Hisense TC14FS68 User manual

TC14FS68
Part No: IES031110
2003. Hisense Electric Corp. All rights reserved
C
R
OWNER'S MANUAL
COLOR TELEVISION

Important safeguards....................................... .......... .......... .......... .......... .......... .....1
Brief Operating Instructions................................. .......... .......... .......... .......... .......... .....3
Learning about your new TV ................................ .......... .......... .......... .......... .......... .....5
Selecting a location for the TV............................... .......... .......... .......... .......... .......... .....5
Connecting your TV......................................... .......... .......... .......... .......... .......... .....5
Connecting the audiovisual equipments ................ .......... .......... .......... .......... .......... .....6
Connecting the antenna ................................ .......... .......... .......... .......... .......... .....6
Connecting a cable converter box ...................... .......... .......... .......... .......... .......... .....7
Using the remote control.................................... .......... .......... .......... .......... .......... .....8
Preparing the remote control for use.................... .......... .......... .......... .......... .......... .....8
Using the TV features ...................................... .......... .......... .......... .......... .......... .....9
Understanding the TV features ......................... .......... .......... .......... .......... .......... .....9
Watching a TV program ................................ .......... .......... .......... .......... .......... .....9
Using the OPTION menu ............................... .......... .......... .......... .......... .......... .....9
Using the PRESET menu .............................. .......... .......... .......... .......... .......... .....10
Changing channels..................................... .......... .......... .......... .......... .......... .....11
Adjusting the picture ................................... .......... .......... .......... .......... .......... .....12
Adjusting the sound .................................... .......... .......... .......... .......... .......... .....12
Selecting BTSC/SAP broadcasts ...................... .......... .......... .......... .......... .......... .....13
Using the CLOCK menu ............................... .......... .......... .......... .......... .......... .....13
Using the V-CHIP menu................................ .......... .......... .......... .......... .......... .....14
Setting the sleep timer ................................. .......... .......... .......... .......... .......... .....16
Displaying the current channel number on screen ...... .......... .......... .......... .......... .......... .....17
Switching between two channels ....................... .......... .......... .......... .......... .......... .....17
Setting the child lock.................................... .......... .......... .......... .......... .......... .....17
Selecting the signal source ............................. .......... .......... .......... .......... .......... .....17
Appendix ................................................... .......... .......... .......... .......... .......... .....17
Cleaning and care ...................................... .......... .......... .......... .......... .......... .....17
Trouble shooting ....................................... .......... .......... .......... .......... .......... .....18
Specifications .......................................... .......... .......... .......... .......... .......... .....19
This is an IEC safety class II (reinforced insulation) product and does not need grounding for safety.
SAFETY CLASS
Please read all the safety and operating instructions carefully before you begin.
WELCOME TO THE BRIGHT AND VIVID WORLD OF HISENSE COLOR TV
Dear customer,
Thank you for your purchasing Hisense color TV. We wish you many years of viewing pleasure.
The goal of this manual is to guide you through setting up and operating your Hisense TV as quickly as possible.
CONTENTS

