Hamilton Engineering EVO 129-599 User manual

34000 Autry Street, Livonia, MI 48150 | 800.968.5530 | Fax [phone] | www.hamiltonengineering.com | LIT91110 REV 06/2018
Hamilton Engineering
EVO 129 –599
FMT-914 Control Congurations
Do not store or use gasoline or other
ammable vapors and liquids in the vicinity
of this or any other appliance.
WHAT TO DO IF YOU SMELL GAS:
• Do not try to light any appliance
• Do not touch any electrical switch
• Do not use any phone in your building
Immediately call your gas supplier from a
neighbor’s phone. Follow the gas supplier
instructions. If you can not reach your gas
supplier, call the re department.
If the information in this manual
is not followed exactly, a re or
explosion may result causing
property damage, personal
injury or death.
WARNING
New York Massachusetts SCAQMD CEC Listed
MEA 425-05-E Boilers: G1-06-06-24A Compliant Rule1146.2 California Energy Commission
Heaters: G1-06-06-24B
ANSI STD Z21-13/Z21.13A
Certied to CSA 4.9-2004
ANSI STD Z21.10.3/Z21.10.3.b
Certied to CSA 4.1-2004, add.A,B
WARNING
These appliances MUST be installed by a properly licensed individual in the City and State which the
unit is being installed. All start up adjustments and subsequent service work must be done by a similarly
licensed contractor or a factory trained service individual. Failure to comply could result in loss of
warranty and or severe personal injury, death and or substantial property damage. These instructions
are required to be kept with the appliance on the left side, in the pocket provided.
ANSI Z21.13-2014/CSA 4.9-2014
UL 795-2011/CSA 3.4
SCAQMD 1146.2

2
34000 Autry Street, Livonia, MI 48150 | 800.968.5530 | Fax [phone] | www.hamiltonengineering.com | LIT91110 REV 06/2018
TABLE OF CONTENTS
TABLE OF CONTENTS
Please note: It is imperative that you are familiar with the general information provided on pages 2-3 and page 6
in order to have a good understanding of the operation of the various congurations.
GENERAL DESCRIPTION
Components & Operations 3-4
CONFIGURATION #1
Domestic Hot Water
Single Heater 5
CONFIGURATION #2
Domestic Hot Water
Multiple Heater Cascade™ 6
GENERAL DESCRIPTION
Central Heating
System Operation 7
CONFIGURATION #3
Central Heating Only
Single Boiler 8
CONFIGURATION #4
Central Heating Only
Multiple Boiler Cascade™ 9
CONFIGURATION #5
Residential Heating w/Pumped DHW
Single Combi Boiler 10
CONFIGURATION #6
Central Heating w/Pumped DHW
Single Boiler 11
CONFIGURATION #7
Central Heating w/Pumped DHW
Multiple Boiler Cascade™ 12
CONFIGURATION #8
Central Heating w/3-way Valve DHW
Single Boiler 13
CONFIGURATION #9
Central Heating w/3-way Valve DHW
Multiple Boiler Cascade™ 14
WIRING DIAGRAM
HWD 129-199.8
Standard Wiring 15
WIRING DIAGRAM
HWH 129-199.8
Wiring w/o 3-way 16
WIRING DIAGRAM
HWH 129-199.8
Wiring w/3-way 17
WIRING DIAGRAM
HWD 199-599
Standard Wiring 18
WIRING DIAGRAM
HWH 199-599
Wiring w/o 3-way 19
WIRING DIAGRAM
HWH 199-599
Wiring w/3-way 20
WIRING DIAGRAM
HWH 79-599
Wiring Universal 21

3
34000 Autry Street, Livonia, MI 48150 | 800.968.5530 | Fax [phone] | www.hamiltonengineering.com | LIT91110 REV 06/2018
PRIMARY APPLIANCE CONTROL – is done utilizing the FMT 914 PCB as custom manufactured by SIT Controls of the
Netherlands for Hamilton Engineering, Inc.
POWER SUPPLY
In all scenarios shown below, 208 – 240 volt single phase power is connected to leads labeled Power L, Power L and
Ground. Appliance primary pump is wired to leads labeled Pump L, Pump L and Ground, pumps must be rated for 208v -
240v power supply. Maximum total allowable externally connected load to the FMT 914 is 550 watts.
SENSORS
Through the following pages you will see sensors (all 10k ohm) in the drawings listed as:
S-1 Flow – this is the leaving water from the heater/boiler.
S-2 Return – this is the entering water to the heater/boiler.
S-3 External – this is the storage tank sensor on water heaters and the common loop/low loss header sensor on boilers.
S-5 Tank – this is the Domestic Hot Water sensor on a heating boiler application only.
S-6 Outdoor – the is the sensor to be mounted outdoors for temperature reset control on a heating boiler application only.
PUMP CONTROL
• All water heaters and boilers are designed to operate with their own 240v pump that will be controlled and the
power to it supplied by the internal wiring.
• If a second 240v pump or diverting valve is utilized, the control is by the FMT 914, but the power
 tothepumpordivertingvalvemustbesuppliedandswitchedthroughaeldsuppliedrelayifthetotalwattage
draw exceeds 550 for all pumps (an additional wiring harness (P/N WRE 74090) is required on all pre-universal
heating models; please refer to our technical bulletin TB025, “EVO Universal Model: Starting Serial Numbers”,
to determine whether your unit is universal or not).
• Standard post burn cycle running of the pumps is as follows:
Water Heater – 1 minute Pump P3
Heating Boiler – 5 minutes Pump P1
Domestic Hot Water heating zone pump – 1 minute – Pump P2/Diverting Valve
Zone/Transport Pump – 5 minutes Pump P3
DISPLAY
The3digitdisplaywillshowdifferentinformationduringnormaloperationbasedonthecongurationoftheappliance:
• Stand alone Water Heater–thetemperaturesetpoint,orcode,orashingfaultcode
• Cascade Water Heater –theLeadheaterwillalwaysdisplaythetemperaturesetpoint,orcode,orashinga
fault code; the Lag heater(s) will either display “0.” If they are not burning or the same temperature as the Lead
 whentheyareburning,ortheirowncode,oraashingfaultcodeifapplicable.Iftheblinking”.”isnotvisibleon
the Lag heaters within 30 seconds of powering up, the Cascade system is not properly connected. This “.”
should be visible whenever power is on to the Lag heater.
• Stand alone Heating Boiler – the temperature setpoint if the boiler has not reached it or A3 if there is still a heat
 demandbuttheboilerhasreachedsetpointorcodeaorashingfaultcode
• Cascade Heating Boiler – the Leadheaterwillalwaysdisplaythetemperaturesetpointoracodeorashing
fault code the Lag heater(s) will either display “0.” If they are not burning or the same temperature as the Lead
 whentheyareburning,ortheirowncodeorashingfaultcodeifapplicable.Iftheblinking”.”isnotvisibleonthe
Lag boilers within 30 seconds of powering up, the Cascade system is not properly connected. This “.” should be
visible whenever power is on to the Lag boiler.
• See Operating Manuals for Fault Codes and their explanations.
PARAMETER CHANGES
Only parameters that need to be changed forthatparticularcongurationwillbenotedonthevariouscongurations,all
others are standard in the base programs.
LEGIONELLA CONTROL
In allofthecongurations shown in the following pages, the FMT 914 has the ability to implement a program to heat the
DHW as required for Legionella control. Parameters involved are: 2 IC for on/off, 2 DC for number of days between use
and 2 DD for water temperature during use.
GENERAL DESCRIPTION

