gopart CR210GP User manual

CD/MP3/SD/MMC/USB Player with FM/MW tuner
CD/MP3/SD/MMC/USB-Player mit FM/MW-Tuner
Lecteur CD/MP3/SD/MMC/USB avec tuner FM/MW
CD/MP3/SD/MMC/USB-speler met FM/MW-tuner
Reproductor USB/SD/MMC con sintonizador de FM/AM
Lettore CD/MP3/SD/MMC/USB con radio FM/MW
Leitor de CD/MP3/SD/MMC/USB com sintonizador AM/FM
Přehrávač disků CD, souborů MP3, karet SD aMMC azařízení
USB stunerem FM/AM
CD/MP3/SD/MMC/USB prehrávač stunerom FM/MW
Odtwarzacz CD/MP3/SD/MMC/USB z tunerem FM/MW
CD/MP3/USB/SD/MMC lejátszó FM/MW rádióval
CD/MP3/SD/MMC/USB плеер с FM/MW тюнером
CR210GP
Operating Instructions
Bedienungsanleitung
Mode d’emploi
Bedieningsinstructies
Instrucciones de funcionamiento
Istruzioni per l’uso
Manual de instruções
Návod kobsluze
Návod na používanie
Instrukcja obsługi
Kezelési útmutató
Инструкция по эксплуатации
270114_CR210GP_manual 01 UK_DE_FR.indd 1 1/27/14 11:38 AM

