Grand Cru GC166 Series User manual

BUILT
UNDER
& FREE
STANDING
@GrandCruWineFridges
www.grandcruwinefridges.com.au
WINE FRIDGE
GC166, GC100 SERIES
OWNERS MANUAL
NEED HELP? CALL
1300 935 683
GRCU4731-User Guide GC100 GC166.indd 1GRCU4731-User Guide GC100 GC166.indd 1 20/9/22 5:14 pm20/9/22 5:14 pm

GRCU4731-User Guide GC100 GC166.indd 2GRCU4731-User Guide GC100 GC166.indd 2 20/9/22 5:14 pm20/9/22 5:14 pm

3
IMPORTANT SAFETY INFORMATION .............................................................................. 4
STRUCTURE & INSTALLATION ....................................................................................... 7
OPERATING THE WINE FRIDGE ...................................................................................... 9
WORKING CLIMATE ...................................................................................................................9
WINE STORAGE ..........................................................................................................................9
RECOMMENDED TEMPERATURES ........................................................................................10
CONTROL PANEL ........................................................................................................... 11
FOR SINGLE ZONE ...................................................................................................................11
FOR DUAL ZONE ......................................................................................................................11
POWER ON/OFF CONTROL .....................................................................................................12
UNLOCKING THE CONTROL PANEL ......................................................................................12
INTERIOR LIGHTING ON/OFF CONTROL ................................................................................12
TEMPERATURE DISPLAY WINDOW ........................................................................................12
TEMPERATURE SETTING ........................................................................................................12
SELECTING FAHRENHEIT (°F) & CELSIUS (°C) DISPLAY .....................................................13
CARE & MAINTENANCE .................................................................................................14
CLEANING THE WINE FRIDGE ................................................................................................14
POWER FAILURE .....................................................................................................................14
MOVING THE WINE FRIDGE ....................................................................................................14
ENERGY SAVING TIPS..............................................................................................................14
TROUBLESHOOTING ......................................................................................................15
REVERSING THE DOOR SWING ......................................................................................16
WARRANTY, SERVICE AND SUPPORT ............................................................................19
STORING AND STACKING ............................................................................................. 20
DIFFERENT SHAPES & SIZES .................................................................................................20
STACKING FOR AGEING ..........................................................................................................20
STACKING FOR ACCESSIBILITY ..............................................................................................20
FREQUENTLY ASKED QUESTIONS .................................................................................21
WINE STORAGE GUIDE ................................................................................................. 25
WINE TEMPERATURE SERVING GUIDE ......................................................................... 27
CONTENTS
GRCU4731-User Guide GC100 GC166.indd 3GRCU4731-User Guide GC100 GC166.indd 3 20/9/22 5:14 pm20/9/22 5:14 pm

4
IMPORTANT SAFEGUARDS
When using an electrical appliance, basic
precautions should always be followed to
reduce the risk of fire, electric shock, and
injury to persons, including the following:
FOR YOUR SAFETY
Read all instructions carefully, even if you
are quite familiar with the appliance.
• The appliance is intended to be used
exclusively for the storage of wine.
• Use this appliance only as described in this
manual. Other uses not recommended may
cause fire, electric shock or personal injury.
• This appliance is not intended for use by
young children or infirm persons unless
they have been adequately supervised
by a responsible person to ensure that
they can use the appliance safely.
• Young children should be
supervised to ensure that they do
not play with the appliance.
• To protect against the risk of electric
shock, DO NOT IMMERSE the unit, cord,
or plug in water or spray any other liquid.
• Unplug the appliance from the plug socket
when not in use, when moving from one
location to another and before cleaning.
IMPORTANT SAFETY INFORMATION
• To disconnect the appliance, grip
the plug and pull it from the wall
outlet. Never pull by the cord.
• Do not operate the appliance in
the presence of explosive and/
or flammable fumes.
• Do not place the appliance or any of
its part near an open flame, cooking
or other heating appliance.
• Do not operate the appliance with a damage
cord or plug, if the product malfunctions, or
if it is dropped or damaged in any manner.
• The use of attachments not recommended
by the manufacturer may be hazardous.
• Place the unit on a dry level surface.
• Do not operate if the housing
is removed or damaged.
• A loose fit between the AC outlet
(receptacle) and plug may cause
overheating and a distortion of the
plug. Contact a qualified electrician
to replace loose or worn outlet.
• Locate the unit away from direct
sunlight and sources of heat
(stove, heater, radiator, etc.).
• This appliance is CFC and HFC-free and
contains small quantities of Isobutane
(R600a), an environmentally friendly coolant.
• You must ensure that the cooling
circuit is undamaged when installing
This manual contains important
information including safety and
installation instructions of the appliances.
Please read it carefully before use and
follow all safety information & instructions.
It is recommended to keep this manual for
easy reference so that you can be familiar
with the operation of the appliance.
BUILT UNDER &
FREE STANDING
WINE FRIDGE
GC166, GC100 SERIES
GRCU4731-User Guide GC100 GC166.indd 4GRCU4731-User Guide GC100 GC166.indd 4 20/9/22 5:14 pm20/9/22 5:14 pm

