Hitachi DS 14DSL Manual

TECHNICAL DATA
AND
SERVICE MANUAL
CORDLESS DRIVER DRILL
DS 14DSL
SPECIFICATIONS AND PARTS ARE SUBJECT TO CHANGE FOR IMPROVEMENT
LIST No. G892 Dec. 2007
D
MODEL
DS 14DSL
Hitachi 
Power Tools

PART
S
DS 14DSL
DESCRIPTION REMARKS
1 311-959 SPECIAL SCREW (LEFT HAND) M6X23 1
2 320-684 DRILL CHUCK 13VLRG-N (W/O CHUCK WRENCH) 1
3 329-086 GEAR BOX ASS'Y 1 INCLUD. 4-8, 10-28
4 329-089 CLUTCH DIAL 1
5 320-758 NUT 1
6 320-757 SPRING 1
7 320-756 THRUST PLATE 1
8 329-087 FRONT CASE 1
9 320-773 CLICK SPRING 1
10 319-744 ROLLER 10
11 306-936 STEEL BALL D5 6
12 328-717 WASHER (B) 1
13 328-718 LOCK RING 1
14 328-721 RING GEAR 1
15 328-720 CARRIER 1
16 328-722 PLANET GEAR (C) SET (4 PCS.) 4
17 320-762 PLATE (B) 1
18 320-763 REAR CASE 1
19 312-712 SCREW SET D3X12 (4 PCS.) 4
20 329-088 SHIFT ARM (A) 1
21 320-765 SLIDE RING GEAR 1
22 328-724 PINION (C) 1
23 320-781 PLANET GEAR (B) SET (4 PCS.) 4
24 328-725 PINION (B) 1
25 328-727 PLANET GEAR (A) SET (4 PCS.) 4
26 328-726 FIRST RING GEAR 1
27 320-768 PLATE (A) 1
28 320-769 MOTOR SPACER 1
29 360-820 ARMATURE PINION SET 1
30 322-520 MAGNET 1
31 322-521 DUST GUARD 1
32 322-993 BRUSH BLOCK 1
33 999-054 CARBON BRUSH 5X6X11.5 (1 PAIR) 2
34 319-918 BRUSH CAP 2
35 313-687 TAPPING SCREW (W/FLANGE) D3X16 (BLACK) 8
36 NAME PLATE 1
37 329-084 HOUSING (A).(B) SET 1
38 328-731 SHIFT KNOB 1
39 329-173 DC-SPEED CONTROL SWITCH 1
40 329-454 PUSHING BUTTON (A) 1
41 HITACHI LABEL 1
42 327-001 M4 TRUSS HD. SCREW (BLACK) 1
43 326-790 HOOK (A) 1
44 306-952 STRAP (BLACK) 1
45 327-002 LOCK NUT M4 (BLACK) 2
46 327-004 PACKING 2
47 328-733 CONTROLLER TERMINAL SET 1
48 329-083 BATTERY BSL 1430 (EUROPE) 2
- 2 - 12 - 07
*ALTERNATIVE PARTS
ITEM
NO. NO. USED
CODE NO.

STANDARD ACCESSORIE
S
DS 14DSL
DESCRIPTION REMARKS
501 CHARGER (MODEL UC 18YRSL) 1
502 328-467 CASE 1
503 983-006 + DRIVER BIT NO. 2 65L 1
OPTIONAL ACCESSORIE
S
DESCRIPTION REMARKS
601 955-657 - DRIVER BIT (A) 3MMX70L 1
602 955-659 - DRIVER BIT (A) 4MMX70L 1
603 955-674 - DRIVER BIT (A) 6MMX70L 1
604 983-004 + DRIVER BIT NO.1 65L 1
605 983-011 + DRIVER BIT NO.3 65L 1
12 - 07 - 3 -
