HENX H36CF900HE User manual

Model: H36CF900HE
Item-No.: 7063703
www.henxgarden.eu
40 Volt Cordless Leaf Blower
Akku Laubbläser, 40 Volt
Soufeur à feuilles sans l de 40 volts
Sofatore per foglie a batteria da 40 Volt
40 Volt accu bladblazer
Operating instructions
Bedienungsanleitung (Original)
Mode d'emploi
Istruzioni per l’uso
Gebruiksaanwijzing
ULTIMATE
GARDEN POWER

2
4
1 2 3
4 5 6
7
14 8
13
11
9
12 10
CBA
D
E
15
16

3
F
G
17
18
19
20

4
Overview
1. Air Outlet
2. Blower Tube
3. Tube Release
4. Lock-on Knob
5. Trigger
6. Handle
7. Control Panel
8. Boost Button
9. Eco Speed Button
10. Power Indication Button
11. On/Off Button
12. Battery Release Button
13. Electric Contacts
14. Ejection Mechanism
15. Battery Release Button
16. Mounting Slot
17. Control Panel
18. Lock-on Knob
19. Trigger
20. Blower Tube Assembly
Übersicht
1. Luftauslass
2. Laubbläserrohr
3. Rohr-Freigabetaste
4. Feststellknopf
5. Triggerschalter
6. Führungsholm
7. Bedienfeld
8. Antriebstaste
9. Eco-Drehzahl-Taste
10. Leistungsanzeigetaste
11. Ein/Aus-Schalter
12. Akku-Freigabetaste
13. Elektrische Kontakte
14. Auswurfmechanismus
15. Akku-Freigabetaste
16. Führung
17. Bedienfeld
18. Feststellknopf
19. Triggerschalter
20. Laubbläserrohr-Baugruppe
21.
Présentation générale
1. Sortie d’air
2. Tube de soufage
3. Déverrouillage du tube
4. Bouton de verrouillage
5. Gâchette
6. Poignée
7. Panneau de commande
8. Bouton d’accélération
9. Sélecteur de vitesse éco
10. Bouton avec témoin d’alimentation
11. Bouton marche/arrêt
12. Bouton de libération de la batterie
13. Contacts électriques
14. Mécanisme d’éjection
15. Bouton de libération de la batterie
16. Fente de montage
17. Panneau de commande
18. Bouton de verrouillage
19. Gâchette
20. Montage du tube de soufage
Panoramica
1. Presa d’aria
2. Tubo del sofatore
3. Rimozione del tubo
4. Manopola di blocco
5. Grilletto
6. Impugnatura
7. Pannello di controllo
8. Pulsante Boost
9. Pulsante Eco Speed
10. Pulsante con indicatore di potenza
11. Pulsante di accensione/spegnimento
12. Pulsante per la rimozione della batteria
13. Contatti elettrici
14. Meccanismo di espulsione
15. Pulsante per la rimozione della batteria
16. Scanalatura di supporto
17. Pannello di controllo
18. Manopola di blocco
19. Grilletto
20. Montaggio del tubo del sofatore
21.

5
Overzicht
1. Luchtuitlaat
2. Blaasbuis
3. Buisontgrendeling
4. Vergrendelknop
5. Trekker
6. Handgreep
7. Bedieningspaneel
8. Boostknop
9. Ecospeedknop
10. Aan-/uit-weergaveknop
11. Aan-/uitknop
12. Accu-ontgrendelknop
13. Elektrische contacten
14. Uitwerpmechanisme
15. Accu-ontgrendelknop
16. Montagesleuf
17. Bedieningspaneel
18. Vergrendelknop
19. Trekker
20. Blaasbuisassemblage

