Gigaset Gigaset SX553 WLAN dsl User manual

Gigaset SX553 WLAN dsl / en / A31008-M1034-B181-1-7619 / cover_front.fm / 27.06.2006
Template 2005_07_27
First steps

II
Gigaset SX553 WLAN dsl / en / A31008-M1034-B181-1-7619 / cover_front.fm / 27.06.2006
Template 2005_07_27

1
Contents
Gigaset SX553 WLAN dsl / en / A31008-M1034-B181-1-7619 / SX553_WLAN_dslIVZ.fm / 27.06.2006
Schablone 2005_07_27
Contents
Safety precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
The Gigaset SX553 WLAN dsl . . . . . . . . . . . . . . . . . . 6
Local area networks with Gigaset products . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Wired local area network (Ethernet) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Wireless local area network (WLAN) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Linking a wireless local area network (WLAN) to an Ethernet (LAN) . . . . . . . . . . 11
Extending the wireless network coverage with a repeater . . . . . . . . . . . . . . . . . . 12
Internet telephony and connecting analogue phones . . . . . . . . . . . . . . . . . . . . . . . . 13
Features and applications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
First steps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
System requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Overview of the installation steps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Setting up the Gigaset SX553 WLAN dsl . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Connecting and activating the Gigaset SX553 WLAN dsl . . . . . . . . . . . . . . . . . . . . . . 19
Ports on the rear panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Connecting to the splitter data port . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Connecting to the phone port . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Connecting to the phone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Connecting to the PC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Connecting to the mains power supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Switching on . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Checking the operating state . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Network configuration of the PCs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Making the basic settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Connecting and configuring additional PCs (optional) . . . . . . . . . . . . . . . . . . . . . . . . 28
The user interface . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Launching the user interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
The start screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Selecting a language . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Connecting to the Internet manually . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Elements on the user interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Basic Setup Wizard . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Regional Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Configuring Internet connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Telephony . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Summary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

2
Contents
Gigaset SX553 WLAN dsl / en / A31008-M1034-B181-1-7619 / SX553_WLAN_dslIVZ.fm / 27.06.2006
Schablone 2005_07_27
Security settings . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Assigning a password . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
SSID . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Setting up security functions for the wireless network . . . . . . . . . . . . . . . . . . . . . . . . 45
WPA2/WPA with Pre-shared key (PSK) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
WEP encryption . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Access control within the wireless network . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
Saving settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
Configuring the Advanced Settings . . . . . . . . . . . . 52
Internet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .53
Internet selection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
Internet Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
DNS Server . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
MAC Address . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
Traffic Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
Firewall . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .62
Attack Detection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
Setting up access control to the Internet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
Setting up the NAT function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
Port Triggering . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
Port Forwarding . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73
Opening the firewall for selected PCs (Exposed Host) . . . . . . . . . . . . . . . . . . . . . 74
Dynamic DNS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75
QoS (Quality of Service) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77
LAN configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78
Assigning static IP addresses to individual PCs . . . . . . . . . . . . . . . . . . . . . . . . . . . 79
Configuring wireless connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80
Setting up wireless security . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83
WPA2-PSK and WPA2-PSK / WPA-PSK . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84
WEP encryption . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 86
Allowed clients . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 88
Repeater function (WDS) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 90
Setting up Internet telephony (VoIP) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 91
VoIP settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92
ISDN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 94
Extensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95
Dialing Plans . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 97
Quick dial . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 100
USB . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .101
File Server . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 102
Web Server . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 105
Print Server . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 108

