The content of this document is part of P7C User Manual (PMU1070011). The Notes and
Acronyms full list is at the complete version of the manual. To get it, please, access:
www.hitecnologia.com.br

User Manual - P7C Controller
Ref.: PMU107001 Version: 1.0.07 31
Technical Specications
Release: 10/20/10
Presentation
P7C
1
programmable controllers line was developed for attending machine and process control ap-
plications. This PLC
1
has up to 368 I/O
1
points at its full conguration and offers all the others HI con-
trollers versatility, including also new and exclusive features. Its design is based on expansible racks,
supporting up to 4 hardware modules per rack. The basic conguration is composed by a main rack
with power supply and capacity up to 4 modules. On the other hand, the Full conguration can be
composed by 1 main rack + 5 expansion racks, providing 24 slots
1
for use. The racks interconnection
must be done always on the right side of the rack, using the connector
1
placed at the backplane
1
.
Technical Specications
04
1 - Check the Notes and Acronysms List at the beggining of this document
Note: The modules can have lever connectors (for the new mod-
ules) or screw connectors.

User Manual - P7C Controller
Ref.: PMU107001 Version: 1.0.07 32 Release: 10/20/10
Technical Specications
Applicable Standards
P7C
1
controller was developed for attending CE certication requirements, being adherent to the
standards dened by IEC61131-2. According to the criterion dened by IEC61131-2, the equipment
is able to operate on the named “Zone B”, attending to the specication of the following standards:
Standards Name
CISPR11, CISPR16-1 Irradiated interference
CISPR11, CISPR16-1 and CISPR16-2 Conducted interference
IEC61000-4-2 Electromagnetic discharge immunity
IEC61000-4-3 Irradiated eletromagnetic elds immunity
IEC61000-4-4 Fast transients immunity
IEC61000-4-5 Immunity against high energy outbreaks
IEC61000-4-6 Immunity against conducted radiofrequency
IEC61000-4-8 Immunity against electromagnetic elds
Technical Data – Main Rack AC (300.107.200.000)
Power Supply AC (PWS800) 85 to 265 VAC or 100 to 400 VDC automatic
Consumption 25 Watts máx
Operating temperature 0 to 60 Cº
Storage temperature -25 Cº to 80 Cº
Humidity ≤90% without condensation
Rack weight 1,0 Kg approximately
Box Aluminium and Carbon Steel
Protection Degree IP30
Dimensions 150 (W) x 110 (H) x 115 (L) mm
Technical Data – Main Rack DC (300.107.200.010)
Power Supply DC (DCC850) 10 to 36 VDC automatic
Consumption 30 Watts máx
Operating temperature 0 to 60 Cº
Storage temperature -25 Cº to 80 Cº
Humidity ≤90% without condensation
Rack weight 1,0 Kg approximately
Box Aluminium and Carbon Steel
Protection Degree IP30
Dimensions 150 (L) x 110 (A) x 115 (P) mm
Technical Data – Expansion Rack (300.107.200.100)
Power Supply Supplied by main rack
Consumption -
Operating temperature 0 to 60 Cº
Storage temperature -25 °C to 80 °C
1 - Check the Notes and Acronysms List at the beggining of this document

User Manual - P7C Controller
Ref.: PMU107001 Version: 1.0.07 33
Technical Specications
Release: 10/20/10
Humidity ≤90% without condensation
Rack weight 0,5 Kg
Box Aluminium and Carbon Steel
Protection Degree IP30
Dimensions 110 (W) x 110 (H) x 115 (P) mm
Maximum number 5 expansion racks
Racks connection
The expansion racks must be connected to the right side of the main rack. In the case of adding
one expansion rack, it is necessary to remove the screw place at the main rack side (Picture A), and
loosen the two screws placed on the rack back side, in order to t the (red) locks, as shown on the
picture (Picture B) and there the connection will be made. For that, approach both racks, in order
to t the locks and connectors
1
together. Push both screws (M3x4) to x the two locks as Picture C
shows.
IMPORTANT: Note the perfect racks connection: they must be aligned after the correct con-
nection. The incorrect connection may result in bad performance or damages to the product.
Picture A: Screw Picture B: Locks / Screws
Picture C: Connection
1 - Check the Notes and Acronysms List at the beggining of this document

