HDL HDL-MP1-W-CATV/TILE.48 User manual

Overview
Tile/1 Port Cable TV Wall Plate (CATV) (See Figure 1) can be used to transmit cable TV signal.
Functions
■Cable TV signal transmission
Important Notes
■The panel should be installed in wall box.
■Please ensure correct wiring.
Product Information
Safety Precautions
■The device should be wall box mounted. HDL will not be responsible for any consequence caused
by the inexpert or faulty installation and wiring methods, which are not in accordance with the in-
structions contained in this operating instruction.
■Please do not privately disassemble or replace any parts of the product. Otherwise, it may cause
mechanical fault, electric shock, fire or personal injuries.
■Please contact our after-sales departments or our designated service agencies for your mainte-
nance service. Product failures caused by private disassembly are not subject to this warranty.
Dimensions - See Figure 2 - 3
Datasheet
Issued: May 12, 2021
File Edition: V1.0.2
1/2
Package Contents
Panel*1 / Short screw*2 / Long screw*2 / Datasheet*1
Figure 1. Tile/1 Port Cable TV Wall Plate (CATV)
Product Name Components Model No.
Tile/1 Port Cable TV Wall Plate
(CATV)
Panel HDL-MP1-W-CATV/TILE.48
Frame HDL-MP1-EC/TILE.48
Figure 3. Dimensions-Side view
Figure 2. Dimensions-Front view
86mm
86mm
35mm

Specifications
Dimensions 86×86×35(mm) (With plastic frame)
90×90×35(mm) (With metal frame)
Net weight 83g (With plastic frame)
Housing material Flame retardant PC
Installation Wall box (See Figure 4)
Approved
CE
RoHS
Technical Data
2/2
Product Name Frame Types Gang Dimensions
2/3/4-gang frames
Metal
2 gang 176*90*10.5(mm)
3 gang 262*90*10.5(mm)
4 gang 348*90*10.5(mm)
2 gang 172*86*10.5(mm)
Plastic 3 gang 258*86*10.5(mm)
4 gang 344*86*10.5(mm)
3 gang
4 gang
2 gang
2 gang
3 gang
4 gang
Notes: Metal panels can be installed either horizontally or vertically. Plastic
panels can be only installed horizontally.
Figure 5. Horizontal installation Figure 6. Vertical installation
Figure 4. Installation
①②③④
Technical support
E-mail: [e-mail]
Website: https://www.hdlautomation.com
©Copyright by HDL Automation Co., Ltd. All rights reserved.
Specifications subject to change without notice.
Installation - See Figure 4
Step 1. Install the wall box in the wall.
Step 2. Secure the power interface into the wall box with screws.
Step 3. Install the panel cover on the power interface.
Step 4. Mount the frame around the socket.
Horizontal installation - See Figure 5
Vertical installation - See Figure 6
Installation
