H3C S3100-52P User manual

H3C S3100-52P Ethernet Switch
Installation Manual
Hangzhou H3C Technologies Co., Ltd.
http://www.h3c.com
Manual Version: T2-08048P-20070410-C-1.01

Copyright © 2006-2007, Hangzhou H3C Technologies Co., Ltd. and its licensors
All Rights Reserved
No part of this manual may be reproduced or transmitted in any form or by any means
without prior written consent of Hangzhou H3C Technologies Co., Ltd.
Trademarks
H3C, , Aolynk, , H3Care, , TOP G, , IRF, NetPilot,
Neocean, NeoVTL, SecPro, SecPoint, SecEngine, SecPath, Comware, Secware,
Storware, NQA, VVG, V2G, VnG, PSPT, XGbus, N-Bus, TiGem, InnoVision and
HUASAN are trademarks of Hangzhou H3C Technologies Co., Ltd.
All other trademarks that may be mentioned in this manual are the property of their
respective owners.
Notice
The information in this document is subject to change without notice. Every effort has
been made in the preparation of this document to ensure accuracy of the contents, but
all statements, information, and recommendations in this document do not constitute
the warranty of any kind, express or implied.
To obtain the latest information, please access:
http://www. h3c.com
Technical Support
[e-mail]
http://www. h3c.com

About This Manual
Related Documentation
In addition to this manual, each H3C S3100-52P Ethernet Switch documentation set
includes the following:
Manual Description
H3C S3100-52P Ethernet Switch
Operation Manual
It is used for assisting the users in
device configuration and typical
applications.
H3C S3100-52P Ethernet Switch
Command Manual It is used for assisting the users in using various commands.
Organization
H3C S3100-52P Ethernet Switch Installation Manual is organized as follows:
Chapter Contents
1 Product Overview Introduces the characteristics and technical
specifications of S3100-52P Ethernet Switches.
2 Preparing for Installation Introduces the installation preparation and
precaution of S3100-52P Ethernet Switches.
3 Installing the Switch
Introduces the procedures to install an
S3100-52P Ethernet Switch, including the setup
of the mainframe, cards, power supply, and
cables.
4 Starting up the Switch at the
Initial Boot
Introduces the booting process of an
S3100-52P Ethernet Switch, including the
power-on booting of the switch and the system
initialization.
5 Loading Boot ROM and Host
Software Introduces the ways to load BootROM and host software for an S3100-52P Ethernet Switch.
6 Maintenance and
Troubleshooting
Introduces the problems that might occur during
the installation and the booting of an S3100-52P
Ethernet Switch and the corresponding
solutions.
Appendix Lightning Protection of
the Switch Introduces lightning protection of an S3100-52P Ethernet Switch.

Conventions
The manual uses the following conventions:
I. GUI conventions
Convention Description
< > Button names are inside angle brackets. For example, click
<OK>.
[ ] Window names, menu items, data table and field names
are inside square brackets. For example, pop up the [New
User] window.
/ Multi-level menus are separated by forward slashes. For
example, [File/Create/Folder].
II. Symbols
Convention Description
Warning Means reader be extremely careful. Improper operation
may cause bodily injury.
Caution Means reader be careful. Improper operation may cause
data loss or damage to equipment.
Note Means a complementary description.
Environmental Protection
This product has been designed to comply with the requirements on environmental
protection. For the proper storage, use and disposal of this product, national laws and
regulations must be observed.