-1-
Important safety instructions
CAUTION
CAUTION: TO REDUCE THE RISK OF ELEC-
TRIC SHOCK, DO NOT REMOVE
COVER(OR BACK).NO USER-
SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED
SERVICE PERSONNEL.
The lightning flashwith arrowhead symbol,within an
equilateral triangle isintended to alertthe user tothe
presence of uninsulateddangerous voltage withinthe
product s enclosure thatmay be ofsufficient magnitude
to constitute arisk of electricshock.
'
The exclamation pointwithin an equilateraltriangle is
intended to alertthe user tothe presence of important
operating and maintenance(servicing ) instructionsin
the literature accompanyingthe set.
CAUTION: CHANGES OR MODIFICATIONS NOT EXPRESSLYAPPROVED BYTHE PARTY
RESPONSIBLE FOR COMPLIANCE WITH THE FCC RULES COULD VOID THE
USERS AUTHORITYTO OPERATE THIS EQUIPMENT.
WARNING: TO PREVENT FIRE OR SHOCKHAZARD, DO NOTEXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.
1. READ THESEINSTRUCTIONS
All the safetyand operating instructionsshould be readbefore the productis operated.
2. KEEP THESE INSTRUCTIONS
The safety andoperating instructions shouldbe retained forfuture reference.
3. HEEDALL WARNINGS
All warnings onthe product andin the operatinginstructions should beadhered to.
4. FOLLOWALL INSTRUCTIONS
All operating anduse instructions shouldbe followed.
5. DO NOTUSE THISAPPARATUS NEAR WATER
Do not usethe product nearwater. Forexample, near abathtub, washbowl, kitchensink, or laundrytub, in awet
basement, or neara swimming pool,and the like.
6. CLEAN ONLY WITHDRY CLOTH
Unplug the TV from thewall outlet beforecleaning. Do notuse liquid cleanersor aerosol cleaners.Use a damp
cloth for cleaning.
7. DO NOTBLOCK ANYVENTILATIONOPENINGS
Slots and openingsin the cabinetback or bottomare provided forventilation, to ensure reliable operation ofthe
TV and toprotect it fromoverheating. Theseopenings must notbe blocked orcovered. Theopenings should never
be blocked byplacing the producton a bed,sofa, rug, orother similar surface.This product should never beplaced
near or overa radiator orheat resource.This product shouldnot be placedin a built-ininstallation such asa bookcase
or rack unlessproper ventilation isprovided or themanufacture's instructions havebeen adhere to.
8. DO NOTINSTALLNEAR ANYHEATSOURCES
This product shouldbe situated awayfrom heat sourcessuch as radiators,stoves, or otherproducts (including amplifiers)
that produce heat.
9. DO NOTDEFEATTHE SAFETY PURPOSE OF THEPOLARIZED OR GROUNDING-TYPEPLUG
A polarizedplug has twoblades with onewider than theother.A grounding-type plug hastwo blades anda third grounding
prong. The wide blade orthe third prongare provided foryour safety. If theprovided plug doesnot fit intoyour outlet, consult
an electrician forreplacement of theobsolete outlet.
10. PROTECT THEPOWER CORD FROMBEING WALKEDON OR PINCHEDPARTICULARLY AT PLUGS, CONVENIENCE
RECEPTACLES, AND THE POINT WHERE THEYEXIT FROM THEAPPARATUS.
11. ONLY USEATTACHMENTS/ACCESSORIES SPECIFIED BYTHE MANUFACTURE.

S3126A
-2-
Important safety instructions
12. USE ONLY WITHCART,STAND,TRIPOD, BRACKET, OR TABLE SPECIFIED BY
THE MANUFACTURER,OR SOLD WITHTHE APPARATUS. WHEN ACART IS USED,
USE CAUTION WHENMOVING THE CART/APPARATUSCOMBINATION TO AVOID
INJURY FROMTIP-OVER.
Do not placethis TVon an unstablecart, stand, tripod,bracket ,or table.The TVmay
fall, causing seriousinjury to someone,and serious damageto the appliance.AnTV
and cart combinationshould be movedwith care. Quickstops, excessive force,and
uneven surfaces maycause the productand cart combinationto overturn.
POWER SOURCE
This TV should be operated only from thetype of powersource indicated onthe marking label.If you arenot sure ofthe type
of power supplyto your home,consult your appliancedealer or localpower company .For TVs intended to operatefrom
battery power,or other sources,refer to theoperating instructions.
16. POWER CORDPROTECTION
Power-supply cords shouldbe routed sothat they arenot likely tobe walked onor pinched byitems placed upon or against
them, paying particularattention to cordsat plugs, conveniencereceptacles, and thepoint where theyexit from theappliance.
17. OUTDOORANTENNA GROUNDING
If an outsideantenna or cablesystem is connectedto
the TV, be surethe antenna orcable system isgrounded
to provide someprotection against voltagesurges
and built-up staticcharges. Section 810of the National
Electrical Code,ANSI/NFPANO.70,provides
information with respectto proper grounding
of the mastand supporting structure,grounding
of the lead-inwire to anantenna discharge unit,
size of groundingconductors, location of
antenna discharge unit,connection to grounding
electrodes, and requirementsfor the grounding
electrode.(Fig.A)
18. LIGHTNING
For added protectionfor this TV receiver during
a lightning storm,or when itis left unattendedand
unused for longperiods of time,unplug it fromthe wall outletand disconnect theantenna or cablesystem. Thiswill prevent
damage to theTV due to lightning andpower line surges.
19. POWER LINES
An outsideantenna system shouldnot be locatedin the vicinityof overhead powerlines, or otherelectric light orpower
circuits, or whereit can fallinto such powerlines or circuits.When installing anoutside atenna system,extreme care should
be taken tokeep from touchingsuch power linesor circuits ascontact with themmight be fatal.
20. OVERLOADING
Do not overloadwall outlets andextension cords asthis can resultin a riskof fire orelectric shock.
21. OBJECTAND LIQUID ENTRY
Never push objectsof any kindinto this TV through openings as they maytouch dangerous voltagepoints or shortout parts
that could resultin fire orelectric shock. Neverspill liquid ofany kind intothe TV.
22. SERVICING
Do not attemptto service thisTV yourself as opening or removing covers mayexpose you todangerous voltage orother
hazards. Refer allservicing to qualifiedservice personnel.
23. REPLACEMENT PARTS
When replacement partsare required, besure the servicetechnician uses replacementparts specified bythe manufacturer
that have thesame characteristics asthe original part.Unauthorized substitutions mayresult in fire,electric shock, injury to
persons or otherhazards.
24. SAFETY CHECK
Upon completion ofany service orrepairs to thisTV,ask the servicetechnician to performroutine safety checksto determine
that the TV is inproper operating condition.
13. UNPLUG THISAPPARATUS DURING LIGHTNINGSTORMS ORWHEN UNUSED
FOR LONG PERIODSOF TIME.
For added Protectionfor this TV receiver duringa lightning storm,or when itis left
unattended and unusedfor long periodof time, unplugit from thewall outlet and
disconnect the antennaor cable system.This willprevent damage tothe TV due to
lightning and powerline surges.
14. REFERALL SERVICINGTO QUALIFIED SERVICE PERSONNEL. SERVICING IS REQUIRED WHEN THEAPPARATUS
HAS BEEN DAMAGEDIN ANYWAY,SUCH ASPOWER-SUPPLYCORD OR PLUGIS DAMAGED, LIQUIDHAS BEEN
SPILLED OR OBJECTSHAVEFALLEN INTO THE APPARATUS, THE APPARATUS HAS BEENEXPOSED TO RAIN OR
MOISTURE, DOES NOTOPERATENORMALLY, OR HASBEEN DROPPED.
15.
ANTENNA LEAD
IN WIRE
ANTENNA
DISCHARGE UNIT
GROUND CLAMPS
POWER SERVICE GROUNDING
ELECTRODE SYSTEM
ELECTRIC
SERVICE
EQUIPMENT
GROUND
CLAMP
EXAMPLE OF ANTENNA GROUNDINGAS PER
NATIONAL ELECTRICAL CODE
FIGURE A
S2898A
GROUNDING WIRES