CONTENTS
UK
Safety Information 4
Panel Controls 5
Other Instructions 6
General Operation 7
CD Player Operation 8
Tuner Operation 9
RDS(Radio Data System 10
USB/SD/MMC Operation 12
Playing MP3/WMA Files 13
Menu Function 15
Electrical Connections 17
Installation Guide 18
Anti-Theft System 19
Troubleshooting 20
Specifications 21
DE
Sicherheitsinformationen 24
Elemente des Bedienteils 25
Weitere Anweisungen 26
Allgemeiner Betrieb 27
CD-Player-Betrieb 28
Tuner-Betrieb 29
RDS (Radio Data System) 30
USB/SD/MMC-Betrieb 32
MP3/WMA-Dateien abspielen 33
Menü-Funktion 35
Elektrischer Anschluss 37
Einbauanleitung 38
Diebstahlsicherung 39
Fehlersuche 40
Technische Daten 41
FR
Informations de sécurité 44
Commandes de la façade 45
Autres instructions 46
Fonctionnement général 47
Utilisation du lecteur CD 48
Fonctionnement du tuner 49
RDS(Radio Data System) 50
Fonctionnement USB/SD/MMC 52
Lecture de fichiers MP3/WMA 53
Fonctionnement du menu 55
Branchements électriques 57
Guide d’installation 58
Système antivol 59
Dépannage 60
Spécifications 61
NL
Veiligheidsinformatie 64
Onderdelen bedieningspaneel 65
Overige instructies 66
Algemene bediening 67
Bediening CD-speler 68
Bediening tuner 69
RDS (Radiodatasysteem) 70
Bediening USB/SD/MMC 72
MP3/WMA-bestanden afspelen 73
Menufuncties 75
Elektrische aansluitingen 77
Installatiehandleiding 78
Antidiefstalsysteem 79
Problemen oplossen 80
Specificaties 81
ES
Información de seguridad 84
Controles del panel 85
Otras instrucciones 86
Funcionamiento general 87
Funcionamiento del reproductor de CD 88
Funcionamiento del sintonizador 89
RDS (Radio Data System) 90
Funcionamiento de USB/SD/MMC 92
Reproducción de archivos MP3/WMA 93
Funciones del menú 95
Conexiones eléctricas 97
Guía de instalación 98
Sistema antirrobo 99
Resolución de problemas 100
Especificaciones 101
IT
Informazioni per la sicurezza 104
Comandi pannello 105
Altre istruzioni 106
Funzionamento generale 107
Funzionamento del lettore CD 108
Funzionamento della radio 109
RDS (Radio Data System) 110
Funzionamento USB/SD/MMC 112
Riproduzione di file MP3/WMA 113
Funzione di menu 115
Collegamenti elettrici 117
Guida all’installazione 118
Sistema antifurto 119
Risoluzione dei problemi 120
Specifiche 121
PT
Informações de segurança 124
Controlos do painel 125
Outras instruções 126
Operação geral 127
Leitor de CD 128
Sintonizador 129
RDS (sistema de radiodifusão de dados) 130
USB/SD/MMC 132
Reproduzir MP3/WMA 133
Funções do menu 135
Ligações eléctricas 137
Guia de instalação 138
Sistema anti-roubo 139
Resolução de problemas 140
Especificações 141
CZ
Bezpečnostní informace 144
Ovládací prvky na panelu 145
Další pokyny 146
Obecná obsluha 147
Obsluha přehrávače disků CD 148
Obsluha tuneru 149
Systém RDS (Radio Data System) 150
Obsluha zařízení USB akaret SD aMMC 152
Přehrávání souborů MP3 aWMA 153
Funkce nabídek 155
Elektrická připojení 157
Návod kinstalaci 158
Systém pro ochranu proti krádeži 159
Řešení potíží 160
Technické údaje 161
SK
Bezpečnostné informácie 164
Ovládacie prvky na paneli 165
Ostatné pokyny 166
Všeobecná obsluha 167
Obsluha CD prehrávača 168
Obsluha tunera 169
RDS (rádiový dátový systém) 170
Obsluha USB/SD/MMC 172
Prehrávanie súborov MP3/WMA 173
Ponuka Funkcia 175
Elektrické pripojenia 177
Návod na inštaláciu 178
Systém proti krádeži 179
Riešenie problémov 180
Špecifikácie 181
PL
Informacje dotyczące bezpieczeństwa 184
Elementy na panelu przednim 185
Pozostałe instrukcje 186
Ogólna obsługa 187
Obsługa odtwarzacza CD 188
Obsługa tunera 189
Usługa RDS 190
Odtwarzanie plików MP3 z nośników USB/
SD/MMC 192
Odtwarzanie plików MP3/WMA 193
Funkcje menu 195
Połączenia elektryczne 197
Wskazówki dotyczące montażu 198
Zabezpieczenie przed kradzieżą 199
Rozwiązywanie problemów 200
Dane techniczne 201
HU
Biztonsági információk 204
Vezérlőelemek a panelen 205
Egyéb utasítások 206
Általános működés 207
CD lejátszó kezelése 208
Rádió kezelése 209
RDS/Radio Data System 210
USB/SD/MMC útmutató 212
MP3/WMA fájlok lejátszása 213
Menü funkciók 215
Elektromos csatlakozások 217
Szerelési útmutató 218
Lopásgátló rendszer 219
Hibakeresés 220
Műszaki adatok 221
RU
Меры предосторожности 224
Кнопки управления 225
Другие сведения 226
Общие сведения об использовании 227
Использование проигрывателя CD-дисков 228
Использование тюнера 229
RDS (Radio Data System, система передачи
данных по каналу радиотрансляции) 230
Использование USB/SD/MMC 232
Воспроизведение файлов MP3/WMA
Функции меню 235
Электрические соединения 237
Руководство по установке 238
Система защиты от кражи 239
Поиск и устранение неисправностей 240
Технические характеристики 241
2CR210GP
270114_CR210GP_manual 01 UK_DE_FR.indd 2 1/27/14 11:38 AM

3
UK
CR210GP
WELCOME
Thank you for purchasing this product.
Please read through these operating instructions so you will know how to operate your model properly.
After you have finished reading the instructions, keep this manual in a safe place for future reference
270114_CR210GP_manual 01 UK_DE_FR.indd 3 1/27/14 11:38 AM

