H2Scan HY-OPTIMA User manual
Parts of this document are controlled in a
schedule drawing. See 90000076-LTDS.
HY-OPTIMA Intrinsically Safe Remote Control
Module Operating Manual
INTRINSICALL SAFE REMOTE CONTROL
OPERATING MANUAL
90000076 R1 Page 2 of 7
MISSION STATEMENT
INTRINSICALL SAFE REMOTE CONTROL
OPERATING MANUAL
90000076 R1 Page 3 of 7
IMPORTANT NOTICES
LIMITED WARRANTY
H2scan Limited Warranty: Each hydrogen instrument (“Product”) will conform, as to all substantial
operational features, to the Product specifications set forth in this Manual and will be free of defects which
substantially affect such Product’s performance for twelve (12) months from the ship date for such
Product.
Must Provide Notice of Defect: If you believe a Product that you believe is defective, you must notify
H2scan in writing, within ten (10) days of receipt of such Product, of your claim regarding any such defect.
Return Product to H2scan for Repair, Replacement or Credit: If the Product is found defective by
H2scan, H2scan’s sole obligation under this warranty is to either (i) repair the Product, (ii) replace the
Product, or (iii) issue a credit for the purchase price for such Product, the particular remedy to be
determined by H2scan on a case-by-case basis.
Voided Warranty: H2scan’s 12 Month Limited Warranty is void for any of the following:
The unit is opened and the manufacturing seal is broken
Unauthorized repair work performed at the customer’s location or carried out by anyone other than
H2scan’s factory trained technicians
Equipment or parts that have been tampered with, misused, neglected, mishandled, improperly adjusted,
or modified in any way without the written consent of H2scan.
Equipment or parts that have been damaged due to shipping, misuse, accidents, mishandling, neglect, or
problems with electrical power sources.
Repair work performed during the warranty period does not prolong the warranty period past the original
period.
System operation in incorrect or inappropriate environments.
Usage that is not in accordance with system guidelines or an operator’s failure to follow manual
instructions.
Limitation of Warranty: THE ABOVE IS A LIMITED WARRANTY AS IT IS THE ONLY WARRANTY
MADE BY H2SCAN. H2SCAN MAKES NO OTHER WARRANTY EXPRESS OR IMPLIED AND
EXPRESSLY EXCLUDES ALL WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A
PARTICULAR PURPOSE. YOUR SOLE REMEDY HEREUNDER IS REPAIR OR REPLACEMENT OF
THE PRODUCT OR A CREDIT FOR THE PURCHASE PRICE FOR SUCH PRODUCT, THE
PARTICULAR REMEDY TO BE DETERMINED BY H2SCAN ON A CASE-BY-CASE BASIS. H2SCAN
SHALL HAVE NO LIABILITY WITH RESPECT TO ITS OBLIGATIONS UNDER THIS AGREEMENT FOR
CONSEQUENTIAL, EXEMPLARY, OR INCIDENTAL DAMAGES EVEN IF IT HAS BEEN ADVISED OF
THE POSSIBILITY OF SUCH DAMAGES. THE STATED EXPRESS WARRANTY IS IN LIEU OF ALL
LIABILITIES OR OBLIGATIONS OF H2SCAN FOR DAMAGES ARISING OUT OF OR IN CONNECTION
WITH THE DELIVERY, USE OR PERFORMANCE OF THE PRODUCTS.
Read and understand this operating manual before installing or using the unit.
If this equipment is used in a manner not specified by H2scan, the protection provided by this equipment
may be impaired.
LIMITATION OF LIABILITY
In the event of a defect in a product, h2scan shall not be responsible for any direct, indirect, incidental or
consequential damages resulting therefrom, including, but not limited to, loss of revenue and/or profit.
INTRINSICALL SAFE REMOTE CONTROL
OPERATING MANUAL
90000076 R1 Page 4 of 7
1 DESCRIPTION
The HY-OPTIMA Intrinsically Safe Remote Control Module is used to control the Explosion Proof In-
line Hydrogen Process Analyzer.
The remote control is used to access the Configuration Menu, change settings and initiate
Calibration. If lost or damaged, spare remote controls can be purchased directly from H2scan.