Brief Operating Instructions
1. Connection
Connect the antenna lead or CATV cable or external equipments ( such as Antenna, Cable TV,VCD,DVD,
VTR,Set top box,etc .) to the corresponding terminals or interface on the TV rear ( please refer to the
owner s manual of the equipment to be connected as well ) and confirm that the signal source is avaliable
and works normally.
2. The remote control
Open the battery cover of the remote control and install two AA size batteries and then close
the battery cover .
VIDEO
OUTPUT
AUDIO OUTPUT(LEFT)
AUDIO OUTPUT(RIGHT)
INPUT OUTPUT
AUDIO INPUT(RIGHT)
VIDEO
INPUT
AUDIO INPUT(LEFT)
VIDEOVIDEO
L(MONO)L(MONO)
RR
-3-
POWER: Power on / off
MUTE: Mute the sound
CHANNEL NUMBER : Direct Channel
selection
V-CHIP:Block certain TV channels
according to the FCC requirements
RECALL: Return to previous channel
DISPLAY: Display the current channel
number
TV/AV: TV / AV selection
SAP: SAP/stereo/Mono selection
CH+/-:Channel selection
V0L+/-:Increase or decrease sound
LOCK: Child lock
P.P : Personal preset
123
5
4
6
789
POWER
MUTE
TV/AV
+
+
__
CH
VOL
RECALL
LOCK V.CHIP SLEEP
MENU
0
DISPLY
SAP
P.P
S-VIDEOS-VIDEO

