Ozito Power X Change PXCBLHTC-018 User manual

*
CORDLESS
BLOWER
INSTRUCTION MANUAL
SPECIFICATIONS
Voltage: 18V
No Load Speed: 12,000/min
Max. Air Speed: 210km/hr
Weight: 1.35kg (w/o battery)
PXCBLHTC-018
WHAT’S IN THE BOX
Cordless Blower
4.0Ah & 2.0Ah Batteries
IN ORDER TO MAKE A CLAIM UNDER THIS WARRANTY YOU MUST
RETURN THE PRODUCT TO YOUR NEAREST BUNNINGS WAREHOUSE
WITH YOUR BUNNINGS REGISTER RECEIPT. PRIOR TO RETURNING
YOUR PRODUCT FOR WARRANTY PLEASE TELEPHONE OUR CUSTOMER
SERVICE HELPLINE:
Australia 1800 069 486
New Zealand 0508 069 486
WARRANTY
TO ENSURE A SPEEDY RESPONSE PLEASE HAVE THE MODEL
NUMBER AND DATE OF PURCHASE AVAILABLE. A CUSTOMER
SERVICE REPRESENTATIVE WILL TAKE YOUR CALL
AND ANSWER ANY QUESTIONS YOU MAY
HAVE RELATING TO THE WARRANTY POLICY
OR PROCEDURE.
OZITO Australia/New Zealand (Head Ofce) 1-23 Letcon Drive, Bangholme, Victoria, Australia 3175.
The benets provided under this warranty are in addition
to other rights and remedies which are available to you at law.
Our goods come with guarantees that cannot be excluded
at law. You are entitled to a replacement or refund for a major failure and for
compensation for any other reasonably foreseeable loss or damage. You are also
entitled to have the goods repaired
or replaced if the goods fail to be of acceptable quality and the failure does not
amount to a major failure.
Generally you will be responsible for all costs associated with
a claim under this warranty, however, where you have suffered
any additional direct loss as a result of a defective product you
may be able to claim such expenses by contacting our customer service helpline
above.
ozito.com.au
0716
WARNING
The following actions will result in the warranty being
void.
• If the tool has been operated on a supply voltage other
than that specied on the tool.
• If the tool shows signs of damage or defects caused
by or resulting from abuse, accidents or alterations.
• Failure to perform maintenance as set out within the instruction manual.
• If the tool is disassembled or tampered with in any way.
5 YEAR REPLACEMENT WARRANTY
Your Product is guaranteed for a period of 60 months from the original date of
purchase and is intended for DIY (Do It Yourself) use only. If a product is defective it
will be replaced in accordance with the terms of this warranty. Lithium Ion
batteries and chargers are covered by a 36 month
warranty. Warranty excludes consumable parts, for example: blower tube.
Fast Charger
Cordless Hedge Trimmer

ONLINE MANUAL
Scan this QR Code with your mobile
device to take you to the online
manual.
6. Battery Release Tab
7. Battery Charge LED’s
8. Battery Charge Indicator Button
9. Charger LED’s
10. Charger
ACCESSORIES
CORDLESS BLOWER (PXCBLK-018)
KNOW YOUR PRODUCT
1
6
2
7
3
8
4
9
5
10
1. ASSEMBLY
SETUP & PREPARATION
1. Align the blower tube with the
outlet of the blower.
3. To remove the blower tube, press
the blower tube release tab
while pulling the tube away from
the housing.
2. Push the blower tube
onto the blower until it
clicks into place.
Fitting the Blower Tube
WARNING! ENSURE THE TOOL IS SWITCHED
OFF AND BATTERY DISCONNECTED BEFORE
PERFORMING ANY OF THE FOLLOWING TASKS.
1. Blow Tube
2. Blow Tube Release Tab
3. Handle
4. Trigger Switch
5. Battery Seating
*

2. BATTERY & CHARGING
Charging your lithium ion battery
The tools battery has been shipped in a low charge condition, and requires charging
prior to use. Allow several cycles of charging and discharging (through use of the tool)
for the battery to reach its optimum performance / runtime.
CAUTION: THE CHARGER FOR THIS PRODUCT
SHOULD BE PROTECTED BY A RESIDUAL CURRENT
DEVICE (RATED AT 30MA OR LESS).
Battery Charge Indicator
The purchased battery is equipped with a
battery charge indicator to show the state of
the battery charge.
Press the charge indicator button and look to
see which LED lights.
Battery requires immediate charging
Low state of charge, requires charging soon.
Mid state of charge
Full state of charge.
Note: The battery needs to be removed from the tool to check the state of charge.
Battery protection system
The tool is equipped with the battery protection system, which helps to ensure a long
service life.
The output power automatically cuts off during operation when the tool and/or battery
are placed under the following situations:
• When the tool is overloaded:
If this occurs, release the trigger switch and remove causes of overload, then pull
the switch trigger again to restart.
• When the remaining battery capacity becomes low:
Recharge the battery pack.
Note: The battery protection system does not in any way damage the tool.
Note: The indicated capacity may be lower than the actual level during use or
immediately after using the tool.
1. Connect the charger into a mains power outlet.
4. The charger LED will illuminate
red signifying that the battery is
charging.
3. With the charger sitting on a at
surface, align the raised ribs on
the battery with the recess in the
charger and slide onto the charger
ensuring a rm connection.
2. The charger LED will ash green
showing power is being supplied
to the charger.
5. The charger LED will illuminate
green once the battery is charged.
