MS33-AR0
4th Gen. Intel® Xeon® Scalable UP Motherboard
User Manual
Rev. 1.0

Copyright
© 2023 Giga Computing TECHNOLOGY CO., LTD. All rights reserved.
The trademarks mentioned in this manual are legally registered to their respective owners.
Disclaimer
Information in this manual is protected by copyright laws and is the property of Giga Computing
Changes to the specications and features in this manual may be made by Giga Computing
without prior notice. No part of this manual may be reproduced, copied, translated, transmitted, or
published in any form or by any means without Giga Computing's prior written permission.
Documentation Classications
In order to assist in the use of this product, Giga Computing provides the following types of documen-
tation:
 User Manual: detailed information & steps about the installation, conguration and use this
product (e.g. motherboard, server barebones), covering hardware and BIOS.

User Guide: detailed information about the installation & use of an add-on hardware or
software component (e.g. BMC rmware, rail-kit) compatible with this product.
Quick Installation Guide: a short guide with visual diagrams that you can reference easily for
installation purposes of this product (e.g. motherboard, server barebones).
Please see the support section of the online product page to check the current availability of these
documents
For More Information
For related product specications, the latest rmware and software, and other information, please visit
our website at: http://www.gigabyte.com/Enterprise.
For GIGABYTE distributors and resellers, additional sales & marketing materials are available from our
reseller portal: http://reseller.b2b.gigabyte.com
For further technical assistance, please contact your GIGABYTE representative or visit
http://esupport.gigabyte.com/ to create a new support ticket.
For any general sales or marketing enquires, you may message GIGABYTE server directly by
email: server[email protected].

- 3 -
Table of Contents
MS33-AR0 Motherboard Layout......................................................................................5
Block Diagram .................................................................................................................7
Chapter 1 Hardware Installation .....................................................................................8
1-1 Installation Precautions.................................................................................... 8
1-2 ProductSpecications...................................................................................... 9
1-3 Installing and Removing the CPU .................................................................. 12
1-4 Installing and Removing Memory................................................................... 14
1-4-1 Eight-ChannelMemoryConguration ...................................................................14
1-4-2 Installing and Removing a Memory Module ..........................................................15
1-4-3 DIMM Population Table .........................................................................................15
1-4-4 Processor and Memory Module Matrix Table .........................................................16
1-4-5 DDR5 DIMM with Intel OptaneTM PMem 300 Series Memory Population..............16
1-4-6 Intel OptaneTMPMem300SeriesMatrixConguration ........................................16
1-5 Installing the M.2 SSD Module....................................................................... 17
1-6 Back Panel Connectors.................................................................................. 18
1-7 Internal Connectors........................................................................................ 19
1-8 Jumper Settings ............................................................................................. 28
Chapter 2 BIOS Setup ..................................................................................................29
2-1 The Main Menu .............................................................................................. 31
2-2 Advanced Menu ............................................................................................. 34
2-2-1 Trusted Computing .................................................................................................35
2-2-2 Serial Port Console Redirection .............................................................................36
2-2-3 SIOConguration...................................................................................................39
2-2-4 PCI Subsystem Settings.........................................................................................40
2-2-5 USBConguration..................................................................................................42
2-2-6 NetworkStackConguration..................................................................................43
2-2-7 PostReportConguration ......................................................................................44
2-2-8 NVMeConguration ...............................................................................................45
2-2-9 ChipsetConguration.............................................................................................46
2-2-10 TlsAuthConguration ............................................................................................47
2-2-11 iSCSIConguration................................................................................................48
2-2-12 Intel(R) Ethernet Controller X710 for 10GBASE-T .................................................49
2-2-13 VLANConguration................................................................................................51
2-2-14 Driver Health...........................................................................................................52
2-3 Chipset Menu................................................................................................. 53
2-3-1 ProcessorConguration.........................................................................................54

