HAMECO HV-45 User manual

User Manual V1.0
HV-45 (HM)
AI 4K UHD Video
Conference Camera
hameco
www.hameco.eu

www.hameco.eu
HV-45 User Manual
hameco
2
Content
Attention ....................................................................................... 3
1. Fast Installation ....................................................................... 3
1.1 Camera Interface ..................................................................... 4
1.2 Camera Operation ................................................................... 4
2. Product Overview .................................................................... 5
2.1 Product Introduction .............................................................. 5
2.1.1 Product Model ...................................................................... 5
2.1.2 Dimensions .......................................................................... 5
2.1.3 Accessories ........................................................................... 5
2.2 Main Features .......................................................................... 6
2.4 Interface Instruction ............................................................... 9
2.4.1 External Interface ................................................................ 9
3. Application Instructions ......................................................... 10
3.1 Remote Controlle .................................................................... 10
3.1.1 Key Instructions ................................................................... 10
3.1.2 Applications ......................................................................... 11
3.2 Menu Setting ........................................................................... 13
3.2.1 Main Menu ............................................................................ 13
4. Maintenance and Troubleshooting ...................................... 17
5. Product Disposal ...................................................................... 18

www.hameco.eu
hameco
3
ATTENTION
This manual introduces functions, installation and operations for the camera in detail.
Please read this manual thoroughly before installation and use.
1.How to Use
To prevent damage to this product or any product connected to it, this product can only be used within
1). Do not expose the product to rain or moisture.
2). In order to prevent the risk of electric shock, do not open the case. Installation and maintenance
3).
4). Wipe it with a soft, dry cloth when cleaning the camera lens. Wipe it gently with a mild detergent if
image.
2.Electrical Safety
Installation and use of this product must strictly comply with local electrical safety standards.
3.Handle with Care
Avoid damage to product caused by heavy pressure, strong vibration or immersion during transporta-
tion, storage and installation.
4.Install with Caution
1). Do not rotate the camera head violently, otherwise it may cause mechanical failure.
2). This product should be placed on a stable desktop or other horizontal surface. Do not install the
product obliquely, otherwise it may display an inclined image.
3).
trays.
4). Housing of this product is made of organic materials. Do not expose it to any liquid, gas or solids
which may corrode the shell.
5). Ensure there are no obstacles within rotation range of the holder.
6). Do not power on before complete installation.
5.Do not Disassemble the Product Without Permission
This product contains no parts which can be maintained by users themselves. Any damage caused by
the user dismantling the product without permission is not covered by the warranty.
6.Magnetic Interference
cause radio interference in household application. Appropriate measures should be taken.
HV-45 User Manual

www.hameco.eu
hameco
4
1. FAST INSTALLATION
1.1 CAMERA INTERFACE
Figure 1.1 camera interface
1.2 Camera Operation
1. Product Installation: Fix the device on an LCD screen, on top of a computer;
or put it directly on a desk or tripod mounting.
2. Connect camera via USB cable to computer, video conference terminal or
other USB input device, log into the video conference software and select a
video device to have image output.
1.camera lens
2.bracket
3. built-in MIC
5. positioning hole
6. USB 3.0 output interface
HV-45 User Manual

www.hameco.eu
hameco
5
2. PRODUCT OVERVIEW
2.1 Product Introduction
2.1.2 Dimensions
2.1.3 Accessories
2.1.1 Product Model
hameco HV-45
AM -- 83° VCM Motor Lens
HM -- 120° Fixed Lens
Accessories
User manual 1
Wireless remote controller 1 piece
USB3.0 cable 1 piece
Warranty card 1 piece
Cushion
HV-45 User Manual