4
UK
CR210GP
PRECAUTIONS - CAUTION
PRECAUTIONS
• Use only in a 12-volt DC negative-ground electrical system.
• Disconnect the vehicle’s negative battery terminal while fitting and connecting the unit.
• When replacing the fuse, be sure to use one with an identical amperage rating.
Using a fuse with a higher amperage rating may cause serious damage to the unit.
• DO NOT attempt to disassemble the unit.
Laser beams from the optical pickup are dangerous to the eyes.
• Make sure that pins or other foreign objects do not get inside the unit;
they may cause malfunctions, or create safety hazards such as electrical shock or laser beam
exposure.
• If you have parked the car for a long time in hot or cold weather, wait until the temperature in the
car becomes normal before operating the unit.
• Keep the volume at a level at which you can hear outside warning sounds (horns sirens, etc.).
CD NOTES
• Playing a defective or dusty CD can cause dropouts in sound.
• Hold CDs as illustrated.
• Do not touch the unlabeled side.
• Do not attach any seal, label or data protection sheet to either side of a disc.
• Do not expose a CD to direct sunlight or excessive heat.
• Wipe a dirty CD from the center outward with a cleaning cloth.
Never use solvents such as benzene or alcohol.
• This unit cannot play 3-inch (8cm) CDs.
Never insert a 3-inch CD or an irregularly shaped CD. The unit may not be able to eject it, resulting in
a malfunction.
Before Operation
• Do not raise the volume level too much, as this will block outside sounds, making driving dangerous.
Stop the car before performing any complicated operation.
CAUTION
• DO NOT open covers and do not repair yourself. Consult the dealer or an experienced technician for
help.
* In addition to ordinary CDs, this unit can play back a CD-R or CD-RW,MP3.
270114_CR210GP_manual 01 UK_DE_FR.indd 4 1/27/14 11:38 AM

5
UK
CR210GP
PANEL CONTROLS
1. - Power on
- Mute
- Press for more than 2 seconds to power off.
2. - Radio tune
- Track skip/seek
3. - Press to pop out/push back the knob.
- Rotate to adjust volume level
4. Radio
- Disc play (when disc inserted)
- USB (when USB inserted)
- Card (when SD/MMC inserted)
- AUX-in
5. – Band switch:
FM1->FM2->FM3->AM1->AM2
6. - Press to select VOL/BAS/TRE/BAL/FAD, rotate the knob to adjust level.
- Hold it to system menu.
7. - Track playback
Button 1: - Play/Pause function.
- Long press if you want to start playback from the beginning of the first track of your disc.
Button 2: - Intro play (10 sec)
Button 3: - Track repeat play
Button 4: - Track random play
Button 5: - MP3 track - skip 10 down
- Hold it to go to previous folder.
Button 6: - MP3 track skip 10 up
- Hold it to go to next folder.
- Radio preset
Press 1~6 to listen to a preset station.
Hold 1~6 to store station.
8. - Program type
9. - AUX-in jack
10. - USB connector
11. - Press to turn RDS AF on/off.
- Long press to turn RDS TA on/off.
12. - Panel release
13. - Display switch
14. - AMS: Radio preset scan
Radio auto preset
- SEARCH: MP3 track/file/character search.
1
2
345
10
12
68
9
7
111314
TA
AF
PTY
270114_CR210GP_manual 01 UK_DE_FR.indd 5 1/27/14 11:38 AM

6
UK
CR210GP
OTHER INSTRUCTIONS
Press the button to open the panel.
1. Disc eject
2. Reset hole
Note: Pressing the RESET hole will erase the clock setting and stored stations.
3. Panel status indicator Lights up when you flip the panel down; Flashes when you remove the panel.
4. Disc slot, insert the disc.
5. SD/MMC card slot
134 25
270114_CR210GP_manual 01 UK_DE_FR.indd 6 1/27/14 11:38 AM