3
Contents
Gigaset SX553 WLAN dsl / en / A31008-M1034-B181-1-7619 / SX553_WLAN_dslIVZ.fm / 27.06.2006
Schablone 2005_07_27
Administration . . . . . . . . . . . . . . . . . . . . . . . . . . . . 109
Regional Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 109
Internet Time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 110
System Password . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 110
Setting up Remote Management . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 111
Backing up and restoring a configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 113
Backing up configuration data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 113
Restoring the saved data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 113
Restoring factory settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 114
Reboot . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 114
Updating firmware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 115
System Log . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 116
Status information . . . . . . . . . . . . . . . . . . . . . . . . . 117
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 117
Security . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 119
Internet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 121
Traffic Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 123
Local Network . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 124
Wireless Network . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 125
Telephony . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 126
Device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 127
Configuring the local network . . . . . . . . . . . . . . . 129
Network configuration with Windows XP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 129
Configuring the network . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 130
Selecting a computer name and workgroup . . . . . . . . . . . . . . . . . . . . . . . . . . . . 131
Checking the network settings and completing the installation procedure . . . . 132
TCP/IP settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 133
Deactivating the HTTP proxy . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 136
Configuring a popup blocker . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 136
Synchronizing TCP/IP settings with the Gigaset SX553 WLAN dsl . . . . . . . . . . . 137
Network configuration with Windows 2000 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 138
Installing network services . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 138
Selecting a computer name and workgroup . . . . . . . . . . . . . . . . . . . . . . . . . . . . 139
Installing the TCP/IP protocol . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 140
TCP/IP settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 142
Deactivating the HTTP proxy . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 144
Deactivating the popup blocker . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 144
Synchronizing the TCP/IP settings with the Gigaset SX553 WLAN dsl . . . . . . . . 145
Network configuration for Windows 98, 98 SE, ME . . . . . . . . . . . . . . . . . . . . . . . . . 146
Setting up a PC as the client for Microsoft networks . . . . . . . . . . . . . . . . . . . . . 146
Selecting a computer name and workgroup . . . . . . . . . . . . . . . . . . . . . . . . . . . . 147
Installing the TCP/IP protocol . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 148
Making TCP/IP settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 149

4
Contents
Gigaset SX553 WLAN dsl / en / A31008-M1034-B181-1-7619 / SX553_WLAN_dslIVZ.fm / 27.06.2006
Schablone 2005_07_27
Deactivating the HTTP proxy . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 153
Deactivating the popup blocker . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 153
Synchronizing the TCP/IP settings with the Gigaset SX553 WLAN dsl . . . . . . . . 154
Checking the connection to the Gigaset SX553 WLAN dsl . . . . . . . . . . . . . . . . . . . . 155
Installing the printer port for network printers . 156
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 156
Installing a standard TCP/IP printer port under
Windows XP/2000 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 156
Installing a printer on the TCP/IP port retrospectively . . . . . . . . . . . . . . . . . . . . . . . . 162
Installing a printer driver under Windows 98 SE or ME . . . . . . . . . . . . . . . . . . . . . . . 163
Instructions for setting up a printer on the PC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 164
Appendix . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 166
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 166
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 169
Authorisation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 170
Disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 170
Service (Customer Care) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 171
Guarantee Certificate United Kingdom . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 172
Guarantee certificate Ireland . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 172
Glossary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 174
Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 187

5
Safety precautions
Gigaset SX553 WLAN dsl / en / A31008-M1034-B181-1-7619 / introduction.fm / 27.06.2006
Template 2005_07_27
Safety precautions
uOnly use the router with the mains adapter that is supplied.
When connecting the router to the mains, make sure that the connection values are
not exceeded.
uProtect the equipment from moisture.
uNever open the router. For reasons of electrical safety, the router may only be
opened by authorised service staff.
uThe router may affect medical equipment. Be aware of the conditions of your envi-
ronment.
uMake sure you include these operating instructions when you pass on your router to
someone else.

6
The Gigaset SX553 WLAN dsl
Gigaset SX553 WLAN dsl / en / A31008-M1034-B181-1-7619 / introduction.fm / 27.06.2006
Template 2005_07_27
The Gigaset SX553 WLAN dsl
The Siemens Gigaset SX553 WLAN dsl is a powerful but simple communications device
for connecting your PC or local area network (LAN) to the Internet (DSL). It contains an
integrated ADSL modem enabling you to access the Internet easily.
You can connect your PC wirelessly to the Gigaset SX553 WLAN dsl and create a wireless
local area network (WLAN). The device supports Super G technology making this possi-
ble. The transmission rate in the wireless local area network can be increased to 108
Mbps thanks to channel bundling. For network security, wireless transmission can be
encrypted using the WPA standard or 64-/128-bit WEP.
The Gigaset SX553 WLAN dsl also offers the functions of a PABX for Internet telephony
(VoIP) and fixed-network telephony allowing you to connect up to two conventional
analogue terminals. Using these analogue phones, you can make calls via the Internet
or via an existing analogue or ISDN phone line.
The Gigaset SX553 WLAN dsl allows several users to access the Internet simultaneously.
A single user account can be shared if your Internet service provider permits this. If you
want to surf the Internet and make calls using the Internet, the Gigaset SX553 WLAN dsl
is a convenient and simple solution.
The Gigaset SX553 WLAN dsl has an extensive range of functions but remains simple to
handle. It can be configured and operational within a few minutes.