- 4 -
2-3-2 CommonRefCodeConguration ...........................................................................57
2-3-3 UPIConguration ...................................................................................................58
2-3-4 MemoryConguration ............................................................................................60
2-3-5 IIOConguration ....................................................................................................63
2-3-6 AdvancedPowerManagementConguration........................................................65
2-3-7 PCHConguration..................................................................................................67
2-3-8 MiscellaneousConguration ..................................................................................69
2-3-9 ServerMEConguration ........................................................................................70
2-3-10 Runtime Error Logging Settings .............................................................................71
2-3-11 Power Policy...........................................................................................................73
2-4 Server Management Menu............................................................................. 75
2-4-1 System Event Log ..................................................................................................77
2-4-2 View FRU Information ............................................................................................78
2-4-3 BMCVLANConguration.......................................................................................79
2-4-4 BMCNetworkConguration...................................................................................80
2-4-5 IPv6BMCNetworkConguration...........................................................................81
2-5 Security Menu ................................................................................................ 82
2-5-1 Secure Boot ...........................................................................................................83
2-6 Boot Menu...................................................................................................... 86
2-7 Save & Exit Menu........................................................................................... 88
2-8 BIOS Recovery .............................................................................................. 90
2-9 BIOS POST Beep code (AMI standard)......................................................... 91
2-9-1 PEI Beep Codes.....................................................................................................91
2-9-2 DXE Beep Codes ...................................................................................................91

- 5 -
MS33-AR0 Motherboard Layout
CPU0
DIMM_P0_H0 DIMM_P0_E0 DIMM_P0_F1 DIMM_P0_F0 DIMM_P0_G1 DIMM_P0_G0 DIMM_P0_H1 DIMM_P0_E1
DIMM_P0_A1 DIMM_P0_D1 DIMM_P0_C0 DIMM_P0_C1 DIMM_P0_B0 DIMM_P0_B1 DIMM_P0_A0 DIMM_P0_D0
1
41
3 4 5 62 7
8
9
10
14
11 15
16
18
17
19
20
21
23
22
2425
26
27
28
29
32
31
30
33
34
35 36 37 38 39 40
12
13

- 6 -
Item Code Description
1 LED_BMC BMC Firmware Readiness LED
2 SPI_TPM TPM Connector
3 SW_ID ID Button with LED
4 USB3_MLAN Server Management LAN Port (Top)/USB 3.0 Ports (Bottom)
5 LAN1 10GbE LAN Port #1
6 LAN2 10GbE LAN Port #2
7 COM1_VGA Serial Port (Top)/VGA Port (Bottom)
8 SYS_FAN5 System Fan Connector #5
9 SYS_FAN4 System Fan Connector #4
10 PMBUS PMBus Connector
11 SSATA_SGP1 SATA SGPIO Connector
12 CASE_OPEN Case Open Intrusion Alert Header
13 SL_SATA2 Slimline Connector #2 (SATA 6Gb/s Signal)
14 SL_SATA1 Slimline Connector #1 (SATA 6Gb/s Signal)
15 SSATA2 SATA 6Gb/s Connector #2
16 SSATA0 SATA 6Gb/s Connector #0
17 ATX1 2x12 Pin Main Power Connector
18 P12V_PCIE 2x3 Pin 12V Power Connector
19 BAT Battery Socket
20 CPU0_FAN2 CPU Fan Connector #2
21 CPU0_FAN1 CPU Fan Connector #1
22 P12V_AUX2 2x4 Pin 12V Power Connector
23 P12V_AUX1 2x4 Pin 12V Power Connector
24 MCIOP0_4BA MCIO Connector (PCIe Gen5)
25 MCIOP0_4DC MCIO Connector (PCIe Gen5)
26 F_USB3 Front Panel USB 3.2 Gen1 Connector
27 FP_1 Front Panel Header
28 BP_1 HDD Backplane Board Connector
29 M2_0 M.2 Slot (PCIe Gen3 x4, Support NGFF-2280/22110)
30 SYS_FAN3 System Fan Connector #3
31 SYS_FAN2 System Fan Connector #2
32 SYS_FAN1 System Fan Connector #1
33 IPMB1 IPMB Connector
34 CN_NCSI NCSI Connector
35 PCIE_1 PCIe x16 Slot #1 (Gen5 x8)
36 PCIE_2 PCIe x16 Slot #2 (Gen5 x16)
37 PCIE_3 PCIe x16 Slot #3 (Gen5 x8)
38 PCIE_4 PCIe x16 Slot #4 (Gen5 x16)
39 PCIE_5 PCIe x16 Slot #5 (Gen5 x8)
40 PCIE_6 PCIe x16 Slot #6 (Gen5 x16)
41 PCIE_7 PCIe x16 Slot #7 (Gen5 x16)