5
the appliance. However, if it becomes
damaged, avoid proximity to open fires
and heat sources of all kinds. The room
in which the appliance is located should
be ventilated for a few minutes.
• Never use an appliance with
a damaged circuit.
Warning: Do not operate
any shock. Do not
immerse the unit, appliance
• Do not attempt to repair or replace
any part of your appliance unless it
is specifically recommended in this
manual. All other servicing should be
referred to a qualified technician.
• Replace all panels after
service before operating.
• Use two or more people to move and
install the appliance. Failure to do so
can result in back or other injury.
• Never clean appliance parts with
flammable fluids. These fumes can create
a fire hazard or explosion. And do not
store or use gasoline or other flammable
vapors and liquids in the vicinity of this
or any other appliance. The fumes can
create a fire hazard or explosion.
• Do not connect or disconnect the electric
plug when your hands are wet.
• It is recommended that a separate
circuit, serving only your appliance be
provided. Use receptacles that cannot
be turned off by a switch or pull chain.
Warning: To reduce the
risk of fire, electric shock
or personal injury, unplug or
disconnect the appliance from the
power supply before servicing.
If you are experiencing problems, check the
Troubleshooting Guide at the back of this
manual. It lists causes of minor operating
problems that you can correct yourself.
DISPOSAL OF OLD APPLIANCE
• Dispose of your appliance
packaging properly.
• Refrigeration equipment must be properly
disposed of in a way which protects the
environment. This applies to your old
appliance and to your new unit once it
has reached the end of its service life.
Warning: Please ensure that
old, worn appliances are
rendered unusable before disposal
by removing the plug, cutting the
network cable, and removing or
destroying any snap fastenings
or bolts. You will thus prevent
children from locking themselves
in the appliance during play (risk
of suffocation) or endangering
their lives in any other way.
DISPOSAL INSTRUCTIONS
• The appliance must not be
disposed of in the dustbin or with
normal household rubbish.
• The coolant circuit, particularly the
heat exchanger at the back/bottom
of the unit, must not be damaged.
• The symbol on the product or its
packaging indicates that this product is not
to be handled as normal household waste
but is to be taken to a recycling collection
point for electrical and electronic goods.
By correctly disposing of this product you
are contributing to the protection of the
environment and to the health of your
fellow human beings. Improper disposal
endangers health and the environment.
• Further information about the
recycling of the product may be
obtained from your town hall, refuse
collection department or the store
where you purchased the product.
GRCU4731-User Guide GC100 GC166.indd 5GRCU4731-User Guide GC100 GC166.indd 5 20/9/22 5:14 pm20/9/22 5:14 pm