7
The Gigaset SX553 WLAN dsl
Gigaset SX553 WLAN dsl / en / A31008-M1034-B181-1-7619 / introduction.fm / 27.06.2006
Template 2005_07_27
Local area networks with Gigaset products
You can use the Siemens Gigaset SX553 WLAN dsl to set up a local area network, e.g. a
home network. All the PCs in this network can communicate with each other and have
access to the Internet.
There are various ways in which you can set up the network using a Gigaset SX553
WLAN dsl. You can
uset up a wired local area network (Ethernet) and allow the connected PCs access to
the Internet (see page 8).
uset up a wireless local area network (WLAN) and allow the connected PCs access to
the Internet (see page 9).
uset up a local area network comprising wireless and wired network components (see
page 11).
Internet
Gigaset SX553 WLAN dsl
Local area network
Windows 98 SE
Windows ME
Windows 2000
Windows XP

8
The Gigaset SX553 WLAN dsl
Gigaset SX553 WLAN dsl / en / A31008-M1034-B181-1-7619 / introduction.fm / 27.06.2006
Template 2005_07_27
Wired local area network (Ethernet)
In a wired local area network, PCs communicate with one another via an Ethernet cable.
When the Siemens Gigaset SX553 WLAN dsl is used, it establishes the connection
between the PCs. For this it has four Ethernet LAN ports for connecting four PCs. The
PCs have to be equipped with a network port (Ethernet). New PCs frequently already
have this port. For older PCs you need to install an Ethernet network card. The PC and
the Ethernet LAN port on the Gigaset SX553 WLAN dsl are connected using an Ethernet
cable (CAT5). There is one supplied. You can obtain additional Ethernet cables from your
retailer.
The Gigaset SX553 WLAN dsl allows all PCs to access the Internet simultaneously.
Internet
Ethernet

9
The Gigaset SX553 WLAN dsl
Gigaset SX553 WLAN dsl / en / A31008-M1034-B181-1-7619 / introduction.fm / 27.06.2006
Template 2005_07_27
Wireless local area network (WLAN)
In a wireless local area network (WLAN) PCs are linked without wires or cables. The PCs
have to be equipped with a wireless local area network adapter (WLAN adapter), e.g. a
Gigaset USB Adapter 108.
We generally differentiate between two types of wireless network:
uInfrastructure mode
uAd-hoc mode
Infrastructure mode
The infrastructure mode connects wireless and wired networks with one another. In
addition to the mobile stations, the infrastructure mode needs an access point such as
the Gigaset SX553 WLAN dsl. In infrastructure mode, the stations in the network always
communicate via this access point. The access point sets up the wireless network on a
permanent basis. Each station that wants to be part of the wireless network must first
register with the access point before it can exchange data. The range of the wireless net-
work can be increased by using an access point.
The access point establishes the connection between the mobile stations of a wireless
network and a wired LAN (Ethernet) or the Internet. In this case this is described as the
device's router functionality. The router sends data packets that are not addressed to sta-
tions within the network "outside" and forwards data packets originating from "outside"
to the appropriate station within the network.
You can use the Gigaset SX553 WLAN dsl to connect
uwirelessly networked PCs to the Internet and
uwirelessly networked PCs to an Ethernet network.
Infrastructure mode is the default configuration for the Gigaset SX553 WLAN dsl. This
configuration is described in the quick guide enclosed with the router.
Ad-hoc mode
An ad-hoc network is a wireless network that has been configured without an access
point or a router.The mobile network components that communicate with each other
directly and wirelessly form the network on an "ad-hoc" basis, i.e. as and when required.
All the stations in the network have the same rights. Ad-hoc networks are used wher-
ever communications networks have to be set up quickly and there is no existing net-
work infrastructure, and where the participants are on the move.

