Holzwurm GERA ADDITION User manual

ASSEMBLY INSTRUCTIONS
GERA ADDITION
Before beginning the assembly of your garden shed, please read the
instructions carefully and follow them closely. By doing so you will avoid
unnecessary problems and save time. It is recommended to start the
assembly process only once all the components of your shed identified have
been identified, analyzed and classified. This notice also contains
recommendations related to maintenance of your shed.

GERA ADDITION P2
A
A
A
P3
P4.1
P5.2
P6
PA3.2 x 13+1 2350 110 28
PA4 x 14 1600 110 28
PA5 x 1 2350 110 28
A
A
A
A
A
B
C
B
C
C
B
A
A
Dimension, mm Details
A B C
PA1 x 13 320 110 28
PA2 x 13 450 110 28
x 1 2350
P1
1680
LIST OF ALL PARTS
Pos. Qty.
C
B
B
C
x2 1600
55 28
219/42 28
88 18
x 27+2 B
C
A
x 2 1720 90 19
x 2 990 35 16
x 2 1175 75 19
2350 120 40
x 2
P2 A
C
B
A
B
B
PA3.1
x 1 909 81 75
PB2.1 x 1 1460 75 81
PC1 x 1 1610 75 66
x 4 1870 35 16
PB1
A
A
P4.2 x 2 1680 75 19
P5.1 x 2 1490 35 16
PB2.2 x 1 1460 75 81
C
B
A
IT B
C
C
A
C
B
A
PA4.1 x 1 1600 110 28

GERA ADDITION P3
Dimension, mm Details
A B C
LIST OF ALL PARTS
Pos. Qty.
x90 x10 x 8
5x702x40 6x70
x 40
3.5x35 m8 m8
x10 x20
A
B
x 1 1455 750 40
P7
x3 x1

GERA ADDITION P4
Position Dimension (mm) Quantity
PA1 320 x 110 x 28 13
PA2 450 x 110 x 28 13
PA3.1 2350 x 55 x 28 1
PA3.2 2350 x 110 x 28 13+1
PA4 1600 x 110 x 28 14
Assembling pillars and gable
PB1
PB2.1
PC1
PA1
PA2
PA3.2
PA4
PA3.1
Position Dimension (mm) Quantity
PB1 909 x 81 x 75 1
PB2.1 1460 x 75 x 81 1
PB2.2 1460 x 75 x 81 1
PC1 1610 x 75 x 66 1
PB2.2
3.5x35mm
x4
Ø M6
x12
x6
6x40 mm
x6
Ø M6

GERA ADDITION P5
Position Dimension (mm) Quantity
PA4.1 1600 x 110 x 28 1
PA5 2350 x 110 x 28 1
Assembling walls
PA5
5x70mm
x2
PA2
PA5
5x70mm
PA3.2
PA4.1

GERA ADDITION P6
Position Dimension (mm) Quantity
P1 1600 x 219/42 x 28 1+1
P2 2350 x 120 x 40 2
Installing roof beams
P1
5x70mm
x2
5x70mm
x4
P2

GERA ADDITION P7
Installing roof beams
Ø M6
x8
Ø M6
x4
x4
x4
~3 cm
~3 cm
6 x 70 mm
3.5 x 35 mm
Position Dimension (inch) Quantity
IT 1870 x 35 x 16 4
IT

GERA ADDITION P8
Position Dimension (mm) Quantity
P3 1680 x 88 x 18 27+2
Installing roof boards
~1,5-2mm
2x40 mm
x81+9
P3

GERA ADDITION P9
Position Dimension (mm) Quantity
P4.1 1720 x 90 x 19 2
P4.2 1680 x 75 x 19 2
P5.1 1490 x 35 x 16 1
P5.2 990 x 35 x 16 1
Fixing fascia
P4.1
3.5x35mm
x6
P5.1
3.5x35mm
x8
3.5x35mm
x6
P5.2
P4.2

GERA ADDITION P10
Position Dimension (mm) Quantity
P6 1175 x 75 x 19 2
Fixing fascia
P6
3.5x35mm
x6
P5.1
P6
P3

GERA ADDITION P11
Position Dimension (mm) Quantity
P7 1455 x 750 x 40 1
Installing the door
ST
x6
3.5x35mm
x3
P7

2350
1628
2076
830
1600
1,60 x 2,35 m, 28 mm 1
1,6 x 2,35,28mm.

1600
1595
450 830 320
1485
28
1781
1610
33
120
75
1,60 x 2,35 m, 28 mm 2
1,6 x 2,35,28mm.

1600 28
1595
1680
42
6°
75
35
1781
1610
120
40
33
120
75
1,60 x 2,35 m, 28 mm 3
1,6 x 2,35,28mm.

2350
1595
1,60 x 2,35 m, 28 mm 4
1,6 x 2,35,28mm.

2076
1610
33
1,60 x 2,35 m, 28 mm 5
1,6 x 2,35,28mm.