6
BEFORE USING THE APPLIANCE
Before using the appliance, please properly
position and install it as described in this
manual. To avoid the risk of fire, electrical
shock or injury when using the appliance,
please follow these basic precautions:
• The appliance is intended to be used
exclusively for the storage of wine.
• Make sure the voltage/current marked
on the rating label corresponds
with your supply voltage. Plug into
a standard 10amp 3-pin outlet.
• It is recommended that a separate circuit,
serving only your appliance be provided.
• Never clean the appliance parts with
flammable fluids which may create a fire
hazard or explosion. And do not store or
use gasoline or other flammable vapours
and liquids in the vicinity of the appliance.
• Do not connect or disconnect the electric
plug when your hands are wet.
• Unplug the appliance or disconnect
power before cleaning, maintenance
or servicing. Failure to do so can
result in electrical shock or death.
• Do not attempt to repair or replace
any part of the appliance unless it is
specifically recommended in this material.
All other servicing should be referred
to a qualified service technician.
• To ensure proper ventilation for the
appliance, the front of the unit must be
completely unobstructed. Locate the unit
away from direct sunlight and sources
of heat (stove, heater, radiator, etc.).
• The fuse (or circuit breaker) size
should be 10 amp or higher.
• It is important for the appliance to be
leveled in order to work properly. You may
adjust the appliance’s feet to level it.
• This appliance is intended for use by
persons with sufficient experience and
knowledge of electrical appliances.
Any other persons (including children)
should be supervised or given instruction
concerning use of the appliance by a
person responsible for their safety.
• Children should be supervised to ensure
that they do not play with the appliance.
• Do not use solvent-based cleaning agents
of abrasives on the interior. These cleaners
may damage or discolor the interior.
• Do not use this appliance for other
than its intended purpose.
• The use of attachments not recommended
by the manufacturer may be hazardous.
• When you dispose the appliance, take off
the door and leave the shelves in place
so that children may not easily climb
inside. And make sure the coolant circuit,
particularly the heat exchanger at the
back/bottom of the unit is not damaged.
• The symbol on the product or its
packaging indicates that this product is not
to be handled as normal household waste
and it is to be taken to a recycling collection
point for electrical and electronic goods.
GRCU4731-User Guide GC100 GC166.indd 6GRCU4731-User Guide GC100 GC166.indd 6 20/9/22 5:14 pm20/9/22 5:14 pm

7
The following pictures only show the structure of the appliance. The dimension
and shelf quantity may differ among the models of the same series.
STRUCTURE & INSTALLATION
Dual Zone Structure
Single Zone Structure
Upper Right Hinge
Upper Right Hinge
Door
Door
Touch-Key Control
Panel & Digital Display
Touch-Key Control
Panel & Digital Display
Outside Cabinet
Outside Cabinet
Handle
Handle
Front Louvre
Front Louvre
Leveling Foot
Leveling Foot
Deep Shelf
Deep Shelf
Shallow Shelf
Shallow Shelf
Lock
Lock
GRCU4731-User Guide GC100 GC166.indd 7GRCU4731-User Guide GC100 GC166.indd 7 20/9/22 5:14 pm20/9/22 5:14 pm

8
UNPACKING AND CLEANING
THE WINE FRIDGE
• Remove the exterior and
interior packing materials.
• Use a soft cloth to clean the interior
surface with lukewarm water.
• If required install the door handle provided
with the appliance by following these steps:
1st Step - Remove the gasket
on the internal door to expose
the two screw holes.
2nd Step - Install the handle with
the screws and washers provided.
3rd Step - Restore the gasket.
LOCKING AND UNLOCKING THE DOOR
• Lock is an optional function. If your Wine
Fridge has such function, a key should be
attached inside the packing of this manual.
• Insert the key into the lock and turn
it counter clockwise to unlock the
door. To lock It, please follow the
reverse operation. Please keep
the key in a safe place.
ACCESSORY INSTALLATION BEFORE OPERATING
DO NOT TURN ON FOR AT LEAST 24 HOURS AFTER DELIVERY
Let the appliance stand upright for approximately 24 hours before
connecting it to the power source, which helps to reduce the possibility
of a cooling-system malfunction from handling during transportation.
Flat
Washer
Screw
Gasket
Screw
Handle
Door
Frame
GRCU4731-User Guide GC100 GC166.indd 8GRCU4731-User Guide GC100 GC166.indd 8 20/9/22 5:14 pm20/9/22 5:14 pm