6
Contents
1. Safety guidelines . . . . . . . 8
2. Important safety instructions . . . 8
3. Additional safety instructions with
bagging attachments . . . . . 9
4. Battery tool use and care . . . .12
5. Instructions . . . . . . . .12
6. Intended use . . . . . . . .14
7. Specications . . . . . . . .14
8. List of parts . . . . . . . .15
9. Assembly . . . . . . . . .15
10. Application. . . . . . . . .16
11. Operation . . . . . . . . .16
12. Operating the blower . . . . . .17
13. Maintenance . . . . . . . .17
14. Troubleshooting . . . . . . .18
15. Warranty . . . . . . . . .18
16. Disposal . . . . . . . . .19
17. EC Declaration of Conformity . . 20
Inhalt
1. Sicherheitshinweise . . . . . 21
2. Wichtige Sicherheitshinweise . . 22
3. Zusätzliche Sicherheitshinweise für
Auffangvorrichtungen . . . . 23
4. Verwendung und Pege des Akkus 25
5. Sicherheitshinweise . . . . . 26
6. Bestimmungsgemäße Verwendung 28
7. Spezikationen . . . . . . 28
8. Lieferumfang . . . . . . . 30
9. Montage . . . . . . . . 30
10. Bestimmungsgemäßer Gebrauch . 30
11. Gebrauch . . . . . . . . 31
12. Bedienungshinweise Laubbläser . 31
13. Wartung . . . . . . . . 32
14. Fehlerbehebung . . . . . . 33
15. Garantie . . . . . . . . 33
16. Entsorgung . . . . . . . 34
17. EU-Konformitätserklärung . . . 35
Table des matières
1. Consignes de sécurité . . . . 36
2. Instructions de sécurité importantes 37
3. Consignes de sécurité
supplémentaires concernant les
accessoires d’ensachage . . . 38
4. Utilisation et soin d’un équipement
sur batterie. . . . . . . . 40
5. Instructions . . . . . . . .41
6. Utilisation prévue . . . . . . 43
7. Spécications . . . . . . . 43
8. Liste des pièces . . . . . . 44
9. Assemblage . . . . . . . 44
10. Application. . . . . . . . 45
11. Fonctionnement . . . . . . 45
12. Utilisation du soufeur . . . . 46
13. Entretien . . . . . . . . 46
14. Dépannage. . . . . . . . 47
15. Garantie . . . . . . . . 47
16. Mise au rebut . . . . . . . 48
17. Déclaration de conformitéCE . . 49
Contenuto
1. Linee guida di sicurezza . . . . 50
2. Importanti istruzioni di sicurezza . 51
3. Ulteriori istruzioni di sicurezza in
presenza di accessori . . . . 52
4. Uso e manutenzione della batteria . 54
5. Istruzioni . . . . . . . . 55
6. Destinazione d'uso . . . . . 57
7. Caratteristiche . . . . . . 57
8. Elenco dei componenti . . . . 58
9. Montaggio . . . . . . . . 58
10. Applicazione . . . . . . . 59
11. Uso . . . . . . . . . . 59
12. Funzionamento del sofatore . . 60
13. Manutenzione . . . . . . . 60
14. Risoluzione dei problemi. . . . .61
15. Garanzia . . . . . . . . .61
16. Smaltimento . . . . . . . 62
17. Dichiarazione di conformità CE . . 63
Inhoud
1. Veiligheidsrichtlijnen . . . . . 64
2. Belangrijke veiligheidsinstructies . 65
3. Aanvullende veiligheidsinstructies
voor opzakhulpstukken . . . . 66
4. Gebruik en onderhoud van
accugereedschap. . . . . . 68
5. Instructies . . . . . . . . 69
6. Beoogd gebruik . . . . . . 71
7. Specicaties . . . . . . . 71
8. Lijst van onderdelen . . . . . 72

7
9. Assemblage . . . . . . . 72
10. Applicatie . . . . . . . . 73
11. Bediening . . . . . . . . 73
12. Gebruik van de bladblazer . . . .74
13. Onderhoud. . . . . . . . .74
14. Probleemoplossing . . . . . 75
15. Garantie . . . . . . . . 75
16. Afvoer . . . . . . . . . 76
17. EU-Conformiteitsverklaring . . . 77

English
8
INTRODUCTION
Congratulations on your selection of the
HENX 40-Volt MAX Lithium-Ion Cordless
Leaf Blower. It has been designed,
engineered and manufactured to give
you the best possible dependability and
performance.
Should you experience any problem you
cannot easily remedy,please contact HENX
customer service centre +800 - 86286286.
This manual contains important information
on the safe assembly, operation and
maintenance of your string trimmer. Read it
carefully before using the string trimmer.
Keep this manual nearby so you can refer to
it at any time.
IMPORTANT
READ CAREFULLY BEFORE USE
KEEP FOR FUTURE REFERENCE
WARNING: Some dust created by power
sanding, sawing, grinding, drilling and other
construction activities contains chemicals
known to the state of California to cause
cancer, birth defects or other reproductive
harm. Some examples of these chemicals
are:
• Lead from lead-based paints
• Crystalline silica from bricks and cement
and other masonry products, and
• Arsenic and chromium from chemically-
treated lumber.
Your risk from these exposures varies,
depending on how often you do this type
of work. To reduce your exposure to these
chemicals: work in a well ventilated area,
and work with approved safety equipment,
such as those dust masks that are specially
designed to lter out microscopic particles.
1. Safety guidelines
Safety symbols
The purpose of safety symbols is to attract
your attention to possible dangers.
The safety symbols and the explanations
with them deserve your careful attention
and understanding. The symbol warnings
do not, by themselves, eliminate any danger.
The instructions and warnings they give
are no substitutes for proper accident
prevention measures.
WARNING: Be sure to read and understand
all safety instructions in this Operator’s
Manual, including all safety alert symbols
such as “DANGER,” “WARNING,” and
“CAUTION” before using this tool. Failure to
following all instructions listed below may
result in electric shock, re, and/or serious
personal injury.
Damage prevention and information
messages
These inform the user of important
information and/or instructions that could
lead to equipment or other property damage
if they are not followed.
Each message is preceded by the word
“NOTICE”, as in the example below:
NOTICE: Equipment and/or property
damage may result if these instructions are
not followed.
WARNING: The operation of any
power tools can result in foreign
objects being thrown into your eyes,
which can result in severe eye
damage. Before beginning power tool
operation, always wear safety
goggles or safety glasses with side
shields and a full face shield when
needed. We recommend a Wide
Vision Safety Mask for use over
eyeglasses or standard safety
glasses with side shields. Always use
eye protection.
2. Important safety instructions
This page depicts and describes safety
symbols that may appear on this product.
Read, understand, and follow all instructions
on the machine before attempting to
assemble and operate.
Safety alert precautions that
involve your safety.
Read operator’s manual. To reduce
the risk of injury,user must read

