GVA GVABD-145 User manual

45FREEZER
/ GVABD-145
Instruction Manual

Contents
Guide to the Appliance
Caring for the Environment
Safety Information and Warnings
Getting Started
Basic Set Up
Troubleshooting
Care and Maintenance
2
3
4
7
9
12
13
1

Guide to the Appliance
1. Recessed handle
2. Wheel
3. Basket
4. Indicator light
5. Thermostat knob
6. Drain hole
Note:
Due to production improvements, the appliance may differ slightly from the diagram
shown. Diagrams in this instruction manual are ready for reference only.
2

Caring for the Environment
Responsible disposal of the packaging
The packaging of your appliance has been selected from environmentally friendly materials and
can usually be recycled. Please ensure these are disposed of correctly.
Plastic wrapping can be a suffocation hazard for babies and young children, please ensure all
packaging materials are out of reach and are safely disposed of. Please ensure they are offered
for recycling rather than throwing these materials away.
Responsible disposal of the appliance
At the end of its working life, do not throw this appliance out with your household rubbish. An
environmentally friendly method of disposal will ensure that valuable raw materials can be
recovered and used again
.
Electrical and electronic appliances contain materials and substances which, if handled or
disposed of incorrectly, could be potentially hazardous on the environment and human health.
Observe any local regulations regarding the disposal of electrical consumer goods and dispose
of it appropriately for recycling and recovery of the refrigerant. This appliance contains the
flammable refrigerant isobutane (R600a) and cyclopentane (R141b) in the cabinet insulation,
and must be disposed of in a separate waste collection. Contact your local authorities for advice
on recycling facilities in your area.
Take care not to damage the pipework at the back of the appliance before or during
transportation so that the refrigerant gas cannot escape.
The plug must be rendered useless and the cable cut off directly behind the appliance or the
machine to prevent misuse.
DANGER.
Risk of child entrapment: When discarding a fridge or freezer, make sure to take off
the door and the spring action or bolt catch. Leave the shelves in place so that children cannot
easily climb in, get trapped inside and suffocate.
3

Safety Information and Wanrings
Read this manual thoroughly before first use, even if you are familiar with this type of product.
We have provided many important safety statements in this manual concerning the use of this
appliance. Always read and observe all safety statements. They reduce the risk of fire, electric
shock and injury when correctly adhered to.
Keep the manual in a safe place for future reference, along with the purchase receipt.
If applicable, pass these instructions on to the next owner of the appliance.
Pay particular attention to safety messages that follow this safety alert symbol or the
words
DANGER
,
WARNING
or
CAUTION
. These words are used to alert you to a
potential hazard that can seriously injure you and others.
The instructions will tell you how to reduce the chance of injury and let you know what can
happen if the instructions are not followed.
DANGER
means that failure to read this safety statement may result in severe personal injury.
WARNING
means that failure to read this safety statement may result in extensive product
damage or serious personal injury.
CAUTION
means that failure to read this safety statement may result in minor or moderate
personal injury, property or equipment damage.
This symbol alerts you to take care as the appliance contains a flammable
refrigerant. Do not expose it to high heat, sparks or open flame.
We assume no liability for any eventual damages caused by misuse of the appliance or non-
compliance with the instructions in this manual.
CAUTION:
Flammable Gas
4

Safety Information and Wanrings
Installation
Heavy:
This appliance is heavy, take care when moving it. To avoid back or other injury, consider
a two person lift or mechanical aid when installing it.
Location:
The room for installing appliance must be at least 1M³per 8g of refrigerant. The
amount and type of refrigerant in the appliance can be found on the rating plate on the back of
the appliance.
Moisture:
Install the freezer in an indoor area protected from wind, rain, water spray or drips.
Heat:
Do not install it next to an oven, grill or other source of high heat.
Ventilation:
To ensure proper ventilation, the front of the unit must be completely unobstructed.
Keep any ventilation openings clear of obstructions. Choose a well-ventilated area with
temperatures above 16˚C and below 43˚C.
Refrigerant circuit:
Do not damage the refrigerant circuit.
Level:
Install the appliance on a level surface or adjust the feet to level the appliance and ensure
proper operation.
Pipes:
Make certain that the pipes are not pinched, kinked or damaged during installations.
Check for leaks after connection.
Electrical Safety
Voltage:
Make sure your outlet voltage and circuit frequency correspond to the voltage stated on
the appliance rating label. Plug the freezer into a 220-240V, 50Hz, 3-prong, power outlet with a
15A fuse at the mains. The outlet must be properly earthed to the ground.
Separate circuit:
Do not use an adaptor; do not use an extension cord. We recommend you
connect the freezer to a separate circuit serving only this appliance. This provides the best
performance and prevents overloading the house wiring circuits that could cause a fire hazard
from overheating. Use a power point that cannot easily be turned off accidentally.
Power cord:
Do not kink or damage the power cord. Do not leave it exposed or dangling. Secure
it behind the appliance so no one steps on or places anything on the cord or against it. Never
unplug the appliance by pulling the cord. Always grip the plug firmly and pull straight out from
the power point.
Damaged cord:
Do not use a cord that shows cracks or abrasion damage along its length or at
either end. If the power cord is damaged, it must be replaced by the manufacturer or its service
agent. Contact the GVA after sales support line to have it replaced.
Electrical work:
If the installation of this appliance requires any electrical work, make sure it is
carried out by a qualified electrician.
5