10
The Gigaset SX553 WLAN dsl
Gigaset SX553 WLAN dsl / en / A31008-M1034-B181-1-7619 / introduction.fm / 27.06.2006
Template 2005_07_27
Linking wireless networks with the Internet
The Gigaset SX553 WLAN dsl has an ADSL interface that permits all stations within its
local area network to access the Internet simultaneously. To be able to use this function-
ality you need a DSL connection obtainable from an Internet service provider. Find out
whether your service provider supports parallel access by several PCs.
Internet
(((
(((
)))(((
)))(((
(((
(((

11
The Gigaset SX553 WLAN dsl
Gigaset SX553 WLAN dsl / en / A31008-M1034-B181-1-7619 / introduction.fm / 27.06.2006
Template 2005_07_27
Linking a wireless local area network (WLAN) to an Ethernet (LAN)
Wireless local area networks can work easily together with existing Ethernet networks.
If you wish to connect mobile stations to an existing wired network, you must group
together all mobile stations into a wireless local area network in infrastructure mode.
The Gigaset SX553 WLAN dsl has four Ethernet interfaces (LAN ports). Up to four PCs
can be connected directly to these LAN ports.
All PCs can access the Internet via the Gigaset SX553 WLAN dsl.
Please note:
You can also connect an Ethernet router to a LAN port to access a larger Ethernet.
If you want to link the Gigaset WLAN network to an existing network, a large number
of settings have to be applied. Therefore we cannot provide a general example for this
use; the configuration depends greatly on the networks in question. We advise having
the configuration of such a network carried out by a specialist.
(((
(((
Wireless local area network (WLAN)
Ethernet
(((
(((
Access Point
)))((( )))(((

12
The Gigaset SX553 WLAN dsl
Gigaset SX553 WLAN dsl / en / A31008-M1034-B181-1-7619 / introduction.fm / 27.06.2006
Template 2005_07_27
Extending the wireless network coverage with a repeater
Using a repeater, e.g. the Gigaset WLAN Repeater, you can extend your wireless net-
work's coverage. Set it up within the range of your network. The repeater will now trans-
mit data traffic into its own wireless area. This technology allows you to set up wireless
networks that cover a much larger area than is possible with a single Gigaset SX553
WLAN dsl.
PCs to be connected in a wireless local area network via a Gigaset WLAN Repeater must
be equipped with a wireless network adapter or a USB adapter.
Internet
)))
(((
)))
)))
Gigaset WLAN Repeater
)))
(((
(((

13
The Gigaset SX553 WLAN dsl
Gigaset SX553 WLAN dsl / en / A31008-M1034-B181-1-7619 / introduction.fm / 27.06.2006
Template 2005_07_27
Internet telephony and connecting analogue phones
The Gigaset SX553 WLAN dsl allows fixed network and Internet telephony (VoIP) via DSL
to be combined for two analogue phones.
This provides you with the full benefits of both technologies. You can make use of the
low-cost call rates of Internet telephony without any additional equipment. You can also
use your analogue or ISDN fixed network connection. The type of calls that are cheaper
for you will depend on what calls you make and when you make them, and the rates
offered by your service provider. The Gigaset SX553 WLAN dsl gives you the complete
freedom of choice at any time.
You can choose whether to connect two analogue phones or base stations for cordless
phones to the two phone ports. If you have an ISDN port, you can configure this con-
nection via the Gigaset SX553 WLAN dsl configuration program.
You will need the relevant access data for your VoIP provider to configure Internet
telephony.
You can, of course, also continue to use Internet telephony on one of the PCs connected
to the Gigaset SX553 WLAN dsl. To do this, the PC must be equipped with a loudspeaker
and a microphone or headset and a full duplex sound card, and have the necessary soft-
ware installed.
Please note that you can only be reached via the Internet (VoIP) when an active Internet
connection is established. You can still be called via the fixed network, however. When
a call is made, the Gigaset SX553 WLAN dsl automatically dials the fixed network if the
Internet connection is deactivated or the VoIP port is not registered.
Internet
Fixed network

