Hausmann PROTEAM A9087 Installation instructions

rev. 07.23.08 cjr ©2008 PROTEAM BY HAUSMANN
Installation/Operation Instructions
Model A9087 - Treatment Table
130 Union St • Northvale NJ 07647 USA
Tel: [phone] • Fax: [phone]
www.proteamtables.com
PARTS LIST
PART QTY PART # DESCRIPTION
A 4 A9087-001 Corner Leg (29” high)
B 12 A9087-002 Flat Head Allen Head Cap Screw #12 x 2” lg
C 3 A9087-003 Long Stretcher
D 2 A9087-004 Center Leg (29” high)
E 1 A9087-005 Long Shelf
F 2 A9087-006 Short Stretcher
G 2 A9087-007 Long Apron
H 2 A9087-008 Center Apron
I 4 A9087-009 1/4 - 20unc x 4 1/2” lg Carriage Bolt
J 4 A9087-010 1/4” Kep Nut
K 1 A9087-011 Upholstered Table Top (30” x 78”)
L 4 A9087-012 Leg Plate
M 2 A9087-013 Short Apron
N 4 A9087-014HB Hex Bolt 4 1/2” lg x 5/16” - 18
O 4 A9087-015 5/16” Flat Washer
P 4 A9087-016 5/16” Split Washer
TOOLS REQUIRED
• 1/2” Socket Wrench
• 7/16” Socket Wrench
• Allen Wrench (supplied by
Hausmann Industries, Inc.)
A
A
A
A
B
B
B
B
B
C
D
D
E
F
F
G
G
HI
J
K
L
M
M
O
P
N
Illustration 1
Velcro
Velcro
Velcro
Please join Hausmann’s effort to reduce
paper use and keep the planet green by
using our paperless Warranty Registration
form. Visit www.hausmann.com and click
on Warranty Registration. If you do not
have web access or prefer the form be mailed or faxed
to you, please call Hausmann Customer Service.
As of January 1, 2010, we will no longer include the
paper based forms, please visit the online link to fill in
your Warranty Form.

rev. 07.23.08 cjr ©2008 PROTEAM BY HAUSMANN
ASSEMBLY INSTRUCTIONS
Clear the area where you will be working and lay down a blanket. Remove all parts from the box and follow the
directions below.
1. Attach Corner Legs “A” with pre-drilled holes facing Leg
Plate “L” and fasten with Hex Head Bolt “N”, 5/16” Split
Washer “P” and 5/16” Flat Washer “O”. Use 1/2” socket
wrench to tighten the Hex Bolts. Attach the Center Legs
“D” with Carriage Bolts “I” and 1/4” Kep Nut “J”. Apply
soap or wax lubrication if needed. Use 7/16” socket
wrench to tighten the carriage bolts.
IMPORTANT: See Illustrations 2 and 3 for tightening
instructions and part placement.
2. Place the Short Stretchers “F” into the slots on the
Corner Legs “A” with the laminated edge facing the
table top. Secure with Flat Head Allen Head Cap Screw
“B” (2 per stretcher). Use Allen Wrench supplied by
Hausmann. (See Illustration 4).
3. Identify the Long Stretchers “C”. There are three long stretchers - two are pre-drilled with holes which line up
with the holes located on the inside of the two Center Legs “D”. Place the long stretchers into the slots of the
Short Stretchers “F” with the laminated edges facing the table top and secure at the ends using (6) Flat Head
Allen Head Cap Screws “B” Then secure the middle of the two outside long stretchers to the center legs using
(2) flat head allen head cap screws. Use the Allen Wrench supplied by Hausmann. (See Illustration 5).
4. Turn the table right side up. Hook and loop velcro strips are factory attached to the bottom of the Long Shelf “E”.
Remove the loop strips of velcro and adhere them firmly to the TOP of the 2 outside Long Stretchers “C” as well
as the TOP of the 2 Short Stretchers “F” in corresponding locations to the hook velcro strips. (See Illustration 1).
5. From one end, place the Long Shelf “E” on top of the stretchers and secure with the corresponding velcro strips
placed during step 4.
NOTE: Placement of velcro strips are to be aligned with each other for secure assembly.
6. Double check to make sure all screws are tight and secure.
PREVENTATIVE MAINTENANCE
1. Inspect bolts and other mechanical fasteners at least every 3 months. Tighten bolts, screws or connectors if
loose.
CAUTION: Tighten until snug but do not overtighten.
2. Please inspect all parts for satisfactory condition. Call your dealer immediately if a problem exists. Discontinue
use of any product that is not in proper working order until situation is rectified.
For assistance please call Hausmann Industries for service at [phone]. Press “5” for Customer Service.
We may request purchase details (date purchased, dealer) to better assist you.
A
Corner
Leg
Illustration 2
LLeg
Plate
OFlat Washer
PSplit Washer
NHex Bolt
IMPORTANT: You must
tighten Hex Bolt until Split
Washer is compressed
FLAT against Flat Washer.
DO NOT OVERTIGHTEN.
Factory installed threaded
insert
Pre-drilled
hole to face
inward
A
D
L
JI
ON
P
F
B
B
B
B
C
Illustration 5
Illustration 4Illustration 3
