3 - HOW TO INSTALL
CHOOSE A WELL-VENTILATED PLACE
Provide at least 6-inch space at both sides to ensure adequate circulation.
There is a stopper bracket at the back side of the refrigerator which needs to be
open as shown in image 1.
Factory Setting
Stopper
Stopper to be opened as shown
*Brackets are in selected model
Image 1
AVOID EXTREME HEAT AND COLD
Place the refrigerator away from direct sunlight & heat sources such as
radiators, cooking ranges, direct air drafts i.e., windows, fans, etc.
PLACE ON A FIRM, LEVEL FLOOR
If the floor requires adjustment, suitable packing will have to be used. No stand
must be used with the refrigerator. It should directly vest on the floor.
USE THE PROPER VOLTAGE AND ELECTRICAL WIRING
Your refrigerator operates on AC 230 V, 50 Hz power supply. If there is a wide
fluctuation in supply voltage, a voltage stabiliser is advisable. Connect the plug
to a 3 pin, 5 amps socket.
Ensure that the wall socket is properly earthed by a qualified electrician. It is
safe to use a socket with a fuse and a switch, at about 1.4 metres from the floor.
To achieve a better cooling performance of the refrigerator, it should be
operated in rated Climate class T (+16°C to +43°C). Outside the climate class it
may not be able to maintain a satisfactory internal temperature.
KEEP IT CLOSE TO THE ELECTRICAL OUTLET
Do not use an extension cord. The wires should be kept off the floor to avoid any
short circuit if the water drips on the floor.
4 - FIRST STEPS
1) Plug the appliance cord into the wall outlet and switch ON the supply.
2) After a single beep from the buzzer (only for electronic models) check if the
light glows after opening the lower door of the refrigerator.
TEMPERATURE CONTROL
Mechanical Model
3) a) For Mechanical- The temperature
control knob in the lower compartment
fully clockwise on the max cool setting.
b) For Basic Electronic Model- The
temperature control knob clockwise on
the max cool setting.
c) For Top Electronic Model- Select Quick
Freeze setting on the digital control panel
at the top of the freezer compartment.
TEMPERATURE CONTROL
Basic Electronic Model
