Hajj PT80 User manual

1
User Manual of
GPS Watch

2
Product interface
1.Family number 1
User can long press number1 button to initiate a phone to call the configured number, short press the
number1 button to turn to watch menu page
2.Power
Press power button for 3-5 seconds to power on off the device
3.Family number 2
long press number2 button to call the configured number, short press the button to see the phone
book, user can choose the number and long press the button 2 to call the number.
4. USB port
Connect USB port to computer via USB cable for charging the device
5.SIM card slot
Insert Mirco SIM card with GSM band before using the device
6. SOS button
Long press sos button 3 seconds after setting sos number for calling out.

3
Please read this manual carefully before attempting installation.
1. Notice before use
1.1 Check
Please check the accessories:
GPS watch 1pc, User manual 1pc, USB cable or charger 1pc .
1.2 Charging
·Connect GPS watch to charger with USB cable. It needs 2~3 hours to chagre.
·The watch can work well during charging.
1.3 Install SIM card
·Only micro SIM card accepted:
Note Make sure the GSM SIM card supplies all of the functions as blow
1. Enough balance of the SIM card
2. The 2G GPRS function
3. The caller ID display function
4. The voice call function.
2. Quick Start
2.1 Set APN
Normally, the watch can search and set the APN automatically, or it can be set manually.
Command format (All characters in English):
pw,password,apn,apn-name,apn-username,apn-password,MCCMNC#
Example:pw,123456,apn,wap.tmobil.cl,wap,wap,73002#
2.2 Set Server
To connect tracking platform, please send the SMS command to set the server.
Command format:
pw,password,ip, x.x.x.x,port #
Example:pw,123456,ip,198.11.183.28,5088#
2.3 Login
Login mobile app to register and tracking the watch. Details refer to user manual of mobile APP.
3. Download the app
User can check GPS tracker remotely via android iOS app or PC,
For Android,
You can download the app from "play store" by searching "Amber360"
For iPhone,
You can download the app from "app store" by searching "Amber360"
For PC
www.amber360.com
3.1 Login the app
 Click the icon “Amber360” on desktop and register an account by App, then login our app with
the account.

 Adding tracker device by
input
4
input
ting the id number.

3.2 Live tracking
User can live track both the positioin of gps tracker and smartphone via the app. For indoor location,
gps tracker get the position by WiFi
by GPS.
3.3 Voice talkback
User can send voice message to gps tracker by pressing “Hold down speak” on smartphone, and user
can also the press “Call button” on the gps watch to
smartphone.
5
User can live track both the positioin of gps tracker and smartphone via the app. For indoor location,
gps tracker get the position by WiFi
mapping and LBS, For outdoor position, gps tracker get position
User can send voice message to gps tracker by pressing “Hold down speak” on smartphone, and user
can also the press “Call button” on the gps watch to
record voice message and then send it to
User can live track both the positioin of gps tracker and smartphone via the app. For indoor location,
mapping and LBS, For outdoor position, gps tracker get position
User can send voice message to gps tracker by pressing “Hold down speak” on smartphone, and user
record voice message and then send it to

3.4 Previous track playback
Previous track could find the route map for nearly three months by choosing the beginning and
ending time.
3.5 Geofence
Click on the upper right corner
“+”under main menu for setup geofence.Then the device will lock
device’s present
position as center automatically, then adjust the radius
(default radius is 100 meters, recommended radius is 500 meters) .Save settings by clicking
The device will send message when the device is out of the range.
3.6 Message
All received messages of can be found in “Alarm information”
low battery alarm, geofence alarm and etc.
6
Previous track could find the route map for nearly three months by choosing the beginning and
“+”under main menu for setup geofence.Then the device will lock
position as center automatically, then adjust the radius
distance by “+” “
(default radius is 100 meters, recommended radius is 500 meters) .Save settings by clicking
The device will send message when the device is out of the range.
All received messages of can be found in “Alarm information”
,
such as emergency call
low battery alarm, geofence alarm and etc.
Previous track could find the route map for nearly three months by choosing the beginning and
“+”under main menu for setup geofence.Then the device will lock
distance by “+” “
－” on map
(default radius is 100 meters, recommended radius is 500 meters) .Save settings by clicking
“Save”.
such as emergency call
, offline alarm,