Charging your lithium ion battery - Fast Charger
Charger LED Indicator
LED Indicator Situation
GREEN (Flashing) Stand By (no battery pack is inserted)
RED (Flashing) Battery is charging (low charge)
RED (Illuminated) Battery is charging (mid charge)
GREEN (Illuminated) Battery is fully charged
BOTH(Illuminated) Battery pack is too hot or too cold (charging will begin
automatically when battery reaches correct charging
temperature).
BOTH (Flashing) Defective battery. Never charge a defective battery
pack!
Remove battery pack from charger.

3. INSERTING & REMOVING THE BATTERY 4. CONTROLS & OPERATION
OPERATION
1. Align the ribs of the battery with
the recess below the handle.
1. Press and hold the battery
release tab to release the
battery.
2. Slide the battery in so
that it clicks into place.
1. To start the blower
squeeze the on/off
switch.
2. To stop the blower
release the on/off
switch.
2. Slide the battery out.
Inserting the Battery into the Blower
Removing the Battery from the Blower
Switching On and Off
Blowing
The blower is ideal for blowing
leaves, grass clippings and
other debris.
Hold the blower rmly, squeeze
the on/off switch, point the jet
of air in front of you and move
forward slowly. Move the
blower from side to side, with
the tube several inches above
the ground.
Be careful where you point the
jet of air as it can move heavy
material and cause injury or
damage to bystanders.
Note: Be aware of other people and animals in the area where you are to
be operating the blower.
Note: Avoid collisions with hard objects which could damage your machine.
WARNING!: DO NOT USE THE BLOWER WITH ANY
TYPE OF ACCESSORY OR ATTACHMENT. SUCH
USAGE MIGHT BE HAZARDOUS.
WARNING!: DO NOT PUT PART OF YOUR BODY
SUCH AS HANDS AND FINGERS IN THE VACUUM
OPENING OR EXHAUST OPENING.
WARNING!: DO NOT SWITCH THE BLOWER ON
IN ENCLOSED OR POORLY VENTILATED SPACES
OR IN THE PRESENCE OF FLAMMABLE AND/OR
EXPLOSIVE LIQUIDS, GASES AND POWDERS.
WARNING! DO NOT USE ANY ATTACHMENTS
OR ACCESSORIES NOT RECOMMENDED BY THE
MANUFACTURER OF THIS PRODUCT, AS IT CAN
RESULT IN SERIOUS PERSONAL INJURY.
PXCBLHTC-018

MAINTENANCE
DESCRIPTION OF SYMBOLS
CARING FOR THE ENVIRONMENT
TROUBLESHOOTING
Power tools that are no longer usable should not be disposed of with household
waste but in an environmentally friendly way. Please recycle where facilities exist.
Check with your local council authority for recycling advice.
Recycling packaging reduces the need for landll and raw materials. Reuse of
recycled material decreases pollution in the environment. Please recycle packaging
where facilities exist. Check with your local council authority for recycling advice.
Spare Part Part No.
Battery pack 4.0Ah PXBP-400
Battery pack 2.0Ah PXBP-200
Fast charger PXCG-030 or PXCFCH-030
Spare parts can be ordered from the Special Orders
Desk at your local Bunnings Warehouse.
For further information, or any parts not listed here,
visit www.ozito.com.au or contact Ozito Customer
Service:
Australia 1800 069 486
New Zealand 0508 069 486
E-mail: [email protected]
SPARE PARTS
THIS MANUAL CONTAINS IMPORTANT SAFETY AND OPERATING INSTRUCTIONS FOR YOUR
BATTERY CHARGER.
1. Before using the charger read all instructions and cautionary markings on the charger, battery pack and the product
using the battery pack.
2. This charger is not intended for any uses other than charging rechargeable batteries. Any other use may result in risk
of re, electric shock or electrocution.
3. Do not place any object on top of the charger or place the charger on a soft surface that may result in excessive
internal heat. Place the charger in a position away from any heat source.
4. To reduce risk of damage to the electric plug and cord, pull by the plug rather than the cord when disconnecting the
charger.
5. Make sure the cord is located so that it will not be stepped on, tripped over, or otherwise subjected to damage or
stress.
6. An extension cord should not be used unless absolutely necessary. Use of an improper extension cord could result in the risk
of re, electric shock or electrocution.
7. Do not operate the charger if it has received a sharp blow, been dropped or otherwise damaged in any way. Have it
checked by an electrician or power tool repairer.
8. Do not disassemble charger. Take it to an electrician or power tool repairer when service or repair is required. Incorrect
reassembly may result in a risk of electric shock, electrocution or re.
9. To reduce risk of electric shock, unplug the charger from the outlet before attempting any cleaning. Removing the
battery pack will not reduce this risk.
10. Never attempt to connect 2 chargers together.
11. DO NOT store or use the tool and battery pack in locations where the temperature may reach or exceed 40ºC (such as inside
sheds or metal buildings in summer).
12. The charger is designed to operate on standard household electrical power (240 volts). Do not attempt to use it on any
other voltage!
13. The battery pack is not fully charged out of the carton. First read the safety instructions and then follow the charging
notes and procedures.
14. The longest life and best performance can be obtained if the battery pack is charged when the air temperature is
between 18 - 24ºC. Do not charge the battery pack in an air temperature below 10ºC or above 40ºC. This is important
and will prevent damage to the battery pack.
15. Do not incinerate the battery pack even if it is seriously damaged or is completely worn out. The battery can explode in
a re.
