Kimin TV Link Loader User manual

EUT Type: TV Link Loader
FCC ID: TGETLL-1000A
Test Report No.: GETEC-E3-05-073
FCC Class B Certification
APPENDIX H
: USER’S MANUAL

TV Link Loader
User’s Manual
ⓒ2005 KIMIN Electronics

* When violated lower part item, serious injury or death can happen.
Attention for Safety
'Attention for Safety' is to prevent accident and danger beforehand using
product safety and right.
Two or three main point in place that keep necessarily and can see alwa
y
9In case this product wet in water, do not put in could apply heat
place to dry.
Can explode or be responsible for transformation or breakdown.
9Do not use in place that temperature is high or there is moisture.
Whether wet because of rain or spill drinking water and so on, in if use be
responsible for battery explosion
or be responsible for breakdown can.
9When wild wind, thunder, lightning strike extremely, control useof
product,
and unplug supply cord and charger.
Can wound serious injury by lightning strike, and fire can breakout.
9Disjoint product voluntarily, or do not shock.
9Power cord is not reflected, and do not use charge Adapter when
part that inserts concert is loose.
9Do to put heavy thing on power cord or is not spread.
9Do not stare infrared rays window directly at infrared rays
communication.
There is danger of eyesight damage.
Warning

* When violated lower part item, slight injury or product damage
can happen.
¾After avoid shock and impact, and extract when nonuse or when is
absent power cord, keep in safe place.
¾Do not drop or strike or shake product extremely.
¾When wild wind, thunder, lightning strike extremely, control useof
product, and unplug together supply cord and charger.
¾Disjoint product voluntarily, or do not shock.
¾Place that there are much dusts avoids setup, and do supply cord
so that do not approximate to heating appliances.
¾After is charged when nonuse battery and leave many long hours,
keep at normal temperature.
¾In case of use again battery after leaving alone many long hours,
have better use after charge perfectly.
Caution

¾Contents
1. Intro
2. Each Button Function Explanation
3. To charge, to turn on Power
4. STANDBY Mode
5. Installation Menu Log-in
6. To use Installation Menu
7. Password Substitute
8. Debug Mode
9. Channel Edit Program
10. Electrical standard
11. Construction

Intro
1
Thank for buying TV Link Loader.
This product has following function.
Remote Control Function
: Achieve channel and volume Up, Down of general remote control
and function of OK button.
Channel Information Storage Function
: Can do channel information of TV to do storage on TV Link
Loader interior.
Channel Information Transfer Facility
: Can transmit channel information of TV that is stored to TV Link
Loader on other TV.
* Use extent is limitative in other TV product that product that see is
exclusive use special procurements mounting of LG Electronics
commercial LCD TV.
Function of This Product

Each button function explanation
2
It is button that act Channel Down of general
remote control according to mode, Volume Down
role.
Down Button
Enter to Password Mode, and it is button that act
as enter of general remote control.
Enter Button
It is button that act Channel Up of general remote
control according to mode, Volume Up role.
Up Button
It is button to store channel information of TV by
TV Link Loader through RS232 communication.
Receive Button
It is button to transmit channel information that is
stored in TV Link Loader by TV through infrared-ray
communication.
Send Button
It is when enter by TV INSTALLATION MENU and
button that select Up, mode of Down button.
MODE Button

To charge, to turn on Power
3
DC 9V
Adapter
If charge
Connect 9V DC Adapter in marked
position
that is and insert to 220V AC
concert.
If turn on power supply
And that is , do marked place's
switch by ON.
After power on
9Confirm that phrase called "TV Link" in LCD original idea first line
and "Ready" in second line is marked.
9Confirm that battery residual quantity on the right top portion and
arrow on right lower column are marked.
9When connected Adapter all, confirm since light is lighted
in 'Power'.
9When connected Adapter all, battery does not pack, confirm
whether light is lighted in 'Charge'.
TVLink
ReadyÅÆ
Connect 9V DC Adapter in marked
position
that is and insert to 220V AC
concert.

STANDBY Mode
4
What is ‘STANDBY’
When power supply enters, is
situation that do not act other thing to
minimize consumption of current.
"Standby" is marked in second line of
LCD.
If get into 'STANDBY' state
Turn on power supply and in case
there is no any manufacturing for 30
seconds, get into 'Standby' state.
Also, get into 'Standby' state to
when there is no any manufacturing
after channel information
transmission or for after click button
20 seconds.
If escape in 'STANDBY' state
Press 'Receive' button, or turn on again while
put out power supply.
TVLink
Standby
