Harxon UHF1601D User manual

[User Manual]
Wireless Data Transceiver
UHF1601D
User Manual
Version：V1.0

[User Manual]
CONTENTS
1、SUMMARY.................................................................................................................................................................. 3
2、INTERFACE.................................................................................................................................................................. 4
2.1 SERIAL DATA CABLE INTERFACE.......................................................................................................................................... 4
2.2 RF INTERFACE..................................................................................................................................................................... 5
3、FUNCTION AND OPERATING INSTRUCTIONS ................................................................................................. 5
3.1 POWER ON......................................................................................................................................................................... 5
3.2 POWER SHIFT...................................................................................................................................................................... 5
3.3 TRANSMITTING CHANNEL SHIFT ......................................................................................................................................... 5
3.4 CHANNEL DISPLAY ............................................................................................................................................................. 5
3.5 DATA TRANSMITTING INDICATOR....................................................................................................................................... 6
4、RADIO SET .................................................................................................................................................................. 6
4.1 OPEN PORTS....................................................................................................................................................................... 6
4.2 MAKE RADIO ENTER CONFIGURATION MODE ..................................................................................................................... 7
4.3 CONFIG RADIO PARAMETERS .............................................................................................................................................. 8
4.4 FINISH TO EXIT CONFIGURATION MODE.............................................................................................................................. 9
5、SOFTWARE UPGRADE ........................................................................................................................................... 10
6、TECHNICAL SPECIFICATIONS .............................................................................................................................. 10

[User Manual]
Copyright Information
This products operation manual and all the related software are protected by Harxon Corporation,
and all rights reserved. All rights of this manual include copyright only belongs to Harxon Corporation
(short for Harxon as below), unless the copyright holders allowed, strictly forbid to copy this manual by
printing、xeroxing、recording and other means.
Disclaimer
We strive to guarantee the accuracy and completeness of this manual contents when compiling, but
for possible errors or omissions, Harxon will not assume any responsibility. Due to the continuous
development of technology, Harxon reserves the rights to change the technical specifications or functions
of their products without any notification to users.
Antenna Installation Warning
1. Any antenna only can be installed and maintained by professional technician. Please make sure that the
radio station is closed when you maintain or work nearby the antenna.
2. In general, radio will be connected to a directional (high-gain) antenna, and fixed to the edge or top of
a building or top of tower. According to the application and antenna gain, total hybrid power may exceed
90W(ERP). Under normal circumstance, only the professional technicians can close to the antenna area,
anyone can’t touch the antenna or close to 2.3m in diameter range of the antenna.
Antenna Gain vs Safe distance recommended
Antenna Gain（HX-U101）
0–5 dBi 5–10 dBi 10–16.5 dBi
The minimum safe
distance
0.6m 1.06m 2.3m

[User Manual]
第4 页共11 页
1、Summary
1601Dis an external Receipt &Transmission 1W radio modem, waterproof to IP67、 Durable
structure，which can apply to all outdoor weather conditions.
1601Dhas 4 pieces of LED、1 piece of nixie tube and 3 pieces of push-button, for user’s
convenience of booting、channel switching、power rating、low voltage alarming and indicating the current
operation channel.
2、Interface
2.1 Serial data line interface

[User Manual]
Interface type: asynchronous serial communication standard of RS232
Pin definitions：
Pin 1------Power，9-16V DC；
Pin 2------power grounding，Power GND；
Pin 3------serial data receiver，RXD；
Pin 4------serial signal grounding；
Pin 5------serial data transmission，TXD.
2.2RF interface
1601DRF interface is TNC female connector of 50Ω.
3、Function and operating instruction
3.1 Booting
Press the button of ON/OFF to boot. LED indicator of ON is green, which means the voltage is
normal, and the machine can work normally; if LED indicator of ON is red flash, which means the
voltage is too low, please turn on the low voltage protection; if LED indicator of ON is red, which means
the voltage is too high, please turn on the overvoltage protection.
3.2 Low power switching
Pressing the button of PWR for switching between high power and low power. If you choose high
power, LED indicator of PWR will turn red; if you choose low power, LED indicator of PWR will turn
green.
Default value: high power.
3.3Transmitting channel switching
Pressing the button of CHANL, 8 channels of “1-8”will be switched within each other, keep