16. Never attempt to open the battery pack for any reason. If the plastic housing of the battery pack breaks or cracks, immedi-
ately discontinue use and do not recharge.
17. During charging, the battery must be placed in a well ventilated area.
BATTERY AND CHARGER SAFETY WARNINGS
• Keepairintakecleanandairventsfreeofdebristoavoidoverheatingthemotor.
• Donotusecleaningagentstocleantheplasticpartsofthetool.
A mild detergent on a damp cloth is recommended. Water must never come into contact with
the tool.
• Iftheblowervibratesabnormally,stopmotorimmediately.Abnormalvibrationusuallyindicates
a mechanical problem continued operation could lead to injury or damage.
• Nolubricationisnecessaryasthemotorisequippedwithlifetime-lubricatedbearings.
WARNING! ALWAYS ENSURE THE TOOL HAS
COMPLETELY STOPPED AND THE BATTERY IS
REMOVED PRIOR TO ANY MAINTENANCE.
Problem Cause Remedy
Blower is not
starting
Possible clogging Clean the blower tube and blower outlet of
any leaves or debris.
Battery is low in charge Charge battery
Battery not inserted
properly
Insert battery pack correctly
Blower is not
operating at
full capacity
Possible clogging Clean the blower tube and blower outlet of
any leaves or debris.
Motor stops
while blowing
Battery has no power Charge battery
Note: Ozito Industries will not be responsible for any damage or injuries caused by the repair of the
blower by an unauthorised person or by mishandling of the blower. This tool is designed for DIY use
- use in commercial or industrial environments will void the warranty.
Read instruction manual
Do not use in the rain or leave the blower outdoors while raining.
Regulator compliance mark
Keep bystanders away. Do not operate whilst people especially
children or pets are in the area.
Wear eye and ear protection.

BLOWER SAFETY WARNINGS
WARNING! When using mains-powered tools, basic safety precautions, including
the following, should always be followed to reduce risk of fire, electric shock, personal
injury and material damage.
Read the whole manual carefully and make sure you know how to switch the tool off in an emergency, before operating the tool.
Save these instructions and other documents supplied with this tool for future reference.
The charger has been designed for 230V and 240V only. Always check that the power supply corresponds to the voltage on the rating
plate.
Note: The supply of 230V and 240V on Ozito tools are interchangeable for Australia and New Zealand.
This tools charger is double insulated, therefore no earth wire is required.
If the supply cord is damaged, it must be replaced by an electrician or a power tool repairer in order to avoid a hazard.
Note: Double insulation does not take the place of normal safety precautions when operating this tool. The insulation system is for
added protection against injury resulting from a possible electrical insulation failure within the tool.
The power supply for this products charger should be protected by a residual current device (rated at 30mA
or less). A residual current device reduces the risk of electric shock.
GENERAL POWER TOOL SAFETY WARNINGS
ELECTRICAL SAFETY
WARNING! Read all safety warnings and all instructions. Failure to follow the warnings and
instructions may result in electric shock, re and/or serious injury.
Save all warnings and instructions for future reference. The term “power tool” in the
warnings refers to your mains-operated (corded) power tool or battery-operated (cordless)
power tool.
1. Work area safety
a. Keep work area clean and well lit. Cluttered or dark areas invite accidents.
b. Do not operate power tools in explosive atmospheres, such as in the presence of
flammable liquids, gases or dust. Power tools create sparks which may ignite the dust or fumes.
c. Keep children and bystanders away while operating a power tool. Distractions can cause you to lose
control.
2. Electrical safety
a. Power tool plugs must match the outlet. Never modify the plug in any way. Do not use
any adapter plugs with earthed (grounded) power tools. Unmodied plugs and matching outlets will
reduce risk of electric shock.
b. Avoid body contact with earthed or grounded surfaces, such as pipes, radiators, ranges
and refrigerators. There is an increased risk of electric shock if your body is earthed or grounded.
c. Do not expose power tools to rain or wet conditions. Water entering a power tool will increase the risk
of electric shock.
d. Do not abuse the cord. Never use the cord for carrying, pulling or unplugging the power
tool. Keep cord away from heat, oil, sharp edges or moving parts. Damaged or entangled cords
increase the risk of electric shock.
e. When operating a power tool outdoors, use an extension cord suitable for outdoor use.
Use of a cord suitable for outdoor use reduces the risk of electric shock.
f. If operating a power tool in a damp location is unavoidable, use a residual current device
(RCD) protected supply. Use of an RCD reduces the risk of electric shock.
3. Personal safety
a. Stay alert, watch what you are doing and use common sense when operating a power
tool. Do not use a power tool while you are tired or under the influence of drugs, alcohol
or medication. A moment of inattention while operating power tools may result in serious personal injury.
b. Use personal protective equipment. Always wear eye protection. Protective equipment such as dust
mask, non-skid safety shoes, hard hat, or hearing protection used for appropriate conditions will reduce personal injuries.
c. Prevent unintentional starting. Ensure the switch is in the off-position before connecting
to power source and/or battery pack, picking up or carrying the tool. Carrying power tools with
your nger on the switch or energising power tools that have the switch on invites accidents.
d. Remove any adjusting key or wrench before turning the power tool on. A wrench or a key left
attached to a rotating part of the power tool may result in personal injury.
e. Do not overreach. Keep proper footing and balance at all times. This enables better control of the
power tool in unexpected situations.
f. Dress properly. Do not wear loose clothing or jewellery. Keep your hair, clothing and
gloves away from moving parts. Loose clothes, jewellery or long hair can be caught in moving parts.
g. If devices are provided for the connection of dust extraction and collection facilities,
ensure these are connected and properly used. Use of dust collection can reduce dust-related hazards.