Installation Manual
H3C S3100-52P Ethernet Switch Table of Contents
i
Table of Contents
Chapter 1 Product Overview........................................................................................................1-1
1.1 Introduction ........................................................................................................................ 1-1
1.2 S3100-52P Ethernet Switch............................................................................................... 1-1
1.2.1 Front Panel.............................................................................................................. 1-1
1.2.2 Rear Panel .............................................................................................................. 1-5
1.3 System Features of the S3100-52P Ethernet Switch ........................................................ 1-6
Chapter 2 Preparing for Installation............................................................................................2-1
2.1 Safety Precautions............................................................................................................. 2-1
2.2 Installation Site................................................................................................................... 2-1
2.2.1 Temperature/Humidity............................................................................................. 2-1
2.2.2 Cleanness ............................................................................................................... 2-2
2.2.3 Electromagnetic Susceptibility ................................................................................ 2-2
2.2.4 Laser Safety ............................................................................................................ 2-3
2.3 Installation Tools................................................................................................................ 2-3
Chapter 3 Installing the Switch....................................................................................................3-1
3.1 Installing a Switch .............................................................................................................. 3-1
3.1.1 Cabinet Mounting .................................................................................................... 3-1
3.1.2 Mounting the Switch on a Tabletop/Workbench ..................................................... 3-6
3.2 Connecting the Power Cord and the Ground Wire............................................................ 3-6
3.2.1 Connecting the AC-Input Power Cord..................................................................... 3-6
3.2.2 Connecting the Ground Wire................................................................................... 3-7
3.3 Connecting the Switch to a Console Terminal................................................................... 3-9
3.3.1 Console Cable......................................................................................................... 3-9
3.3.2 Connecting the Console Cable ............................................................................. 3-10
3.4 Verifying Installation......................................................................................................... 3-10
Chapter 4 Starting up the Switch at the Initial Boot .................................................................. 4-1
4.1 Setting up a Configuration Environment............................................................................ 4-1
4.2 Connecting the Console Cable .......................................................................................... 4-1
4.3 Setting Terminal Parameters ............................................................................................. 4-1
4.4 Booting the Switch ............................................................................................................. 4-4
4.4.1 Verifying Installation before Power-up .................................................................... 4-4
4.4.2 Powering up the Switch........................................................................................... 4-4
Chapter 5 Loading Boot ROM and Host Software ..................................................................... 5-1
5.1 Introduction to Loading Approaches.................................................................................. 5-1
5.2 File attribute in Boot ROM ................................................................................................. 5-1
5.2.1 Introduction to File Attribute .................................................................................... 5-1

Installation Manual
H3C S3100-52P Ethernet Switch Table of Contents
ii
5.2.2 Impact of File Attributes on Downloading and Booting ........................................... 5-2
5.2.3 Setting the Attribute of a File................................................................................... 5-3
5.3 Loading Software Locally................................................................................................... 5-5
5.3.1 Boot Menu ............................................................................................................... 5-5
5.3.2 Loading Software from Console Port Using XModem ............................................ 5-6
5.3.3 Loading Software from an Ethernet Port Using TFTP .......................................... 5-11
5.3.4 Loading Software from an Ethernet Port Using FTP............................................. 5-12
5.4 Loading Software Remotely............................................................................................. 5-13
5.4.1 Loading Software Remotely Using FTP ................................................................ 5-14
5.4.2 Loading Software Remotely Using TFTP.............................................................. 5-15
Chapter 6 Maintenance and Troubleshooting............................................................................ 6-1
6.1 Dealing with Loading Failures............................................................................................ 6-1
6.2 Dealing with Password Loss.............................................................................................. 6-1
6.2.1 Dealing with User Password Loss........................................................................... 6-1
6.2.2 Recovering the Boot ROM Password ..................................................................... 6-2
6.3 Dealing with Power System Failures ................................................................................. 6-2
6.4 Dealing with Configuration System Failures...................................................................... 6-2

Installation Manual
H3C S3100-52P Ethernet Switch Chapter 1 Product Overview
1-1
Chapter 1 Product Overview
1.1 Introduction
H3C S3100-52P Ethernet Switch is wire speed layer 2 Ethernet switch. It is a intelligent
NMS-manageable switch intended for the use in a network environment where high
performance, dense port distribution, and ease of installation are required.
Table 1-1 shows the specifications of the H3C S3100-52P Ethernet switch.
Table 1-1 Specifications of the S3100-52P
Model Power supply
unit (PSU)
Number of
service
ports
Number of
100 Mbps
ports
Number of
1000 Mbps
uplink
ports
Console
port
H3C
S3100-52P AC-input 52
48 10/100
Mbps
(electrical)
4 (SFP) 1
1.2 S3100-52P Ethernet Switch
1.2.1 Front Panel
On its front panel the S3100-52P Ethernet switch provides 48 fixed auto-negotiation
10Base-T/100Base-TX Ethernet ports, four 1000 Mbps SFP ports and one Console
port.
I. Schematic diagram
(1) 10/100 Mbps Ethernet port status LEDs (2) Console port
(3) 7-segment digitron display (4) Mode button
(5) Port mode LED (6) AC-input power LED
(7) 1000 Mbps SFP port status LEDs
Figure 1-1 Front panel of the S3100-52P