User Manual - P7C Controller
Ref.: PMU107001 Version: 1.0.07 34 Release: 10/20/10
Technical Specications
Supply
The power supply connector
1
is a spring connector
1
that does not need a screw to be tightened. To
insert the wire in the terminal block
1
, use a screw-driver at the smaller hole (as indicated by A, at the
following picture). Push the screw-driver until open the spring (as indicated by letter B at the following
picture) and, after, insert the wire in the corresponding terminal block
1
. After this procedure, remove
the screw-driver and make sure the connection was completed correctly. To remove the wire is pos-
sible to execute the same procedure indicated by letters A and B of the following picture.
ATTENTION: Electric-shock danger: the bad utilisation may result in re or death. Read and
follow the instructions indicated at this manual:
Make sure that the cables which will be connected to the power supply are disenergized be-
fore any operation;
Inspect the cable before each utilisation. Do not use if the cable is damaged.
Insert the cable completely into the terminal block
1
;
Do not use excessive force to make the connections;
Keep the equipment away from water. Do not use it if wet;
Avoid the overheating. Unwind the cable and do not cover it with any material;
Do not superimpose, drag or put objects above the cable;
AC Rack (PWS800)
Terminal Con-
nector1
Signal
1 AC
2 AC
3 Ground
DC Rack (DCC850)
T e r m i n a l
Connector1
Signal
1 -
2 +
3 Ground
1 - Check the Notes and Acronysms List at the beggining of this document

User Manual - P7C Controller
Ref.: PMU107001 Version: 1.0.07 35
Technical Specications
Release: 10/20/10
IMPORTANT: The main Rack MRK AC power supply can be from 85 to 265 VAC or 100 to 400
VDC. The main Rack MRK DC power supply can be from 10 to 36VDC. We recommend the use
of a rigid or exible 2,5mm2 wire (7mm stripped) or exible 1,5mm2 wire with eyelets terminal.
Earth-Protection Connector
OR
IMPORTANT: Use connector
1
Faston 6.3 totally isolated for 1mm2 green and yellow cable.
This connection with the rack can be made at the bottom side, on the top side or both ways.
Addressing
Racks addresing
The expansion racks are coupled on the main rack right side, being possible to couple up to ve
expansions. Each rack has a three straps
1
set named J1, J2, J3. This set, placed at the backplanes
1
,
(between the connectors
1
of the third and fourth slots
1
) must be congured according to the position
of the rack, using jumpers
1
, as the following:
Identication J1 J2 J3
Main Rack OFF OFF OFF
Expansion Rack 01 ON OFF OFF
Expansion Rack 02 OFF ON OFF
Expansion Rack 03 ON ON OFF
Expansion Rack 04 OFF OFF ON
Expansion Rack 05 ON OFF ON
Caption:
ON: with jumper1
OFF: without jumper1
Caption:
1 - Check the Notes and Acronysms List at the beggining of this document
Note: The modules can have lever connectors (for the new modules) or screw connectors.

User Manual - P7C Controller
Ref.: PMU107001 Version: 1.0.07 36 Release: 10/20/10
Technical Specications
Termination Module – BBT260
The termination module must be, obligatorily, connected to the last expansion rack or, if it does not
exist, then it must be connected to the main rack.
IMPORTANT:
The equipment does not work without the termination module;
The module can not be connected and/or disconnected with the equipment turned on. Make
sure the equipment is turned off before any opperation;
Fixing the Rack on trails
To x the rack on the trail is necessary to t the rack lower part (as indicated by number 1, at the
picture), pushing from the bottom to the top. To put the rack in the trail just t the lower part of the
rack (as indicated by number 1 at the picture), pushing to the top and at the direction of the trail (as
indicated by number 2 at the picture):
1 - Check the Notes and Acronysms List at the beggining of this document
Note: The modules can have lever connectors (for the new modules) or screw connectors.

User Manual - P7C Controller
Ref.: PMU107001 Version: 1.0.07 37
Technical Specications
Release: 10/20/10
Removing the rack from trails
To remove the rack from the trail, just push it to the top (as indicated by number 1, at the picture) and
also move it to the front (as indicated by number 2, at the picture):
Dimensions (mm)
Main Rack
Expansion Rack
Part Number
Code Identication
300.107.200.000 P7C
1
MRK AC main rack
300.107.200.010 P7C
1
MRK DC main rack
300.107.200.100 P7C
1
XRK expansion rack
1 - Check the Notes and Acronysms List at the beggining of this document
Note: The modules can have lever connectors (for the new modules) or screw connectors.