4. Power tool use and care
a. Do not force the power tool. Use the correct power tool for your application. The correct
power tool will do the job better and safer at the rate for which it was designed.
b. Do not use the power tool if the switch does not turn it on and off. Any power tool that cannot be
controlled with the switch is dangerous and must be repaired.
c. Disconnect the plug from the power source and/or the battery pack from the power
tool before making any adjustments, changing accessories, or storing power tools. Such
preventive safety measures reduce the risk of starting the power tool accidentally.
d. Store idle power tools out of the reach of children and do not allow persons unfamiliar
with the power tool or these instructions to operate the power tool. Power tools are dangerous in
the hands of untrained users.
e. Maintain power tools. Check for misalignment or binding of moving parts, breakage of
parts and any other condition that may affect the power tool’s operation. If damaged,
have the power tool repaired before use. Many accidents are caused by poorly maintained power tools.
f. Keep cutting tools sharp and clean. Properly maintained cutting tools with sharp cutting edges are less likely to
bind and are easier to control.
g. Use the power tool, accessories and tool bits etc. in accordance with these instructions,
taking into account the working conditions and the work to be performed. Use of the power
tool for operations different from those intended could result in a hazardous situation.
5. Battery tool use and care
a. Recharge only with the charger specified by the manufacturer. A charger that is suitable for one
type of battery pack may create a risk of re when used with another battery pack.
b. Use power tools only with specifically designated battery packs. Use of any other battery packs may
create a risk of injury and re.
c. When battery pack is not in use, keep it away from other metal objects, like paper clips,
coins, keys, nails, screws or other small metal objects, that can make a connection from
one terminal to another. Shorting the battery terminals together may cause burns or a re.
d. Under abusive conditions, liquid may be ejected from the battery; avoid contact. If
contact accidentally occurs, flush with water. If liquid contacts eyes, additionally seek
medical help. Liquid ejected from the battery may cause irritation or burns.
6. Service
a. Have your power tool serviced by a qualified repair person using only identical
replacement parts. This will ensure that the safety of the power tool is maintained.
• Always wear adequate protective clothing when operating the blower to avoid injuries to face, eyes,
hands, feet, head or hearing. Use safety glasses or a face shield, high boots or sturdy shoes, long
trousers, work gloves, a hard hat and ear defenders.
• Do not start the tool when it is upside down or when it is not in the operating position.
• Switch the motor off and remove the battery when the tool is not being used, left unattended, being
cleaned or being moved from one place to another.
• Do not operate the tool near people, especially children or pets. Turn it off if they get too close.
Maintain a safe distance of at least 5m from other people when using the tool.
• Never direct the blower direction nozzle towards bystanders or pets. Never blow debris in the
direction of bystanders or pets. The operator is responsible for accidents or hazards occurring to
other people or their property.
• Do not handle the battery or the tool with wet hands and do not use the tool in
the rain.
• Keep all the air intakes and the blower tube free of dust, lint, hair and other material that may cause
a reduction in air ow.
• Keep a balanced and stable stance while using the tool. Do not switch on the tool in enclosed or
poorly ventilated spaces or in the presence of inammable and/or explosive substances such as
liquids, gasses and powders.
• Do not get distracted and always concentrate on what you are doing. Use common sense. Never
operate the tool when you are tired, sick or under the inuence of alcohol or other drugs.
• Do not operate this appliance with long loose hair or loose tting jewellery. Tie long loose hair back
and remove loose tting jewellery.
• Only operate the tool during broad daylight or with adequate articial light.
• When the tool is not in use, store it in a dry place and out of reach of children.
• Only use the tool according to the instructions given in this manual.
• Check regularly that the screws are tight.
WARNING! When servicing, use only identical replacement parts. Use of any other parts
may create a hazard or cause product damage. To ensure safety and reliability, all repairs should
be performed by a qualied service technician.
WARNING! This appliance is not intended for use by young or inrm persons unless
supervised by a responsible person to ensure that they can use the appliance safely. Young
children should be supervised to ensure that they do not play with the appliance.

CORDLESS
HEDGE TRIMMER
INSTRUCTION MANUAL
SPECIFICATIONS
Voltage: 18V
No Load Speed: 2,200/min
Max. Cutting Capacity: 11mm
Blade Length: 460mm
Weight: 2.10kg (w/o battery)
PXCBLHTC-018
WHAT’S IN THE BOX
Cordless Hedge Trimmer
ozito.com.au
Blade Cover
IN ORDER TO MAKE A CLAIM UNDER THIS WARRANTY YOU MUST
RETURN THE PRODUCT TO YOUR NEAREST BUNNINGS WAREHOUSE
WITH YOUR BUNNINGS REGISTER RECEIPT. PRIOR TO RETURNING
YOUR PRODUCT FOR WARRANTY PLEASE TELEPHONE OUR CUSTOMER
SERVICE HELPLINE:
Australia 1800 069 486
New Zealand 0508 069 486
WARRANTY
TO ENSURE A SPEEDY RESPONSE PLEASE HAVE THE MODEL
NUMBER AND DATE OF PURCHASE AVAILABLE. A CUSTOMER
SERVICE REPRESENTATIVE WILL TAKE YOUR CALL
AND ANSWER ANY QUESTIONS YOU MAY
HAVE RELATING TO THE WARRANTY POLICY
OR PROCEDURE.