9
WINE STORAGE
• The standard shelves are designed
perfectly for Bordeaux style bottle
storage. The maximum bottle loading
may vary subject to the different size or
dimension of wine bottles you store.
• The shelves can be pulled out by
approximately 2/3 for easy access
to the wine storage. There are two
designs for the pull-out shelves:
- The shelves are without telescopic
rails, but with a plastic Stopper on
each sides of the shelf track to prevent
bottles from falling. (MODEL GC166SS)
- The shelves are with Telescopic Rails
which has stoppers by themselves.
(MODEL GC166D/DB/DBT/DWT)
Stopper
Stopper
WORKING CLIMATE
• The appliance is designed for operating
from SN to T climate (see below climate
class chart). It is recommended to
maintain the ambient around 22-25°C
which helps the appliance working
with low power consumption.
Climate Class Ambient
Temperature
SN = Subnormal 10°C -32°C
(50°F-90°F)
N = Normal 16°C -32°C
(61°F-90°F)
ST =Subtropical 18°C -38°C
(64°F-100°F)
T = Tropical 18°C -43°C
(64°F-109°F)
• If the ambient temperature is above or
below the designed climate range, the
performance of the unit may be affected.
For example, the appliance operating
in extreme cold or hot conditions may
cause interior temperatures to fluctuate,
and the temperature set 5-22°C
may not be reached sometimes.
OPERATING THE WINE FRIDGE
GRCU4731-User Guide GC100 GC166.indd 9GRCU4731-User Guide GC100 GC166.indd 9 20/9/22 5:14 pm20/9/22 5:14 pm

10
• To prevent damaging the door gasket,
make sure to have the door opened fully
all the way before pulling the shelves out.
• Please store wine in sealed bottles.
• Do not cover the shelves with aluminum
foil or any other shelf material which
may prevent air circulation.
• Should the wine fridge be left empty
for long periods it is suggested that
the appliance is unplugged, and after
careful cleaning, leave the door ajar
to allow air to circulate inside the
cabinet in order to avoid possible
condensation, mould or odours forming.
RECOMMENDED TEMPERATURES
Wine Type Recommended Temperature
Red 14-18°C (59°F-64°F)
White 6-14°C (48°F-57°F)
Rose 6-12°C (50°F-52°F)
Sparkling 4-10°C (41°F-46°F)
For further information see the
Wine Temperature Serving Guide
“WINE TEMPERATURE SERVING
GUIDE” on page 27.
GRCU4731-User Guide GC100 GC166.indd 10GRCU4731-User Guide GC100 GC166.indd 10 20/9/22 5:14 pm20/9/22 5:14 pm

11
FOR SINGLE ZONE
Power Lighting
Lock/Unlock ˚C/˚F Interchange
Temp-Up
Display Window Temp-Down
FOR DUAL ZONE
Temp-UpDisplay Window
Upper Zone
Display Window
Bottom Zone Zone SelectPower Lighting
˚C/˚F Interchange
Lock/Unlock
Temp-Down
CONTROL PANEL
GRCU4731-User Guide GC100 GC166.indd 11GRCU4731-User Guide GC100 GC166.indd 11 20/9/22 5:14 pm20/9/22 5:14 pm

