PARTS LIST
DE0751B (Panel Type Door - Black)
DE0751S (Panel Type Door - Stainless)
DE0751W (Wrap Type Door - Stainless)
EV0751B (Panel Type Door - Black)
EV0751S (Panel Type Door - Stainless)
EV0751W (Wrap Type Door - Stainless)
DV0751 SERIES
PART#632359
NORCOLD 12/12/2007

DV0751SERIESPARTSLIST-PAGE2
REFRIGERATOR ASSEMBLY - DV0751 SERIES
1
2
3
4
5
6
7
89
10
7
11
12
13
14
14
15
16
17
18
19
20
21
22
23
24
25
26
38
38
39
27
27
28
28
29 29
30 30
3131
32
32
33
33 34
34
35
36
37
Panel Type Door
Wrap Type Door

DV0751SERIESPARTSLIST-PAGE3
REFRIGERATOR ASSEMBLY - DV0751 SERIES
Continued on Page 4
NO. PART # DESCRIPTION DE0751B EV0751B DE0751S EV0751S DE0751W EV0751W
1 422513800 COVER-CONTROL/BLACK X
422513810 COVER-CONTROL/STAINLESS X X
2 169000500 POWERSUPPLY-AC (SP-243B) DE0751B DE0751S DE0751W
169000510 POWERSUPPLY-AC (SP-260A) EV0751B EV0751S EV0751W
3 163010710 POWERSUPPLY-DC X X X
4 160220100 KNOB-THERMOSTAT X X X
5 300207400 PLATELATCH X X X
6 501042700 BOLT/SCREW X X X
7 160932620 HINGE X X X
8 416027200 BUSHING-RUBBER/CABINET/COOLING UNIT TUBING X X X
9 404006300 BUSHING-"I"/PLASTIC/CABINET/COOLING UNIT TUBING X X X
10 645109400 HOLDER-SHELF/REAR X X X
11 422601500 FRAME-CABINET BOTTOM/BLACK X
422601510 FRAME-CABINET BOTTOM/STAINLESS X X
12 427401100 SUPPORT-LOWER CABINET/RH X X X
13 427401000 SUPPORT-LOWER CABINET/LH X X X
14 80830431610 SCREW-BOTTOM LEG X X X
15 160928900 FAN ONLY-50 CYCLE/40 WATT X X X
16 422305000 HOLDER-THERMISTER/AT EVAPORATOR X X X
17 605505420 THERMISTER-EVAPORATOR X X X
18 161011310 COOLING UNIT X X X
19 500013600 SCREW X X X
20 160203000 ICECUBETRAY X X X
21 433003800 DRAINAGEPAN X X X
22 523003510 SHELF-UPPER/HOLDS DRAINAGEPAN X X X
23 523003500 SHELF-LOWER X X X
24 323012720 FRAME-CABINET SIDE/RH/BLACK X
323012730 FRAME-CABINET SIDE/RH/STAINLESS X X
25 322376401 COVER-CABINET FRAME/FRONT/4 SIDES X X X
26 323012620 FRAME-CABINET SIDE/LH/BLACK X
323012630 FRAME-CABINET SIDE/LH/STAINLESS X X
27 160057800 DOORASSY-WITHOUT DOOR POCKET/PANEL TYPE/BLACK X
160057810 DOOR ASSY-WITHOUT DOOR POCKET/PANEL TYPE/STAINLESS X
160057820 DOOR ASSY-WITHOUT DOOR POCKET/WRAP TYPE/STAINLESS X
28 422603600 DOOR FRAMECOVER-BOTTOM/BLACK X
422603610 DOOR FRAMECOVER-BOTTOM/STAINLESS X X

DV0751SERIESPARTSLIST-PAGE4
REFRIGERATOR ASSEMBLY - DV0751 SERIES (Continued from Page 3)
NO. PART # DESCRIPTION DE0740B EV0740B DE0740S EV0740S DE0740W EV0740W
29 160949000 DOOR FRAMEASSY-PANEL TYPE/BLACK(FOAM LINER) X
160949010 DOORFRAMEASSY-PANEL TYPE/STAINLESS (FOAM LINER) X
160949200 DOOR FRAMEASSY-WRAP TYPE/STAINLESS (FOAM LINER) X
30 520004410 SPRING-TRAVEL LATCH X X X
31 505503420 PIN LATCH X X X
32 422513900 HANDLE-DOOR/BLACK X
422513910 HANDLE-DOOR/STAINLESS X X
33 422114500 COVER LATCH-BLACK X
422114510 COVER LATCH-STAINLESS X X
34 422114600 COVER PLATE-BLACK X
422114610 COVER PLATE-STAINLESS X X
35 302313350 DOOR PANEL-BLACK X
302313360 DOOR PANEL-STAINLESS X
36 422508810 DOOR POCKET-DOOR SHELF BIN X X X
37 422508610 PARTITION-DOOR POCKET X X X
38 323012100 FRAME-CABINET/TOP/BOTTOM/BLACK X
323012110 FRAME-CABINET/TOP/BOTTOM/STAINLESS X X
39 323012600 FRAME-CABINET/LH/FLUSH MOUNT KIT/BLACK/0751 X
323012610 FRAME-CABINET/LH/FLUSH MOUNT KIT/STAINLESS/0751 X X
323012700 FRAME-CABINET/RH/FLUSH MOUNT KIT/BLACK/0751 X
323012710 FRAME-CABINET/RH/FLUSH MOUNT KIT/STAINLESS/0751 X X
NS 606901100 FERRITECORE X X X
NS = NOT SHOWN