4
34000 Autry Street, Livonia, MI 48150 | 800.968.5530 | Fax [phone] | www.hamiltonengineering.com | LIT91110 REV 06/2018
GENERAL DESCRIPTION
That are represented by:
The following pages contain drawings that apply to all models of EVO products:
In addition, most drawings reference a Low Loss Header, which may also
be replaced by properly implemented Primary-Secondary Piping:
From
Boilers
To
Boilers
To
Zones
From
Zones

5
34000 Autry Street, Livonia, MI 48150 | 800.968.5530 | Fax [phone] | www.hamiltonengineering.com | LIT91110 REV 06/2018
CONFIGURATION #1
Conguration #1 – DOMESTIC WATER HEATING (DHW) – model prex HWD
STAND ALONE WATER HEATER
• If an external temperature sensor (10k ohm thermistor) is connected to terminals 1 & 2 (or 3 & 4, 28 & 29
depending on model), the heater will be automatically controlled by this sensor.
• If an external temperature sensor is not connected to terminals 1 & 2 (or 3 & 4, 28 & 29 depending on model),
the heater will be controlled by its own inlet (return) temperature sensor. If there is no external sensor
connected, the water heater pump P3 must be running constantly.
 Inthiscongurationthefollowingcanbedone:
1. Adjust the heater minimum and maximum temperature setting via the red wheel located on the display
panel, within the range of 50 – 159°F (Parameter 2 EA, 2 EB)
2. An external on-off tank thermostat instead of the 10k ohm thermistor can be connected to terminals 5 & 6
(or 13 & 14, 57 & 58 depending on model). If a standard tank thermostat is used, there will be no modulation.
 Inthiscongurationthefollowingcannot be done:
1. Three way valves cannot be utilized.
2. A second pump cannot be controlled.
CDM 4/10/06 1/2"=1'
Dwg. By:
34000 Autry
Livonia, MI 48150
PH: [phone]
Fax: [phone] Description:
Date: Scale:
Customer:
HAMILTON
ENGINEERING
Dwg.
No.:
Checked.
By:
Stand Alone Water Heater
No External Tank Sensor
Stand Alone Water Heater
External Tank Sensor
Pump 3
Storage
Tank
Pump 3
Storage
Tank
Required parameter changes
from base program Default Change to
Base Program - DXXXLCO.pia
None

6
34000 Autry Street, Livonia, MI 48150 | 800.968.5530 | Fax [phone] | www.hamiltonengineering.com | LIT91110 REV 06/2018
CONFIGURATION #2
Conguration #2 – CASCADE WATER HEATERS
 •Inthisconguration,anexternalsensoronterminals1&2(or3&4,28&29dependingonmodel)oran
aquastat on terminals 5 & 6 (or 13 & 14, 57 & 58 depending on model) MUST be connected to the LEAD
HEATER ONLY.
 InthiscongurationthefollowingcanbedoneontheLEAD HEATER ONLY:
1. Adjust the heater minimum and maximum temperature setting via the red wheel located on the display
panel, within the range of 50 – 159°F (Parameter 2 EA, 2 EB)
It is important to set the red potentiometer wheel to the desired setpoint on the Lag heaters with the power off to
the Lead heater. This way, in the event of a control or power failure to the Lead heater, the Lag heaters will
operate at the desired temperature.
Adjust offset, Hysterese (droop) and modulation range in Parameters 2IF – 2IM and 2CD – 2CF.
CDM 4/11/06 1/2"=1'
Dwg. By:
34000 Autry
Livonia, MI 48150
PH: [phone]
Fax: [phone] Description:
Date: Scale:
Customer:
HAMILTON
ENGINEERING
Dwg.
No.:
Checked.
By:
Cascading Water Heater
With External Tank Sensor
Pump 3
Storage
Tank
Pump 3 Pump 3
Lead Lag 1 Lag 2
Required parameter changes
from base program Default Change to
Base Program - DXXXLCO.pia
All Lag Heaters - 2CA 5 2
All Lag Heaters - 2IA 0 1 - 7