3.Switching on/off
1) Connect the TV to power outlet. The power indicator will glow in red color. Press the power switch or the POWER
button on the remote control to turn on the TV.
2) Press the power switch or the POWER button on the remote control to turn offthe TV.
4.Signal source selection
Press the TV/AVbutton to select TV or AV mode.
5.Air/Cable selection
Youcan select the signal receiving method according to the following steps:
1) Press the MENU button repeatedlyuntil the PRESET menu appears as
shown in the right .
2) Press the CH+ or CH- button to select the item Antenna.
3) Press the VOL+ or VOL- to change theitem betweenAir and Cable.
Position 17
PRESET
Add/Delete
Antenna
Auto-search
Add
Air
Select
:Adjust :
6.Channel search
1) Press the MENU button repeatedlyuntil the PRESET menu appears as
shown in the right.
2) Press the CH+ or CH- button to select the item Auto-search.
3) Press the VOL+ or VOL- to start toauto-search programs.
Position 17
PRESET
Add/Delete
Antenna
Auto-search
Add
Air
Select
:Adjust :
7.Picture adjustment
1) Press the MENU button, and the PICTURE menu appears as shown in the right.
2) Press the CH+ or CH- to selectthe item you want to adjust.
3) Press the VOL+ or VOL- to adjust the level .
Bright 80
Contrast
Color
Sharp
Tint
80
00
80
80
Select
:Adjust :
8.Sound adjustment
1) Press the MENU button repeatedly until AUDIO menu appears as shown right .
2) Press the CH+ or CH- to selectthe item you want to adjust.
3) Press the VOL+ or VOL- to adjust the item.
Volume
50
AUDIO
Balance 00
Select
:Adjust :
9.Timer setting
1) Press the MENU button repeatedlyuntil the CLOCK menu appears as
shown in the right.
2) Press the CH+ or CH- to selectthe item you want to set.
3) Press VOL+ to set hour and press VOL- to set minute.
Time
CLOCK
On-time
Off-time
Attention
Exchange
Select
:Adjust :
Position
:
:
:
:
:
Note2: For more detailed information, please refer to the manual.owner's
Note1: All keys mentioned above are on the remote control unless indicated otherwise..
-4-

-5-
Learning about your new TV
Youcan operate your TVby using the buttons on the front panel or the remote control. All the terminals on
the front and the back panel provide the connections you will need to connect other equipment to your TV.
Caution:
The TV power plug has one prong wider than the other and will fit only one way into a standard
electrical outlet(120VAC,60Hz).If the plug does not fit into the outlet, try turning it around. If the
plug still does not fit, the outlet is probably non-standard and must be replaced by a qualified
electrician.
Do not tamper with the plug or try to force it into a non-standard outlet.
Selecting a location for the TV
1) Place the TVon the floor or on a sturdy platform in a location where light does not directly hit the screen.
2) Place the TVfar enough from the walls to allow proper ventilation. Inadequate ventilation may cause
overheating, which may damage the TV.
Note: The above figures are for reference only, please refer to the actual units to determine their appearance.
Front Controls Back Connections
Aerial socket
AC CORD AND PLUG
S-Video
Front panel
Video output
Audio output(left)
Audio output(right)
Audio input(right)
Video input
Audio input(left)
INPUT
L(MONO)
RR
OUTPUT
VIDEO
VIDEO
L(MONO)
AUDIO
If you haven't connected electronic equipment before, or you have been frustrated in the past, you may wish
to read this section.(Cables are not supplied.)
Caution: Do not plug the TV in until you havefinished connecting all of your equipment.
Connecting your TV
CHANNEL DOWN
VOLUME UP
MENU
VOLUME DOWN
TV/AV
CHANNEL UP
TV/AV MENU CH
VOL
POWER INDICATOR
INFRARED SENSOR
POWER SWITCH
S-VIDEOS-VIDEO
RIGHT LEFT VIDEO

To enjoy the programs coming from your audiovisual equipments such as VCR, DVD, Satellite receiver, Camcorder,
Audio amplifier and etc, the signal must be received by the set via the AV input terminals at rear. You can also record
the TV programs to a video tape by VCR. Connect the devices as the following figure.
Note:
1.The program coming through AV input terminals can't be re-recorded via AV output terminals.
2.When the TV is in AV mode, there is no signal output on the OUTPUT terminals.
3.When connecting S-VIDEO, Audio Left and Right cables should be connected to AUDIO INPUT terminals.
Also the S-VIDEO and VIDEO INPUT terminals can't be connected simultaneously. When you want to watch
TV program, please shut the S-VIDEO signal.
Connecting the audiovisual equipments
Connecting your TV
To enjoy the terrestrial signal transmitted by your local TV station, you need an indoor or outdoor aerial (not supplied).
Perfect picture quality requires a good signal and generally means that an outdoor aerial must be implemented. The
exact type and location of the aerial will depend on your particular area. Consult your local dealer or service
personnel for best advice. If you are a subscriber of your local CATV net, the outdoor or indoor aerial is not needed.
Connect the equipments as the following figure.
-6-
AERIAL SOCKET
REAR VIEW
TWIN-LEAD FEEDER ¦¸(300 )
Loosen the screw Insert the feeder in Tighten the screw
Plug(not supplied)
Adaptor (not supplied)
The signal comes from:
!An outdoor aerial
!An indoor aerial
Connecting the aerial
To the input terminals
PLAY VIDEO TAPE, DVD etc.
INPUT
OUTPUT
VIDEO
VIDEO
LEFT(MONO)
LEFT(MONO)
RIGHT
RIGHT
VCR/DVD
RECORD THE TV PROGRAM
From the output terminals
INPUT
L(MONO)
RR
OUTPUT
VIDEO
VIDEO
L(MONO)
S-VIDEO
TV
AUDIO
S-VIDEOS-VIDEO
COAXIAL CABLE(75¦¸)