4. Settings
Select
“settings” in main front menu, then you will enter into settings of the device. Settings includes:
Working mode, Admin number, Whitelist, Phonebook, Voice Monitoring, Language and Timezone,
Remote Shutdown etc.
4.1 Setup working mode
The device can setup GPS
data uploading interval in working mode setting, which it is related to the
standby time of battery.
1. Tracking every 10
seconds: Fast positioning mode and standby time is 8 hours.
2. Tracking every 10 minutes: Standard positioning and standby time is 48 hours.
3. Tracking every 1 hour:
Power saving
4.2 Setup admin number
Enter into “S
ettings”, click“set admin number” and input the admin phone number. The device will
send the alarm information to this number. The alarm information includes low battery alarm,
Geo-
fence alarm and other alarm.
4.3 Setup whitelist
Only the phone number in
the whitelist can call the device.
4.4 Setup phonebook
User can press the “Call button” on watch tracker and then choose one contact in phonebook to
initiate a call. Maxium 10 contact numbers can be setup in phonebook.
4.5 Setup Voice monitoring number
Th
e number in voice monitoring is same as admin number, after set admin number, press the headset
button in map page, watch will call to admin number, then admin number can listen into the watch
tracker and hear the voice around the watch.
4.6 Setup language
s and timezone
User can also setup the languages and the timezone for the device.
4.7 Other settings
1. Remote shutdown
7
“settings” in main front menu, then you will enter into settings of the device. Settings includes:
Working mode, Admin number, Whitelist, Phonebook, Voice Monitoring, Language and Timezone,
data uploading interval in working mode setting, which it is related to the
seconds: Fast positioning mode and standby time is 8 hours.
2. Tracking every 10 minutes: Standard positioning and standby time is 48 hours.
Power saving
mode and standby time is over 72 hours.
ettings”, click“set admin number” and input the admin phone number. The device will
send the alarm information to this number. The alarm information includes low battery alarm,
fence alarm and other alarm.
the whitelist can call the device.
User can press the “Call button” on watch tracker and then choose one contact in phonebook to
initiate a call. Maxium 10 contact numbers can be setup in phonebook.
4.5 Setup Voice monitoring number
e number in voice monitoring is same as admin number, after set admin number, press the headset
button in map page, watch will call to admin number, then admin number can listen into the watch
tracker and hear the voice around the watch.
s and timezone
User can also setup the languages and the timezone for the device.
“settings” in main front menu, then you will enter into settings of the device. Settings includes:
Working mode, Admin number, Whitelist, Phonebook, Voice Monitoring, Language and Timezone,
data uploading interval in working mode setting, which it is related to the
seconds: Fast positioning mode and standby time is 8 hours.
2. Tracking every 10 minutes: Standard positioning and standby time is 48 hours.
mode and standby time is over 72 hours.
ettings”, click“set admin number” and input the admin phone number. The device will
send the alarm information to this number. The alarm information includes low battery alarm,
User can press the “Call button” on watch tracker and then choose one contact in phonebook to
e number in voice monitoring is same as admin number, after set admin number, press the headset
button in map page, watch will call to admin number, then admin number can listen into the watch

8
Shutdown the the device remotely.
2. About device
It includes device name, device number and duration of platform and etc.
5 . Troubles & Shooting
Troubles Shootings
Device is not enabled on
app Please check if：
1. SIM card is not enabled
2. apn is not setup
Device is offline on APP Please check if：
1.1.1 1. SIM card no singal
2. GPRS is canceled or not enabled
1.1.2 3. The SIM card is in debts
Positioning is not accurate The device support two modes of positioning,
1.GPS positioning is mainly for outdoor positioning, the
accutracy is around 10 meters.
2.GSM positioning is mainly for indoor positioning, the
accuracy for LBS positioning is around 500-1000 meters.