12
POWER ON/OFF CONTROL
• When the appliance is plugged in to a
power outlet, it powers on automatically.
• Touch the power mark and
hold for 10 seconds to turn off
(or turn on) the appliance.
• No matter whether the appliance is under
a locked or unlocked situation, you can turn
off the appliance by touching the power
mark and holding for 10 seconds.
Warning: To avoid breaking
the compressor, please do not
turn on the appliance again within
5 minutes after you turn it off.
UNLOCKING THE CONTROL PANEL
• To unlock the control panel, touch the
power mark and lighting mark
with 2 fingers at the same time and
hold for 3 seconds. When unlocked
a buzz sound will be heard.
• The control panel will be automatically
locked with a buzz sound heard after
10 seconds without being touched.
• Under the locked situation, the control
panel will not react to any touch
operation other than for lighting on/
off and temperature setting.
INTERIOR LIGHTING ON/OFF CONTROL
• Under the unlocked situation, touch
the lighting mark to turn on (or
turn off) the interior LED lighting.
• The lighting will be continuously
on if it is not turned off.
TEMPERATURE DISPLAY WINDOW
• The temperature is displayed in digital
display form. The digital display is shown as
the set temperature when you are setting
the temperature, and it will change to
be the actual temperature inside cabinet
after 10 seconds without being touched.
• When the temperature probe is out of
order, the display window will show
with “HH” or “LL” instead of a digital
figure while a continuous buzz sound
will be heard. In case of this happens,
this appliance is designed to keep
the compressor and fan running
periodically which helps to keep the
desired temperature of the inside
cabinet to protect your stored wines.
Warning: To avoid destroying
your stored wines, it is
strongly recommended to have the
appliance repaired immediately,
as the periodical running cannot
ensure the appliance will achieve
the temperature you have set.
TEMPERATURE SETTING
For Single Zone beverage fridge:
• The temperature setting range
is 5-22°C (41-72°F).
• Directly touch the or mark to set
the wine fridge temperature as you want.
• The first touch on or mark will
recall the previous set temperature
displayed in the digital window. If the
appliance runs after a power failure (or
unplugging), the previous set temperature
does not exist and is replaced by the
defaulted temperature at 10°C.
• Touch the mark to increase the set
temperature by 1°C (or by 1°F). On the
contrary, touch the mark to decrease
the set temperature by 1°C (or by 1°F).
GRCU4731-User Guide GC100 GC166.indd 12GRCU4731-User Guide GC100 GC166.indd 12 20/9/22 5:14 pm20/9/22 5:14 pm

13
• The digital will change to display the real
temperature of the inside cabinet after
10 seconds without being touched.
For Dual Zone wine fridges:
• The temperature setting ranges are
5-12°C (41-54°F) for the upper zone and
12-22°C (54-72°F) for the bottom zone.
• You need to select the set zone by
touching the mark before touching
the mark or to set the desired
temperature. The display window with
digital flashing indicates the zone
ready for temperature setting.
• The first touch on mark or will
recall the previous set temperature
displayed in the digital window. If the
appliance runs after a power failure (or
unplugging), the previous set temperature
does not exist and is replaced by the
defaulted temperature at 10°C for the
upper zone and 16°C for the bottom zone.
• Touch the mark to increase
the set temperature by 1°C (or
by 1°F). Alternatively, touch the
mark to decrease the set
temperature by 1°C (or by 1°F).
• The digital will change to display the real
temperature of the inside cabinet after
10 seconds without being touched.
Note: For the first time to use the
appliance or to restart the appliance
after having been shut off for a long time,
you may find a few degrees variance
between the set temperature and the
displayed temperature. It is normal and
everything of the appliance will be in
the order after a few hours running.
SELECTING FAHRENHEIT (°F)
OR CELSIUS (°C) DISPLAY
For Single Zone
Touch the and marks with 2
fingers at the same time and hold for
5 seconds, you can interchange the
Fahrenheit and Celsius display.
For Dual Zone
Directly touch the mark, you can
interchange the Fahrenheit and Celsius
display for both zones at the same time.
GRCU4731-User Guide GC100 GC166.indd 13GRCU4731-User Guide GC100 GC166.indd 13 20/9/22 5:14 pm20/9/22 5:14 pm

14
CARE & MAINTENANCE
CLEANING THE WINE FRIDGE
• Turn off the power, unplug the appliance,
and remove all items including shelves.
• Wipe the inside surfaces with a sponge
and baking soda solution. The solution
should be about 2 tablespoons of
baking soda to 1 litre of warm water.
• Wash the shelves with a mild
detergent solution. Allow the wooden
shelves to dry before placing them
back into the wine fridge.
• Remove excess water from the sponge
or cloth when cleaning the controls, or
any other electrical display areas.
• Wipe the outside cabinet with warm
water and a mild liquid detergent.
Wipe dry with a clean soft cloth.
• Do not use steel wool or steel brush
on the stainless steel. These will
contaminate the stainless steel with
steel particles and rusting may occur.
POWER FAILURE
Most power failures are corrected within
a few hours and should not affect the
temperature of your appliance if you
minimize the number of times the door is
opened. If the power is going to be off for
a longer period of time, you need to take
the proper steps to protect your contents.
MOVING THE WINE FRIDGE
• Remove all items.
• Securely tape down all loose items
(shelves) inside your appliance.
• Turn the adjustable legs up to
the base to avoid damage.
• Tape the door shut.
• Ensure the appliance stays secure in the
upright position during transportation.
Also protect the outside of appliance
with a blanket, or similar item.
ENERGY SAVING TIPS
• The appliance should be located away
from heat producing appliances,
and away from direct sunlight.
• Ensure that the unit is adequately
ventilated. Never cover the air vents.
• Only open the door when necessary.
Avoid leaving the door open for long periods
or opening/closing the door frequently.
GRCU4731-User Guide GC100 GC166.indd 14GRCU4731-User Guide GC100 GC166.indd 14 20/9/22 5:14 pm20/9/22 5:14 pm