9
English
and understand operator’s manual
before using this product.
Long Hair. Failure to keep long hair
away from the air in let could
result in personal injury.
Loose Clothing. Failure to keep
loose clothing from being drawn
into air intake.
Eye Protection. Always wear safety
goggles or safety glasses with
side shields and a full face shield
when operating this product.
Blower Tube. Do not operate
without tube in place.
Keep Bystanders. Away keep all
bystanders at least 50 ft. away.
CE stands for “Conformité
Européenne”, which means “In
accordance with EU Regulations”.
With the CE marking, the
manufacturer conrms that this
Electric tool complies with the
applicable European directives.
This product uses lithium-ion
(Li-ion) batteries.Local,state,or
federal laws may prohibit disposal
of batteries in ordinary trash.
Consult your local waste authority
for information regarding available
recycling and/or disposal options.
Do not expose to rain.
Charging and Store the battery
pack only in dry rooms with an
ambient temperature of 50°F to
104°F (+10°C to +40°C).
IPX1
IPX4
Ingress
Protection
Degree
Protection from
splashing water
VVolt Voltage
AAmperes Current
Hz Hertz
Frequency
(cycles per
second)
WWatt Power
min Minutes Time
CFM Cubic feet
per minute Air volume
MPH Miles per
hour Air velocity
Alternating
current Type of current
Direct
current
Type or a
characteristic of
current
N0
No load
speed
Rotational speed,
at no load
... /min Per minute
Revolutions,
strokes, surface
speed, orbits etc.,
per minute
3. Additional safety instructions
with bagging attachments
• Charging battery pack only in dry
conditions and an ambient temperature
of 50°F to 104°F (10°C to 40°C).
• Protect them from humidity and direct
sunlight!
• Store the charger, battery pack and
machine only in dry places with an
ambient temperature of 50°F to 104°F
(10°C to 40°C).
READ ALL INSTRUCTIONS BEFORE USING
THIS PRODUCT!
DANGER: People with electronic devices,
such as pacemakers, should consult their
physician(s) before using this product.
Operation of electrical equipment in close

English
10
proximity to a heart pacemaker could cause
interference or failure of the pacemaker.
WARNING: To ensure safety and reliability,
all repairs should be performed by a
qualied service technician.
WARNING: To reduce risk of re, electric
shock, or injury:
Know your power blower. Read the
instruction manual carefully. Learn the
blower’s applications and limitations, as well
as the specic potential hazards related to
this blower. Following this rule will reduce
the risk of electric shock, re, or serious
injury.
a. Do not allow the blower to be used
as a toy. Close attention is necessary
when used by or near children.
b. Use only as described in this manual.
Use only manufacturer’s recommended
attachments.
c. If the blower is not working as it
should, has been dropped, damaged,
left outdoors, or dropped into water,
return it to a service center.
d. Do not handle the charger, including
charger plug, or charger terminals with
wet hands.
e. Do not put any object into any
openings. Do not use with any opening
blocked; keep openings free of dust, lint,
hair, and anything that may reduce air
ow.
f. Keep hair, loose clothing, ngers, and all
parts of body away from openings and
moving parts. Loose clothes, jewelry, or
long hair can be drawn into air vents.
g. Secure long hair above shoulder level to
prevent entanglement in moving parts.
h. Use extra care when cleaning on stairs.
i. Stay alert, watch what you are
doing and use common sense when
operating a power blower. Do not use
the blower while tired, upset, or under
the inuence of drugs, alcohol, or
medication. A moment of inattention
while operating blowers may result in
serious personal injury.
j. Avoid accidental starting. Be sure
that the switch is in the locked or off
position before inserting the battery
pack. Carrying blowers with your nger
on the switch or inserting the battery
pack into a blower with the switch on
invites accidents.
k. Use safety equipment. Always wear
eye protection. Dust mask, non-skid
safety shoes, hard hat, or hearing
protection must be used for appropriate
conditions.
l. Do not use on a ladder, rooftop, tree, or
other unstable support. Stable footing
on a solid surface enables better control
of the blower in unexpected situations.
m. Always take care of your feet, children,
or pets around you when removing
the battery pack from blower. Serious
injury could result if the battery pack
falls.
n. Do not use the blower if switch does
not turn it on or off. A blower that
cannot be controlled with the switch is
dangerous and must be repaired.
o. Disconnect the battery pack from
the blower before making any
adjustments, changing accessories,
or storing the blower. Such preventive
safety measures reduce the risk of
starting the blower accidentally.
p. Turn off all controls before removing
the battery.
q. DO NOT attempt to clear clogs from the
unit without rst removing the battery.
r. Check for misalignment or binding of
moving parts, breakage of parts, and
any other condition that may affect
the blower’s operation. If damaged,
have the blower serviced before using.
Many accidents are caused by poorly
maintained blowers.
s. Keep the blower and its handle dry,
clean and free from oil and grease.
Always use a clean cloth when
cleaning. Never use brake uids,
gasoline, petroleum-based products, or
any strong solvents to clean your blower.
Following this rule will reduce the risk of
loss of control and deterioration of the
enclosure plastic.
t. Always wear safety glasses with side
shields. Everyday glasses have only

