Go EveryWhere PT-05 User manual

PT-05 PersonalTracker
(GPS+SMS+GPRS)
UserGuide
Version 1.0

GPStrackerPage1of46
Content
USER GUIDE..........................................................................................................................1
VERSION1.0..........................................................................................................................1
1INTRODUCTION................................................................................................................2
2FEATURE:..........................................................................................................................3
3SPECIFICATION................................................................................................................3
HARDWARE ............................................................................................................................4
OTHER ....................................................................................................................................5
4HARDWAREDESCRIPTION..........................................................................................6
5GET STARTED...................................................................................................................9
(5.1) ACCESSORIES...............................................................................................................9
(5.2) CHARGEBATTERY ......................................................................................................10
(5.3) BUY SIM CARD...........................................................................................................11
(5.4) INSTALL SIM CARD .................................................................................................11
6OPERATION.....................................................................................................................11
7DISPLAYINGLOCATIONONMAP............................................................................18
8MOREPROFESSIONALSMSINSTRUCTION..........................................................24
9SMSINSTRUCTIONEXAMPLE:..................................................................................27
10GPRSCOMMUNICATIONSETTING.......................................................................28
11CAUTION:......................................................................................................................31
12DIY!!!BUILDYOURCONTROLCENTERSYSTEMONYOUR PC.................32
13TROUBLE SHOOTING.................................................................................................35
ATTACHMENT:WORLDWIDEAPN (ACCESSPOINT NAME) LIST...........................41

GPStrackerPage2of46
1Introduction
PT-05 isapersonalremoteposition device
with build-in GPSand GSM/GPRSmodules.
It isacompactsize, highaccuracy remote
location tracking device.
Basedon GPSsatellite,
itprovides accurateposition information
underdynamicconditions.
Personalremotepositiondevicetransmit
thelongitudeand latitudecoordinatetoauthorizedcellphone.
Youcan usethesefeaturesforprotecting and searching children andold
persons. Further, youcan use itas asecurity purposeandotherpurpose
which needsremotepositioning suchas assetprotectionandanimaltracking.

GPStrackerPage3of46
2Feature:
♦Build-inGPSpersonallocator.
♦GSM/SMScommunicationorGPRSTCP/UDPconnection.
♦Worksworldwide!Support3-frequencyGSM900/1800/1900 MHZ
And4-frequencyGSM850/900/1800/1900 MHZ.(Optional)
♦High sensitivity, newtechnologyand latestGPSSiRF-StarIIIchipset!
Excellentforfixingthepositionevenataweaksignalstatus.
♦Compactsize,andsmallerthanonenamecard. Easy to hide
♦VeryLowpowerconsumption
♦FastSignalAcquisition
♦Supportsinglelocationand continuoustracking
♦Supportlocationtriggeredby tracker
♦Supportlocationtriggeredby authorized cellphone
♦Supportalarm andremotemonitor
♦Supportquick dialing buttonsfor3presetphonenumbers
♦Supportvoicemonitoring function
♦SupportBi-Directionconversation withoutearmicrophone
♦Supportremovableinternalbattery
♦Supportchecklocationby SMSand GPRS
♦Supportautomaticly savingpower
♦Monitorscantrack thepersonwithoutinterfering him,
LIVE!Real-Timetracking!
♦Locatethelocatorholderby themobilephoneviaSMS(SMSsystem).
♦SOSbutton send outexactlocationforimmediaterescue/action.
♦Geo-fencing torestrictmovementtoadefined radius.
♦Nomonthlyservicechargestobepaidtothecallcenter
Newfeature:
USBconfiguration cableforbulk number
optionalwaterproofcase;
withoptionalexternalbattery (extendto workfor7days);
optionalpetcollar;
WorkingwithSMSmodem,GPRSsoftware kitsandPDA tracking
kits.customer canwatchthepositionandtrace oftheirobjectonthe
mapreal-timeautomaticallyatverylowcost,withoutmonthly
payment,withoutanymanualinput. Supportalmostall navigation
map,includeGoogleearth.