1.1 INTRINSICALLY SAFE REQUIREMENTS
Only replace the battery in a safe (non-hazardous) location.
WARNING - Only the following batteries have been tested and approved for maintaining the
intrinsic safety of the remote control:
Panasonic CR1632
Energizer CR1632
Renata CR1632
Using any other battery may impair the safety of the remote.
A lanyard or anything else attached to the remote while in hazardous locations must not have
metallic parts.
1.2 OPERATION
To control the 2700, hold the remote control so the LED points towards the 2700’s display
panel.
Pressing ▲(up arrow button) moves the cursor up.
Pressing ▼(down arrow button) moves the cursor down.
Pressing ►(right arrow button) selects the next menu.
Pressing ◄(left arrow button) selects the previous menu.
Pressing (enter button) selects the function.
See the 2700 Operator’s Manual for menu structure.
1.3 BATTERY REPLACEMENT
See the photos below.
Pry open the case with a flat-tip screwdriver.
Remove the board from the case, battery end out first.
Replace the battery. Be sure the negative (-) side touches the board and the positive side (+)
touches the battery holder.
Place the case half with the buttons face down on a surface.
Slide the board in LED end first, battery side up.
There are small tabs in the case that fit into the notches on either side of the board. The sides
of the case may need to be bent out slightly so the board can snap in.
Snap the case together.
INTRINSICALL SAFE REMOTE CONTROL
OPERATING MANUAL
90000076 R1 Page 5 of 7
LED
INTRINSICALL SAFE REMOTE CONTROL
OPERATING MANUAL
90000076 R1 Page 6 of 7
2 CERTIFICATIONS
For Use In Class I, Division 1, Groups A, B, C, and D, T4, Hazardous (Classified) Locations Only as to
Intrinsic Safety
- Standard No. UL 913, 7th Ed., Intrinsically Safe Apparatus and Associated Apparatus
for Use in Class I, II, and III, Division 1, Hazardous (Classified) Locations
- Standard No. CAN/CSA C22.2 No. 157-92, Rev. 2003-06 (Reaffirmed 2012),
Intrinsically Safe and Non-incendive Equipment for Use in Hazardous Locations
DEMKO 11 ATEX 8175718 II 1G Ex ia IIC T4
Ex ia IIC T4 Ga
-20ºC ≤Ta ≤55ºC
EN 60079-0:2009 - ELECTRICAL APPARATUS FOR EXPLOSIVE GAS ATMOSPHERES. PT. 0,
GENERAL REQUIREMENTS
IEC 60079-0 - ELECTRICAL APPARATUS FOR EXPLOSIVE GAS ATMOSPHERES. PT. 0,
GENERAL REQUIREMENTS - Edition 4 - Revision Date 2004
EN 60079-11:2007 - ELECTRICAL APPARATUS FOR EXPLOSIVE GAS
ATMOSPHERES. PT. 11, INTRINSIC SAFETY "i"
IEC 60079-11 - ELECTRICAL APPARATUS FOR EXPLOSIVE GAS
ATMOSPHERES. PT. 11, INTRINSIC SAFETY "I" - Edition 4 - Revision Date 1999
EN 60079-26:2007 - EXPLOSIVE ATMOSPHERES – PART 26: EQUIPMENT WITH EQUIPMENT
PROTECTION LEVEL (EPL) Ga
CENELEC EN 60079-0 - EXPLOSIVE ATMOSPHERES - PART 0: EQUIPMENT - GENERAL
REQUIREMENTS - Edition 1 - Issue Date 2009/08/01
CENELEC EN 60079-11 - EXPLOSIVE ATMOSPHERES - PART 11: EQUIPMENT PROTECTION
BY INTRINSIC SAFETY "I" - Edition 1 - Issue Date 2007/01/01
CENELEC EN 60079-26 - EXPLOSIVE ATMOSPHERES - PART 26: EQUIPMENT WITH
EQUIPMENT PROTECTION LEVEL (EPL) GA - Edition 1 - Issue Date 2007/03/01
0359
INTRINSICALL SAFE REMOTE CONTROL
OPERATING MANUAL
90000076 R1 Page 7 of 7
Manual copyright © 2011, H2scan
Instrument software copyright © 2011, H2scan
Wide Range SensorTM protected under US patent number 5,279,795
