Henk 70Installation drawings

Marking Lenght pcs
WALL LOG 70x146
SR-1 70x145 RAFTER 4207 2
HITTING BLOCK 70mm 2
03/10/2022

KL-1 Roof board 28x120 MT10 2916 38+2
AR-1 45x95 Floor Frame Cutout ! 3760 1
AR-2 45x95 Floor Frame 3760 1
AR-3 45x70 Floor Frame 45x70 2000 1
AR-4 45x95 Floor Frame 2000 13
PL-1 28x120 Floor board (Front room) 1796 21
PL-2 28x120 Floor board (Sauna room) 1765 21
SR-2 45x45 Roof edge support 4207 2
PP-1 15x55 base- and ceiling boards ~2,1 14
RL-1 18x95 Roof moulding (front and back) ~4,3 2
RL-2 18x95 Roof moulding (sides) ~3,0 2
LR-1 45x45 ceiling beams 1795 2
LR-2 15x55 distance board for ceiling 2000 5
SL-1 STP 14x121 Sauna ceiling paneling 1795 20
18x95 Door mouldings EXTRA ~2,4 2
UK-1 18x95 Door mouldings 1890 8
UK-2 18x95 Door mouldings 890 2
UK-3 18x95 Door mouldings 790 2
UK-4 15x55 Door Moulding 670 2
UK-5 15x55 Door Moulding 570 2
AK-1 18x95 Window Mouldings 1310 2
AK-2 18x95 Window Mouldings 1060 2
AK-3 18x95 Window Mouldings 625 4

U-1 Wood frame outside door 70x690x1860 Bronze 1
U-2 Glass door 70x590x1860 Bronze 1
A-1 Window 70x1100x540 Bronze 1
TE-1 28x70+28x30 T- shape fillet 1860 4
TE-2 28x70+28x30 T- shape fillet 540 2
Sauna bench 600x1992 1
Sauna bench 500x1992 1
Sauna bench 300x1992 1
Sauna bench 500x1196 1
Sauna bench 200x960 1
Bench support set 45x45 1
Extra bench support 45x45x1000 + M10 1
RN-1 Water drainage detail 1
3 MM SLOPE DETAIL UNDER FLOORBOARD 1995 1
6 MM SLOPE DETAIL UNDER FLOORBOARD 1995 1
9 MM SLOPE DETAIL UNDER FLOORBOARD 1995 1
12 MM SLOPE DETAIL UNDER FLOORBOARD 1995 1
SPU INSULATION 30x600x1200 6

GSPublisherVersion 92.3.83.100
Henk 70
Threaded rod M10 2420 3
Threaded rod M10 2140 3
Drive nut M10 6
Washer M10 6
Nut M10 6
Screw 3,5x40 A2 RV mouldings 200
Screw 3,5x50 Floor board 400
Screw 4,2x55 RV roof mouldings 100
Screw 4,5x70 Bench supports/ sauna ceiling 100
Screw 5,0x90 Floor frame, wall connections 200
KRUVI 6x180 rafters, wall connections 50
Nail 1.4x40 mouldings + ceiling panels 200
Nail 75 MM roof boards 400
Foil tape 1
VENTILATION LOUVER WOOD 2
VENTILATION GRID METAL 2
Installation manual 1
BENCH SKIRT 1992 1
BENCH SKIRT 1241 1
HEATER GUARD DIY (PREMIUM) 1
extra WATER DRAINAGE GUTTER 1995 + LEFT 1
EXTRAS

GSPublisherVersion 89.3.84.100
Hanko 70_82106.bvn6.08.2021Plaan110 x 5470 x 186
60 x 186
AA11BBCC22SR-1SR-11 8691 869
692 000692 138
691 800691 800694 033
692 000692 1382 069
2003 8072004 007
Floor plan

GSPublisherVersion 89.3.84.100
+3mm+6mm+9mm
A
B C
1
2
3760
2090 2000
AR-1
AR-2
AR-3 (45x70)
AR-4 AR-4 AR-4 AR-4 AR-4 AR-4 AR-4 AR-4 AR-4 AR-4 AR-4 AR-4
AR-4
45
45
386 386 386 386 397 397 397 397
1812
+12mm+9mm+6mm+3mmAttatch slope details to floor frame to give incline for water drainage*Check that Floor Frame diagonals are the same lenght!A=B!Floor frame
A
B

GSPublisherVersion 89.3.84.100
Water drainage detailScrews 90mm01* Use 90mm screwsTAKE CARE! WATER DRAINAGE DETAIL HAS SHARP EDGES!Install water drainage detail before first wall logFloor frame01

GSPublisherVersion 89.3.84.100
FLOOR BOARDS
AB C
1
2
1765 1796
PL-2 PL-1
+3 +6 +9 +12
FIX THE FLOOR MOULDING WITH THE 3x40 MM STAINLESS SCREW
leave the 2-3 mm gap with walls
FIX THE FLOOR BOARDS WITH THE SCREWS (DIAGONALLY, NON VISIBLE)
BEFORE INSTALLING THE FLOOR BOARDS, INSTALL THE WATER DRAINAGE GUTTER
AND PLYWOOD BOARDS 3, 6, 9, 12 MM
+3 +6 +9 +12
Floor boards

GSPublisherVersion 92.3.83.100
+12mm+9mm+6mm+3mm15x55 base board+5mm+0mmFloor boards1. Attach slope details to give floor boards incline3. Attach base board 15x55 to water drainage detail to fix water drainage detail to wallIncline2. Install water drainage detail +5mm to give incline

GSPublisherVersion 89.3.84.100
25mm
Screw 180mmScrew 90mmFirst log wall rowInstall first log wall row to the floor frame with 90mm and 180mm screws(Suggestion: Drill hole before screwing)Leave 25mm cap between outer wall log and floor frame

GSPublisherVersion 89.3.84.100
Screw 180mmScrew 180mmWall log installationTo install wall logs, use hammer and hitting blockIf the wall log is bent (swelling and shrinking) then use 180mm screws