7
UK
CR210GP
GENERAL OPERATION
Power On/Off Button
Press the POWER button to turn the unit on when the vehicle ignition switch is on. Press and hold the
button to turn the unit off.
Adjust Volume level
Rotate the VOL/MENU control to adjust volume level. Rotate it clockwise to increase and anticlockwise to
decrease the volume.
Audio Mute
Press the MUTE button to mute the volume from the system. “MUTE” will appear on the display panel
and the volume will be muted.
Press the MUTE button again, or rotate/press the VOL/MENU control to return the volume level to the
setting in use before the Mute function was activated.
Audio Controls
To adjust the bass, treble, balance and fader, press the VOL/MENU control until the appropriate audio
control appears on the
display panel. Within five seconds, rotate the VOL/MENU control to adjust the audio settings for the
selected function.
Mode Button (SRC)
Press the SRC button to change between Radio, DISC (when disc is in), USB (when USB is connected),
Card(when SD/MMC card is in) or AUX play.
Auxiliary Input
To access an auxiliary device:
1. Connect the portable audio player to the AUX interface on the front panel.
2. Press the SRC button to select Aux-In mode.
Press SRC again to cancel Aux-In mode and go to the next mode.
Display Selector (DISP)
This unit can display either the clock time or radio frequency/CD player functions.
Ordinarily, the radio frequency or CD player track indication is displayed, but the unit will display the
time when the DISP button is pressed. The time will display for approximately 5 seconds then return to
the radio or CD player function display.
Setting the Clock
The correct time of day can be set by pressing and holding the DISP button.
To set the clock, perform the following steps:
1. Turn the vehicle ignition and radio on.
2. Press the DISP button to view the clock.
3. With the clock visible on the display, press and hold the DISP button until the time display flashes.
4. Within 5 seconds, rotate the VOL/MENU control counter clockwise to adjust the minutes to the desired
setting. To change the hour, rotate the VOL/MENU control clockwise to adjust the hour to the desired
time.
270114_CR210GP_manual 01 UK_DE_FR.indd 7 1/27/14 11:38 AM

8
UK
CR210GP
CD PLAYER OPERATION
Inserting a Disc
With the label surface facing up, fully insert a compact disc into the disc slot until the mechanism
engages and pulls the disc in. Play will automatically begin from the first track on the disc.
NOTE: The unit is designed for play of standard 5” (12 cm.) compact discs only. Do not attempt to use
3” (8 cm.) CD singles in this unit, either with or without an adaptor, as damage to the player and/or the
disc may occur.
Disc Eject Button
Press the eject button to stop disc play and eject the disc. The unit will revert to radio operation. Discs
may be ejected with the vehicle ignition switch on or off. If an ejected disc is not removed from the disc
slot within 10 seconds of being ejected, the disc will be re-inserted automatically.
NOTE: To prevent a disc from accidentally being damaged, always remove the disc from the unit when
disc play is finished.
CD Play/Pause Selector
Press the 1 >/|| button to pause disc playback.
Press 1 >/|| again to resume disc playback.
Seek Up/Next Track
Press the next track >>| button during disc play to select the beginning of the next track.
Seek Down/Previous Track
Press the previous track |<< button during disc play to select the beginning of the current track. Press
twice to select the beginning of the previous track.
Cue/Review Functions
High-speed audible search to any section of the disc can be made by the Cue and Review functions.
Press and hold the next track >>| button to advance rapidly forwards or the previous track |<< button
to advance rapidly backwards.
Intro Play Selector
During disc play, press the 2/INT button to select “INT ON” and play the first 10 seconds of each track.
Press 2/INT again to select “INT FOLD” and play the first 10 seconds of each track in the current folder.
When a desired track is reached, press the 2/INT button to select “INT OFF” and play the current track.
Track Repeat Play Select
During disc play, press the 3/RPT button to select “RPT ON” and repeatedly play the selected track.
Press 3/RPT again to select “RPT FOLD” and repeatedly play all tracks in the current folder. Repeat play
will continue until 3/RPT is pressed to select “RPT OFF”.
Random Play Select
During disc play, press the 4/RDM button to select “RDM ON” and play all tracks on the disc in random,
shuffled order. Press 4/RDM again to select “RDM FOLD” and randomly play all songs in the current
folder. In Random Play mode, you can press the tune/track buttons to select tracks in a random order
instead of the normal progression. Press 4/ RDM again to select “RDM OFF” and cancel Random Play
mode.
270114_CR210GP_manual 01 UK_DE_FR.indd 8 1/27/14 11:38 AM

9
UK
CR210GP
TUNER OPERATION
Band
During radio play, press the BAND button to choose between three FM, and two MW bands.
The indication “MW”,“FM” appears on the display panel according to your selection.
Up Tuning
Press the seek up >>| button to tune stations upward step-by-step. The current frequency will be shown
in digital format on the display panel.
Press and hold the seek >>| button to the next available station.
Down Tuning
Press the seek down |<< button to tune stations downward step-by-step.
Press and hold the seek down |<< button to the previous available station.
Auto Store
Press the AMS button to scan preset stations 1-6. Hold it to automatically select six strong stations and
store them in the current band.
The new stations replace stations already stored in that band.
To restore the original preset stations, press both DISP and 3 buttons on the panel for more than 2
seconds, the unit will load the factory radio settings and power off.
270114_CR210GP_manual 01 UK_DE_FR.indd 9 1/27/14 11:38 AM