- 7 -
Block Diagram

- 8 -
Hardware Installation
1-1 Installation Precautions
The motherboard contains numerous delicate electronic circuits and components which can
become damaged as a result of electrostatic discharge (ESD). Prior to installation, carefully read
the user's manual and follow these procedures:
• Prior to installation, do not remove or break motherboard S/N (Serial Number) sticker or
warranty sticker provided by your dealer. These stickers are required for warranty validation.
• Always remove the AC power by unplugging the power cord from the power outlet before
installing or removing the motherboard or other hardware components.
• When connecting hardware components to the internal connectors on the motherboard,
make sure they are connected tightly and securely.
• When handling the motherboard, avoid touching any metal leads or connectors.
• It is best to wear an electrostatic discharge (ESD) wrist strap when handling electronic
components such as a motherboard, CPU or memory. If you do not have an ESD wrist
strap,keepyourhandsdryandrsttouchametalobjecttoeliminatestaticelectricity.
• Prior to installing the motherboard, please have it on top of an antistatic pad or within an
electrostatic shielding container.
• Before unplugging the power supply cable from the motherboard, make sure the power
supply has been turned off.
• Before turning on the power, make sure the power supply voltage has been set according to
the local voltage standard.
• Before using the product, please verify that all cables and power connectors of your
hardware components are connected.
• To prevent damage to the motherboard, do not allow screws to come in contact with the
motherboard circuit or its components.
• Make sure there are no leftover screws or metal components placed on the motherboard or
within the computer casing.
• Do not place the computer system on an uneven surface .
• Do not place the computer system in a high-temperature environment.
• Turning on the computer power during the installation process can lead to damage to
system components as well as physical harm to the user.
• If you are uncertain about any installation steps or have a problem related to the use of the
product,pleaseconsultacertiedcomputertechnician.
• To avoid any potential short circuit of the DIMM slots, please remove any stand-offs from the
chassis that will be located underneath the DIMM slots, before installing the motherboard
into the chassis.
Chapter 1 Hardware Installation