11
English
impact resistant lenses. They are NOT
safety glasses. Following this rule will
reduce the risk of eye injury. Always
wear eye protection with side shields
along with hearing protection when
operating this equipment.
u. Protect your lungs. Wear a face or
dust mask if the operation is dusty.
v. Following this rule will reduce the risk of
serious personal injury.
w. Protect your hearing. Wear hearing
protection during extended periods
of operation. Following this rule will
reduce the risk of serious personal
injury.
x. Battery powered blowers do not have
to be plugged into an electrical outlet;
therefore, they are always in operating
condition. Be aware of possible
hazards when not using your battery
powered blower or when changing
accessories. Following this rule will
reduce the risk of electric shock, re, or
serious personal injury.
y. Wear heavy long pants, long sleeves,
boots, and gloves. Avoid loose
garments or jewelry that could get
caught in moving parts of the machine
or its motor.
z. Do not operate the equipment while
barefoot or when wearing sandals or
similar lightweight footwear. Wear
protective footwear that will protect
your feet and improve your footing on
slippery surfaces.
aa. Do not incinerate the appliance even
if it is severely damaged. The batteries
can explode in a re.
ab. Batteries can explode in the presence
of a source of ignition, such as a pilot
light. To reduce the risk of serious
personal injury, never use any cordless
product in the presence of open ame.
An exploded battery can propel debris
and chemicals. If exposed, ush with
water immediately.
ac. Keep rm footing and balance. Do not
overreach. Overreaching can result in
loss of balance.
ad. Check the work area before each
use. Remove all objects such as rocks,
broken glass, nails, wire, or string which
can be thrown by or become entangled
in the machine.
ae. Do not point the blower tube in the
direction of people or pets.
af. Never run the unit without the proper
equipment attached. Always ensure
that the blower tube is installed.
ag. When not in use, the blower should be
stored indoors in a dry, secure place
out of the reach of children.
ah. Keep all bystanders, children, and pets
at least 50 ft. away.
ai. Blower service must be performed
only by qualied repair personnel.
Service or maintenance performed by
unqualied personnel may result in a
risk of injury.
aj. When servicing a blower, use only
identical replacement parts. Follow
instructions in the Maintenance section
of this manual. Use of unauthorized
parts or failure to follow Maintenance
Instructions may create a risk of shock
or injury.
ak. Never use the blower near res or
hot ashes. Use near res or ashes can
spread res and result in serious injury
and/or property damage. Never use
blower to spread chemicals, fertilizers,
or any other toxic substances.
Spreading these substances could
result in serious injury to the operator or
bystanders.
al. Never place the blower on any surface,
except a hard, clean surface when the
engine is running. Gravel, sand, and
other debris can be picked up by the
air inlet and thrown at the operator or
bystanders, causing possible serious
injuries.
am. Save these instructions. Refer to them
frequently and use them to instruct
others who may use this tool. If you
loan this tool to someone else, also loan
these instructions to them to prevent
misuse of the product and possible
injury.

