The RF-5800H-MP is a member of the FALCON®II family of multiband tactical
radio systems. It is an advanced HF-SSB/VHF-FM manpack radio that provides
reliable tactical communications through enhanced secure voice and data
performance, networking, and extended battery life. The transceiver’s extended
frequency range (to 60 MHz) provides secure FSK 16 kbps CVSD voice and data
in the VHF band in addition to the HF capability. It is like having two radios in
one compact package.
High speed data rates, up to 9600 bps (HF), and selectable ARQ modes reduce
on-the-air transmission time and enhance secure data transmissions for
improved communications reliability and throughput. The combined robust
digital voice (MELP, LPC-10) and serial tone data modem operate over poor
communication channels. The RF-5800H-MP includes a last ditch voice mode
that transmits digital voice using ultra robust 3G waveforms for operation in
channels where no other waveforms will work.
A serial-tone ECCM waveform with DSP-based excision filtering and a 600 bps
vocoder are combined to provide reliable, secure HF communications in the
presence of jamming. Secure digital voice, 75 to 2400 bps data, and ARQ mode
are supported in the ECCM mode.
The latest third generation HF Link Automation, STANAG 4538, is included and
provides high performance ALE and data link protocols, providing superior
linking and error free data transfer.
The Harris Citadel®ASIC provides high speed data and digital voice encryption
using either a Harris-standard or a customer-unique algorithm.
An internal Global Positioning System (GPS) receiver option provides local
position information and Automatic Position Reporting (APR). This feature
allows the radio to be used in situational awareness systems without PCs
attached to the outstation radios.The accurate GPS timing data can be used
for ECCM and advanced ALE synchronization.
Integrated telephony capability allows the radio operator to place and
receive telephone calls using the radio keypad when used with the RF-
6010 Tactical Network Access Hub.
The data capability and network management features of the
RF-5800H-MP utilize industry standard IP-based protocols
to provide fast, simple, and direct communications, and
permit easy setup and maintenance of tactical
networks.
The removable Keypad/Display Unit provides
easy access to controls for on-the-move
operation.
®
assuredcommunications™
RF-5800H-MP
ADVANCED HF/VHF
TACTICAL RADIO
SYSTEM
a fully integrated, compact
communications system,
offering the security and
performance features your
missions demand

RF Communications Division | 1680 University Avenue | Rochester, NY USA 14610
www.harris.com 1-585-244-5830
© Copyright 2005 Harris Corporation 08/05 DS-211J
Specifications for the RF-5800H-MP
General
Frequency Range 1.6 to 59.999 MHz
Net Presets 75, fully programmable
Frequency Stability ±0.5 x 10–6
Emission Modes J3E (single sideband, upper or lower, suppressed carrier telephony)
H3E (compatible AM single sideband plus full carrier)
A1A, J2A (compatible CW), selectable; F3E (FM telephone)
RF Input/Output Impedance 50 ohm nominal, unbalanced
Power Input 26 VDC (20.5 to 32 VDC)
Data Interface Synchronous or asynchronous (RS-232C; MIL-STD-188-114A)
Dimensions (with battery case) 10.5W x 3.5H x 13.2D inches (26.7W x 8.1H x 34.3D cm)
Radio Weight 10 lb (4.7 kg) without batteries
Receiver
Sensitivity SSB: –113 dBm (0.5 µV) for 10 dB SINAD
Audio Output 15 mW at 1000 ohm to external handset
Squelch Front panel adjustable, active squelch selectable
IF Rejection Greater than 80 dB
Image Rejection Greater than 80 dB (1st IF image)
AGC Mode dependent, automatically selected
Intermodulation Distortion –80 dB or better for two –30 dBm signals separated 30 kHz or more
Overload Protection Receiver protected to 32 VRMS
Transmitter
Power Output 1, 5, 20 watts PEP/Average -1/+2 dB (1, 5, 10 watts FM)
Audio Input 1.5 mV at 150 ohm or 0 dBm at 600 ohm for full rated output
Carrier Suppression Greater than 60 dB below PEP output (J3E mode)
Undesired Sideband Suppression Greater than 60 dB below PEP output
Spurious Outputs –50 dB relative to rated output, except harmonics which are –40 dB
(Greater than 20 kHz from Fc) minimum for fo= 1.6-30 MHz
Antenna Tuning Capability OE-505 10-foot (3 m) whip (1.6 to 60 MHz)
RF-1936P (AS-2259) NVIS (3.5 to 10 MHZ)
RF-1940-AT001/RF-1941 dipole
Environmental
Test Method Per MIL-STD-810F
Vibration Ground Tactical
Immersion 3 ft. (.9m) of water
Operating Temperature–40˚C to +70˚C
Features
Encrypted Data HF: MIL-STD-188-110B App. C (9600 bps and 12,800 bps uncoded),
App. B 39-tone (2400 bps), (maximum data rate)
Serial Tone (2400 bps),
STANAG 4285 (2400 bps), STANAG 4415 (75 bps),
STANAG 4539 (9600bps), FSK (600 bps)
VHF: FSK (16 Kbps)
Automatic Link Establishment (ALE) STANAG 4538 FLSU, MIL-STD-188-141B Appendix A
Frequency Hopping Serial Tone ECCM
Vocoder HF: LPC-10-52E (600/2400), MELP (600/2400), VHF: CVSD
Data Link Layer Protocol (ARQ) STANAG 4538 (3G), pFED-STD-1052
System Configuration Digital Encryption GPS
RF-5800H-MP025 Citadel —
RF-5800H-MP026 Citadel Internal
RF-5800H-MP035 Datotek/Citadel —
RF-5800H-MP036 Datotek/Citadel Internal
Major System Components
RF-5800H-V006 20 Watt Vehicular Adapter
RF-5832H 125 Watt Power Amplifier
RF-5833H 150 Watt Vehicular Adapter Unit
RF-5834H 400 Watt Power Amplifier
RF-5382H 150 Watt Antenna Coupler
RF-382A 400 Watt Antenna Coupler
RF-5845H Pre/Post Selector
®
FALCON and Citadel are registered trademarks of Harris Corporation.
Specifications are subject to change without notice.
