HIGHLEAD GC20688-BDCE Series Instruction Manual

Parts Catalog
SHANGHAI BIAOZHUN HAILING SEWING MACHINERY CO., LTD.
GC20688-BDCE Serie
Compound-Feed,Heavy Material
Lockstitch Sewing Machine
Instruction Manual
From the library of: Superior Sewing Machine & Supply LLC

----- CONTENTS -----
1. PRECAUTIONS BEFORE STARTING OPERATION···············································································1
1) Safety precautions····································································································································1
2) Precaution before Starting Operation····································································································1
3) Precaution for Operating Conditions·····································································································1
2. SPECIFICATIONS ·········································································································································1
3. PREPARATION BEFORE STARTING TO OPERATE·············································································2
1) Connection of control box ·······················································································································2
2) Oil pan·······················································································································································3
3) Operation panel········································································································································3
4) Adjusting the needle stop position··········································································································3
5) Lubrication···············································································································································4
4. HOW TO USE THE MACHINE ···················································································································5
1) Threading··················································································································································5
2) Adjusting of the thread regulator···········································································································5
3) Adjusting of upper thread tension········································································································ 5
4) Winding the lower thread························································································································5
5) Threading the lower thread·····················································································································6
6) Adjusting the lower-thread tension········································································································6
7) Installing the needle·································································································································6
8) Alternating presser foot movement amount··························································································7
9) Adjusting the presser foot pressure······································································································ 7
10) Adjusting the stitch length ······················································································································7
11) Using the manual switches ······················································································································7
12) Cleaning····················································································································································7
13) Lubrication···············································································································································8
14) Adjusting the trailing length after thread trimming·············································································9
15) Back tacking·············································································································································9
16) Adjusting the feed dog·····························································································································9
17) Adjusting the needle bar height············································································································10
18) Adjusting the gap between the needle and the rotary hook tip··························································10
19) Adjusting of the needle and the hook timing·······················································································10
20) Hook protection······································································································································11
21) Adjusting the needle and feed mechanism timing···············································································11
22) Adjusting the opener position···············································································································12
23) Adjusting the presser foot height··········································································································12
24) Adjusting the alternating presser foot movement amount·································································13
From the library of: Superior Sewing Machine & Supply LLC

25) Adjusting the presser foot timing ·········································································································14
26) Adjusting the fixed knife position·········································································································15
27) Adjusting the thread holding spring position······················································································15
28) Adjusting the knife timing position······································································································15
29) Adjusting the driving knife height········································································································15
30) Adjusting the driving knife stop position·····························································································16
31) Adjusting the driving knife operating position ···················································································16
32) Adjusting the thread trimming timing·································································································17
33) Safety clutch ···········································································································································17
34) Regulate the atmospheric pressure······························································································18
5. HOW TO USE THE VERTICAL CUTTER·······························································································18
1) Idle of the knife when the vertical cutter is turned off···························································19
2) Timing of the deactivation of the knife ·····················································································19
3) Position of the release block········································································································· 19
4) Lubrication of the eccentric ·········································································································19
5) Stroke of the knife ···························································································································19
6) Timing of knife movement ············································································································20
7) Knife overlap ····································································································································20
8) Setting and pressure of the knife blades ···················································································20
----- PARTS LIST -----
A. ARM BED AND ITS ACCESSORIES···········································································································21
B. THREAD TENSION REGULATOR MECHANISM ··················································································25
C. SEWING MECHANISM································································································································28
D. PRESSER FOOT MECHANISM··················································································································31
E. UPPER FEED LIFTING ROCK SHAFT MECHANISM···········································································34
F. STITCH REGULATOR MECHANISM········································································································37
G. FEEDINGAND FEED LIFTING & ROTATING HOOK SHAFT MECHANISM··································40
H. HOOK SADDLE MECHANISM ··················································································································43
I. OIL LUBRICATION MECHANISM ···········································································································47
J. ACCESSORIES················································································································································50
K. PNEUMATIC CONTROL UNIT···················································································································52
L. KNIFR MECHANISM····································································································································54
From the library of: Superior Sewing Machine & Supply LLC