- 9 -
Hardware Installation
1-2 Product Specications
Socket
Socket
Security
Security Server Operating Properties
Power Supply
Form Factor E-ATX
304.8W x 330.2D (mm)
Socket
Socket
Security
Security Server Operating Properties
Power Supply
CPU 4th Generation Intel® Xeon® Scalable Processors
Intel® Xeon® Platinum Processor, Intel® Xeon® Gold Processor,
Intel® Xeon® Silver Processor
CPU TDP up to 350W
1 x LGA4677; Socket E
Socket
Socket
Security
Security Server Operating Properties
Power Supply
Chipset Intel®C741 Chipset
Socket
Socket
Security
Security Server Operating Properties
Power Supply
Memory 16 x DIMM slots
DDR5 memory supported only
8-Channel memory architecture
RDIMM modules up to 128GB supported
3DS RDIMM modules up to 256GB supported
Memory speed: Up to 4800 MHz (1DPC), 4400MHz (2DPC)
Socket
Socket
Security
Security Server Operating Properties
Power Supply
LAN 2 x 10Gb/s BASE-T LAN ports (Intel® X710-AT2)
NCSI function supported
1 x 10/100/1000 management LAN
Socket
Socket
Security
Security Server Operating Properties
Power Supply
Onboard
Graphics
Integrated in Aspeed® AST2600
2D Video Graphic Adapter with PCIe bus interface
1920x1200@60Hz 32bpp, DDR4 SDRAM
Socket
Socket
Security
Security
Storage Interface 2 x SlimSAS with 8 x SATA 6Gb/s ports
2 x 7-pin SATA 6Gb/s ports
Socket
Socket
Security
Security
RAID Intel® SATA RAID 0/1/10/5
Socket
Socket
Security
Security
Expansion Slots Slot_7: 1 x PCIe x16 (Gen5 x16 bus) slot, from CPU_0
Slot_6: 1 x PCIe x16 (Gen5 x16 or x8 bus) slot, from CPU_0, shared with Slot_5
Slot_5: 1 x PCIe x16 (Gen5 x8 bus) slot, from CPU_0
Slot_4: 1 x PCIe x16 (Gen5 x16 or x8 bus) slot, from CPU_0, shared with Slot_3
Slot_3: 1 x PCIe x16 (Gen5 x8 bus) slot, from CPU_0
Slot_2: 1 x PCIe x16 (Gen5 x16 or x8 bus) slot, from CPU_0, shared with Slot_1
Slot_1: 1 x PCIe x16 (Gen5 x8 bus) slot, from CPU_0
1 x M.2 slot:
- M-key
- PCIe Gen3 x4 per slot
- Supports 2280/22110 cards
- From PCH (C741)
NOTE:
We reserve the right to make any changes to the product specications and product-related
information without prior notice.

- 10 -
Hardware Installation
Socket
Socket
Security
Security
Internal I/O
Connectors
1 x 24-pin ATX main power connector
2 x 8-pin ATX 12V power connectors
1 x 6-pin ATX 12V power connectors
2 x MCIO 8i connectors ( For system integration only)
1 x M.2 slot
2 x CPU fan headers
5 x System fan headers
1 x USB 3.2 Gen1 header
1 x TPM header
1 x Front panel header
1 x HDD back plane board header
1 x PMBus connector
1 x IPMB connector
1xClearCMOSjumper
1xBIOSrecoveryjumper
1 x Buzzer
Socket
Socket
Security
Security
Rear I/O
Connectors
2 x USB 3.2 Gen1
1 x VGA
1 x COM
2 x RJ45
1 x MLAN
1 x ID button with LED
Socket
Socket
Security
Security
TPM 1 x TPM Header with SPI Interface
Optional TPM2.0 kit: CTM010
Socket
Socket
Security
Security
Board
Management
Aspeed® AST2600 management controller
GIGABYTE Management Console (AMI MegaRAC SP-X) web interface
Dashboard
HTML5 KVM
Sensor Monitor (Voltage, RPM, Temperature, CPU Status …etc.)
Sensor Reading History Data
FRU Information
SEL Log in Linear Storage / Circular Storage Policy
Hardware Inventory
FanProle
System Firewall
Power Consumption
Power Control
LDAP / AD / RADIUS Support
Backup&RestoreConguration
Remote BIOS/BMC/CPLD Update
Event Log Filter
User Management
Media Redirection Settings
Socket
Socket
Security
Security

- 11 -
Hardware Installation
Socket
Socket
Security
Security
Board
Management
(continued)
PAM Order Settings
SSL Settings
SMTP Settings
Socket
Socket
Security
Security
Operating
Properties Operating temperature: 10°C to 40°C
Operating humidity: 8-80% (non-condensing)
Non-operating temperature: -40°C to 60°C
Non-operating humidity: 20%-95% (non-condensing)