[User Manual]
pressing for fast forward, digital tube display the current channel number.
3.4Channel Display
Operation Mode: Display the channel number of “1-8”transmitting rate.
3.5Low voltage indicator
While transmitting data，TX/RX LED indicator of ON will be red flash；While receving data，
TX/RX LED indicator show green.
4、Radio model setting
4.1 Open ports
Open the configured software, ，choose the corresponding port, baud
rate defaulted as38400, click the port .

[User Manual]
4.2 Make radio modem enter the configuration mode
Connecting the power line and serial port line, which confirmed to be connected correctly,
repower, press the button of “ON/OFF”for booting, LED indicator of ON show green. Within 3 seconds,
click the butto to make the radio modem enter configuration mode, reading and
saving the information of configured radio modem (shown as the chart below), button of “load”failure
and turn gray. Digital tube of radio modem show “C”, radio modem will enter the configuration mode.

[User Manual]
4.3 Configuring the parameter radio modem
4.3.1 Configuring the customized rate, defaulted rate as:
There are two groups of defaulted rate value（transmitting and receiving frequency），click " def
ault " below，Will set all the frequencies in the corresponding column。
4.3.2 Configuring the serial baud rate
Serial baud rate optional 9600,19200,38400,57600,115200 bps.(Note: if you want to reconnect radio
modem after modifying the baud rate of serial port, you have to modify the serial baud rate
here .

[User Manual]
4.3.3 Configuring the current channel ch1-ch8
You can choose one channel as the current communication channel in the 1-8 channel，click
button，Configuring Radio Parameters；
Noted：Before Configuring Radio Parameters，click“Read”Button，First
read all the configuration parameters of the machine, and then make the appropriate parameter
modification；
4.4 Finish to exit the configuration mode
Click the button to exit configuration mode, the digital tube of radio modem
will show the current channel number.

[User Manual]
5、Software upgrading
Fault description
Cause analysis
Solution
Cannot boot
Power cable connection is not
reliable or positive and negative
reversed
Correctly connect power cable
Unable to enter configuration
mode
Serial port configuration is not
correct, improper operation
Correctly configured serial baud
rate and related parameters, click
the "Connect" button Boot within
3 seconds
Unable to transmit and receive
data
Frequency, protocol, air baud
rate, the baud rate and other
parameters configured
incorrectly
Correctly configured transmitter
and receiver parameters and
serial port parameters
6、Technical Specifications
Total Performance Specifications
Name
Specifications
Frequency Range
410~470MHz
Operating Mode
half-duplex
Channel Spacing
25KHz or 12.5KHz
Operating Voltage
9-20V
Power Consumption
(typical value)
High power
transmitter
5W @ DC 12V
Low power
transmitter (5W)
3W @ DC 12V
Reception
1.2W @ DC 12V

[User Manual]
Frequency Stability
≤±1.0ppm
Dimension
148×76×30mm
Operating Temperature
-30℃~+60℃
Storage Temperature
-55℃~+85℃
Antenna Interface
TNC-Female
Antenna Interface
Impedance
50ohm
Data Power Interface
LEMO，HGG.1B.305
Transmitter Performance Specifications
Name
Specifications
RF output power
High power（1W）
30±1dBm@DC12V
Low power（0.5W）
27±1dBm@DC12V
RF Power Stability
±1dB
Adjacent Channel
Power Restrain
>50dB
Receiver Performance Specifications
Name
Specifications
Sensitivity
>-115dBm@BER 10-3，9600bps
Adjacent Channel
Selectivity
>50dB@25KHz
Modem
Name
Specifications
Air Rate
9600bps
Modulation
GMSK