www.hameco.eu
hameco
6
2.2 Main Features
This product is a new 4K UHD ePTZ video conference camera. It is built with AI func-
tions, which can automatically frame all people in the meeting and place them in the
middle of the scene. It also has perfect functions and superior performance,
which adopts advanced ISP processing algorithms in order to provide vivid
images with evenly clear brightness, strong color layering, high resolution, and
fantastic color rendition. Easy and convenient to install and maintain, stable and reliable.
• 4K UHD:
It employs a 1/2.5 inch, 8 million-pixel high
quality CMOS sensor; supports 4K UHD;
provides 4K@ 30fps MJPG video resolution
at most; and provides clear UHD video and
vivid expressions and movements. At the
same time, it is compatible with 1080p and
• EPTZ:
EPTZ and 4X digital Zoom
• Built-in pickup:
Includes 2 built-in pick-ups, all-round pick-
up. The antique noise suppression algo-
rithm ensures your voice is perfect. The ef-
fective pick-up distance is up to 5 meters.
•Dual stream output:
The USB 3.0 port supports main stream
and sub-stream output at the same time.
• Auto framing:
With an excellent facial detection algo-
rithm, the device automatically adjusts the
zoom according to the number of people in
the meeting. It can frame all of the meet-
ing participants and position them in the
middle of the scene.
• Wide view angle without distortion:
for options
• Low Noise and High SNR:
SNR of the video. Image is clear even un-
der low light conditions.
• Multiple Installations:
Standard equipped with mold clamp.
Easy to install on any device, such as LCD
screen, PC, table and tripod.
• Easy to Use:
No need to download driver; USB Plug and
play.
• Wide Application:
Personal video conferencing, enterprise
collaboration
etc...
HV-45 User Manual

www.hameco.eu
hameco
7
Model Number AM BM HM
Camera Parameter
Image Sensor 1/2.5 Inch High Quality 4K CMOS Sensor
8.28MP 16:9
Video output port 1* USB3.0, Type B, support audio output over USB3.0
Audio input 2 built-in MIC pickups
View Angle 93.5°(D)/83°(H)/ 53.1°(V) 126°(D)/120°(H)/85°(V)
Video Format
Min Illumination 0.1Lux (F1.8, AGC ON)
Lens f=3.5mm f=3.24mm
Aperture F2.0±5%
Digital zoom 4X
DNR 2D & 3D DNR
Ultra-low illumination
White Balance Auto / Manual/ One Push/ 3000K/ 3500K/ 4000K/ 4500K/ 5000K/ 5500K/
Focus Auto / Manual/ One push Focus (available on AM series)
Auto / Manual
HV-45 User Manual

www.hameco.eu
hameco
8
Auto framing
Backlight compensation
Dual stream
SNR >55dB
USB Feature
Operation Systems higher, Linux (Require to support UVC.)
Video Compression format YUY2, MJPG, H.264, H.265
Audio over USB3.0 Support
USB communication
protocol UVC, UAZ
PTZ control Support EPTZ
Hardware requirement /USB3.0 port ( USB 3.0 is needed for 4K)
Other Parameters
Input Voltage 5V
Input Current 1A (Max.)
Power consumption 5W (Max.)
Store Temperature
Store Humidity
Working
Temperature
Working Humidity
Dimension (W*H*D) 222mm×93.25mm×56.5mm
Weight Around 0.53kg
Application Indoor
Accessory User Manual; Warranty card, remote controller, USB3.0 cable
HV-45 User Manual

www.hameco.eu
hameco
9
2.4 Interface Instruction
2.4.1 External Interface
The interface illustration is as Figure 2.4 below:
HV-45 User Manual

www.hameco.eu
hameco
10
3. APPLICATION INSTRUCTIONS
3.1 Remote Controller
3.1.1 Key Instructions
1. Standby Key:
After pressing for 3 seconds, the camera will be in standby mode. Press again
for 3 seconds, and the camera will self-test again and go back to the HOME po-
sition. Note: If preset 0 is set, and there is no operation within 12 seconds, the
2.Camera Address Selection:
Select the camera address.
3.Number Key:
Set or call 0-9 presets.
4. *, # Key:
Key combination use:
is on, release hands. Power on the camera again, it will successfully be paired
with the WR controller.
is on, release hands. Power on the camera again, it will cancel pairing with the
WR controller.
5. Focus Control Key:
Auto Focus: Enter into auto focus mode.
Manual Focus: The camera focus mode is manual.
Lens near
7.Set or Clear Preset key:
8. Electronic Pan/Tilt Control Key:
Press Key : Up
Press Key : Down
Press Key : Left
Press Key: Right
“HOME” Key: Return to the middle position or enter into the sub-menu
9. BLC Control Key:
HV-45 User Manual