14
The Gigaset SX553 WLAN dsl
Gigaset SX553 WLAN dsl / en / A31008-M1034-B181-1-7619 / introduction.fm / 27.06.2006
Template 2005_07_27
Features and applications
The Gigaset SX553 WLAN dsl's wide range of features makes it ideal for a large number
of applications, such as:
uInternet access
The Gigaset SX553 WLAN dsl allows several users to have Internet access via the
integrated ADSL modem.
– Since many DSL providers permit communication with end users via PPPoE pro-
tocol, the Gigaset SX553 WLAN dsl has an integrated Client for this protocol, so
you no longer have to install this service on your PC.
– If your Internet service provider permits this, the Gigaset SX553 WLAN dsl sup-
ports shared Internet access for up to 252 users. So several users in your network
can surf the Internet at the same time, all using the same Internet account.
uSetting up a local area network
The Gigaset SX553 WLAN dsl offers the following possibilities:
– Four devices connected via Ethernet ports with a transmission speed of 10 or
100 Mbps (with automatic recognition).
– Up to 252 mobile terminals via a radio interface with a transmission speed of up
to 108 Mbps. It complies with Standard IEEE 802.11g and can work with all prod-
ucts that satisfy Standard IEEE 802.11b or 802.11g. The Super G technology
allows for high transmission speed.
– Using a Gigaset SX553 WLAN dsl makes it easy to set up a network at home or in
small offices. For example, users can exchange data or share resources on the
network, such as a file server or printer. You can connect a USB memory or a
printer to the USB interface of the Gigaset SX553 WLAN dsl and make them avail-
able to all users in your network.
The Gigaset SX553 WLAN dsl supports DHCP for dynamic IP configuration of the
local area network, and DNS for domain name mapping.
uConnecting phones and Internet telephony
The Gigaset SX553 WLAN dsl permits
– Internet telephony via the DSL port,
– fixed network telephony via the analogue or ISDN port,
– the connection of two analogue phones for Internet telephony and fixed network
calls,
– the connection of an answering machine or fax.
Data transfer for VoIP is carried out by the SIP protocol with high connection and
voice quality. If the Internet connection has been interrupted or you do not want to
make a call via VoIP, you can simply make a call on the fixed network.

15
The Gigaset SX553 WLAN dsl
Gigaset SX553 WLAN dsl / en / A31008-M1034-B181-1-7619 / introduction.fm / 27.06.2006
Template 2005_07_27
uSecurity functions
The Gigaset SX553 WLAN dsl offers comprehensive security measures:
–Firewall protection against unauthorised access from the Internet
All the PCs in the local area network use the Public IP address of the
Gigaset SX553 WLAN dsl's for their Internet connections, which makes them
'invisible' on the Internet. The Gigaset SX553 WLAN dsl only allows access from
the Internet if it has been requested from the local area network.
With the firewall the Gigaset SX553 WLAN dsl also offers comprehensive protec-
tion against hacker attacks.
– Service filtering and URL blocking
The Gigaset SX553 WLAN dsl can filter Internet access. Here you determine which
PCs may access which Internet services.
In addition, you can deactivate access to certain Internet domains and sites
(URL blocking).
– Access control and encryption for the local area network
You can use various encryption methods and authentication methods (WEP, WPA/
WPA2, 802.1x MAC access control) to prevent unauthorised access to your wire-
less LAN or make data illegible to unauthorised parties.
uOffering your own services on the Internet
– If you want to offer your own services on the Internet, you can set up the
Gigaset SX553 WLAN dsl as a virtual server without permitting further access to
the local area network.
–DMZ
This allows you to release a PC on your local area network for unlimited access to
the Internet. Please note that in this case your local area network will no longer
be adequately protected against Internet attacks.
– With the Gigaset SX553 WLAN dsl, you can easily set up an FTP server and/or
HTTP server for access from the Internet.

16
First steps
Gigaset SX553 WLAN dsl / en / A31008-M1034-B181-1-7619 / device.fm / 27.06.2006
Template 2005_07_27
First steps
Contents
The package contains the following components:
u1 Gigaset SX553 WLAN dsl,
u1 mains adapter (220 V/12 V 1.5A DC),
u2 CAT5 cables (grey),
u1 phone cord (black),
u1 adapter with TAE plug for an analogue phone port,
u1 adapter with TAE socket for connecting analogue phones to the router,
u1 CD with this User Guide and the driver software for operating a network printer on
the Gigaset SX553 WLAN dsl via Windows 98 SE/ME,
u1 supplementary sheet with information about security and disposing of the device.
System requirements
You require the following components to operate your Gigaset SX553 WLAN dsl:
uA PC with
– an 802.11g or 802.11b compatible wireless Network adapter
Owing to the superior range and the high data throughput from the Super G tech-
nology, we recommend you use the Gigaset PC Card 108 or the Gigaset USB
Adapter 108.
or
–anEthernet port (10Base-T or 100Base-TX)
uA Web browser such as Microsoft Internet Explorer V 6.0 or higher and Mozilla Fire-
fox V 1.0 or higher for configuring your Gigaset SX553 WLAN dsl.
Note:
An 802.11b-compatible network adapter has a maximum transmission speed of
11 Mbps. An 802.11g-compatible network adapter has a maximum transmission
speed of 54 Mbps. A network adapter that supports Super G has a maximum trans-
mission speed of 108 Mbps.