GSPublisherVersion 89.3.84.100
KEERMELATID
SEINAPRUSSE PAIGALDADES JÄLGI,
ET IGASREASOLEKS AUK OLEMAS!
LÕÕKMUTTER
KEERMELATT
JÄTKUMUTTER
SEIB
RUTTEM
Keermelattide paigaldusSeinaprusside paigaldusel jälgida, et igas reas oleks auk olemas. Vajadusel puurida uus auk.Kui keermelatt koosneb mitmest osast, siis kasutada jätkumutrit.
THREADED RODS
WHEN INSTALLING THE WALL LOGS,
PLEASE CHECK THAT ALL THE HOLES ARE DRILLED!
LENGTHENING BOLT
DRIVE NUT
THREADED ROD
WASHER
NUT
Threaded rodsIf threaded rod is in multiple pieces, use lenghtening boltWhen installing wall logs, check for threaded rod holes in every wall log. If needed, drill a new hole.

GSPublisherVersion 89.3.84.100
Hanko 70_82106.bvn6.08.2021Sein C C-1-1 2 339 C-2-1 2 339 C-3-1 2 339 C-4-1 2 339 C-5-1 2 339 C-6-1 2 339 C-7-1 2 339 C-8-1 2 339 C-9-1 2 339 C-10-1 2 339 C-11-1 2 339 C-12-1 2 339 C-13-1 2 339 C-14-1 2 339 C-15-1 2 339 C-16-1 2 339 C-17-1 1 653 C-18-1 6202 420M102 140M1012
2 448
1352 0691352 3397°
Wall layoutsWall C

GSPublisherVersion 89.3.84.100
Hanko 70_82106.bvn6.08.2021Sein B84165668 B-1-1 2 339 B-2-1 841 B-2-2 841 B-3-1 841 B-3-2 841 B-4-1 841 B-4-2 841 B-5-1 841 B-5-2 841 B-6-1 841 B-6-2 841 B-7-1 841 B-7-2 841 B-8-1 841 B-8-2 841 B-9-1 841 B-9-2 841 B-10-1 841 B-10-2 841 B-11-1 841 B-11-2 841 B-12-1 841 B-12-2 841 B-13-1 841 B-13-2 841 B-14-1 841 B-14-2 84184165668 B-15-1 2 339 B-16-1 2 339 B-17-1 1 653 B-18-1 6202 420M102 140M10121357076567071351352 0691352 339
2 448681 904
8°
7oWall BWall layouts