10
UK
CR210GP
RDS ( Radio Data System )
RDS service availability varies with location. Please understand if RDS service is not available in you
area, the following features are not available.
RDS Basics
AF (Alternative Frequency): When the radio signal strength is poor, enabling the AF function will allow
the unit to automatically search another station with the same PI (Program Identification) as the current
station but with stronger signal strength.
PS (Program Service name): The name of station will be display instead of frequency.
AF Mode: Press AF button to switch AF mode on and off.
AF on: AF function is activated.
AF off: AF function is disabled.
Note: AF indicator on LCD will flash until RDS information is received. If RDS service is not available in
your area, turn off the AF mode.
REG Mode: Press AF for more than 2 seconds to switch REG mode on and off.
REG on: AF function will implement the regional code (of the PI) and only stations in the current region
can be tuned automatically.
REG off: AF function will ignore the regional code(of the PI) and stations in the other regions can also be
tuned automatically.
CT Service ( Clock Time )
When receiving an RDS station, the CT (Clock Time) service automatically adjusts the time.
Traffic Announcements
Some RDS FM stations periodically provide traffic information.
TP (Traffic Program Identification)
Broadcasting of traffic information.
TA (Traffic Announcements Identification)
Radio announcements on traffic conditions.
TA Mode: Press TA to turn on/off the TA function. When TA mode is turned on, the TA indicator will blink.
When traffic announcement is received, the TA indicator will display. The unit will temporarily switch
to the tuner mode (regardless of the current mode) and begin broadcasting the announcement at TA
volume level. After the traffic announcement is over, it will return to the previous mode and volume level.
When TA is turned on, SEEK, SCAN, AMS function can only be received or saved when traffic program
identification (TP) code is received.
270114_CR210GP_manual 01 UK_DE_FR.indd 10 1/27/14 11:38 AM

11
UK
CR210GP
RDS ( Radio Data System )
EON (Enhanced Other Networks)
When EON data is received, the EON indicator lights and the TA and AF functions are enhanced.
TA: Traffic information can be received from the current station or stations in other network.
AF: The frequency list of preset RDS stations is updated by EON data. EON enables the radio to make
fuller use of RDS information. It constantly updates the AF list of preset stations, including the one that
currently tuned into. If you preset a station around the area at your home, you will later be able to re-
ceive the same station at an alternative frequency, or any other station serving the same program, EON
also keeps track of locally available TP stations for quick reception.
PTY Reception ( Program Type )
RDS FM stations provide a program type identification signal.
Example: news, rock, info, sport, etc.
PTY Type Preset
Press PTY button once to enter the MUSIC type or press “ PTY ” twice to enter the SPEECH type. Then
use function to select the desired program type. The selected PTY type is shown and searching starts if
no other function is selected for 2 seconds.
If there is no corresponding program type, NO PTY is shown and the unit will return to normal mode.
270114_CR210GP_manual 01 UK_DE_FR.indd 11 1/27/14 11:38 AM

12
UK
CR210GP
1. Loading SD/MMC Card
Open the panel, insert the SD/MMC card into the slot, with the front side to
the left.
The unit will play the music automatically.
2. Take out SD/MMC Card
Press SRC button and switch to non CARD mode, open the panel, slight press
SD/MMC card, which will pop out for removal.
3. Loading USB equipment
Open the cap, insert the USB device into the connector and the unit will play
the music in the USB device automatically.
4. Take out USB equipment
Press the SRC button and switch to non USB- DRIV mode, then remove the
USB device, close the cap.
USB/SD/MMC Notes
USB functions (flash memory type) MP3 music play
1. SD/ MMC card support.
2. USB flash memory 2 in 1 (SD/MMC ) support.
3. Fat 12/fat 16/fat 32 is possible.
4. File name : 32 byte/dir name : 32 byte/tag name : 32 byte
5. Tag (ID3 tag ver 2.0)
- title/artist/album : 32 byte support.
6. Multi card reader not support.
7. USB 1.1 support, USB 2.0 support (It can not support USB 2.0 speed. Just,
get the same speed with USB 1.1).
Not all kinds of USB devices are compatible with the unit.
USB/SD/MMC MP3 PLAYBACK
270114_CR210GP_manual 01 UK_DE_FR.indd 12 1/27/14 11:38 AM