GPStrackerPage4of46
3Specification
Hardware
GSMmodule embeddedGSM900/1800/1900Mhz
embeddedGSM850/900/1800/1900Mhz(Optional)
andGPRSTCP/UDP
GPSChipset latestGPSSiRF-StarIIIchipset
GPSSensitivity -158Db
GPSFrequency L1,1575.42 MHz
C/ACode 1.023MHzchip rate
Channels 20channelall-in-viewtracking
Position Accuracy 10meters,2DRMS
VelocityAccuracy 0.1 m/s
TimeAccuracy 1 ussynchronizedto GPStime
Default datum WGS-84
Reacquisition 0.1 sec.,average
Hotstart 1 sec., average
Warmstart 38sec.,average
Coldstart 42sec.,average
AltitudeLimit 18,000 meters(60,000 feet)max.
Velocity Limit 515 meters/second (1000 knots)max.
Acceleration Limit Lessthan4g
JerkLimit 20m/sec

GPStrackerPage5of46
Other
Operatingtemperature -25 to65 C
Humidity 5%to 95%Non-condensing
Dimension 76mm ×44mm ×20 mm×13mm
Voltage Rechargeableandreplaceable1200mAhbattery(3.7V),
5Vforcharginginput.
Charging connector DC 5V(USBport)
Standby time Over60hours
LED 3LEDsshowingPower, GPS andGSMstatus,
Andotheroperationstatus.
KEY SOSEmergencykey,quickdialkeyB,quickdial
keyC,power key

GPStrackerPage6of46
4Hardwaredescription
RedLED---indicatepowerstate：
StateMeaning
Constantdark thepoweristoo lowtowork
orCharging wascompleted.
Light0.1sdark0.1s Thepowerisnotenough
ConstantLighting Charging
Light1sdark2s Working
BlueLED--indicatetheGPSsignalstate:
StateMeaning
ConstantLightingOnekeybepressed
Light0.1sdark0.1s Initial
Light0.1sdark2.9s GPSreceiverworkwell
Light1sdark2s No GPSsignal
GreenLED--indicatetheGSMsignalstate:
StateMeaning
ConstantLighting Onecalliscoming
Light0.1sdark0.1s Initial
Light0.1sdark2.9s GSMreceiverworkwell
Light1sdark2s No GSMsignal

GPStrackerPage7of46
Button Function description
Button Meaning
Powerbutton Turnon/Turnoff .
Pleasesee6.1fordetailsfor moredetails.
SOSbutton YoucanassignaphonenumbertotheSOS
button.Whenthisbuttonispressed,PT05 will
sendit’slocationinformation tothepresetphone
numberbySMS,atthesametime,PT05 willdial
thepresetphonenumber.
CallBbutton YoucanassignaphonenumbertotheQuickCall
Bbutton .whenthisbutton ispressed,PT05 will
dialthepresetphonenumber.
CallCbutton YoucanassignaphonenumbertotheQuickCall
Cbutton.whenthisbuttonispressed, PT05 will
dialthepresetphonenumber.
USB
SOSbutton
CallBbutton
Call Cbutton
LED
Poweron

GPStrackerPage8of46
SIMCard
Battery

GPStrackerPage9of46
5GetStarted
(5.1)Accessories
1. USBcharged cable
2 Wallchargerandcarcharger

GPStrackerPage10of46
3. CD –ROM(Includingourproductdocumentandprogram)
4. USBConfigurecableforbulk number(Option)
(5.2)Chargebattery
BeforeyoucanusethePT05, you must
FULLYchargethebatteryby USBcableatleast2hoursunderthepower-
offcondition.
Chargerstateindicate:
RedlightisOn ,itindicates thatitisincharging.
RedlightisOff, itindicates thatchargecompleted.

GPStrackerPage11of46
(5.3)BuySIM card
BuySIMcard fromlocaltelecommunication serviceprovider.
( Note: Please makesure that yourSIM cardsupport SMSfunctionand
haveenough deposit)
(5.4) InstallSIMcard
1openthecover
2. insterttheSIMCard

GPStrackerPage12of46
6Operation
(6.1)TurnOn/TurnOff
Turn on :
Whenthedevice isoff,press thepowerbutton andwaitforabout8
seconds.It willenterstandbymode.Itissuggestedthatyoubeaouter
placewhereit canreceivethebetterGPS signal when youturnonthe
device.
Turn off:
Whenthedeviceison,pressthebutton and waitfor8 seconds.When
theLEDsgoout,it indicatesthatthedeviceisin offforsure.
(tips:Howtoget betterGPS signal:
1Workingoutdoor,PT05 cangetbetterGPS signal;
2Thefront sideofPT05 should beplaced towardsky. )
(6.2)Apply foronepositionservice
Nomatterwhereyouare,whenyou wanttoknowthepositionofyour
tracker,sendaSMSormakeatelephonecalltoPT05;it willreport its

GPStrackerPage13of46
location backtoyou bySMS.
Editamessageasfollowingformat,thensend ittoPT05:
Format:W+Password+, +000
(initpasswordis:000000)
Forexample:W000000,000
ThePT05 send backoneSMS,whichincludingthepositioninformation
Position Datameans:
Longitude=114 degree-04cent-57.74 second
Latitude=22degree -32cent-40.05second

