English 1
1 Information about the documentation
1.1 About this documentation
• Read this documentation before initial operation or use. This is a prerequisite for safe, trouble-free
handling and use of the product.
• Observe the safety instructions and warnings in this documentation and on the product.
• Always keep the operating instructions with the product and make sure that the operating instructions
are with the product when it is given to other persons.
1.2 Explanation of symbols used
1.2.1 Warnings
Warnings alert persons to hazards that occur when handling or using the product. The following signal words
are used:
DANGER
DANGER !
▶Draws attention to imminent danger that will lead to serious personal injury or fatality.
WARNING
WARNING !
▶Draws attention to a potential threat of danger that can lead to serious injury or fatality.
CAUTION
CAUTION !
▶Draws attention to a potentially dangerous situation that could lead to slight personal injury or damage
to the equipment or other property.
1.2.2 Symbols in the documentation
The following symbols are used in this document:
Read the operating instructions before use.
Instructions for use and other useful information
Dealing with recyclable materials
Do not dispose of electric equipment and batteries as household waste
1.2.3 Symbols in the illustrations
The following symbols are used in illustrations:
These numbers refer to the corresponding illustrations found at the beginning of these operating
instructions
The numbering reflects the sequence of operations shown in the illustrations and may deviate
from the steps described in the text
Item reference numbers are used in the overview illustrations and refer to the numbers used in
the product overview section
This symbol is intended to draw special attention to certain points when handling the product.
1.3 Explanation of signs used
1.3.1 Symbols
The following symbols are used:
Printed: 15.02.2019 | Doc-Nr: PUB / 5300600 / 000 / 02
2 English
Protection class II (double-insulated)
For indoor use only
1.4 Product information
products are designed for professional users and only trained, authorized personnel are
permitted to operate, service and maintain the products. This personnel must be specifically informed about
the possible hazards. The product and its ancillary equipment can present hazards if used incorrectly by
untrained personnel or if used not in accordance with the intended use.
The type designation and serial number are printed on the rating plate.
▶Write down the serial number in the table below. You will be required to state the product details when
contacting Hilti Service or your local Hilti organization to inquire about the product.
Product information
Monitor PSA 200
Generation 01
Serial no.
2 Safety
2.1 Additional safety instructions, detectors
This product complies with all the requirements of the applicable directives, but Hilti cannot entirely
rule out the possibility of interference caused by powerful magnetic or electromagnetic fields affecting
it, possibly leading to incorrect measurements. Check accuracy by taking measurements by other
means when working under such conditions, or if you are unsure.
▶Before operating the device, read the operating instructions stored in its memory.
▶Use the product only when it is in perfect working order.
▶Never tamper with or modify the product in any way.
▶Do not operate the scanning tool in explosive atmospheres, such as in the presence of flammable liquids,
gases or dust.
➥ Sparks that can ignite dust, fumes or vapors can be created in the scanning tool.
▶Acclimatize the scanning tool before using it.
➥ Big differences in temperature can lead to incorrect operation.
▶Always check the device settings before using it.
▶After switching on, observe the display.
➥ A disclaimer appears when the device powers up. You must accept this disclaimer in order to access
the main menu.
▶Comply with warnings if they are issued.
▶Keep the display clean and carefully dry the device before stowing it in a transport container.
▶Keep to the specified range of operating and storage temperatures between -25 °C and +63 °C.
▶Remove the battery prior to storage.
Printed: 15.02.2019 | Doc-Nr: PUB / 5300600 / 000 / 02
English 3
3 Description
3.1 Product
@On/off button
;Windows button
=Confirmation button
%Increase brightness
&Reduce brightness
(Mute the device
)Screenshot function
+Switch WLAN on/off
§Touchscreen
/Battery charge state
:Power LED
∙Microphone
$Light sensor
3.2 Use
The tablet is designed to be used to display and analyses scans made with Hilti Scan systems. Scans can
be managed in projects and subsequently transferred to a PC for data evaluation and archival.
4 Before use
4.1 Charging and switching on
1. Charge the device fully.
2. Switch the device on by pressing the on/off button.
3. Start the PSA 200 application.
4. Before the PSA 200 application can be used you must accept the terms of the disclaimer notice displayed.
5. Press the Xsymbol at top right to end the PSA 200 application.
6. To switch the device off select Start →Shut down.
4.2 Activation
1. Type the activation key and your contact data.
When starting the PSA 200 application for the first time you will be required to enter your contact
data and the activation key.
Printed: 15.02.2019 | Doc-Nr: PUB / 5300600 / 000 / 02
4 English
2. Confirm your entries by pressing the Activate function button.
The PSA 200 application cannot be used unless your contact data and a valid activation key have
been entered.
4.3 Settings
1. Select the desired language, the desired country and the units you wish to be displayed.
When operating a brand new device you will first be requested to select the country-specific
settings.
2. Confirm the settings you have made by pressing the OK function button.
By pressing Skip you can postpone making these settings until the next time the PSA 200
application is started.
5 Operation
5.1 Displaying the operating instructions
1. Press the ?symbol at top right.
The operating instructions will be shown in the right context in the display. You can then browse
through the complete operating instructions.