- 12 -
Hardware Installation
1-3 Installing and Removing the CPU
Read the following guidelines before you begin to install the CPU:
• Make sure that the motherboard supports the CPU.
• Always turn off the computer and unplug the power cord from the power outlet before installing
the CPU to prevent hardware damage.
• Unplug all cables from the power outlets.
• Disconnect all telecommunication cables from their ports.
• Placethesystemunitonaatandstablesurface.
• Open the system according to the instructions.
WARNING!
Failure to properly turn off the server before you start installing components may cause serious
damage. Do not attempt the procedures described in the following sections unless you are a
qualiedservicetechnician.
Follow these instructions to Install the CPU:
1. Align and install the processor on the carrier.
NOTE: Apply thermal compound evenly on the top of the CPU. Remove the protective cover from
the underside of the heat sink.
2. Carefullyiptheheatsinkcover.Theninstallthecarrierassemblyonthebottomoftheheatsink
and make sure the gold arrow is located in the correct direction.
3. Remove the CPU cover.
NOTE: Save the CPU cover in the event that you need to remove the CPU from the socket.
4. Align the heat sink with the CPU socket by the guide pins and make sure the gold arrow is located
in the correct direction. Then place the heat sink onto the top of the CPU socket.
5. Position the rotating wires into the latch position. Tighten the screws in a sequential order
(1g2g3g4).
NOTE: When dissembling the heat sink, loosen the screws in reverse order (4g3g2g1) and
then move the rotating wires into the unlatch position.
Pin1 1
2

- 13 -
Hardware Installation
3
4
5
1
2
3
4
Note!
• The illustrations of the heat-sink installation shown are for reference only..

- 14 -
Hardware Installation
1-4 Installing and Removing Memory
Read the following guidelines before you begin to install the memory:
•Make sure that the motherboard supports the memory. It is recommended to use memory of the
same capacity, brand, speed, and chips.
•Always turn off the computer and unplug the power cord from the power outlet before installing
the memory to prevent hardware damage.
•Memory modules have a foolproof design. A memory module can be installed in only one
direction. If you are unable to insert the memory, switch the direction.
1-4-1 Eight-Channel Memory Conguration
This motherboard provides 16 DDR5 memory slots and supports Eight-Channel Technology. After the
memoryisinstalled,theBIOSwillautomaticallydetectthespecicationsandcapacityofthememory.
CPU0
DIMM_P0_H0 DIMM_P0_E0 DIMM_P0_F1 DIMM_P0_F0 DIMM_P0_G1 DIMM_P0_G0 DIMM_P0_H1 DIMM_P0_E1
DIMM_P0_A1 DIMM_P0_D1 DIMM_P0_C0 DIMM_P0_C1 DIMM_P0_B0 DIMM_P0_B1 DIMM_P0_A0 DIMM_P0_D0

- 15 -
Hardware Installation
1-4-2 Installing and Removing a Memory Module
Before installing a memory module, make sure to turn off the computer and unplug the
power cord from the power outlet to prevent damage to the memory module.
Be sure to install DDR5 DIMMs on this motherboard.
1
2
2
Follow these instructions to install a DIMM module:
1. Insert the DIMM memory module vertically into the DIMM slot and push it down.
2. Close the plastic clip at both edges of the DIMM slots to lock the DIMM module.
3. Reverse the installation steps when you want to remove the DIMM module.
1-4-3 DIMM Population Table
Type Ranks Per DIMM
and Data Width
DIMM
Capacity
(GB)
Speed (MT/s); Voltage (V);
DIMM per Channel (DPC)
1DPC* 2DPC
16Gb 1.1V
RDIMM
SRx8 (RC D) 16GB
4800 4400
SRx4 (RC C) 32GB
SRx4 (RC F) 9x4 32GB
DRx8 (RC E) 32GB
DRx4 (RC A) 64GB
DRx4 (RC B) 9x4 64GB
RDIMM 3DS (4R/8R)x4
(RC A)
2H-128GB
4H-256GB
*1DPC applies to 1SPC or 2SPC implementations (SPC - Sockets Per Channel)