Installation Manual
H3C S3100-52P Ethernet Switch Chapter 1 Product Overview
1-2
II. LEDs
The S3100-52P Ethernet switch provides one AC-input power LED, one port mode
LED, one 7-segment digitron display, 48 x 10/100 Mbps Ethernet port status LEDs, and
four SFP port status LEDs on its front panel. You can learn how it operates by reading
the LEDs as shown in Table 1-2.
Table 1-2 LEDs on the front panel of the S3100-52P
LED Mark Color Indicates
Speed Solid green
Speed of the 10/100 Mbps ports,
state of the 1000 Mbps SFP ports,
or fabric state.
Duplex Solid yellow
10/100 Mbps duplex mode, state
of the 1000 Mbps SFP ports, or
fabric state.
Mode
LED Mode
PoE — —
Solid green
The system passes the Power-On
Self-Test (POST) and is operating
normally.
Flashing green (1 Hz) The system is going through the
POST or is downloading software.
Solid red The POST of the system fails or a
serious fault is detected.
Flashing yellow (1 Hz) Some ports fail to pass the POST
and some functions are disabled.
Power
LED PWR
OFF The power is disconnected.

Installation Manual
H3C S3100-52P Ethernet Switch Chapter 1 Product Overview
1-3
LED Mark Color Indicates
ON A 100 Mbps link is present.
Green
Flash Data is being received/sent on the
port.
ON A 10 Mbps link is present.
Yellow
Flash Data is being received/sent on the
port.
Flashing yellow
(3 Hz)
A 10 Mbps link is present and the
port is disabled.
Speed
OFF No link is present.
ON The port is operating in full duplex
mode.
Green
Flash Data is being received/sent on the
port.
ON The port is operating in half duplex
mode.
Yellow
Flash Data is being received/sent on the
port.
Flashing yellow
(3 Hz) The port fails POST.
Duplex
OFF No data is being received/sent on
the port.
10Base
-T/100
Base
-TX
Mode
port
LED
—
PoE — —
ON A 1000 Mbps link is present.
Green
Flash Data is being received/sent on the
port.
Flashing yellow
(3 Hz) The port fails POST.
Speed
OFF No link is present.
ON The port is operating in full duplex
mode.
Green
Flash Data is being received/sent on the
port.
Yellow — —
Flashing yellow
(3 Hz) The port fails POST.
1000
Base
SFP
port
LED
—
Duplex
OFF No link is present.

Installation Manual
H3C S3100-52P Ethernet Switch Chapter 1 Product Overview
1-4
LED Mark Color Indicates
POST
running
PWR flashes
green
The POST test ID (in the range 1
to 9).
POST
failed
PWR flashes
yellow
The POST test ID of the failed
test.
Software
downloa
ding
PWR flashes
green
A bar rotates clockwise around the
display.
Fan
failed PWR stays red “F”, meaning the FAN fails.
7-
segme
nt
digitron
display
Unit
Unit id Button
released
UNIT ID in the fabric; and for a
standalone unit, “1”
III. Attributes of the 10Base-T/100Base-TX Ethernet ports
Table 1-3 Attributes of the 10Base-T/100Base-TX Ethernet Ports on the S3100-52P
Attribute Description
Connector RJ-45
Number of ports 48
Rate
z10 Mbps, half duplex/full duplex
z100 Mbps, half-duplex/full duplex
zMDI/MDI-X auto-sensing
Standard IEEE 802.3u
Transmission segment over the selected
medium
100 m (328.08 ft) over the category-5
unshielded twisted pair (UTP) cable
IV. Console port
The S3100-52P Ethernet switch provides one EIA/TIA-232 compliant Console port for
local or remote switch configuration.
Table 1-4 Console port attributes
Attribute Description
Connector RJ-45
Standard EIA/TIA-232
Baud rate 9600 bps (default)