13
UK
CR210GP
Display Information
During playback, ID3 tag information display will scroll on the screen:
FOLDER, FILE, ALBUM, TITLE, ARTIST and Track Number/Elapsed Time.
Folder Up/Down
Press the 5/DN button to go to the previous folder. Press the 6/UP button to go to the next folder.
Direct Song/File Access
1. Press the AMS button once and press the knob to enable direct track searching.
2. Rotate the VOL/MENU control to select a digit.
3. Press the VOL/MENU control to confirm entry and the next digit will flash.
4. Rotate the VOL/MENU control to select desired digit.
5. Repeat above steps to enter subsequent digits, as necessary.
NOTE: The unit will only allow the selection of digits that correspond with the number of files on the
media you are searching.
6. Once the track number appears on the screen, long press the VOL/MENU control to play the selected
song/file.
Searching Folders/Files
1. Press the AMS button twice and press the knob to access the file search option.
2. Rotate the VOL/MENU control to select the desired directory/song.
3. Press the VOL/MENU control to view the files inside the selected directory.
4. Rotate the VOL/MENU control to select the song/file. Long press the VOL/MENU control to play the
selected song/file.
Searching by Name (CHAR-SCH)
1. Press the AMS button three times and press the knob to access the character search option.
2. Rotate the VOL/MENU control to select the characters A-Z, _ , - , + , and 0-9 for the first character.
3. Press the VOL/MENU control to confirm entry of the character and move to the next digit.
4. Repeat for up to eight characters.
5. Press and hold the VOL/MENU control for 2 seconds to begin the search.
6. If a directory is found, rotate the VOL/ MENU control to select the song/file in this directory/folder.
7. Press and hold the VOL/MENU control for 2 seconds to play the selected song/file.
“NO MATCH” appears if there is no file beginning with the search string entered.
PLAYING MP3/WMA FILES
270114_CR210GP_manual 01 UK_DE_FR.indd 13 1/27/14 11:38 AM

14
UK
CR210GP
PLAYING MP3/WMA FILES
MP3 Overview
• MP3 is short for MPEG Audio Layer 3 and refers to an audio compression technology standard.
• This product allows playback of MP3 files on CD-R or CD-RW discs.
• The unit can read MP3 files written in the format compliant with ISO 9660. However it does not sup-
port the MP3 data written by the method of packet write.
• The unit can not read an MP3 file that has a file extension other than “.mp3”.
• If you play a non-MP3 file that has the “.mp3” extension, you may hear some noise.
• In this manual, we refer to what are called “MP3 file” and “folder” in PC terminology as “Track” and
“Album”, respectively.
• Maximum number of directory level is 8, including the root directory. Maximum number of files and
folders per disc is 256.
• The unit may not play tracks in the order of track numbers.
• The unit plays only the audio tracks if a disc contains both audio tracks and MP3 files.
• When playing a disc of 8kbps or VBR*, the elapsed playing time in the display window will not be cor-
rect and also the intro play may not function properly.
*VBR: Variable Bit Rate.
Note on creating your own CD-Rs or CD-RWs containing MP3 files
• To enjoy high quality sound, we recommend converting to MP3 files with a sampling frequency of 44.1
kHz and a fixed bit rate of 128 kbps.
• DO NOT store more than 256 MP3 files per disc.
• For ISO 9660-compliant format, the maximum allowable depth of nested folders is 8, including the
root directory(folder).
• When CD-R disc is used, playback is possible only for discs which have been finalised.
• Make sure that when MP3 CD-R is burned that it is formatted as a data disc and NOT as an audio disc.
• You should not write non-MP3 files or unneeded folders along with MP3 files on the CD-R otherwise it
takes a long time until the unit will start to play MP3 files.
• With some CD-R media, data may not be properly written depending on their manufacturing quality. In
this case, data may not be reproduced correctly. High quality CD-R disc is recommended.
• Up to 16 characters are displayed for the name of an Album or a Track. ID3 TAG version 1.x is required.
• Note that the unit may not play tracks in the order that you wrote them to the disc.
270114_CR210GP_manual 01 UK_DE_FR.indd 14 1/27/14 11:38 AM