GSPublisherVersion 89.3.84.100
Hanko 70_82106.bvn6.08.2021Sein A A-1-1 2 339 A-2-1 2 339 A-3-1 2 339 A-4-1 2 339 A-5-1 2 339 A-6-1 2 339 A-7-1 2 339 A-8-1 2 339 A-9-1 2 339 A-10-1 2 339 A-11-1 2 339 A-12-1 2 339 A-13-1 2 339 A-14-1 2 339 A-15-1 2 339 A-16-1 2 339 A-17-1 1 653 A-18-1 6202 420M102 140M10121352 0691352 339
2 448
7°
2-1-1 4 007 2-2-1 4 007 2-3-1 4 007 2-4-1 4 007 2-5-1 4 007 2-6-1 4 007 2-7-1 4 007 2-8-1 4 007 2-9-1 4 007 2-10-1 4 007 2-11-1 4 007 2-12-1 4 007 2-13-1 4 007 2-14-1 4 007 2-15-1 4 007 2-16-1 4 007 2-17-1 4 707 2-18-1 4 8071 35272 2-19-1 1 35255272 2-19-21 17572 2-19-355272 2-19-482272 2-19-5
AC 90x90x2 116*
+0,028IRON?BCA7001351 8691 8691341004 007
2 516
WALL 2
GSPublisherVersion 49.3.94.100PATIO L PLUSGSPublisherVersion 31.9.100.100PATIO LGSPublisherVersion 33.9.100.100PATIO M
GSPublisherVersion 28.4.100.100PATIO S PLUSGSPublisherVersion 7.4.100.100 PATIO SGSPublisherVersion 18.4.100.100 PATIO XSGSPublisherVersion 48.4.100.100PATIO XXSInstall hole undersauna ceilingInstall hole undersauna benchesVentilation Louvre and ventilation gridTo install ventilation louvre and ventilation grid use saw or diamond drill bit.=10cmVentilation louvre woodVentilation gridPATIO SInstall hole undersauna benches Install hole undersauna ceiling
Install hole undersauna ceilingInstall hole undersauna benchesInstall holes undersauna ceilingInstall holes undersauna ceilingInstall holes undersauna benchesInstall holes underceilingInstall holes under ceilingInstall holes undersauna benches
GSPublisherVersion 49.3.94.100PATIO L PLUSGSPublisherVersion 31.9.100.100PATIO LGSPublisherVersion 33.9.100.100PATIO MGSPublisherVersion 28.4.100.100PATIO S PLUSGSPublisherVersion 7.4.100.100 PATIO SGSPublisherVersion 18.4.100.100 PATIO XSGSPublisherVersion 48.4.100.100PATIO XXSInstall hole undersauna ceilingInstall hole undersauna benchesVentilation Louvre and ventilation gridTo install ventilation louvre and ventilation grid use saw or diamond drill bit.=10cmVentilation louvre woodVentilation gridPATIO SInstall hole undersauna benches Install hole undersauna ceiling Install hole undersauna ceilingInstall hole undersauna benchesInstall holes undersauna ceilingInstall holes undersauna ceilingInstall holes undersauna benchesInstall holes underceilingInstall holes under ceilingInstall holes undersauna benches
GSPublisherVersion 49.3.94.100PATIO L PLUSGSPublisherVersion 31.9.100.100PATIO LGSPublisherVersion 33.9.100.100PATIO MGSPublisherVersion 28.4.100.100PATIO S PLUSGSPublisherVersion 7.4.100.100 PATIO SGSPublisherVersion 18.4.100.100 PATIO XSGSPublisherVersion 48.4.100.100PATIO XXSInstall hole undersauna ceilingInstall hole undersauna benchesVentilation Louvre and ventilation gridTo install ventilation louvre and ventilation grid use saw or diamond drill bit.=10cmVentilation louvre woodVentilation gridPATIO SInstall hole undersauna benches Install hole undersauna ceiling Install hole undersauna ceilingInstall hole undersauna benchesInstall holes undersauna ceilingInstall holes undersauna ceilingInstall holes undersauna benchesInstall holes underceilingInstall holes under ceilingInstall holes undersauna benches
GSPublisherVersion 49.3.94.100PATIO L PLUSGSPublisherVersion 31.9.100.100PATIO LGSPublisherVersion 33.9.100.100PATIO MGSPublisherVersion 28.4.100.100PATIO S PLUSGSPublisherVersion 7.4.100.100 PATIO SGSPublisherVersion 18.4.100.100 PATIO XSGSPublisherVersion 48.4.100.100PATIO XXSInstall hole undersauna ceilingInstall hole undersauna benchesVentilation Louvre and ventilation gridTo install ventilation louvre and ventilation grid use saw or diamond drill bit.=10cmVentilation louvre woodVentilation gridPATIO SInstall hole undersauna benches Install hole undersauna ceiling Install hole undersauna ceilingInstall hole undersauna benchesInstall holes undersauna ceilingInstall holes undersauna ceilingInstall holes undersauna benchesInstall holes underceilingInstall holes under ceilingInstall holes undersauna benches
Ventilation grid holeunder sauna ceilingInstall ventilation louvre and ventilation grid using saw or diamond drill
Sein C C-1-1 2 339 C-2-1 2 339 C-3-1 2 339 C-4-1 2 339 C-5-1 2 339 C-6-1 2 339 C-7-1 2 339 C-8-1 2 339 C-9-1 2 339 C-10-1 2 339 C-11-1 2 339 C-12-1 2 339 C-13-1 2 339 C-14-1 2 339 C-15-1 2 339 C-16-1 2 339 C-17-1 3 0383 138 143900 C-18-1 3 139 C-19-1 2 747
AC 90x90x2 184*
+0,028IRON?2 565M122 490M12126991352 0691351002 339
2 584
GSPublisherVersion 49.3.94.100PATIO L PLUSGSPublisherVersion 31.9.100.100PATIO LGSPublisherVersion 33.9.100.100PATIO M
GSPublisherVersion 28.4.100.100PATIO S PLUSGSPublisherVersion 7.4.100.100 PATIO SGSPublisherVersion 18.4.100.100 PATIO XSGSPublisherVersion 48.4.100.100PATIO XXSInstall hole undersauna ceilingInstall hole undersauna benchesVentilation Louvre and ventilation gridTo install ventilation louvre and ventilation grid use saw or diamond drill bit.=10cmVentilation louvre woodVentilation gridPATIO SInstall hole undersauna benches Install hole undersauna ceiling
