 -GA-8IGML-TseriesMotherboard
English
CPUHeatSinkInstallation
1.Hookoneendofthecooler
brackettotheCPUsocketfirst. 2.Hooktheotherendofthe
coolerbrackettotheCPU
socket.
MPlease use Intelapprovedcooling fan.
MWerecommend you toapplythethermaltapetoprovidebetterheat
conduction betweenyourCPUand heatsink.
(TheCPUcooling fanmightstick totheCPUduetothehardening ofthe
thermalpaste.During thiscondition ifyou trytoremove thecooling fan,you
mightpull theprocessoroutoftheCPUsocketalonewiththecooling fan,and
mightdamagetheprocessor.To avoidthisfromhappening,wesuggestyou to
eitheruse thermaltapeinsteadofthermalpaste,orremove thecooling fanwith
extremecaution.)
MMake suretheCPUfanpowercableispluggedintotheCPUfanconnector,
thiscompletes theinstallation.
MPlease refertoCPUheatsinkuser’smanualformoredetail installation
procedure.

-11 -HardwareInstallation Process
English
Step2:Install memorymodules
D:DoubleSided DIMM S:SingleSided DIMM
X:NotUse
The motherboardhas2dualinline memorymodule(DIMM)sockets.The BIOSwill automatically
detectsmemorytypeandsize.Toinstallthememorymodule,justpushitverticallyintotheDIMMSlot
.The DIMM modulecan onlyfitinone direction due tothe notch.Memorysizecan varybetween
sockets.
TotalMemorySizesWithUnbufferedDDRDIMM
Devicesused on DIMM 1DIMM x64 /x72 2 DIMMsx64 /x72
64 Mbit(2Mx8x4banks)128 MBytes256 MBytes
64 Mbit(1Mx16x4banks)32 MBytes64 MBytes
128 Mbit(4Mx8x4banks)256 MBytes512 MBytes
128 Mbit(2Mx16x4banks)64 MBytes128 MBytes
256 Mbit(8Mx8x4banks)512 MBytes1GBytes
256 Mbit(4Mx16x4banks)128 MBytes256 MBytes
512 Mbit(16Mx8x4banks)1GBytes2GBytes
512 Mbit(8Mx16x4banks)256 MBytes512 MBytes
Notes:Double-sided x16 DDR memorydevicesarenotsupportbyIntel845E/Gchipset.
DDR1DDR2
S S
DS
D D
DX
SD
S X

-12 -GA-8IGML-TseriesMotherboard
English
MPlease notethattheDIMM modulecanonlyfitinonedirection dueto
thetwonotches.Wrong orientation will cause improperinstallation.
Please changetheinsertorientation.
DDR
1.TheDIMMslothasanotch,sothe
DIMMmemorymodulecanonlyfitinonedirection.
2. InserttheDIMMmemorymoduleverticallyintothe
DIMMslot.Then pushitdown.
3.ClosetheplasticclipatbothedgesoftheDIMMslots
tolocktheDIMM module.
Reversetheinstallationstepswhenyouwishto
removetheDIMM module.
EstablishedontheexistingSDRAMindustryinfrastructure,DDR(DoubleDataRate)memoryisa
highperformanceandcost-effectivesolutionthatallowseasyadoptionformemoryvendors,OEMsand
systemintegrators.
DDR memoryisasensibleevolutionarysolution forthe PCindustrythatbuildson the existing
SDRAMinfrastructure,yetmakesawesomeadvancesinsolvingthesystemperformancebottleneckby
doublingthe memorybandwidth.DDRSDRAMwillofferasuperiorsolutionandmigration pathfrom
existing SDRAMdesignsdue toitsavailability,pricing and overall marketsupport. PC2100 DDR
memory(DDR266)doublesthedataratethroughreadingandwritingatboththerisingandfallingedgeof
theclock,achievingdatabandwidth2XgreaterthanPC133whenrunningwiththesameDRAMclock
frequency.Withpeakbandwidthof2.1GBpersecond,DDRmemoryenablessystemOEMstobuild
highperformanceandlowlatencyDRAMsubsystemsthataresuitableforservers,workstations,high-
end PC'sand value desktop SMAsystems.Withacorevoltage ofonly2.5Voltscompared to
conventionalSDRAM's3.3volts,DDRmemoryisacompellingsolutionforsmall formfactordesktops
andnotebookapplications.
DDR Introduction