15
TROUBLESHOOTING
If you feel the appliance is out of order, follow these instructions to try to see if
you can solve the problem simply by yourself before calling for service.
Problem Problem Possible Cause / Measure
The wine fridge does
not operate
• Not plugged in.
• The appliance is turned off.
• The circuit breaker tripped or a blown fuse.
The wine fridge is
not cold enough
• Check the temperature control setting.
• External environment may require a higher setting.
• The door is opened too frequently.
• The door is not closed completely.
• The door gasket does not seal properly.
Automatically turn-on
and turn-off frequently
• The room temperature is hotter than normal.
• A large amount of contents has been
added to the wine fridge.
• The door is opened too frequently.
• The door is not closed completely.
• The temperature control is not set correctly.
• The door gasket does not seal properly.
The lighting does not work • Not plugged in.
• The circuit breaker tripped or a blown fuse.
• The lighting is turned off.
Too much vibration • Check to assure that the appliance is level.
• Check to assure no parts inside the cabinet
or in the compressor chamber are loose.
The wine fridge seems to
make too much noise
• The rattling noise may come from the flow
of the refrigerant, which is normal.
• As each cycle ends, you may hear gurgling
sounds caused by the flow of refrigerant.
• Contraction and expansion of the inside walls
may cause popping and crackling noises.
• The appliance is not level.
The door will not close properly. • The wine fridge is not level.
• The door was reversed and not properly installed.
• The gasket is dirty.
• The shelves are out of position.
The display window is shown
with “HH” or “LL” instead of
a digital figure, and/or with
a continuous buzz sound.
• The temperature probe is out of order.
GRCU4731-User Guide GC100 GC166.indd 15GRCU4731-User Guide GC100 GC166.indd 15 20/9/22 5:14 pm20/9/22 5:14 pm

16
REVERSING THE DOOR SWING
This instruction is based on a unit with
a right door hinge installed already.
*All removed parts should be saved
in case of door re-reversal.
TO REVERSE THE DOOR HINGES
1. Prize up the hinge screw holes cover
[1] and hinge cover [2] with a straight
screwdriver. Take out the upper hinge
by loosening the screws (3a), and lift
up the whole door. See Figure 1
Figure 1
1
2
4
3a
5
2. Move the support rod (6] (at the bottom
of the door) from the right to the left
side. Move the hinge hole cover (at
the top of the door) from the left side
to the right side. See Figures 2 & 3.
Figure 2
6 63b 3b
Figure 3
7 7
3. Pull out the bottom hinge cover (9) and
take out the bottom hinge by loosing
the screws. Loose the 4 screws on the
bottom left side. Install the bottom
hinge to the left side while screw the
holes on the right side. See Figure 4.
Figure 4.1
8
9
3c
10
11
Figure 4.2
10
8
3c
GRCU4731-User Guide GC100 GC166.indd 16GRCU4731-User Guide GC100 GC166.indd 16 20/9/22 5:14 pm20/9/22 5:14 pm