Install hole undersauna ceilingInstall hole undersauna benchesInstall holes undersauna ceilingInstall holes undersauna ceilingInstall holes undersauna benchesInstall holes underceilingInstall holes under ceilingInstall holes undersauna benches
GSPublisherVersion 49.3.94.100PATIO L PLUSGSPublisherVersion 31.9.100.100PATIO LGSPublisherVersion 33.9.100.100PATIO MGSPublisherVersion 28.4.100.100PATIO S PLUSGSPublisherVersion 7.4.100.100 PATIO SGSPublisherVersion 18.4.100.100 PATIO XSGSPublisherVersion 48.4.100.100PATIO XXSInstall hole undersauna ceilingInstall hole undersauna benchesVentilation Louvre and ventilation gridTo install ventilation louvre and ventilation grid use saw or diamond drill bit.=10cmVentilation louvre woodVentilation gridPATIO SInstall hole undersauna benches Install hole undersauna ceiling Install hole undersauna ceilingInstall hole undersauna benchesInstall holes undersauna ceilingInstall holes undersauna ceilingInstall holes undersauna benchesInstall holes underceilingInstall holes under ceilingInstall holes undersauna benches
GSPublisherVersion 49.3.94.100PATIO L PLUSGSPublisherVersion 31.9.100.100PATIO LGSPublisherVersion 33.9.100.100PATIO MGSPublisherVersion 28.4.100.100PATIO S PLUSGSPublisherVersion 7.4.100.100 PATIO SGSPublisherVersion 18.4.100.100 PATIO XSGSPublisherVersion 48.4.100.100PATIO XXSInstall hole undersauna ceilingInstall hole undersauna benchesVentilation Louvre and ventilation gridTo install ventilation louvre and ventilation grid use saw or diamond drill bit.=10cmVentilation louvre woodVentilation gridPATIO SInstall hole undersauna benches Install hole undersauna ceiling Install hole undersauna ceilingInstall hole undersauna benchesInstall holes undersauna ceilingInstall holes undersauna ceilingInstall holes undersauna benchesInstall holes underceilingInstall holes under ceilingInstall holes undersauna benches
GSPublisherVersion 49.3.94.100PATIO L PLUSGSPublisherVersion 31.9.100.100PATIO LGSPublisherVersion 33.9.100.100PATIO MGSPublisherVersion 28.4.100.100PATIO S PLUSGSPublisherVersion 7.4.100.100 PATIO SGSPublisherVersion 18.4.100.100 PATIO XSGSPublisherVersion 48.4.100.100PATIO XXSInstall hole undersauna ceilingInstall hole undersauna benchesVentilation Louvre and ventilation gridTo install ventilation louvre and ventilation grid use saw or diamond drill bit.=10cmVentilation louvre woodVentilation gridPATIO SInstall hole undersauna benches Install hole undersauna ceiling Install hole undersauna ceilingInstall hole undersauna benchesInstall holes undersauna ceilingInstall holes undersauna ceilingInstall holes undersauna benchesInstall holes underceilingInstall holes under ceilingInstall holes undersauna benches
Ventilation grid holeunder sauna benchesWALL CInstall ventilation louvre and ventilation grid using saw or diamond drill
Sein C C-1-1 2 339 C-2-1 2 339 C-3-1 2 339 C-4-1 2 339 C-5-1 2 339 C-6-1 2 339 C-7-1 2 339 C-8-1 2 339 C-9-1 2 339 C-10-1 2 339 C-11-1 2 339 C-12-1 2 339 C-13-1 2 339 C-14-1 2 339 C-15-1 2 339 C-16-1 2 339 C-17-1 3 0383 138 143900 C-18-1 3 139 C-19-1 2 747
AC 90x90x2 184*
+0,028IRON?2 565M122 490M12126991352 0691351002 339
2 584
GSPublisherVersion 49.3.94.100PATIO L PLUSGSPublisherVersion 31.9.100.100PATIO LGSPublisherVersion 33.9.100.100PATIO M
GSPublisherVersion 28.4.100.100PATIO S PLUSGSPublisherVersion 7.4.100.100 PATIO SGSPublisherVersion 18.4.100.100 PATIO XSGSPublisherVersion 48.4.100.100PATIO XXSInstall hole undersauna ceilingInstall hole undersauna benchesVentilation Louvre and ventilation gridTo install ventilation louvre and ventilation grid use saw or diamond drill bit.=10cmVentilation louvre woodVentilation gridPATIO SInstall hole undersauna benches Install hole undersauna ceiling
Install hole undersauna ceilingInstall hole undersauna benchesInstall holes undersauna ceilingInstall holes undersauna ceilingInstall holes undersauna benchesInstall holes underceilingInstall holes under ceilingInstall holes undersauna benches
GSPublisherVersion 49.3.94.100PATIO L PLUSGSPublisherVersion 31.9.100.100PATIO LGSPublisherVersion 33.9.100.100PATIO MGSPublisherVersion 28.4.100.100PATIO S PLUSGSPublisherVersion 7.4.100.100 PATIO SGSPublisherVersion 18.4.100.100 PATIO XSGSPublisherVersion 48.4.100.100PATIO XXSInstall hole undersauna ceilingInstall hole undersauna benchesVentilation Louvre and ventilation gridTo install ventilation louvre and ventilation grid use saw or diamond drill bit.=10cmVentilation louvre woodVentilation gridPATIO SInstall hole undersauna benches Install hole undersauna ceiling Install hole undersauna ceilingInstall hole undersauna benchesInstall holes undersauna ceilingInstall holes undersauna ceilingInstall holes undersauna benchesInstall holes underceilingInstall holes under ceilingInstall holes undersauna benches
GSPublisherVersion 49.3.94.100PATIO L PLUSGSPublisherVersion 31.9.100.100PATIO LGSPublisherVersion 33.9.100.100PATIO MGSPublisherVersion 28.4.100.100PATIO S PLUSGSPublisherVersion 7.4.100.100 PATIO SGSPublisherVersion 18.4.100.100 PATIO XSGSPublisherVersion 48.4.100.100PATIO XXSInstall hole undersauna ceilingInstall hole undersauna benchesVentilation Louvre and ventilation gridTo install ventilation louvre and ventilation grid use saw or diamond drill bit.=10cmVentilation louvre woodVentilation gridPATIO SInstall hole undersauna benches Install hole undersauna ceiling Install hole undersauna ceilingInstall hole undersauna benchesInstall holes undersauna ceilingInstall holes undersauna ceilingInstall holes undersauna benchesInstall holes underceilingInstall holes under ceilingInstall holes undersauna benches