-7-
Connecting a cable converter box
This television has an extended tuning range and can tunemost cable channels without using a cable
company supplied converter box. Some cable companies offer[premium pay channels] in which signal is
scrambled. Descrambling these signals for normal viewing requires the use of a descrambler device which
is generally provided by the cable company.
For subscribers to Basic Cable TV Service
For basic cable service not requiring a Converter/Descrambler box, connect the CATV 75 ohm Coaxial
Cable directly to the Antenna Jack on the back of the television.
For subscribers to Scrambled Cable TV Service
If you subscribe to a cable service which requires the use of a Converter/Descrambler box, connect the
incoming cable to the Converter/Descrambler box and connect the output of the box to the Antenna Jack
on the back of the television. Follow the connections shown below. Set the television to the output of the
Converter/Descrambler box(usually channel 3 or 4)and use the Converter/Descrambler box to select
channels.
For Subscribers to Unscrambled Basic Cable with Scrambled Premium Channels
If you subscribe to a cable service in which basic cable channels are unscrambled and premium channels
require the use of a Converter/Descrambled box, you may wishto use a two-set signal splitter(sometimes
called [two set coupler]) and an A/B Switch box from the cable installer or an electronics supply store.
Follow the connections shown below. With the switch inthe B position, you can directly tune any
screwed channels on your TV. With the switch in the Aposition, tune your TV to the output of the
Converter/Descrambler box(usually channel 3 or 4) and use the box to tune scrambled channels.
Note:
When you use a converter box with your TV, there may be features that you cannot
program using the remote control.
Connecting your TV
INPUT
L(MONO)
R
R
OUTPUT
VIDEO
VIDEO
L(MONO)
S-VIDEO
AUDIO
Converter/Descrambler
Converter/Descrambler
Splitter A/B Switch

Preparing the remote control for use
Installing the remote control batteries
1. Open the battery cover of the back of the remote control.
2. Install two AA size(1.5V) batteries. Match the + and - signs on the batteries to the signs on the battery
compartment.
Using the remote control
°´¼ýÍ··½ÏòÇáÍÆ
¼´¿ÉжϺиÇ
Slide in the direction of the
arrow to remove the
battery cover.
6m
30
30
-8-
3. Close the battery cover on to the remote control.
Note:
1.Dispose of your batteries in a designated disposal area. Do not throw your batteries into fire.
2.Do not mix battery types or combine used batteries with new ones.
3.Remove dead batteries immediately to prevent battery acid from leaking into the battery compartment.
4.If you do not intend to use the remote control for a long time, remove the batteries.
5.The effective range of remote control is suggested in the figure.
RIGHT LEFT VIDEO

Using the TV features
-9-
Language English
OPTION
Coring
C.caption
Game
Off
Off
Select
:Adjust :
Watching a TV program
1)Connect to power outlet, the power indicator will display red. Press the power switch or the POWER
button on the remote control t .
2)Select the on-screen display language (See Using the OPTION menu).
3)Auto-search the programs(See Using the PRESET menu).
4)Press CH+ and CH- or the channel number buttons on the remote control to s
.
5)Adjust the picture quality for a natural looking image(See Adjusting the picture).
6)Press VOL+ and VOL- to a . Also, you can adjust it in the AUDIO menu(See Adjusting the
sound).
7)Press the power switch or the POWER button on the remote control to turn off the TV.
the TV
o turn on the TV
elect the channel you wish(See
Changing channels)
djust the volume
Using the OPTION menu
1)Press the MENU button repeatedly until OPTION menu as shown.
2)Press the CH+ or CH- to select the item you want to adjust.
appears right
Tinted, Bright Black Matrix Picture Tube
181 Channels Selection-All VHF/UHF channels plus up to 125.
PLL Frequency Synthesized Tuning-The latest PLL frequencysynthesized electronic tuning system
provides free and easy channel selection, and lets you tune directly to any channel using the channel
number buttons on the remote control.
On-Screen Function Display
Full-Function Remote Control
Sleep Timer
Closed Caption Decoder-Youmay view specially labelled(cc)TV program, movies, news, prerecorded
tapes, etc. with either a dialogue caption or text display added to the program.
Auto Shut Off Function-If there is no signal input from the antenna terminal and no operation for 15
minutes, the TV willturn itself off .
V-CHIP-Enables parents to prevent their children from watching inappropriate programs on TV.
BTSC/SAP
Understanding the TV features