15
UK
CR210GP
Press VOL knob for more than 2 seconds to enter menu mode, then each press changes the mode
as follows: TA mode -> MASK mode -> TA VOL mode ->RETUNE mode -> DSP mode -> ESP mode
->MULT mode -> LOUD ON/OFF mode
-> BEEP ON/OFF -> SEEK1/2 mode(only in tuner mode) -> ST/MO mode(only in tuner mode) -> LOCAL/
DX mode(only in tuner mode) -> VOL mode -> 12/ 24 HOUR mode
TA mode
Rotate the knob to choose TA ALARM or TA SEEK mode. If the TA (traffic announcements) is turned on
and there is no traffic program identification code received in the specified time, no TA/TP will display
and either TA ALARM or TA SEEK will be activated.
TA ALARM mode :Alarm is turned on.
TA SEEK mode: TA SEEK is automatically activated.
MASK mode
Rotate the knob to choose MASK DPI or MASK ALL mode.
In some cases, the AF function may be influenced by some interference, examples are signals with
strong field but without the RDS data. For this reason, the unit has two options to avoid the above
interference.
MASK DPI mode :
Only AF which has different program identification is masked.
MASK ALL mode :
The AF which has different program identification and NO RDS signal with high field strength is masked.
TA VOL mode
Rotate the knob to adjust TA volume level.
RETUNE mode
Rotate the knob to choose RETUNE-S or RETUNE-L.
RETUNE-S or RETUNE-L is time length selection of TA SEEK retune interval.
RETUNE-S: Short, TA SEEK retune interval is 45 seconds.
RETUNE-L: Long, TA SEEK retune interval is 180 seconds.
Remark: RETUNE mode functions for TA during TA SEEK mode only.
DSP mode
Rotate the knob to choose DSP sound effect: POP -> FLAT -> CLASSIC -> ROCK -> OFF
EPS mode
ESP 12s: Selected as CD-ESP time 12 seconds, MP3-ESP time >100 seconds.
ESP 45s: Selected as CD-ESP time 45 seconds, MP3-ESP time >100 seconds.
MENU FUNCTION
270114_CR210GP_manual 01 UK_DE_FR.indd 15 1/27/14 11:38 AM

16
UK
CR210GP
MULT mode
MULT OFF: Mixed CD, one session CD.
MULT ON: Mixed, extra, multi session CD.
LOUD ON/OFF
Rotate the knob to choose loudness on or off.
BEEP ON/OFF mode
Rotate the knob to choose button beep sound on or off.
SEEK 1/2 mode
Rotate the knob to choose radio seek mode 1 or 2.
SEEK 1: Searching station will stop when the next station is received.
SEEK 2: Searching station will stop when |<< or >>| button is released and next station is received.
STEREO/MONO mode
Rotate the knob to choose FM stereo or mono.
LOCAL/DX mode
Rotate the knob to choose tuner sensitivity local or distant.
VOL mode
Rotate the knob to choose volume last/adjust mode.
VOL LAST: The turn-on volume level is the volume of latest power off.
VOL ADJUST: Press the knob to enter A-VOL mode, rotate to set the turn-on volume level.
12/24 HOUR mode
Rotate the knob to choose time format: 12 or 24 HOUR.
MENU FUNCTION
270114_CR210GP_manual 01 UK_DE_FR.indd 16 1/27/14 11:38 AM

17
UK
CR210GP
ELECTRICAL CONNECTIONS
Wiring Diagram
(Black)
ANTENNA
Rear line out
(Gray)
R(Red)
L(White)
Location Function
Connector A Connector B
1 Rear Right (+) / Purple
2 Rear Right (-) / Purple with Black Stripe
3 Front Right (+) / Gray
4 Battery 12V(+) / Yellow Front Right (-) / Gray with Black Stripe
5ANT/AMP control / Blue
with white stripe Front Left(+) / White
6 Front Left(-) / White with Black Stripe
7 ACC+ / Red Rear Left (+) / Green
8 Ground / Black Rear Left (-) / Green with Black Stripe
270114_CR210GP_manual 01 UK_DE_FR.indd 17 1/27/14 11:38 AM

