Holtkoetter Bernie Turbo Series User manual

205 Hardman Avenue South, South Saint Paul, MN 55075
Voice: [phone] • Fax: [phone]
e-mail: [e-mail]
www.holtkoetter.com
ASSEMBLY INSTRUCTIONS FOR
Major lamp parts manufactured in Germany by Holtkötter Leuchten GmbH.
Bulbs manufactured in Germany by Osram GmbH. Final assembly by Holtkötter in South Saint Paul, MN.
Holtkötter ®and Holtkötter Leuchten®are registered trademarks of Holtkötter. All Rights Reserved.
© Holtkötter
Bernie Turbo Series Floor Lamp
No. 6424*P1
Congratulations, you have just purchased the leading-
edge dimming technology from Holtkötter International,
Inc. Our “Dimm-System Punkt 1” (Dimming System Point
1 (*P1)) is specifically designed to provide specialized
features for ease and convenience of use.
Features of “Dimm System Punkt 1” include:
Point Dimming - the lamp may be turned on
with a single click of the P1 dimmer.
Soft On - the lamp will come on low and continue to
brighten to full brightness. This allows the eye to adjust
to a gradual increase in light.
Soft / Delayed Off - turn the lamp off with a single
click of the P1 dimmer. The lamp will dim to 60%
brightness of the original setting, remaining briefly at
that level to allow you to exit the room; then the lamp
gradually turns itself off. This “soft” off provides a few
moments of light after turning the lamp off, rather
than immediate darkness as is the case with other
switches.
Dimming Cycle - to adjust the lamp to the perfect
light level for any situation, press and hold the P1
dimmer. The dimmer will cycle through all dimming levels. When the lamp
achieves the light level of your choice, release the P1 dimmer.
Care Instructions
Use only a soft, dry cloth to clean. If necessary, a slightly damp, soft cloth can be used to spot
clean. Do not use common household cleaners on lamps or fixtures, as the lacquer on the
outside of the brass may be damaged as a result.
UL requires the following safety instructions:
Lighted lamp is HOT! WARNING: Improper use of this fixture may increase the risk of FIRE,
ELECTRICAL SHOCK, EXPOSURE TO EXCESSIVE RADIATION or INJURY TO PERSONS.
IN ORDER TO REDUCE THESE RISKS, PLEASE FOLLOW THESE SAFETY INSTRUCTIONS:
1. Before replacing bulb, UNPLUG lamp and allow bulb to cool.
2. DO NOT touch hot glass shield or operate lamp with a missing glass shield.
3. Keep lamp away from materials that may burn.
4. Do not remain in light if skin feels warm or look directly at a lighted bulb.
5. Use of the Osram bulb provided with this lamp prevents exposure to excessive UV Radiation.
Use of any other bulb may cause a risk of exposure to excessive UV Radiation. Use of any
other bulb may also cause a risk of overheating or may rupture the bulb.
6424/1*P1

e-mail: [e-mail]
www.holtkoetter.com
ASSEMBLY INSTRUCTIONS FOR
Major lamp parts manufactured in Germany by Holtkötter Leuchten GmbH.
Bulbs manufactured in Germany by Osram GmbH. Final assembly by Holtkötter in South Saint Paul, MN.
Holtkötter ®and Holtkötter Leuchten®are registered trademarks of Holtkötter. All Rights Reserved.
© Holtkötter
This low-voltage halogen floor lamp comes fully assembled.
Glass Shield and Bulb Replacement Instructions
1. Be sure to turn the lamp off and allow it to cool before attempting glass shield and/or bulb
replacement.
2. The glass shield (A) is held in place with a metal spring clip (B). To remove this clip, hold
each side and pull firmly from the socket. This will release the glass shield. (Skip to Step 5
unless replacing bulb).
3. To remove the old bulb (C), pull it straight out of the socket. For a replacement bulb, use
only Osram Halostar ECO/IRC, max. 60 W. (Order Code: 9250*060-HSTAR).
4. Install the new bulb, being careful not to touch the bulb envelope
with your bare hands. Hold the bulb at the porcelain grip and push it
straight into the socket.
5. Press the metal clip over the shield and onto the socket, making sure that both sides snap
into place.
Diagram
Replace the Fuse
An integrated fuse to protect the dimming circuit can be found in the box housing
the plug. Please check the fuse first, in case the lamp does not come on.
A four (4) Amp replacement fuse can be found on the Holtkoetter parts website:
http://www.holtkoetter.com/products/parts/fuse-4amp.aspx or at your local automotive
or electronics parts store.
1. Unscrew the screws (D) located on each corner of the plug housing (E).
2. Open the housing to reveal the circuit board.
3. Locate the black box inside labeled Fuse 5 x 20 (F) and open it.
4. Remove and discard old fuse; replace with the new fuse.
5. Close the small fuse box and the plug housing.
6. Replace and tighten the four screws on the outside of the plug housing.
BC A
F
DE
Bernie Turbo Series Floor Lamp
No. 6424*P1