-10-
Using the TV features
Position 17
PRESET
Add/Delete
Antenna
Auto-search
Add
Air
Select
:Adjust :
The item is for decreasing the noise of the background.
Press VOL+ or VOL- to select On or Off.
Press VOL+ or VOL- to change the on-screen display language among English, French, Spanish and Portuguese.
This is a game preset by the manufacturer in the TV set.
1)Press VOL+ or VOL- to enter the game, then the screen will display as shown .
2)Press the RECALL button to start the game, then press RECALL three times
the system will reward you according to the number.
3)Press the DISPLAY button to
Note: The rules of the game
1)If one of the three numbers is 8, you will get one coin.
2)If two of the three numbers are same, but they are all not 8, you can get two coins.
3)If two of the three numbers are same and they are all 8, you can get three coins.
4)If the three numbers arrange as 123 or 321, you will get four coins.
5)If the three numbers are all same, you can get five coins.
right
to pitch on the number. And then
quit the game. RECALL : Play
DISPLAY: Exit
7 7 7
Gifts :
Youhave two options with the closed caption feature: captions or text. A caption is a printed version of
the dialogue, narration and/or sound effects of a TV program. Text is information not rated to the
program that appears on half of the TV screen.
Press VOL+ or VOL- to change the item among Off/CC1/CC2/CC3/CC4/TT1/TT2/TT3/TT4.
Using the PRESET menu
1)Press the MENU button repeatedly until the PRESET menu appears as
shown.
2)Press the CH+ or CH- button to select the item you want to adjust.
right
The item allows the TV to auto-search programs through the whole channels from Air to Cable.
Press VOL+ or VOL- to start it.

Using the TV features
-11-
The item allows you to add or delete a channel.
Press VOL+ or VOL- to select Add or Delete.
If some channel is set to Delete, the channel will be skipped when
you select a channel by pressing CH+ and CH-.
The item allows you to select the signal receiving method.
change the item between Air and Cable. Press VOL+ or VOL- to
Changing channels
To change the channel, you can
1.Press CH +or CH- on the remote control or on the TV.
2.Press the channel number buttons(0-9).
1) To select a one-digit channel : Press the 0 button to display 0- and then press a button from 1-9.
2) To select a two-digit channel : Press a button from 1-9 to select the first number, then press a button
from 0-9 again to select the second number. For example, to select channel 28, press the 2 button first ,
2- will appear on the screen, and then press the 8 button.
3) To select a three-digit channel: Press the 1 button for about one second until 1-- appears on the screen, then
press buttons from 0-9 successively to select the other two numbers. For example, to select channel 120,
press the button 1 for one second , 1-- will appear on the screen, then press the button 2 and the button 0
successively.
CH
Note:
1)When the search is finished, the screen will display as left shown below and the TV will automatically turn to the
first channel that has a program. Otherwise the screen will display as right shown below.
2) The PRESET menu will not appear when the TV is in AV status.
3) Press the VOL+ or VOL- to stop the auto-search if you want.
Search finished
Please watch
Nothing searched
Check antenna
Press VOL+ and VOL- or the channel number buttons to select the channel thatyou wish.

-12-
Note: The items in this menu are explained in details as following.
Adjusting the picture
Adjusting the picture quality
Bright 80
Contrast
Color
Sharp
Tint
80
00
80
80
Select
:Adjust :
Item Pressing
Contrast
Brightness
Sharpness
Color
Tint Purplish
Softer
Paler
Lower
Lighter
VOL-
Sharper
Deeper
Higher
Darker
VOL+
Greenish
1)Press the MENU button, then the PICTURE menu appears as shown.
2)Press the CH+ or CH- to select the item you want to adjust.
3)Press the VOL+ or VOL- to adjust the level .
right
Selecting the picture mode
You can select the picture quality instantly among four preset modes and one user-set mode.
Press the P.P button on the remote control repeatedly to select the desired picture quality.
PersonalPersonal LightVividSoftStandard
Adjusting the sound
Volume
50
AUDIO
Balance 00
Select
:Adjust :
You can adjust the balance if the volume of the left and right speaker is different.
Press VOL+ to increase the volume of the right speaker
Press VOL- to increase the volume of the left speaker
Press the VOL+ or VOL- to increase or decrease the volume.
1)Press the MENU button repeatedly until AUDIO menu appears as shown.
2)Press the CH+ or CH- to select the item you want to adjust.
right
Using the TV features