18
UK
CR210GP
INSTALLATION GUIDE
Installation Opening
This unit can be installed in any dashboard having an opening as shown below. The dashboard should
be 4.75mm - 5.56mm thick in order to be able to support the unit.
If the opening is too small, carefully cut or file as necessary until the sleeve easily slides into the open-
ing. Do not force the sleeve into the opening or cause it to bend or bow. Check for sufficient space
behind the dashboard for the unit chassis.
Install the unit
Important: Remove the two screws on the top of the unit before installation.
Otherwise, the player will not work.
1. Inset mounting collar into the dashboard, and bend the mounting tabs out with a screwdriver.
Make sure that lock lever is flush with the mounting collar (not projecting outward).
2. Secure the rear of the unit. After fixing mounting bolt and power connector, fix the rear of the unit to
the car body by rubber cushion.
3. Insert trim plate.
183mm
52mm
Mounting bolt
rubber cushion.
1
2
3
Remov
e the
tw
o screws.
lock lever
270114_CR210GP_manual 01 UK_DE_FR.indd 18 1/27/14 11:38 AM

19
UK
CR210GP
ANTI-THEFT SYSTEM
This unit is equipped with a detachable panel.
Removing this panel makes the radio totally inoperable.
Remove the detachable panel
1. Switch off the power of the unit.
2. Press button to flip down the panel.
3. Hold the right part of the panel. Press to the left side, then remove the panel.
4. Place the panel into the case and take it with you when you leave the car.
Install the panel
1. Hold the panel and ensure the panel faces downward, and position left side of the panel in the panel
bracket, then insert the right part.
2. Press the top of panel until it locks.
Remove the unit
1. Remove the panel and the trim plate.
2. Insert both T-Keys into hole on the front of the set until they lock.
3. Pull out the unit.
Reset
1
2
1
2
Reset
Press the RESET button with a pointed object to reset the unit to
the original status.
Note: Press the RESET button will erase the clock setting.
270114_CR210GP_manual 01 UK_DE_FR.indd 19 1/27/14 11:38 AM

20
UK
CR210GP
The following checklist can help you solve some problems which you may encounter when using the
unit. Before consulting it, check the connections and follow the instructions in the user manual. Do not
use the unit in abnormal condition, for example without sound, or with smoke or foul smell can cause
fire or electric shock, immediately stop using it and call the store where you purchased it.
TROUBLESHOOTING
Problem Possible cause Solution
General
The unit will not switch on. Car ignition is not on. Turn your car key in the ignition.
Cable is not properly connected. Check cable connection.
Fuse is burnt. Replace fuse with a new fuse of the
same capacity.
No sound Volume is set at minimum or the mute
function is on.
Check the volume or switch the
mute function off.
The unit or screen does not work normally. The unit system is unstable. Press the RESET button.
DISC mode
The appliance will not play discs. The disc is inserted incorrectly. Disc must be inserted with the label
side facing up. Clean the disc and
check for damage. Try another disc.
The disc is dirty or damaged.
Sound skips due to vibration. Mounting angle is over 30˚. Adjust mounting angle to less
than 30˚.
Mounting is unstable. Mount the unit securely with the
supplied parts.
TUNER mode
Unable to receive stations. The antenna is not connected properly. Connect the antenna properly.
Poor quality reception of radio station The antenna is not fully extended or it
is broken.
Fully extend the antenna and if
broken, replace it with a new one.
Preset stations are lost. The battery cable is not properly con-
nected.
Connect the permanent live on the
unit to the permanent live on the
vehicle.
USB/SD/MMC mode
Unable to insert USB device or SD/MMC card. The memory card or USB device has
been inserted the wrong way round.
Insert it the other way around.
The USB device or SD/MMC card cannot be read. NTFS format is not supported. Check that the file system is in FAT
or FAT32 format. Due to different
formats, some models of storage
devices or MP3 players may not
be read.
270114_CR210GP_manual 01 UK_DE_FR.indd 20 1/27/14 11:38 AM