7
34000 Autry Street, Livonia, MI 48150 | 800.968.5530 | Fax [phone] | www.hamiltonengineering.com | LIT91110 REV 06/2018
CENTRAL HEATING
CENTRAL HEATING (CH) – Model prex HWH
Inthesecongurationstheroomthermostatreferencecanbea:
On/off—Thermostatisconnectedandtheinputisclosed.Theowsetpointtemperatureisdeterminedbyaheatcurve.
TheheatcurvedeterminestheowsetpointtemperaturebyusingthetemperatureofS6(outside)(terminals1&2or
9&10,26&27dependingonmodel).Whennooutsidesensorisconnected(automaticallydetected),theowsetpoint
temperature is determined by the red wheel setting.
*Power being switched is 30 VDC. Connection is made at terminals 5 & 6 (or 13 & 14, 57 & 58 depending on model) (X1–9,18).
Note: if this circuit is not opened pump P3 will run all of the time except during a call for DHW. This circuit
should also be used for warm weather shut down, night set back etc.
OpenTherm—Thermostatisconnectedandtheinputisclosed.Theowsetpointtemperatureisdeterminedbythis
modulating thermostat utilizing the heat curve as described below in Outdoor reset. If no outdoor sensor is present, it is based
in setpoint. The thermostat sends the setpoint temperature to the FMT 914. Connection is made at terminals 5 & 6 (or 13 &
14, 57 & 58 depending on model); this requires the use of the optional OpenTherm Bus, two wire communication board.
0-10Vdc—Thermostatisconnected.Theowtemperatureisdeterminedbyconvertingtheinputvoltagetoaow
setpoint temperature. When the measured voltage is below 1-volt heat demand will end. Connection is made at terminals 7 & 8
(or 30 & 31 depending on model).
Outdoor Reset—Boiler water temperature can be controlled automatically based on outdoor temperature if a 10k ohm
thermistor is connected to terminals 1 & 2 (or 9 & 10, 26 & 27 depending on model). The control will automatically sense
thepresenceofthesensor.Whenanoutsidetemperaturesensorisconnected,theowtemperaturewillbeset,ina
linear way, from the outside temperature, in accordance with the equation: Tow = (40 – Parameter Data) K + Z (°C)
It is adjustable with two levels of settings:
a) Installer level: At this level it will be possible to change the angle of the heat curve, that is the K – factor (reset ratio),
plus the minimum water temperature (p = 2 ET) at the outdoor temperature you want heating to begin (p = 2 EP).
Minimum water temperature should be based on the type of radiation used for heat distribution. To operate at this level,
you will need a laptop or PDA with the appropriate SIT software.
b) User level: The user can adjust the boiler water temperature by a parallel shifting of the heating curve when
adjusting the red potentiometer wheel. This is the Z factor and has a programmable range from 0 – 20°C (36°F)
(factory default is 20°C 36°F), which allows for a + 10°C to a -10°C from center position adjustment.
Note: the maximum temperature setting (parameter 2EP) does not shut the boiler down, it sets the curve only!
Calculating required Parameter inputs:
1. Determine maximum outdoor temperature for specifying a corresponding water temperature.
2. Determine the minimum water temperature that will work at the above temperature.
3. Determine the design outdoor temperature of the heating system.
4. Determine the design water temperature to satisfy the radiation style at design air temperature.
Dividing the difference of the two water temperatures by the difference of the two air temperatures equals the “K” factor.
Factory Defaults
K = 1.4
Parameter 2 ES
Range 0 - 8
Z = red wheel position, + or – 18°F
from center point (12:00)
Parameter 2 EU
0 – 36°F range
Maximum outdoor temp. = 70°F
Parameter 2 EP
32 – 104°F range
Water temp at maximum air temp. = 70°F
Parameter 2 ET
32 – 140°F range

8
34000 Autry Street, Livonia, MI 48150 | 800.968.5530 | Fax [phone] | www.hamiltonengineering.com | LIT91110 REV 06/2018
Conguration #3 – STAND ALONE BOILER (NO DOMESTIC HOT WATER)
• A room thermostat is to be connected to terminals 5 & 6 (or 13 & 14, 57 & 58 depending on model). If no
yellow jumper wire is attached to 5 & 6 (or 13 & 14, 57 & 58 depending on model), which will be removed to
connect room thermostat, additional wiring is required. Consult factory.
• Connect any external sensor to terminals 1 & 2 (or 3 & 4, 28 & 29 depending on model) (highly recommended).
 Inthiscongurationthefollowingcanbedone:
1. Adjust the boiler minimum and maximum temperature setting via the potentiometer located on the display
panel, within the range of 95 – 195°F. (Parameter 2 EB, 2 EA )
2. Outdoor temperature reset can be enabled by connecting a 10k ohm sensor to terminals 1 & 2 (or 9 & 10,
26 & 27 depending on model) – this will be automatically sensed by the FMT 914; see instructions Page 5
of this manual.
3. Pump P3 can be controlled based on the Room Thermostat must add heating harness WRE74090 and
wire to P3 leads. Caution: Maximum available wattage for external load on the FMT 914 control board
is 550 watts. If pumps P1 & P3 total less, they both can be powered directly off the board. If not, a
relay (240v coil) must be used for pump P3.
CONFIGURATION #3
BD 8/11/09 1/2"=1'
Dwg. By:
34000 Autry
Livonia, MI 48150
PH: [phone]
Fax: [phone] Description:
Date: Scale:
Customer:
HAMILTON
ENGINEERING
Dwg.
No.:
Checked.
By:
Optional
Sensor
Stand Alone Boiler
No External Sensor
No Domestic Hot Water
Pump 1
Zone
Load
Pump 3
Low Loss Header
Room
Thermostat
Outside Wall
S6
Outside Sensor
(Optional)
Required parameter changes
from base program Default Change to
Base Program - HXXXKPCO.pia
None