—1 —
1. PRECAUTIONS BEFORE STARTING OPERATION
1) Safety precautions
(1) When turning the power on, keep your hands and fingers away from the area around/under the needle
and the area around the pulley.
(2) Power must be turned off when the machine is not used, or when the operator leaves his/her seat.
(3) The power must be turned off before tilting the machine head, installing or adjusting the machine, or
when replacing.
(4) Avoid placing fingers, hairs, bars etc. nears the pulley, bobbin winder pulley, when the machine is
operation. Injury could result.
(5) Do not insert fingers into the thread take-up cover, under/round the needle, or pulley when the
machine is in operation.
(6) If a mini motor cover, finger guard, and/or eye guard are installed, do not operate the machine
without these safety devices.
2) Precaution before starting operation
(1) If the machine's oil pan has an oil sump, never operate the machine before filling it.
(2) If the machine is lubricated by a drop oiler, never operate the machine before lubricating.
(3) When a new sewing machine is first turned on, verify the rotational direction of the pulley with the
power on. (The pulley should rotate counterclockwise when viewed from the pulley.)
(4) Verify the voltage and (single or three) phase with those given on the machine nameplate.
3) Precaution for Operating Conditions
(1) Avoid using the machine at abnormally high temperature (35℃or higher) or low temperatures (5℃
or lower). Otherwise, machine failure may result.
(2) Avoid using the machine in dusty conditions. Avoid using the machine in areas where too much
electrical noise, resulted from the high-frequency welder and others, is generated
2. SPECIFICATIONS
Item GC20688-DCE GC20688-BDCE
Max. Speed 3000rpm 2800rpm
Stitch length 0 to 6mm 0 to 6mm
Needle bar stroke 34mm 34mm
Presser foot
clearance
By hand 9 mm 9 mm
By knee 16 mm 16 mm
Rotating hook 1.6 times 2.5 times
Needle DP×17 #18-#25 DP×17 #18-#25
Presser foot alternation 1-7mm 1-7mm
Auto presser foot lifter Pneumatic Pneumatic
Oil lubrication method Automatic lubrication Automatic lubrication
Bed dimensions 300×120 mm 300×120 mm
Needle gauge（mm）8
If sewing with stitch length of 6 mm or more, set the sewing speed to 2000 rpm or less.
From the library of: Superior Sewing Machine & Supply LLC

—2 —
3. PREPARATION BEFORE STARTING TO OPERATE
1) Connection of control box
It shows the connection of the
electrical wires of the whole machine
on the right picture.
When the machine needs to be
assembled, each line should be linked
to the right joint according to the
instruction of the picture.
All the pins on the control box
have signals of function showing, and
usually, different wires have different
kinds of joint.
Caution: the pin of synchronizer wire is
the same with another two external pins
and if there is a misconnection, the
synchronizer might be burn.
When connecting the pipes, please check the
joint at the picture of the whole machine above
as reference.
And also there have an instruction mark of
each joint of the solenoid at the setting board.
From the library of: Superior Sewing Machine & Supply LLC

—3 —
2) Oil pan
(1) Install the oil pan 3 to the underside of the
worktable 1 in the place shown in the illustration
using the nails 2.
(2) From front view, the oil pan 3 to the side is
60mm; from right view, the oil pan 3 to the side is
80mm.
3) Operation panel
(1) Install the operation panel 1 to
the set plate 2 with the three screws 3.
(2) Install the set plate 2 to the
back of the machine arm with the two
screws 4.
4) Adjusting the needle stop position
(1) Adjusting the needle up stop position
When the sewing machine stops in the needle up stop position (the stop position of trimming) and the
treadle is pressed back, the red mark on the pulley should be consistent with the mark on the belt cover A.
Adjust as follows:
a. Turn off the power switch.
b. Loosen the screw 4, and then remove the cover 3.
From the library of: Superior Sewing Machine & Supply LLC