Installation Manual
H3C S3100-52P Ethernet Switch Chapter 1 Product Overview
1-5
Attribute Description
Service
zConnection to the ASCII terminal
zConnection to the serial interface of a local terminal
(a PC for example) or to a remote terminal (through
a pair of modems), where terminal emulation
program is run
V. Attributes of the 1000 Mbps SFP ports
The S3100-52P Ethernet switch provides four gigabit SFP interfaces (numbered 49 to
52) on its front panel. You can choose SFP modules as needed. The available SFP
modules are listed in Table 1-5. Enough available SFP modules and their hot
swappable feature allow you to do networking more flexibly.
Table 1-5 SFP modules supported by the S3100-52P Ethernet switch
Item Specific model
Gigabit SFP modules
zSFP-GE-SX-MM850-A
zSFP-GE-LX-SM1310-A
zSFP-GE-LH40-SM1310
zSFP-GE-LH40-SM1550
zSFP-GE-LH70-SM1550
Electrical port SFP
module SFP-GE-T
SFP
modules
Gigabit BIDI modules zSFP-GE-LX-SM1310-BIDI
zSFP-GE-LX-SM1490-BIDI
Note:
zFor specifications of each SFP module, refer to H3C Low-End Series Ethernet
Switches Pluggable modules manual.
zThe available SFP modules may change as time goes by. For the updated
information about SFP modules, ask H3C marketing or technical support personnel.
1.2.2 Rear Panel
The S3100-52P Ethernet switch has an AC power socket and a grounding screw on its
rear panel, as shown in Figure 1-2.

Installation Manual
H3C S3100-52P Ethernet Switch Chapter 1 Product Overview
1-6
(1): AC-input power socket (2): Grounding screw
Figure 1-2 Rear panel of the S3100-52P
Following are the input voltage specifications of the S3100-52P Ethernet switch:
Rated voltage: 100 to 240 VAC; 50 to 60 Hz
Max. tolerance: 90 to 264 VAC; 50 to 60 Hz
1.3 System Features of the S3100-52P Ethernet Switch
Table 1-6 System features of the S3100-52P
Item S3100-52P
Dimensions (Height x width x depth) 43.6 x 440 x 260 mm (1.72 x 17.32 x 10.24
in.)
Weight 4 kg (8.82 lb)
Management port 1 Console port
Service port 48 x 10/100 Mbps electrical ports and four
1000 Mbps SFP ports
Input voltage
S3100-52P Ethernet Switch only support
AC power input.
AC:
Rated voltage: 100 to 240 VAC; 50 to 60 Hz
Max. tolerance: 90 to 264 VAC; 50 to 60 Hz
Power consumption (full load) 50 W
Operating temperature 0 to 45 C (32 to 113 F)
Relative humidity (noncondensing) 10% to 90%

Installation Manual
H3C S3100-52P Ethernet Switch Chapter 2 Preparing for Installation
2-1
Chapter 2 Preparing for Installation
2.1 Safety Precautions
To avoid any device impairment and bodily injury caused by improper use, observe
these rules:
zBefore cleaning the switch, unplug the power plug of the switch first. Do not clean
the switch with wet cloth or liquid.
zDo not place the switch near water or any damp area. Prevent water or moisture
from entering the switch chassis.
zDo not place the switch on an unstable case or desk. The switch might be
damaged severely in case of a fall.
zEnsure proper ventilation of the equipment room and keep the ventilation vents of
the switch free of obstruction.
zMake sure that the operating voltage is the same one labeled on the switch.
zDo not open the chassis while the switch is operating or when electrical hazards
are present to avoid electrical shocks.
zWhen replacing interface cards, wear ESD-protective gloves to avoid damaging
the cards.
2.2 Installation Site
The S3100-52P Ethernet switch must be used indoors. You can mount your switch in a
rack or on a tabletop/workbench, but make sure:
zAdequate clearance is reserved at the air inlet/exhaust vents for ventilation.
zThe rack or table/workbench has a good ventilation system.
zThe rack is sturdy enough to support the device and its accessories.
zThe rack or table/workbench is well earthed.
To ensure normal operation and long service life of your VG, install it in an environment
that meets the requirements described in the following subsections.
2.2.1 Temperature/Humidity
You must maintain a proper temperature and humidity in the equipment room.
Long-term high humidity may lead to bad insulation, electricity leakage, mechanical
property changes, and corrosion. However, if the relative humidity is two low, captive
screws may become loose as the result of contraction of insulation washers and static
electricity may be produced in a dry environment to jeopardize the CMOS circuits on
the device. High temperature is the most undesirable condition, because it accelerates