English
12
SAVE THESE INSTRUCTIONS!
4. Battery tool use and care
a. Do not charge the battery pack
outdoors.
b. Use only the charger supplied by the
manufacturer to recharge.
c. Do not leave blower unattended when
the battery is inserted. Remove the
battery when the blower is not in use
and before servicing.
d. Do not operate blowers in explosive
atmospheres, such as in the presence
of ammable liquids, gases, or dust.
Blowers create sparks which may ignite
the dust or fumes.
e. Recharge only with the charger
specied by the manufacturer. A
charger that is suitable for one type of
battery pack may create a risk of re
when used with another battery pack.
f. Use the battery operated blowers only
with specically designated battery
packs. Use of any other battery packs
may create a risk of injury and re.
g. When battery pack is not in use, keep
it away from other metal objects, like
paper clips, coins, keys, nails, screws
or other small metal objects that can
make a connection from one terminal
to another. Shorting the battery
terminals together may cause burns
or a re.
h. Under abusive conditions, liquid
may be ejected from the battery;
avoid contact. If contact accidentally
occurs, ush with water. If liquid
contact eyes, additionally seek medical
help. Liquid ejected from the battery
may cause irritation or burns.
i. Battery powered leaf blowers do not
have to be plugged into an electrical
outlet; therefore, they are always
in operating condition. Be aware of
possible hazards when not using your
battery powered leaf blowers or when
changing accessories. Following this
rule will reduce the risk of electric
shock, re, or serious personal injury.
j. Do not charge the battery pack
outdoors.
k. Use only the charger supplied by the
manufacturer to recharge.
l. Do not leave blowers unattended when
the battery is inserted. Remove the
battery when the blower is not in use
and before servicing.
m. Do not use to pick up ammable or
combustible liquids, such as gasoline,
or use in areas where they may be
present.
n. Do not operate blowers in explosive
atmospheres, such as in the presence
of ammable liquids, gases, or dust.
Blowers create sparks which may ignite
the dust or fumes.
o. Use the battery operated blower only
with specically designated battery
pack.
p. Use of any other batteries may create a
risk of re.
q. Use only with battery packs and
chargers listed below.
BATTERY PACK CHARGER
H36B25,H36B50,
H36B75
H36KC400
H36MC100
(XVE129-
4200300)
5. Instructions
When using an electrical appliance, basic
precautions should always be followed,
including the following:
5.1 Training
a. Read the instructions carefully. Be
familiar with the controls and the
correct use of the machine.
b. Never allow children or people
unfamiliar with these instructions to
use the machine. Local regulations can
restrict the age of the operator.
c. Keep in mind, that the operator or user
is responsible for accidents or hazards
occurring to other people or their
property.

13
English
5.2 Preparation
a. Obtain ear protection and safety
glasses. Wear them at all times while
operating the machine.
b. While operating the machine always
wear substantial footwear and long
trousers.
c. Do not operate the machine when
barefoot or wearing open sandals. Avoid
wearing clothing that is loose tting or
that has hanging cords or ties.
d. Do not wear loose clothing or jewellery
that can be drawn into the air inlet. Keep
long hair away from the air inlets.
e. Operate the machine in a recommended
position and only on a rm, level
surface.
f. Do not operate the machine on a paved
or gravel surface where ejected material
could cause injury.
g. Before using, always visually inspect
to see, that the bolts and other
fasteners are secure, the housing
is undamaged and that guards and
screens are in place. Replace worn
or damaged components in sets to
preserve balance. Replace damaged or
unreadable labels.
h. Never operate the machine while
people, especially children, or pets are
nearby.
5.3 Operation
a. Before starting the machine, make
certain that the feeding chamber is
empty.
b. Keep your face and body away from the
feed intake opening.
c. Do not allow hands or any other part of
the body or clothing inside the feeding
chamber, discharge chute, or near any
moving part.
d. Keep proper balance and footing at all
times. Do not overreach. Never stand
at a higher level than the base of the
machine when feeding material into it.
e. Always stand clear of the discharge
zone when operating this machine.
f. When feeding material into the machine
be extremely careful that pieces of
metal, rocks, bottles, cans or other
foreign objects are not included.
g. If the cutting mechanism strikes any
foreign objects or if the machine
should start making any unusual noise
or vibration, immediately shut off the
power source and allow the machine
to stop. Disconnect the machine from
the supply and take the following steps
before restarting and operating the
machine: i) inspect for damage; ii)
replace or repair any damaged parts; iii)
check for and tighten any loose parts.
h. Do not allow processed material to
build up in the discharge zone; this may
prevent proper discharge and can result
in kickback of material through the
intake opening.
i. If the machine becomes clogged, shut-
off the power source and disconnect
the machine from supply before
cleaning debris.
j. Never operate the machine with
defective guards or shields, or without
safety devices, for example debris
collector in place. NOTE If a debris
collector is not used the text of the
example may be deleted.
k. Keep the power source clean of debris
and other accumulations to prevent
damage to the power source or possible
re.
l. Do not transport this machine while the
power source is running.
m. Stop the machine, and remove battery
pack from the machine. Make sure
that all moving parts have come to a
complete stop - whenever you leave the
machine, before clearing blockages or
unclogging chute, - before checking,
cleaning or working on the machine.
n. Do not tilt the machine while the power
source is running.
5.4 Maintenance and storage
a. When the machine is stopped for
servicing, inspection, or storage, or
to change an accessory, shut off the
power source, disconnect the machine
from the supply and make sure that all
moving parts are come to a complete