9
34000 Autry Street, Livonia, MI 48150 | 800.968.5530 | Fax [phone] | www.hamiltonengineering.com | LIT91110 REV 06/2018
CONFIGURATION #4
Conguration #4 – CASCADE BOILERS (NO DOMESTIC HOT WATER)
 •InthiscongurationanexternalsensorMUSTbeconnectedtoterminals1&2(or3&4,28&29depending
on model) on the LEAD BOILER ONLY and be positioned to sense common loop temperature (after/at low
loss header).
• A room thermostat is to be connected to terminals 5 & 6 (or 13 & 14, 57 & 58 depending on model) of the
LEAD BOILER ONLY. If no yellow jumper wire is attached to terminals 5 & 6 (or 13 & 14, 57 & 58 depending
on model), which will be removed to connect room thermostat, additional wiring is required. Consult factory.
 Inthiscongurationthefollowingcanbedone:
1. Adjust the boiler minimum and maximum temperature setting via the potentiometer, within the range of
50 - 192°F (Parameter 2 EB, 2 EA)
2. Pump P3 can be controlled based on the Room Thermostat, must add heating harness WRE74090 and
wire to P3 leads. Caution: maximum available wattage for external load on the FMT 914 control
board is 550 watts. If pumps P1 & P3 total less, they both can be powered directly off the board. If
not, a relay (240v coil) must be used for pump P3.
It is important to set the red potentiometer wheel to the desired setpoint on the Lag boilers with the power off to
the Lead boiler. This way, in the event of a control or power failure to the Lead boiler, the Lag boilers will
operate at the desired temperature.
BPD 8/10/09 1/2"=1'
Dwg. By:
34000 Autry
Livonia, MI 48150
PH: [phone]
Fax: [phone] Description:
Date: Scale:
Customer:
HAMILTON
ENGINEERING
Dwg.
No.:
Checked.
By:
Pump 1 Pump 1 Pump 1
Zone
Load
Pump 3
Low Loss Header
S3
(Cascade)
Lead Lag 1 Lag 2
0-10 VDC (Optional)
Room
Thermostat
Outside Wall
S6
Outside Sensor
(Optional)
Cascade Boiler
With External Sensor
No Domestic Hot Water
Required parameter changes
from base program Default Change to
Base Program - HXXXKPCO.pia
All Lag Heaters - 2CA 5 2
All Lag Heaters - 2IA 0 1 - 7

10
34000 Autry Street, Livonia, MI 48150 | 800.968.5530 | Fax [phone] | www.hamiltonengineering.com | LIT91110 REV 06/2018
CONFIGURATION #5
Conguration #5 – STAND ALONE RESIDENTIAL BOILER WITH DOMESTIC HOT WATER PUMP
(Model number will always end in 9.8, ex. HWH 129.8)
• A room thermostat is to be connected to terminals 5 & 6 (or 13 & 14, 57 & 58 depending on model). If no
yellow jumper wire is attached to 5 & 6 (or 13 & 14, 57 & 58 depending on model), which will be removed to
connect room thermostat, additional wiring is required. Consult local supplier.
• No external sensor is required to be connected to terminals 1 & 2 (or 3 & 4, 28 & 29 depending on model). If a
sensor is connected (sensing after low loss header), it will be automatically detected.
• The tank sensor or an aquastat is to be connected to harness leads labeled “Tank Sensor”.
• The domestic hot water pump is to be connected to the harness leads labeled “L & Close”. Be sure to cap the
line labeled “Open”.
 •Aowcheckmustbeinstalledonthedomestichotwaterloopandprimaryheatingloop.
 Inthiscongurationthefollowingcanbedone:
1. Adjust the boiler minimum and maximum temperature setting via the potentiometer located on the display
panel, within the range of 50 - 192°F.(Parameter 2 EB, 2 EA )
2. An outdoor sensor can be connected to terminals 1 & 2 (or 9 & 10, 26 & 27 depending on model).
3. Setting for the DHW tank (factory default is 140°F, Parameter 2 LF (must be less than 2 CC)).
 4.SettheowtemperaturetotheDHWtank.(Factory default is 185°F) (Parameter 2 CE)
5. Pump P3 can be controlled based on the Room Thermostat, wire to P3 leads. Caution: Maximum available
wattage for external load on the FMT 914 control board is 550 watts. If pumps P1 & P3 total less, they
both can be powered directly off the board, if not a relay (240v coil) must be used for pump P3.
BD 8/11/09 1/2"=1'
Dwg. By:
34000 Autry
Livonia, MI 48150
PH: [phone]
Fax: [phone] Description:
Date: Scale:
Customer:
HAMILTON
ENGINEERING
Dwg.
No.:
Checked.
By:
Stand Alone Boiler
With External Sensor
Pumped Domestic Hot Water
Stainless
Indirect
Heater
Pump 1
Zone
Load
Pump 3
Outside Wall
S6
Outside Sensor
(Optional)
Pump 2
Low Loss Header
Room
Thermostat
Required parameter changes
from base program Default Change to
Base Program - HXXXKPCO.pia
None