—4 —
c. When the red mark stops in a position over the mark on the belt cover, the needle up stop position disc 1
should be turned in the opposite direction as the direction of machine pulley rotation. When the red mark stops
in a position under the mark on the belt cover, Turn the disc 1 in the same direction as the pulley rotation
direction.
(2) Adjusting the needle down stop position
When the sewing machine stops in the needle down stop position, the black mark on the pulley should be
consistent with the mark on the belt cover A. Adjust as follows:
a. Turn off the power switch.
b. When the black mark stops in a position over the mark on the belt cover, the needle down stop position
disc 2 should be turned in the opposite direction as the direction of machine pulley rotation. When the black
mark stops in a position under the mark on the belt cover, Turn the disc 2 in the same direction as the pulley
rotation direction.
c. After adjusting, install the cover 3, with screw 4.
Note: There is no need to loosen the screw 5, when turning the discs.
5) Lubrication
Before the new machine is used, please loosen the screw 2 and
full the oil into the oil case. Set the oil level between “EMPTY” and
“FULL”. Then replace oil-filling screw 2.
From the library of: Superior Sewing Machine & Supply LLC

—5 —
4. HOW TO USE THE MACHINE
1) Threading
Raise the thread take-up lever to its highest position and thread the upper thread in the following order.
2) Adjusting of the thread regulator
The thread regulator 9 (see the right picture) regulates the amount of needle thread necessary for stitch
formation. The setting depends on the following factors: material thickness, yarn characteristics and stitch
length.
The thread regulator is fitted with slots for this purpose. Moving in the “+”direction increases the quantity
of needle thread; Moving in the “-”direction reduces the quantity of needle thread.
3) Adjusting of upper thread tension
Tension should be as low as possible. The crossover point should be in the center of the material. Upper
thread tension can be adjusted by thread tension nut 4 and 5 (see the picture of above). Turn the thread tension
nut clockwise to increase the needle thread tension. Turn the thread tension nut counter-clockwise to decrease
the needle thread tension.
4) Winding the lower thread
(1) Place the bobbin onto the bobbin winder shaft.
(2) Pass the thread for winding thread as shown in the figure, and wind the end of the thread clockwise
around the bobbin several times.
(3) Push the bobbin presser 1 toward the bobbin.
(4) The operation will automatically stop when winding is completed. The amount of thread wound onto the
bobbin should be a maximum of 80% if the bobbin capacity. The amount of thread would be regulated by screw
2.
(5) After the thread has been wound on, remove the bobbin and cut the thread with the thread-trimming
knife 3.
From the library of: Superior Sewing Machine & Supply LLC

—6 —
5) Threading the lower thread
(1) Raise flap 1 and remove the empty bobbin.
(2) Insert bobbin 2 in such a way that when the thread is unwound from it moves in the opposite direction
to the gripper.
(3) Pass the thread through slit 3 and below spring 6, pass the thread through slit 4 and pull about 3 cm
through.
(4) Close flap 1 and pass the thread through the flap’s
guide 5.
6) Adjusting the lower-thread tension
The lower-thread tension should be set in accordance with the type of seam required. Adjust the tension
with screw 7. (See the picture of above)
7) Installing the needle
Note: Before attach needle, be sure to turn off the power.
1) Turn the balance wheel by hand to raise the needle bar to its highest position;
2) Loosen the needle clamping screw；
3) Hold the needles so that the two needles side with the long grooved (faces each other), and insert it as deeply
as it will go into the needle clamping holes( model GC20688-2-D);Hold the needle to its side with the long
groove side(left),then insert the needle as deeply as it will go into the needle clamping hole(model
GC20688-1-D).
4) Tighten the needle clamping screw.
From the library of: Superior Sewing Machine & Supply LLC