English
14
stop. Allow the machine to cool before
making any inspections, adjustments,
etc. Maintain the machine with care and
keep it clean.
b. Store the machine in a dry place out of
the reach of children.
c. Always allow the machine to cool before
storing.
d. When servicing the shredding means
be aware that, even though the power
source is switched off due to the
interlock feature of the guard, the
shredding means can still be moved.
e. Replace worn or damaged parts for
safety. Use only genuine replacement
parts and accessories.
f. Never attempt to override the
interlocked feature of the guard.
6. Intended use
This tool is used to blow away dust leaves.
7. Specications
Model H36CF900HE H36CF900ES
Voltage 40V DC 40V DC
No Load Speed
Boost: 25000 RPM Boost: 25000 RPM
High: 22000 RPM High: 18000 RPM
Low: 18000 RPM Low: 10000 RPM
Air Volume
Boost: 530CFM Boost: 530CFM
High: 442 CFM High: 353CFM
Low: 353 CFM Low: 170 CFM
Air Velocity
Boost: 48 M/S Boost: 48M/S
High: 40 M/S High: 32 M/S
Low: 32 M/S Low: 16 M/S
Approx. Run Time
4 min. (1P1) (Boost)
12 min. (2P1) (Boost)
18 min. (3P1) (Boost)
4 min. (1P1) (Boost)
12 min. (2P1) (Boost)
18 min. (3P1) (Boost)
7 min. (1P1) (High speed)
19 min. (2P1) (High speed)
28 min. (3P1) (High speed)
13 min. (1P1) (High speed)
32 min. (2P1) (High speed)
46 min. (3P1) (High speed)
15 min. (1P1) (Eco speed)
33 min. (2P1) (Eco speed)
47 min. (3P1) (Eco speed)
68 min. (1P1) (Eco speed)
147 min. (2P1) (Eco speed)
210 min. (3P1) (Eco speed)
Blower Weight (Without
battery pack, with tube) 2.1 kg 2.1 kg
LpA 85dB(A), K=3
LwA measured 96dB(A), K=3
LwA guranteed 99 dB(A)

15
English
Vibration Max. 4.21mm/s2, K=1.5m/s2
Battery pack Lithium-Ion
Models H36B75 H36B50 H36B25 H36B200
Voltage 40 VDC 40 VDC 40 VDC 40 VDC
7.5Ah 5.0Ah 2.5Ah 20Ah
Charger (model) H36KC400
Input 100-240VAC 50-60Hz, 400W
Output 40VDC, 8A
Allowable charge
temperature range 0 - 40 °C
Charger (model) H36MC100(XVE129-4200300)
Input 100-120VAC, 50/60Hz, 2.5A Max;
Output 42.0VDC, 3A
Allowable charge
temperature range 0- 40 °C
Note: 1. 1P: H36B25; 2P:H36B50; 3P:H36B75.
8. List of parts
PART NAME QUANTITY
Blower 1
Blower tube 1
Operator’s manual 1
9. Assembly
WARNING: If any parts are damaged or
missing, do not operate this product until
the parts are replaced. Use of this product
with damaged or missing parts could result
in serious personal injury.
WARNING: Do not attempt to modify
this product or create accessories not
recommended for use with this blower. Any
such alteration or modication is misuse
and could result in a hazardous condition
leading to possible serious personal injury.
9.1 Unpacking
• Carefully remove the product and any
accessories from the box. Make sure
that all items listed in the packing list are
included.
WARNING: Do not use this product if
any parts on the packing list are already
assembled to your product when you unpack
it. Parts on this list are not assembled to the
product by the manufacturer and require
customer installation.
• Use of a product that may have been
improperly assembled could result in
serious personal injury.
• Inspect the tool carefully to make sure
no breakage or damage occurred during
shipping.
• Do not discard the packing material
until you have carefully inspected and
satisfactorily operated the tool.
• If any parts are damaged or missing,
please return the product to the place of
purchase.
9.2 Assembling the blower tube
WARNING: To prevent accidental starting
that could cause serious personal injury,
always remove the battery pack from the
tool when assembling parts.