Safety Information and Wanrings
Usage Conditions and Restrictions
Indoor domestic use only:
This appliance is intended for indoor household use only. It is not
suitable for commercial, industrial or outdoor use.
Intended purpose:
Do not use this appliance for anything other than its intended purpose and
only use it as described in this manual. Do not attempt to alter or modify this appliance in any
way.
Electrical type appliances:
Do not use any such appliances inside the food storage compartments
of the appliance, unless they are specifically recommended in this manual.
Usage restrictions:
The appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless
they have been given supervision or instruction concerning use of the appliance by a person
responsible for their safety.
Children:
Supervise children to ensure they do not play with the freezer. Never allow children to
operate, play with or crawl inside the freezer.
Cleaning and Maintenance
Disconnect:
Unplug the freezer or disconnect power before cleaning or servicing. Failure to do so
can result in electrical shock, injury or death. Do not connect or disconnect the electric plug when
your hands are wet.
Flames:
Do not let open flames or ignition sources enter the appliance.
Flammable/explosive substances:
Never clean this appliance with flammable fluids. Do not store
or use volatile, flammable or explosive propellants or liquids close to this or any other appliance.
The fumes can create a fire hazard or explosion caused by electric sparks.
Solvents:
Do not use solvent based cleaning agents or abrasives on the interior. These cleaners
may damage or discolour the interior.
Defrosting aids:
Do not use mechanical devices, steam cleaners or other means to accelerate the
defrosting process. Never use a sharp or metal instrument to remove frost as it may damage the
cooling system and will void the warranty. We recommend using a plastic scraper.
Service:
Do not attempt to repair or replace any part of the freezer unless it is specifically
recommended in this manual. Refer all other servicing to a qualified technician, or contact the
GVA after sales support line for advice on repair or replacement. It is hazardous for anyone other
than an Authorised Service Person to service this appliance. In Queensland - the authorized
Service Person MUST hold a Gas Work Authorisation for hydrocarbon refrigerants, to carry out
servicing or repairs which involve the removal of covers.
6

Getting Started
Before First Use
•Unpack the appliance, keep all packaging materials until you have made sure your new
freezer is undamaged and in good working order.
•Plastic wrapping can be a suffocation hazard for babies and young children, so ensure all
packaging materials are out of their reach.
•Check to ensure you have all the parts listed on the 'Guide to the Appliance' page, plus
an instruction manual and a warranty card.
•Read this manual to familiarise yourself with all the parts. Pay particular attention to the
safety instructions on the previous pages.
•Unwind the cord to its full length and inspect it for damage. Do not use the appliance if
the appliance or its cord has been damaged. In case of damage, contact the GVA after
sales support line for advice on examination, repair or return of the damaged product.
•Make sure the freezer is disconnected from the power supply before cleaning the interior
surfaces with lukewarm water using a soft cloth to remove any dust from transit and
storage. Dry the appliance thoroughly.
•Your new freezer is now ready for use – see page 9 for set up instructions.
Overloading the freezer will affect cold air circulation and cooling performance. We therefore
recommend you only load the freezer up to about 70% of it’s storage volume, always leave some
space around food stored and do not use containers that are too large and block ventilation
openings.
Installing the Freezer
•Before installing your new freezer, read all safety instructions in this manual, especially
the sections on electrical safety and installation. Then follow the instructions below.
•This appliance is designed to be freestanding only and should not be recessed or built in.
•Place the freezer on a sturdy, level floor that is strong enough to support the appliance
when it is fully loaded.
•DO NOT install the appliance directly on carpeting or soft material. Carpeting must be
removed or be protected by a metal or wood panel beneath the appliance, which extends
at least the full width and depth of the appliance.
•
NOTE:
Ensure that the appliance does not stand on the electrical supply cable. Parts
which heat up should not be exposed. Whenever possible, the back of the appliance
should be close to a wall but leaving the required distance for ventilation.
7