GSPublisherVersion 49.3.94.100PATIO L PLUSGSPublisherVersion 31.9.100.100PATIO LGSPublisherVersion 33.9.100.100PATIO MGSPublisherVersion 28.4.100.100PATIO S PLUSGSPublisherVersion 7.4.100.100 PATIO SGSPublisherVersion 18.4.100.100 PATIO XSGSPublisherVersion 48.4.100.100PATIO XXSInstall hole undersauna ceilingInstall hole undersauna benchesVentilation Louvre and ventilation gridTo install ventilation louvre and ventilation grid use saw or diamond drill bit.=10cmVentilation louvre woodVentilation gridPATIO SInstall hole undersauna benches Install hole undersauna ceiling Install hole undersauna ceilingInstall hole undersauna benchesInstall holes undersauna ceilingInstall holes undersauna ceilingInstall holes undersauna benchesInstall holes underceilingInstall holes under ceilingInstall holes undersauna benches
Ventilation grid holeunder sauna benchesWALL CInstall ventilation louvre and ventilation grid using saw or diamond drill
Sein C C-1-1 2 339 C-2-1 2 339 C-3-1 2 339 C-4-1 2 339 C-5-1 2 339 C-6-1 2 339 C-7-1 2 339 C-8-1 2 339 C-9-1 2 339 C-10-1 2 339 C-11-1 2 339 C-12-1 2 339 C-13-1 2 339 C-14-1 2 339 C-15-1 2 339 C-16-1 2 339 C-17-1 3 0383 138 143900 C-18-1 3 139 C-19-1 2 747
AC 90x90x2 184*
+0,028IRON?2 565M122 490M12126991352 0691351002 339
2 584
GSPublisherVersion 49.3.94.100PATIO L PLUSGSPublisherVersion 31.9.100.100PATIO LGSPublisherVersion 33.9.100.100PATIO M
GSPublisherVersion 28.4.100.100PATIO S PLUSGSPublisherVersion 7.4.100.100 PATIO SGSPublisherVersion 18.4.100.100 PATIO XSGSPublisherVersion 48.4.100.100PATIO XXSInstall hole undersauna ceilingInstall hole undersauna benchesVentilation Louvre and ventilation gridTo install ventilation louvre and ventilation grid use saw or diamond drill bit.=10cmVentilation louvre woodVentilation gridPATIO SInstall hole undersauna benches Install hole undersauna ceiling
Install hole undersauna ceilingInstall hole undersauna benchesInstall holes undersauna ceilingInstall holes undersauna ceilingInstall holes undersauna benchesInstall holes underceilingInstall holes under ceilingInstall holes undersauna benches
GSPublisherVersion 49.3.94.100PATIO L PLUSGSPublisherVersion 31.9.100.100PATIO LGSPublisherVersion 33.9.100.100PATIO MGSPublisherVersion 28.4.100.100PATIO S PLUSGSPublisherVersion 7.4.100.100 PATIO SGSPublisherVersion 18.4.100.100 PATIO XSGSPublisherVersion 48.4.100.100PATIO XXSInstall hole undersauna ceilingInstall hole undersauna benchesVentilation Louvre and ventilation gridTo install ventilation louvre and ventilation grid use saw or diamond drill bit.=10cmVentilation louvre woodVentilation gridPATIO SInstall hole undersauna benches Install hole undersauna ceiling Install hole undersauna ceilingInstall hole undersauna benchesInstall holes undersauna ceilingInstall holes undersauna ceilingInstall holes undersauna benchesInstall holes underceilingInstall holes under ceilingInstall holes undersauna benches
GSPublisherVersion 49.3.94.100PATIO L PLUSGSPublisherVersion 31.9.100.100PATIO LGSPublisherVersion 33.9.100.100PATIO MGSPublisherVersion 28.4.100.100PATIO S PLUSGSPublisherVersion 7.4.100.100 PATIO SGSPublisherVersion 18.4.100.100 PATIO XSGSPublisherVersion 48.4.100.100PATIO XXSInstall hole undersauna ceilingInstall hole undersauna benchesVentilation Louvre and ventilation gridTo install ventilation louvre and ventilation grid use saw or diamond drill bit.=10cmVentilation louvre woodVentilation gridPATIO SInstall hole undersauna benches Install hole undersauna ceiling Install hole undersauna ceilingInstall hole undersauna benchesInstall holes undersauna ceilingInstall holes undersauna ceilingInstall holes undersauna benchesInstall holes underceilingInstall holes under ceilingInstall holes undersauna benches
GSPublisherVersion 49.3.94.100PATIO L PLUSGSPublisherVersion 31.9.100.100PATIO LGSPublisherVersion 33.9.100.100PATIO MGSPublisherVersion 28.4.100.100PATIO S PLUSGSPublisherVersion 7.4.100.100 PATIO SGSPublisherVersion 18.4.100.100 PATIO XSGSPublisherVersion 48.4.100.100PATIO XXSInstall hole undersauna ceilingInstall hole undersauna benchesVentilation Louvre and ventilation gridTo install ventilation louvre and ventilation grid use saw or diamond drill bit.=10cmVentilation louvre woodVentilation gridPATIO SInstall hole undersauna benches Install hole undersauna ceiling Install hole undersauna ceilingInstall hole undersauna benchesInstall holes undersauna ceilingInstall holes undersauna ceilingInstall holes undersauna benchesInstall holes underceilingInstall holes under ceilingInstall holes undersauna benches
Ventilation grid holeunder sauna benchesWALL CInstall ventilation louvre and ventilation grid using saw or diamond drill
Wall layoutsWall AVentilation hole under sauna bench