—7 —
8) Alternating presser foot movement amount
The alternating movement amount for the inner presser foot and the outer presser foot can be adjusted
within the range of 1-7 mm using the alternating presser foot movement dial 1. Turn the alternating presser foot
movement dial 1 clockwise or counterclockwise to align the mark. (MIN. A, B, C, D, E, F MAX. )
9) Adjusting the presser foot pressure
The presser foot pressure should be set as
weak as possible, but strong enough so that the
material does not slip. If the presser-adjusting
dial 1 is turned clockwise, the presser foot
pressure will become stronger, and if it is turned
counterclockwise, the pressure will become
weaker.
10) Adjusting the stitch length
The feed adjustment dials 2 and 3 can be used to set two different types of stitch length. (See the picture of
above) Use feed adjustment dial 2 to set the big stitch length. Use feed adjustment dial 3 to set the little stitch
length. The sewing machine will switch between the two stitch lengths each time the stitch length change switch
is pressed.
11) Using the manual switches
(1) Quick reverse switch
Back tacking is carried out during sewing only while the switch 1 is being pressed.
(2) Auto back tacking select switch
If the switch 3 is pressed when either start back tacking or
end back tacking has been set to ON at the operation panel,
back tacking is canceled for the first time only. Furthermore,
if the switch 3 is pressed when neither starting nor end back
tacking has been set, back tacking is carried out for the first
time only.
(3) Needle up or down switch
If the switch 4 is pressed, The needle will move up to the
needle up stop position from down stop position or move down to the needle down stop position from up
stop position.
12) Cleaning
(1) The area around the feed dog and the hook should be cleaned every day.
(2) Remove any thread scraps from inside the rotary hook.
(3) Keep the control box clean.
From the library of: Superior Sewing Machine & Supply LLC

—8 —
13) Lubrication
(1) Check the oil level at the sight glass 1 every week. If the oil is not
enough, remove oil-filling screw 2 and pour in oil. Check oil level
at sight glass 2. The oil level must be between “EMPTY” and
“FULL”. Replace oil-filling screw 2. After running for 500 hours
since buying the new sewing machine, the oil must be changed.
Then change the oil every two years.
(2) The oil quantity is pre-set at a
relatively high level in order
to ensure adequate
lubrication during running–in.
This setting should be
checked and corrected after
running-in. (approx. 50
hours). The hook is to have positive lubrication with the least possible amount of oil. Let the sewing
machine run approx.2 minutes. And run in intervals. Hold a piece of paper next to the hook and check if
sufficient oil is spun oil onto the paper. Remove cover plate 2. Loosen screw 3 until the tube 1 no longer
moves. This is the case when the tube is in the center of the drilled hole. Turn screw 3 in until the tube
movement just starts and then a 1/8 turn farther. The hook lubrication is preset. Attach cover plate 2 again.
Setting the hook lubrication with screw 3.
(3) Lubricating wicks and felt (see the picture of above)
a. The wick 1 leading from the oil sump to the oscillating crank 4 must be fixed between the groove 2 in the
arm and the spring 3 of the recirculation wick.
From the library of: Superior Sewing Machine & Supply LLC

—9 —
b. When the oil satchel is changed, the flock side should be faced to connecting plate 10. The oil wick 7 and
8 should be set between the oil satchel 9 and plate 8.
(4) Checking the lubrication oil.
Turn on the power switch. Depress the treadle gently and check that the oil level rises in the oil sight glass.
14)Adjusting the trailing length after thread trimming
Adjust by turning the pre-tensioner 1. If the
tension of the pre-tension is increased, the
lengths of the threads trailing from the needle
tips will be reduced; if the tension is reduced,
the lengths will be increased.
15)Back tacking
When the reverse lever 1 or the quick
reverse switch is pressed during sewing, the feed
direction will be reversed. When it is released,
the feed direction will return to normal.
16)Adjusting the feed dog
Set the feed adjustment dials to the minimum
settings. Then adjust as follows so that the feed
dog 1 is at its highest position (0.5mm above the
top of the needle plate 2) when the needle bar is at
its lowest position.
(1) Turn the machine pulley to set the feed dog 1
is at its highest position.
(2) Loosen the screw 3.
(3)Adjust the feed dog’s height.
(4) Tighten the screw 3.
From the library of: Superior Sewing Machine & Supply LLC

