Haneco Lucido 100W5K-V2 User manual

Instruction Manual
1. Anti-Burst glass cover
2, Die cast aluminum body
3. Mounting bracket
4. 1m cable
GENERAL
These operating instructions must be read thoroughly as they contain important notes on the
safety, usage and maintenance of your product.
USAGE
The function of this LED Floodlight is to light areas such as rooms, parking spaces, building sites,
workshops, property etc. The led floodlight can be used both indoors and outdoors because of its
protection class.
Live (L): Brown
Neutral(N): Green
Earth(E): Yellow / Green Mixed

SAFETY INSTRUCTIONS
If the power cable is damaged then this must be replaced by a specialist workshop in order to
avoid the risk of injury or accident.
Always remove the power plug when the product is not in use and before cleaning or if faulty.
Never submerge the product in water. The product is protected against jet water from different
angles because of its protection class IP65 but it is not suitable for use under water.
Do not operate the product after such an incident and have the product checked by an
authorised service centre. This is also valid if a power plug or the product is damaged or if the
product falls down. Risk of electric shock!
Repairs may only be carried out by authorized workshops.
Only connect the flood light to a correctly installed earthed socket with a supply voltage in
accordance with the type plate.
INITIAL OPERATION/FAULTS AND RESOLUTION
If in doubt do not use the product but rather contact your retailer.
The product is supplied in stable packaging for protection.
Remove the product from the packaging carefully.
Remove all the packaging from the product.
Clean the product and all accessory parts of packaging residue.
Unwind the power cable completely.
Mount the product at a suitable location on the pre-attached mounting bracket
Or mount the product on a carrying bracket or stand that is recommended by the manufacturer
and suitable for this purpose. Please ensure that the carrying bracket or stand is standing on a
stable, secure surface.
Adjust the product to the direction that is to be lit.
Make sure that the power cable length is sufficient in order to supply power to the product.
Insert the power plug into a suitable, earthed socket and do not look directly into the lamp.
FAULTS AND RESOLUTION
If the LED floodlight doesn't work:
- Check that the power cable is plugged in correctly.
- Test the socket by plugging in a different product.
- If the socket is not working – check fuses.
- Check the power cable and socket for damage. Discontinue use of the product if damage is
found
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