GSPublisherVersion 89.3.84.100
Hanko 70_82106.bvn6.08.2021Sein 2 2-1-1 4 007 2-2-1 4 007 2-3-1 4 007 2-4-1 4 007 2-5-1 4 007 2-6-1 4 007 2-7-1 4 007 2-8-1 4 007 2-9-1 4 007 2-10-1 4 007 2-11-1 4 007 2-12-1 4 007 2-13-1 4 007 2-14-1 4 007 2-15-1 4 00714 2070 2-16-1 4 208CBA1001351 8691 8691341004 007
2 108
2-1-1 4 007 2-2-1 4 007 2-3-1 4 007 2-4-1 4 007 2-5-1 4 007 2-6-1 4 007 2-7-1 4 007 2-8-1 4 007 2-9-1 4 007 2-10-1 4 007 2-11-1 4 007 2-12-1 4 007 2-13-1 4 007 2-14-1 4 007 2-15-1 4 007 2-16-1 4 007 2-17-1 4 707 2-18-1 4 8071 35272 2-19-1 1 35255272 2-19-21 17572 2-19-355272 2-19-482272 2-19-5
AC 90x90x2 116*
+0,028IRON?BCA7001351 8691 8691341004 007
2 516
WALL 2
GSPublisherVersion 49.3.94.100PATIO L PLUSGSPublisherVersion 31.9.100.100PATIO LGSPublisherVersion 33.9.100.100PATIO M
GSPublisherVersion 28.4.100.100PATIO S PLUSGSPublisherVersion 7.4.100.100 PATIO SGSPublisherVersion 18.4.100.100 PATIO XSGSPublisherVersion 48.4.100.100PATIO XXSInstall hole undersauna ceilingInstall hole undersauna benchesVentilation Louvre and ventilation gridTo install ventilation louvre and ventilation grid use saw or diamond drill bit.=10cmVentilation louvre woodVentilation gridPATIO SInstall hole undersauna benches Install hole undersauna ceiling
Install hole undersauna ceilingInstall hole undersauna benchesInstall holes undersauna ceilingInstall holes undersauna ceilingInstall holes undersauna benchesInstall holes underceilingInstall holes under ceilingInstall holes undersauna benches
GSPublisherVersion 49.3.94.100PATIO L PLUSGSPublisherVersion 31.9.100.100PATIO LGSPublisherVersion 33.9.100.100PATIO MGSPublisherVersion 28.4.100.100PATIO S PLUSGSPublisherVersion 7.4.100.100 PATIO SGSPublisherVersion 18.4.100.100 PATIO XSGSPublisherVersion 48.4.100.100PATIO XXSInstall hole undersauna ceilingInstall hole undersauna benchesVentilation Louvre and ventilation gridTo install ventilation louvre and ventilation grid use saw or diamond drill bit.=10cmVentilation louvre woodVentilation gridPATIO SInstall hole undersauna benches Install hole undersauna ceiling Install hole undersauna ceilingInstall hole undersauna benchesInstall holes undersauna ceilingInstall holes undersauna ceilingInstall holes undersauna benchesInstall holes underceilingInstall holes under ceilingInstall holes undersauna benches
GSPublisherVersion 49.3.94.100PATIO L PLUSGSPublisherVersion 31.9.100.100PATIO LGSPublisherVersion 33.9.100.100PATIO MGSPublisherVersion 28.4.100.100PATIO S PLUSGSPublisherVersion 7.4.100.100 PATIO SGSPublisherVersion 18.4.100.100 PATIO XSGSPublisherVersion 48.4.100.100PATIO XXSInstall hole undersauna ceilingInstall hole undersauna benchesVentilation Louvre and ventilation gridTo install ventilation louvre and ventilation grid use saw or diamond drill bit.=10cmVentilation louvre woodVentilation gridPATIO SInstall hole undersauna benches Install hole undersauna ceiling Install hole undersauna ceilingInstall hole undersauna benchesInstall holes undersauna ceilingInstall holes undersauna ceilingInstall holes undersauna benchesInstall holes underceilingInstall holes under ceilingInstall holes undersauna benches
GSPublisherVersion 49.3.94.100PATIO L PLUSGSPublisherVersion 31.9.100.100PATIO LGSPublisherVersion 33.9.100.100PATIO MGSPublisherVersion 28.4.100.100PATIO S PLUSGSPublisherVersion 7.4.100.100 PATIO SGSPublisherVersion 18.4.100.100 PATIO XSGSPublisherVersion 48.4.100.100PATIO XXSInstall hole undersauna ceilingInstall hole undersauna benchesVentilation Louvre and ventilation gridTo install ventilation louvre and ventilation grid use saw or diamond drill bit.=10cmVentilation louvre woodVentilation gridPATIO SInstall hole undersauna benches Install hole undersauna ceiling Install hole undersauna ceilingInstall hole undersauna benchesInstall holes undersauna ceilingInstall holes undersauna ceilingInstall holes undersauna benchesInstall holes underceilingInstall holes under ceilingInstall holes undersauna benches
Ventilation grid holeunder sauna ceilingInstall ventilation louvre and ventilation grid using saw or diamond drill
Sein C C-1-1 2 339 C-2-1 2 339 C-3-1 2 339 C-4-1 2 339 C-5-1 2 339 C-6-1 2 339 C-7-1 2 339 C-8-1 2 339 C-9-1 2 339 C-10-1 2 339 C-11-1 2 339 C-12-1 2 339 C-13-1 2 339 C-14-1 2 339 C-15-1 2 339 C-16-1 2 339 C-17-1 3 0383 138 143900 C-18-1 3 139 C-19-1 2 747
AC 90x90x2 184*
+0,028IRON?2 565M122 490M12126991352 0691351002 339
2 584
GSPublisherVersion 49.3.94.100PATIO L PLUSGSPublisherVersion 31.9.100.100PATIO LGSPublisherVersion 33.9.100.100PATIO M
GSPublisherVersion 28.4.100.100PATIO S PLUSGSPublisherVersion 7.4.100.100 PATIO SGSPublisherVersion 18.4.100.100 PATIO XSGSPublisherVersion 48.4.100.100PATIO XXSInstall hole undersauna ceilingInstall hole undersauna benchesVentilation Louvre and ventilation gridTo install ventilation louvre and ventilation grid use saw or diamond drill bit.=10cmVentilation louvre woodVentilation gridPATIO SInstall hole undersauna benches Install hole undersauna ceiling
Install hole undersauna ceilingInstall hole undersauna benchesInstall holes undersauna ceilingInstall holes undersauna ceilingInstall holes undersauna benchesInstall holes underceilingInstall holes under ceilingInstall holes undersauna benches
GSPublisherVersion 49.3.94.100PATIO L PLUSGSPublisherVersion 31.9.100.100PATIO LGSPublisherVersion 33.9.100.100PATIO MGSPublisherVersion 28.4.100.100PATIO S PLUSGSPublisherVersion 7.4.100.100 PATIO SGSPublisherVersion 18.4.100.100 PATIO XSGSPublisherVersion 48.4.100.100PATIO XXSInstall hole undersauna ceilingInstall hole undersauna benchesVentilation Louvre and ventilation gridTo install ventilation louvre and ventilation grid use saw or diamond drill bit.=10cmVentilation louvre woodVentilation gridPATIO SInstall hole undersauna benches Install hole undersauna ceiling Install hole undersauna ceilingInstall hole undersauna benchesInstall holes undersauna ceilingInstall holes undersauna ceilingInstall holes undersauna benchesInstall holes underceilingInstall holes under ceilingInstall holes undersauna benches
GSPublisherVersion 49.3.94.100PATIO L PLUSGSPublisherVersion 31.9.100.100PATIO LGSPublisherVersion 33.9.100.100PATIO MGSPublisherVersion 28.4.100.100PATIO S PLUSGSPublisherVersion 7.4.100.100 PATIO SGSPublisherVersion 18.4.100.100 PATIO XSGSPublisherVersion 48.4.100.100PATIO XXSInstall hole undersauna ceilingInstall hole undersauna benchesVentilation Louvre and ventilation gridTo install ventilation louvre and ventilation grid use saw or diamond drill bit.=10cmVentilation louvre woodVentilation gridPATIO SInstall hole undersauna benches Install hole undersauna ceiling Install hole undersauna ceilingInstall hole undersauna benchesInstall holes undersauna ceilingInstall holes undersauna ceilingInstall holes undersauna benchesInstall holes underceilingInstall holes under ceilingInstall holes undersauna benches
GSPublisherVersion 49.3.94.100PATIO L PLUSGSPublisherVersion 31.9.100.100PATIO LGSPublisherVersion 33.9.100.100PATIO MGSPublisherVersion 28.4.100.100PATIO S PLUSGSPublisherVersion 7.4.100.100 PATIO SGSPublisherVersion 18.4.100.100 PATIO XSGSPublisherVersion 48.4.100.100PATIO XXSInstall hole undersauna ceilingInstall hole undersauna benchesVentilation Louvre and ventilation gridTo install ventilation louvre and ventilation grid use saw or diamond drill bit.=10cmVentilation louvre woodVentilation gridPATIO SInstall hole undersauna benches Install hole undersauna ceiling Install hole undersauna ceilingInstall hole undersauna benchesInstall holes undersauna ceilingInstall holes undersauna ceilingInstall holes undersauna benchesInstall holes underceilingInstall holes under ceilingInstall holes undersauna benches