11
34000 Autry Street, Livonia, MI 48150 | 800.968.5530 | Fax [phone] | www.hamiltonengineering.com | LIT91110 REV 06/2018
Conguration #6 – STAND ALONE BOILER WITH DOMESTIC HOT WATER PUMP
(Requires additional heating wiring harness – p/n WRE 74090)
• A room thermostat is to be connected to terminals 5 & 6 (or 13 & 14, 57 & 58 depending on model). If no yellow
jumper wire is attached to 5 & 6 (or 13 & 14, 57 & 58 depending on model), which will be removed to connect
room thermostat, additional wiring is required. Consult local supplier.
• No external sensor is required to be connected to terminals 1 & 2 (or 3 & 4, 28 & 29 depending on model). If a
sensor is connected (sensing after low loss header), it will be automatically detected.
• The tank sensor or an aquastat is to be connected to harness leads labeled “Tank Sensor”.
• The domestic hot water pump is to be connected to the harness leads labeled “L & Close”, be sure to cap the
line labeled “Open”.
 •Aowcheckmustbeinstalledonthedomestichotwaterloopandprimaryheatingloop.
 Inthiscongurationthefollowingcanbedone:
1. Adjust the boiler minimum and maximum temperature setting via the potentiometer located on the
display panel, within the range of 50 - 192°F. (Parameter 2 EB, 2 EA )
2. An outdoor sensor can be connected to terminals 1 & 2 (or 9 & 10, 26 & 27 depending on model).
3. Setting for the DHW tank (factory default is 140°F, Parameter 2 LF (must be less than 2 CC)).
 4.SettheowtemperaturetotheDHWtank.Factory default is 185°F (Parameter 2 CE).
5. Pump P3 can be controlled based on the Room Thermostat, wire to P3 leads. Caution: Maximum available
wattage for external load on the FMT 914 control board is 550 watts. If pumps P1 & P3 total less, they
both can be powered directly off the board. If not, a relay (240v coil) must be used for pump P3.
CONFIGURATION #6
BD 8/11/09 1/2"=1'
Dwg. By:
34000 Autry
Livonia, MI 48150
PH: [phone]
Fax: [phone] Description:
Date: Scale:
Customer:
HAMILTON
ENGINEERING
Dwg.
No.:
Checked.
By:
Stand Alone Boiler
With External Sensor
Pumped Domestic Hot Water
Stainless
Indirect
Heater
Pump 1
Zone
Load
Pump 3
Outside Wall
S6
Outside Sensor
(Optional)
Pump 2
Low Loss Header
Room
Thermostat
Required parameter changes
from base program Default Change to
Base Program - HXXXKPCO.pia
Only Boiler - 2IB 1 0

12
34000 Autry Street, Livonia, MI 48150 | 800.968.5530 | Fax [phone] | www.hamiltonengineering.com | LIT91110 REV 06/2018
CONFIGURATION #7
Conguration #7 – CASCADE BOILERS WITH DOMESTIC HOT WATER PUMP
(Requires additional wiring harness – p/n WRE 74090 on the Lead boiler only)
• A room thermostat is to be connected to terminals 5 & 6 (or 13 & 14, 57 & 58 depending on model) of the LEAD
BOILER ONLY. If no yellow jumper wire is attached to 5 & 6 (or 13 & 14, 57 & 58 depending on model), which
will be removed to connect room thermostat, additional wiring is required. Consult local supplier.
 •InthiscongurationanexternalsensororaquastatMUSTbeconnectedtoterminals1&2(or3&4,28&29
depending on model) on the LEAD BOILER ONLY to sense common loop temperature (after/at low loss header).
• The tank sensor or aquastat is to be connected to leads labeled “Tank Sensor” on the Lead boiler.
• The DHW pump is to be connected to the harness leads labeled “L and Close” in the Lead boiler, be sure and
cap the wire labeled “Open”.
 •Aowcheckmustbeinstalledonthedomestichotwaterloopandtheheatingloop.
 Inthiscongurationthefollowingcanbedone:
1. Adjust the boiler minimum and maximum temperature setting via the potentiometer located on the display
panel, within the range of 50 - 192°F. (Parameter 2 EB, 2 EA )
2. Set boiler water temperature to the DHW tank. (Factory default is 185°) (Parameter 2 CE)
3. Set the DHW water temperature (Factory default is 140°F (must be less than 2CC)). (Parameter 2 LF)
4. Pump P3 can be controlled based on the Room Thermostat, wire to P3 leads. Caution: Maximum available
wattage for external load on the FMT 914 control board is 550 watts. If pumps P1 & P3 total less, they
both can be powered directly off the board, if not a relay (240v coil) must be used for pump P3.
It is important to set the red potentiometer wheel to the desired setpoint on the Lag boilers with the power off to
the Lead boiler. This way, in the event of a control or power failure to the Lead boiler, the Lag boilers will operate
at the desired temperature.
BPD 8/11/09 1/2"=1'
Dwg. By:
34000 Autry
Livonia, MI 48150
PH: [phone]
Fax: [phone] Description:
Date: Scale:
Customer:
HAMILTON
ENGINEERING
Dwg.
No.:
Checked.
By:
Cascade Boiler
With External Sensor
Pumped Domestic Hot Water
Utilizing Full Cascade Output
Stainless
Indirect
Heater
Pump 1 Pump 1 Pump 1
Zone
Load
Pump 3
Low Loss Header
S3
(Cascade)
Outside Wall
S6
Outside Sensor
(Optional) Lead Lag 1 Lag 2
Room
Thermostat
Pump 2
0-10 VDC (Optional)
Required parameter changes
from base program Default Change to
Base Program - HXXXKPCO.pia
All Boilers 1 0
All Lag Boilers - 2IA 0 1 - 7