- 16 -
Hardware Installation
1-4-4 Processor and Memory Module Matrix Table
4 DIMM
Memory Q’ty
for CPU
1 DIMM
2 DIMM
6 DIMM
8 DIMM
12 DIMM
16 DIMM
CPU0
B0
B1
A0A1 D0
D1
C0C1G1G0
H1
H0 E1 E0
F1
F0
V
V V
VVVV
VV V V V
V
VV
VV
V VV V
V
V VV
V
V V
V
V
V
V
V VV V VV V V V VV V VV VV
V
1-4-5 DDR5 DIMM with Intel OptaneTM PMem 300 Series Memory Population
DIMM Type Ranks Per DIMM
and Data Width
DIMM Capacity
(GB)
DRAM Density
16Gb
RDIMM
1Rx8 16GB
1Rx4 32GB
2Rx8 32GB
2Rx4 64GB
RDIMM 3DS 4Rx4 (2H) 128GB
8Rx4 (4H) 256GB
1-4-6 Intel OptaneTM PMem 300 Series Matrix Conguration
Note:
• AD (App Direct Mode): DDR5 is 1LM and PMem is in App Direct Mode.
• MM (Memory Mode)
• Mixed Mode
»Intel recommands DRAM to PMem 300 series MM, NM/FM ratio is between 1:2 and 1:8.
(NM=Near Memory; FM = Far Memory)
»PMem 300 1:2 NM:FM ratio support will initially be for up to 64GB DDR5 DIMMs.
• No mixing of PMem and NVDIMMs within the platform.
CPU0
DDR5 + PMem
8+8
Mode
1LM+AD, MM,MM+AD
DIMM_P0_D0DIMM_P0_C0DIMM_P0_F0DIMM_P0_H0 DIMM_P0_G1 DIMM_P0_F1 DIMM_P0_A0DIMM_P0_E0
PMemPMemPMem PMem DDR5DDR5 DDR5 DDR5
DIMM_P0_D1
PMem
DIMM_P0_C1
PMem DDR5
DIMM_P0_B0
DDR5
DIMM_P0_B1DIMM_P0_A1
DDR5
DIMM_P0_E1DIMM_P0_H1 DIMM_P0_G0
DDR5PMem PMem

- 17 -
Hardware Installation
1-5 Installing the M.2 SSD Module
Follow the steps below to install a M.2 SSD module on your motherboard:
Step1. Insert the M.2 SSD module into the slot.
Step2. Secure it with the screw, tightening as necessary to fasten the M.2 SSD module in place.
1
2
CAUTION
The position of the stand-off screw will depend on the size of the M.2 device. Refer to the size of the
M.2 device and change the position of the stand-off screw accordingly.

- 18 -
Hardware Installation
1-6 Back Panel Connectors
1Serial Port
Connect to serial-based mouse or data processing devices.
2VGA Port
Connect to a monitor device.
310GbE LAN Port #2
The Gigabit Ethernet LAN port provides Internet connection at up to 10 Gbps data rate. See the section
below for a description of the states of the LAN port LEDs.
410GbE LAN Port #1
The Gigabit Ethernet LAN port provides Internet connection at up to 10 Gbps data rate. See the section
below for a description of the states of the LAN port LEDs.
5Server Management LAN Port
The LAN port provides Internet connection with data transfer speeds of 10/100/1000Mbps. This port is
the dedicated LAN port for Server Management.
6USB 3.2 Gen1 Ports
The USB port supports the USB 3.2 specification. Use this port for USB devices such as a USB
keyboard/mouse,USBprinter,USBashdriveetc.
7ID button with LED
Whenthesystemidenticationisactive,theIDLEDonthefront/backpanelglowsblue.
1
2
34
5
7
6
LAN and ID Button LEDs
Link/Activity LED
Speed LED
LAN Port
ID button/LED:
10/100/1000 LAN LED:
State Description
Yellow On 1Gbps data rate
Green On 100Mbps data rate
Off 10Mbps data rate
State Description
Blue On Systemidenticationisactive
Off Systemidenticationisdisabled
10GbE LAN LED:
State Description
Yellow On 5Gbps, 2.5Gbps, 1Gbps data rate
Green On 10Gbps data rate
Off 100Mbps data rate
• Whenremovingthecableconnectedtoabackpanelconnector,rstremovethecablefromyour
device and then remove it from the motherboard.
• When removing the cable, pull it straight out from the connector. Do not rock it side to side to
prevent an electrical short inside the cable connector.