GPStrackerPage14of46
( Tips:Applyforonepositionserviceby another easierway:
(a) DialthePT05 telephonenumber byyourmobilephone
(b) After listeningtheringofPT05 for10~20seconds, hangoffthephone
(c) Then,after 20second,yourmobilephonewillreceivethePositionSMS. )
(6.3).Setatimeintervalfortrackingreportfunction
Trackingreport functioncanbeturned onoroffaccordingto the
requirementsoftheuser.Tracking functionwill continuallyreport
tracker spositionuntilitgetstopcommand. Inthiscontinuoustracking
mode,PT05 will send oneposition messageatapresettimeinterval.
(ItissaythatPT05 willsendonepositionmessageatevery timeinterval)
Step1:Editamessageasfollowing format,then send itto PT05:
-----W+Password+,+002,+XXX
(Note:XXXUnit:presetminutes interval
--ifXXX=000 itisSTOPtracking )
Forexample:W000000,002,005
(itsmeansthatPT05 willsend Position Dataeach5 minute.)
Step 2:PT05 willsend backoneSMS---SetTime(presettimeinterval)OK
Inthisexample,theSMSis SetTime(005Min)OK

GPStrackerPage15of46
ThisSMSmeansthatPT05 isintracking modenowandpreset
timeintervalis5 minutes.
Step3:PT05 will sendbackposition SMSatpresenttimeinterval.
In thisexample,theSMSwill send backposition dataatevery5
minutes.ThetargetphonewillreceivethePositionDataeach 005
minute.
Position Datameans:
Longitude=114 degree-04cent-57.74 second
Latitude=22degree -32cent-40.05second
(Note:
if SMSshow:
Longitude=000degree-00cent-00 second
Latitude=00degree-00cent-00second
ItmeansthatGPSsignalistoo weaktowork well )
(6.4).Stopcontinuoustrackingreportfunction
Thisfunction isusedtoturnofftracking report function.

GPStrackerPage16of46
Editamessageas followingformat,then send itto PT05:
Format:W+passwaord+,+002+,+000
Forexample:W000000,002,000
ThePT05 will sendbackoneSMS-----Stop TimerOK. Thismessage
meanstrackingreportfunction isturned off.
(6.5)SetpresetphonenumberforSOSkey.
Thisfunction isused tosetwhattelephonenumberwillbedialed
whenpressSOSkey..
Step1 . Editamessageasfollowing format,then send itto PT05
W+password+,+003+,+3+,+1+,+area number+telephonenumber
Forexample
“W000000,003,3,1,008613628888444”
Step2 .Aboutten secondslater,thePT05 willsendbackoneSMS----
SetTelOK/003,3,1,008613628888444.Thismessagemeansthe
presetphonenumberforSOSkeyisOK.
step3 .PresstheSOSbutton, thePT05 willsend oneAlarm
SMSto“0086 13628888444”,and thendial“0086
13628888444”.
Note:
(a)AfterSOSbutton bepressed, youcancallandtalkwithanotherpeoplebyear
microphone
(b)PresstheCall Key B, youcanhangup thecallorcanceltheSOScall
(c) AfterpresstheSOSkey,PT05 donotgointonormalstateuntilyoupressCall keyB
tocanceltheSOScall
(d)Aboutareanumber
Indifferentcountries,theareanumbermaydifferent.Pleasecontactwithyour
telecommunicationprovidertogettheareanumber.
Ifanyquestion aboutthisfunction,welcometoconnectourtechnicalsupport

GPStrackerPage17of46
(6.6)MakeaSOShelp
Thisfunctionisespeciallyusefulwheninemergency. When SOSkey
ispressed, PT05 willinSOSstateand 2followingSMStothepreset
phonenumber:SOSAlarmandthePosition info. Atthesametime,
PT05 willdialpresettelephonenumber.Whenthetelephonebe
pickedup, 2way communicationstarts.
OncetheSOSbutton ispressed, aSOShelpismade.
(6.7)CancelaSOScall
Whenin SOSstate,press CallBkeytohang upthephone, exit
SOSstateandreturn normalstate.

GPStrackerPage18of46
(6.8)DialthepresetphonenumberbyCallBorCall C
PresstheCallBbutton/CallCbutton once, PT05 will callthe
presetphonenumberofCallB/CallC,then youcantalkwithanother
people.
Ifyou wanttocompletethistalking,youcanhang upthecalling by
pressingtheCall Bbutton.
(6.9)Receiveonecomingcall
Whenonecallcoming, aringwillbemade, you can pressSOSkeyto
receivethecomingcall, thentalkwith anotherpeopledirectly.

GPStrackerPage19of46
Ifyou wantto completethistalking,youcanhangupthecallingby
pressingtheCall Bbutton.