English
16
a. Align the groove in the tube with the
knob on the blower housing. Push the
tube onto the blower housing until the
latch snaps into place (See Fig. A & B).
b. To remove the tube, press and hold the
tube-release button to disengage the
latch, then pull the tube straight from
the blower (See Fig. C).
9.3 Know your blower (See Fig. D)
The safe use of this product requires and
understanding of the information on the
tool and in this instruction manual as
well as knowledge of the project you are
attempting. Before use of this product,
familiarize yourself with all operating
features and safety rules.
Control Panel Power Indicator, On/Off
Button, Speed control
Trigger Starts or stops the
blower
Lock-on knob Lock the speed on
without keeping fingers
on the
Battery-Release
Button
Releases the battery
pack from the blower.
Over mold
Handle
Ergonomic handle with
overmold improves
comfort and grip.
10. Application
You may use this product for the purposes
listed below:
Clearing hard surfaces such as driveways
and walkways
Keeping decks and driveways free from
leaves and pine needles
11. Operation
WARNING: Do not allow familiarity with this
product to make you careless. Remember
that a careless fraction of a second is
sufcient to inict serious injury.
WARNING: Always wear eye protection with
side shields, along with hearing protection.
Failure to do so could result in objects being
thrown into your eyes and other possible
serious injuries.
WARNING: Do not use any attachments
or accessories not recommended by
the manufacturer of this product. The
use of attachments or accessories not
recommended can result in serious
personal injury.
Before each use, inspect the entire product
for damaged, missing, or loose parts, such
as screws, nuts, bolts, caps, etc. Tighten
securely all fasteners and caps and do not
operate this product until all missing or
damaged parts are replaced.
11.1 To instal/remove battery pack (See
Fig. E)
Charge before rst use.
WARNING: Always remove the battery pack
from the product when you are assembling
parts, making adjustments, cleaning, or
when not in use. Removing the battery pack
will prevent accidental starting that could
cause serious personal injury.
a. Installing
Align the ribs of the battery pack with the
mounting slots in the blower’s battery port.
Press the battery pack down until it snaps
into position.
b. Removing
Remove the battery pack from the blower.
WARNING: Always take care to note the
location of your feet, children, or pets when
pressing the battery-release button. Serious
injury could result if the battery pack falls.
Press the battery-release button; the battery
pack will disengage from the latch and
the ejection mechanism will assist with
removal.
11.2 Starting/Stopping the blower (See
Fig.F)
a. To start the blower, press power on
button then press the trigger.
b. The blower will begin to run.
c. To stop the blower, release the trigger,
press power off.
11.3 Adjusting the air velocity (See Fig. F)
a. The blower is equipped with stepless
speed regulation to control the air
speed.

17
English
b. The lock-on knob rotates clockwise to
adjust the wind speed and free your
nger from the trigger.
c. The blower starts with High speed, can
switch the speed by pressing the speed
button.
d. Boost speed mode last for 10 seconds,
then the wind volume will return to the
previous high or Eco speed.
e. Power indicator shows the balance
power of the battery.
12. Operating the blower
a. To keep from scattering debris, blow
around the outer edges of a debris pile.
b. Never blow directly into the center of a
pile.
c. To reduce sound levels, limit the number
of pieces of equipment used at any one
time.
d. Use rakes and brooms to loosen debris
before blowing. In dusty conditions,
slightly dampen surfaces if water is
available.
e. Conserve water by using power blowers
instead of hoses for many lawn and
garden applications, including areas
such as gutters, screens, patios, grills,
porches, and gardens.
f. Watch out for children, pets, open
windows, or freshly washed cars, and
blow debris safely away.
g. After using blowers or other equipment,
clean up! Dispose of debris properly.
13. Maintenance
WARNING: When servicing, use only
identical replacement parts. Use of any
other parts may create a hazard or cause
product damage. To ensure safety and
reliability, all repairs should be performed by
a qualied service technician.
WARNING: To avoid serious personal injury,
always remove the battery pack from the
product when cleaning or performing any
maintenance.
13.1 General maintenance
Avoid using solvents when cleaning plastic
parts. Most plastics are susceptible to
damage from various types of commercial
solvents and may be damaged by their use.
Use clean clothes to remove dirt, dust, oil,
grease, etc.
WARNING: Do not at any time let brake
uids, gasoline, petroleum based products,
penetrating oils, etc., come in contact with
plastic parts. Chemicals can damage,
weaken or destroy plastic which may result
in serious personal injury.
13.2 Storage
• Clean all foreign material from the air
inlets of the blower.
• Store indoors in a place that is
inaccessible to children. Keep away
from corrosive agents, such as garden
chemicals and de-icing salts.