13
34000 Autry Street, Livonia, MI 48150 | 800.968.5530 | Fax [phone] | www.hamiltonengineering.com | LIT91110 REV 06/2018
CONFIGURATION #8
Conguration #8 - STAND ALONE BOILER WITH DOMESTIC HOT WATER DIVERTING VALVE
(Requires additional heating wiring harness – p/n WRE 74090)
• A room thermostat is to be connected to terminals 5 & 6 (or 13 & 14, 57 & 58 depending on model). If no
yellow jumper wire is attached to terminals 5 & 6 (or 13 & 14, 57 & 58 depending on model), which will be
removed to connect room thermostat, additional wiring is required. Consult local supplier.
• No external sensor is to be connected to terminals 1 & 2 (or 3 & 4, 28 & 29 depending on model).
• The tank sensor or an aquastat is to be connected to harness leads labeled “Tank Sensor”.
• The domestic hot water diverting valve is to be connected to the harness leads labeled “3-way Open”,
“3-way Close”, and “3-way L”.
Inthiscongurationthefollowingcanbedone:
1. Adjust the boiler minimum and maximum temperature setting via the potentiometer located on the display
panel, within the range of 50 - 192°F. (Parameter 2 EB, 2 EA)
2. Set boiler water temperature to the DHW tank. (Factory default is 185°) (Parameter 2 CE)
3. Set the DHW water temperature (Factory default is 140°F (must be less than 2CC)) (Parameter 2 LF)
BD 8/11/09 1/2"=1'
Dwg. By:
34000 Autry
Livonia, MI 48150
PH: [phone]
Fax: [phone] Description:
Date: Scale:
Customer:
HAMILTON
ENGINEERING
Dwg.
No.:
Checked.
By:
Stand Alone Boiler
With External Sensor Diverting
Valve Domestic Hot Water
S3
Stainless
Indirect
Heater
Pump 1
Zone
Load
Pump 3
Low Loss Header
Outside Wall
Room
Thermostat
S6
Outside Sensor
(Optional)
Required parameter changes
from base program Default Change to
Base Program - HXXXK3CO.pia
Only Boiler - 2EF 3 0

14
34000 Autry Street, Livonia, MI 48150 | 800.968.5530 | Fax [phone] | www.hamiltonengineering.com | LIT91110 REV 06/2018
Conguration #9 - CASCADE BOILERS WITH DOMESTIC HOT WATER DIVERTING VALVE
(Must add heating harness WRE74090 to the Lead Boiler only)
• A room thermostat is to be connected to terminals 5 & 6 (or 13 & 14, 57 & 58 depending on model) of the
LEAD BOILER ONLY. If no yellow jumper wire is attached to terminals 5 & 6 (or 13 & 14, 57 & 58 depending
on model), which will be removed to connect room thermostat, additional wiring is required. Consult factory.
 •InthiscongurationanexternalsensororaquastatMUSTbeconnectedtoterminals1&2(or3&4,28&29,
depending on model) on the LEAD BOILER ONLY and be positioned to sense common loop temperature
(after/at the low loss header).
• The tank sensor or aquastat is to be connected to harness leads labeled “Tank Sensor” in the Lead boiler.
• The domestic hot water diverting valve is to be connected to the harness leads in the Lead boiler labeled
“3-way Open”, “3-way Close”, and “3-way L”. Alternately, with a different piping layout, a DHW pump can be
connected to the harness leads labeled “L and Close”. Cap the wire labeled “Open”.
 Inthiscongurationthefollowingcanbedone:
1. Adjust the boiler minimum and maximum temperature setting via the potentiometer located on the display
panel, within the range of 95 – 195°F. (Parameter 2 EB, 2 EA)
 2.SettheowtemperaturetotheDHWtank.(Factory default is 185°F) (Parameter 2 CE)
3. Set the DHW water temperature . (Factory default is 140°F) (Parameter 2 LF)
4. Pump P3 can be controlled based on the Room Thermostat, and wire to P3 leads. Caution: Maximum
available wattage for external load on the FMT 914 control board is 550 watts. If pumps P1 & P3 total
less, they both can be powered directly off the board. If not a relay (240v coil) must be used for pump P3.
It is important to set the red potentiometer wheel to the desired setpoint on the Lag boilers with the power off to
the Lead boiler. This way, in the event of a control or power failure to the Lead boiler, the Lag boilers will operate
at the desired temperature.
CONFIGURATION #9
BPD 8/10/09 1/2"=1'
Dwg. By:
34000 Autry
Livonia, MI 48150
PH: [phone]
Fax: [phone] Description:
Date: Scale:
Customer:
HAMILTON
ENGINEERING
Dwg.
No.:
Checked.
By:
Stainless
Indirect
Heater
Pump 1 Pump 1 Pump 1
Zone
Load
Pump 3
Low Loss Header
S3
(Cascade)
Outside Wall
S6
Outside Sensor
(Optional) Lead Lag 1 Lag 2
Room
Thermostat
0-10 VDC (Optional)
Cascade Boiler
With External Sensor Diverting
Valve Domestic Hot Water
From Lead Boiler Only
Required parameter changes
from base program Default Change to
Base Program - HXXXK3CO.pia
All Lag Boilers - 2IA 0 1 - 7
Lead Boiler - 2CA 5 2
Lead Boiler - 2EF 3 0

15
34000 Autry Street, Livonia, MI 48150 | 800.968.5530 | Fax [phone] | www.hamiltonengineering.com | LIT91110 REV 06/2018
HWD 129–199.8 STANDARD WIRING