Getting Started
•Locate the freezer
- Away from direct sunlight, which may affect the acrylic coating.
- Away from sources of heat (stove, heater, radiator, dishwasher, etc.), which may
increase power consumption.
- In an area without extreme cold ambient temperatures, which may affect cooling
performance.
- In a cool, well-ventilated area, without excessive moisture and high humidity.
•Installing the appliance in the coolest area of the room will save energy consumption and
running costs.
•To ensure correct operation, this appliance must not be located where the temperature
will be below 16°C or above 43°C.
•Ensure there are no obstructions that could prevent the freezer door from closing.
•To level the appliance, adjust the levelling legs at the bottom of the appliance.
•The freezer must have at least 50mm clearance between the rear of the appliance and
the wall, 100mm between the sides and wall, and the space above the top should be at
least 700mm.
•Before plugging in your new freezer, let it stand upright for approximately 2 hours. This
will allow the refrigerant gases to settle into the compressor and reduce the possibility of
a malfunction in the cooling system from handling during transportation.
•The freezer is suitable for connection to 220-240VAC 50Hz supply. The freezer must be
plugged into a dedicated individual 220-240VAC main socket outlet.
•Plug the appliance into an exclusive, properly installed and earthed wall outlet. Do not
under any circumstances cut or remove the third (ground) prong from the power cord. If
in doubt about your setup, direct any questions concerning power and/or grounding to a
certified electrician.
•Do not use an extension cord or an adapter plug.
•Secure the freezer’s supply cord behind the appliance. Do not leave it exposed or
dangling to prevent injury and accidental disconnection from the power supply.
NOTE
: After plugging the appliance into a wall outlet, allow the unit to cool down for 2 or 3
hours before placing food in the freezer.
8

Basic Set Up
First Use
Cleaning the Interior
Before using the appliance for the first time, wash the interior and all internal accessories with
lukewarm water and some neutral soap so as to remove the typical smell of a brand new product
and then dry thoroughly.
Important
Do not use detergents or abrasive powders, as these will damage the finish.
Temperature Setting
Set the temperature using the temperature control knob.
Position 1- Cold.
Position 5 - Colder. (Normally set at this position.)
Position 7- Coldest.
Position Max - To fast freeze food. After 24 hours reset the freezer back to the desired setting.
The freezer may not operate at the correct temperature if it is in a particularly hot location or if
you open the door too often.
Daily Use
Freezing Fresh Food
•The freezer is suitable for freezing fresh food and storing frozen and deep-frozen food for
a long time.
•Place the fresh food to be frozen in the bottom compartment.
•The maximum amount of food that can be frozen in 24 hours is specified on the rating
plate.
•The freezing process takes 24 hours: during this period do not add other food to be
frozen.
9

Basic Set Up
Storing Frozen Food
When first starting up or after a period out of use. Before putting the product in the compartment
let the appliance run at least 2 hours on the higher settings.
Important
In the event of accidental defrosting, for example the power has been off for longer
than the value shown in the event of accidental defrosting, for example the power has
been off for more than 8 hours, the defrosted food must be consumed quickly or cooked
immediately and then re-frozen (after cooked).
Space Requirements
The following are recommended clearances around the chest freezer.
Sides 10cm
Back 10cm
Top 70cm
Positioning
Install this appliance at a location where the ambient temperature corresponds to the climate
class indicated on the rating plate of the appliance.
Location
The appliance should be installed well away from sources of heat such as radiators, boilers,
direct sunlight etc. Ensure that air can circulate freely around the back of the cabinet. To ensure
best performance, if the appliance is positioned below an overhanging wall unit, the minimum
distance between the top of the cabinet and the wall unit must be at least 700mm. Ideally,
however, the appliance should not be positioned below overhanging wall units. Accurate
levelling is ensured by one or more adjustable feet at the base of the appliance.
Warning
It must be possible to disconnect the appliance from the mains power supply; the
plug must therefore be easily accessible after installation
.
10