www.hameco.eu
hameco
11
10. Menu Setting
Open or close the OSD menu
Enter / exit the OSD menu or return to the previous menu
11. Address Setting
*# F1
* # F2
* #
* # : Camera Address No. 4
12. Key Combination Functions
1) # # # 2) * # 6
3) * # 9 4) * # 4
5) # 6) * # 0-9
7) * #
3.1.2 Applications
Power on the camera, press the “SET” and “ * ” keys together for 5 seconds, the indicator light will be
set and call preset positions via the wireless remote controller.
Key Instructions:
1. In these instructions, “press the key” means a click rather than a long held press, and a special sound
will be made if a long held press for more than one second is required.
2. * # F1 *
# F1
1) Camera Selection
Select the camera address to control.
2) Pan/Tilt Control
Up: pressDown: press
Left: pressRight: press
Press and hold the up/down/left/right key, the pan/tilt will keep running,
from slow to fast, until it runs to the endpoint; the pan/tilt running stops
as soon as the key is released.
HV-45 User Manual

www.hameco.eu
hameco
12
3) Presets
4) Zoom Control
5) Focus Control
1. Preset setting: To set a preset position, the users should press
set a relative preset. Note: 10 preset positions in total are available
by remote controller.
2. Preset calling: Press a number key 0-9 directly to call a relative
preset.
Note: Action is in vain if there is no relative preset position.
3. Preset clearing: To clear a preset position, the user can press the
press the number key 0-9 to
clear the relative preset.
presets.
ZOOM IN: press “ZOOM“ key ZOOM OUT: press “ZOOM” key
Press and hold the key, the camera will keep zooming in or
zooming out and stops as soon as the key is released.
Focus (near): focus+
Focus (far): focus-
Auto Focus: yes
Manual Focus: yes
Press and hold the key, the action of focus will continue and stops
as soon as the key is released.
6) Address Setting
*# F1
* # F2
* # F3
# F4
HV-45 User Manual

www.hameco.eu
hameco
13
3.2 Menu Setting
3.2.1 Main Menu
MENU
using the scroll arrow to point at or highlight the selected items.
MENU English
Language Default
Image Style
(Exposure)
(Color)
(Image)
(Focus)
(Noise Reduction)
(Auto Zoom)
(Double stream)
(Version)
(Restore Default)
Select Change Value
Mode: Auto, Manual, Shutter priority, Iris priority
and Brightness priority.
EV:
Compensation Level:
mode when EV is ON)
BLC: ON/OFF for options (only available in auto
mode)
close
Anti-Flicker: OFF/50Hz/60Hz for options (only
available in Auto/Iris priority/Brightness priority
modes)
Gain Limit:
priority /Brightness priority mode)
WDR:
1. press
2. Image Style Setting: press
3. Exposure Setting
HOME
(EXPOSURE SET) as follows:
Shutter Priority: 1/25,1/30,1/50,1/60,1/90,1/100,1/120,1/180,1/250,1/350,1/500,1/
1000,1/2000,1/3000,1/4000,
1/6000, 1/10000 (only available in Manual and Shutter priority mode)
Brightness:
HV-45 User Manual

www.hameco.eu
hameco
14
4. Color Setting
as follows:
5. Image Setting
HOME
COLOR
WB Mode
RG Tuning
BG Tuning
Saturation
Hue
AWB Sensitivity
Select Change Value
Auto
0
0
100%
7
High
WB Mode: Auto, Manual, One Push, 3000K,
3500K, 4000K, 4500K, 5000K, 5500K, 6000K,
RG Tuning:
mode)
BG Tuning:
mode)
Red Gain:
mode)
Blue Gain:
mode)
Saturation:
180%, 190%, 200%
Hue:
AWB Sensitivity: high/middle/low (only availa-
ble in Manual mode)
HV-45 User Manual