17
First steps
Gigaset SX553 WLAN dsl / en / A31008-M1034-B181-1-7619 / device.fm / 27.06.2006
Template 2005_07_27
uTo access the Internet you require
– a DSL port (splitter),
– the access data for your Internet service provider.
Trademarks
Microsoft, Windows 98, Windows 98 SE, Windows ME, Windows 2000, Windows XP and
Internet Explorer are registered trademarks of the Microsoft Corporation.
Mozilla Firefox is a registered trademark of the Mozilla Organization.
Super G is a registered trademark of Atheros Communications, Inc.
Overview of the installation steps
1. First install an Ethernet network card or a wireless Network adapter such as the
Gigaset PC Card 108 in the PCs you want to connect to the Gigaset SX553 WLAN dsl.
The installation is described in the products' user guide.
2. Then make the necessary connections (PCs, phones, splitter) to the Gigaset SX553
WLAN dsl and activate the device (see page 19).
3. Before the PCs can communicate with the Gigaset SX553 WLAN dsl and with
each other in a local network, you may have to change their network settings (see
page 27). Configure these network settings on one PC first so that it can establish a
connection to the Gigaset SX553 WLAN dsl. You can then use this PC to configure
the device. To find out how to do this, refer to the section entitled "Configuring the
local network" on page 129.
4. In a wireless connection you establish the link from the PC's wireless network adapt-
er to the Gigaset SX553 WLAN dsl. This is described in the user guide for the network
adapter.
5. Then configure the Gigaset SX553 WLAN dsl to activate the device's Internet access
(refer to the section entitled "Basic Setup Wizard" on page 35). To do this you will
require the access data from your Internet service provider.
For experienced users
The default settings for the Gigaset SX553 WLAN dsl are:
– IP address: 192.168.2.1
– Subnet mask: 255.255.255.0
– SSID: ConnectionPoint
– Radio channel: 11
Caution: By default there is no encr yption active. Please be sure to make your network
secure. You will find information about this in the section entitled "Configuring wire-
less connections" on page 80.
Please note:
When installing wireless network adapters, use the default SSID for the
Gigaset SX553 WLAN dsl: ConnectionPoint.

18
First steps
Gigaset SX553 WLAN dsl / en / A31008-M1034-B181-1-7619 / device.fm / 27.06.2006
Template 2005_07_27
uIf you want to connect more PCs to the Gigaset SX553 WLAN dsl, configure their net-
work settings so as to set up the local network (refer to the section entitled
"Configuring the local network" on page 129).
uIf you want to use the Gigaset SX553 WLAN dsl for Internet telephony, you must con-
figure your VoIP provider's registration data (refer to the section entitled "Setting up
Internet telephony (VoIP)" on page 91).
uIf you wish to use other functions of the Gigaset SX553 WLAN dsl, e.g. the compre-
hensive security features, use the Security Setup (see page 42) or the Advanced
Setup (see page 52).
Setting up the Gigaset SX553 WLAN dsl
Front panel
The Gigaset SX553 WLAN dsl can be set up in any suitable location in the home or office.
You do not need any special wiring. However, you should comply with the following
guidelines:
uOperate the Gigaset SX553 WLAN dsl only indoors within a temperature range of
+5 to +40 °C. Do not position the Gigaset SX553 WLAN dsl near sources of heat.
Do not cover the ventilation slots. High temperatures can damage the device.
uA mains socket for 220/230 V~ and a connection socket for the splitter or LAN must
be available in the place where you set up the Gigaset SX553 WLAN dsl.
uDo not position the device in the immediate vicinity of stereo equipment, TV sets or
microwave ovens. This may cause interference.
uPosition the Gigaset SX553 WLAN dsl so that it is as near to the centre of your wire-
less network as possible. The general rule is: the higher you place the antennae,
the better the performance. Make sure that the place where you position the
Gigaset SX553 WLAN dsl offers optimum reception throughout the house or office.
uPosition the Gigaset SX553 WLAN dsl on a non-slip surface. The router feet do not
normally leave any traces on the surface they are on. However, some furniture sur-