OZITO Australia/New Zealand (Head Ofce) 1-23 Letcon Drive, Bangholme, Victoria, Australia 3175.
The benets provided under this warranty are in addition
to other rights and remedies which are available to you at law.
Our goods come with guarantees that cannot be excluded
at law. You are entitled to a replacement or refund for a major failure and for
compensation for any other reasonably foreseeable loss or damage. You are also
entitled to have the goods repaired
or replaced if the goods fail to be of acceptable quality and the failure does not
amount to a major failure.
Generally you will be responsible for all costs associated with
a claim under this warranty, however, where you have suffered
any additional direct loss as a result of a defective product you
may be able to claim such expenses by contacting our customer service helpline
above.
0716
WARNING
The following actions will result in the warranty being
void.
• If the tool has been operated on a supply voltage other
than that specied on the tool.
• If the tool shows signs of damage or defects caused
by or resulting from abuse, accidents or alterations.
• Failure to perform maintenance as set out within the instruction manual.
• If the tool is disassembled or tampered with in any way.
5 YEAR REPLACEMENT WARRANTY
Your Product is guaranteed for a period of 60 months from the original date of
purchase and is intended for DIY (Do It Yourself) use only. If a product is defective it
will be replaced in accordance with the terms of this warranty. Lithium Ion
batteries and chargers are covered by a 36 month
warranty. Warranty excludes consumable parts, for example: blade, blade cover.
*
Cordless Blower
4.0Ah & 2.0Ah Batteries
Fast Charger

ONLINE MANUAL
Scan this QR Code with your mobile
device to take you to the online manual.
KNOW YOUR PRODUCT
1. ASSEMBLY
SETUP & PREPARATION
The blade cover protects the blade
when not in use. Simply slide it
off the blade before use. Once
nished operating, place the cover
back over the blade.
Ensure the safety guard
is tted securely onto the
hedge trimmer before use.
Tighten the screws on either
side if necessary.
Blade Cover
Safety Guard
WARNING! ENSURE THE TOOL IS SWITCHED
OFF AND BATTERY DISCONNECTED BEFORE
PERFORMING ANY OF THE FOLLOWING TASKS.
WARNING! NEVER USE THE HEDGE TRIMMING
UNLESS THE SAFETY GUARD IS FITTED.
WARNING! NEVER START THE HEDGE TRIMMER
WHILE THE BLADE COVER IS FITTED.
9. Battery Release Tab
10. Battery Charge LED’s
11. Battery Charge Indicator Button
12. Blade Cover
13. Charger LED’s
14. Charger
ACCESSORIES
1
9
2
10
3 4 5 6
11
7
12
8
13 14
1. Impact Guard
2. Blade
3. Safety Guard
4. Front Handle
5. Safety Switch
6. On/Off Trigger
7. Rear Handle
8. Battery Seating
CORDLESS HEDGE TRIMMER (PXCHTK-018)
WARNING! WHEN HANDLING THE BLADE ASSEMBLY,
WEAR NON-SLIP, HEAVY-DUTY PROTECTIVE GLOVES.
DO NOT PLACE YOUR HAND OR FINGERS BETWEEN
BLADES OR IN ANY POSITION WHERE THEY COULD
GET PINCHED OR CUT. NEVER TOUCH BLADES
OR SERVICE THE UNIT WITH THE BATTERY PACK
INSTALLED.
*

2. BATTERY & CHARGING
The tools battery has been shipped in a low charge condition, and requires charging
prior to use. Allow several cycles of charging and discharging (through use of the tool)
for the battery to reach its optimum performance / runtime.
CAUTION: THE CHARGER FOR THIS PRODUCT
SHOULD BE PROTECTED BY A RESIDUAL CURRENT
DEVICE (RATED AT 30MA OR LESS).
Battery Charge Indicator
The purchased battery is equipped with a
battery charge indicator to show the state of
the battery charge.
Press the charge indicator button and look to
see which LED lights.
Battery requires immediate charging
Low state of charge, requires charging soon.
Mid state of charge
Full state of charge.
Note: The battery needs to be removed from the tool to check the state of charge.
Battery protection system
The tool is equipped with the battery protection system, which helps to ensure a long
service life.
The output power automatically cuts off during operation when the tool and/or battery
are placed under the following situations:
• When the tool is overloaded:
If this occurs, release the trigger switch and remove causes of overload, then pull
the switch trigger again to restart.
• When the remaining battery capacity becomes low:
Recharge the battery pack.
Note: The battery protection system does not in any way damage the tool.
Note: The indicated capacity may be lower than the actual level during use or
immediately after using the tool.
1. Connect the charger into a mains power outlet.
4. The charger LED will illuminate
red signifying that the battery is
charging.
3. With the charger sitting on a at
surface, align the raised ribs on
the battery with the recess in the
charger and slide onto the charger
ensuring a rm connection.
2. The charger LED will ash green
showing power is being supplied
to the charger.
5. The charger LED will illuminate
green once the battery is charged.
Charging your lithium ion battery - Fast Charger
Charger LED Indicator
LED Indicator Situation
GREEN (Flashing) Stand By (no battery pack is inserted)
RED (Flashing) Battery is charging (low charge)
RED (Illuminated) Battery is charging (mid charge)
GREEN (Illuminated) Battery is fully charged
BOTH(Illuminated) Battery pack is too hot or too cold (charging will begin
automatically when battery reaches correct charging
temperature).