Ventilation grid holeunder sauna benchesWALL CInstall ventilation louvre and ventilation grid using saw or diamond drill
Sein C C-1-1 2 339 C-2-1 2 339 C-3-1 2 339 C-4-1 2 339 C-5-1 2 339 C-6-1 2 339 C-7-1 2 339 C-8-1 2 339 C-9-1 2 339 C-10-1 2 339 C-11-1 2 339 C-12-1 2 339 C-13-1 2 339 C-14-1 2 339 C-15-1 2 339 C-16-1 2 339 C-17-1 3 0383 138 143900 C-18-1 3 139 C-19-1 2 747
AC 90x90x2 184*
+0,028IRON?2 565M122 490M12126991352 0691351002 339
2 584
GSPublisherVersion 49.3.94.100PATIO L PLUSGSPublisherVersion 31.9.100.100PATIO LGSPublisherVersion 33.9.100.100PATIO M
GSPublisherVersion 28.4.100.100PATIO S PLUSGSPublisherVersion 7.4.100.100 PATIO SGSPublisherVersion 18.4.100.100 PATIO XSGSPublisherVersion 48.4.100.100PATIO XXSInstall hole undersauna ceilingInstall hole undersauna benchesVentilation Louvre and ventilation gridTo install ventilation louvre and ventilation grid use saw or diamond drill bit.=10cmVentilation louvre woodVentilation gridPATIO SInstall hole undersauna benches Install hole undersauna ceiling
Install hole undersauna ceilingInstall hole undersauna benchesInstall holes undersauna ceilingInstall holes undersauna ceilingInstall holes undersauna benchesInstall holes underceilingInstall holes under ceilingInstall holes undersauna benches
GSPublisherVersion 49.3.94.100PATIO L PLUSGSPublisherVersion 31.9.100.100PATIO LGSPublisherVersion 33.9.100.100PATIO MGSPublisherVersion 28.4.100.100PATIO S PLUSGSPublisherVersion 7.4.100.100 PATIO SGSPublisherVersion 18.4.100.100 PATIO XSGSPublisherVersion 48.4.100.100PATIO XXSInstall hole undersauna ceilingInstall hole undersauna benchesVentilation Louvre and ventilation gridTo install ventilation louvre and ventilation grid use saw or diamond drill bit.=10cmVentilation louvre woodVentilation gridPATIO SInstall hole undersauna benches Install hole undersauna ceiling Install hole undersauna ceilingInstall hole undersauna benchesInstall holes undersauna ceilingInstall holes undersauna ceilingInstall holes undersauna benchesInstall holes underceilingInstall holes under ceilingInstall holes undersauna benches
GSPublisherVersion 49.3.94.100PATIO L PLUSGSPublisherVersion 31.9.100.100PATIO LGSPublisherVersion 33.9.100.100PATIO MGSPublisherVersion 28.4.100.100PATIO S PLUSGSPublisherVersion 7.4.100.100 PATIO SGSPublisherVersion 18.4.100.100 PATIO XSGSPublisherVersion 48.4.100.100PATIO XXSInstall hole undersauna ceilingInstall hole undersauna benchesVentilation Louvre and ventilation gridTo install ventilation louvre and ventilation grid use saw or diamond drill bit.=10cmVentilation louvre woodVentilation gridPATIO SInstall hole undersauna benches Install hole undersauna ceiling Install hole undersauna ceilingInstall hole undersauna benchesInstall holes undersauna ceilingInstall holes undersauna ceilingInstall holes undersauna benchesInstall holes underceilingInstall holes under ceilingInstall holes undersauna benches
GSPublisherVersion 49.3.94.100PATIO L PLUSGSPublisherVersion 31.9.100.100PATIO LGSPublisherVersion 33.9.100.100PATIO MGSPublisherVersion 28.4.100.100PATIO S PLUSGSPublisherVersion 7.4.100.100 PATIO SGSPublisherVersion 18.4.100.100 PATIO XSGSPublisherVersion 48.4.100.100PATIO XXSInstall hole undersauna ceilingInstall hole undersauna benchesVentilation Louvre and ventilation gridTo install ventilation louvre and ventilation grid use saw or diamond drill bit.=10cmVentilation louvre woodVentilation gridPATIO SInstall hole undersauna benches Install hole undersauna ceiling Install hole undersauna ceilingInstall hole undersauna benchesInstall holes undersauna ceilingInstall holes undersauna ceilingInstall holes undersauna benchesInstall holes underceilingInstall holes under ceilingInstall holes undersauna benches
Ventilation grid holeunder sauna benchesWALL CInstall ventilation louvre and ventilation grid using saw or diamond drill
Sein C C-1-1 2 339 C-2-1 2 339 C-3-1 2 339 C-4-1 2 339 C-5-1 2 339 C-6-1 2 339 C-7-1 2 339 C-8-1 2 339 C-9-1 2 339 C-10-1 2 339 C-11-1 2 339 C-12-1 2 339 C-13-1 2 339 C-14-1 2 339 C-15-1 2 339 C-16-1 2 339 C-17-1 3 0383 138 143900 C-18-1 3 139 C-19-1 2 747
AC 90x90x2 184*
+0,028IRON?2 565M122 490M12126991352 0691351002 339
2 584
GSPublisherVersion 49.3.94.100PATIO L PLUSGSPublisherVersion 31.9.100.100PATIO LGSPublisherVersion 33.9.100.100PATIO M
GSPublisherVersion 28.4.100.100PATIO S PLUSGSPublisherVersion 7.4.100.100 PATIO SGSPublisherVersion 18.4.100.100 PATIO XSGSPublisherVersion 48.4.100.100PATIO XXSInstall hole undersauna ceilingInstall hole undersauna benchesVentilation Louvre and ventilation gridTo install ventilation louvre and ventilation grid use saw or diamond drill bit.=10cmVentilation louvre woodVentilation gridPATIO SInstall hole undersauna benches Install hole undersauna ceiling
Install hole undersauna ceilingInstall hole undersauna benchesInstall holes undersauna ceilingInstall holes undersauna ceilingInstall holes undersauna benchesInstall holes underceilingInstall holes under ceilingInstall holes undersauna benches
GSPublisherVersion 49.3.94.100PATIO L PLUSGSPublisherVersion 31.9.100.100PATIO LGSPublisherVersion 33.9.100.100PATIO MGSPublisherVersion 28.4.100.100PATIO S PLUSGSPublisherVersion 7.4.100.100 PATIO SGSPublisherVersion 18.4.100.100 PATIO XSGSPublisherVersion 48.4.100.100PATIO XXSInstall hole undersauna ceilingInstall hole undersauna benchesVentilation Louvre and ventilation gridTo install ventilation louvre and ventilation grid use saw or diamond drill bit.=10cmVentilation louvre woodVentilation gridPATIO SInstall hole undersauna benches Install hole undersauna ceiling Install hole undersauna ceilingInstall hole undersauna benchesInstall holes undersauna ceilingInstall holes undersauna ceilingInstall holes undersauna benchesInstall holes underceilingInstall holes under ceilingInstall holes undersauna benches
GSPublisherVersion 49.3.94.100PATIO L PLUSGSPublisherVersion 31.9.100.100PATIO LGSPublisherVersion 33.9.100.100PATIO MGSPublisherVersion 28.4.100.100PATIO S PLUSGSPublisherVersion 7.4.100.100 PATIO SGSPublisherVersion 18.4.100.100 PATIO XSGSPublisherVersion 48.4.100.100PATIO XXSInstall hole undersauna ceilingInstall hole undersauna benchesVentilation Louvre and ventilation gridTo install ventilation louvre and ventilation grid use saw or diamond drill bit.=10cmVentilation louvre woodVentilation gridPATIO SInstall hole undersauna benches Install hole undersauna ceiling Install hole undersauna ceilingInstall hole undersauna benchesInstall holes undersauna ceilingInstall holes undersauna ceilingInstall holes undersauna benchesInstall holes underceilingInstall holes under ceilingInstall holes undersauna benches
GSPublisherVersion 49.3.94.100PATIO L PLUSGSPublisherVersion 31.9.100.100PATIO LGSPublisherVersion 33.9.100.100PATIO MGSPublisherVersion 28.4.100.100PATIO S PLUSGSPublisherVersion 7.4.100.100 PATIO SGSPublisherVersion 18.4.100.100 PATIO XSGSPublisherVersion 48.4.100.100PATIO XXSInstall hole undersauna ceilingInstall hole undersauna benchesVentilation Louvre and ventilation gridTo install ventilation louvre and ventilation grid use saw or diamond drill bit.=10cmVentilation louvre woodVentilation gridPATIO SInstall hole undersauna benches Install hole undersauna ceiling Install hole undersauna ceilingInstall hole undersauna benchesInstall holes undersauna ceilingInstall holes undersauna ceilingInstall holes undersauna benchesInstall holes underceilingInstall holes under ceilingInstall holes undersauna benches
Ventilation grid holeunder sauna benchesWALL CInstall ventilation louvre and ventilation grid using saw or diamond drill
Wall layoutsVentilation hole under sauna ceilingWall 2