- 19 -
Hardware Installation
1-7 Internal Connectors
Read the following guidelines before connecting external devices:
• First make sure your devices are compliant with the connectors you wish to connect.
• Before installing the devices, be sure to turn off the devices and your computer. Unplug the power
cord from the power outlet to prevent damage to the devices.
• After installing the device and before turning on the computer, make sure the device cable has
been securely attached to the connector on the motherboard.
1) ATX1 11) FP_1
2) P12V_PCIE 12) BP_1
3) P12V_AUX1/P12V_AUX2 13) SPI_TPM
4) SSATA0/SSATA2 14) IPMB1
5) SSATA_SGP1 15) CN_NCSI
6) CPU0_FAN1/CPU0_FAN2 16) LED_BMC
7) SYS_FAN1/SYS_FAN2/SYS_FAN3 17) BAT
8) SYS_FAN4/SYS_FAN5 18) CASE_OPEN
9) PMBUS
10) F_USB3
CPU0
DIMM_P0_H0 DIMM_P0_E0 DIMM_P0_F1 DIMM_P0_F0 DIMM_P0_G1 DIMM_P0_G0 DIMM_P0_H1 DIMM_P0_E1
DIMM_P0_A1 DIMM_P0_D1 DIMM_P0_C0 DIMM_P0_C1 DIMM_P0_B0 DIMM_P0_B1 DIMM_P0_A0 DIMM_P0_D0
13
17
16
11
12
1
2
3
45 9
6
7
8
10
14
15
18

- 20 -
Hardware Installation
1/2/3) ATX1/P12V_PCIE/P12V_AUX1/P12V_AUX2
(2x12 Main Power Connector and 2x3/2x4 12V Power Connector)
With the use of the power connector, the power supply can supply enough stable power to all the components
onthemotherboard.Beforeconnectingthepowerconnector,rstmakesurethepowersupplyisturnedoff
and all devices are properly installed. The power connector possesses a foolproof design. Connect the power
supply cable to the power connector in the correct orientation. The 12V power connector mainly supplies
power to the CPU. If the 12V power connector is not connected, the computer will not start.
To meet expansion requirements, it is recommended that a power supply that can withstand high
power consumption be used (500W or greater). If a power supply is used that does not provide the
required power, the result can lead to an unstable or unbootable system.
ATX1
P12V_AUX1/P12V_AUX2
8
5
4
1
PinNo. Denition
1 GND
2 GND
3 GND
4 GND
5 +12V
6 +12V
7 +12V
8 +12V
Pin No. Denition Pin No. Denition
1 3.3V 13 3.3V
2 3.3V 14 -12V
3 GND 15 GND
4 +5V 16 PS_ON
5 GND 17 GND
6 +5V 18 GND
7 GND 19 GND
8 Power Good 20 -5V
9 5VSB 21 +5V
10 +12V 22 +5V
11 +12V 23 +5V
12 3.3V 24 GND
113
1224
Pin No. Denition
1 +12V
2 +12V
3 +12V
4 GND
5 GND
6 GND
6
4
3
1
P12V_PCIE