BOTH (Flashing) Defective battery. Never charge a defective battery
pack!
Remove battery pack from charger.

3. INSERTING & REMOVING THE BATTERY 4. CONTROLS & OPERATION
OPERATION
1. Align the ribs of the battery with
the recess in below the handle.
1. Press and hold the safety switch.
1. Press and hold the battery
release tab to release the
battery.
2. Slide the battery in so
that it clicks into place.
2. To start the hedge
trimmer, squeeze the on/
off trigger.
3. To stop operating,
release the on/off
trigger.
2. Slide the battery out.
Inserting the Battery into the Hedge Trimmer
Removing the Battery from the Hedge Trimmer
Switching On and Off
Top cutting
Use a wide sweeping motion.
A slight downward tilt of the
cutting blades in the direction
of motion gives the best
cutting results.
Side cutting
When trimming the sides of the hedge,
begin at the bottom and cut upwards.
Trim the side of a hedge so that it will
be slightly narrower at the top. This
shape will expose more of the hedge,
resulting in a more uniform growth.
WARNING! DO NOT USE ANY ATTACHMENTS
OR ACCESSORIES NOT RECOMMENDED BY THE
MANUFACTURER OF THIS PRODUCT, AS IT CAN
RESULT IN SERIOUS PERSONAL INJURY.
WARNING! CLEAR THE AREA TO BE CUT BEFORE
EACH USE. REMOVE ALL OBJECTS, SUCH AS CORDS,
LIGHTS, WIRE, OR STRING WHICH CAN BECOME
ENTANGLED IN THE CUTTING BLADE AND CREATE A
RISK OF SERIOUS PERSONAL INJURY.
WARNING! IF THE BLADE JAMS ON ANY ELECTRICAL
CORD OR LINE, DO NOT TOUCH THE BLADE! IT
CAN BECOME ELECTRICALLY LIVE AND VERY
DANGEROUS. CONTINUE TO HOLD THE HEDGE
TRIMMER BY THE INSULATED REAR HANDLE
OR LAY IT DOWN AND AWAY FROM YOU IN A
SAFE MANNER. DISCONNECT THE ELECTRICAL
SERVICE TO THE DAMAGED LINE OR CORD BEFORE
ATTEMPTING TO FREE THE BLADE. FAILURE TO HEED
THIS WARNING MAY RESULT IN SERIOUS PERSONAL
INJURY OR POSSIBLE DEATH.
PXCBLHTC-018

MAINTENANCE
DESCRIPTION OF SYMBOLS
CARING FOR THE ENVIRONMENT
TROUBLESHOOTING
Power tools that are no longer usable should not be disposed of
with household waste but in an environmentally friendly way. Please
recycle where facilities exist. Check with your local council authority
for recycling advice.
Recycling packaging reduces the need for landll and raw materials.
Reuse of recycled material decreases pollution in the environment.
Please recycle packaging where facilities exist. Check with your local
council authority for recycling advice.
THIS MANUAL CONTAINS IMPORTANT SAFETY AND OPERATING INSTRUCTIONS FOR YOUR
BATTERY CHARGER.
1. Before using the charger read all instructions and cautionary markings on the charger, battery pack and the product using the
battery pack.
2. This charger is not intended for any uses other than charging rechargeable batteries. Any other use may result in risk of re,
electric shock or electrocution.
3. Do not place any object on top of the charger or place the charger on a soft surface that may result in excessive internal heat.
Place the charger in a position away from any heat source.
4. To reduce risk of damage to the electric plug and cord, pull by the plug rather than the cord when disconnecting the charger.
5. Make sure the cord is located so that it will not be stepped on, tripped over, or otherwise subjected to damage or stress.
6. An extension cord should not be used unless absolutely necessary. Use of an improper extension cord could result in the risk of re,
electric shock or electrocution.
7. Do not operate the charger if it has received a sharp blow, been dropped or otherwise damaged in any way. Have it checked by an
electrician or power tool repairer.
8. Do not disassemble charger. Take it to an electrician or power tool repairer when service or repair is required. Incorrect reas-
sembly may result in a risk of electric shock, electrocution or re.
9. To reduce risk of electric shock, unplug the charger from the outlet before attempting any cleaning. Removing the battery pack
will not reduce this risk.
10. Never attempt to connect 2 chargers together.
11. DO NOT store or use the tool and battery pack in locations where the temperature may reach or exceed 40ºC (such as inside sheds or
metal buildings in summer).
12. The charger is designed to operate on standard household electrical power (240 volts). Do not attempt to use it on any other
voltage!
13. The battery pack is not fully charged out of the carton. First read the safety instructions and then follow the charging notes and
procedures.
14. The longest life and best performance can be obtained if the battery pack is charged when the air temperature is between 18 -
24ºC. Do not charge the battery pack in an air temperature below 10ºC or above 40ºC. This is important and will prevent damage
to the battery pack.
15. Do not incinerate the battery pack even if it is seriously damaged or is completely worn out. The battery can explode in a re.
16. Never attempt to open the battery pack for any reason. If the plastic housing of the battery pack breaks or cracks, immediately
discontinue use and do not recharge.
17. During charging, the battery must be placed in a well ventilated area.
BATTERY AND CHARGER SAFETY WARNINGS
Cleaning and Storage
• Keepairintakecleanandairventsfreeofdebristoavoidoverheatingthemotor.
• Donotusecleaningagentstocleantheplasticpartsofthetool.
A mild detergent on a damp cloth is recommended. Water must never come into contact with
the tool.