English
18
14. Troubleshooting
PROBLEM CAUSE SOLUTION
Blower doesn’t work. • The battery pack is not
attached to the blower.
• No electrical contact
between the blower and
battery
• The battery pack is
depleted.
• The battery pack or
blower is too hot.
• Attach the battery pack
to the blower.
• Remove battery, check
contacts and reinstall
the battery pack.
• Charge the battery pack.
• Cool the battery pack
and blower until the
temperature drops
below 152°F (67°C).
The air velocity
decreases obviously.
• Excessive wearing of
motor fan.
• The air inlet is blocked by
debris.
• Contact Q-stion service
center for repair.
• Remove the battery
pack, clear the debris.
15. Warranty
HENX Warranty policy
2 year limited warranty on HENX outdoor
power equipment and 2 year limited
warranty on HENX battery packs and
chargers.
Please contact Q-stion Customer Service
at +800 - 86286286 any time you have
questions or warranty claims.
Limited service warranty
FOR TWO YEARS from the date of original
retail purchase, this HENX product is
warranted against defects in material or
workmanship. Defective product will receive
free repair.
FOR TWO YEARS from the date of original
retail purchase, the HENX ONE System
battery pack and charger are warranted
against defects in material or workmanship.
Defective product will receive free repair.
This warranty does not cover routine
maintenance parts and consumables that
can wear out from normal use within the
warranty period.
a. This warranty applies only to the original
purchaser from an authorized HENX
retailer and may not be transferred.
b. The warranty period for any HENX
product or part used for industrial,
professional or commercial purpose is
ONE year.
c. This warranty is void if the product has
been used for rental purpose.
d. This warranty does not cover the
damage resulting from modication,
alteration or unauthorized repair.
e. This warranty only covers defects
arising under normal usage and does
not cover any malfunction, failure or
defect resulting from misuse, abuse
(including overloading of the product
beyond capacity and immersion in
water or other liquid), accidents, neglect
or lack of proper installation, and
improper maintenance or storage.
f. This warranty does not cover normal
deterioration of the exterior nish,
including but not limited to scratches,
dents, paint chips, or to any corrosion
or discoloring by heat, abrasive and
chemical cleaners.
How to obtain service
For warranty service, please contact Q-stion
customer service at +800 - 86286286 or
mail [e-mail].

19
English
When requesting warranty service, you must
present the original dated sales receipt.
An authorized service center will be selected
to repair the product according to the stated
warranty terms.
Additional limitations
To the extent permitted by applicable law,
all implied warranties, including warranties
of MERCHANTABILITY or FITNESS FOR A
PARTICULAR PURPOSE, are disclaimed.
Any implied warranties, including warranties
of merchantability or tness for a particular
purpose, that cannot be disclaimed under
state law are limited to three years from
the date of purchase for outdoor power
equipment and two years from date of
purchase for battery pack and charger.
Some states do not allow limitations on how
long an implied warranty lasts and/or do not
allow the exclusion or limitation of incidental
or consequential damages, so the above
limitations may not apply to you.
This warranty gives you specic legal rights,
and you may also have other rights which
vary from state to state.
Costumer Service:
Q-Stion B.V.
+800 - 86286
Email: [e-mail]
Parts list
40V LITHIUM-ION CORDLESS BLOWER (See
Fig. G)
Model Number: H36CF900
The Model Number will be found on the
Nameplate attached to the housing of the
blower. Always mention the Model Number
when ordering parts for this tool.
PART NAME QUANTITY
Blow Tube Assembly 1
16. Disposal
To comply with European Directive
2012/19/EU concerning old electric
and electronic equipment and its
implementation in national laws, old electric
power tools have to be separated from other
waste and disposed of in an environment-
friendly fashion, e.g. by taking to a recycling
depot.
Recycling alternative to the return request:
As an alternative to returning the equipment
to the manufacturer, the owner of the
electrical equipment must make sure that
the equipment is properly disposed of if he
no longer wants to keep the equipment. The
old equipment can be returned to a suitable
collection point that will dispose of the
equipment in accordance with the national
recycling and waste disposal regulations.
This does not apply to any accessories or
aids without electrical components supplied
with the old equipment.
Environmental damage through incorrect
disposal of the batteries / rechargeable
batteries.
Batteries /rechargeable batteries
may not be disposed of with the
usual domestic waste. They may
contain toxic heavy metals and are subject
to hazardous waste treatment rules and
regulations. Please dispose of batteries
according to the relevant local
requirements.
Remove the battery from the product before
disposal.

English
20
17. EC Declaration of Conformity
We here with declare, Ningbo AOSHENG Machine Co., Ltd
Linshan Industrial Park, Yuyao City, Zhejiang
Province, China
That the following machine complies with the appropriate basic safety and health
requirements of the EC Directive based on its design and type, as brought into circulation
by us.
In case of alteration of the machine, not agreed upon by us, this declaration will lose its
validity
Machine Description: Cordless leaf blower
Machine Type: H36CF900HE, H36CF900ES
Trade name: N.A.
Serial Number: N.A.
Applicable EC Directives: EC Machinery Directive: 2006/42/EG
EC Directive of Electromagnetic Compatibility
(2004/108/EC)
EC Directive of noise emission (2000/14/EC)
Applicable Harmonized Standards: EN 60745-1
EN 15503
EN 55014-1
EN 55014-2
Authorized Signature/Date/ Place: .. Product Manager
Ningbo AOSHENG Machine Co., Ltd
Linshan Industrial Park, Yuyao City, Zhejiang
Province, China
Title of Signatory:
Name and address of the authorized
person that put the technical
documents together
Ningbo AOSHENG Machine Co., Ltd
Linshan Industrial Park, Yuyao City, Zhejiang
Province, China