Installation Manual
H3C S3100-52P Ethernet Switch Chapter 2 Preparing for Installation
2-2
aging of insulation materials and can thus significantly lower reliability and service life of
your switch.
For the temperature/humidity requirement on the S3100-52P switch, refer to section
1.3 “System Features of the S3100-52P Ethernet Switch”.
2.2.2 Cleanness
Dust is a hazard to the operating safety of your device. The dust accumulated on the
chassis can be adsorbed by static electricity and result in poor contact of metal
connectors or metal contact points. This can not only shorten the service life of your
device but also cause communications failures. When the relative indoor humidity is
low, electrostatic adsorption is more likely to happen. The contents of the dust must be
limited as shown in Table 2-1:
Table 2-1 Dust content limits in an equipment room
Substance Unit Content
Dust Particles/m³
≤3 X 104
(No visible dust on the
tabletop for three days)
Remark: the diameter of a dust particle ≥5μm
Besides dust, there are rigorous limits on the harmful gases that can accelerate the
erosion and aging of metals, such as salts, acids, and sulfides, as shown in Table 2-2.
Table 2-2 Harmful gas limits in the equipment room
Gas Maximum (mg/m3)
SO20.2
H2S 0.006
NH30.05
Cl20.01
2.2.3 Electromagnetic Susceptibility
The operation of your switch can be affected by external interferences, such as
conducted emission by capacitance coupling, inductance coupling, electromagnetic
wave radiation, and common impedance (including the grounding system) coupling,
and leads (power cords, signaling cables and output wires. To eliminate the
interferences, make sure to:

Installation Manual
H3C S3100-52P Ethernet Switch Chapter 2 Preparing for Installation
2-3
zFor the AC power supply that adopts TN system, use a monophase three-line
power socket with Protection Earth (PE) to effectively filter interference from the
power grid.
zKeep the device far from radio transmitting stations, radar stations, and
high-frequency devices.
zUse electromagnetic shielding when necessary, for example, use shielded
interface cables.
zRoute interface cables only indoors to prevent signal ports from getting damaged
by overvoltage or overcurrent caused by lightning strikes.
2.2.4 Laser Safety
The S3100-52P Ethernet switch is a class-1 laser device.
If the extended optical modules on your switch are operating, do not stare into the
optical ports because the laser light emitted by the optical fiber can hurt your retina.
Caution:
Staring into the laser beam produced by the fiber can hurt your eyes.
2.3 Installation Tools
zFlat-blade screwdriver
zPhillips screwdriver
zESD-preventive wrist strap
Caution:
The installation tools are not provided with the S3100-52P Ethernet Switch.

Installation Manual
H3C S3100-52P Ethernet Switch Chapter 3 Installing the Switch
3-1
Chapter 3 Installing the Switch
Caution:
When you ask your sales agent to maintain the switch, you must ensure that the
dismantlement-preventive seal on a mounting screw of the switch chassis is intact. If
you want to open the chassis, you should contact the agent for permission. Otherwise,
you will bear any consequence resulted from your actions without permission.
3.1 Installing a Switch
3.1.1 Cabinet Mounting
You can install a switch into a 19-inch standard cabinet in one of the following four
ways:
zUse front mounting ears
zUse front mounting ears and a tray
zUse front mounting ears and guide rails
Note:
Guide rails purchased from H3C apply only to standard cabinets 1,000 mm (39.4 in)
deep. Use other supports to substitute for guide rails in the case of other cabinet
depths.
I. Introduction to mounting ear
Figure 3-1 shows the appearance of a front mounting ear.