2. To close the operating instructions, press the Back function button.
5.2 Main menu
The PSA 200 application starts with the main menu, which can also be accessed at any time by pressing the
Home button at top left of the screen. From there you can also access the project management and settings
screens.
5.3 Project management
Using the functions accessed from the Projects submenu you can manage projects, display and analyze
previously recorded scans and import new data.
5.4 Importing PS 1000 X-Scan projects and data
1. Connect the PS 1000 X-Scan using the PSA 52 data cable.
2. Press the Import function button and then select the PS 1000 X-Scan.
3. Either use the check boxes to select one or more projects or tap a project to show the scans it contains.
These scans can then also be selected by way of the check boxes.
4. Confirm your selection by pressing the OK function button and, if individual scans have been selected
(see point 3), then select the target project on the PSA 200 tablet.
5. The selected objects (projects or individual scans) will then be imported.
5.5 Importing PS 200 S Ferroscan projects and data
1. Insert the PSA 56 infrared adapter in a USB port on the PSA 200 tablet.
2. Position the PS 200 S opposite the PSA 200 tablet so that the IR interfaces are facing each other directly.
3. Press the Import function button and then select the PS 200 S.
4. Select the project into which the scans from the PS 200 S are to be imported.
5. All the scans from the PS 200 S will then be imported into the selected project on the PSA 200 tablet.
5.6 Importing PS 300 projects and data
1. Connect the PS 300 to the PSA 200 by means of the data cable.
2. Press the Import function button and then select the PS 300.
3. Either use the check boxes to select one or more projects or tap a project to show the scans it contains.
These scans can then also be selected by way of the check boxes.
Printed: 15.02.2019 | Doc-Nr: PUB / 5300600 / 000 / 02
English 5
4. Confirm your selection by pressing the OK function button and, if individual scans have been selected
(see point 4), then select the target project on the PSA 200 tablet.
➥ The selected objects (projects or individual scans) will then be imported.
5. When finished, sever the connection between the PSA 200 and the PS 300 / PS 300W.
5.7 Analyzing scans
1. Select the desired scan from a project.
➥ The scan is then displayed.
2. Use the function button to set the display mode to 2D or 3D.
3. The Param. and Visualization function buttons can be used to change the visualization and calculation
parameters. If you change the values in Param., the data will have to be recalculated. To do this, press
the OK confirmation button beside the parameter that has changed.
4. The Extras function button provides access to various functions including the ability to export simple
reports in PDF format or to make and play back audio recordings.
5. You can use the Drillhole function button to show the drillholes in Imagescans or to define new drillholes.
6. The data from the PSA 200 tablet can be transferred to a PC for further analysis.
6 The following settings can be adjusted:
• Country settings
• Options
• Software update
7 Care and maintenance
WARNING
Risk of injury with battery inserted !
▶Always remove the battery before carrying out care and maintenance tasks!
Care and maintenance of the tool
• Carefully remove stubborn dirt.
• Clean the air vents carefully with a dry brush.
• Use only a slightly damp cloth to clean the casing. Do not use cleaning agents containing silicone as
these can attack the plastic parts.
Care of the Liion batteries
• Keep the battery free from oil and grease.
• Use only a slightly damp cloth to clean the casing. Do not use cleaning agents containing silicone as
these may attack the plastic parts.
• Avoid ingress of moisture.
Maintenance
• Check all visible parts and controls for signs of damage at regular intervals and make sure that they all
function correctly.
• Do not operate the product if signs of damage are found or if parts malfunction. Have it repaired
immediately by Hilti Service.
• After cleaning and maintenance, fit all guards or protective devices and check that they function correctly.
To help ensure safe and reliable operation, use only genuine Hilti spare parts and consumables. Spare
parts, consumables and accessories approved by Hilti for use with the product can be found at your
local Hilti Store or online at: www.hilti.group.
8 Transport and storage of cordless tools
Transport
CAUTION
Accidental starting during transport !
▶Always transport your products with the batteries removed!
Printed: 15.02.2019 | Doc-Nr: PUB / 5300600 / 000 / 02
6 English
▶Remove the battery.
▶Never transport batteries in bulk form (loose, unprotected).
▶Check the tool and batteries for damage before use after long periods of transport.
Storage
CAUTION
Accidental damage caused by defective or leaking batteries !
▶Always store your products with the batteries removed!
▶Store the tool and batteries in a place that is as cool and dry as possible.
▶Never store batteries in direct sunlight, on heating units or behind a window pane.
▶Store the tool and batteries in a place where they cannot be accessed by children or unauthorized
persons.
▶Check the tool and batteries for damage before use after long periods of storage.
9 Disposal
Most of the materials from which Hilti tools and appliances are manufactured can be recycled. The
materials must be correctly separated before they can be recycled. In many countries, your old tools,
machines or appliances can be returned to Hilti for recycling. Ask Hilti Service or your Hilti representative
for further information.
▶Do not dispose of power tools, electronic equipment or batteries as household waste!
10 Manufacturer’s warranty
▶Please contact your local Hilti representative if you have questions about the warranty conditions.