• Ifthetrimmervibratesabnormally,stopmotorimmediately.Abnormalvibrationusuallyindicates
a mechanical problem continued operation could lead to injury or damage.
• Alwaysplacethebladecoveronthebladebeforestoringortransportingthehedgetrimmer.Use
caution to avoid the sharp teeth of the blade.
• Storethehedgetrimmerindoors,inadryplacethatisinaccessibletochildren.
WARNING! ALWAYS ENSURE THE TOOL HAS
COMPLETELY STOPPED AND THE BATTERY IS
REMOVED PRIOR TO ANY MAINTENANCE.
Problem Cause Remedy
Trimmer is not
starting
Possible clogging Clean the trimmer blade of any
leaves or debris.
Battery is low in charge Charge battery
Battery not inserted properly Insert battery pack correctly
Trimmer is not
operating at full
capacity
Possible clogging Clean the trimmer blade of any
leaves or debris.
Motor stops while
trimming
Battery has no power Charge battery
Note: Ozito Industries will not be responsible for any damage or injuries caused by the repair of the
trimmer by an unauthorised person or by mishandling of the trimmer. This tool is designed for DIY use
- use in commercial or industrial environments will void the warranty.
Read instruction manual
Do not trim in the rain or leave the hedge trimmer outdoors
while raining.
Wear eye protection
Wear ear protection
Regulator compliance mark
Sharpening the cutting blade
1. Start and stop your hedge
trimmer until the cutter blade
and the guard are slightly
offset.
2. Remove the battery pack from
your hedge trimmer.
3. Clamp the blade assembly in a vise and le the exposed cutting surface of each
blade tooth. Remove as
little material as possible.
4. Remove the hedge trimmer from
the vise and insert the battery pack. Repeat
steps 1-3 for the unsharpened edges of the
blade teeth.
Note: Do not operate your hedge trimmer with
dull or damaged cutting blades. This may cause
overload and will give unsatisfactory cutting
results.
Lubricating the blade
For best operation and longer blade life, lubricate the hedge trimmer blade with light
weight machine oil before and after each use.
1. Remove the battery pack from the hedge
trimmer.
2. Lay the hedge trimmer on a at surface. Apply
a light weight machine oil along the edge of
the top blade.
WARNING! DO NOT OIL WHILE THE HEDGE TRIMMER
IS RUNNING.

• Keep all parts of the body away from the cutter blade. Do not remove cut
material or hold material to be cut when blades are moving. Make sure the switch is off when
clearing jammed material. A moment of inattention while operating the hedge trimmer may result
in serious personal injury.
• Carry the hedge trimmer by the handle with the cutter blade
stopped. When transporting or storing the hedge trimmer always t the cutting device cover.
Proper handling of the hedge trimmer will reduce possible personal injury from the cutter blades.
• Hold the power tool by insulated gripping surfaces only, because the
cutter blade may contact hidden wiring. Cutter blades contacting a “live” wire may
make exposed metal parts of the power tool “live” and could give the operator an electric shock.
• Perform visual inspection on the hedge being trimmed. To ensure no wire
fences or foreign objects that the hedge trimmer may contact during operation.
• Never allow children or people unfamiliar with these instructions to use the Hedge Trimmer.
• Avoid using the Hedge Trimmer, while people, especially children or pets, are nearby.
• Use the Hedge Trimmer only in daylight or good articial light.
• Never operate the Hedge Trimmer with damaged guards or without guards in place.
• Switch on the Hedge Trimmer only when the hands and feet are away from the cutting blades.
• Use only the manufacturer’s recommended replacement parts and accessories.
• Always remove the battery from the Hedge Trimmer when leaving the Hedge Trimmer unattended.
• Always remove the battery from the Hedge Trimmer before carrying out maintenance or cleaning
work.
• Inspect and maintain the Hedge Trimmer regularly. Have the Hedge Trimmer repaired only by an
authorized repairer.
• When not in use, store the Hedge Trimmer out of the reach of children.
• Face the cutting blades away from yourself, other people and animals while the power is connected
to the Hedge Trimmer (especially during operation).
• Use both handles.
• Keep ventilation openings clear of debris. Keep handles dry, clean and free of oil and grease.
• Never reach underneath the Hedge Trimmer (the cutting blade area) until it has completely stopped
and the power has been disconnected.
WARNING! When servicing, use only identical replacement parts. Use of any other parts
may create a hazard or cause product damage. To ensure safety and reliability, all repairs
should be performed by a qualied service technician.
WARNING! This appliance is not intended for use by young or inrm persons unless
supervised by a responsible person to ensure that they can use the appliance safely. Young
children should be supervised to ensure that they do not play with the appliance.
Spare parts can be ordered from the Special Orders
Desk at your local Bunnings Warehouse.
For further information, or any parts not listed here,
visit www.ozito.com.au or contact Ozito Customer
Service:
Australia 1800 069 486
New Zealand 0508 069 486
E-mail: [email protected]
SPARE PARTS
WARNING! When using mains-powered tools, basic safety precautions, including
the following, should always be followed to reduce risk of fire, electric shock, personal
injury and material damage.
Read the whole manual carefully and make sure you know how to switch the tool off in an emergency, before operating the tool.
Save these instructions and other documents supplied with this tool for future reference.
The charger has been designed for 230V and 240V only. Always check that the power supply corresponds to the voltage on the rating
plate.
Note: The supply of 230V and 240V on Ozito tools are interchangeable for Australia and New Zealand.