16
34000 Autry Street, Livonia, MI 48150 | 800.968.5530 | Fax [phone] | www.hamiltonengineering.com | LIT91110 REV 06/2018
HWH 129–199.8 W/O 3-WAY
FCD 10/28/09
EVO micro (HWH 129-199.8 w/o 3-way)
Wiring Diagram with Heating Options
N.T.S.
Description:
Dwg. By: Date: Scale:
Customer:
HAMILTON
Dwg.
No.:
Checked.
By:
3-way Open to CH
3-way L
3-way Close
Pump P2 L
Pump P2 L
240v
switched
to Pump
K0
K1
K2
K3
K4
=white
=yellow
=brown
=green
=gray
=orange
=blue
=red
=black
=purple
K5
K6
K7
K8
K9
K10
K12
K17
K18
K19
=yellow/green
=yellow/white
=blue/white
=red/white
=black/white
All Wire Size: AWG 18
+-
SETPOINT TEMPERATURE
BURNER ON
RESET S ERVICE
K2
K2
K7
K4
K6
1 221
X6 X7
20191817161513 1412111095 6 7 83 421
Low Water
Cut-Off
2
1
12
K6
K2
K2
K10
K6
On/Off
Switch
43
2
1
K6
K10
K2
Printed Circuit Board FMT914
K6
K2
K10
K1
K0
K10
K6K2
K2K2
K2K2
K5
K5
K3
K3
K6
K10
K2
K7K8K6
K10
K6
K2
K10
K6
K2
K6
K2
K6
K6
3.15 Amp
Pressure Switch
Open switch
indicates as H-1
Fixed High Limit
Open switch
indicates as H-1
S1
S2
Fan-2
Fan-1
20
19
10
11
12
13
14
15
16
17
18
2
3
4
5
6
7
8
1
9
18
17
16
15
14
13
12
11
101
9
8
7
6
5
4
3
2
10
9
8
7
4
5
6
2
3
1
4
5
6
2
3
1
1
6
5
4
3
2
Fan
654
321
Transformer
Fuse
X 10
X 9
X 8
X5
X 4
X 2
X 1
Gas valve-1
X 3
Water Flow Switch
Open switch
indicates as H-1
A
A
K10
K10
K10
Pump L
Pump G
Pump L
Boiler Pump P-1
208 - 240v
Line Voltage
Power L
Power G
Power L
K7
K7
CONTRO L
WELL
Tank Sensor
K7
K7
Pump P3 L
Pump P3 L
240v
switched
to Pump
Pump P-3
Central Heat
Low Temp.
Pump P-2
DHW Indirect
High Temp.
Indirect coil is
heated off high
temp loop - Pump P-2
K2
K6
K7
K6
K2
K6
K2
K6
K2
K6 K2 K7
K6 K2
K6
K2

17
34000 Autry Street, Livonia, MI 48150 | 800.968.5530 | Fax [phone] | www.hamiltonengineering.com | LIT91110 REV 06/2018
HWH 129–199.8 W/3-WAY

18
34000 Autry Street, Livonia, MI 48150 | 800.968.5530 | Fax [phone] | www.hamiltonengineering.com | LIT91110 REV 06/2018
HWD 199-599 STANDARD WIRING
Pump G
Pump L
K8K8
Outside
Sensor
9 1087
0-10 VDC
K2 K6
+ -
K1K1
Remote
Thermostat
5 6
VST-7
K2 K6K10
20191815 16 17
K10 K6K2
VST-6
X 3
1 2
3
4
1 2 4 18 19 20 17163 15
Cascade
Connection
Power Supply
60 Hz
208-230 VAC
Gas valve-1
X 1
X 2
X 4
X5
X 8
X 9
X 10
Fuse
Transformer
1 2 3 4 5 6
fan
2
3
4
5
6
1
1
3
2
6
5
4
1
3
2
6
5
4
7
8
9
10
2
3
4
5
6
7
8
9
1 10
11
12
13
14
15
16
17
18
Gas valve-2
9
1
8
7
6
5
4
3
2
18
17
16
15
14
13
12
11
10
19
20
fan-1 fan-2
Switch
S2
S1
Fixed High Limit
Open switch
indicates H-1
Pressure Switch
Open switch
indicates as H-1 3.15 Amp
=yellow/green
=yellow/white
=blue/white
=red/white
=black/white
K10
K12
K17
K18
K19
K5
K6
K7
K8
K9
=orange
=blue
=red
=black
=purple
=white
=yellow
=brown
=green
=gray
K0
K1
K2
K3
K4
K6 K6 K2 K6 K2 K6
K10 K2 K6K10
K6 K8 K7
K2K10 K6
K3
K3
K5
K5
K2 K2
K2 K2
K2 K6
K10
K2
K6
K10
K0
K1
K10
K2
K6
Model 599 only
Inlet sensor
Outlet sensor
Printed Circuit Board FMT914
Pump
230 VAC
External
Sensor
L
SERVICE
RESET
BURNE R ON
TEMPERATURE
SETPOINT
- +
L LL
+ -
K2
On/Off
ST-1 ST-2 ST-3 ST-4 ST-6 ST-7
K9 K9
ST-5
K7K6
11 12 1413
K6 K4
X6 X7
1 2 21
Lock Out
Signal
Dry Contact
Additional
Heat Source
Dry Contact
FCD 10/28/09
EVO DUO (HWD 199-599)
Standard Wiring Diagram
K2K2
Water Flow Switch
Open switch
indicates as H-1
N.T.S.
34000 Autry
Livonia, MI 48150
PH: [phone]
Fax: [phone]
Description:
Dwg. By: Date: Scale:
Customer:
HAMILTON
ENGINEERING
Dwg.
No.:
Checked.
By:
Pump L
Pump G
Pump L
Pump L
Heater Pump
All Wire Size: AWG 18
LOW WATER
CUT OFF
A
A
15-16-17
18-19-20
Line Voltage