-13-
Muting the sound
Press to temporarily turn off the sound. While the
sound is off, the screen will display as shown.
To restore the sound, press MUTE again.
MUTE on the remote control
right
Mute
x
25
Selecting BTSC/SAP broadcasts
You can enjoy watching TV while you listen to high-fidelity stereo sound with the BTSC feature. BTSC can
also transmit a second audio program(SAP) containing a second language or other audio information.
Press the SAP button on the remote control, the TV will execute different operations according to
the different broadcasts that it has received.
Note:
1)If the TV receivesMono broadcasts, press the SAP button repeatedly, the word Mono appears
on the screen .
2)When
3)When
4)When
the TV receives Mono SAP broadcasts, press the SAP button repeatedly, the words Mono and
SAP will alternate to appear on the screen.
the TV receives Stereo broadcasts, press the SAP button repeatedly, the words Mono and
Stereo will alternate to appear on the screen.
the TV receives Stereo SAP broadcasts, press the SAP button repeatedly, the words Mono,
Stereo and SAP will alternate to appear on the screen.
Using the CLOCK menu
Time
CLOCK
On-time
Off-time
Attention
Exchange
Select
:Adjust :
Position
:
:
:
:
:
The item allows you to set the time on the TV.
Press VOL+ to set hour, the clock counts up one hour for each press of VOL+ button.
Press VOL- to set minute, the clock counts up one minute for each press of VOL- button.
local
The item allows the TV automatically turns on to a preset channel when preset time comes.
Set this item just like the Time setting.
The item allows the TV automatically to switch to standby mode when the preset time comes.
Set this item just like the Time setting.
1)Press the MENU button repeatedly until the CLOCK menu appears as
hown on the right.
2)Press the CH+ or CH- to select the item you want to adjust.
s
Using the TV features
Note: The time you set in this menu is for reference only.

The item is for reminding you when preset time comes. The screen will display
as shown. It will disappear when you press any button.
Set this item just like the Time setting.
right
Attention
The item allows the TV automatically to turn to a channel preset in the Position when the preset time comes.
Set this item just like the Time setting.
The item allows preset time in On-time or Exchange comes.the TV automatically turns to the channel when the
Press VOL+ or VOL- to preset a channel.
Using the V-CHIP menu
V-CHIP enables parents to prevent their children from viewing certain programs or channels.
To use the V-CHIP to block programs by rating
1)Press the V-CHIP button, then the V-CHIP menu appears as shown on the right.
2)Press the CH+ or CH- to select the item you want to set.
Block On
V-CHIP MENU
TV Rating
MPAA Rating
Change password
Select
:Adjust :
old password :
Please input
new password :
Please input
password again :
Input new
Please remember
Password changed
There is a default password(0000) preset by manufacturer on the TV. If you want to change it, please follow
the steps below.
1)Press VOL+ or VOL-, the screen will display as shown below to ask you to enter the old password.
2) Enter the default password, the TV will ask you to enter a new password.
3) Enter a new password you like, the TV will ask you to enter it again for confirmation.
4)Enter the new password again.
Note:
You can only use the channel number buttons(0-9) for the password enter.
1)If the two new password enters are same, the screen will display that the password has been changed.
Otherwise the password remains unchanged. You have to retry.
2)
Using the TV features
-14-

Using the TV features
-15-
1)Press VOL+ or VOL-,
2)
the screen will display as left shown below to ask you to enter a password.
Enter the right password, the Block will alternate between On and Off.
If the password is wrong, the screen will display as right shown below.
password :
Please input
Wrong password
1)Press VOL+ or VOL- and the TV will ask you to enter a password.
2)Enter the right password, display as shown below.
3)Press the CH+ or CH- to select the ratings.
4)Press to the selected ratings.
the screen will left
MENU button block(B) or unblock(U)
1)Press VOL+ or VOL- and the TV will ask you to enter a password.
2)Enter the right password, will display as shown below.
3)Press the CH+ or CH- to select the rating.
4)Press unblock(U) the selected rating.
.
the screen right
MENU button to block(B) or
TV-Y
FV
TV-Rating
TV-Y7
TV-G
TV-PG
Rating
TV-MA
TV-14
Age Based Rating
V
S
L
D
U
U
U
U
U
U
U
U U UU
U U UU
U UU
G
MPAA-Rating
PG
PG-13
R
Movie
X
NC-17
Age Based Rating
Rating
U
U
U
U
U
U
Note:
1) As you block ratings, all ratings higher than the ones you select are blocked as well. For example, if you
choose to block the MPAA rating R, the higher ratings, NC-17 and X, are automatically blocked too.
2) You can press TV-Rating menu and MPAA-Rating menu.
About TV Ratings
The TV ratings are divided into two groups: age-based and content-based.
VOL+ or VOL- to alternate between

