Half Off Ponds VARIABLE FLOW Series User manual

VARIABLE FLOW SERIES
SUBMERSIBLE WATER PUMP
OWNER’S MANUAL
PLEASE READ THIS MANUAL
SAVE FOR FUTURE REFERENCE
ATTENTION: NEVER OPERATE THIS PUMP OUT OF WATER
This pump requires to be submerged in fresh-water only during operation.

THE INSTRUCTIONS AND WARNINGS HEREIN PRESUME EXISTING FAMILIARITY WITH THE
DESIGN AND FUNCTION OF THESE AND SIMILAR PRODUCTS AND THEIR COMPONENTS.
The model(s) represented in this manual may have additions and/or modifications made at any time. Pictures represent a standard unit
series and an actual unit may vary slightly. This manual is based on the latest products′ information available at the time of creation or
last revision. It is believed to be generally accurate and reliable. Please consult our customer service representatives here at Half Off
Ponds if detailed information is desired, or whenever there is a question about a given unit’s configuration or performance specifications
at 1-866-831-6558.
VARIABLE FLOW SUBMERSIBLE WATER PUMP
MODEL CHART
Variable
Flow
Series
Model #
Rated
Voltage /
Hertz
Rated
Watts
Rated
Current
Input
(Amps)
Pump
Output
Diameter
Fitting
Output
Diameter
Recommended
Hose
Diameter
Max
Head
Height
Max
Flow
(GPH)
VF-4000
120V,60Hz
45-130w
2A
2”
2”
2”
19’
4,000
VF-5800
120V,60Hz
80-200w
3A
2”
2”
2”
24’
5,800
VF-8000
120V,60Hz
130-335w
4.4A
2”
2”
3”
31’
8,000
Introduction
Congratulations on your purchase of a Half Off Ponds’ Variable
Flow Series Water Pump! Thank you for being a valued
customer! We are grateful for the opportunity to provide you with
superior products, such as an Variable Flow Series Water Pump
that is manufactured to the highest standards using quality
materials.
Safety First
It is recommended that you thoroughly read and understand this manual prior to first startup and before you attempt to service the
model to which Variable Flow Series Submersible Water Pump this applies.
If you have any questions, we’ll be happy to help. Please call us, at 1-866-831-6558.
THE FOLLOWING CAUTIONS AND WARNINGS ARE FOR YOUR OWN SAFETY!
Attention: This pump is not intended for use by persons, (including children) with reduced physical
sensory or mental capabilities, or lack of experience and knowledge, unless they have been given
supervision or instruction concerning use of the pump by a person responsible for their safety.

This pump is designed to be submerged during operation for
proper function and cooling. Never operate this pump without
it being fully submerged in fresh-water only.
Never pick up pump by, remove, or put stress on the cord.
Never operate this pump connected to any voltage other than
that shown on the pump.
Never place your hand, or any object, in or near the inlet
opening while this equipment is operating. If pump inlet is
clogged, always turn off the power supply first and wait until
motor is completely stopped before removing any clogged
material.
Never operate this pump in a swimming pool or in a marina
area.
Never leave children unattended around this pump while
operating.
The pump has a built-in thermal overload trip which prevents
the pump from overheating. Never restart the pump before
letting the pump cool down.
Always have this pump connected to properly grounded
GFCI electrical outlet.
Always disconnect from electrical supply before handling
pump.
Remember, Correct Installation Is Your Responsibility!
Make sure you have the proper installation conditions. The Variable Flow Series Submersible Water Pump needs to be protected
from any objects/debris during operation. Before beginning assembly or operation of product, make sure all parts are present.
If any part of your Variable Flow Series Submersible Water Pump is missing or damaged, do not attempt to assemble, install, or
operate.
Plumbing
For maximum water flow, it is recommended that the largest tubing size
for your pump is used during your installation. Selecting the correct
tubing for your project is crucial for the durability of the installation.
We highly recommend using our Freeze Flex tubing!
Freeze Flex is ideal for ponds and waterfalls requiring quality high-
strength flexible tubing that resists kinking and collapsing.
Refer to the Variable Flow Series Submersible Water Pump Model
Chart for proper hose size recommendations depending on your
model.
Attention: Do not operate this pump under any condition other than those for which it is specified.
Failure to observe these precautions can result in serious injury and will void the warranty!

