HAEGER KS-100C User manual

- - 1 - -
Product：CHEST FREEZER
Catalog：
1、specification
2、exploded view
3、part list
4、system diagram
5、circuit diagram
6、trouble shooting
Server manual
1、specification
MODEL KS-100C/KS-200C/KS-300C
KS-103C/KS-203C/KS-3-3C
TYPE CHEST FREEZER

- - 2 - -
2、Exploded view

- - 3 - -
3、Part list
No Chinese Name Part Name Quantity 备注
1 门边框 Door frame 2
2 门壳 Door panel 1
3 门封条 Door gasket 1
4 网篮 Basket 1
6 围框 Frame 1
7 箱体 Body 1
8 温控器 Thermostat 1
9 温控面罩 Thermostat lid 1
10 温控旋钮 Thermostat control knob 1
11 指示灯 Indicator light 1
12 开关 Switch 1
13 单向轮 Wheel 2
14 电源线 Power supply card with plug 1
15 过滤器 Filter 1
16 压缩机连线 Compressor connect wire 1
17 温控连线 Thermostat connect wire 1
18 百叶窗 Window shade 1
19 压线板 Press line board 1
20 压线板螺钉 Press line board bolt 2
21 铁件接线盒 Junction box 1
22 接线支架 Connection bracket 1
23 压缩机底板螺钉 Compressor base bolt 4
24 压缩机底板垫片 Compressor base washer 4
25 压缩机底板 Compressor base 1
26 橡胶垫 Rubber washer 1
27 加液管 Refrigerant pipe 1
28 压缩机 Compressor 1
29 热保护器 Overload protect 1
30 启动器 PTC starter 1
31 罩壳 Cover 1
32 卡簧 Clip reed 1
33 冷凝管 Condenser 4
34 弹簧铰链 Spring gemel 2
35 铰链垫片 Gemel washer 2
36 铰链螺钉 Gemel bolt 8
37

- - 4 - -
38
39
4、system diagram

- - 5 - -
5、Wiring diagram
6、Trouble shooting guide
N
O. Problem Possible cause
1 The freezer does not get
cold at all Not plug in. The circuit breaker tripped or fuse.
The freezer temperature control is set at “OFF”。
2 The freezer does not get
cold enough. The freezer control dial set to “1” The freezer place in direct sunlight/near a stove or the door
is not closed completely.
The door being opened and closed frequently。
The door gasket does not seal properly.
The freezer overloaded。
3 Vibrations The freezer is not level and firm.

- - 6 - -
4 The freezer is noisy The ratting noise may come from the flow of the freezer
which is normal。
Contraction and expansion of the inside walls may cause.
The freezer unstable or touching the well.
The freezer is not level.
5 The door will not close
properly. The freezer is not level. The doors were not properly installed。
The gasket is dirty and distortion。
6 The light does not work The switch is in the “off” position.
The home circuit breaker or fuse has tripped.
The gasket is dirty and distortion.
7 Operating for all long time The ambient temperature is too high and temperature
controller in freezer chamber is set at strong position.
Too much food is placed in the freezer.
The door is not closed completely or the gasket not sealing
Open the door too often.