-13 -HardwareInstallation Process
English
Step3:Install expansion cards
1.Readtherelatedexpansioncard’sinstructiondocumentbeforeinstalltheexpansioncardinto
thecomputer.
2.Removeyourcomputer’schassiscover,screwsandslotbracketfromthecomputer.
3.Presstheexpansioncardfirmlyintoexpansionslotinmotherboard.
4.Besurethemetalcontactsonthecardareindeedseatedintheslot.
5.Replacethescrewtosecuretheslotbracketoftheexpansioncard.
6.Replaceyourcomputer’schassiscover.
7.Poweronthe computer,ifnecessary,setupBIOSutilityofexpansion cardfromBIOS.
8. Installrelateddriverfromtheoperatingsystem.
AGPCard
Pleasecarefullypulloutthesmall white-
drawablebarattheendoftheAGPslotwhen
youtrytoinstall/Uninstall theAGPcard.
PleasealigntheAGPcardtotheonboard
AGPslotandpress firmlydownon theslot.
MakesureyourAGPcardislocked bythe
smallwhite-drawablebar.

-14 -GA-8IGML-TseriesMotherboard
English
Step4:Connectribbon cables,cabinetwires,and power
supply
Step4-1:I/O Back PanelIntroduction
uPS/2Keyboardand PS/2Mouse Connector
PS/2MouseConnector
(6pinFemale)
PS/2KeyboardConnector
(6pinFemale)
ØThisconnectorsupportsstandardPS/2
keyboardand PS/2mouse.
vUSB/LAN ConnectorØBeforeyouconnectyourdevice(s)intoUSB
connector(s),pleasemakesureyourdevice(s)
suchasUSB keyboard,mouse,scanner,zip,
speaker..etc.HaveastandardUSBinterface.
AlsomakesureyourOS(Win95 withUSB
supplement,Win98,Windows2000,Windows
ME,WinNTwithSP6)supportsUSBcontroller.
IfyourOSdoesnotsupportUSBcontroller,
pleasecontactOSvendorforpossiblepatchor
driverupgrade.Formoreinformationplease
contactyourOSordevice(s)vendors.
wx
v
u
y
USB 1
USB 0
LAN*
“*”NotsupportforGA-8IGML-T-C

-15 -HardwareInstallation Process
English
xGame/MIDIPorts
Joystick/MIDI(15 pinFemale)
yAudioConnectors
ØThisconnectorsupportsjoystick,MIDIkeyboard
andotherrelateaudiodevices.
ØAfterinstallonboardaudiodriver,youmay
connectspeakertoLineOutjack,microphoneto
MICInjack.DevicelikeCD-ROM,walkman
etccanbe connectedtoLine-Injack.
wParallelPortand VGAPort/COMAPort
ParallelPort
(25pinFemale)
SerialPort
(9pinMale)
LineIn
MICIn
LineOut
ØThismainboardsutports1standardCOMport,
1VGAportand1LPTport. Devicelikeprinter
canbeconnectedtoLPTport;mouseand
modemetccanbeconnectedtoCOMport.
VGAPort
(15pinFemale)

-16 -GA-8IGML-TseriesMotherboard
English
Step4-2:ConnectorsIntroduction
A)CPU_FAN K)F_USB1
B)ATXL)COMB
C)FDD/IDE1/IDE2M)SPDIF
D)SYS_FAN N)CD_IN
E)CLR_CMOSO)AUX_IN
F)BATTERY P)CI
G)F_PANELQ)IR
H)PWR_LED R)F_AUDIO
I)F_USB2S)SUR_CEN
J)BIOS_WPT)ATX_12V
D
E
A B
LM
C
KGHI
F
J
N
O
P
C
Q
R
S
T