Electrical Requirements
This pump is rated at 120 Volts 60Hz. Only use a power supply rating voltage at 120
volts and 60Hz, which complies with that listed on label on the Variable Flow Series
Submersible Water Pump. The cord must be plugged into a GFCI outlet that is properly
installed and grounded in accordance with all local codes and ordinances.
A hard-wired installation is not recommended and will result in the warranty being
voided!
It is your responsibility to contact a qualified electrician and assure that the electrical
installation is adequate and in conformance with all national and local codes and
ordinances. Make sure this pump is securely installed before any operation.
Operation
•For safety as well as proper performance and lifespan, we recommend Variable Flow pumps be installed inside of a skimmer
box, or similar filtration unit. We highly recommend not to place, nor operate, your Variable Flow Series Submersible Water
Pump directly into your pond. The pump should not be susceptible to damage from any loose debris, mud, or rocks in the
pond to prevent the filter from becoming clogged or cause serious damage to your pump, or any fish you may have in your
pond.
•Submerge the pump completely in the water to make the pump body fill with water.
•The water temperature should not exceed 95°F (35°C) and do not let the pump freeze in the wintertime.
•The electrical connection should be
secured in a water-proof place and should
be at least 6 feet (2 meters) away from the
water feature. Ensure that the electrical
cord loops below the electrical outlet to
form a “Drip Loop”. This will prevent water
from running down the cord into the
electrical outlet.
•Never operate this pump on an extension cord; doing so causes a drop in volts and will result in a voided warranty.
•A minimum water level of approximately 6 inches is required to prevent the pump from taking in air.
•The pump can be switched on by simply plugging it in and switched off by un-plugging it.
•A routine maintenance schedule is critical for proper operation of your pump and will give it a longer operational-life. For
proper cleaning, refer to the maintenance section of this manual.
•If you have any issues with your pump, refer to the trouble shooting section of this manual.
Troubleshooting
If your pump fails to start, or slows down significantly under load, regardless of water level, disconnect from power supply and check the
following conditions:
•Check that the supply voltage is correct.
•Verify rotor/impeller can turn freely in the proper direction.
•Check plug and cord for damage.
•Check to see if any dirt entered the output assembly. If so, cleaning instructions are explained within the maintenance section.
•Check to see if any of your hoses or jets have become clogged. Clean them if necessary.
•Ensure the pump has sufficiently cooled down if overheating has occurred.
Maintenance
It is your responsibility to upkeep on the maintenance on your Variable Flow Series Submersible Water Pump. You must conduct
regular routine inspections and make necessary repairs to your pump in order to maintain proper operations.
If the pump is housed in a skimmer make sure the screens and filters in the skimmer are kept clean and free of debris. This will allow
water to flow unrestricted into the pump chamber.
If the pump is operated directly in the water feature, make sure the pump intake screen is kept clean and free of debris.
Every water feature is different; learn how frequently your pump needs to be cleaned to allow unrestricted water flow.
Pumps that become damaged due to restricted water flow (running “dry”) are not covered under the terms of the warranty.
EXAMPLE OF A GFCI OUTLET
(GROUNDED FAULT CIRCUIT INTERRUPT)
RESET BUTTON
TEST BUTTON
Attention: Repeating cycles of stopping and restarting will damage this pump. Do not continue operation at low
water level or while the inlet is clogged with debris. It may cause noise, heavy vibration, and pump damage.

Function Button Lock：
While the pump is running, press the “▲” or “▼“ button for three seconds until the LED light flashes for 3
seconds, the controller locked; Similarly, press the “▲” or “▼“ button for 3 seconds again, LED indicator light
flashes for three times, the controller is now unlocked.
Screen Saver:
Once the controller is plugged into the GFCI outlet. If no buttons are pressed for 17 seconds the controller will
enter screen saver mode. It will wake up when you press any button.
Data memory function:
When the pump powers down, the controller keeps the same settings in memory.
Error Codes
.
•Er01: Controller current issue, check the GFCI and unplug the pump to reset it.
•
•Er02: Controller overheating; Move the controller to a shaded area, it might need a cover over it to keep
it out of the sun.
•
•Er03: The pump is running dry. Check the pond and skimmer water level and make sure the skimmer
leaf basket, and pump intake screen is clear of debris.
•
•Er04: The pump was blocked; The impeller is blocked, clean the pump and impeller to ensure the
impeller can rotate.
•
•Er05: Controller voltage issue; check the GFCI and unplug the pump to reset it
LED Digital Display
ON/OFF
Flow Adjustment

SEE OUR FULL SELECTION
www.halfoffponds.com
Complete Pond & Pondless Kits
Largest online selection of complete, everything-you-need. Choose from our standard kits, semi-custom or full
custom potions.
Pond Liner
Half Off Ponds offers the widest range of pond liner materials and sizes.
Your trusted source for EPDM, PVC & LLDPE liners.
Attention: We recommend that you remove the pump from the water feature and soak it for up to 36 hours
in a solution of CLR (Calcium Lime Rust) and water at least once a year, before pond winterization and
storing your pump. Rinse thoroughly before re-installing the pump in the water feature.