19
34000 Autry Street, Livonia, MI 48150 | 800.968.5530 | Fax [phone] | www.hamiltonengineering.com | LIT91110 REV 06/2018
HWH 199-599 W/O 3-WAY
Pump P1 L
Low Water
Cut Off
Pump P1 L
K9
K9
On/Off
K2
208 - 240 VAC
-+ L LL
+-
SETPOINT TEMPERATURE
BURNER ON
RESET SERVICE
60 Hz,
208-240 VAC
L
Sensor
External Pump
Printed Circuit Board FMT914
Outlet sensor
Inlet sensor
Model 599 only
K6
K2
K10
K0
K10
K6
K2
K10
K6K2
K5
K5
K3
K3
K6K10 K2
K7K8K6
K10 K6K2K10 K 6K 2K0K0K6K6
K0
K1
K2
K3
K4
=white
=yellow
=brown
=green
=gray
=orange
=blue
=red
=black
=purple
K5
K6
K7
K8
K9
K10
K12
K17
K18
K19
=yellow/green
=yellow/white
=blue/white
=red/white
=black/white
3.15 Amp
S1
S2
Switch
fan-2
fan-1
20
19
10
11
12
13
14
15
16
17
18
2
3
4
5
6
7
8
1
9
Gas valve-2
18
17
16
15
14
13
12
11
101
9
8
7
6
5
4
3
2
10
9
8
7
4
5
6
2
3
1
4
5
6
2
3
1
1
6
5
4
3
2
fan
654
321
Transformer
Fuse
X 10
X 9
X 8
X5
X 4
X 2
X 1
Gas valve-1
Power Supply
Cascade
Connection
153 16 17 20
19
18421
4 3
2
1
X 3
K2 K6
K10 K10 K6K2
65
Thermostat
Central Heat
Room
K1 K1
-+
K4K4
0-10 VDC
7 8 109
Sensor
Outside
K8 K8
15-16-17
18-19-20
Pump P3 L
Pump P3 L
3-way Open to CH
3-way L
3-way Close
K7
K7
Additional
Heat Source
Dry Contact
Dry Contact
Signal
Lock Out
1 221
X7
X6
K4K6
13 141211
K6 K7
ST-5
15 16 17 18 19 2 0
Pump P2 L
Pump P1 G
12
K1
Pump P2 L
240v
switched
to Pump
240v
switched
to Pump
CONTROL
WELL
K2K2
K2K2
K2K2
Pressure Switch
Open switch
indicates as H-1
Fixed High Limit
Open switch
indicates as H-1
Water Flow Switch
Open switch
indicates as H-1
ST-1 ST-2 ST-3 ST-4 ST-7ST-6
VST-6 VST-7
A
A
P-1
Boiler Pump
Tank Sensor
Line Voltage
FCD 10/28/09 N.T.S.
EVO duo (HWH 199-599 w/o 3-way)
Wiring Diagram with Heating Options
All Wire Size: AWG 18
Power L
Power G
Power L
34000 Autry
Livonia, MI 48150
PH: [phone]
Fax: [phone]
Description:
Dwg. By: Date: Scale:
Customer:
HAMILTON
ENGINEERING
Dwg.
No.:
Checked.
By:
P-3
Heating Pump
Low Temp
P-2
DHW Indirect Pump
High Temp

20
34000 Autry Street, Livonia, MI 48150 | 800.968.5530 | Fax [phone] | www.hamiltonengineering.com | LIT91110 REV 06/2018
HWH 199-599 W/3-WAY
Pump P1 L
Low Water
Cut Off
Pump P1 L
K9
K9
On/Off
K2
208 - 240 VAC
-+ L LL
+-
SETPOINT TEMPERATURE
BURNER ON
RESET SERVICE
60 Hz,
208-240 VAC
L
Sensor
External Pump
Printed Circuit Board FMT914
Outlet sensor
Inlet sensor
Model 599 only
K6
K2
K10
K0
K10
K6
K2
K10
K6K2
K5
K5
K3
K3
K6K10 K2
K7K8K6
K10 K6K2K10 K 6K 2K0K0K6K6
K0
K1
K2
K3
K4
=white
=yellow
=brown
=green
=gray
=orange
=blue
=red
=black
=purple
K5
K6
K7
K8
K9
K10
K12
K17
K18
K19
=yellow/green
=yellow/white
=blue/white
=red/white
=black/white
3.15 Amp
S1
S2
Switch
fan-2
fan-1
20
19
10
11
12
13
14
15
16
17
18
2
3
4
5
6
7
8
1
9
Gas valve-2
18
17
16
15
14
13
12
11
101
9
8
7
6
5
4
3
2
10
9
8
7
4
5
6
2
3
1
4
5
6
2
3
1
1
6
5
4
3
2
fan
654
321
Transformer
Fuse
X 10
X 9
X 8
X5
X 4
X 2
X 1
Gas valve-1
Power Supply
Cascade
Connection
153 16 17 20
19
18421
4 3
2
1
X 3
K2 K6
K10 K10 K6K2
65
Thermostat
Central Heat
Room
K1 K1
-+
K4K4
0-10 VDC
7 8 109
Sensor
Outside
K8 K8
15-16-17
18-19-20
Pump P3 L
Pump P3 L
3-way Open to CH
3-way L
3-way Close
K7
K7
Additional
Heat Source
Dry Contact
Dry Contact
Signal
Lock Out
1 221
X7
X6
K4K6
13 141211
K6 K7
ST-5
15 16 17 18 19 2 0
Pump P1 G
12
K1
240v
switched
to Pump
CONTROL
WELL
K2K2
K2K2
K2K2
Pressure Switch
Open switch
indicates as H-1
Fixed High Limit
Open switch
indicates as H-1
Water Flow Switch
Open switch
indicates as H-1
ST-1 ST-2 ST-3 ST-4 ST-7ST-6
VST-6 VST-7
A
A
P-1
Boiler Pump
Tank Sensor
Line Voltage
FCD 10/28/09 N.T.S.
EVO duo (HWH 199-599 w/3-way)
Wiring Diagram with Heating Options
All Wire Size: AWG 18
Power L
Power G
Power L
34000 Autry
Livonia, MI 48150
PH: [phone]
Fax: [phone]
Description:
Dwg. By: Date: Scale:
Customer:
HAMILTON
ENGINEERING
Dwg.
No.:
Checked.
By:
P-3
Heating Pump
Low Temp
Close
N
N
Open
24V Transformer