—10 —
17)Adjusting the needle bar height
Set the feed adjustment dials to the minimum settings. Then adjust so that the distance from the setting surface
of the needle plate 2 to the end of the needle bar 1 is 18.5mm
when the needle bar 1 is at its lowest position.
(1) Remove the face plate.
(2) Set the feed adjustment dials to “0”.
(3) Turn the pulley to set the needle bar 1 to its lowest
position.
(4) Loosen the screw 3 and then move the needle bar 1 up or
down to adjust so that the distance from the setting surface of
the needle plate 2 to the end of the needle bar 1 is 18.5 mm.
(5) Tighten the screw 3, install the face plate.
18)Adjusting the gap between the needle and the
rotary hook tip
The gap between the needle and the rotary hook tip 1 is 0.1 mm.
Set the rotary hook tip at the level of the middle of the needle. Then
adjusting the gap as follow:
(1) Loosen the screws 2 and 5 (see the picture of below).
(2) Set the hook base 6 to the fit position.
(3) Rotate the adjusting plate 3, let the hook base 6 depend on the bed plate
4.
(4) Tighten the screws 2 and 5.
19)Adjusting of the needle and the hook timing
(1) Set the stitch length to “0”.
(2) Remove the needle plate.
From the library of: Superior Sewing Machine & Supply LLC

—11 —
(3) Overturn the arm.
(4) Loosen the screw 1
(5) Turn the machine pulley to raise the needle bar
from its low position to the point that the needle rises 2.4
mm.
(6) Turn the rotary hook to align the rotary hook tip
with the center of the needle.
(7) Tighten the screw 1.
20) Hook protection
In looping stroke position the needle must abut on
the hook protection 1 without being displaced.
Move needle in looping stroke position by pulley. In looping
stroke position the hook tip is at the level of the middle of the
needle. Press needle against hook protection 1 manually. The needle
should not touch the hook tip.
21)Adjusting the needle and feed mechanism timing
(1) Horizontal feed direction
Set the feed adjustment dials to the maximum settings. Then
turn the machine pulley until the needle bar is at its lowest position.
Then adjust so that the needle and the feed dog do not move even when the reverse lever is moved up and down
at this time.
a. Remove the bed upper cover 1.
b. Set the feed adjustment dial to the maximum
settings.
c. Loosen the two screws 2.
d. Turn the machine pulley until the needle bar is at its
lowest position.
From the library of: Superior Sewing Machine & Supply LLC

—12 —
e. Turn the lower feed cam 3 gradually until it is at the
position where the needle and the feed dog do not move even when the reverse lever is moved up and
down.
f. Tighten the two screws 2.
(2) Vertical feed direction
Set the feed adjustment dials to the minimum settings. Then adjust as follows so that the feed dog 1 is at its
highest position (0.5mm above the top of the needle plate 2) when the needle bar is at its lowest position.
a. Loosen the two screws 3
b. Turn the machine pulley to set the needle bar to its lowest position.
c. Turn feed cam 4 to align the point 5 of feed cam 4 with the centerline of feed rod 6
d. Tighten the screws 3
22) Adjusting the opener position
Adjust so that the clearance between the needle plate 3
and the stopper 4 of the inner rotary hook 2 is 0.5-0.7
mm when the opener 1 is at its closest position to the
inner rotary hook 2.
(1) Turn the machine pulley to move the opener 1 in
direction “a” (opening direction), and then loosen the
screw 5
(2) Turn the machine pulley to move the opener 1 in
direction “b” (closing direction), and then loosen the
screw 6.
(3) Turn the machine pulley to move the opener 1 as
close to the inner rotary hook 2 as possible.
(4) While pressing the opener 1 against the inner
rotary hook 2 with your finger, adjust so that the
clearance between the needle plate 3 and the stopper 4 of
the inner rotary hook 2 is 0.5-0.7 mm.
(5) Tighten the screw 6.
(6) Turn the machine pulley to move the opener 1 in direction “a” (opening direction), and then tighten the
screw 5.
23)Adjusting the presser foot height
The standard height of the outer presser foot 7 is 9 mm when it is raised by the presser lifter bar 1.
(1) Remove the belt cover.
From the library of: Superior Sewing Machine & Supply LLC