Submersible Pond Pumps
Complete range of energy efficient small statuary and fountain pumps to high flow 12,500+ GPH large
fish pond and waterfall pumps.
Water Treatments
Create healthy environments for your
water garden or prized koi fish.
Fish Food
Select from growth, color enhancing, or
cold weather formulations.
Pond & Landscape Lighting
Beautiful finishing touches
that show off your pond &
landscape.
Lighted Spillways & Kits
Build striking formal falls with
lighted acrylic & stainless-
steel spillways.

LIMITED WARRANTY
Products manufactured by are warranted to the original user only to be free of defects in material and workmanship for a
period of 24 months from the date of purchase, but not more than 30 months from the date of manufacture. HALF OFF
PONDS liability under this warranty shall be limited to repairing or replacing, at HALF OFF PONDS’s discretion, without
charge, F.O.B. HALF OFF PONDS will not be liable for any cost of removal, installation, transportation, or any other
charges which may arise in connection with a warranty claim.
Products which are sold but not manufactured by HALF OFF PONDS are subject to the warranty provided by the
manufacturer of said product(s) and not by HALF OFF PONDS’s warranty. HALF OFF PONDS will not be liable for
damage or wear to products caused by abnormal operating conditions, accident, abuse, misuse, unauthorized alteration
or repair, or if the product was not installed in accordance with HALF OFF PONDS’s printed installation and operating
instructions.
To obtain service under this warranty, the defective product must be returned to the distributor or dealer of HALF OFF
PONDS’s products from which it was purchased together with proof of purchase and installation date, failure date, and
supporting installation data. Unless otherwise provided, the distributor or dealer will contact HALF OFF PONDS or an
authorized service station for instructions. Any defective product to be returned to HALF OFF PONDS or a service
station must be sent freight prepaid: documentation supporting the warranty claim and/or a Return Merchandise
Authorization (RMA) must be included if so instructed. In the absence of suitable proof of purchase date, the effective
date of this warranty will be based upon the date of manufacture.
Any replacement product may be either new or like-new, provided that it has functionality at least equal to that of the
product being replaced. No requests for service under this warranty will be accepted if received more than 30 days after
the term of the warranty. Correction of defects, in the manner and for the duration of the warranty described in this
warranty, shall constitute complete fulfillment of all liabilities and responsibilities of HALF OFF PONDS to the user with
respect to the product, and shall constitute full satisfaction of all claims, whether based on contract, negligence, and
strict liability or otherwise. Except for the obligations specifically set forth in this warranty, in no event shall HALF OFF
PONDS be liable for direct, indirect, special, incidental, or consequential damages, whether based on contract, tort, or
any other legal theory and whether advised of the possibility of such damages.
HALF OFF PONDS reserves the right to change or improve its products or any portions thereof without being obligated
to provide such a change or improvement for units sold and/or shipped prior to such a change or improvement.
THERE ARE NO EXPRESS OR IMPLIED WARRANTIES, INCLUDING MERCHANTABILITY OR FITNESS FOR A
PARTICULAR PURPOSE, WHICH EXTEND BEYOND THOSE WARRANTIES DESCRIBED OR REFERRED TO
ABOVE EXCEPT AS EXPRESSLY HEREIN PROVIDED THE GOODS ARE SOLD “AS IS”, THE ENTIRE RISK AS TO
QUALITY AND FITNESS FOR A PARTICULAR PURPOSE, AND PERFORMANCE OF THE GOODS IS WITH THE
BUYER, AND SHOULD THE GOODS PROVE DEFECTIVE FOLLOWING THER PURCHASE, THE BUYER AND NOT
THE MANUFACTURER, DISTRIBUTOR, OR RETAILER ASSUMES THE ENTIRE RISK OF ALL NECESSARY
SERVICING AND REPAIR.
Some jurisdictions do not allow the exclusions or limitation of incidental or consequential damages and some
jurisdictions do not allow limitations on how long implied warranties may last or require you to pay certain expenses as
set forth above. Therefore, the above limitations or exclusions may not apply to you. This warranty gives you specific
legal rights and you may also have other rights which vary from jurisdictions to jurisdiction.