www.hameco.eu
hameco
15
6. Focus Setting
FOCUS MODE
Focus Mode
AF Zone
AF Sensitivity
NOISE REDUCTION
NR-2D
NR-3D
Select
Select
Change Value
Change Value
Auto
Center
Low
2
5
Focus Mode: Auto, manual, one-push
AF-Zone: Up, middle, down, overall
AF-Sensitivity: High, middle, low
2D Noise Reduction:
3D Noise Reduction:
7. Noise Reduction Setting
HOME
(NOISE REDUCTION) as follows,
HV-45 User Manual

www.hameco.eu
hameco
16
8. Auto Framing Setting
AUTO FRAMING
Auto Framing
RESTORE DEFAULT
Restore Default?
VERSION
CAM Version
Focus Version
Select
Select
Select
Change Value
Change Value
Change Value
Close
No
1.0.0 2019-7-31
1.0.6 2018-8-21
9. Dual Stream Setting
10. Version
Move the pointer to VERSION
11. Restore Default
HOME
RESTORE DEFAULT as below: Restore default: Yes/No for options (the video
format and color style won’t be restored).
Note: If the address of former remote is not 1
but another one from 2, 3, 4, the correspond-
ing camera address will restore to 1 when
all parameters or system parameters are
restored. User should change the remote ad-
dress to 1 (press No.1 according to the cam-
era so to get normal operation).
HV-45 User Manual

www.hameco.eu
hameco
17
4. MAINTENANCE AND TROUBLESHOOTING
4.1 Maintenance
1) Please disconnect the camera if it is not used for a long period time.
2) Use a soft cloth or tissue to clean the camera cover.
3) Wipe it with a soft, dry cloth when cleaning the camera lens. Wipe it gently with a mild
detergent if needed. Do not use strong or corrosive detergents to avoid scratching the
4.2 Troubleshooting
1) No video output
a. Check that the USB cable is properly connected and the power indicator light is ON.
b. Check whether the machine could perform a self-check after restarting.
c. Restart PC.
d. Check whether the camera is recognized by the PC.
2) Occasionally no image
a. Check the USB cable quality and whether it is properly connected.
3) Image dithering when zoomed-in or zoomed-out
a. Check whether the camera installation position is solid.
b. Check for shaking machines or objects around the camera.
4) Remote controller does not work
a. Re-match the camera and the wireless remote controller.
b. Set the camera address to 1 (The camera address will go back to 1 after restoring
default setting).
c. Check whether the battery installed on the remote control is low.
d. Check that the camera working mode is the normal operating mode (see Table 2.2
and Table 2.3).
e. Exit the menu. The menu is only displayed under MJPG/H.264/H.265 compression
format.
HV-45 User Manual

www.hameco.eu
HV-45 User Manual
hameco
18
Copyright Notice:
All the contents of this manual and the copyright ownership belong to our company.
Without the approval of the Company, no one can imitate, copy, reproduce or translate
arbitrarily. This manual contains no guarantee, standpoint expression or other
implications in any form. Specifications and information of this manual mentioned are
solely for informational purposes information is for reference only and subject to
change without notice.
All rights reserved. No reproducing is allowed without acknowledgement.
Declaration of conformity:
This product is in conformity with the relevant EU harmonisation legislation.
5.PRODUCT DISPOSAL
Safety
For your own safety, this product should only be used with CE and RoHS approved
equipment. Using this product with non-approved equipment would void the warranty.
Disposal of your product
Municipal waste stream. Old appliances must be collected separately in order to optimise
the recovery and recycling of the materials to reduce the impact on human health
and the environment. The crossed out “wheeled bin” symbol on the product reminds
you of your obligation that when you dispose of the appliance, it must be separately
collected. Consumers should contact their local authority or retailer for information
concerning the correct disposal of their old appliance.