—13 —
(2) Loosen the presser adjusting screw, to release the presser foot pressure.
(3) Raise the presser lifters bar 1 and then loosen the screw 2.
(4) Move the outer presser bar up or down to adjust so that the height of the outer presser foot 7 is 9 mm.
(5) While the stopper pin 6 is touching against the notch B in the presser foot lifter connection 5 and while
pushing the presser lifter shaft so that there is no play in the thrust direction, tighten the screw 2.
(6) Turn the presser adjusting screw to adjust the presser foot pressure.
(7) Install the belt guards.
24)Adjusting the alternating presser foot
movement amount
(1) Maximum alternating presser foot movement
amount. Carry out the following adjustment to set the
maximum alternating movement amounts for the inner
presser foot 1 and outer presser foot 2 to the maximum
of 7 mm.
a. Remove the upper plate.
b. Remove the adjusting bracket 3.
c. Loosen screw 5 of adjusting bracket collar 4.
d. Adjust the adjusting bracket collar 4. If the
adjusting bracket collar 4 is be installed at the highest
position, the alternating presser foot movement amount
is 1-6mm. If it is at the lowest position, the alternating
presser foot movement amount is 1.6-7mm.
e. Tighten the screw 5.
f. Install the adjusting bracket 3.
g. Loosen the bolt 6 and turn connecting lever 7 to
From the library of: Superior Sewing Machine & Supply LLC

—14 —
adjust so that the distance from the outer edge of the arm to the outer edge of the pin 7 is 78 mm at this time.
Then tighten the bolt 6. (When installing the upper plate, set the alternating presser foot movements dial to the
“min.” position.)
(2) Inner presser foot 1 and outer presser foot 2
movement amounts. Carry out the following adjustment to
make the movement amounts for the inner presser foot 1
and outer presser foot 2 equal when the presser feet are
lowered and the machine pulley is turned.
a. Set the feed adjustment dials to the maximum
settings.
b. Open the cover 4
c. Turn the alternating presser foot movement dial to the “B” position.
d. Loosen the screw 3
e. Turn the machine pulley toward you to align the tip of the
needle and the top of the feed dog with the top of the needle plate.
f. Move the connecting lever to adjust so that both the inner
presser foot 2 and outer presser foot 1 are in contact with the top
of the needle plate at this time. Then tighten the screw 3.
25)Adjusting the presser foot timing
When the presser feet are lowered and the
machine pulley is turned toward you. The
inner presser foot should touch the feed dog
before the needle arrives at the feed dog.
Then when the needle lifts up, the tip of the
needle should move away from the feed dog
before the inner presser foot moves away.
(1) Remove the upper cover 4.
From the library of: Superior Sewing Machine & Supply LLC