Basic Set Up
Electrical Connection
Before plugging in, ensure that the voltage and frequency shown on the rating plate correspond
to your domestic power supply. The appliance must be earthed. The power supply cable plug is
provided with a contact for this purpose. If the domestic power supply socket is not earthed,
connect the appliance to a separate earth in compliance with current regulations, consulting a
qualified electrician. The manufacturer declines all responsibility if the above safety precautions
are not observed.
11

Troubleshooting
If you experience a problem with your freezer, check in the following table for solutions to help
you solve the problem. If after these checks you still have a problem with your freezer, call the
GVA after sales support line for advice.
Problem
Possible Cause
Solution
Appliance does
not work
Mains plug is not plugged in or is
loose
Insert mains plug.
Fuse has blown or is defective
Check fuse, replace if necessary.
Socket is defective
Mains malfunctions are to be
corrected by an electrician.
Appliance freezes
too much
Temperature is set too cold or the
appliance runs at MAX setting.
Turn the temperature regulator to a
warmer setting temporarily.
The food is not
frozen enough.
Temperature is not properly
adjusted.
Please look in the initial
Temperature Setting section.
Door was open for an extended
period.
Open the door only as long as
necessary.
A large quantity of warm food was
placed in the appliance within the
last 24 hours.
Turn the temperature regulation to
a colder setting temporarily.
The appliance is near a heat source.
Please look in the installation
location section.
Heavy build-up of
frost on the door
seal.
Door seal is not air-tight.
Carefully warm the leaking sections
of the door seal with a hair dryer (on
a cool setting). At the same time
shape the warmed door seal by
hand such that it sits correctly.
Unusual noises
The appliance is touching the wall or
other objects.
Move the appliance slightly.
A component, e.g. a pipe, on the
rear of the appliance is touching
another part of the appliance or the
wall.
If necessary, carefully bend the
component out of the way.
12

Care and Maintenance
Defrosting the Freezer
When?
For the most efficient operation and minimum energy consumption, defrost the appliance
when the frost accumulated on the evaporator is about 5mm thick.
How?
Turn the thermostat dial to the [0] position and unplug the appliance. Remove food from
the appliance and keep them in another freezer or cooler bag.
Defrosting usually takes a few hours. After defrosting, dry the inside of the appliance and return
the thermostat dial to the desired position.
To defrost quickly, remove all food from the appliance and leave the door open.
CAUTION:
Do not use boiling water because it may damage the plastic parts. Never use sharp
or metallic instruments to remove frost as they may damage the cooling system. Use a plastic
scraper if required.
Cleaning the Freezer
•Unplug the freezer, and remove the bottles.
•Wash the inside with a warm water and baking soda solution. The solution should be
about two tablespoons of baking soda to one litre of water.
•Wash the shelves and trays with a mild detergent solution.
•The outside of the freezer should be cleaned with mild detergent and warm water.
•It may also be necessary to periodically wipe the bottom part of the storage area, as the
freezer is designed to retain humidity and condensation may collect in this area.
Power Failure
Most power failures are corrected within a few hours and should not affect the temperature of
your freezer if you minimize the number of times the door is opened. If the power is going to be
off for a longer period of time, you will need to take the proper steps to protect your contents.
Vacation Time
During long absences, remove all the bottles, unplug the freezer, clean the freezer, and leave
the door open slightly to avoid possible formation of condensation, mould or odours.
Energy Saving Tips
•Place the freezer in the coolest area of the room, away from heat-producing appliances
and out of direct sunlight.
•Do not line any freezer storage bin with aluminium foil, wax paper or paper towels. Liners
interfere with cold air circulation, reducing cooling efficiency.
•Do not leave the freezer door open for longer than required.
13

Care and Maintenance
Moving the Freezer
•Remove all the contents in the freezer.
•Securely tape down any loose items inside your freezer.
•Turn the levelling screws up to the base to avoid damage.
•Tape the door shut.
•Be sure the freezer stays in the upright position during transportation.
15

M.E.W. (Australia) Pty Ltd
15 Vaughan St
Essendon Fields VIC 3041
ACN 152 719 036
1300 725 885
[email protected]
gvaproducts.com.au
While every effort has been made in the preparation of this instruction manual, the publishers cannot be
held responsible for the accuracy of the information contained herein or any consequences arising from it.
