Installation/Operation Instructions
Model 6292, 6293, 6294 –Hand Therapy Tables
Tools Required:
Phillips Screwdriver
Large Allen Wrench (Included)
A) INSTALLATION INSTRUCTIONS:
Attaching Columns to Tabletop:
1. Place the tabletop on the floor with the underside
facing upward.
2. Place the columns on top of the tabletop so that
the colored sticker on the tabletop is matched with
the corresponding color sticker on the column.
3. To ensure that the alignment is correct have the
red handles face outwards so that the columns are
lined up with the pre-drilled holes.
4. Attach both of the columns with (6) wood screws
(H) each using Phillips screw driver as shown below.
NOTE: Do not over tighten the screws
Part Lists
Part
Qty
Description
A
1
Laminate Tabletop
B
1
Utility Drawer (6293 only)
C
4
Glide (Not shown)
D
4
2” Casters
E
2
Columns
F
1
‘U’ Base
Product Specifications
Model #
Length
Width
Height
Weight Capacity
6292
37”
19”
W/ Casters:
30”–42”
W/ Glides:
29”-41”
250 lbs
6293
37”
19”
6294
37”
24”
HARDWARE
ITEM #
QTY
DESCRIPTION
G
6
6mm Allen screw
(Pre-Installed)
H
12
5/8” Phillips head wood
screw
I
4
Split Washer
J
4
Flat Washer
K
1
Allen Wrench
L
1
Caster Wrench
Figure 1: Model 6293 with Casters
Wood Screws (H)
Pre-Drilled Holes
A
B
D
E
F
Colored sticker

Rev. 04062018 BH Page 2of 2©2018 HAUSMANN INDUSTRIES, INC.
Attach Base to Two Columns:
1. (Do not remove the screws indicated with the stickers)
2. Remove the three (3) 6mm Allen Screws (G) from each of the columns and set aside.
3. For proper orientation, match the column with the colored dot to the corresponding colored dot on
the base.
4. Place the base on top of the columns aligning columns with the holes on the base, the remaining
screw should be aligned to the larger hole on the base.
5. Secure the columns to the base using the three 6mm Allen screws (G) that were removed and set
aside earlier.
6. For casters, put a split washer and flat washer on each caster and attach casters to the base by
threading them into their corresponding holes on the underside of the base. Securely tighten the
casters using the wrench (L) supplied.
7. For glides, attach the glides to the base by threading them into
their corresponding holes in the underside of the base.
OPERATING INSTRUCTIONS:
1. To elevate top, manually pull the tabletop to raise the top to desired height. (No need to use the handles)
2. To lower top, squeeze both red handles located on each end simultaneously to release columns and
push down on the top to the desired height. Release handles at the desired height.
Colored Dot