17
4. To reinstall the door to the opposite
side, insert the door support rod to
the bottom hinge through a washer
(11) and screw the upper hinge which
has connected with the door. Finally,
cover the hinges (4) as well as the
hinge screw holes. See Figures 5 &6.
Figure 5
4
5
3a
Figure 6
41
2
HOW TO REVERSE THE DOOR HANDLE
1. Remove the gasket at the right inner side
of the door to expose the 2 decorative
screws (1). Unscrew them in a clockwise
direction with a straight screwdriver
at first, and then loosen them in a
counter-clockwise direction by fingers
from the outer side of the door. Now the
screw holes are ready for installing the
handle to the right side. See Figure 1.
Figure 1
1
2. Remove the gasket at the left inner side
of the door to expose the 2 handle screws
(2). Unscrew them in a counter-clockwise
direction with a cross screwdriver, take
out the screws and the washers (3) as
well as the handle (4). See Figure 2.
Figure 2
4
3 2
GRCU4731-User Guide GC100 GC166.indd 17GRCU4731-User Guide GC100 GC166.indd 17 20/9/22 5:14 pm20/9/22 5:14 pm

18
3. Install the handle to the outer right
side of the door. See Figure 3.
Figure 3
4
3 2
4. Install the 2 decorative screws (1)
to the holes at the left side of the
outer door (backwards to the steps
of unscrewing it). See Figure 4.
Figure 4
1
5. Tidy and restore the gasket.
GRCU4731-User Guide GC100 GC166.indd 18GRCU4731-User Guide GC100 GC166.indd 18 20/9/22 5:14 pm20/9/22 5:14 pm

19
Thank you for purchasing a Grand Cru Wine Fridge from Home Icon International Pty
Ltd. Home Icon provides a 5-year warranty on the Grand Cru range of Wine Fridges.
WARRANTY REGISTRATION
Register your wine fridge now for warranty, and allow us to
provide you with the best possible after sales service:
1. Please log on to our website at www.grandcruwinefridges.com.au
2. Click on the ‘Support’ tab across the top
3. Select ‘Warranty Registration’ and fi ll out the details as required
This warranty does not cover the following:
• Any damages caused from improper use or not used in
accordance with the instruction manuals.
• Damage caused by connecting your product to the wrong power source/supply.
• Incorrect installation or modifi cations made during installation or use of the product.
• Removing screws or otherwise opening the outer case will void the warranty.
• Any damages resulting from poor handling or moving of the
product, misuse, fi re or water damage etc.
• Failure to maintain the product as per the Instruction Manual.
• Problems caused by incorrect or inadequate venting of the product.
SERVICE AND SUPPORT
Should an instance arrive where you require assistance, contact our support team:
1. Please log on to our website at www.grandcruwinefridges.com.au
2. Click on the ‘Support’ tab across the top
3. Select the ‘Request a Service’ option and fi ll out the details as required
NEED HELP? CALL
1300 935 683
WARRANTY, SERVICE AND SUPPORT
GRCU4731-User Guide GC100 GC166.indd 19GRCU4731-User Guide GC100 GC166.indd 19 20/9/22 5:14 pm20/9/22 5:14 pm

20
DIFFERENT SHAPES AND SIZES
This brochure makes reference to the
‘standard Bordeaux style bottle’ when
specifying capacity. However, wine
producers use a huge range of different
bottle shapes and sizes. Bottle shape variety
should be considered when selecting the
appropriate Grand Cru cabinet in which
to house your precious collection, since
shelf height and adjustability varies across
the product range. Please also be aware
that some bottles will not fi t opposite
each other on the same shelf and this
may affect capacity. You may need to lay
the bottles opposite more suitably shaped
bottles. Ideally, bottles should lie with
their necks comfortably interlocking.
STACKING FOR AGEING
When fi lling your cabinet, we suggest
stacking the bottles you wish to cellar
and mature at the back of the shelves,
and the wines you wish to consume
in the shortterm at the front.
STACKING FOR ACCESSIBILITY
When stacking bottles, it is practical to
keep bottles from the same case together.
See diagrams below, in which bottles
from the same case are represented by
the same colours. Vertically stacking
same-case bottles enables safe and
easy access to all your different wines.
STACKING FOR STORING & SERVING
FRONT VIEW TOP VIEW
SERVING SERVING SERVING SERVING
STORING STORING STORING STORING
Back Row
Front Row
STORING AND STACKING
GRCU4731-User Guide GC100 GC166.indd 20GRCU4731-User Guide GC100 GC166.indd 20 20/9/22 5:14 pm20/9/22 5:14 pm
