Hesstar HCF-PD11 User manual

CHEST FREEZER
HCF-PD11
HCF-PD16

2
Dear customers,
Thank you for purchasing our product. In order to ensure your safety and achieve the best results, please read
this instruction manual carefully.
Before you start:
Read all the instructions before using. Keep this manual for future reference.
Warning: Never try to use this appliance for applications or in a way which is not described in the
instruction, otherwise severe hazards may occur.
Do not use the appliance in a dusty environment or in an explosive atmosphere (inflammable gases,
vapors, vapors from organic solvents).
This appliance is intended for HOUSEHOLD USE ONLY and not for commercial or industrial use.
General safety advice
Keep the appliance out of reach for children! Do not allow children to play with the appliance
Unplug the appliance from outlets when not in use, before adding or removing parts, or before cleaning.
Make sure to place the plug all the way into the socket when connecting your appliance.
Insert the plug into a single grounded socket.
Never use the appliance in a place where combustible and inflammable materials are kept.
For safety reasons, be sure to repair or replace parts at an authorized service dealer.
If the power supply cord is damaged, it must be replaced by the manufacturer, its service agent or
similarly qualified persons in order to avoid a hazard.
The motor is permanently lubricated and will require no oil.
 The appliance must be positioned so that the plug is accessible.
I. Introduction to the Product
1.It uses a quality, effective and hermetic compressor with a broad range or starting voltage, suitable
ambient temperature not higher than 38°C, reasonable matching of the refrigerator system guarantees
its powerful refrigerant ability and energy saving.
2.The thermal insulating layer of the refrigerator is made from hard polyurethane foamed plastic, which
makes it light-weighted and it has a good ability of cold prevention
3.Other features including Cornering and lockable door, fast freezing, ultra thick heat preservation layer
with better heat preservation effect and copper pipe evaporator.
4.It uses a steel wire-shaped condenser but not that of a slide-shaped with electric fan so as to reduce
the noise.
5.The lowest freezing temperature is at <= -18ºC.

3
II. Caution Of Safety
1. An individual single-phased socket must be used. It should be reliably connected to a grounding
wire.
Caution: Do not connect grounding wire to a water or gas pipe.
2. Strictly no storing strong base, strong acid, organic solvent and corrosive goods together with food.
3. Do not pour water directly onto the freezer, which may cause a declining of the insulation and
corrosiveness.
4. When the refrigerator will not be used for a long time, disconnect the power cord then clean it.
Please examine the wiring circuit before using it.
5. Please refer to the Trouble Shooting references when the unit is facing some problems. Do not
attempt to solve the problem on your own, please refer to certified technician only.
III. Caution for using.
1. Unpack all packages before using the refrigerator. Do not topple it over more than 60º while moving
it. Even though it can be moved slowly with the universal wheels under its base, the wheels were not
meant for uneven ground usage which may damage it and other parts if used vigorously.
2. Place the freezer at your desired place and do not operate it for at least
1 hour. The refrigerator should be installed in an environment with good ventilation, cool and dry.
Avoid placing it nearby heat generating equipment and under direct sunlight. When installing, the
universal wheels should be padded firmly so as to avoid excess vibration and noise.
3. After 1 hour the freezer should be run empty upon initial operation. Please turn the thermostat knob
to 7 and food can be stored after just 4 hours of initial running. Food must occupy 1/3 of the storage
area and be evenly arranged. They must be wrapped in plastic bags to obtain the original freshness
and taste.
4. Temperature can be adjusted by using the thermostat. Clock wise turning will decrease the
temperature whilst anti-clockwise to increase. Figures shown indicate the temperature level: 3-5 for
normal, 0 for stop running and 7 for continuously running.
Caution: No.7 can only be used if the foods need to be frozen quickly.
5. Do not frequently open and shut the refrigerator door to avoid lost of cooling effect and to save
energy.
6. The surface and inside of the freezer should be kept clean at all times to avoid body rust.
7. Generally, clean the freezer after every 30-45 days of usage. Please use a soft cloth moistened in
neutral soapsuds or detergent.
Caution: Please unplug the power cord before cleaning the unit.

4
IV. Ordinary troubles and remedies.
Please refer to the trouble shooting lists on next page to overcome any minor problems that occur
during operations.
Phenomenon/ Problem Cause Insp.Content Remedy Remark
Red light not functioning No Electricity Fuse Broken Check fuse Replace fuse
Loose plug and
socket
Check for loose
contact
Replace or service
socket
With Electricity Loose red bulb Check for loose
contact
Tighten the bulb
Broken red bulb Remove red bulb Replace red bulb
Green light not functioning Compressor working
well
Loose green bulb Check for loose
contact
Tighten the bulb
Broken green bulb Remove green
bulb
Replace the bulb
Loose thermostat Check thermostat Tighten the
thermostat
Compressor not
working
Loose thermostat Check for loose
contact
Tighten the
thermostat
Thermostat damage Check for short
circuit
Replace thermostat
Non-stop running of machine Does not refrigerate
well
Thick frost on surface Check thickness
<=5mm
Defrost time
Door open frequently Avoid open
Too much food stored Lessen the quantity.
Refrigerate well R134a/R12
Leaked
Set temp.<ambient
temp
Check temp level
“5-6”
Adjust level to “2-4”
Thermostat not
working
Replace thermostat
Too noisy Refrigerator installed on uneven ground Check universal
wheels
Put on a level and
even ground
Loose screws in condenser or compressor Check for loose
screws.
Tighten the loose
screws
Compressor not working but red
and green light working.
Loose of starting relay or heat preventing socket Check damaged
contact
Tighten the
connection
Compressor damaged Repair/Service
Compressor
Voltage less than 187V Check the voltage
level
Use a power
regulator

5
WARNING:
Do not use mechanical devices or other means to accelerate the defrosting process, other than those
recommended by the manufacturer.
Except for the items recommended by manufacturer, do not use any electric appliance in the units.
This apparatus is not intended to be used by those with physical, Sensory or mentally defects, or by those with
a lack of experience and common sense (including children), unless they are with adults responsible for their
safety and who care enough to give guidance on how to use this apparatus
If the supply cord is damaged, it must be replaced by the manufacturer or its service agent or a similarly
qualified person in order to avoid a hazard.
Keep ventilation opening, in the appliance enclosure or in the built-in structure, clear of obstruction.
Do not damage the refrigerant circuit.
Do not use electrical appliances inside the food storage compartments of the appliance, unless they are of the
type recommended by the manufacturer.