This tools charger is double insulated therefore no earth wire is required.
If the supply cord is damaged, it must be replaced by an electrician or a power tool repairer in order to avoid a hazard.
Note: Double insulation does not take the place of normal safety precautions when operating this tool. The insulation system is for
added protection against injury resulting from a possible electrical insulation failure within the tool.
The power supply for this products charger should be protected by a residual current device (rated at 30mA
or less). A residual current device reduces the risk of electric shock.
GENERAL POWER TOOL SAFETY WARNINGS
ELECTRICAL SAFETY
WARNING! Read all safety warnings and all instructions. Failure to follow the warnings and
instructions may result in electric shock, re and/or serious injury.
Save all warnings and instructions for future reference. The term “power tool” in the
warnings refers to your mains-operated (corded) power tool or battery-operated (cordless)
power tool.
1. Work area safety
a. Keep work area clean and well lit. Cluttered or dark areas invite accidents.
b. Do not operate power tools in explosive atmospheres, such as in the presence of
flammable liquids, gases or dust. Power tools create sparks which may ignite the dust or fumes.
c. Keep children and bystanders away while operating a power tool. Distractions can cause you to lose
control.
2. Electrical safety
a. Power tool plugs must match the outlet. Never modify the plug in any way. Do not use
any adapter plugs with earthed (grounded) power tools. Unmodied plugs and matching outlets will
reduce risk of electric shock.
b. Avoid body contact with earthed or grounded surfaces, such as pipes, radiators, ranges
and refrigerators. There is an increased risk of electric shock if your body is earthed or grounded.
c. Do not expose power tools to rain or wet conditions. Water entering a power tool will increase the risk
of electric shock.
d. Do not abuse the cord. Never use the cord for carrying, pulling or unplugging the power
tool. Keep cord away from heat, oil, sharp edges or moving parts. Damaged or entangled cords
increase the risk of electric shock.
e. When operating a power tool outdoors, use an extension cord suitable for outdoor use.
Use of a cord suitable for outdoor use reduces the risk of electric shock.
f. If operating a power tool in a damp location is unavoidable, use a residual current device
(RCD) protected supply. Use of an RCD reduces the risk of electric shock.
3. Personal safety
a. Stay alert, watch what you are doing and use common sense when operating a power
tool. Do not use a power tool while you are tired or under the influence of drugs, alcohol
or medication. A moment of inattention while operating power tools may result in serious personal injury.
b. Use personal protective equipment. Always wear eye protection. Protective equipment such as dust
mask, non-skid safety shoes, hard hat, or hearing protection used for appropriate conditions will reduce personal injuries.
c. Prevent unintentional starting. Ensure the switch is in the off-position before connecting
to power source and/or battery pack, picking up or carrying the tool. Carrying power tools with
your nger on the switch or energising power tools that have the switch on invites accidents.
d. Remove any adjusting key or wrench before turning the power tool on. A wrench or a key left
attached to a rotating part of the power tool may result in personal injury.
e. Do not overreach. Keep proper footing and balance at all times. This enables better control of the
power tool in unexpected situations.
f. Dress properly. Do not wear loose clothing or jewellery. Keep your hair, clothing and
gloves away from moving parts. Loose clothes, jewellery or long hair can be caught in moving parts.
g. If devices are provided for the connection of dust extraction and collection facilities,
ensure these are connected and properly used. Use of dust collection can reduce dust-related hazards.
4. Power tool use and care
a. Do not force the power tool. Use the correct power tool for your application. The correct
power tool will do the job better and safer at the rate for which it was designed.
b. Do not use the power tool if the switch does not turn it on and off. Any power tool that cannot be
controlled with the switch is dangerous and must be repaired.
c. Disconnect the plug from the power source and/or the battery pack from the power
tool before making any adjustments, changing accessories, or storing power tools. Such
preventive safety measures reduce the risk of starting the power tool accidentally.
d. Store idle power tools out of the reach of children and do not allow persons unfamiliar
with the power tool or these instructions to operate the power tool. Power tools are dangerous in
the hands of untrained users.
e. Maintain power tools. Check for misalignment or binding of moving parts, breakage of
parts and any other condition that may affect the power tool’s operation. If damaged,
have the power tool repaired before use. Many accidents are caused by poorly maintained power tools.
f. Keep cutting tools sharp and clean. Properly maintained cutting tools with sharp cutting edges are less likely to
bind and are easier to control.
g. Use the power tool, accessories and tool bits etc. in accordance with these instructions,
taking into account the working conditions and the work to be performed. Use of the power
tool for operations different from those intended could result in a hazardous situation.
5. Battery tool use and care
a. Recharge only with the charger specified by the manufacturer. A charger that is suitable for one
type of battery pack may create a risk of re when used with another battery pack.
b. Use power tools only with specifically designated battery packs. Use of any other battery packs may
create a risk of injury and re.
c. When battery pack is not in use, keep it away from other metal objects, like paper clips,
coins, keys, nails, screws or other small metal objects, that can make a connection from
one terminal to another. Shorting the battery terminals together may cause burns or a re.
d. Under abusive conditions, liquid may be ejected from the battery; avoid contact. If
contact accidentally occurs, flush with water. If liquid contacts eyes, additionally seek
medical help. Liquid ejected from the battery may cause irritation or burns.
6. Service
a. Have your power tool serviced by a qualified repair person using only identical
replacement parts. This will ensure that the safety of the power tool is maintained.
HEDGE TRIMMER SAFETY WARNINGS