GSPublisherVersion 89.3.84.100
Hanko 70_82106.bvn6.08.2021Sein 1
1-1-1 4 007 1-2-1 2 561 1-2-2 691 1-3-1 2 561 1-3-2 691 1-4-1 2 561 1-4-2 691 1-5-1 2 561 1-5-2 691 1-6-1 2 561 1-6-2 691 1-7-1 2 561 1-7-2 691 1-8-1 2 561 1-8-2 691 1-9-1 2 561 1-9-2 691 1-10-1 2 561 1-10-2 6914871 1668 1-11-1 2 561 1-11-2 691 1-12-1 487 1-12-2 908 1-12-3 691 1-13-1 487 1-13-2 908 1-13-3 691 1-14-1 487 1-14-2 908 1-14-3 691 1-15-1 487 1-15-2 908 1-15-3 6914871 16632 1-16-1 4 007 1-17-1 4 00714 2070 1-18-1 4 208CBA1353521 1663515577565561341001351 8691 8691341004 007
2 3801 420584681 904
Wall layoutsWall 1

GSPublisherVersion 89.3.84.100
Horizontal cut Opening cuttingOpening upper or lower wall log vertical cut is made in site.Cut in site

GSPublisherVersion 89.3.84.100
Screw 180mmRafter 70x145Rafters0202Fix roof rafters to log walls with 180mm screws
SR-1SR-1SR-1