—15 —
(2) Loosen the two screws 1.
(3) Turn the machine pulley until the needle tip and the feed dog’s up face is the same plane.
(4) Turn inner presser cam to adjust so that the point of inner presser cam is facing straight up.
(5) Tighten the screws 2.
(6) When installing the upper plate, set the
alternating presser foot movement dial to the “MIN.”
position.
26)Adjusting the fixed knife position
The distance from the groove of slide plate to
the fixed knife 1 should be 26 mm. Furthermore, the
distance from the edge of the needle plate to the left
edge of the tip of the fixed knife 1 should be 4 mm.
(1) Loosen the two bolts 2.
(2) Adjust the position of the fixed knife 1, and then
tighten the bolts 2.
27)Adjusting the thread holding spring
position (see the picture of above)
The thread holding spring 1 holds the lower thread
after thread trimming to prepare it for the next sewing
operation. The clearance between the thread holding
spring 1 and the side of the fixed knife 2 should be
1.4-1.6 mm.
(1) Loosen the two screws 3.
(2) Move the thread holding spring 1 to adjust its
position, and then tighten the screws 3.
28)Adjusting the knife timing position
After adjusting the position of the fixed knife 1,
adjust the knife timing position.
Adjust so that the driving knife 1 starts touching the fixed knife at a position 5.5 mm
along the front edge of the driving knife 1.
(1) Loosen the two bolts 3 and 4.
(2) Move the driving knife 1 to the left or right to adjust its position.
(3) Then tighten the bolts 3 and 4.
29)Adjusting the driving knife height
The clearance between the lower blade edge of the driving knife 1 and the lower surface of the inner rotary
From the library of: Superior Sewing Machine & Supply LLC

—16 —
hook should be 0.3-0.4mm.
(1) Loosen the two screws 2 and 5.
(2) Move the driving knife shaft 6 up or down to adjust the position of the driving knife 1.
(6) Tighten the screws 2 and 5 on the setting collars again.
30)Adjusting the driving knife stop position
The distance from the blade of the fixed knife 2 to the end of the driving knife 1 should be 0.5 mm when
the driving knife 1 has moved as far as possible toward the fixed knife 2.
(1) Tilt back the machine head.
(2) Turn the machine pulley to move the roller 4 of the driving knife arm 3 to the outermost side (right side) of
the thread trimmer cam 5.
(3) Loosen the bolt 6.
(4) Move the driving knife 1 so that the distance between
the blade of the fixed knife 2 to the end of the driving knife 1
is 0.5 mm, and then tighten the bolt 6.
31)Adjusting the driving knife operating position
The standard distance from the left side of driving knife
arm 1 to the screw tip on the plunger 2 of the thread trimming
solenoid is 1 mm. The clearance between the outermost side
(right side) of the thread trimmer cam 5 and the roller 6 of the driving knife arm should be 0.1 mm.
From the library of: Superior Sewing Machine & Supply LLC

—17 —
(1) Overturn the arm.
(2) Loosen the bolt 3
(3) Turn the plunger 2 of the thread trimming solenoid so that the distance from the left side of driving knife
arm 1 to the screw tip on the plunger 2 of the thread trimming solenoid is 1 mm, and then tighten the bolt 3.
(4) Loosen the bolt 4.
(5) Set the plunger 2 to the position where it projects as far as possible to the left.
(6) Turn the machine pulley to move the roller 6 of the driving knife arm to the outermost side (right side) of
the thread trimmer cam 5.
(7) Move the roller 6 so that the clearance between the outermost side (right side) of the thread trimmer cam 5
and the roller 6 is 0.1mm, and then tighten the bolt 4.
32)Adjusting the thread trimming timing
The center of the pin 1, the center of the reference hole 3 and the center of the roller 4 of the driving knife
arm should be in a straight line when the thread take-up lever is at the highest position. (The white point on the
pulley and the point on the belt cover are in a straight line.)
(1) Turn the machine pulley until the white point on the pulley and the point on the belt cover are in a straight
line.
(2) Overturn the arm.
(3) Loosen the three bolts 5
(4) Turn the thread trimmer cam 2 to adjust the position of the thread trimmer cam 2 so that the center of the
pin 1, the center of the reference hole 3 and the center of the roller 4 of the driving knife arm are in a straight
line.
(5) Tighten the bolts 5.
33)Safety clutch
The standard safety clutch 2 in the lower toothed belt wheel protects the hook from being displaced or
damaged in case of thread jamming in the hook path. When the hook is blocked, the safety clutch 2 must come
out.
From the library of: Superior Sewing Machine & Supply LLC