Installation Manual
H3C S3100-52P Ethernet Switch Chapter 3 Installing the Switch
3-2
(1) (2)
L2
r
L1
(1): Screw hole used to fix the mounting ear to the cabinet (Use one M6 screw)
(2): Screw hole used to fix the switch to the mounting ear
Figure 3-1 Appearance of a standard front mounting ea
Note:
If you install a S3100-52P switch into a 19-inch standard cabinet, the configuration type
of the front mounting ear is standard configuration.
II. Use front mounting ears to install a switch
Follow these steps to mount a switch into a 19-inch standard cabinet:
1) Wear an ESD-preventive wrist strap to check the grounding and stability of the
cabinet.
2) Take out the screws which are packed together with the front mounting ears, and
fix one end of mounting ears to the switch, as shown in Figure 3-2.
Front panel
) Figure 3-2 Fix front mounting ears (1

Installation Manual
H3C S3100-52P Ethernet Switch Chapter 3 Installing the Switch
3-3
3) Place the switch horizontally in a proper position, and fix the other end of mounting
ears to the front brackets with screws and captive nuts, as shown in Figure 3-3.
Front panel
Fr
Front square-holed
Front
mounting ear
ont mounting ear
bracket
Front panel
Fr
Front square-holed
Front
mounting ear
ont mounting ear
bracket
Figure 3-3 Fix front mounting ears (2)
III. Use front mounting ears and a tray
Follow these steps to install a switch into a 19-inch standard cabinet:
1) Wear an ESD-preventive wrist strap to check the grounding and stability of the
cabinet.
2) Fix the delivered tray horizontally in a proper position.
3) Take out the screws which are packed together with the front mounting ears, and
fix one end of mounting ears to the switch, as shown in Figure 3-2.
4) Place the switch on the tray horizontally, slide the tray into the cabinet, and fix the
other end of mounting ears to the front brackets with crews and captive nuts, as
shown in Figure 3-3.
IV. Use front mounting ears and guide rails
zIntroduction to guide rail
Figure 3-4 shows the appearance of a guide rail.

Installation Manual
H3C S3100-52P Ethernet Switch Chapter 3 Installing the Switch
3-4
Slotted hole 1 Cooling hole Slotted hole 2
il
Slotted hole 1: Used to fix the guide rail to the rear bracket. You can adjust the screw hole
position according to the position of the switch.
Cooling hole: Used for heat dissipation between switch and cabinet
Slotted hole 2: Used to fix the guide rail to the front bracket
Figure 3-4 Appearance of a guide ra
Note:
Guide rails purchased from H3C apply only to standard cabinets 1,000 mm (39.4 in)
deep. Use other supports to substitute for guide rails in the case of other cabinet
depths.
zInstallation procedure
Follow these steps to install a switch into a 19-inch standard cabinet
Wear an ESD-preventive wrist strap to check the grounding and stability of the cabinet.
2) Take out the screwed packed together with the front mounting ears and fix one end
of the front mounting ears to the switch, as shown in Figure 3-2.
3) Install guide rails on the brackets on both sides of the cabinet with M5 self-tapping
screws, as shown in Figure 3-5.

Installation Manual
H3C S3100-52P Ethernet Switch Chapter 3 Installing the Switch
3-5
Figure 3-5 Install guide rails
4) Hold the two sides of the switch and slide it gently along the guide rails into the
cabinet until it is located in a proper position, as shown in Figure 3-6. Ensure that
the bottom side of the guide rails and the switch are in close contact.
Front panel
s Figure 3-6 Install front mounting ears and guide rail
5) Fix the other end of front mounting ears to the front brackets of the cabinet with M6
screws and captive nuts and ensure that the front mounting ears and guide rails
have fixed the switch in the cabinet securely, as shown in Figure 3-7.