The Motion Picture Association of America(MPAA) uses a rating system to qualify motion picture content.
Television broadcasters employ a rating system to qualify the content of televison programs as well.
The MPAA and TV ratings work with the V-CHIP feature and allow you to block out programming above
the rating limits you determine.
About MPAA Ratings
Age Defined as
TV-Y
TV-Y7
TV-G
TV-PG
TV-14
TV-MA
All children
Directed to older children
General audience
Parental Guidance suggested
Parents Strongly cautioned
Mature Audience only
Contents Defined as
FV
D
L
S
V
Fantasy Violence
Suggestive dialogue
Strong language
Sexual situations
Violence
Rating Defined as
G
PG
PG-13
R
NC-17
X
General audience
Parental Guidance suggested
Parents strongly cautioned
Restricted
No one 17 and under admitted
Adult audience only
Setting the sleep timer
You can set the TV so it turns off automatically.
To set the sleep timer:
1) Press the SLEEP button on the remote control. The screen will display
as shown on the right.
2) Press the SLEEP button he clock will count up 15 minutes
for each press of the SLEEP button(15,30,45....).
To confirm the sleep timer setting:
P
To cancel the sleep timer:
Press the SLEEP button repeatedly until the display disappears
repeatedly and t
The timer can be set up to 120 minutes.
ress the SLEEP button and the remaining time will be momentarily displayed.
.
Sleep
Using the TV features
-16-

Displaying the current channel number on screen
Press the DISPLAY button on the remote control, the current channel number will display on the top-right
corner of the screen. Whenever you want to cancel it, press the DISPLAY button again.
Switching between two channels
Press the RECALL button on the remote control to return to the previous channel that you have just viewed.
Press the RECALL button repeatedly, alternate between the present and previous channels.the screen will
Setting the child lock
Press the LOCK button to unlocklock or the TV.
When the TV is locked, the screen will turn to blue background, and nothing can be viewed unless you press
LOCK again to unlock it.
Selecting the signal source
Press the TV/AV button to select TV or AV mode.
Using the TV features
-17-
Note:
1) If you have set the sleep timer, the Off-time (See Using the CLOCK menu) you set will be cleared
automatically.
2) If you have set the On-time (See Using the CLOCK menu), when the preset time comes to turn on the TV,
the sleep timer will be set to 120 minutes automatically. It will be cancelled automatically when you execute
any operation with the TV(This feature is just for nobody being at home, however the TV turns on
automatically).
Appendix
Cleaning and care
WARNING: TV sets use high voltage. Do not try to remove the cabinet back. Refer servicing to qualified
service technicians.
To clean the TV screen:
1) Unplug the TVto avoid possible shock hazard.
2) Use a clean cellulose sponge or chamois cloth dampened with a solution of mild detergent and warm
water to clean the TV screen and trim. Do not use too much water because water spills into the cabinet
can cause damage to the TV.
3) Wipe off anyexcess moisture with a clean dry cloth.
4)Polish the cabinet with a quality furniture polish to maintain the finish and appearance of the cabinet.
Caution: Never use strong solvents such as thinner, benzene, or other chemicals on or near the cabinet.
These chemicals can damage the finish of the cabinet.

Troubleshooting
Before calling a service technician, please check the following table for a possible cause of the problem and
some solutions.
-18-
Problem Solution
TV will not turn on
No picture, no sound
No sound, picture OK
Poor sound, picture OK
Poor picture, sound OK
Poor reception of broadcast channels
Unable to select a certain channel
Multiple images
Poor color or no color
The remote control does not operate
Make sure the power cord is plugged in, then press POWER.
The remote control batteries may be dead. Replace the batteries.
Check the antenna/cable connections.
The sound may be muted. Press VOL+.
The station may have broadcast difficulties. Try another channel.
The station may have broadcast difficulties. Try another channel
Check the antenna connections.
The station may have broadcast difficulties. Try another channel.
Adjust the picture from the menu.
The channel may be deleted with the Add/Del feature.
The station may have broadcast difficulties. Try another channel.
Use a highly directional outdoor antenna.
The station may have broadcast difficulties. Try another channel.
Adjust the TINT and COLOR in the menu.
If you change the direction of the TV while it is turned on, the
picture could suffer from color shading. If so, turn off the TV and
allow it to cool down for several hours before turning it on again.
Check to see if the TV/AV mode is properly set.
There may be an obstruction between the remote control and the
remote control sensor.
The remote control batteries may be dead. Replace the batteries.
The station may have broadcast difficulties. Try another channel.
Check the antenna connections.
If you are using a VCR, make sure the TV/AV button is set correctly.
Appendix
